TEXAS INSTRUMENTS TPS65160, TPS65160A Technical data

Download

www.ti.com

COMP

VINB

FREQ

EN1 EN2 DRN FBN REF PGND PGND

SW SW

AVIN

GND

DRP

FBP

Boot

SWB

DLY1

TPS65160

VINB

FBB

DLY2

SUP

12 V

2*22 F

1 F

C16

1 F

0.47 FD2

VGL

−5 V/50 mA

R3 620 k

150 k

C8 220 nF

470 F

22 nF

C10 10 nF

C11

10 nF

C17 22 nF

1.2 k

R7 2 k

D6 SL22

15 H

Cb 100 nF

R6 56 k

C14 10 nF

C12 2*22 F

3.3 V/1.5 A

C13

0.47 F

1 M

VGH

23 V/50 mA

0.47 F

C15

470 nF

R2 56 k

R1 680 k

3* 22 F

22 pF

SL22

10 H

15 V/1.5 A

8 12 20

21 22

9 11 13 24

7 28 25

4 5 1 3 23 27 10 14 17 18 19 15 2

LOGIC

BIAS POWER SUPPLY FOR TV AND MONITOR TFT LCD PANELS

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

FEATURES

• Gate Drive Signal to Drive External MOSFET

• 8-V to 14-V Input Voltage Range • Internal and Adjustable Soft Start

• V

Output Voltage Range up to 20 V • Short-Circuit Protection

• 1% Accurate Boost Converter With 2.8-A • 23-V (TPS65160) Overvoltage Protection

Switch Current

• 1.5% accurate 1.8-A Step-Down Converter

• 500-kHz/750-kHz Fixed Switching Frequency

• 19.5-V (TPS65160A) Overvoltage Protection

• Thermal Shutdown

• Available in TSSOP-28 Package

• Negative Charge Pump Driver for VGL

• Positive Charge Pump Driver for VGH

• Adjustable Sequencing for VGL, VGH

APPLICATIONS

• TFT LCD Displays for Monitor and LCD TV

DESCRIPTION

The TPS65160 offers a compact power supply solution to provide all four voltages required by thin-film transistor (TFT) LCD panel. With its high current capabilities, the device is ideal for large screen monitor panels and LCD TV applications.

TYPICAL APPLICATION

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

PowerPAD is a trademark of Texas Instruments.

PRODUCTION DATA information is current as of publication date. Products conform to specifications per the terms of the Texas Instruments standard warranty. Production processing does not necessarily include testing of all parameters.

www.ti.com

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

DESCRIPTION (CONTINUED)

The device can be powered directly from a 12-V input voltage generating the bias voltages VGH and VGL, as well as the source voltage V provide the source voltage V and a negative charge-pump driver provide adjustable regulated output voltages VGL and VGH to bias the TFT. Both boost and step-down converters, as well as the charge-pump driver, operate with a fixed switching frequency of 500 kHz or 750 kHz, selectable by the FREQ pin. The TPS65160 includes adjustable power-on sequencing. The device includes safety features like overvoltage protection of the boost converter and short-circuit protection of the buck converter, as well as thermal shutdown. Additionally, the device incorporates a gate drive signal to control an isolation MOSFET switch in series with V the end of this data sheet.

This integrated circuit can be damaged by ESD. Texas Instruments recommends that all integrated circuits be handled with appropriate precautions. Failure to observe proper handling and installation procedures can cause damage.

ESD damage can range from subtle performance degradation to complete device failure. Precision integrated circuits may be more susceptible to damage because very small parametric changes could cause the device not to meet its published specifications.

and logic voltage for the LCD panels. The device consists of a boost converter to

and a step-down converter to provide the logic voltage for the system. A positive

or VGH. See the application circuits at

ORDERING INFORMATION

–40 ° C to 85 ° C

(1) For the most current package and ordering information, see the Package Option Addendum at the end of this document, or see the TI

Web site at www.ti.com .

(2) The PWP package is available taped and reeled. Add R-suffix to the device type (TPS65160PWPR) to order the device taped and

reeled. The TPS65160PWPR package has quantities of 2000 devices per reel. Without suffix, the TPS65160PWP is shipped in tubes with 50 devices per tube.

UVLO Overvoltage protection ORDERING PACKAGE

(typ) Vs (typ) MARKING

6 V 23 V TPS65160PWP TSSOP28 (PWP) TPS65160 8 V 19.5 V TPS65160APWP TSSOP28 (PWP) TPS65160A

(1)

(2)

PACKAGE

ABSOLUTE MAXIMUM RATINGS

over operating free-air temperature range (unless otherwise noted)

Voltages on pin VIN, SUP Voltages on pin EN1, EN2, FREQ Voltage on pin SW Voltage on pin SWB Voltages on pin OS, GD Continuous power dissipation See Dissipation Rating Table

stg

(1) Stresses beyond those listed under absolute maximum ratings may cause permanent damage to the device. These are stress ratings

(2) All voltage values are with respect to network ground terminal.

Operating junction temperature –40 ° C to 150 ° C Storage temperature range –65 ° C to 150 ° C Temperature (soldering, 10 s) 260 ° C

only, and functional operation of the device at these or any other conditions beyond those indicated under recommended operating conditions is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.

(2)

(1)

UNIT

–0.3 V to 16.5 V

–0.3 V to 15 V

25 V 20 V 25 V

DISSIPATION RATINGS

PACKAGE RTH

28-Pin TSSOP 28 ° C/W (PowerPAD

(1) See Texas Instruments application report SLMA002 regarding thermal characteristics of the PowerPAD package.

(1)

soldered) 3.57 W 1.96 W 1.42 W

TA≤ 25 ° C TA= 70 ° C TA= 85 ° C

POWER RATING POWER RATING POWER RATING

www.ti.com

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

RECOMMENDED OPERATING CONDITIONS

over operating free-air temperature range (unless otherwise noted)

MIN NOM MAX UNIT

SUP

L µH

LOGIC

(1) See application section for further information.

ELECTRICAL CHARACTERISTICS

(unless otherwise noted)

SUPPLY CURRENT

QIN

SUP

UVLO

REF

LOGIC SIGNALS EN1, EN2, FREQ

CONTROL AND SOFT START DLY1, DLY2, SS

DLY1

DLY2

Output voltage range of the main boost converter TPS65160 20 V

TPS65160A 17.5 V Maximum operating voltage at the charge-pump driver supply pin SUP 15 V Input capacitor at VINB 2x22 µF Input capacitor AVIN 1 µF Inductor boost converter Inductor buck converter Output voltage range of the step-down converter V

(1)

LOGIC

1.8 5.0 V

10 15

Output capacitor boost converter 3x22 Output capacitor buck converter 2x22 Operating ambient temperature –40 85 ° C Operating junction temperature –40 125 ° C

= 12 V, SUP = VIN, EN1 = EN2 = VIN, VS= 15 V, V

= 3.3 V, TA= –40 ° C to 85 ° C, typical values are at TA= 25 ° C

LOGIC

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

Input voltage range

TPS65160 8 14 V TPS65160A 9.2 14 V

VGH = 2 x VS, 0.2 2

Quiescent current into AVIN Boost converter not

switching VGH = 2 x VS, 0.2 0.5

Quiescent current into VINB Buck converter not

switching Shutdown current into AVIN EN1 = EN2 = GND 0.1 2 Shutdown current into VINB EN1 = EN2 = GND 0.1 2 Shutdown current into SUP EN1 = EN2 = GND 0.1 4 µA Quiescent current into SUP VGH = 2 x V

Undervoltage lockout threshold

TPS65160 VINfalling 6 6.4 V TPS65160A VINfalling 8 8.8 V

0.2 2 mA

Reference voltage 1.203 1.213 1.223 V Thermal shutdown Temperature rising 155 ° C Thermal shutdown hysteresis 5 ° C

High-level input voltage EN1, EN2 2.0 V Low-level input voltage EN1, EN2 0.8 V High-level input voltage FREQ 1.7 V Low-level input voltage FREQ 0.4 V

Input leakage current

EN1 = EN2 = FREQ = 0.01 0.1 µA

GND or V

Delay1 charge current 3.3 4.8 6.2 µA Delay2 charge current V

THRESHOLD

= 1.213 V 3.3 4.8 6.2 µA

SS charge current 6 9 12 µA

µF

µA

www.ti.com

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

ELECTRICAL CHARACTERISTICS (continued)

= 12 V, SUP = VIN, EN1 = EN2 = VIN, VS= 15 V, V

(unless otherwise noted)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

INTERNAL OSCILLATOR

OSC

BOOST CONVERTER (VS)

V I

DS(ON)

MAX

LIM

Ileak Switch leakage current V

Vovp Overvoltage protection

GATE DRIVE (GD)

V V

STEP-DOWN CONVERTER (V

V V I

FBB

DS(ON)

LIM

Ileak Switch leakage current V

(1) The GD signal is latched low when the main boost converter output VSis within regulation. The GD signal is reset when the input

Oscillator frequency kHz

Output voltage range

Feedback regulation voltage 1.136 1.146 1.156 V

TPS65160 20 V TPS65160A 17.5 V

Feedback input bias current 10 100 nA N-MOSFET on-resistance (Q1) ISW= 500 mA 100 185 m Ω P-MOSFET on-resistance (Q2) ISW= 200 mA 10 16 Ω Maximum P-MOSFET peak switch current 1 A N-MOSFET switch current limit (Q1) 2.8 3.5 4.2 A

TPS65160 V

TPS65160A V Line regulation Load regulation 0.03 %/A

Gate drive threshold

GD output low voltage I

(1)

GD output leakage current VGD = 20 V 0.05 1 µA

)

LOGIC

Output voltage range 1.8 5 V

LOGIC

Feedback regulation voltage 1.195 1.213 1.231 V

FBB

Feedback input bias current 10 100 nA N-MOSFET on-resistance (Q1) ISW= 500 mA 175 300 m Ω N-MOSFET switch current limit (Q1) 2 2.6 3.3 A

Line regulation Load regulation 0.037 %/A

voltage or enable of the boost converter is cycled low.

= 3.3 V, TA= –40 ° C to 85 ° C, typical values are at TA= 25 ° C

LOGIC

FREQ = high 600 750 900 FREQ = low 400 500 600

= 15 V 1 10 µA

rising 22 23 24.5 V

OUT

rising 18 19.5 20.5 V

OUT

10.6 V ≤ Vin ≤ 11.6 V 0.0008 %/V at 1 mA

rising Vs-12% Vs-8% Vs-4% V

= 500 µA 0.3 V

(sink)

= 0 V 1 10 µA

10.6 V ≤ VIN≤ 11.6 V 0.0018 %/V at 1 mA

www.ti.com

1 2

3 4 5

6 7 8 9

10 11 12

28 27

26 25 24

23 22 21 20 19 18 17

COMP

SW PGND PGND

SUP

EN2

DRP

DRN

FREQ

SS GD

DLY2 DLY1 REF GND

AVIN

VINB VINB NC SWB BOOT

Thermal PAD (see Note)

13 14

16 15

FBN

FBP

EN1 FBB

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

ELECTRICAL CHARACTERISTICS (continued)

= 12 V, SUP = VIN, EN1 = EN2 = VIN, VS= 15 V, V

(unless otherwise noted)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

NEGATIVE CHARGE-PUMP VGL

VGL Output voltage range –2 V V I

FBN

DS(ON)

POSITIVE CHARGE-PUMP OUTPUT VGH

V I

FBP

DS(ON)

Feedback regulation voltage –36 0 36 mV

FBN

Feedback input bias current 10 100 nA Q4 P-Channel switch r

Current sink voltage drop

DropN

Feedback regulation voltage 1.187 1.213 1.238 V

FBP

Feedback input bias current 10 100 nA Q3 N-Channel switch r

Current source voltage drop

DropP

(Vsup – V

)

DRP

DS(ON)

(2)

DS(ON)

(2)

= 3.3 V, TA= –40 ° C to 85 ° C, typical values are at TA= 25 ° C

LOGIC

= 20 mA 4.4 Ω

OUT

= 50 mA, 130 190

DRN

= V

FBN

FBNnominal

= 100 mA, 270 420

DRN

= V

FBN

FBNnominal

= 20 mA 1.1 Ω

OUT

= 50 mA, 400 680

DRP

= V

FBP

FBPnominal

= 100 mA, 850 1600

DRP

= V

FBP

FBPnominal

–5%

(2) The maximum charge-pump output current is typically half the drive current of the internal current source or current sink.

NOTE: The thermally enhanced PowerPAD™ is connected to PGND.

www.ti.com

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

TERMINAL FUNCTIONS

TERMINAL

NAME NO.

SUP 8 I of the TPS65160 main boost converter. Because the SUP pin is rated to a maximum voltage of 15 V, it needs to

FREQ 12 I

AVIN 22 I VINB 20, 21 I Power input voltage pin for the buck converter.

EN1 16 I converter starts up, and after a delay time set by DLY1, the negative charge pump comes up. This pin must be

EN2 9 I charge pump starts up after the buck converter is within regulation and a delay time set by DLY2 has passed by.

DRN 11 O Drive pin of the negative charge pump. FBN 13 I Feedback pin of negative charge pump. REF 24 O Internal reference output typically 1.213 V PGND 6, 7 Power ground

SS 28 O

DLY1 25 O

DLY2 26 O

COMP 2 FBB 15 I Feedback pin of the buck converter

SWB 18 O Switch pin of the buck converter NC 19 Not connected

BOOT 17 I FBP 14 I Feedback pin of positive charge pump.

DRP 10 O Drive pin of the positive charge pump.

GD 27

GND 23 Analog ground

OS 3 I

FB 1 I Feedback of the main boost converter generating Vsource (V SW 4, 5 I Switch pin of the boost converter generating Vsource (VS). PowerPAD The PowerPAD needs to be connected and soldered to power ground (PGND).

I/O DESCRIPTION

This is the supply pin of the positive and negative charge-pump driver and can be connected to the input or output be connected to the input of the TPS65160 for an output voltage greater than 15 V.

Frequency adjust pin. This pin allows setting the switching frequency with a logic level to 500 kHz = low and 750 kHz = high.

Analog input voltage of the device. This is the input for the analog circuits of the device and should be bypassed with a 1- µ F ceramic capacitor for good filtering.

This is the enable pin of the buck converter and negative charge pump. When this pin is pulled high, the buck terminated and not be left floating. A logic high enables the device and a logic low shuts down the device.

The boost converter starts only with EN1 = high, after the step-down converter is enabled. EN2 is the enable pin of the boost converter and positive charge pump. When this pin is pulled high, the boost converter and positive

This pin must be terminated and not be left floating. A logic high enables the device and a logic low shuts down the device.

This pin allows setting the soft-start time for the main boost converter VS. Typically a 22-nF capacitor needs to be connected to this pin to set the soft-start time.

Connecting a capacitor from this pin to GND allows the setting of the delay time between V converter output high) to VGL during start-up.

Connecting a capacitor from this pin to GND allows the setting of the delay time between V converter output high) to VSBoost converter and positive charge-pump VGH during start-up.

This is the compensation pin for the main boost converter. A small capacitor and, if required, a resistor is connected to this pin.

N-channel MOSFET gate drive voltage for the buck converter. Connect a capacitor from the switch node SWB to this pin.

This is the gate drive pin which can be used to control an external MOSFET switch to provide input to output isolation of VSor VGH. See the circuit diagrams at the end of this data sheet. GD is an open-drain output and is latched low as soon as the boost converter is within 8% of its nominal regulated output voltage. GD goes high impedance when the EN2 input voltage is cycled low.

Output sense pin. The OS pin is connected to the internal rectifier switch and overvoltage protection comparator. This pin needs to be connected to the output of the boost converter and cannot be connected to any other voltage rail. Connect a 470-nF capacitor from OS pin to GND to avoid noise coupling into this pin. The PCB trace of the OS pin needs to be wide because it conducts high current.

LOGIC

(step-down

www.ti.com

TYPICAL CHARACTERISTICS

0.02

0.04

0.06

0.08

0.1

0.12

0.14

0.16

−40 −20 0 20 40 60 80 100 120 140

DS(on)

− N-Channel Switch −

TA − Temperature − C

Ω

VI = 8 V , VI = 12 V , VI = 14 V

100

0 0.5 1 1.5 2

VI = 12 V , VO = 15 V , L = 10 H

IO − Output Current − A

Efficiency − %

TABLE OF GRAPHS

MAIN BOOST CONVERTER (Vs)

η Efficiency main boost converter Vs vs Load current VS=15 V,V r

DS(ON)

STEP-DOWN CONVERTER (Vlogic)

η Efficiency main boost converter V r

DS(ON)

SYSTEM PERFORMANCE

osc

N-channel main switch Q1 vs Input voltage and temperature 2 Soft-start boost converter C

= 22 nF 3

PWM operation at full-load current 4 PWM operation at light-load current 5 Load transient response 6

vs Load current V

LOGIC

N-channel main switch Q1 8 PWM operation - continuous mode 9 PWM operation - discontinuous mode 10 Soft start 11 Load transient response 12

Oscillation frequency vs Input voltage and temperature 13 Power-up sequencing EN2 connected to V Power-up sequencing EN2 enabled seperately 15

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

FIGURE

= 12 V 1

= 3.3 V,V

= 12 V 7

BOOST CONVERTER EFFICIENCY BOOST CONVERTER

vs r

OUTPUT CURRENT vs

Figure 1. Figure 2.

- N-CHANNEL SWITCH

DS(ON)

TEMPERATURE

www.ti.com

5 V/div

1 A/div

VI = 12 V , VO = 15 V/ 1.2 A, C

(SS)

= 22 nF

2 ms/div

10 V/div

50 mV/div

(Inductor)

1 A/div

1 s/div

VI = 12 V , VO = 15 V/1.5 A

VI = 12 V , VS = 15 V , CO = 3*22 F, C

(comp)

= 22 nF,

L = 6.8 H, FREQ= High

200 mV/div

100 s/div

(Inductor)

1 A/div

10 V/div

50 mV/div

500 mA/div

1 s/div

VI = 3.3 V , VO = 10 V/10 mA

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

SOFT-START PWM OPERATION BOOST CONVERTER

BOOST CONVERTER CONTINUOUS MODE

Figure 3. Figure 4.

PWM OPERATION BOOST CONVERTER LOAD TRANSIENT RESPONSE BOOST CONVERTER

CONTINUOUS MODE: LIGHT LOAD

Figure 5. Figure 6.

www.ti.com

0 0.5 1 1.5 2

= 12 V ,

VO = 3.3 V , L = 15 H

IO − Output Current − A

Efficiency − %

0.05

0.1

0.15

0.2

0.25

−40 −20 0 20 40 60 80 100 120 140

DS(on)

− N-Channel Switch −

VI = 8 V , VI = 12 V , VI = 14 V

TA − Temperature − C

Ω

5 V/div

20 mV/div

(Inductor)

100 mA/div

500 ns/div

VI = 12 V, VO = 3.3 V/45 mA

5 V/div

20 mV/div

(Inductor)

1 A/div

500 ns/div

VI = 12 V , VO = 3.3 V/1.5 A

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

EFFICIENCY STEP-DOWN CONVERTER STEP-DOWN CONVERTER

vs r

LOAD CURRENT vs

Figure 7. Figure 8.

STEP-DOWN CONVERTER STEP-DOWN CONVERTER

PWM OPERATION PWM OPERATION

CONTINUOUS MODE DISCONTINUOUS MODE

- N-CHANNEL SWITCH

DS(ON)

TEMPERATURE

Figure 9. Figure 10.

www.ti.com

VO1

100 mV/div

270 mA to 1.3 A

50 s/div

VI = 12 V , V

(logic)

= 3.3 V ,

CO = 2*22 F, FREQ = High

1 V/div

(Inductor)

1 A/div

200 s/div

VI = 12 V , VO = 3.3 V/1.2 A

V Logic

2 V/div

VGL

5 V/div

VGH

10 V/div

2 ms/div

695

700

705

710

715

720

725

730

735

740

−50 0 50 100 150

Switching Frequency − kHz

VI = 8 V , VI = 12 V , VI = 14 V

TA − Temperature − C

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

SOFT-START LOAD TRANSIENT RESPONSE

STEP-DOWN CONVERTER STEP-DOWN CONVERTER

Figure 11. Figure 12.

SWITCHING FREQUENCY POWER-UP SEQUENCING

TEMPERATURE

Figure 13. Figure 14.

vs EN2 CONNECTED TO V

www.ti.com

V Logic

2 V/div

5 V/div

VGH

5 V/div

1 ms/div

EN2

2 V/div

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

POWER-UP SEQUENCING

EN2 ENABLED SEPARATELY

Figure 15.

www.ti.com

Current Control

Soft Start

500 kHz/

750 kHz

Oscillator

D S

VFB

1.154 V

Comparator

GM Amplifier

Sawtooth

Generator

VFB

1.154

Vref

1.213V

Bias

Vref=1.213 V

Thermal

Shutdown

Sequencing

AVIN SW SW

GND

PGND

Negative

Charge Pump

Vref

1.2 13V

GM Amplifier

Low Gain

Current Limit

and

Soft Start

DLY

Vref

DLY1

AVIN

FREQ

Clock

SUP

DRVP

Positive

Charge Pump

Current

Control

Soft Start

DRVP

COMP

DLY

AVIN

Vref

SUP

DRVN

VINB

Regulator

8 V

Sawtooth

Generator

Compensation

and

Soft Start

Vref

Logic

Clock

Clock/2

Clock/4

0.9 V

0.6 V

Clock Select During Short Circuit

and Soft Start

Control Logic

Ref

Current Limit

SWB

BOOT

FBB

Error Amplifier

SUP

DRVNN

FBN

Vref

1.213V

Reference

Output

VREF

DLY1

Vref

DLY2

Step-Down

Converter

D S

EN1

EN2

Clock

DLY1 DLY2

Vref

Overvoltage Comparator

Control Logic

DLY

FBP

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

BLOCK DIAGRAM

www.ti.com

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

DETAILED DESCRIPTION

Boost Converter

The main boost converter operates in pulse-width modulation (PWM) and at a fixed switching frequency of 500 kHz or 750 kHz set by the FREQ pin. The converter uses an unique fast response, voltage-mode controller scheme with input voltage feedforward. This achieves excellent line and load regulation (0.03%-A load regulation typical) and allows the use of small external components. To add higher flexibility to the selection of external component values, the device uses external loop compensation. Although the boost converter looks like a nonsynchronous boost converter topology operating in discontinuous conduction mode at light load, the TPS65160 maintains continuous conduction even at light-load currents. This is achieved with a novel architecture using an external Schottky diode with an integrated MOSFET in parallel connected between SW and OS. See the Functional Block Diagram. The intention of this MOSFET is to allow the current to go negative that occurs at light-load conditions. For this purpose, a small integrated P-Channel MOSFET with typically 10- Ω r sufficient. When the inductor current is positive, the external Schottky diode with the lower forward voltage conducts the current. This causes the converter to operate with a fixed frequency in continuous conduction mode over the entire load current range. This avoids the ringing on the switch pin as seen with standard nonsynchronous boost converter and allows a simpler compensation for the boost converter.

Soft Start (Boost Converter)

The main boost converter has an adjustable soft start to prevent high inrush current during start-up. The soft-start time is set by the external capacitor connected to the SS pin. The capacitor connected to the SS pin is charged with a constant current that increases the voltage on the SS pin. The internal current limit is proportional to the voltage on the soft-start pin. When the threshold voltage of the internal soft-start comparator is reached, the full current limit is released. The larger the soft-start capacitor value, the longer the soft-start time.

ds(on)

Overvoltage Protection of the Boost Converter

The main boost converter has an overvoltage protection to protect the main switch Q2 at pin (SW) in case the feedback (FB) pin is floating or shorted to GND. In such an event, the output voltage rises and is monitored with the overvoltage protection comparator over the OS pin. See the functional block diagram. As soon as the comparator trips at typically 23 V, TPS65160, (19 V, TPS65160A), the boost converter turns the N-Channel MOSFET switch off. The output voltage falls below the overvoltage threshold and the converter continues to operate.

Frequency Select Pin (FREQ)

The frequency select pin (FREQ) allows setting the switching frequency of the entire device to 500 kHz (FREQ = low) or 750 kHz (FREQ = high). A lower switching frequency gives a higher efficiency with a slightly reduced load transient regulation.

Thermal Shutdown

A thermal shutdown is implemented to prevent damage caused by excessive heat and power dissipation. Typically, the thermal shutdown threshold is 155 ° C.

Step-Down Converter

The nonsynchronous step-down converter operates at a fixed switching frequency using a fast response voltage mode topology with input voltage feedforward. This topology allows simple internal compensation, and it is designed to operate with ceramic output capacitors. The converter drives an internal 2.6-A N-channel MOSFET switch. The MOSFET driver is referenced to the switch pin SWB. The N-channel MOSFET requires a gate drive voltage higher than the switch pin to turn the N-Channel MOSFET on. This is accomplished by a bootstrap gate drive circuit running of the step-down converter switch pin. When the switch pin SWB is at ground, the bootstrap capacitor is charged to 8 V. This way, the N-channel gate drive voltage is typically around 8 V.

www.ti.com

DRVP

DRP

Current Control

Soft Start

VGHVG

23 V/50 mA

C13

0.47

FBP

Cfly

F

SUP = Vin for Vs > 15 V SUP = Vs for Vs  15 V

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

DETAILED DESCRIPTION (continued) Soft Start (Step-Down Converter)

To avoid high inrush current during start-up, an internal soft start is implemented in the TPS65160. When the step-down converter is enabled over EN1, its reference voltage slowly rises from zero to its power-good threshold of typically 90% of Vref. When the reference voltage reaches this power-good threshold, the error amplifier is released to its normal operation at its normal duty cycle. To further limit the inrush current during soft start, the converter frequency is set to 1/4 comparator that monitors the feedback voltage. See the internal block diagram. Soft start is typically completed within 1 ms.

Short-Circuit Protection (Step-Down Converter)

To limit the short-circuit current, the device has a cycle-by-cycle current limit. To avoid the short-circuit current rising above the internal current limit when the output is shorted to GND, the switching frequency is reduced as well. This is implemented by two comparators monitoring the feedback voltage. The step-down converter switching frequency is reduced to 1/2 of fs when the feedback is below 0.9 V and to 1/4 frequency when the feedback voltage is below 0.6 V.

Positive Charge Pump

The positive charge pump provides a regulated output voltage set by the external resistor divider. Figure 16 shows an extract of the positive charge-pump driver circuit. The maximum voltage which can be applied to the charge-pump driver supply pin, SUP, is 15 V. For applications where the boost converter voltage Vs is higher than 15 V, the SUP pin needs to be connected to the input. The operation of the charge-pump driver can be understood best with Figure 16 . During the first cycle, Q3 is turned on and the flying capacitor Cfly charges to the source voltage, Vs. During the next clock cycle, Q3 is turned off and the current source charges the drive pin, DRP, up to the supply voltage, VSUP. Because the flying capacitor voltage sits on top of the drive pin voltage, the maximum output voltage is Vsup+Vs.

of the switching frequency fs and then 1/2 of fs determined by the

of the switching

Figure 16. Extract of the Positive Charge-Pump Driver

If higher output voltages are required, another charge-pump stage can be added to the output. Setting the output voltage:

www.ti.com

out

 1.2131 

R5 R6



R5  R6



out

 1



 R6 

out

1.213

 1

out

 V

REF



R3 R4

  1.213 V 

R3 R4

R3  R4 

out

REF

 R4 

out

1.213

EN2

EN1

Vo4

VGL

DLY1

VGH

DLY2

Vin

VinVs, VGH

Fall Time Depends on Load Current and Feedback Resistor

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

DETAILED DESCRIPTION (continued)

Negative Charge Pump

The negative charge pump provides a regulated output voltage set by the external resistor divider. The negative charge pump operates similar to the positive charge pump with the difference that the voltage on the supply pin, SUP, is inverted. The maximum negative output voltage is VGL = (–V across the external diodes and internal charge-pump MOSFETs. In case VGL needs to be lower than –VS, an additional charge-pump stage needs to be added.

Setting the output voltage:

)+Vdrop. Vdrop is the voltage drop

SUP

The lower feedback resistor value, R4, should be in a range between 40 k Ω to 120 k Ω or the overall feedback resistance should be within 500 k Ω to 1 M Ω . Smaller values load the reference too heavily, and larger values may cause stability problems. The negative charge pump requires two external Schottky diodes. The peak current rating of the Schottky diode has to be twice the load current of the output. For a 20-mA output current, the dual-Schottky diode BAT54 is a good choice.

Power-On Sequencing (EN1, EN2, DLY1, DLY2)

The TPS65160 has an adjustable power-on sequencing set by the capacitors connected to DLY1 and DLY2 and controlled by EN1 and EN2. Pulling EN1 high enables the step-down converter and then the negative charge-pump driver. DLY1 sets the delay time between the step-down converter and negative charge-pump driver. EN2 enables the boost converter and positive charge-pump driver at the same time. DLY2 sets the delay time between the step-down converter Vlogic and the boost converter Vs. This is especially useful to adjust the delay when EN2 is always connected to Vin. If EN2 goes high after the step-down converter is already enabled, then the delay DLY2 starts when EN2 goes high. See Figure 17 and Figure 18 .

Figure 17. Power-On Sequencing With EN2 Always High (EN2=Vin)

www.ti.com

EN2

EN1

Vo4

VGL

DLY1

VGH ,Vs

DLY2

Vin

VGH

Vin

Fall Time Depends on Load Current and Feedback Resistor

dly



4.8 A  td Vref



4.8 A  td

1.213 V

with td  Desired delay time

dly



4.8 A  2.3 ms

1.213 V

 9.4 nF  Cdly  10 nF

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

DETAILED DESCRIPTION (continued)

Figure 18. Power-On Sequencing Using EN1 and EN2

Setting the Delay Times DLY1, DLY2

Connecting an external capacitor to the DLY1 and DLY2 pins sets the delay time. If no delay time is required, these pins can be left open. To set the delay time, the external capacitor connected to DLY1 and DLY2 is charged with a constant current source of typically 4.8 µA. The delay time is terminated when the capacitor voltage has reached the internal reference voltage of Vref = 1.213 V. The external delay capacitor is calculated:

Example for setting a delay time of 2.3 mS:

Gate Drive Pin (GD)

This is an open-drain output that goes low when the boost converter, Vs, is within regulation. The gate drive pin GD remains low until the input voltage or enable EN2 is cycled to ground.

Undervoltage Lockout

To avoid misoperation of the device at low input voltages, an undervoltage lockout is included which shuts down the device at voltages lower than 6 V.

Input Capacitor Selection

For good input voltage filtering, low ESR ceramic capacitors are recommended. The TPS65160 has an analog input, AVIN, and two input pins for the buck converter VINB. A 1-µF input capacitor should be connected directly from the AVIN to GND. Two 22-µF ceramic capacitors are connected in parallel from the buck converter input VINB to GND. For better input voltage filtering, the input capacitor values can be increased. See Table 1 and the Application Information section for input capacitor recommendations.

www.ti.com

D  1 

Vin 

Vout

avg



(

1  D) lsw 

Vin

Vout

 2.8 A with lsw  minimum switch current of the TPS65160 (2.8 A).

swpeak



Vin D

2  ƒs  L



out

1  D

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

DETAILED DESCRIPTION (continued)

Table 1. Input Capacitor Selection

CAPACITOR VOLTAGE RATING COMPONENT SUPPLIER COMMENTS

22 µF/1210 16 V Taiyo Yuden EMK325BY226MM C

1 µF/1206 16 V Taiyo Yuden EMK316BJ106KL C

Boost Converter Design Procedure

The first step in the design procedure is to verify whether the maximum possible output current of the boost converter supports the specific application requirements. A simple approach is to use the converter efficiency, by taking the efficiency numbers from the provided efficiency curves or to use a worst-case assumption for the expected efficiency, e.g., 80%.

1. Duty Cycle:

2. Maximum output current:

3. Peak switch current:

(VINB)

(AVIN)

With

Isw = converter switch current (minimum switch current limit = 2.8 A) fs = converter switching frequency (typical 500 kHz/750 kHz) L = Selected inductor value η = Estimated converter efficiency (use the number from the efficiency curves or 0.8 as an estimation)

The peak switch current is the steady-state peak switch current that the integrated switch, inductor, and external Schottky diode must be able to handle. The calculation must be done for the minimum input voltage where the peak switch current is highest.

Inductor Selection (Boost Converter)

The TPS65160 operates typically with a 10-µH inductor. Other possible inductor values are 6.8-µH or 22-µH. The main parameter for the inductor selection is the saturation current of the inductor, which should be higher than the peak switch current as previously calculated, with additional margin to cover for heavy load transients. The alternative, more conservative approach, is to choose the inductor with saturation current at least as high as the typical switch current limit of 3.5 A. The second important parameter is the inductor DC resistance. Usually, the lower the DC resistance the higher the efficiency. The efficiency difference between different inductors can vary between 2% to 10%. Possible inductors are shown in Table 2 .

Table 2. Inductor Selection (Boost Converter)

INDUCTOR VALUE COMPONENT SUPPLIER DIMENSIONS in mm Isat/DCR

22 µH Coilcraft MSS1038-103NX 10,2 x 10,2 x 3,6 2.9 A/73 m Ω 22 µH Coilcraft DO3316-103 12,85 x 9,4 x 5,21 3.8 A/38 m Ω 10 µH Sumida CDRH8D43-100 8,3 x 8,3 x 4,5 4.0 A/29 m Ω 10 µH Sumida CDH74-100 7,3 x 8,0 x 5,2 2.75 A/43 m Ω 10 µH Coilcraft MSS1038-103NX 10,2 x 10,2 x 3,6 4.4 A/35 m Ω

6.8 µH Wuerth Elektronik 7447789006 7,3 x 7,3 x 3,2 2.5 A/44 m Ω

www.ti.com

D  1 

Vout

Vin

avg



(

1  D) lsw 

Vin

Vout

 2.8 A with lsw  minimum switch current of the TPS65160 (2.8 A).

out

 1.146 V 1 

R1 R2



Cƒƒ 

2    ƒz R1



2    10 kHz  R1

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

Output Capacitor Selection (Boost Converter)

For best output voltage filtering, a low ESR output capacitor is recommended. Ceramic capacitors have a low ESR value and work best with the TPS65160. Usually, three 22-µF ceramic output capacitors in parallel are sufficient for most applications. If a lower voltage drop during load transients is required, more output capacitance can be added. See Table 3 for the selection of the output capacitor.

Table 3. Output Capacitor Selection (Boost Converter)

CAPACITOR VOLTAGE RATING COMPONENT SUPPLIER

22 µF/1812 16 V Taiyo Yuden EMK432BJ226MM

Rectifier Diode Selection (Boost Converter)

To achieve high efficiency, a Schottky diode should be used. The reverse voltage rating should be higher than the maximum output voltage of the converter. The average rectified forward-current rating needed for the Schottky diode is calculated as the off-time of the converter times the maximum switch current of the TPS65160:

Usually, a Schottky diode with 2-A maximum average rectified forward-current rating is sufficient for most applications. Secondly, the Schottky rectifier has to be able to dissipate the power. The dissipated power is the average rectified forward current times the diode forward voltage.

= I

x V

avg

= Isw x (1 x D) x V

(with Isw = minimum switch current of the TPS65160 (2.6 A)

Table 4. Rectifier Diode Selection (Boost Converter)

CURRENT RATING Vr V

avg

3 A 20 V 0.36 at 3 A 46 ° C/W SMC MBRS320, International Rectifier 2 A 20 V 0.44 V at 3 A 75 ° C/W SMB SL22, Vishay Semiconductor 2 A 20 V 0.5 at 2 A 75 ° C/W SMB SS22, Fairchild Semiconductor

forward

R θ

SIZE COMPONENT SUPPLIER

Setting the Output Voltage and Selecting the Feedforward Capacitor (Boost Converter)

The output voltage is set by the external resistor divider and is calculated as:

Across the upper resistor, a bypass capacitor is required to achieve a good load transients response and to have a stable converter loop. Together with R1, the bypass capacitor Cff sets a zero in the control loop. Depending on the inductor value, the zero frequency needs to be set. For a 6.8-µH or 10-µH inductor, fz = 10 kHz and for a 22-µH inductor, fz = 7 kHz.

A value coming closest to the calculated value should be used.

Compensation (COMP) (Boost Converter)

The regulator loop can be compensated by adjusting the external components connected to the COMP pin. The COMP pin is the output of the internal transconductance error amplifier. A single capacitor connected to this pin sets the low-frequency gain. Usually, a 22-nF capacitor is sufficient for most of the applications. Adding a series resistor sets an additional zero and increases the high-frequency gain. The following formula calculates at what frequency the resistor increases the high-frequency gain.

www.ti.com



2    Cc  Rc

out

 1.213 V 1 

R1 R2





2    8 kHz  R1



2    8 kHz  2k

 9.9 nF  10 nF

(Example for the 3.3-V output)

IL Vout 

1 

Vout

Vin

L  ƒ

Lmax

 I

outmax



I

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

Lower input voltages require a higher gain and therefore a lower compensation capacitor value.

Step-Down Converter Design Procedure

Setting the Output Voltage

The step-down converter uses an external voltage divider to set the output voltage. The output voltage is calculated as:

with R1 as 1.2 k Ω , and internal reference voltage V(ref)typ = 1.213 V At load current <1 mA, the device operates in discontinuous conduction mode. When the load current is reduced

to zero, the output voltage rises slightly above the nominal output voltage. At zero load current, the device skips clock cycles but does not completely stop switching; thus, the output voltage sits slightly higher than the nominal output voltage. Therefore, the lower feedback resistor is selected to be around 1.2 k Ω to always have around 1-mA minimum load current.

Selecting the Feedforward Capacitor

The feedforward capacitor across the upper feedback resistor divider sets a zero in the converter loop transfer function. For a 15-µH inductor, fz = 8 kHz and when a 22-µH inductor is used, fz = 17 kHz.

Usually a capacitor value closest to the calculated value is selected.

Inductor Selection (Step-Down Converter)

The TPS65160 operates typically with a 15-µH inductor value. For high efficiencies the inductor should have a low DC resistance to minimize conduction losses. This needs to be considered when selecting the appropriate inductor. In order to avoid saturation of the inductor, the inductor should be rated at least for the maximum output current of the converter, plus the inductor ripple current that is calculated as:

With:

f = Switching frequency (750 kHz, 500 kHz minimal) L = Inductor value (typically 15 µH) ∆ IL= Peak-to-peak inductor ripple current I

= Maximum inductor current

Lmax

The highest inductor current occurs at maximum Vin. A more conservative approach is to select the inductor current rating just for the typical switch current of 2.6 A.

Table 5. Inductor Selection (Step-Down Converter)

INDUCTOR VALUE COMPONENT SUPPLIER DIMENSIONS in mm Isat/DCR

15 µH Sumida CDRH8D28-150 8,3 x 8,3 x 3,0 1.9 A/53 m Ω 15 µH Coilcraft MSS1038-153NX 10,2 x 10,2 x 3,6 3.6 A/50 m Ω 15 µH Wuerth 7447789115 7,3 x 7,3 x 3,2 1.75 A/100 m Ω

www.ti.com

D  1 

Vout

Vin

avg

 (1  D)  Isw  1 

Vout

Vin

 2 A with Isw  minimum switch current of the TPS65160 (2 A)

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

Rectifier Diode Selection (Step-Down Converter)

To achieve high efficiency, a Schottky diode should be used. The reverse voltage rating should be higher than the maximum output voltage of the step-down converter. The averaged rectified forward current at which the Schottky diode needs to be rated is calculated as the off-time of the step-down converter times the maximum switch current of the TPS65160:

Usually, a Schottky diode with 1.5-A or 2-A maximum average rectified forward current rating is sufficient for most applications. Secondly, the Schottky rectifier has to be able to dissipate the power. The dissipated power is the average rectified forward current times the diode forward voltage.

= I

x V

avg

CURRENT RATING Vr V

= Isw x (1 – D) x VFwith Isw = minimum switch current of the TPS65160 (2 A).

Table 6. Rectifier Diode Selection (Step-Down Converter)

avg

3 A 20 V 0.36 V at 3 A 46 ° C/W SMC MBRS320, International Rectifier 2 A 20 V 0.44 V at 2 A 75 ° C/W SMB SL22, Vishay Semiconductor 2 A 20 V 0.5 V at 2 A 75 ° C/W SMB SS22, Fairchild Semiconductor

1.5 A 20 V 0.445 V at 1.0 A 88 ° C/W SMA SL12, Vishay Semiconductor

forward

R θ

SIZE COMPONENT SUPPLIER

Output Capacitor Selection (Step-Down Converter)

The device is designed to work with ceramic output capacitors. When using a 15-µH inductor, two 22-µF ceramic output capacitors are recommended. More capacitance can be added to improve the load transient response.

Table 7. Output Selection (Boost Converter)

CAPACITOR VOLTAGE RATING COMPONENT SUPPLIER

22 µF/0805 6.3 V Taiyo Yuden JMK212BJ226MG

Layout Consideration

The PCB layout is an important step in the power supply design. An incorrect layout could cause converter instability, load regulation problems, noise, and EMI issues. Especially with a switching dc-dc converter at high load currents, too-thin PCB traces can cause significant voltage spikes. Good grounding becomes important as well. If possible, a common ground plane to minimize ground shifts between analog (GND) and power ground (PGND) is recommended. Additionally, the following PCB design layout guidelines are recommended for the TPS65160:

1. Separate the power supply traces for AVIN and VINB, and use separate bypass capacitors.

2. Use a short and wide trace to connect the OS pin to the output of the boost converter.

3. To minimize noise coupling into the OS pin, use a 470-pF bypass capacitor to GND.

4. Use short traces for the charge-pump drive pins (DRN, DRP) of VGH and VGL because these traces carry switching waveforms.

5. Place the flying capacitors as close as possible to the DRP and DRN pin, avoiding a high voltage spike at these pins.

6. Place the Schottky diodes as close as possible to the IC, respective to the flying capacitors connected to the DRP and DRN.

7. Route the feedback network of the negative charge pump away from the drive pin traces (DRN) of the negative charge pump. This avoids parasitic coupling into the feedback network of the negative charge pump giving good output voltage accuracy and load ragulation. To do this, use the FREQ pin and trace to isolate DRN from FBN.

www.ti.com

COMP

VINB

FREQ

EN1 EN2

DRN FBN REF

PGND

SW SW

AVIN

GND

DRP

FBP

Boot

SWB

DLY1

TPS65160

SL22

VINB

FBB

DLY2

SUP

Vin

12 V

2*22 F

1 F

C16

1 F

0.47 F

VGL

−5 V/50 mA

470 F

R3 620 k

R4 150 k

220 nF

22 nF

C10 10 nF

C11

10 nF

C17 22 nF

D6 SL22

15 H

Cb 100 nF

1.2 k

R7 2 k

C14 10 nF

C12 2*22 F

Vlogic

3.3 V/1.5 A

44.2 k

909 k

C13

0.47 F

VGH

26 V/50 mA

0.47 FC5

15 V/1.5 A

R2 56 k

C15 470 nF

C2 3*22 F

R1 680 k

22 pF

10 H

8 12 20 21 22

11 13 24

7 28 25

4 5 1 3 23 27 10 14 17 18 19 15 2 26

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

APPLICATION INFORMATION

Figure 19. Positive-Charge Pump Doubler Running From the Output V

Required When Higher VGH Voltages Are Needed.

(SUP = VS)

www.ti.com

1 F

0.47 F

VGL

−5 V/50 mA

470 F

R3 620 k

R4 150 k

220 nF

22 nF

C10 10 nF

C11

10 nF

C17 22 nF

D6 SL22

15 H

Cb 100 nF

1.2 k

R7 2 k

C14 10 nF

C13

0.47 F

Vlogic

3.3 V/1.5 A

56 k

1 M

VGH

23 V/50 mA

0.47 FC5

15 V/1.5 A

R2 56 k

C15 470 nF

3*22 F R1

680 k

22 pF

10 H

Vin

12 V

2*22 F

C16

1 F

COMP

VINB

FREQ

EN1 EN2 DRN FBN

REF PGND PGND

SW SW

AVIN

GND

DRP

FBP

Boot

SWB

DLY1

TPS65160

SL22

VINB

FBB

DLY2

SUP

SI2343

C18

220 nF

510 k

R10

100 k

C19 1 F

C12 2*22 F

8 12 20 21

22 16

11 13 24

7 28 25

4 5

1 3

23 27

10 14 17 18 19 15 2

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

APPLICATION INFORMATION (continued)

Figure 20. Driving an Isolation FET for V

using the GD Pin

www.ti.com

1 F

0.47 F

VGL

−5 V/50 mA

470 F

R3 620 k

R4 150 k

220 nF

22 nF

C10 10 nF

C17 22 nF

D6 SL22

15 H

Cb 100 nF

1.2 k

R7 2 k

C14 10 nF

C12 2*22 F

Vlogic

3.3 V/1.5 A

76 k

1 M

VGH

23 V/50 mA

0.47 FC5

13.5 V/2 A

C15 470 nF

C2 3*22 F

R1 820 k

22 pF

6.9 H

Vin

12 V  10%

2*22 F

COMP

VINB

FREQ

EN1 EN2 DRN FBN

REF PGND PGND

SW SW

AVIN

GND

DRP

FBP Boot SWB

DLY1

TPS65160

SL22

VINB

FBB

DLY2

SUP

C16

1 F

C11

10 nF

R2 75 k

C13

0.47 F

12 20

21 22

9 11 13

7 28 25

4 5

1 3 23 27 10

14 17 18

19 15 2 26

APPLICATION INFORMATION (continued)

TPS65160, TPS65160A

SLVS566B – MARCH 2005 – REVISED JULY 2005

Figure 21. 12-V to 13.5-V Conversion

PACKAGE OPTION ADDENDUM

www.ti.com

26-Jun-2006

PACKAGING INFORMATION

Orderable Device Status

(1)

Package

Type

Package Drawing

Pins Package

Qty

Eco Plan

TPS65160APWP ACTIVE HTSSOP PWP 28 50 Green (RoHS &

no Sb/Br)

TPS65160APWPG4 ACTIVE HTSSOP PWP 28 50 Green (RoHS &

no Sb/Br)

TPS65160APWPR ACTIVE HTSSOP PWP 28 2000 Green (RoHS &

no Sb/Br)

TPS65160APWPRG4 ACTIVE HTSSOP PWP 28 2000 Green (RoHS &

no Sb/Br)

TPS65160PWP ACTIVE HTSSOP PWP 28 50 Green (RoHS &

no Sb/Br)

TPS65160PWPG4 ACTIVE HTSSOP PWP 28 50 Green (RoHS &

no Sb/Br)

TPS65160PWPR ACTIVE HTSSOP PWP 28 2000 Green (RoHS &

no Sb/Br)

TPS65160PWPRG4 ACTIVE HTSSOP PWP 28 2000 Green (RoHS &

no Sb/Br)

(1)

The marketing status values are defined as follows:

ACTIVE: Product device recommended for new designs. LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect. NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in

a new design.

PREVIEW: Device has been announced but is not in production. Samples may or may not be available. OBSOLETE: TI has discontinued the production of the device.

(2)

Lead/Ball Finish MSL Peak Temp

CU NIPDAU Level-2-260C-1 YEAR

(3)

(2)

Eco Plan - The planned eco-friendly classification: Pb-Free (RoHS), Pb-Free (RoHS Exempt), or Green (RoHS & no Sb/Br) - please check

http://www.ti.com/productcontent for the latest availability information and additional product content details.

TBD: The Pb-Free/Green conversion plan has not been defined. Pb-Free (RoHS): TI's terms "Lead-Free" or "Pb-Free" mean semiconductor products that are compatible with the current RoHS requirements

for all 6 substances, including the requirement that lead not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered at high temperatures, TI Pb-Free products are suitable for use in specified lead-free processes. Pb-Free (RoHS Exempt): This component has a RoHS exemption for either 1) lead-based flip-chip solder bumps used between the die and package, or 2) lead-based die adhesive used between the die and leadframe. The component is otherwise considered Pb-Free (RoHS compatible) as defined above. Green (RoHS & no Sb/Br): TI defines "Green" to mean Pb-Free (RoHS compatible), and free of Bromine (Br) and Antimony (Sb) based flame retardants (Br or Sb do not exceed 0.1% by weight in homogeneous material)

(3)

MSL, Peak Temp. -- The Moisture Sensitivity Level rating according to the JEDEC industry standard classifications, and peak solder

temperature.

Important Information and Disclaimer:The information provided on this page represents TI's knowledge and belief as of the date that it is provided. TI bases its knowledge and belief on information provided by third parties, and makes no representation or warranty as to the accuracy of such information. Efforts are underway to better integrate information from third parties. TI has taken and continues to take reasonable steps to provide representative and accurate information but may not have conducted destructive testing or chemical analysis on incoming materials and chemicals. TI and TI suppliers consider certain information to be proprietary, and thus CAS numbers and other limited information may not be available for release.

In no event shall TI's liability arising out of such information exceed the total purchase price of the TI part(s) at issue in this document sold by TI to Customer on an annual basis.

Addendum-Page 1

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should obtain the latest relevant information before placing orders and should verify that such information is current and complete. All products are sold subject to TI’s terms and conditions of sale supplied at the time of order acknowledgment.

TI warrants performance of its hardware products to the specifications applicable at the time of sale in accordance with TI’s standard warranty. Testing and other quality control techniques are used to the extent TI deems necessary to support this warranty . Except where mandated by government requirements, testing of all parameters of each product is not necessarily performed.

TI assumes no liability for applications assistance or customer product design. Customers are responsible for their products and applications using TI components. To minimize the risks associated with customer products and applications, customers should provide adequate design and operating safeguards.

TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right, copyright, mask work right, or other TI intellectual property right relating to any combination, machine, or process in which TI products or services are used. Information published by TI regarding third-party products or services does not constitute a license from TI to use such products or services or a warranty or endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual property of the third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of information in TI data books or data sheets is permissible only if reproduction is without alteration and is accompanied by all associated warranties, conditions, limitations, and notices. Reproduction of this information with alteration is an unfair and deceptive business practice. TI is not responsible or liable for such altered documentation.

Resale of TI products or services with statements different from or beyond the parameters stated by TI for that product or service voids all express and any implied warranties for the associated TI product or service and is an unfair and deceptive business practice. TI is not responsible or liable for any such statements.

Following are URLs where you can obtain information on other Texas Instruments products and application solutions:

Products Applications

Amplifiers amplifier.ti.com Audio www.ti.com/audio Data Converters dataconverter.ti.com Automotive www.ti.com/automotive

DSP dsp.ti.com Broadband www.ti.com/broadband Interface interface.ti.com Digital Control www.ti.com/digitalcontrol Logic logic.ti.com Military www.ti.com/military Power Mgmt power.ti.com Optical Networking www.ti.com/opticalnetwork Microcontrollers microcontroller.ti.com Security www.ti.com/security Low Power Wireless www.ti.com/lpw Telephony www.ti.com/telephony

Video & Imaging www.ti.com/video Wireless www.ti.com/wireless

Mailing Address: Texas Instruments

Post Office Box 655303 Dallas, Texas 75265

TEXAS INSTRUMENTS TPS65160, TPS65160A Technical data

Specifications and Main Features

Frequently Asked Questions

User Manual

FEATURES

APPLICATIONS

DESCRIPTION

TYPICAL APPLICATION

DESCRIPTION (CONTINUED)

ABSOLUTE MAXIMUM RATINGS

DISSIPATION RATINGS

RECOMMENDED OPERATING CONDITIONS

ELECTRICAL CHARACTERISTICS

TYPICAL CHARACTERISTICS

BLOCK DIAGRAM

DETAILED DESCRIPTION

Boost Converter

Soft Start (Boost Converter)

Overvoltage Protection of the Boost Converter

Frequency Select Pin (FREQ)

Thermal Shutdown

Step-Down Converter

Short-Circuit Protection (Step-Down Converter)

Positive Charge Pump

Negative Charge Pump

Power-On Sequencing (EN1, EN2, DLY1, DLY2)

Setting the Delay Times DLY1, DLY2

Gate Drive Pin (GD)

Undervoltage Lockout

Input Capacitor Selection

Boost Converter Design Procedure

Inductor Selection (Boost Converter)

Output Capacitor Selection (Boost Converter)

Rectifier Diode Selection (Boost Converter)

Setting the Output Voltage and Selecting the Feedforward Capacitor (Boost Converter)

Compensation (COMP) (Boost Converter)

Step-Down Converter Design Procedure

Setting the Output Voltage

Selecting the Feedforward Capacitor

Inductor Selection (Step-Down Converter)

Rectifier Diode Selection (Step-Down Converter)

Output Capacitor Selection (Step-Down Converter)

Layout Consideration

APPLICATION INFORMATION
