Chapter 1
General
Information
This chapter details the Texas Instruments (TI) DM38500 PFC/PWM
Combination Controller 100W Power Factor Correction Preregulator
Evaluation Module (EVM) SLUU068. It includes a list of EVM features, a brief
description of the module illustrated with a pictorial, schematic diagrams, and
EVM specifications.
Topic Page
1.1 Features 1−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Description 1−2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Operating Guidelines 1−3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 DM38500 EVM Performance 1−5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
General Information
1-1
Features
1.1 Features
UCC38500 PFC/PWM Combination Controller 100W Power Factor Correction Preregulator include:
J Combines PFC and 2nd Stage Down Converter Controls
J Controls Boost Preregulator to Near-unity Power Factor
J Accurate Power Limiting
J Improved Feedforward Line Regulation
J Peak Current Mode Control in Second Stage
J Programmable Oscillator
J Leading Edge/Trailing Edge Modulation for Reduced Output Ripple
J Low Startup Supply Current
J Synchronized Second Stage with Programmable Soft-start
J Programmable Second Stage Shut-down
1.2 Description
The UCC38500 provides all the functions necessary for active power factor
correction and a second stage dc-to-dc converter all in one integrated circuit.
The control IC uses leading edge modulation for the boost stage and trailing
edge modulation for the step down converter to reduce the RMS current in the
boost capacitor. The dc-to-dc controller uses peak current mode control for
easy loop compensation.
The UCC38500 evaluation board is designed to illustrate the performance of
the IC in a complete off-line 100W two-stage power converter using power factor correction. The demonstration board was designed to operate with a universal input voltage range (i.e. 85−265 Vac) with a regulated 12V dc output.
Caution
High-voltage levels are present on the evaluation module whenever it is
energized. Proper precautions must be taken when working with the
EVM. The output capacitor has high levels of energy storage and it must
be discharged before the load is removed. Serious injury can occur if
proper safety precautions are not followed.
1-2
1.3 Operating Guidelines
The operating guidelines for the evaluation board are provided with reference
to the schematic in Figure 1−1 and the component layout in Figure 2−1.
1.3.1 Step 1. Load Connections
A resistive or electronic load can be applied to the output terminals labeled
OUT− and OUT+.
Note: For safety reasons the load should be connected before power is supplied to the demonstration board.
1.3.2 Step 2. Applying Input Power
Description
A 60 Hz AC power source not exceeding 265 V
terminals AC−N and AC−L for proper operation.
needs be applied across
RMS
1.3.3 Step 3. Evaluating the Demonstration’s Boards Performance.
With the AC source set between 85−265 V
regulated and the input current should track the input voltage shape with near
unity power factor . The operation of the circuit is verified over the line and load
range and shows efficiency as high as 85%. At lighter loads, there may be
some distortion in the line current due to Discontinuous Conduction Mode
(DCM) operation. Please refer to Figures 1−2, 1−3 and 1−4 for typical EVM
performance.
the output voltage should be
RMS
1.3.4 Additional Information
For more information, pin description and specifications for the UCC38500
PFC/PWM Combination Controller, please refer to the datasheet or contact
the Texas Instruments Semiconductor Product Information Center at
1-800-336-5236 or 1-972-644-5580. Product Information can also be found
on the World Wide Web at www.ti.com.
General Information
1-3
Description
Figure 1−1.DM38500 Evaluation Module Application Schematic
C8
12 V
OUT −
100 W
OUT +
HIGH
TEMPERATURE −
AND RESTRICTIONS
SEE EVM WARNINGS
L2
PGND
C3
Q1
R2
R1C4
D2
T2
C5
GT2
PWR
HIGH
TEMPERATURE −
AND RESTRICTIONS
SEE EVM WARNINGS
D1
BIAS
CC
CIRCUIT
V
VAC
Note: High-Voltage component. See EVM Warnings and Restrictions at the back of this document.
Note: High-Temperature component. See EVM W arnings and Restrictions at the back of this document.
+
D8
T1
D4
GND
L1 D3
RMS
85−265V
AC−L
−
PGND2
C29 C30
Q2
GT2
HIGH VOLTAGE −
AND RESTRICTIONS
SEE EVM WARNINGS
R23
R34
R22
R33
C2
Q3
GT1
D11
C26
ISENSE2
R12 R11
C7
R4
D6
U4
UCC38500
R21
R20
R5
GT1
R7
PGNDPGND
12
GT1
OVP/ENBL
4
C23
PGND
R14
R19
AC−N
GT2
R6
CC
V
10
GT2
VSENSE
3
R28
C25
R15
PKLIMIT
D10
PGND
D9
C18
C21
R25
9
5
CT
VCC
VAOUT
ISENSE
1
16
R29
REF
V
R18
HIGH VOLTAGE −
AND RESTRICTIONS
SEE EVM WARNINGS
2
RT
MOUT
17
PGND
6
GND
CAOUT
15
D12
R24
BIAS
CC
CIRCUIT
V
SGND
V
PGND
R17
C22
REF
13
11
SS2
PWRGND
IAC
VFF
19
18
C19
R13
C16
7
VERR
PKLIMIT
14
PKLIMIT
R3
R30
R39
R26
D16
C28
C17
8
ISENSE2
VREF
20
C24
D14
R36
H11AV1
ISENSE2
REF
V
SGND
Q5
R31
1
6
D15
PGND2
5
C13
C27
R10
D5
R16
C38
CC
V
2
C12
R32
C14 R35
SGND
SGND
L1
3
4
U3
C6
C20
D7
R27
D13
UDG−00094
PGND2
SGND
1-4
1.4 DM38500 EVM Performance
Figure 1−2 through 1−4 shows the typical evaluation module performance.
Figure 1−2.DM38500 EVM Efficiency
90
85
80
DM38500 EVM Performance
UCC38500 EFFICIENCY
vs
OUTPUT POWER
VIN= 265 V
75
70
Efficiency −%
65
60
55
50
Figure 1−3.DM38500 Power Factor
1.00
VIN= 175 V
VIN= 85 V
2010 4030 6050 8070 90 100
P
− W
OUT
UCC38500 PF
vs
OUTPUT POWER
0.95
Power Factor
0.90
0.85
2010
VIN = 85 V
VIN = 175 V
VIN = 265 V
4030 6050 8070 90 100
P
− W
OUT
General Information
1-5
DM38500 EVM Performance
Figure 1−4.DM38500 Total Harmonic Distortion
UCC38500 TOTAL HARMONIC DISTORTION
vs
35
OUTPUT POWER
30
VIN = 265 V
25
20
VIN = 175 V
15
10
Total Harmonic Distortion
VIN = 85 V
5
0
2010
4030 6050 8070 90 100
P
− W
OUT
1-6
Chapter 2
Reference
This chapter includes a parts list and PCB layout illustrations for the DM38500
EVM.
Topic Page
2.1 DM38500 EVM Part Descriptions 2−2. . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 DM38500 Board Layouts 2−4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Reference
2-1
DM38500 EVM Part Descriptions
Diodes
Fuses
Heat sinks
Inductors
MOSFETs
2.1 DM38500 EVM Part Descriptions
Table 2−1.DM38500 Part Descriptions
Description Reference Qty Value/Type Number Manufacturer
C12, C20,
C29
C13 1 47 pF, 50 V, ceramic Panasonic ECU−S2A470JCA
C7, C16,
C14
C17, C38 2 100 pF, 50 V, ceramic Panasonic ECU−S1H101JCA
C19 1 2.2 nF, 50 V, ceramic Panasonic ECU−S1H222JCB
C2 1
Capacitors
Diodes
Heat sinks HS4, HS5 2 For D3 and D8 Aavid 579302 B 0 00 00
MOSFETs Q3 1 14 A, 500 V, n−channel IR IRFP450
Not used
C21 1 680 pF, 50 V, ceramic Panasonic ECU−S1H681JCB
C22
C24 1 100 pF, 50 V, ceramic Panasonic ECU−S1H101JCA
C25 1 150 nF, 50 V, ceramic Panasonic ECU−S1H154KBB
C26 1 47 nF, 600 V, polypropylene Panasonic ECQ−E6473KF
C27, C18 2 100 pF, 50 V, ceramic Panasonic ECU−S1H105KBB
C28, C23 2 2.2 µF, 50 V, ceramic Panasonic ECU−S1H225MEB
C3 1 100 µF, 450 V, electrolytic Panasonic ECO−S2WB101BA
C30 1 1800 µF, 25 V, electrolytic Panasonic ECA−IEFQ182
C4, C5, C8 3 0.1 µF, 50 V, ceramic Panasonic ECU−S1H104KBB
C6 1 100 µF, 25 V, electrolytic Panasonic EEU−FCIE101S
D1 1 6 A, 600 V, GI756CT General Inst. GI756CT
D11 1
D12 1 1 A, 40 V, Shottky SR103CT
D13 1 TL431CLP TI TL431C
D14 1 10 V, 1 W, Zener 1N4740
D15, D2
D3 1 6 A, 600 V, ultra fast IR HFA08TB60−ND
D4, D6 2 1 A, 600 V, fast recovery Philips BYV26C
D5,D7,D9,
D10, D16
D8 1
FH1, FH2 2 3AG Fuse clip
F1 1 6 A, 250 V
HS3 1 For Q3 Aavid 513201
HS1, HS2 2 For Q1 and Q2 Avid 593002 B 0 34 00
L1 1 1.7 mH, 2.5 A, coupled Cooper CTX08−14730
L2 1 35 µH, 8.3 A Cooper CTX08−14279
Q1,Q2 2 8 A, 500 V, n−channel IR IRF840
Q5 1 NPN transistor MJE13005
Q4, R8, R9,
C9, C15,
C10
3 1 µF, 50 V, polypropylene Panasonic ECQ−V1H105JL
3 10 nF, 50 V, ceramic Panasonic ECU−S1H103JCB
470 nF, 400 V,
polypropylene
1 390 pF, 50 V, ceramic Panasonic ECU−S1H391JCA
6 A, 600 V, bridge rectifier,
PB66
2 18 V, 1 W, Zener 1N4746
5 1 A, 40 V, Shottky 1N5819
6 A, 600 V, full wave
rectifier
6 Not used
Panasonic ECQ−E4474KZ
Diodes Inc. PB66
IR HBR2045
Part
Number
2-2
DM38500 EVM Part Descriptions
Resistors
Resistors
Transformers
ICs
ICs
Description
Miscellaneous
PCB PCB 1 Bare board UCC38500 PCB
Reference Qty Value/Type Number Manufacturer
R1, R12 2 Short
R10, R36 2 200 Ω, ¼ W
R25, R29,
R27
R13 1 2 kΩ, ¼ W
R14 1 1.5 kΩ, ¼ W
R15, R19 2 3.92 kΩ, ¼ W
R16 1 750 Ω, ¼ W
R17 1 7.5 kΩ, ¼ W
R18, R24 2 392 kΩ, ¼ W
R2, R11 2 1 kΩ, ¼ W
R20 1 22.1 kΩ, ¼ W
R21 1 8.25 kΩ, ¼ W
R22, R33 2 562 kΩ, ¼ W
R23 1 200 kΩ, ¼ W
R26 1 100 Ω, ¼ W
R28 1 100 kΩ, ¼ W
R30 1 30.1 kΩ, ¼ W
R31 1 33.2 kΩ, ¼ W
R32 1 4.75 kΩ, ¼ W
R34 1 221 kΩ, ¼ W
R35 1 16.2 kΩ, ¼ W
R39 1 1 kΩ, 1 W
R4 1 1 Ω, 1 W, ±5%
R5 1 0.33 Ω, 3 W, ±5%
R6, R7 2 20 Ω, ¼ W
R3 1 51 kΩ, 2 W, 400 V
T1 1 8 mH, 10 A, 10.8:1 Cooper CTX08−14226
T2 1 560−990 µH, 1:1 gate drive Cooper CTX08−14225
U4 1
U3 1 Opto-isolator 4N36
X1 3
X2 1
X3
X4 4 Nut #4x40
X5 3
X6 1 Bevel washer #4 (@Q3)
3 10 kΩ, ¼ W
BiCMOS PFC/PWM
combination controller
Thermal pad TO−220
(@ Q1, Q2, D8)
Thermal pad TO−247
(@ Q3)
Screw pan head #4−40 X
4
7/16 (@Q1, Q2, Q3, D8)
Nylon shoulder washer #4
(@Q1, Q2, D8)
Texas
Instruments
Part
Number
UCC38500N
Notes:
1) The values of these components are to be determined by the user in accordance with the application requirements.
2) Unless otherwise specified, all resistors have a tolerance of ±1%.
3) Capacitor C38 is located at reference designator R38 on the PCB.
Reference
2-3
DM38500 Board Layouts
2.2 DM38500 Board Layouts
Board layout examples of the DM38500 EVM PCB are shown in the following
illustrations. They are not to scale and appear here only as a reference.
Figure 2−1.DM38500 EVM PC Board: Top Assembly
2-4
Loading...
