About This Manual
Related Documentation From Texas Instruments
Preface
This user’s guide describes the characteristics, operation, and use of the
TPS61130EVM–206 SEPIC evaluation module (EVM). This EVM is a Texas
Instruments high-efficiency, single Li-Ion input, dual output (SEPIC and LDO)
converter that is configured to deliver 3.3 V at 300 mA and 1.5 V at 200 mA.
The 3.3-V output is provided by the SEPIC converter and the 1.5-V output is
provided by the integrated LDO. This user’s guide includes setup instructions,
a schematic diagram, a bill of materials (BOM), and PCB layout drawings for
the evaluation module.
How to Use This Manual
This document contains the following chapters:
- Chapter 1—Introduction
- Chapter 2—Setup
- Chapter 3—Board Layout
- Chapter 4—Schematic and Bill of Materials
Related Documentation From Texas Instruments
TPS61130 data sheet (SLVS431)
If You Need Assistance. . .
Contact your local TI sales representative.
v
Contents
FCC Warning
This equipment is intended for use in a laboratory test environment only. It generates, uses, and can radiate radio frequency energy and has not been tested
for compliance with the limits of computing devices pursuant to subpart J of
part 15 of FCC rules, which are designed to provide reasonable protection
against radio frequency interference. Operation of this equipment in other environments may cause interference with radio communications, in which case
the user at his own expense will be required to take whatever measures may
be required to correct this interference.
vi
Contents
1 Introduction 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Setup 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Input/Output Connector Descriptions 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.1 J1 – VBAT 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.2 J2 – GND 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.3 J3 – VOUT 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.4 J4 – GND 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.5 J5 – LDOOUT 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.6 J6 – GND 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.7 J7 – PGOOD, LBO 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.8 JP1 – SKIPEN 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.9 JP2 – EN 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.10 JP3 – LDOEN 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1.11 JP4 – LDOIN 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Setup 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Operation 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Board Layout 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Layout 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Schematic and Bill of Materials 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 Schematic 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Bill of Materials 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
vii
Contents
3–1 Top Layer 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–2 Bottom Layer 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–3 Top Assembly 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4–1 TPS61130EVM–206 Schematic 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4–1. TPS61130EVM–206 Bill of Materials 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
viii
Chapter 1
The Texas Instruments TPS61130EVM evaluation module (EVM) helps
designers evaluate the operation and performance of the TPS61 130 family of
devices. These devices are high efficiency SEPIC converters that offer an
integrated LDO.
This EVM is specifically designed and optimized to operate from a Li-Ion input
(3.0 V to 4.2 V). Operation at input voltages less than 3.0 V is possible with
reduced output current. The default output voltages of this EVM are 3.3 V for
the SEPIC output and 1.5 V for the LDO output. If desired, this EVM can easily
be modified to supply higher or lower output voltages. The SEPIC converter
can be set up to provide an output voltage between 2.5 V and 5.5 V. The LDO
can be set up to provide an output voltage between 0.9 V and 5.5 V. Output
voltages other than the default values may be evaluated by adjusting the
appropriate feedback resistor dividers. Also, other fixed output voltage
versions of the devices can be easily evaluated using this EVM. Refer to the
data sheet (SLVS431) for the various fixed output voltage options available in
the TPS6113x device family as well as for more information on adjusting the
output voltage.
1-1
1-2
Chapter 2
This chapter describes the jumpers and connectors on the EVM as well as how
to properly connect, setup, and use the TPS61130EVM–206.
Topic Page
2.1 Input/Output Connector Descriptions 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Setup 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Operation 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup
2-1
Input/Output Connector Descriptions
2.1 Input/Output Connector Descriptions
2.1.1 J1 – VBAT
This is t h e p o sitive connection to the input power supply. The leads to the input
supply should be twisted and kept as short as possible to minimize EMI
transmission.
2.1.2 J2 – GND
This is the return connection for the input power supply.
2.1.3 J3 – VOUT
This is the positive connection from the output of the SEPIC power supply.
Connect this pin to the positive input of the load.
2.1.4 J4 – GND
This is the negative connection from the output of the SEPIC power supply.
Connect this pin to the negative input of the load.
2.1.5 J5 – LDOOUT
This is the positive connection from the output of the LDO power supply.
Connect this pin to the positive input of the load.
2.1.6 J6 – GND
This is the negative connection from the output of the LDO power supply.
Connect this pin to the negative input of the load.
2.1.7 J7 – PGOOD, LBO
Pin 1 of this jumper is the PGOOD output of the TPS61130. Pin 2 of this jumper
is the LBO output of the TPS61130. Both signals are pulled up to Vout through
a 1-MΩ resistor on the PCB.
2.1.8 JP1 – SKIPEN
This jumper enables or disables SKIPEN by connecting the shorting jumper
to either the ON or OFF position. With SKIPEN set ON the part goes into a
more efficient pulse skip mode of operation at light loads.
2.1.9 JP2 – EN
This jumper enables and disables the SEPIC portion of the EVM.
2.1.10 JP3 – LDOEN
This jumper enables and disables the LDO portion of the EVM.
2-2
2.1.11 JP4 – LDOIN
2.2 Setup
2.3 Operation
Setup
This is the input connection to the integrated LDO of the TPS61130. Shorting
the VBAT pin and the center pin connects the VBAT input of the EVM to the
LDOIN on the TPS61130. Shorting the VOUT pin and the center pin connects
the VOUT pin of the EVM to the LDOIN on the TPS61130. This jumper may
be removed and any voltage up to 5.5 V can be applied to the input of the LDO
by directly connecting a voltage source to the center pin of JP4.
Connect an input supply between J1 and J2. The voltage range on this supply
should stay b e t w ee n 3.0 V and 5.5 V. Connect a load for the SEPIC converter
between J3 and J4. Connect a load for the LDO between J5 and J6. Configure
the SKIPEN jumper to the desired setting. Configure JP4 to provide power to
the LDO from the desired source.
The EVM has been optimized to operate from a Li-Ion battery input voltage
range (3.0 V to 4.2 V). The SEPIC output voltage is set to 3.3 V and is capable
of supplying 300 mA. The LDO output is set to 1.5 V and is capable of supplying
200 mA. After connecting the input and output connections, and setting the
SKIPEN jumper (JP1) to the desired setting, turn on the input supply, and then
enable the outputs as desired with JP2 and JP3.
The resistor divider on the LBI pin is designed to trip the LBO output when the
input supply voltage drops below 2.9 V.
Setup
2-3
2-4
Chapter 3
This chapter provides the TPS61130EVM–206 board layout and illustrations.
Topic Page
3.1 Layout 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Board Layout
3-1
Layout
3.1 Layout
Figure 3–1.Top Layer
Board layout is critical for all switch mode power supplies. Figures 1, 2, and
3 show the board layout for the TPS61130EVM–206 PWB. The nodes with
high switching frequencies and currents are short and are isolated from the
noise sensitive feedback circuitry. Careful attention has been given to the routing of high frequency current loops. Refer to the data sheet for specific layout
guidelines.
Figure 3–2.Bottom Layer
3-2
Figure 3–3.Top Assembly
Layout
Board Layout
3-3
3-4
Chapter 4
This chapter provides the TPS61130EVM–206 schematic and bill of materials.
Topic Page
4.1 Schematic 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Bill of Materials 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Schematic and Bill of Materials
4-1
Schematic
4.1 Schematic
Figure 4–1.TPS61130EVM–206 Schematic
+
4.2 Bill of Materials
Table 4–1.TPS61130EVM–206 Bill of Materials
COUNT Ref Des DESCRIPTION SIZE MFR PART NUMBER
3 C1, C5, C6 Capacitor, ceramic, 2.2-µF, 6.3-V,
X5R, 10%
1 C3 Capacitor, ceramic, 10-µF, 6.3-V,
X5R, 10%
1 C4 Capacitor, tantalum, 120-µF, 10-V,
140-mΩ, 20%
1 C7 Capacitor, ceramic, 22-µF, 10-V,
X5R, 10%
7 J1– J7 Header, 2-pin, 100-mil spacing,
(36-pin strip)
4 JP1–JP4 Header, 3-pin, 100-mil spacing,
(36-pin strip)
1 L1 Inductor, SMT, 22-µH, 811-mA,
429-mΩ
1 R1 Resistor, chip, 845-kΩ, 1/16-W, 1% 603 Std Std
3 R2, R4, R6 Resistor, chip, 178-kΩ, 1/16-W, 1% 603 Std Std
3 R3, R7, R9 Resistor, chip, 1-MΩ, 1/16-W, 1% 603 Std Std
1 R5 Resistor, chip, 357-kΩ, 1/16-W, 1% 603 Std Std
1 U1 IC, single cell or dual cell Li-Ion
boost/sepic converter
1 –– PCB, 2.6 In x 1.6 In x 0.062 In Any SLVP206
4 –– Shunt, 100-mil, black 0.100 In 3M 929950–00
805 Murata GRM21BR60J225KC01B
805 Murata GRM21BR60J106KE01
7343 (D) Vishay 595D127X0010D2T
1210 Murata GRM32ER61A226KA65
0.100 In x 2 In Sullins PTC36SAAN
0.100 In x 3 In Sullins PTC36SAAN
0.300 In x 0.300 In Coiltronics DRQ74–220
TSSOP-16 TI TPS61130PW
4-2
Loading...
