Texas Instruments XIO3130 EVM User Manual

SLLU108 – July 2008

XIO3130 EVM

1.1 Overview

The Texas Instruments XIO3130 EVM is a functional implementation of a four-port PCIe-to-PCIe switch.
The XIO3130 EVM was designed to allow validation of three separate functional modes. In normal mode,
the EVM is configured as a generic PCI Express (PCIe) switch. In hot-plug mode, downstream ports 1 and
2 are configured as hot-pluggable slots. In ExpressCard mode, all three downstream ports are configured
to support the ExpressCard adapter board. The different functional modes are discussed later in this
document.

Figure 1-1 shows the EVM board. There are various jumpers, dipswitches, push buttons, and LEDs to

support the various functional modes. For the board to operate, power must be applied via the peripheral
power connector located to the right side of the board. Endpoints can be plugged directly into any one or
all of the downstream ports. The upstream edge connector can be plugged into any PCIe slot on a
motherboard. Once the EVM with attached endpoints is plugged into a PCIe motherboard and power is
provided to the EVM, nothing else needs to be done in order for the EVM to operate. The two LEDs in the
upper right-hand corner light up when power is applied to the peripheral power connector.

Figure 1-1. EVM Board

SLLU108 – July 2008 XIO3130 EVM 1

Submit Documentation Feedback

Normal-Mode Operation

1.2 Normal-Mode Operation

By default, the EVM should be configured to operate in normal mode. The six jumpers (J7, J11, J13, J14,
J15, and J16) should be covering both pins of each header (see Figure 1-2 ).

www.ti.com

Figure 1-2. Power Jumpers

The dipswitch should be configured with SCL slide switch in the up position and DN1_DPSTRP,
DN2_DPSTRP, and DN3_DPSTRP slide switches in the down position (see Figure 1-3 ). This
configuration enables the EEPROM and disables hot-plug operation.

Figure 1-3. Dipswitch Configuration

The EEPROM (U3) should also be preconfigured for normal-mode operation. See Section 1.5 for an
explanation of how to configure the EEPROM. Upon deassertion of PERST, the XIO3130 automatically
reads data from the EEPROM. This data is used to preset various PCI configuration register bits. For
normal-mode operation, the data in the EEPROM will configure bits in the following registers:

• GPIO C control register (PCI register offset: C0h in upstream bridge)
– PCIE_GPIO12_CTL = 010b – Port 1 ACT_LED0

– PCIE_GPIO13_CTL = 011b – Port 2 ACT_LED1
– PCIE_GPIO14_CTL = 100b – Port 3 ACT_LED2

Setting these bits configures LED1 as activity LED for port 1, LED2 as activity LED for port 2, and LED3
as activity LED for port 3. Any time a TLP is transferred to or from the slot, the activity LED flashes. LEDs
4 and 5 are nonfunctional in normal mode; pressing the push buttons will have no effect on the XIO3130.

2 XIO3130 EVM SLLU108 – July 2008

Submit Documentation Feedback

www.ti.com

• General control register (PCI register offset: D4h in each downstream bridge)
– RCVR_PRSNT_EN = 0b – PRSNT pin is used to determine whether slot is present

– REFCK_DIS = 0b – REFCK enabled
– LINK_ACT_RPT_CAP = 1b – Slot is link active reporting capable
– SLOT_PRSNT = 1b – Port connected to slot

• General slot info register (PCI register offset EEh in each downstream bridge)
– SLOT_NUM = 1b for slot 1, 2b for slot 2, and 3b for slot 3

1.3 Hot-Plug-Mode Operation

In hot-plug mode, the EVM board utilizes the TPS2363 PCIe server dual-slot hot-plug controller to switch
power on and off to slots 1 and 2. The TPS2363 is directly controlled by the hot-plug controller built into
the XIO3130. Slot 3 operates in normal mode. To configure the EVM for hot-plug operation, the six
jumpers (J7, J11, J13, J14, J15, J16) must be removed (see Figure 1-5 ).

Hot-Plug-Mode Operation

Figure 1-4. GPIO Control Register

Figure 1-5. Power Jumpers

The dipswitch should be configured with SCL, DN1_DPSTRP and DN2_DPSTRP slide switches in the up
position, and DN3_DPSTRP slide switches in the down position (see Figure 1-6 ). This configuration
enables the EEPROM and enables hot-plug operation on slots 1 and 2.

SLLU108 – July 2008 XIO3130 EVM 3

Submit Documentation Feedback

Hot-Plug-Mode Operation

www.ti.com

Figure 1-6. Dipswitch Configuration

The EEPROM (U3) should be reconfigured for hot-plug-mode operation. See Section 1.5 for an
explanation of how to configure the EEPROM. Upon deassertion of PERST, the XIO3130 automatically
reads data from the EEPROM. This data is used to preset various PCI configuration register bits. For
hot-plug-mode operation, the data in the EEPROM configures bits in the following registers:

• GPIO B control register (PCI Register offset: BEh in upstream bridge)
– PCIE_GPIO8_CTL = 010b – Port 1 ACT_BTN0

– PCIE_GPIO9_CTL = 100b – Port 1 ATN_LED0

• GPIO C control register (PCI register offset: C0h in upstream bridge)
– PCIE_GPIO10_CTL = 011b –Port 2 ACT_BTN1

– PCIE_GPIO11_CTL = 101b – Port 2 PWRFLT1
– PCIE_GPIO12_CTL = 101b – Port 1 PWR_LED0
– PCIE_GPIO13_CTL = 110b – Port 2 PWR_LED1

• GPIO D control register (PCI register offset: C2h in upstream bridge)
– PCIE_GPIO15_CTL = 101b – Port 1 PWRFLT0

– PCIE_GPIO16_CTL = 011b – Port 2 ATN_LED1

Setting these bits configures LED1 as PWR_LED0 for port 1 and LED2 as PWR_LED1 for port 2. LED3 is
not used in hot-plug mode. LEDs 4 will be configured as ATN_LED0 for port 1 and LED5 will be
configured as ATN_LED1 for port 2. Push-button switch SW2 is the attention button for port 1 and SW3 is
the attention button for port 2.

Figure 1-7. GPIO Control Register

4 XIO3130 EVM SLLU108 – July 2008

Submit Documentation Feedback

www.ti.com

ExpressCard-Mode operation

• General control register (PCI register offset: D4h in port 1 and port 2 downstream bridges)
– RCVR_PRSNT_EN = 0b – PRSNT pin is used to determine whether slot is present

– REFCK_DIS = 0b – REFCK enabled
– LINK_ACT_RPT_CAP = 1b – Slot is link active reporting capable
– SLOT_PFIP = 1b – Power fault input implemented
– SLOT_PRSNT = 1b – Port connected to slot
– SLOT_ABP = 1b – Attention button implemented
– SLOT_PCP = 1b – Power controller implemented
– SLOT_AIP = 1b – Attention indicator implemented
– SLOT_PIP = 1b – Power indicator implemented
– SLOT_HPS = 1b – Device present that can be removed without prior notification.
– SLOT_HPC = 1b – Slot is hot-plug capable
– RC_PF_CTL = 1b – REFCK output enable is a function of PWR_FAULT

• General control register (PCI register offset: D4h in port 3 downstream bridge)
– RCVR_PRSNT_EN = 0b – PRSNT pin is used to determine whether slot is present

– REFCK_DIS = 0b – REFCK enabled
– LINK_ACT_RPT_CAP = 1b – Slot is link active reporting capable
– SLOT_PRSNT = 1b – Port connected to slot

• General slot info register (PCI register offset EEh in each downstream bridge)
– SLOT_NUM = 1b for slot 1, 2b for slot 2, and 3b for slot 3

1.4 ExpressCard-Mode operation

For this mode of operation, the ExpressCard adapter board is used in conjunction with the XIO3130 EVM
board. This adapter board utilizes the TI TPS2231 power interface switch to switch power on and off to the
ExpressCard slot. TI also offers a dual-power interface switch called the TPS2236. Figure 1-8 shows the
adapter board.

SLLU108 – July 2008 XIO3130 EVM 5

Submit Documentation Feedback

ExpressCard-Mode operation

www.ti.com

Figure 1-8. ExpressCard Adapter Board

To configure the XIO3130 EVM for ExpressCard-mode operation, connect the ribbon cable connector from
J1 on the adapter board to one of the matching connectors (J2, J3 or J4) on the XIO3130 EVM board.
Then plug the adapter board into the adjacent PCIe slot as shown in Figure 1-9 . It does not matter which
PCIe slot is used, but the ribbon cable must be plugged into the connector just below and to the right of
the PCIe slot that the adapter board is plugged into.
