TMS320R2811, TMS320R2812

Digital Signal Processors

Data Manual

Literature Number: SPRS257C

June 2004 − Revised June 2006

                      !     !   

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should obtain the latest relevant information before placing orders and should verify that such information is current and complete. All products are sold subject to TI’s terms and conditions of sale supplied at the time of order acknowledgment.

TI warrants performance of its hardware products to the specifications applicable at the time of sale in accordance with TI’s standard warranty. Testing and other quality control techniques are used to the extent TI deems necessary to support this warranty. Except where mandated by government requirements, testing of all parameters of each product is not necessarily performed.

TI assumes no liability for applications assistance or customer product design. Customers are responsible for their products and applications using TI components. To minimize the risks associated with customer products and applications, customers should provide adequate design and operating safeguards.

TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right, copyright, mask work right, or other TI intellectual property right relating to any combination, machine, or process in which TI products or services are used. Information published by TI regarding third-party products or services does not constitute a license from TI to use such products or services or a warranty or endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual property of the third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of information in TI data books or data sheets is permissible only if reproduction is without alteration and is accompanied by all associated warranties, conditions, limitations, and notices. Reproduction of this information with alteration is an unfair and deceptive business practice. TI is not responsible or liable for such altered documentation.

Resale of TI products or services with statements different from or beyond the parameters stated by TI for that product or service voids all express and any implied warranties for the associated TI product or service and is an unfair and deceptive business practice. TI is not responsible or liable for any such statements.

Following are URLs where you can obtain information on other Texas Instruments products and application solutions:

Products

Applications

Amplifiers amplifier.ti.com Audio www.ti.com/audio

Data Converters dataconverter.ti.com Automotive www.ti.com/automotive

DSP dsp.ti.com Broadband www.ti.com/broadband

Interface interface.ti.com Digital Control www.ti.com/digitalcontrol

Logic logic.ti.com Military www.ti.com/military

Power Mgmt power.ti.com Optical Networking www.ti.com/opticalnetwork

Microcontrollers microcontroller.ti.com Security www.ti.com/security

Low Power Wireless www.ti.com/lpw Telephony www.ti.com/telephony

Video & Imaging www.ti.com/video

Wireless www.ti.com/wireless

Mailing Address: Texas Instruments Post Office Box 655303 Dallas, Texas 75265

Revision History

REVISION HISTORY

This data sheet revision history highlights the technical changes made to the SPRS257B device-specific data sheet to make it an SPRS257C revision.

PAGE

NO.

23−24 Modified description of EMU0 and EMU1 in Table 2−2

100 Modified note under Table 6−9 100 Modified note under Table 6−10 and changed values from MIN to MAX 100 Moved values from MIN to MAX in Table 6−12 101 Moved values from MIN to MAX in Table 6−14

ADDITIONS/CHANGES/DELETIONS

13 Changed Temperature Options bullet in Features list 15 Added a separate row to Table 2−1 Hardware Features to modify Q temperature options 20 Modified symbol (§) note in Table 2−2 23 Modified Note in description of TRST in Table 2−2

31 Modified memory map in Figure 3−2 32 Modified memory map in Figure 3−3 87 Added the ZHH package to the Absolute Maximum Ratings table (6.1) 88 Added X1 to XCLKIN in the Recommended Operating Conditions table (6.2) 93 Modified XCLKIN values in Table 6−3

102 Modified note C in Figure 6−13 103 Modified the last symbol note ( 109 Modified note in Figure 6−22

111 Modified note in Figure 6−23 105 Modified note on Table 6−19 105 Modified note on Table 6−20

113 Modified note on Figure 6−24 127 Deleted last sentence in the fifth paragraph under section 6.27 XHOLD and XHOLDA 131 Modified gain error and internal voltage reference values in Table 6−41

||)

in Table 6−16

June 2004 − Revised June 2006 SPRS257C

Revision History

This page intentionally left blank.

June 2004 − Revised June 2006SPRS257C

Contents

Section Page

1 Features 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Introduction 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 Description 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Device Summary 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Pin Assignments 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3.1 Terminal Assignments for the GHH and ZHH Packages 16. . . . . . . . . . . . . . . . . . .

2.3.2 Pin Assignments for the PGF Package 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3.3 Pin Assignments for the PBK Package 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4 Signal Descriptions 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Functional Overview 30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 Memory Map 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 Brief Descriptions 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.1 C28x CPU 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.2 Memory Bus (Harvard Bus Architecture) 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.3 Peripheral Bus 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.4 Real-Time JTAG and Analysis 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.5 External Interface (XINTF) (2812 Only) 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.6 M0, M1 SARAMs 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.7 L0, L1, L2, L3, H0 SARAMs 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.8 Boot ROM 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.9 Security 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.10 Peripheral Interrupt Expansion (PIE) Block 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.11 External Interrupts (XINT1, 2, 13, XNMI) 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.12 Oscillator and PLL 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.13 Watchdog 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.14 Peripheral Clocking 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.15 Low-Power Modes 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.16 Peripheral Frames 0, 1, 2 (PFn) 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.17 General-Purpose Input/Output (GPIO) Multiplexer 37. . . . . . . . . . . . . . . . . . . . . . . .

3.2.18 32-Bit CPU-Timers (0, 1, 2) 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.19 Control Peripherals 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2.20 Serial Port Peripherals 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3 Register Map 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4 Device Emulation Registers 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.5 External Interface, XINTF (2812 Only) 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.5.1 Timing Registers 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.5.2 XREVISION Register 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.6 Interrupts 43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.6.1 External Interrupts 46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.7 System Control 47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.7.1 OSC and PLL Block 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.7.2 Loss of Input Clock 49. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.7.3 PLL-Based Clock Module 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.7.4 External Reference Oscillator Clock Option 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.7.5 Watchdog Block 51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.7.6 Low-Power Modes Block 51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4 Peripherals 53. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.1 32-Bit CPU-Timers 0/1/2 53. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

June 2004 − Revised June 2006 SPRS257C

Contents

4.2 Event Manager Modules (EVA, EVB) 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2.1 General-Purpose (GP) Timers 58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2.2 Full-Compare Units 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2.3 Programmable Deadband Generator 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2.4 PWM Waveform Generation 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2.5 Double Update PWM Mode 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2.6 PWM Characteristics 59. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2.7 Capture Unit 60. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2.8 Quadrature-Encoder Pulse (QEP) Circuit 60. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2.9 External ADC Start-of-Conversion 60. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.3 Enhanced Analog-to-Digital Converter (ADC) Module 61. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.4 Enhanced Controller Area Network (eCAN) Module 66. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.5 Multichannel Buffered Serial Port (McBSP) Module 70. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.6 Serial Communications Interface (SCI) Module 73. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.7 Serial Peripheral Interface (SPI) Module 76. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.8 GPIO MUX 80. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5 Development Support 83. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.1 Device and Development Support Tool Nomenclature 83. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.2 Documentation Support 84. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6 Electrical Specifications 87. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.1 Absolute Maximum Ratings 87. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.2 Recommended Operating Conditions† 88. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.3 Electrical Characteristics Over Recommended Operating Conditions

(Unless Otherwise Noted) 88. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.4 Current Consumption by Power-Supply Pins Over Recommended Operating Conditions

During Low-Power Modes at 150-MHz SYSCLKOUT (TMS320R281x) 89. . . . . . . . . . . . . . . . . .

6.5 Current Consumption Graphs 89. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.6 Reducing Current Consumption 90. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.7 Power Sequencing Requirements 90. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.8 Signal Transition Levels 91. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.9 Timing Parameter Symbology 92. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.10 General Notes on Timing Parameters 92. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.11 Test Load Circuit 92. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.12 Device Clock Table 93. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.13 Clock Requirements and Characteristics 93. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.13.1 Input Clock Requirements 93. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.13.2 Output Clock Characteristics 95. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.14 Reset Timing 95. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.15 Low-Power Mode Wakeup Timing 100. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.16 Event Manager Interface 103. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.16.1 PWM Timing 103. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.16.2 Interrupt Timing 105. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.17 General-Purpose Input/Output (GPIO) − Output Timing 106. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.18 General-Purpose Input/Output (GPIO) − Input Timing 107. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.19 SPI Master Mode Timing 108. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.20 SPI Slave Mode Timing 112. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.21 External Interface (XINTF) Timing 115. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.22 XINTF Signal Alignment to XCLKOUT 117. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.23 External Interface Read Timing 119. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.24 External Interface Write Timing 120. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

June 2004 − Revised June 2006SPRS257C

Contents

6.25 External Interface Ready-on-Read Timing With One External Wait State 121. . . . . . . . . . . . . . . .

6.26 External Interface Ready-on-Write Timing With One External Wait State 124. . . . . . . . . . . . . . . .

6.27 XHOLD

and XHOLDA 127. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.28 XHOLD/XHOLDA Timing 128. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.29 On-Chip Analog-to-Digital Converter 130. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.29.1 ADC Absolute Maximum Ratings 130. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.29.2 ADC Electrical Characteristics Over Recommended Operating Conditions 131. .

6.29.3 Current Consumption for Different ADC Configurations

(at 25-MHz ADCCLK) 132. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.29.4 ADC Power-Up Control Bit Timing 133. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.29.5 Detailed Description 134. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.29.5.1 Reference Voltage 134. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.29.5.2 Analog Inputs 134. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.29.5.3 Converter 134. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.29.5.4 Conversion Modes 134. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.29.6 Sequential Sampling Mode (Single-Channel) (SMODE = 0) 134. . . . . . . . . . . . . . .

6.29.7 Simultaneous Sampling Mode (Dual-Channel) (SMODE = 1) 136. . . . . . . . . . . . . .

6.29.8 Definitions of Specifications and Terminology 137. . . . . . . . . . . . . . . . . . . . . . . . . . .

6.30 Multichannel Buffered Serial Port (McBSP) Timing 138. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.30.1 McBSP Transmit and Receive Timing 138. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.30.2 McBSP as SPI Master or Slave Timing 141. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7 Migration From F281x Devices 145. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

8 Mechanical Data 147. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

June 2004 − Revised June 2006 SPRS257C

Figures

List of Figures

Figure Page

Figure 2−1. TMS320R2812 179-Ball GHH and ZHH MicroStar BGA (Bottom View) 16. . . . . . . . . . . . . . . . . . . . . .

Figure 2−2. TMS320R2812 176-Pin PGF LQFP (Top View) 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 2−3. TMS320R2811 128-Pin PBK LQFP (Top View) 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3−1. Functional Block Diagram 30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3−2. R2812 Memory Map 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3−3. R2811 Memory Map 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3−4. External Interface Block Diagram 42. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3−5. Interrupt Sources 43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3−6. Multiplexing of Interrupts Using the PIE Block 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3−7. Clock and Reset Domains 47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3−8. OSC and PLL Block 49. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3−9. Recommended Crystal/Clock Connection 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 3−10. Watchdog Module 51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4−1. CPU-Timers 53. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4−2. CPU-Timer Interrupts Signals and Output Signal 54. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4−3. Event Manager A Functional Block Diagram 58. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4−4. Block Diagram of the R281x ADC Module 62. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4−5. ADC Pin Connections With Internal Reference 63. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4−6. ADC Pin Connections With External Reference 64. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4−7. eCAN Block Diagram and Interface Circuit 67. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4−8. eCAN Memory Map 68. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4−9. McBSP Module With FIFO 71. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4−10. Serial Communications Interface (SCI) Module Block Diagram 75. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4−11. Serial Peripheral Interface Module Block Diagram (Slave Mode) 79. . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 4−12. GPIO/Peripheral Pin MUXing 82. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 5−1. TMS320x28x Device Nomenclature 84. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−1. Typical Current Consumption Over Frequency 89. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−2. Typical Power Consumption Over Frequency 90. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−3. Output Levels 91. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−4. Input Levels 91. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−5. 3.3-V Test Load Circuit 92. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−6. Clock Timing 95. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−7. Power-on Reset in Microcomputer Mode (XMP/MC = 0) 96. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−8. Power-on Reset in Microprocessor Mode (XMP/MC = 1) 97. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−9. Warm Reset in Microcomputer Mode 98. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−10. Effect of Writing Into PLLCR Register 99. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−11. IDLE Entry and Exit Timing 100. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−12. STANDBY Entry and Exit Timing 101. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−13. HALT Wakeup Using XNMI 102. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−14. PWM Output Timing 103. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

June 2004 − Revised June 2006SPRS257C

Figure 6−15. TDIRx Timing 103. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−16. EVASOC Timing 104. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−17. EVBSOC Timing 104. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−18. External Interrupt Timing 106. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−19. General-Purpose Output Timing 106. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−20. GPIO Input Qualifier − Example Diagram for QUALPRD = 1 107. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−21. General-Purpose Input Timing 107. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−22. SPI Master Mode External Timing (Clock Phase = 0) 109. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−23. SPI Master External Timing (Clock Phase = 1) 111. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−24. SPI Slave Mode External Timing (Clock Phase = 0) 113. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−25. SPI Slave Mode External Timing (Clock Phase = 1) 114. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−26. Relationship Between XTIMCLK and SYSCLKOUT 117. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−27. Example Read Access 119. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−28. Example Write Access 120. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−29. Example Read With Synchronous XREADY Access 122. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−30. Example Read With Asynchronous XREADY Access 123. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−31. Write With Synchronous XREADY Access 125. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−32. Write With Asynchronous XREADY Access 126. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−33. External Interface Hold Waveform 128. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−34. XHOLD/XHOLDA Timing Requirements (XCLKOUT = 1/2 XTIMCLK) 129. . . . . . . . . . . . . . . . . . . . .

Figure 6−35. ADC Analog Input Impedance Model 133. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−36. ADC Power-Up Control Bit Timing 133. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−37. Sequential Sampling Mode (Single-Channel) Timing 135. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−38. Simultaneous Sampling Mode Timing 136. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−39. McBSP Receive Timing 140. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−40. McBSP Transmit Timing 140. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Figure 6−41. McBSP Timing as SPI Master or Slave: CLKSTP = 10b, CLKXP = 0 141. . . . . . . . . . . . . . . . . . . . . .

Figure 6−42. McBSP Timing as SPI Master or Slave: CLKSTP = 11b, CLKXP = 0 142. . . . . . . . . . . . . . . . . . . . . .

Figure 6−43. McBSP Timing as SPI Master or Slave: CLKSTP = 10b, CLKXP = 1 143. . . . . . . . . . . . . . . . . . . . . .

Figure 6−44. McBSP Timing as SPI Master or Slave: CLKSTP = 11b, CLKXP = 1 144. . . . . . . . . . . . . . . . . . . . . .

Figures

June 2004 − Revised June 2006 SPRS257C

Tables

List of Tables

Table Page

Table 2−1. Hardware Features 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2−2. Signal Descriptions 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−1. Wait States 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−2. Boot Mode Selection 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−3. Peripheral Frame 0 Registers 39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−4. Peripheral Frame 1 Registers 39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−5. Peripheral Frame 2 Registers 39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−6. Device Emulation Registers 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−7. XINTF Configuration and Control Register Mappings 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−8. XREVISION Register Bit Definitions 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−9. PIE Peripheral Interrupts 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−10. PIE Configuration and Control Registers 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−11. External Interrupt Registers 46. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−12. PLL, Clocking, Watchdog, and Low-Power Mode Registers 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−13. PLLCR Register Bit Definitions 49. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−14. Possible PLL Configuration Modes 50. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 3−15. R281x Low-Power Modes 52. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4−1. CPU-Timers 0, 1, 2 Configuration and Control Registers 55. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4−2. Module and Signal Names for EVA and EVB 56. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4−3. EVA Registers 57. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4−4. ADC Registers 65. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4−5. 3.3-V eCAN Transceivers for the R281x DSPs 67. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4−6. CAN Registers Map 69. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4−7. McBSP Register Summary 72. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4−8. SCI-A Registers 76. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4−9. SCI-B Registers 76. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4−10. SPI Registers 78. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4−11. GPIO MUX Registers 80. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 4−12. GPIO Data Registers 81. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−1. Typical Current Consumption by Various Peripherals (at 150 MHz) 90. . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−2. TMS320R281x Clock Table and Nomenclature 93. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−3. Input Clock Frequency 93. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−4. XCLKIN Timing Requirements − PLL Bypassed or Enabled 94. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−5. XCLKIN Timing Requirements − PLL Disabled 94. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−6. Possible PLL Configuration Modes 94. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−7. XCLKOUT Switching Characteristics (PLL Bypassed or Enabled) 95. . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−8. Reset (XRS) Timing Requirements 95. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−9. IDLE Mode Timing Requirements 100. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−10. IDLE Mode Switching Characteristics 100. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−11. STANDBY Mode Timing Requirements 100. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−12. STANDBY Mode Switching Characteristics 100. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−13. HALT Mode Timing Requirements 101. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−14. HALT Mode Switching Characteristics 101. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−15. PWM Switching Characteristics†‡ 103. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−16. Timer and Capture Unit Timing Requirements 103. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−17. External ADC Start-of-Conversion − EVA − Switching Characteristics† 104. . . . . . . . . . . . . . . . . . . . .

June 2004 − Revised June 2006SPRS257C

Table 6−18. External ADC Start-of-Conversion − EVB − Switching Characteristics 104. . . . . . . . . . . . . . . . . . . . . .

Table 6−19. Interrupt Switching Characteristics 105. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−20. Interrupt Timing Requirements 105. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−21. General-Purpose Output Switching Characteristics 106. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−22. General-Purpose Input Timing Requirements 107. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−23. SPI Master Mode External Timing (Clock Phase = 0) 108. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−24. SPI Master Mode External Timing (Clock Phase = 1) 110. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−25. SPI Slave Mode External Timing (Clock Phase = 0) 112. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−26. SPI Slave Mode External Timing (Clock Phase = 1) 114. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−27. Relationship Between Parameters Configured in XTIMING and Duration of Pulse 115. . . . . . . . . . . .

Table 6−28. XINTF Clock Configurations 117. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−29. External Memory Interface Read Switching Characteristics 119. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−30. External Memory Interface Read Timing Requirements 119. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−31. External Memory Interface Write Switching Characteristics 120. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−32. External Memory Interface Read Switching Characteristics (Ready-on-Read, 1 Wait State) 121. . . .

Table 6−33. External Memory Interface Read Timing Requirements (Ready-on-Read, 1 Wait State) 121. . . . . .

Table 6−34. Synchronous XREADY Timing Requirements (Ready-on-Read, 1 Wait State) 121. . . . . . . . . . . . . . .

Table 6−35. Asynchronous XREADY Timing Requirements (Ready-on-Read, 1 Wait State) 121. . . . . . . . . . . . . .

Table 6−36. External Memory Interface Write Switching Characteristics (Ready-on-Write, 1 Wait State) 124. . .

Table 6−37. Synchronous XREADY Timing Requirements (Ready-on-Write, 1 Wait State) 124. . . . . . . . . . . . . . .

Table 6−38. Asynchronous XREADY Timing Requirements (Ready-on-Write, 1 Wait State) 124. . . . . . . . . . . . . .

Table 6−39. XHOLD/XHOLDA Timing Requirements (XCLKOUT = XTIMCLK) 128. . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−40. XHOLD/XHOLDA Timing Requirements (XCLKOUT = 1/2 XTIMCLK) 129. . . . . . . . . . . . . . . . . . . . . .

Table 6−41. DC Specifications 131. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−42. AC Specifications 132. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−43. ADC Power-Up Delays 133. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−44. Sequential Sampling Mode Timing 135. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−45. Simultaneous Sampling Mode Timing 136. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−46. McBSP Timing Requirements 138. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−47. McBSP Switching Characteristics 139. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 6−48. McBSP as SPI Master or Slave Timing Requirements (CLKSTP = 10b, CLKXP = 0) 141. . . . . . . . .

Table 6−49. McBSP as SPI Master or Slave Switching Characteristics (CLKSTP = 10b, CLKXP = 0) 141. . . . . .

Table 6−50. McBSP as SPI Master or Slave Timing Requirements (CLKSTP = 11b, CLKXP = 0) 142. . . . . . . . . .

Table 6−51. McBSP as SPI Master or Slave Switching Characteristics (CLKSTP = 11b, CLKXP = 0) 142. . . . . .

Table 6−52. McBSP as SPI Master or Slave Timing Requirements (CLKSTP = 10b, CLKXP = 1) 143. . . . . . . . .

Table 6−53. McBSP as SPI Master or Slave Switching Characteristics (CLKSTP = 10b, CLKXP = 1) 143. . . . . .

Table 6−54. McBSP as SPI Master or Slave Timing Requirements (CLKSTP = 11b, CLKXP = 1) 144. . . . . . . . . .

Table 6−55. McBSP as SPI Master or Slave Switching Characteristics (CLKSTP = 11b, CLKXP = 1) 144. . . . . .

Table 6−56. Feature Comparison Between F281x and R281x Devices 145. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 7−1. Thermal Resistance Characteristics for 179-GHH 147. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 7−2. Thermal Resistance Characteristics for 179-ZHH 147. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 7−3. Thermal Resistance Characteristics for 176-PGF 147. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 7−4. Thermal Resistance Characteristics for 128-PBK 147. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Tables

June 2004 − Revised June 2006 SPRS257C

Tables

June 2004 − Revised June 2006SPRS257C

1 Features

Features

D High-Performance Static CMOS Technology

− 150 MHz (6.67-ns Cycle Time)

− Low-Power (1.8-V Core @135 MHz, 1.9-V Core @150 MHz, 3.3-V I/O) Design

D JTAG Boundary Scan Support

†

D High-Performance 32-Bit CPU

(TMS320C28x)

− 16 x 16 and 32 x 32 MAC Operations

− 16 x 16 Dual MAC

− Harvard Bus Architecture

− Atomic Operations

− Fast Interrupt Response and Processing

− Unified Memory Programming Model

− 4M Linear Program/Data Address Reach

− Code-Efficient (in C/C++ and Assembly)

− Code and Pin Compatible to F2810, F2811, and F2812 devices

− TMS320F24x/LF240x Processor Source Code Compatible

D On-Chip Memory

− 20K x 16 Total Single-Access RAM (SARAM)

− L0 and L1: 2 Blocks of 4K x 16 Each

SARAM

− L2 and L3: 2 Blocks of 1K X 16 SARAM

− H0: 1 Block of 8K x 16 SARAM

− M0 and M1: 2 Blocks of 1K x 16 Each

SARAM

D SPI, SCI, and GPIO Boot Loader Modes to

Support Loading Code From Off-chip Sources to On-chip RAM. SPI Boot Mode Supports Loading From an External Serial EEPROM.

D Boot ROM (4K x 16)

− With Software Boot Modes

− Standard Math Tables

D External Interface (2812)

− Up to 1M Total Memory

− Programmable Wait States

− Programmable Read/Write Strobe Timing

− Three Individual Chip Selects

D Clock and System Control

− Dynamic PLL Ratio Changes Supported

− On-Chip Oscillator

− Watchdog Timer Module

D Three External Interrupts D Peripheral Interrupt Expansion (PIE) Block

That Supports 45 Peripheral Interrupts

D Three 32-Bit CPU-Timers D Motor Control Peripherals

− Two Event Managers (EVA, EVB)

− Compatible to 240xA Devices

D Serial Port Peripherals

− Serial Peripheral Interface (SPI)

− Two Serial Communications Interfaces (SCIs), Standard UART

− Enhanced Controller Area Network (eCAN)

− Multichannel Buffered Serial Port (McBSP)

D 12-Bit ADC, 16 Channels

− 2 x 8 Channel Input Multiplexer

− Two Sample-and-Hold

− Single/Simultaneous Conversions

− Fast Conversion Rate: 80 ns/12.5 MSPS

D Up to 56 General Purpose I/O (GPIO) Pins D Advanced Emulation Features

− Analysis and Breakpoint Functions

− Real-Time Debug via Hardware

D Development Tools Include

− ANSI C/C++ Compiler/Assembler/Linker

− Code Composer Studio IDE

− DSP/BIOS

− JTAG Scan Controllers

†

D Low-Power Modes and Power Savings

− IDLE, STANDBY, HALT Modes Supported

− Disable Individual Peripheral Clocks

D Package Options

− 179-Ball MicroStar BGA With External Memory Interface (GHH), (ZHH) (2812)

− 176-Pin Low-Profile Quad Flatpack (LQFP) With External Memory Interface (PGF) (2812)

− 128-Pin LQFP Without External Memory Interface (PBK) (2811)

D Temperature Options:

− A: −40°C to 85°C (GHH, ZHH, PGF, PBK)

− S: −40°C to 125°C (GHH, ZHH, PGF, PBK)

− Q: −40°C to 125°C (PGF, PBK)

TMS320C24x, Code Composer Studio, DSP/BIOS, and MicroStar BGA are trademarks of Texas Instruments. †

IEEE Standard 1149.1−1990, IEEE Standard Test-Access Port

June 2004 − Revised June 2006 SPRS257C

Introduction

2 Introduction

This section provides a summary of each device’s features, lists the pin assignments, and describes the function of each pin. This document also provides detailed descriptions of peripherals, electrical specifications, parameter measurement information, and mechanical data about the available packaging.

2.1 Description

The TMS320R2811 and TMS320R2812 devices, members of the TMS320C28x DSP generation, are highly integrated, high-performance solutions for demanding control applications. The functional blocks and the memory maps are described in Section 3, Functional Overview.

Throughout this document, TMS320R2811 and TMS320R2812 are abbreviated as R2811 and R2812, respectively.

TMS320C28x is a trademark of Texas Instruments. All trademarks are the property of their respective owners.

June 2004 − Revised June 2006SPRS257C

Introduction

Temperature Options

2.2 Device Summary

Table 2−1 provides a summary of each device’s features.

Table 2−1. Hardware Features

FEATURE R2811 R2812

Instruction Cycle (at 150 MHz) 6.67 ns 6.67 ns Single-Access RAM (SARAM)

(16-bit word) Boot ROM Yes Yes External Memory Interface — Yes Event Managers A and B

(EVA and EVB)

S General-Purpose (GP) Timers 4 4 S Compare (CMP)/PWM 16 16 S Capture (CAP)/QEP Channels 6/2 6/2

Watchdog Timer Yes Yes 12-Bit ADC Yes Yes

S Channels 16 16 32-Bit CPU Timers 3 3 SPI Yes Yes SCIA, SCIB SCIA, SCIB SCIA, SCIB CAN Yes Yes McBSP Yes Yes Digital I/O Pins (Shared) 56 56 External Interrupts 3 3 Supply Voltage 1.8-V Core, (135 MHz) 1.9-V Core (150 MHz), 3.3-V I/O

Packaging 128-pin PBK

A: −40°C to 85°C Yes Yes

Temperature Options

Product Status

†

See Section 5.1, Device and Development Support Nomenclature for descriptions of product development stages.

†

S: −40°C to 125°C Yes Yes Q: −40°C to 125°C Yes PGF package only

†

20K 20K

EVA, EVB EVA, EVB

179-ball GHH

179-ball ZHH

176-pin PGF

TMS TMS

June 2004 − Revised June 2006 SPRS257C

Introduction

2.3 Pin Assignments

Figure 2−1 illustrates the ball locations for the 179-ball GHH and ZHH ball grid array (BGA) packages. Figure 2−2 shows the pin assignments for the 176-pin PGF low-profile quad flatpack (LQFP) and Figure 2−3 shows the pin assignments for the 128-pin PBK LQFP. Table 2−2 describes the function(s) of each pin.

2.3.1 Terminal Assignments for the GHH and ZHH Packages

See Table 2−2 for a description of each terminal’s function(s).

XZCS0AND1

SPISOMIA PWM9 XR/W

SPISIMOA XA[1] XRD

MCLKXA MFSRA XD[3]

MDXA MDRA XD[0]

XMP/MC

AVDD-

REFBG

PWM8

PWM10

PWM7 TEST2

SPICLKA

MCLKRA XD[1] MFSXA XD[2]

RESEXT

ADCREFP

XD[6] PWM11 XD[7] C5TRIP

XD[4]

ADC-

AVSS-

REFBG

PWM12

SPISTEA

DDIO

SSA1

DDA1

ADCREFM ADCINA5

T4PWM

_T4CMP

_QEP3

T3PWM

_T3CMP

ADCINB7 C3TRIP

CAP6

_QEPI2

C4TRIP

CAP4

CAP5

_QEP4

XD[5] XD[13]

XA[0]

ADC-

BGREFIN

XD[8]

TEST1 XD[9] X2

C6TRIP

XHOLD

DDIO

TDIRB XD[10]

TCLKINB

XNMI

_XINT13

T3CTRIP

_PDPINTB

XD[11] XA[2] XWE

X1/

XCLKIN

DDIO

T4CTRIP/

EVBSOC

XA[3] PWM1

DDIOVSS

XHOLDA

T2CTRIP

EVASOC

PWM5

T1PWM

_T1CMP

CAP1

_QEP1

XA[13] C2TRIP XA[8] C1TRIP

CAP2

_QEP2

XCLKOUT XA[7] TCLKINA TDIRA

CANTXA CANRXA

PWM3 PWM4 XD[12]

XA[4]

CAP3

_QEPI1

DDIO

XZCS2

SCIRXDB

T2PWM

_T2CMP

XA[5]

SCITXDB

DDIO

PWM2

PWM6

T1CTRIP

_PDPINTA

XA[6]

XINT1

ADCINB6 ADCINB5 ADCINB4 ADCINA1 ADCINA6 XRS

ADCINB3 ADCINB0 ADCINB1 ADCINA2

ADCINB2

DDAIO

ADCINA0 ADCINA4 V

SSAIO

ADCLO ADCINA3 ADCINA7 XREADY XA[17]

SSA2VSS1

DDA2VDD1

XA[18]

SCITXDA

SCIRXDA XA[16] XD[15] TESTSEL XA[11]

XINT2

_ADCSOC

_XBIO

EMU1

XA[15]

EMU0 TDO TMS XA[9]

XA[12] XA[10] TDI

XD[14] TRST

XA[14]

_XPLLDIS

TCK

XZCS6AND7

1412 1310 1189563412 7

Figure 2−1. TMS320R2812 179-Ball GHH and ZHH MicroStar BGA (Bottom View)

June 2004 − Revised June 2006SPRS257C

2.3.2 Pin Assignments for the PGF Package

The TMS320R2812 176-pin PGF low-profile quad flatpack (LQFP) pin assignments are shown in Figure 2−2. See Table 2−2 for a description of each pin’s function(s).

Introduction

XZCS6AND7

TESTSEL

TRST

TCK

EMU0 XA[12] XD[14]

XF_XPLLDIS

XA[13]

V V

DD XA[14] V

DDIO

EMU1 XD[15] XA[15]

XINT1_XBIO

XNMI_XINT13

XINT2_ADCSOC

XA[16]

SCITXDA

XA[17]

SCIRXDA

XA[18]

XHOLD

XRS

XREADY

DD1

SS1

ADCBGREFIN

SSA2

DDA2 ADCINA7 ADCINA6 ADCINA5

ADCINA4

ADCINA3 ADCINA2

ADCINA1 ADCINA0

ADCLO

SSAIO

VDDV

XA[11]

TDI

XA[10]

TDO

TMS

XA[9]

132 89

133

176

131

130

129

128

127

126

134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175

23456789101112131415161718192021222324252627282930313233343536373839404142

125

C2TRIP

C3TRIP

124

123

C1TRIP

XA[8]

121

122

XCLKOUT

120

119

XA[7]

TCLKINA

118

117

T2CTRIP / EVASOC

TDIRA

116

115

DDIO

114

T1CTRIP_PDPINTA

VDDVSSV

XA[6]

111

113

112

110

CAP3_QEPI1

XA[5]

CAP2_QEP2

CAP1_QEP1

109

108

107

106

105

T2PWM_T2CMP

XA[4]

T1PWM_T1CMP

PWM6

VSSV

99989796959493

101

104

103

102

100

PWM5

XD[13]

XD[12]

PWM4

PWM3

PWM2

PWM1

929190

SCIRXDB

SCITXDB

CANRXA

87 86 85 84 83 82 81 80 79 78 77 76 75 74 73 72 71 70 69 68 67 66 65 64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46

XZCS2 CANTXA

XA[3] XWE T4CTRIP/EVBSOC XHOLDA V

DDIO

XA[2] T3CTRIP_PDPINTB V

X1/XCLKIN X2

DD XD[11] XD[10]

TCLKINB TDIRB V

SS V

DDIO XD[9] TEST1

TEST2 XD[8] V

DDIO C6TRIP

C5TRIP C4TRIP CAP6_QEPI2 CAP5_QEP4 V

SS CAP4_QEP3 V

DD T4PWM_T4CMP

XD[7] T3PWM_T3CMP V

SS XR/W PWM12 PWM11 PWM10 PWM9 PWM8 PWM7

DDAIO

ADCINB0

ADCINB1

ADCINB2

ADCINB3

ADCINB4

ADCINB5

ADCINB6

ADCINB7

ADCREFP

ADCREFM

SSA1

DDA1

AVSSREFBG

AVDDREFBG

MCXMP/

XA[0]

MDRA

ADCRESEXT

XD[0]

MDXA

XD[1]

MCLKRA

XD[2]

MFSXA

XD[3]VDDIO

MFSRA

MCLKXA

XD[4]

SPICLKA

XD[5]

SPISTEA

XD[6]

SPISIMOA

XRD

XA[1]

SPISOMIA

XZCS0AND1

Figure 2−2. TMS320R2812 176-Pin PGF LQFP (Top View)

June 2004 − Revised June 2006 SPRS257C

Introduction

2.3.3 Pin Assignments for the PBK Package

The TMS320R2811 128-pin PBK low-profile quad flatpack (LQFP) pin assignments are shown in Figure 2−3. See Table 2−2 for a description of each pin’s function(s).

TESTSEL

TRST

TCK

EMU0

XF_XPLLDIS

DDIO

EMU1

XINT1_XBIO

XNMI_XINT13

XINT2_ADCSOC

ADCBGREFIN

SCITXDA

SCIRXDA

XRS

DD1

SS1

SSA2

DDA2 ADCINA7 ADCINA6 ADCINA5 ADCINA4 ADCINA3 ADCINA2 ADCINA1 ADCINA0

ADCLO

SSAIO

128

TDI

TDO

TMS

VDDV

96 65

9291908988

98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120 121 122 123 124 125 126 127

2345678

C1TRIP

C2TRIP

C3TRIP

XCLKOUT

878685

101112

TCLKINA

TDIRA

T2CTRIP/ EVASOC

131415

DDIO

VDDV

T1CTRIP_PDPINTA

CAP1_QEP1

CAP2_QEP2

CAP3_QEPI1

T2PWM_T2CMP

T1PWM_T1CMP

PWM6

757473

222324

VSSV

PWM5

PWM4

PWM3

PWM1

PWM2

SCIRXDB

SCITXDB

CANRXA

63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34

CANTXA V

SS T4CTRIP T3CTRIP_PDPINTB

SS X1/XCLKIN X2 V

DD TCLKINB TDIRB

SS V

DDIO TEST1 TEST2 V

DDIO C6TRIP C5TRIP C4TRIP CAP6_QEPI2 CAP5_QEP4 CAP4_QEP3

DD T4PWM_T4CMP

T3PWM_T3CMP V

SS PWM12

PWM11 PWM10 PWM9 PWM8 PWM7

/EVBSOC

DDAIO

ADCINB0

ADCINB1

ADCINB2

ADCINB3

ADCINB4

ADCINB5

ADCINB6

ADCINB7

ADCREFP

ADCREFM

AVSSREFBG

AVDDREFBG

SSA1

DDA1

ADCRESEXT

MDRA

MDXA

MCLKRA

MFSXA

Figure 2−3. TMS320R2811 128-Pin PBK LQFP

(Top View)

DDIO

MFSRA

MCLKXA

SS V

SPICLKA

SPISTEA

SPISIMOA

SPISOMIA

June 2004 − Revised June 2006SPRS257C

2.4 Signal Descriptions

Table 2−2 specifies the signals on the R281x devices. All digital inputs are TTL-compatible. All outputs are

3.3 V with CMOS levels. Inputs are not 5-V tolerant.

Introduction

June 2004 − Revised June 2006 SPRS257C

Introduction

19-bit XINTF Address Bus

16-bit XINTF Data Bus

Table 2−2. Signal Descriptions

PIN NO.

NAME

XA[18] D7 158 − O/Z − XA[17] B7 156 − O/Z − XA[16] A8 152 − O/Z − XA[15] B9 148 − O/Z − XA[14] A10 144 − O/Z − XA[13] E10 141 − O/Z − XA[12] C11 138 − O/Z − XA[11] A14 132 − O/Z XA[10] C12 130 − O/Z − XA[9] D14 125 − O/Z − XA[8] E12 121 − O/Z − XA[7] F12 118 − O/Z − XA[6] G14 111 − O/Z − XA[5] H13 108 − O/Z − XA[4] J12 103 − O/Z − XA[3] M11 85 − O/Z − XA[2] N10 80 − O/Z − XA[1] M2 43 − O/Z − XA[0] G5 18 − O/Z

XD[15] A9 147 − I/O/Z PU XD[14] B11 139 − I/O/Z PU XD[13] J10 97 − I/O/Z PU XD[12] L14 96 − I/O/Z PU XD[11] N9 74 − I/O/Z PU XD[10] L9 73 − I/O/Z PU XD[9] M8 68 − I/O/Z PU XD[8] P7 65 − I/O/Z PU XD[7] L5 54 − I/O/Z PU XD[6] L3 39 − I/O/Z PU XD[5] J5 36 − I/O/Z PU XD[4] K3 33 − I/O/Z PU XD[3] J3 30 − I/O/Z PU XD[2] H5 27 − I/O/Z PU XD[1] H3 24 − I/O/Z PU

XD[0] G3 21 − I/O/Z PU 16-bit XINTF Data Bus †

Typical drive strength of the output buffer for all pins is 4 mA except for TDO, XCLKOUT, XF, XINTF, EMU0, and EMU1 pins, which are 8 mA.

‡

I = Input, O = Output, Z = High impedance

PU = pin has internal pullup; PD = pin has internal pulldown. Pullup/pulldown strength is given in Section 6.3. The pullups/pulldowns are enabled in boundary-scan mode.

179-PIN

GHH

AND ZHH

176-PIN

PGF

128-PIN

PBK

XINTF SIGNALS (2812 ONLY)

XINTF SIGNALS (2812 ONLY) (CONTINUED)

I/O/Z‡PU/PD

†

DESCRIPTION

19-bit XINTF Address Bus

16-bit XINTF Data Bus

June 2004 − Revised June 2006SPRS257C

Introduction

Table 2−2. Signal Descriptions

PIN NO.

NAME DESCRIPTIONPU/PD

XMP/MC F1 17 − I PD

XHOLD E7 159 − I PU

XHOLDA K10 82 − O/Z −

XZCS0AND1 P1 44 − O/Z −

XZCS2 P13 88 − O/Z −

XZCS6AND7 B13 133 − O/Z −

XWE N11 84 − O/Z −

XRD M3 42 − O/Z −

XR/W N4 51 − O/Z −

XREADY B6 161 − I PU

†

Typical drive strength of the output buffer for all pins is 4 mA except for TDO, XCLKOUT, XF, XINTF, EMU0, and EMU1 pins, which are 8 mA.

‡

I = Input, O = Output, Z = High impedance

PU = pin has internal pullup; PD = pin has internal pulldown. Pullup/pulldown strength is given in Section 6.3. The pullups/pulldowns are enabled in boundary-scan mode.

179-PIN

GHH

AND ZHH

176-PIN

PGF

128-PIN

PBK

I/O/Z

‡

†

(Continued)

Microprocessor/Microcomputer Mode Select. Switches between microprocessor and microcomputer mode. When high, Zone 7 is enabled on the external interface. When low, Zone 7 is disabled from the external interface, and on-chip boot ROM may be accessed instead. This signal is latched into the XINTCNF2 register on a reset and the user can modify this bit in software. The state of the XMP/MC

External Hold Request. XHOLD, when active (low), requests the XINTF to release the external bus and place all buses and strobes into a high-impedance state. The XINTF will release the bus when any current access is complete and there are no pending accesses on the XINTF.

External Hold Acknowledge. XHOLDA is driven active (low) when the XINTF has granted a XHOLD XINTF buses and strobe signals will be in a high-impedance state. XHOLDA is released when the XHOLD drive the external bus when XHOLDA

XINTF Zone 0 and Zone 1 Chip Select. XZCS0AND1 is active (low) when an access to the XINTF Zone 0 or Zone 1 is performed.

XINTF Zone 2 Chip Select. XZCS2 is active (low) when an access to the XINTF Zone 2 is performed.

XINTF Zone 6 and Zone 7 Chip Select. XZCS6AND7 is active (low) when an access to the XINTF Zone 6 or Zone 7 is performed.

Write Enable. Active-low write strobe. The write strobe waveform is specified, per zone basis, by the Lead, Active, and Trail periods in the XTIMINGx registers.

Read Enable. Active-low read strobe. The read strobe waveform is specified, per zone basis, by the Lead, Active, and Trail periods in the XTIMINGx registers. NOTE: The XRD

Read Not Write Strobe. Normally held high. When low, XR/W indicates read cycle is active.

Ready Signal. Indicates peripheral is ready to complete the access when asserted to 1. XREADY can be configured to be a synchronous or an asynchronous input. See the timing diagrams for more details.

pin is ignored after reset.

request. All

signal is released. External devices should only

is active (low).

and XWE signals are mutually exclusive.

indicates write cycle is active; when high, XR/W

June 2004 − Revised June 2006 SPRS257C

Introduction

Table 2−2. Signal Descriptions

PIN NO.

NAME DESCRIPTIONPU/PD

X1/XCLKIN K9 77 58 I

X2 M9 76 57 O Oscillator Output

XCLKOUT F11 119 87 O −

TESTSEL A13 134 97 I PD Test Pin. Reserved for TI. Must be connected to ground.

179-PIN

GHH AND

ZHH

176-PIN

PGF

128-PIN

PBK

JTAG AND MISCELLANEOUS SIGNALS

I/O/Z

‡

†

(Continued)

Oscillator Input − input to the internal oscillator. This pin is also used to feed an external clock. The 28x can be operated with an external clock source, provided that the proper voltage levels be driven on the X1/XCLKIN pin. It should be noted that the X1/XCLKIN pin is referenced to the 1.8-V (or 1.9-V) core digital power supply (VDD), rather than the 3.3-V I/O supply (V be used to clamp a buffered clock signal to ensure that the logic-high level does not exceed VDD (1.8 V or 1.9 V) or a

1.8-V oscillator may be used.

Output clock derived from SYSCLKOUT to be used for external wait-state generation and as a general-purpose clock source. XCLKOUT is either the same frequency , 1/ 2 the frequency, or 1/4 the frequency of SYSCLKOUT. At reset, XCLKOUT = SYSCLKOUT/4. The XCLKOUT signal can be turned off by setting bit 3 (CLKOFF) of the XINTCNF2 register to 1. Unlike other GPIO pins, the XCLKOUT pin is not placed in a high impedance state during reset.

Device Reset (in) and Watchdog Reset (out).

). A clamping diode may

DDIO

Device reset. XRS causes the device to terminate execution. The PC will point to the address contained at the location 0x3FFFC0. When XRS level, execution begins at the location pointed to by the

XRS D6 160 113 I/O PU

TEST1 M7 67 51 I/O −

TEST2 N7 66 50 I/O − †

Typical drive strength of the output buffer for all pins is 4 mA except for TDO, XCLKOUT, XF, XINTF, EMU0, and EMU1 pins, which are 8 mA.

‡

I = Input, O = Output, Z = High impedance

PU = pin has internal pullup; PD = pin has internal pulldown. Pullup/pulldown strength is given in Section 6.3. The pullups/pulldowns are enabled in boundary-scan mode.

PC. This pin is driven low by the DSP when a watchdog reset occurs. During watchdog reset, the XRS driven low for the watchdog reset duration of 512 XCLKIN cycles.

The output buffer of this pin is an open-drain with an internal pullup (100 µA, typical). It is recommended that this pin be driven by an open-drain device.

This pin is a “no connect (NC)” (i.e., this pin is not connected to any circuitry internal to the device).

is brought to a high

pin will be

June 2004 − Revised June 2006SPRS257C

Introduction

Table 2−2. Signal Descriptions

PIN NO.

NAME DESCRIPTIONPU/PD

TRST B12 135 98 I PD

TCK A12 136 99 I PU JTAG test clock with internal pullup

TMS D13 126 92 I PU

TDI C13 131 96 I PU

TDO D12 127 93 O/Z −

EMU0 D11 137 100 I/O/Z PU

†

Typical drive strength of the output buffer for all pins is 4 mA except for TDO, XCLKOUT, XF, XINTF, EMU0, and EMU1 pins, which are 8 mA.

‡

I = Input, O = Output, Z = High impedance

PU = pin has internal pullup; PD = pin has internal pulldown. Pullup/pulldown strength is given in Section 6.3. The pullups/pulldowns are enabled in boundary-scan mode.

179-PIN

GHH

AND ZHH

176-PIN

PGF

128-PIN

PBK

I/O/Z

‡

JTAG

†

(Continued)

JTAG test reset with internal pulldown. TRST, when driven high, gives the scan system control of the operations of the device. If this signal is not connected or driven low, the device operates in its functional mode, and the test reset signals are ignored.

NOTE: Do not use pullup resistors on TRST internal pulldown device. TRST and must be maintained low at all times during normal device operation. In a low-noise environment, TRST be left floating. In other instances, an external pulldown resistor is highly recommended. The value of this resistor should be based on drive strength of the debugger pods applicable to t h e design. A 2.2-kΩ resistor generally of fers adequate protection. Since this is application-specific, it is recommended that each target board be validated for proper operation of the debugger and the application.

JTAG test-mode select (TMS) with internal pullup. This serial control input is clocked into the TAP controller on the rising edge of TCK.

JTAG test data input (TDI) with internal pullup. TDI is clocked into the selected register (instruction or data) on a rising edge of TCK.

JTAG scan out, test data output (TDO). The contents of the selected register (instruction or data) is shifted out of TDO on the falling edge of TCK.

Emulator pin 0. When TRST is driven high, this pin is used as an interrupt to or from the emulator system and is defined as input/output through the JTAG scan. This pin is also used to put the device into boundary-scan mode. With the EMU0 pin at a logic-high state and the EMU1 pin at a logic-low state, a rising edge on the TRST

pin would latch the device into boundary-scan

mode. NOTE: An external pullup resistor is recommended on

this pin. The value of this resistor should be based on the drive strength of the debugger pods applicable to the design. A 2.2-kΩ to 4.7-kΩ resistor is generally adequate. Since this is application-specific, it is recommended that each target board be validated for proper operation of the debugger and the application.

is an active high test pin

; it has an

may

June 2004 − Revised June 2006 SPRS257C

Introduction

ADC pins should not be driven before V

, V

, and

pins have been fully powered up.

DDAIO

pins have been fully powered up.

ADC pins should not be driven before the V

, V

and V

DDAIO

pins have been fully powered up.

Table 2−2. Signal Descriptions

PIN NO.

NAME DESCRIPTIONPU/PD

EMU1 C9 146 105 I/O/Z PU

ADCINA7 B5 167 119 I ADCINA6 D5 168 120 I ADCINA5 E5 169 121 I ADCINA4 A4 170 122 I ADCINA3 B4 171 123 I ADCINA2 C4 172 124 I ADCINA1 D4 173 125 I ADCINA0 A3 174 126 I ADCINB7 F5 9 9 I ADCINB6 D1 8 8 I ADCINB5 D2 7 7 I ADCINB4 D3 6 6 I ADCINB3 C1 5 5 I ADCINB2 B1 4 4 I ADCINB1 C3 3 3 I ADCINB0 C2 2 2 I

ADCREFP E2 11 11 I/O

†

Typical drive strength of the output buffer for all pins is 4 mA except for TDO, XCLKOUT, XF, XINTF, EMU0, and EMU1 pins, which are 8 mA.

‡

I = Input, O = Output, Z = High impedance

PU = pin has internal pullup; PD = pin has internal pulldown. Pullup/pulldown strength is given in Section 6.3. The pullups/pulldowns are enabled in boundary-scan mode.

179-PIN

GHH AND

ZHH

176-PIN

PGF

128-PIN

PBK

JTAG (CONTINUED)

ADC ANALOG INPUT SIGNALS

I/O/Z

‡

†

(Continued)

Emulator pin 1. When TRST is driven high, this pin is used as an interrupt to or from the emulator system and is defined as input/output through the JTAG scan. This pin is also used to put the device into boundary-scan mode. With the EMU0 pin at a logic-high state and the EMU1 pin at a logic-low state, a rising edge on the TRST

pin would latch the device into boundary-scan

mode. NOTE: An external pullup resistor is recommended on

8-Channel analog inputs for Sample-and-Hold A. The

DDA1

DDA2

8-Channel Analog Inputs for Sample-and-Hold B. The

DDA1

ADC Voltage Reference Output (2 V). Requires a low ESR (50 mΩ − 1.5 Ω) ceramic bypass capacitor of 10 µF to analog ground. (Can accept external reference input (2 V) if the software bit is enabled for this mode. 1−10 µF low ESR capacitor can be used in the external reference mode.)

DDA2

June 2004 − Revised June 2006SPRS257C

Introduction

Recommended Operating Conditions, for voltage requirements.

requirements.

Table 2−2. Signal Descriptions

PIN NO.

NAME DESCRIPTIONPU/PD

ADCREFM E4 10 10 I/O

ADCRESEXT F2 16 16 O ADC External Current Bias Resistor (24.9 kΩ ±5%) ADCBGREFIN E6 164 116 I Test Pin. Reserved for TI. Must be left unconnected. AVSSREFBG E3 12 12 I ADC Analog GND AVDDREFBG E1 13 13 I ADC Analog Power (3.3-V)

ADCLO B3 175 127 I V

SSA1

SSA2

DDA1

DDA2

SS1

DD1

DDAIO

SSAIO

†

Typical drive strength of the output buffer for all pins is 4 mA except for TDO, XCLKOUT, XF, XINTF, EMU0, and EMU1 pins, which are 8 mA.

‡

I = Input, O = Output, Z = High impedance

PU = pin has internal pullup; PD = pin has internal pulldown. Pullup/pulldown strength is given in Section 6.3. The pullups/pulldowns are enabled in boundary-scan mode.

179-PIN

GHH

AND ZHH

P12 − 63 K12 100 74 G12 112 82 C14 128 94 B10 143 102

176-PIN

PGF

F3 15 15 I ADC Analog GND C5 165 117 I ADC Analog GND

F4 14 14 I ADC Analog 3.3-V Supply A5 166 118 I ADC Analog 3.3-V Supply C6 163 115 I ADC Digital GND A6 162 114 I ADC Digital 1.8-V (or 1.9-V) Supply B2 1 1 3.3-V Analog I/O Power Pin A2 176 128 Analog I/O Ground Pin

H1 23 20 L1 37 29 P5 56 42 P9 75 56

C8 154 110

128-PIN

PBK

ADC ANALOG INPUT SIGNALS (CONTINUED)

POWER SIGNALS

I/O/Z

‡

†

(Continued)

ADC Voltage Reference Output (1 V). Requires a low ESR (50 mΩ − 1.5 Ω) ceramic bypass capacitor of 10 µF to analog ground. (Can accept external reference input (1 V) if the software bit is enabled for this mode. 1−10 µF low ESR capacitor can be used in the external reference mode.)

Common Low Side Analog Input. Connect to analog ground.

1.8-V or 1.9-V Core Digital Power Pins. See Section 6.2

June 2004 − Revised June 2006 SPRS257C

Introduction

Table 2−2. Signal Descriptions

PIN NO.

NAME DESCRIPTIONPU/PD

DDIO

GPIOA0 PWM1 (O)

GPIOA1 PWM2 (O)

GPIOA2 PWM3 (O)

GPIOA3 PWM4 (O)

GPIOA4/PWM5 (O) K11 98 72 I/O/Z PU GPIO or PWM Output Pin #5 GPIOA5

PWM6 (O) GPIOA6

T1PWM_T1CMP (I) †

Typical drive strength of the output buffer for all pins is 4 mA except for TDO, XCLKOUT, XF, XINTF, EMU0, and EMU1 pins, which are 8 mA.

‡

I = Input, O = Output, Z = High impedance

PU = pin has internal pullup; PD = pin has internal pulldown. Pullup/pulldown strength is given in Section 6.3. The pullups/pulldowns are enabled in boundary-scan mode.

179-PIN

GHH AND

ZHH

M10 78 59

K13 99 73

G13 113 − E14 120 88 B14 129 95 D10 142 − C10 − 103

N14 − − G11 114 83

M12 92 68 I/O/Z PU GPIO or PWM Output Pin #1

M14 93 69 I/O/Z PU GPIO or PWM Output Pin #2

K14 101 75 I/O/Z PU GPIO or PWM Output Pin #6

176-PIN

PGF

G4 19 17 K1 32 26

L2 38 30 P4 52 39 K6 58 − P8 70 53

L11 86 62

J14 105 −

B8 153 109

J4 31 25

L7 64 49

L10 81 −

E9 145 104 N8 69 52

L12 94 70 I/O/Z PU GPIO or PWM Output Pin #3

L13 95 71 I/O/Z PU GPIO or PWM Output Pin #4

J11 102 76 I/O/Z PU GPIO or Timer 1 Output

128-PIN

PBK

POWER SIGNALS (CONTINUED)

GPIO OR EVA SIGNALS

I/O/Z

‡

†

(Continued)

Core and Digital I/O Ground Pins

3.3-V I/O Digital Power Pins

June 2004 − Revised June 2006SPRS257C

Introduction

Table 2−2. Signal Descriptions

PIN NO.

NAME DESCRIPTIONPU/PD

GPIOA7 T2PWM_T2CMP (I)

GPIOA8 CAP1_QEP1 (I)

GPIOA9 CAP2_QEP2 (I)

GPIOA10/ CAP3_QEPI1 (I)

GPIOA11 TDIRA (I)

GPIOA12 TCLKINA (I)

GPIOA13 C1TRIP

(I)

GPIOA14 C2TRIP

(I)

GPIOA15 C3TRIP

(I)

GPIOB0 PWM7 (O)

GPIOB1 PWM8 (O)

GPIOB2 PWM9 (O)

GPIOB3 PWM10 (O)

GPIOB PWM11 (O)

GPIOB5 PWM12 (O)

GPIOB6/ T3PWM_T3CMP (I)

GPIOB7/ T4PWM_T4CMP (I)

GPIOB8/CAP4_QEP3 (I) M5 57 43 I/O/Z PU GPIO or Capture Input #4 GPIOB9/CAP5_QEP4 (I) M6 59 44 I/O/Z PU GPIO or Capture Input #5 GPIOB10/CAP6_QEPI2 (I) P6 60 45 I/O/Z PU GPIO or Capture Input #6 GPIOB11/TDIRB (I) L8 71 54 I/O/Z PU GPIO or Timer Direction GPIOB12/TCLKINB (I) K8 72 55 I/O/Z PU GPIO or Timer Clock Input

†

Typical drive strength of the output buffer for all pins is 4 mA except for TDO, XCLKOUT, XF, XINTF, EMU0, and EMU1 pins, which are 8 mA.

‡

I = Input, O = Output, Z = High impedance

PU = pin has internal pullup; PD = pin has internal pulldown. Pullup/pulldown strength is given in Section 6.3. The pullups/pulldowns are enabled in boundary-scan mode.

179-PIN

GHH

AND ZHH

J13 104 77 I/O/Z PU GPIO or Timer 2 Output

H10 106 78 I/O/Z PU GPIO or Capture Input #1

H11 107 79 I/O/Z PU GPIO or Capture Input #2

H12 109 80 I/O/Z PU GPIO or Capture Input #3

F14 116 85 I/O/Z PU GPIO or Timer Direction

F13 117 86 I/O/Z PU GPIO or Timer Clock Input

E13 122 89 I/O/Z PU GPIO or Compare 1 Output Trip

E11 123 90 I/O/Z PU GPIO or Compare 2 Output Trip

F10 124 91 I/O/Z PU GPIO or Compare 3 Output Trip

176-PIN

PGF

N2 45 33 I/O/Z PU GPIO or PWM Output Pin #7

P2 46 34 I/O/Z PU GPIO or PWM Output Pin #8

N3 47 35 I/O/Z PU GPIO or PWM Output Pin #9

P3 48 36 I/O/Z PU GPIO or PWM Output Pin #10

L4 49 37 I/O/Z PU GPIO or PWM Output Pin #11

M4 50 38 I/O/Z PU GPIO or PWM Output Pin #12

K5 53 40 I/O/Z PU GPIO or Timer 3 Output

N5 55 41 I/O/Z PU GPIO or Timer 4 Output

128-PIN

PBK

GPIO OR EVA SIGNALS (CONTINUED)

GPIOB OR EVB SIGNALS

I/O/Z

‡

†

(Continued)

June 2004 − Revised June 2006 SPRS257C

Introduction

Table 2−2. Signal Descriptions

PIN NO.

NAME DESCRIPTIONPU/PD

GPIOB13/C4TRIP (I) N6 61 46 I/O/Z PU GPIO or Compare 4 Output Trip GPIOB14/C5TRIP (I) L6 62 47 I/O/Z PU GPIO or Compare 5 Output Trip GPIOB15/C6TRIP (I) K7 63 48 I/O/Z PU GPIO or Compare 6 Output Trip

GPIOD0/ T1CTRIP_PDPINTA

GPIOD1/ T2CTRIP

GPIOD5/ T3CTRIP_PDPINTB

GPIOD6/ T4CTRIP

GPIOE0/XINT1_XBIO (I) D9 149 106 I/O/Z − GPIO or XINT1 or XBIO input GPIOE1/

XINT2_ADCSOC (I) GPIOE2

XNMI_XINT13 (I)

GPIOF0 SPISIMOA (O)

GPIOF1 SPISOMIA (I)

GPIOF2 SPICLKA (I/O)

GPIOF3 SPISTEA (I/O)

GPIOF4 SCITXDA (O)

GPIOF5 SCIRXDA (I)

GPIOF6 CANTXA (O)

GPIOF7 CANRXA (I)

† ‡

/EVASOC (I)

/EVBSOC (I)

Typical drive strength of the output buffer for all pins is 4 mA except for TDO, XCLKOUT, XF, XINTF, EMU0, and EMU1 pins, which are 8 mA. I = Input, O = Output, Z = High impedance PU = pin has internal pullup; PD = pin has internal pulldown. Pullup/pulldown strength is given in Section 6.3. The pullups/pulldowns are enabled in boundary-scan mode.

(I)

179-PIN

GHH AND

ZHH

H14 110 81 I/O/Z PU Timer 1 Compare Output Trip

G10 115 84 I/O/Z PU

P10 79 60 I/O/Z PU Timer 3 Compare Output Trip

P11 83 61 I/O/Z PU

N12 87 64 I/O/Z PU GPIO or eCAN transmit data

N13 89 65 I/O/Z PU GPIO or eCAN receive data

176-PIN

PGF

D8 151 108 I/O/Z − GPIO or XINT2 or ADC start of conversion

E8 150 107 I/O/Z PU GPIO or XNMI or XINT13

M1 40 31 I/O/Z − GPIO or SPI slave in, master out

N1 41 32 I/O/Z − GPIO or SPI slave out, master in

K2 34 27 I/O/Z − GPIO or SPI clock

K4 35 28 I/O/Z − GPIO or SPI slave transmit enable

C7 155 111 I/O/Z PU GPIO or SCI asynchronous serial port TX data

A7 157 112 I/O/Z PU GPIO or SCI asynchronous serial port RX data

128-PIN

PBK

GPIOD OR EVA SIGNALS

GPIOD OR EVB SIGNALS

GPIOE OR INTERRUPT SIGNALS

GPIOF OR SPI SIGNALS

GPIOF OR SCI-A SIGNALS

GPIOF OR CAN SIGNALS

GPIOF OR McBSP SIGNALS

I/O/Z

‡

†

(Continued)

Timer 2 Compare Output Trip or External ADC Start-of-Conversion EV-A

Timer 4 Compare Output Trip or External ADC Start-of-Conversion EV-B

June 2004 − Revised June 2006SPRS257C

Introduction

Table 2−2. Signal Descriptions

PIN NO.

NAME DESCRIPTIONPU/PD

GPIOF8 MCLKXA (I/O)

GPIOF9 MCLKRA (I/O)

GPIOF10 MFSXA (I/O)

GPIOF11 MFSRA (I/O)

GPIOF12 MDXA (O)

GPIOF13 MDRA (I)

GPIOF14 XF_XPLLDIS

GPIOG4/SCITXDB (O) P14 90 66 I/O/Z − GPIO or SCI asynchronous serial port transmit data GPIOG5/SCIRXDB (I) M13 91 67 I/O/Z − GPIO or SCI asynchronous serial port receive data

†

Typical drive strength of the output buffer for all pins is 4 mA except for TDO, XCLKOUT, XF, XINTF, EMU0, and EMU1 pins, which are 8 mA.

‡

I = Input, O = Output, Z = High impedance

PU = pin has internal pullup; PD = pin has internal pulldown. Pullup/pulldown strength is given in Section 6.3. The pullups/pulldowns are enabled in boundary-scan mode.

(O)

179-PIN

GHH

AND ZHH

A11 140 101 I/O/Z PU

176-PIN

PGF

J1 28 23 I/O/Z PU GPIO or transmit clock

H2 25 21 I/O/Z PU GPIO or receive clock

H4 26 22 I/O/Z PU GPIO or transmit frame synch

J2 29 24 I/O/Z PU GPIO or receive frame synch

G1 22 19 I/O/Z − GPIO or transmitted serial data

G2 20 18 I/O/Z PU GPIO or received serial data

128-PIN

PBK

GPIOF OR XF CPU OUTPUT SIGNAL

GPIOG OR SCI-B SIGNALS

I/O/Z

‡

†

(Continued)

This pin has three functions:

1) XF − General-purpose output pin.

2) XPLLDIS − This pin will be sampled during reset to check if the PLL needs to be disabled. The PLL will be disabled if this pin is sensed low. HALT and STANDBY modes cannot be used when the PLL is disabled.

3) GPIO − GPIO function

NOTE: Other than the power supply pins, no pin should be driven before the 3.3-V rail has reached recommended operating conditions. However , i t i s acceptable for an I/O pin to ramp along with the 3.3-V supply.

June 2004 − Revised June 2006 SPRS257C

Functional Overview

3 Functional Overview

Memory Bus

GPIO Pins

TINT0

TINT1

G P

U X

XINT13

XNMI

CPU-Timer 0 CPU-Timer 1

CPU-Timer 2

TINT2

PIE

(96 interrupts)

External Interrupt

Control

(XINT1/2/13, XNMI)

SCIA/SCIB

SPI FIFO

McBSP

eCAN

EVA/EVB

†

FIFO

INT14

INT[12:1]

INT13 NMI

C28x CPU

Real-Time JTAG

External

Interface

‡

(XINTF)

M0 SARAM

1K x 16

M1 SARAM

1K x 16

L0 SARAM

4K x 16

L1 SARAM

4K x 16

L2 SARAM

1K X 16

Control

Address(19)

Data(16)

XRS

X1/XCLKIN

XF_XPLLDIS

†

45 of the possible 96 interrupts are used on the devices.

‡

XINTF is available on the R2812 devices only.

16 Channels

12-Bit ADC

System Control

(Oscillator and PLL

Peripheral Clocking

Low-Power

Modes

WatchDog)

Peripheral Bus

RS CLKIN

Memory Bus

Figure 3−1. Functional Block Diagram

L3 SARAM

1K X 16

H0 SARAM

8K × 16

Boot ROM

4K × 16

June 2004 − Revised June 2006SPRS257C

3.1 Memory Map

Block

Start Address

Functional Overview

On-Chip Memory External Memory XINTF

0x00 0000

0x00 0040 0x00 0400

0x00 0800

0x00 0D00

Low 64K

(24x/240x Equivalent Data Space)

0x00 0E00

0x00 2000

0x00 6000

0x00 7000

0x00 8000 0x00 9000

0x00 A000

0x00 A400

0x00 A800

Data Space Prog Space

M0 Vector − RAM (32 × 32)

(Enabled if VMAP = 0)

M0 SARAM (1K × 16) M1 SARAM (1K × 16)

Peripheral Frame 0

PIE Vector - RAM

(256 × 16)

(Enabled if VMAP

= 1, ENPIE = 1)

Reserved

Peripheral Frame 1

(Protected)

Peripheral Frame 2

(Protected)

L0 SARAM (4K × 16)

L1 SARAM (4K × 16)

L2 SARAM (1K × 16)

L3 SARAM (1K × 16)

Reserved

Data Space Prog Space

Reserved

XINTF Zone 0 (8K × 16, XZCS0AND1

XINTF Zone 1 (8K × 16, XZCS0AND1) (Protected)

Reserved

XINTF Zone 2 (0.5M × 16, XZCS2

XINTF Zone 6 (0.5M × 16, XZCS6AND7)

)

0x00 2000 0x00 4000

0x08 0000 0x10 0000 0x18 0000

High 64K

Program Space)

(24x/240x Equivalent

LEGEND:

0x3F7FF8

0x3F 8000

0x3F A000

0x3F F000

0x3F FFC0

128-bit Password (see Note H)

H0 SARAM (8K × 16)

Boot ROM (4K × 16)

(Enabled if MP/MC

BROM Vector - ROM (32 × 32)

(Enabled if VMAP = 1, MP/MC

Only one of these vector maps—M0 vector, PIE vector, BROM vector, XINTF vector—should be enabled at a time.

NOTES: A. Memory blocks are not to scale.

B. Reserved locations are reserved for future expansion. Application should not access these areas. C. Boot ROM and Zone 7 memory maps are active either in on-chip or XINTF zone depending on MP/MC D. Peripheral Frame 0, Peripheral Frame 1, and Peripheral Frame 2 memory maps are restricted to data memory only.

User program cannot access these memory maps in program space. E. “Protected” means the order of Write followed by Read operations is preserved rather than the pipeline order. F. Certain memory ranges are EALLOW protected against spurious writes after configuration.

G. Zones 0 and 1 and Zones 6 and 7 share the same chip select; hence, these memory blocks have mirrored locations. H. The passwords are set to all ones.

Figure 3−2. R2812 Memory Map (See Notes A through H)

Reserved

= 0)

= 0, ENPIE = 0)

Reserved

XINTF Zone 7 (16K × 16, XZCS6AND7

(Enabled if MP/MC

XINTF Vector - RAM (32 × 32)

(Enabled if VMAP = 1, MP/MC

= 1)

= 1, ENPIE = 0)

0x3F C000

)

, not in both.

June 2004 − Revised June 2006 SPRS257C

Functional Overview

Block

Start Address

0x00 0000

0x00 0040 0x00 0400

0x00 0800

0x00 0D00

Low 64K

(24x/240x Equivalent Data Space)

0x00 0E00 0x00 2000

0x00 6000

0x00 7000

0x00 8000 0x00 9000

0x00 A000

0x00 A400

0x00 A800

On-Chip Memory

Data Space Prog Space

M0 Vector − RAM (32 × 32)

(Enabled if VMAP = 0)

M0 SARAM (1K × 16) M1 SARAM (1K × 16)

Peripheral Frame 0

PIE Vector - RAM

(256 × 16)

(Enabled if VMAP

= 1, ENPIE = 1)

Reserved

Peripheral Frame 1

(Protected)

Peripheral Frame 2

(Protected)

L0 SARAM (4K × 16,) L1 SARAM (4K × 16)

L2 SARAM (1K × 16)

L3 SARAM (1K × 16)

Reserved

High 64K

Program Space)

(24x/240x Equivalent

LEGEND:

Only one of these vector maps—M0 vector, PIE vector, BROM vector, XINTF vector—should be enabled at a time.

NOTES: A. Memory blocks are not to scale.

B. Reserved locations are reserved for future expansion. Application should not access these areas. C. Peripheral Frame 0 , P e r i p h e ral Frame 1, and Peripheral Frame 2 memory maps are restricted to data memory only. User program

cannot access these memory maps in program space. D. “Protected” means the order of Write followed by Read operations is preserved rather than the pipeline order. E. Certain memory ranges are EALLOW protected against spurious writes after configuration. F. The passwords are set to all ones.

Figure 3−3. R2811 Memory Map (See Notes A through F)

0x3F 7FF8

0x3F 8000

0x3F A000

0x3F F000

0x3F FFC0

Reserved

128-bit Password (see Note F)

H0 SARAM (8K × 16)

Reserved

Boot ROM (4K × 16)

(Enabled if MP/MC

BROM Vector - ROM (32 × 32)

(Enabled if VMAP = 1, MP/MC

= 0)

= 0, ENPIE = 0)

June 2004 − Revised June 2006SPRS257C

Functional Overview

The low 64K of the memory-address range maps into the data space of the 240x. The “High 64K” of the memory address range maps into the program space of the 24x/240x. 24x/240x-compatible code will only execute from the “High 64K” memory area. Hence, the top 32K of H0 SARAM block can be used to run 24x/240x-compatible code (if MP/MC (if MP/MC

mode is high).

mode is low) or , on the 2812, code can be executed from XINTF Zone 7

The XINTF consists of five independent zones. One zone has its own chip select and the remaining four zones share two chip selects. Each zone can be programmed with its own timing (wait states) and to either sample or ignore external ready signal. This makes interfacing to external peripherals easy and glueless.

NOTE:

The chip selects of XINTF Zone 0 and Zone 1 are merged together into a single chip select (XZCS0AND1 a single chip select (XZCS6AND7

); and the chip selects of XINTF Zone 6 and Zone 7 are merged together into

). See Section 3.5, “External Interface, XINTF (2812 only)”,

for details.

Peripheral Frame 1, Peripheral Frame 2, and XINTF Zone 1 are grouped together so as to enable these blocks to be “write/read peripheral block protected”. The “protected” mode ensures that all accesses to these blocks happen as written. Because of the C28x pipeline, a write immediately followed by a read, to different memory locations, will appear in reverse order on the memory bus of the CPU. This can cause problems in certain peripheral applications where the user expected the write to occur first (as written). The C28x CPU supports a block protection mode where a region of memory can be protected so as to make sure that operations occur as written (the penalty is extra cycles are added to align the operations). This mode is programmable and by default, it will protect the selected zones.

On the 2812, at reset, XINTF Zone 7 is accessed if the XMP/MC

pin is pulled high. This signal selects microprocessor or microcomputer mode of operation. In microprocessor mode, Zone 7 is mapped to high memory such that the vector table is fetched externally. The Boot ROM is disabled in this mode. In microcomputer mode, Zone 7 is disabled such that the vectors are fetched from Boot ROM. This allows the user to either boot from on-chip memory or from off-chip memory. The state of the XMP/MC is stored in an MP/MC

mode bit in the XINTCNF2 register. The user can change this mode in software and

signal on reset

hence control the mapping of Boot ROM and XINTF Zone 7. No other memory blocks are affected by XMP/MC

. I/O space is not supported on the 2812 XINTF. The wait states for the various spaces in the memory map area are listed in Table 3−1.

Table 3−1. Wait States

AREA WAIT-STATES COMMENTS

M0 and M1 SARAMs 0-wait Fixed

Peripheral Frame 0 0-wait Fixed Peripheral Frame 1

Peripheral Frame 2

L0, L1, L2, and L3 SARAMs 0-wait

H0 SARAM 0-wait Fixed

Boot-ROM 1-wait Fixed

XINTF

0-wait (writes)

2-wait (reads)

0-wait (writes)

2-wait (reads)

Programmable,

1-wait minimum

Fixed

Programmed via the XINTF registers. Cycles can be extended by external memory or peripheral. 0-wait operation is not possible.

June 2004 − Revised June 2006 SPRS257C

Functional Overview

3.2 Brief Descriptions

3.2.1 C28x CPU

The C28x DSP generation is the newest member of the TMS320C2000 DSP platform. The C28x is source code compatible to the 24x/240x DSP devices, hence existing 240x users can leverage their significant software investment. Additionally, the C28x is a very efficient C/C++ engine, hence enabling users to develop not only their system control software in a high-level language, but also enables math algorithms to be developed using C/C++. The C28x is as efficient in DSP math tasks as it is in system control tasks that typically are handled by microcontroller devices. This efficiency removes the need for a second processor in many systems. The 32 x 32-bit MAC capabilities of the C28x and its 64-bit processing capabilities, enable the C28x to efficiently handle higher numerical resolution problems that would otherwise demand a more expensive floating-point processor solution. Add to this the fast interrupt response with automatic context save of critical registers, resulting in a device that is capable of servicing many asynchronous events with minimal latency. The C28x has an 8-level-deep protected pipeline with pipelined memory accesses. This pipelining enables the C28x to execute at high speeds without resorting to expensive high-speed memories. Special branch-look-ahead hardware minimizes the latency for conditional discontinuities. Special store conditional operations further improve performance.

3.2.2 Memory Bus (Harvard Bus Architecture)

As with many DSP type devices, multiple busses are used to move data between the memories and peripherals and the CPU. The R28x memory bus architecture contains a program read bus, data read bus and data write bus. The program read bus consists of 22 address lines and 32 data lines. The data read and write busses consist of 32 address lines and 32 data lines each. The 32-bit-wide data busses enable single cycle 32-bit operations. The multiple-bus architecture, commonly termed “Harvard Bus”, enables the R28x to fetch an instruction, read a data value, and write a data value in a single cycle. All peripherals and memories attached to the memory bus prioritize memory accesses.

Generally, the priority of memory bus accesses can be summarized as follows:

Highest: Data Writes (Simultaneous data and program writes cannot occur

on the memory bus.) Program Writes (Simultaneous data and program writes cannot occur

on the memory bus.) Data Reads Program Reads (Simultaneous program reads and fetches cannot occur

on the memory bus.)

Lowest: Fetches (Simultaneous program reads and fetches cannot occur

on the memory bus.)

3.2.3 Peripheral Bus

To enable migration of peripherals between various Texas Instruments (TI) DSP family of devices, R281x adopts a peripheral bus standard for peripheral interconnect. The peripheral bus bridge multiplexes the various busses that make up the processor “Memory Bus” into a single bus consisting of 16 address lines and 16 or 32 data lines and associated control signals. T wo versions of the peripheral bus are supported on R281x. One version only supports 16-bit accesses (called peripheral frame 2) and this retains compatibility with C240x-compatible peripherals. The other version supports both 16- and 32-bit accesses (called peripheral frame 1).

C28x and TMS320C2000 are trademarks of Texas Instruments.

June 2004 − Revised June 2006SPRS257C

3.2.4 Real-Time JTAG and Analysis

R281x implements the standard IEEE 1149.1 JTAG interface. Additionally, R281x supports real-time mode of operation whereby the contents of memory, peripheral and register locations can be modified while the processor is running and executing code and servicing interrupts. The user can also single step through non-time critical code while enabling time-critical interrupts to be serviced without interference. R281x implements the real-time mode in hardware within the CPU. This is a unique feature to R281x, no software monitor is required. Additionally, special analysis hardware is provided which allows the user to set hardware breakpoint or data/address watch-points and generate various user selectable break events when a match occurs.

3.2.5 External Interface (XINTF) (2812 Only)

This asynchronous interface consists of 19 address lines, 16 data lines, and three chip-select lines. The chip-select lines are mapped to five external zones, Zones 0, 1, 2, 6, and 7. Zones 0 and 1 share a single chip-select; Zones 6 and 7 also share a single chip-select. Each of the five zones can be programmed with a different number of wait states, strobe signal setup and hold timing and each zone can be programmed for extending wait states externally or not. The programmable wait-state, chip-select and programmable strobe timing enables glueless interface to external memories and peripherals.

3.2.6 M0, M1 SARAMs

All C28x devices contain these two blocks of single access memory, each 1K x 16 in size. The stack pointer points to the beginning of block M1 on reset. The M0 block overlaps the 240x device B0, B1, B2 RAM blocks and hence the mapping of data variables on the 240x devices can remain at the same physical address on C28x devices. The M0 and M1 blocks, like all other memory blocks on C28x devices, are mapped to both program and data space. Hence, the user can use M0 and M1 to execute code or for data variables. The partitioning is performed within the linker. The C28x device presents a unified memory map to the programmer. This makes for easier programming in high-level languages.

Functional Overview

3.2.7 L0, L1, L2, L3, H0 SARAMs

R281x contains an additional 18K x 16 of single-access RAM (SARAM), divided into 5 blocks (4K + 4K +1K +1K+ 8K). Each block can be independently accessed, minimizing pipeline stalls. Each block is mapped to both program and data space.

3.2.8 Boot ROM

The Boot ROM is factory-programmed with boot-loading software. The Boot ROM program executes after device reset and checks several GPIO pins to determine which boot mode to enter . For example, the user can select to download new software to internal RAM through one of several serial ports. Other boot modes exist as well. The Boot ROM also contains standard tables, such as SIN/COS waveforms, for use in math-related algorithms. Table 3−2 shows the details of how various boot modes may be invoked. See the TMS320F28x

DSP Boot ROM Reference Guide (literature number SPRS095), for more information.

June 2004 − Revised June 2006 SPRS257C

Functional Overview

GPIOF4/

GPIOF12/

GPIOF3/

GPIOF2/

GPIOF4/

GPIOF12/

GPIOF3/

GPIOF2/

Table 3−2. Boot Mode Selection

BOOT MODE SELECTED

(Internal PU status Reserved 1 x x x Call SPI_Boot to load from an external serial SPI EEPROM 0 1 x x Call SCI_Boot to load from SCI-A 0 0 1 1 Jump to H0 SARAM address 0x3F 8000 Reserved 0 0 0 1 Call Parallel_Boot to load from GPIO Port B 0 0 0 0

†

PU = pin has an internal pullup No PU = pin does not have an internal pullup

‡

Extra care must be taken due to any effect toggling SPICLK to select a boot mode may have on external logic.

If the boot mode selected is H0, then no external code is loaded by the bootloader.

†)

(SCITXDA)

PU No PU No PU No PU

0 0 1 0

(MDXA)

(SPISTEA)

(SPICLK)

3.2.9 Security

R281x devices contain a non−utilizable code security module for compatibility with C281x and F281x devices. The passwords for the security module are hard-wired in the device as all 0xFFFF. After a device reset, the L0 and L1 SARAM blocks are in a locked condition until a dummy read of the passwords is performed. The R281x Boot ROM performs a dummy read of the password locations. If execution after reset begins directly in external memory on R2812 devices (i.e., MP/MC

=1 ), the user should perform 8 dummy reads, one each

from address 0x3F7FF8 through 0x3F7FFF.

3.2.10 Peripheral Interrupt Expansion (PIE) Block

‡

The PIE block serves to multiplex numerous interrupt sources into a smaller set of interrupt inputs. The PIE block can support up to 96 peripheral interrupts. On R281x, 45 of the possible 96 interrupts are used by peripherals. The 96 interrupts are grouped into blocks of 8 and each group is fed into 1 of 12 CPU interrupt lines (INT1 to INT12

). Each of the 96 interrupts is, supported by its own vector stored in a dedicated RAM block that can be overwritten by the user . The vector is, automatically fetched by the CPU on servicing the interrupt. It takes 8 CPU clock cycles to fetch the vector and save critical CPU registers. Hence the CPU can quickly respond to interrupt events. Prioritization of interrupts is controlled in hardware and software. Each individual interrupt can be enabled/disabled within the PIE block.

3.2.11 External Interrupts (XINT1, 2, 13, XNMI)

R281x supports three masked external interrupts (XINT1, 2, 13). XINT13 is combined with one non-masked external interrupt (XNMI). The combined signal name is XNMI_XINT13. Each of the interrupts can be selected for negative or positive edge triggering and can also be enabled/disabled (including the XNMI). The masked interrupts also contain a 16-bit free running up counter, which is reset to zero when a valid interrupt edge is detected. This counter can be used to accurately time stamp the interrupt.

3.2.12 Oscillator and PLL

R281x can be clocked by an external oscillator or by a crystal attached to the on-chip oscillator circuit. A PLL is provided supporting up to 10-input clock-scaling ratios. The PLL ratios can be changed on-the-fly in software, enabling the user to scale back on operating frequency if lower power operation is desired. Refer to the Electrical Specification section for timing details. The PLL block can be set in bypass mode.

3.2.13 Watchdog

R281x supports a watchdog timer. The user software must regularly reset the watchdog counter within a certain time frame; otherwise, the watchdog will generate a reset to the processor. The watchdog can be disabled if necessary.

June 2004 − Revised June 2006SPRS257C

3.2.14 Peripheral Clocking

The clocks to each individual peripheral can be enabled/disabled so as to reduce power consumption when a peripheral is not in use. Additionally, the system clock to the serial ports (except eCAN) and the event managers, CAP and QEP blocks can be scaled relative to the CPU clock. This enables the timing of peripherals to be decoupled from increasing CPU clock speeds.

3.2.15 Low-Power Modes

R281x devices are full static CMOS devices. Three low-power modes are provided:

IDLE: Place CPU into low-power mode. Peripheral clocks may be turned off selectively and only

those peripherals that need to function during IDLE are left operating. An enabled interrupt from an active peripheral will wake the processor from IDLE mode.

STANDBY: Turn off clock to CPU and peripherals. This mode leaves the oscillator and PLL functional.

An external interrupt event will wake the processor and the peripherals. Execution begins on the next valid cycle after detection of the interrupt event.

HALT: Turn off oscillator. This mode basically shuts down the device and places it in the lowest

possible power consumption mode. Only a reset or XNMI will wake the device from this mode.

3.2.16 Peripheral Frames 0, 1, 2 (PFn)

R281x segregates peripherals into three sections. The mapping of peripherals is as follows:

Functional Overview

PF0: XINTF: External Interface Configuration Registers (2812 only)

PIE: PIE Interrupt Enable and Control Registers Plus PIE Vector Table Timers: CPU-Timers 0, 1, 2 Registers

PF1: eCAN: eCAN Mailbox and Control Registers PF2: SYS: System Control Registers

GPIO: GPIO MUX Configuration and Control Registers EV: Event Manager (EVA/EVB) Control Registers McBSP: McBSP Control and TX/RX Registers SCI: Serial Communications Interface (SCI) Control and RX/TX Registers SPI: Serial Peripheral Interface (SPI) Control and RX/TX Registers ADC: 12-Bit ADC Registers

3.2.17 General-Purpose Input/Output (GPIO) Multiplexer

Most of the peripheral signals are multiplexed with general-purpose I/O (GPIO) signals. This enables the user to use a pin as GPIO if the peripheral signal or function is not used. On reset, all GPIO pins are configured as inputs. The user can then individually program each pin for GPIO mode or Peripheral Signal mode. For specific inputs, the user can also select the number of input qualification cycles. This is to filter unwanted noise glitches.

3.2.18 32-Bit CPU-Timers (0, 1, 2)

CPU-Timers 0, 1, and 2 are identical 32-bit timers with presettable periods and with 16-bit clock prescaling. The timers have a 32-bit count down register, which generates an interrupt when the counter reaches zero. The counter is decremented at the CPU clock speed divided by the prescale value setting. When the counter reaches zero, it is automatically reloaded with a 32-bit period value. CPU-Timer 2 is reserved for Real-Time OS (RTOS)/BIOS applications. CPU-Timer 2 is reserved for the DSP/BIOS real-time operating system (DSP/BIOS R TOS), and is connected to INT14 of the CPU. CPU-Timer 1 is for general use, and is connected to INT13 of the CPU. CPU-Timer 0 is also for general use, and is connected to the PIE block.

June 2004 − Revised June 2006 SPRS257C

Functional Overview

3.2.19 Control Peripherals

R281x supports the following peripherals which are used for embedded control and communication:

EV: The event manager module includes general-purpose timers, full-compare/PWM units,

capture inputs (CAP) and quadrature-encoder pulse (QEP) circuits. Two such event managers are provided which enable two three-phase motors to be driven or four two-phase motors. The event managers on R281x are compatible to the event managers on the 240x devices (with some minor enhancements).

ADC: The ADC block is a 12-bit converter, single ended, 16-channels. It contains two

sample-and-hold units for simultaneous sampling.

3.2.20 Serial Port Peripherals

R281x supports the following serial communication peripherals:

eCAN: This is the enhanced version of the CAN peripheral. It supports 32 mailboxes, time stamping

of messages, and is CAN 2.0B-compliant.

McBSP: This is the multichannel buffered serial port that is used to connect to E1/T1 lines,

phone-quality codecs for modem applications or high-quality stereo-quality Audio DAC devices. The McBSP receive and transmit registers are supported by a 16-level FIFO. This significantly reduces the overhead for servicing this peripheral.

SPI: The SPI is a high-speed, synchronous serial I/O port that allows a serial bit stream of

programmed length (one to sixteen bits) to be shifted into and out of the device at a programmable bit-transfer rate. Normally, the SPI is used for communications between the DSP controller and external peripherals or another processor. Typical applications include external I/O or peripheral expansion through devices such as shift registers, display drivers, and ADCs. Multi-device communications are supported by the master/slave operation of the SPI. On R281x, the port supports a 16-level, receive and transmit FIFO for reducing servicing overhead.

SCI: The serial communications interface is a two-wire asynchronous serial port, commonly

known as UART. On R281x, the port supports a 16-level, receive and transmit FIFO for reducing servicing overhead.

3.3 Register Map

R281x devices contain three peripheral register spaces. The spaces are categorized as follows:

• Peripheral Frame 0: These are peripherals that are mapped directly to the CPU memory bus.

• Peripheral Frame 1: These are peripherals that are mapped to the 32-bit peripheral bus.

• Peripheral Frame 2: These are peripherals that are mapped to the 16-bit peripheral bus.

See Table 3−3.

See Table 3−4.

See Table 3−5.

June 2004 − Revised June 2006SPRS257C

Functional Overview

Table 3−3. Peripheral Frame 0 Registers

NAME ADDRESS RANGE SIZE (x16) ACCESS TYPE

Device Emulation Registers

reserved

XINTF Registers

reserved

CPU-TIMER0/1/2 Registers

reserved

PIE Registers

PIE Vector Table

Reserved

†

Registers in Frame 0 support 16-bit and 32-bit accesses.

‡

If registers are EALLOW protected, then writes cannot be performed until the user executes the EALLOW instruction. The EDIS instruction disables writes. This prevents stray code or pointers from corrupting register contents.

0x00 0880

0x00 09FF 0x00 0A00

0x00 0B1F 0x00 0B20

0x00 0B3F 0x00 0B40

0x00 0BFF 0x00 0C00

0x00 0C3F 0x00 0C40

0x00 0CDF 0x00 0CE0

0x00 0CFF

0x00 0D00

0x00 0DFF

0x00 0E00 0x00 0FFF

Table 3−4. Peripheral Frame 1 Registers

†

‡

384 EALLOW protected

288

32 Not EALLOW protected

192

64 Not EALLOW protected

160

32 Not EALLOW protected

256 EALLOW protected

512

NAME ADDRESS RANGE SIZE (x16) ACCESS TYPE

eCAN Registers

eCAN Mailbox RAM

reserved

The eCAN control registers only support 32-bit read/write operations. All 32-bit accesses are aligned to even address boundaries.

0x00 6000

0x00 60FF 0x00 6100

0x00 61FF 0x00 6200

0x00 6FFF

Table 3−5. Peripheral Frame 2 Registers

NAME ADDRESS RANGE SIZE (x16) ACCESS TYPE

reserved

System Control Registers

reserved

SPI-A Registers

†

Peripheral Frame 2 only allows 16-bit accesses. All 32-bit accesses are ignored (invalid data may be returned or written).

256

(128 x 32)

256

(128 x 32)

3584

Some eCAN control registers (and selected bits in other eCAN control registers) are EALLOW-protected.

Not EALLOW-protected

†

0x00 7000 0x00 700F

0x00 7010 0x00 702F

0x00 7030 0x00 703F

0x00 7040 0x00 704F

32 EALLOW Protected

16 Not EALLOW Protected

June 2004 − Revised June 2006 SPRS257C

Functional Overview

Peripheral Frame 2 Registers

NAME ADDRESS RANGE SIZE (x16) ACCESS TYPE

SCI-A Registers

reserved

External Interrupt Registers

reserved

GPIO MUX Registers

GPIO Data Registers

ADC Registers

reserved

EV-A Registers

reserved

EV-B Registers

reserved

SCI-B Registers

reserved

McBSP Registers

reserved

†

Peripheral Frame 2 only allows 16-bit accesses. All 32-bit accesses are ignored (invalid data may be returned or written).

0x00 7050

0x00 705F

0x00 7060

0x00 706F

0x00 7070

0x00 707F

0x00 7080

0x00 70BF 0x00 70C0

0x00 70DF 0x00 70E0

0x00 70FF

0x00 7100 0x00 711F

0x00 7120

0x00 73FF

0x00 7400

0x00 743F

0x00 7440

0x00 74FF

0x00 7500

0x00 753F

0x00 7540

0x00 774F

0x00 7750

0x00 775F

0x00 7760

0x00 77FF

0x00 7800

0x00 783F

0x00 7840

0x00 7FFF

†

(Continued)

16 Not EALLOW Protected

32 EALLOW Protected

32 Not EALLOW Protected

736

64 Not EALLOW Protected

192

64 Not EALLOW Protected

528

16 Not EALLOW Protected

160

64 Not EALLOW Protected

1984

3.4 Device Emulation Registers

These registers are used to control the protection mode of the C28x CPU and to monitor some critical device signals. The registers are defined in Table 3−6.

June 2004 − Revised June 2006SPRS257C

Table 3−6. Device Emulation Registers

NAME ADDRESS RANGE SIZE (x16) DESCRIPTION

DEVICECNF PARTID 0x00 0882 1 0x0003 − R281x REVID 0x00 0883 1 PROTSTART 0x00 0884 1 Block Protection Start Address Register

PROTRANGE 0x00 0885 1 Block Protection Range Address Register reserved

0x00 0880 0x00 0881

0x00 0886 0x00 09FF

2 Device Configuration Register

Revision ID Register (0x0001 − Silicon Rev. A) Revision ID Register (0x0002 − Silicon Rev. B)

378

3.5 External Interface, XINTF (2812 Only)

This section gives a top-level view of the external interface (XINTF) that is implemented on the 2812 devices. The external interface is a non-multiplexed asynchronous bus, similar to the C240x external interface. The

external interface on the 2812 is mapped into five fixed zones shown in Figure 3−4. Figure 3−4 shows the 2812 XINTF signals. The operation and timing of the external interface, can be controlled by the registers listed in Table 3−7.

Table 3−7. XINTF Configuration and Control Register Mappings

Functional Overview

NAME ADDRESS SIZE (x16) DESCRIPTION

XTIMING0 0x00 0B20 2 XINTF Timing Register , Zone 0 can access as two 16-bit registers or one 32-bit register XTIMING1 0x00 0B22 2 XINTF Timing Register , Zone 1 can access as two 16-bit registers or one 32-bit register XTIMING2 0x00 0B24 2 XINTF Timing Register , Zone 2 can access as two 16-bit registers or one 32-bit register XTIMING6 0x00 0B2C 2 XINTF Timing Register, Zone 6 can access as two 16-bit registers or one 32-bit register XTIMING7 0x00 0B2E 2 XINTF Timing Register, Zone 7 can access as two 16-bit registers or one 32-bit register XINTCNF2 0x00 0B34 2 XINTF Configuration Register can access as two 16-bit registers or one 32-bit register XBANK 0x00 0B38 1 XINTF Bank Control Register XREVISION 0x00 0B3A 1 XINTF Revision Register

3.5.1 Timing Registers

XINTF signal timing can be tuned to match specific external device requirements such as setup and hold times to strobe signals for contention avoidance and maximizing bus efficiency. The timing parameters can be configured individually for each zone. This allows the programmer to maximize the efficiency of the bus, based on the type of memory or peripheral that the user needs to access. All XINTF timing values are with respect to XTIMCLK, which is equal to or one-half of the SYSCLKOUT rate, as shown in Figure 6−26.

For detailed information on the XINTF timing and configuration register bit fields, see the TMS320F28x DSP External Interface (XINTF) Reference Guide (literature number SPRU067).

3.5.2 XREVISION Register

The XREVISION register contains a unique number to identify the particular version of XINTF used in the product. For the 2812, this register will be configured as described in Table 3−8.

Table 3−8. XREVISION Register Bit Definitions

BIT(S) NAME TYPE RESET DESCRIPTION

15−0 REVISION R 0x0004

June 2004 − Revised June 2006 SPRS257C

Current XINTF Revision. For internal use/reference. Test purposes only. Subject to change.

Functional Overview

Data Space Prog Space

0x00 0000

XD(15:0)

XA(18:0)

0x00 2000

0x00 4000

0x00 6000

0x08 0000

0x10 0000

0x18 0000

0x3F C000

0x40 0000

XINTF Zone 0

(8K × 16)

XINTF Zone 1

(8K × 16)

XINTF Zone 2

(512K × 16)

XINTF Zone 6

(512K × 16)

XINTF Zone 7

(mapped here if MP/MC

(16K × 16)

= 1)

XZCS0 XZCS1

XZCS2

XZCS6

XZCS7

XREADY XMP/MC

XHOLD

XHOLDA

XCLKOUT (see Note E)

XZCS0AND1

XZCS6AND7

XWE XRD XR/W

NOTES: A. The mapping of XINTF Zone 7 is dependent on the XMP/MC device input signal and the MP/MC mode bit (bit 8 of XINTCNF2

B. Each zone can be programmed with different wait states, setup and hold timing, and is supported by zone chip selects

(XZCS0AND1 glueless connection to many external memories and peripherals.

C. The chip selects for Zone 0 and 1 are ANDed internally together to form one chip select (XZCS0AND1

that is connected to XZCS0AND1

D. The chip selects for Zone 6 and 7 are ANDed internally together to form one chip select (XZCS6AND7

that is connected to XZCS6AND7 MP/MC

E. XCLKOUT is also pinned out on the 2810 and 2811.

, XZCS2, XZCS6AND7), which toggle when an access to a particular zone is performed. These features enable

). Any external memory

is dually mapped to both Zones 0 and Zone 1.

). Any external memory

is dually mapped to both Zones 6 and Zone 7. This means that if Zone 7 is disabled (via the

mode) then any external memory is still accessible via Zone 6 address space.

Figure 3−4. External Interface Block Diagram

June 2004 − Revised June 2006SPRS257C

3.6 Interrupts

Figure 3−5 shows how the various interrupt sources are multiplexed within R281x devices.

Functional Overview

INT1 to INT12

C28x CPU

INT14

INT13

PIE

†

96 Interrupts

MUX

TINT0 TINT2 TINT1

WAKEINT

Peripherals (SPI, SCI, McBSP, CAN, EV, ADC)

Interrupt Control

XINT1CR(15:0)

XINT1CTR(15:0)

Interrupt Control

XINT2CR(15:0)

XINT2CTR(15:0)

TIMER 0

TIMER 2 (for RTOS)

TIMER 1

(41 Interrupts)

WDINT LPMINT

Watchdog

Low-Power Modes

XINT1

XINT2

GPIO

MUX

select

enable

NMI

†

Out of a possible 96 interrupts, 45 are currently used by peripherals.

Interrupt Control

XNMICR(15:0)

XNMICTR(15:0)

XNMI_XINT13

Figure 3−5. Interrupt Sources

Figure 3−6 shows how the interrupts are multiplexed using the PIE block. Eight PIE block interrupts are grouped into one CPU interrupt. In total, 12 CPU interrupt groups, with 8 interrupts per group equals 96 possible interrupts. On R281x, 45 of these are used by peripherals as shown in Table 3−9.

June 2004 − Revised June 2006 SPRS257C

Functional Overview

CPU

INTx

PIEACKx

(Enable/Flag)

Figure 3−6. Multiplexing of Interrupts Using the PIE Block

INT1 INT2

INT11 INT12

MUX

IER(12:1)IFR(12:1)

(Enable)(Flag)

(Enable) (Flag)

PIEIERx(8:1) PIEIFRx(8:1)

MUX

INTx.1 INTx.2 INTx.3 INTx.4 INTx.5 INTx.6 INTx.7 INTx.8

INTM

Global

Enable

From

Peripherals or

External

Interrupts

CPU

(EV-A)

(EV-B)

†

CMP3INT

CMP6INT

SCIRXINTB

(EV-A)

T2UFINT

(EV-A)

(EV-B)

T4UFINT

(EV-B)

(SCI-B)

PDPINTB

(EV-B)

CMP2INT

(EV-A)

T2CINT

(EV-A)

CMP5INT

(EV-B)

T4CINT

(EV-B)

SPITXINTA

(SPI)

SCITXINTA

(SCI-A)

PDPINTA

(EV-A)

CMP1INT

(EV-A)

T2PINT

(EV-A)

CMP4INT

(EV-B)

T4PINT

(EV-B)

SPIRXINTA

(SPI)

SCIRXINTA

(SCI-A)

Table 3−9. PIE Peripheral Interrupts

PIE INTERRUPTS

INTERRUPTS

INT1

INT2 reserved

INT3 reserved

INT4 reserved

INT5 reserved

INT6 reserved reserved INT7 reserved reserved reserved reserved reserved reserved reserved reserved

INT8 reserved reserved reserved reserved reserved reserved reserved reserved INT9 reserved reserved

INT10 reserved reserved reserved reserved reserved reserved reserved reserved INT11 reserved reserved reserved reserved reserved reserved reserved reserved INT12 reserved reserved reserved reserved reserved reserved reserved reserved

†

Out of the 96 possible interrupts, 45 interrupts are currently used. The remaining interrupts are reserved for future devices. These interrupts can be used as software interrupts if they are enabled at the PIEIFRx level, provided none of the interrupts within the group is being used by a peripheral. Otherwise, interrupts coming in from peripherals may be lost by accidentally clearing their flag while modifying the PIEIFR.

INTx.8 INTx.7 INTx.6 INTx.5 INTx.4 INTx.3 INTx.2 INTx.1

WAKEINT

(LPM/WD)

TINT0

(TIMER 0)

T1OFINT

(EV-A)

CAPINT3

(EV-A)

T3OFINT

(EV-B)

CAPINT6

(EV-B)

ADCINT

(ADC)

T1UFINT

(EV-A)

CAPINT2

(EV-A)

T3UFINT

(EV-B)

CAPINT5

(EV-B)

MXINT

(McBSP)

ECAN1INT

(CAN)

XINT2 XINT1 reserved

T1CINT

(EV-A)

CAPINT1

(EV-A)

T3CINT

(EV-B)

CAPINT4

(EV-B)

MRINT

(McBSP)

ECAN0INT

(CAN)

T1PINT

T2OFINT

T3PINT

T4OFINT

reserved reserved

SCITXINTB

(SCI-B)

To summarize, there are two safe cases when the reserved interrupts could be used as software interrupts:

1) No peripheral within the group is asserting interrupts.

2) No peripheral interrupts are assigned to the group (example PIE group 12).

June 2004 − Revised June 2006SPRS257C

Table 3−10. PIE Configuration and Control Registers

Functional Overview

NAME ADDRESS

PIECTRL 0x0000−0CE0 1 PIE, Control Register PIEACK 0x0000−0CE1 1 PIE, Acknowledge Register PIEIER1 0x0000−0CE2 1 PIE, INT1 Group Enable Register PIEIFR1 0x0000−0CE3 1 PIE, INT1 Group Flag Register PIEIER2 0x0000−0CE4 1 PIE, INT2 Group Enable Register PIEIFR2 0x0000−0CE5 1 PIE, INT2 Group Flag Register PIEIER3 0x0000−0CE6 1 PIE, INT3 Group Enable Register PIEIFR3 0x0000−0CE7 1 PIE, INT3 Group Flag Register PIEIER4 0x0000−0CE8 1 PIE, INT4 Group Enable Register PIEIFR4 0x0000−0CE9 1 PIE, INT4 Group Flag Register PIEIER5 0x0000−0CEA 1 PIE, INT5 Group Enable Register PIEIFR5 0x0000−0CEB 1 PIE, INT5 Group Flag Register PIEIER6 0x0000−0CEC 1 PIE, INT6 Group Enable Register PIEIFR6 0x0000−0CED 1 PIE, INT6 Group Flag Register PIEIER7 0x0000−0CEE 1 PIE, INT7 Group Enable Register PIEIFR7 0x0000−0CEF 1 PIE, INT7 Group Flag Register

Size (x16)

DESCRIPTION

PIEIER8 0x0000−0CF0 1 PIE, INT8 Group Enable Register PIEIFR8 0x0000−0CF1 1 PIE, INT8 Group Flag Register PIEIER9 0x0000−0CF2 1 PIE, INT9 Group Enable Register PIEIFR9 0x0000−0CF3 1 PIE, INT9 Group Flag Register PIEIER10 0x0000−0CF4 1 PIE, INT10 Group Enable Register PIEIFR10 0x0000−0CF5 1 PIE, INT10 Group Flag Register PIEIER11 0x0000−0CF6 1 PIE, INT11 Group Enable Register PIEIFR11 0x0000−0CF7 1 PIE, INT1 1 Group Flag Register PIEIER12 0x0000−0CF8 1 PIE, INT12 Group Enable Register PIEIFR12 0x0000−0CF9 1 PIE, INT12 Group Flag Register Reserved 0x0000−0CFA

0x0000−0CFF

Note: The PIE configuration and control registers are not protected by EALLOW mode. The PIE vector table is protected.

6 Reserved

June 2004 − Revised June 2006 SPRS257C

Functional Overview

3.6.1 External Interrupts

Table 3−11. External Interrupt Registers

NAME ADDRESS SIZE (x16) DESCRIPTION

XINT1CR 0x00 7070 1 XINT1 control register XINT2CR 0x00 7071 1 XINT2 control register

reserved XNMICR 0x00 7077 1 XNMI control register

XINT1CTR 0x00 7078 1 XINT1 counter register XINT2CTR 0x00 7079 1 XINT2 counter register

reserved XNMICTR 0x00 707F 1 XNMI counter register

Each external interrupt can be enabled/disabled or qualified using positive or negative going edge. For more information, see the TMS320F28x System Control and Interrupts Reference Guide (literature number SPRU078).

0x00 7072 0x00 7076

0x00 707A 0x00 707E

June 2004 − Revised June 2006SPRS257C

3.7 System Control

This section describes R281x oscillator, PLL and clocking mechanisms, the watchdog function and the low power modes. Figure 3−7 shows the various clock and reset domains in R281x devices that will be discussed.

Reset

SYSCLKOUT

Peripheral Reset

Watchdog

Block

Functional Overview

XRS

C28x

CPU

Peripheral Bus

System Control

Registers

Peripheral

Registers

Low-Speed Prescaler

Peripheral

Registers

High-Speed Prescaler

Peripheral

Registers

CLKIN

Clock Enables

eCAN

LSPCLK

Low-Speed Peripherals

SCI-A/B, SPI, McBSP

HSPCLK

High-Speed Peripherals

EV-A/B

PLL

Power

Modes

Control

I/O

OSC

GPIO

MUX

X1/XCLKIN

XF_XPLLDIS

GPIOs

HSPCLK

ADC

Registers

NOTE A: CLKIN is the clock input to the CPU. SYSCLKOUT is the output clock of the CPU. They are of the same frequency.

12-Bit ADC

16 ADC Inputs

Figure 3−7. Clock and Reset Domains

The PLL, clocking, watchdog and low-power modes are controlled by the registers listed in Table 3−12.

June 2004 − Revised June 2006 SPRS257C

Functional Overview

Table 3−12. PLL, Clocking, Watchdog, and Low-Power Mode Registers

NAME ADDRESS SIZE (x16) DESCRIPTION

reserved reserved 0x00 7018 1

reserved 0x00 7019 1 HISPCP 0x00 701A 1 High-Speed Peripheral Clock Prescaler Register for HSPCLK clock LOSPCP 0x00 701B 1 Low-Speed Peripheral Clock Prescaler Register for LSPCLK clock

PCLKCR 0x00 701C 1 Peripheral Clock Control Register

reserved 0x00 701D 1 LPMCR0 0x00 701E 1 Low Power Mode Control Register 0 LPMCR1 0x00 701F 1 Low Power Mode Control Register 1 reserved 0x00 7020 1 PLLCR 0x00 7021 1 PLL Control Register SCSR 0x00 7022 1 System Control & Status Register WDCNTR 0x00 7023 1 Watchdog Counter Register reserved 0x00 7024 1 WDKEY 0x00 7025 1 Watchdog Reset Key Register

reserved WDCR 0x00 7029 1 Watchdog Control Register reserved

†

All of the above registers can only be accessed, by executing the EALLOW instruction.

‡

The PLL control register (PLLCR) is reset to a known state by the XRS reset PLLCR.

0x00 7010 0x00 7017

0x00 7026 0x00 7028

0x00 702A 0x00 702F

‡

signal only. Emulation reset (through Code Composer Studio) will not

†

3.7.1 OSC and PLL Block

Figure 3−8 shows the OSC and PLL block on R281x.

June 2004 − Revised June 2006SPRS257C

Functional Overview

XPLLDIS

XF_XPLLDIS

XCLKIN

X1/XCLKIN

On-Chip

Oscillator

(OSC)

Latch

XRS

OSCCLK (PLL Disabled)

Bypass

4-Bit PLL Select

PLL

PLL Block

CLKIN

CPU

Figure 3−8. OSC and PLL Block

The on-chip oscillator circuit enables a crystal to be attached to R281x devices using the X1/XCLKIN and X2 pins. If a crystal is not used, then an external oscillator can be directly connected to the X1/XCLKIN pin and the X2 pin is left unconnected. The logic-high level in this case should not exceed V

. The PLLCR bits [3:0]

set the clocking ratio.

Table 3−13. PLLCR Register Bit Definitions

BIT(S) NAME TYPE XRS RESET

15:4 reserved R = 0 0:0

†

SYSCLKOUT = (XCLKIN * n)/2, where n is the PLL multiplication factor.

DESCRIPTION

SYSCLKOU

3:0 DIV R/W 0,0,0,0

†

The PLLCR register is reset to a known state by the XRS

3.7.2 Loss of Input Clock

In PLL enabled mode, if the input clock XCLKIN or the oscillator clock is removed or absent, the PLL will still issue a “limp-mode” clock. The limp-mode clock will continue to clock the CPU and peripherals at a typical frequency of 1−4 MHz. The PLLCR register should have been written to with a non-zero value for this feature to work.

Bit Value n SYSCLKOUT

0000 PLL Bypassed XCLKIN/2 0001 1 XCLKIN/2 0010 2 XCLKIN 0011 3 XCLKIN * 1.5 0100 4 XCLKIN * 2 0101 5 XCLKIN * 2.5 0110 6 XCLKIN * 3 0111 7 XCLKIN * 3.5 1000 8 XCLKIN * 4 1001 9 XCLKIN * 4.5 1010 10 XCLKIN * 5 1011 11 Reserved 1100 12 Reserved 1101 13 Reserved 1110 14 Reserved 1111 15 Reserved

reset line. If a reset is issued by the debugger, the PLL clocking ratio is not changed.

June 2004 − Revised June 2006 SPRS257C

Functional Overview

Normally, when the input clocks are present, the watchdog counter will decrement to initiate a watchdog reset or WDINT interrupt. However, when the external input clock fails, the watchdog counter will stop decrementing (i.e., the watchdog counter does not change with the limp-mode clock). This condition could be used by the application firmware to detect the input clock failure and initiate necessary shut-down procedure for the system.

3.7.3 PLL-Based Clock Module

R281x has an on-chip, PLL-based clock module. This module provides all the necessary clocking signals for the device, as well as control for low-power mode entry. The PLL has a 4-bit ratio control to select different CPU clock rates. The watchdog module should be disabled before writing to the PLLCR register. It can be re-enabled (if need be) after the PLL module has stabilized, which takes 131072 XCLKIN cycles.

The PLL-based clock module provides two modes of operation:

• Crystal-operation

This mode allows the use of an external crystal/resonator to provide the time base to the device.

• External clock source operation

This mode allows the internal oscillator to be bypassed. The device clocks are generated from an external clock source input on the X1/XCLKIN pin.

X2X1/XCLKIN X1/XCLKIN X2

(see Note A)

NOTE A: TI recommends that customers have the resonator/crystal vendor characterize the operation of their device with the DSP chip. The

Crystal

(a) (b)

resonator/crystal vendor has the equipment and expertise to tune the tank circuit. The vendor can also advise the customer regarding the proper tank component values that will ensure start-up and stability over the entire operating range.

(see Note A)

External Clock Signal

(Toggling 0−VDD)

Figure 3−9. Recommended Crystal/Clock Connection

Table 3−14. Possible PLL Configuration Modes

PLL MODE REMARKS SYSCLKOUT

Invoked by tying XPLLDIS pin low upon reset. PLL block is completely

PLL Disabled

PLL Bypassed

PLL Enabled

disabled. Clock input to the CPU (CLKIN) is directly derived from the clock signal present at the X1/XCLKIN pin.

Default PLL configuration upon power-up, if PLL is not disabled. The PLL itself is bypassed. However, the /2 module in the PLL block divides the clock input at the X1/XCLKIN pin by two before feeding it to the CPU.

Achieved by writing a non-zero value “n” into PLLCR register. The /2 module in the PLL block now divides the output of the PLL by two before feeding it to the CPU.

XCLKIN

XCLKIN/2

(XCLKIN * n) / 2

3.7.4 External Reference Oscillator Clock Option

The typical specifications for the external quartz crystal for a frequency of 30 MHz are listed below:

• Fundamental mode, parallel resonant

• C

• CL1 = C

• C

(load capacitance) = 12 pF

= 24 pF

= 6 pF

shunt

• ESR range = 25 to 40 Ω

June 2004 − Revised June 2006SPRS257C

3.7.5 Watchdog Block

The watchdog block on R281x is identical to the one used on the 240x devices. The watchdog module generates an output pulse, 512 oscillator clocks wide (OSCCLK), whenever the 8-bit watchdog up counter has reached its maximum value. To prevent this, the user disables the counter or the software must periodically write a 0x55 + 0xAA sequence into the watchdog key register which will reset the watchdog counter. Figure 3−10 shows the various functional blocks within the watchdog module.

Functional Overview

OSCCLK

Internal

XRS

Pullup

WDKEY(7:0)

Key Detector

WDRST

(See Note A)

/512

Watchdog

55 + AA

WDCR (WDPS(2:0))

Watchdog

Prescaler

Bad Key

Good Key

Core-reset

WDCR (WDCHK(2:0))

1 0 1

WDCLK

WDCR (WDDIS)

Clear Counter

Bad WDCHK Key

WDCNTR(7:0)

8-Bit

Watchdog

Counter

CLR

Generate

Output Pulse

(512 OSCCLKs)

SCSR (WDENINT)

WDRST

WDINT

NOTE A: The WDRST signal is driven low for 512 OSCCLK cycles.

Figure 3−10. Watchdog Module

The WDINT

signal enables the watchdog to be used as a wakeup from IDLE/STANDBY mode timer.

In STANDBY mode, all peripherals are turned off on the device. The only peripheral that remains functional is the watchdog. The Watchdog module will run off the PLL clock or the oscillator clock. The WDINT is fed to the LPM block so that it can wake the device from STANDBY (if enabled). See Section 3.7.6, Low-Power Modes Block, for more details.

In IDLE mode, the WDINT

signal can generate an interrupt to the CPU, via the PIE, to take the CPU out of

IDLE mode. In HALT mode, this feature cannot be used because the oscillator (and PLL) are turned off and hence so is

the WATCHDOG.

3.7.6 Low-Power Modes Block

The low-power modes on R281x are similar to the 240x devices. Table 3−15 summarizes the various modes.

June 2004 − Revised June 2006 SPRS257C

signal

Functional Overview

Table 3−15. R281x Low-Power Modes

MODE LPM(1:0) OSCCLK CLKIN SYSCLKOUT EXIT

Normal X,X on on on −

IDLE 0,0 on on on

STANDBY 0,1

HALT 1,X

†

The Exit column lists which signals or under what conditions the low power mode will be exited. A low signal, on any of the signals, will exit the low power condition. This signal must be kept low long enough for an interrupt to be recognized by the device. Otherwise the IDLE mode will not be exited and the device will go back into the indicated low power mode.

‡

The IDLE mode on the C28x behaves differently than on the 24x/240x. On the C28x, the clock output from the core (SYSCLKOUT) is still functional while on the 24x/240x the clock is turned off.

On the C28x, the JTAG port can still function even if the core clock (CLKIN) is turned off.

(watchdog still running)

off

(oscillator and PLL turned off,

watchdog not functional)

off off

‡

Any Enabled Interrupt,

T1/2/3/4CTRIP

C1/2/3/4/5/6TRIP

†

XRS,

WDINT

XNMI

Debugger

XRS,

WDINT

XINT1,

XNMI,

SCIRXDA, SCIRXDB,

CANRX,

Debugger

XRS,

XNMI,

Debugger

The various low-power modes operate as follows:

IDLE Mode: This mode is exited by any enabled interrupt or an XNMI that is

recognized by the processor. The LPM block performs no tasks during this mode as long as the LPMCR0(LPM) bits are set to 0,0.

STANDBY Mode: All other signals (including XNMI) will wake the device from ST ANDBY

mode if selected by the LPMCR1 register. The user will need to select which signal(s) will wake the device. The selected signal(s) are also qualified by the OSCCLK before waking the device. The number of OSCCLKs is specified in the LPMCR0 register.

HALT Mode: Only the XRS

and XNMI external signals can wake the device from HALT mode. The XNMI input to the core has an enable/disable bit. Hence, it is safe to use the XNMI signal for this function.

NOTE: The low-power modes do not affect the state of the output pins (PWM pins included). They will be

in whatever state the code left them when the IDLE instruction was executed.

June 2004 − Revised June 2006SPRS257C

4 Peripherals

The integrated peripherals of R281x are described in the following subsections:

• Three 32-bit CPU-Timers

• Two event-manager modules (EVA, EVB)

• Enhanced analog-to-digital converter (ADC) module

• Enhanced controller area network (eCAN) module

• Multichannel buffered serial port (McBSP) module

• Serial communications interface modules (SCI-A, SCI-B)

• Serial peripheral interface (SPI) module

• Digital I/O and shared pin functions

4.1 32-Bit CPU-Timers 0/1/2

There are three 32-bit CPU-timers on R281x devices (CPU-TIMER0/1/2). CPU-Timer 1 i s reserved for TI system functions and Timer 2 is reserved for DSP/BIOS. CPU-Timer 0 can be

used in user applications. These timers are different from the general-purpose (GP) timers that are present in the Event Manager modules (EVA, EVB).

Peripherals

NOTE: If the application is not using DSP/BIOS, then CPU-Timers 1 and 2 can be used in the application.

Reset

Timer Reload

SYSCLKOUT

TCR.4

(Timer Start Status)

TINT

16-Bit Timer Divide-Down

TDDRH:TDDR

16-Bit Prescale Counter

PSCH:PSC

Borrow

32-Bit Timer Period

Figure 4−1. CPU-Timers

PRDH:PRD

32-Bit Counter

TIMH:TIM

Borrow

June 2004 − Revised June 2006 SPRS257C

Peripherals

In R281x devices, the timer interrupt signals (TINT0, TINT1, TINT2) are connected as shown in Figure 4−2.

INT1

INT12

C28x

INT13

INT14

NOTES: A. The timer registers are connected to the Memory Bus of the C28x processor.

B. The timing of the timers is synchronized to SYSCLKOUT of the processor clock.

PIE

TINT2

TINT0

TINT1

XINT13

CPU-TIMER 0

CPU-TIMER 1

(Reserved for TI

system functions)

CPU-TIMER 2 (Reserved for

DSP/BIOS)

Figure 4−2. CPU-Timer Interrupts Signals and Output Signal (See Notes A and B)

The general operation of the timer is as follows: The 32-bit counter register “TIMH:TIM” is loaded with the value in the period register “PRDH:PRD”. The counter register, decrements at the SYSCLKOUT rate of the C28x. When the counter reaches 0, a timer interrupt output signal generates an interrupt pulse. The registers listed in Table 4−1 are used to configure the timers. For more information, see the TMS320F28x System Control and Interrupts Reference Guide (literature number SPRU078).

June 2004 − Revised June 2006SPRS257C

Table 4−1. CPU-Timers 0, 1, 2 Configuration and Control Registers

NAME ADDRESS SIZE (x16) DESCRIPTION

TIMER0TIM 0x00 0C00 1 CPU-Timer 0, Counter Register TIMER0TIMH 0x00 0C01 1 CPU-Timer 0, Counter Register High TIMER0PRD 0x00 0C02 1 CPU-Timer 0, Period Register TIMER0PRDH 0x00 0C03 1 CPU-Timer 0, Period Register High TIMER0TCR 0x00 0C04 1 CPU-Timer 0, Control Register reserved 0x00 0C05 1 TIMER0TPR 0x00 0C06 1 CPU-Timer 0, Prescale Register TIMER0TPRH 0x00 0C07 1 CPU-Timer 0, Prescale Register High TIMER1TIM 0x00 0C08 1 CPU-Timer 1, Counter Register TIMER1TIMH 0x00 0C09 1 CPU-Timer 1, Counter Register High TIMER1PRD 0x00 0C0A 1 CPU-Timer 1, Period Register TIMER1PRDH 0x00 0C0B 1 CPU-Timer 1, Period Register High TIMER1TCR 0x00 0C0C 1 CPU-Timer 1, Control Register reserved 0x00 0C0D 1 TIMER1TPR 0x00 0C0E 1 CPU-Timer 1, Prescale Register TIMER1TPRH 0x00 0C0F 1 CPU-Timer 1, Prescale Register High TIMER2TIM 0x00 0C10 1 CPU-Timer 2, Counter Register TIMER2TIMH 0x00 0C11 1 CPU-Timer 2, Counter Register High TIMER2PRD 0x00 0C12 1 CPU-Timer 2, Period Register TIMER2PRDH 0x00 0C13 1 CPU-Timer 2, Period Register High TIMER2TCR 0x00 0C14 1 CPU-Timer 2, Control Register reserved 0x00 0C15 1 TIMER2TPR 0x00 0C16 1 CPU-Timer 2, Prescale Register TIMER2TPRH 0x00 0C17 1 CPU-Timer 2, Prescale Register High

reserved

0x00 0C18

0x00 0C3F

Peripherals

4.2 Event Manager Modules (EVA, EVB)

The event-manager modules include general-purpose (GP) timers, full-compare/PWM units, capture units, and quadrature-encoder pulse (QEP) circuits. EVA and EVB timers, compare units, and capture units function identically. However, timer/unit names differ for EV A and EVB. Table 4−2 shows the module and signal names used. Table 4−2 shows the features and functionality available for the event-manager modules and highlights EVA nomenclature.

Event managers A and B have identical peripheral register sets with EVA starting at 7400h and EVB starting at 7500h. The paragraphs in this section describe the function of GP timers, compare units, capture units, and QEPs using EVA nomenclature. These paragraphs are applicable to EVB with regard to function—however , module/signal names would differ. Table 4−3 lists the EVA registers. For more information, see the

TMS320F28x DSP Event Manager (EV) Reference Guide (literature number SPRU065).

June 2004 − Revised June 2006 SPRS257C

Peripherals

EVENT MANAGER MODULES

Table 4−2. Module and Signal Names for EVA and EVB

MODULE SIGNAL MODULE SIGNAL

GP Timers

Compare Units

Capture Units

QEP Channels

External Clock Inputs

External Trip Inputs Compare

External Trip Inputs

†

In the 24x/240x-compatible mode, the T1CTRIP_PDPINTA

GP Timer 1 GP Timer 2

Compare 1 Compare 2 Compare 3

Capture 1 Capture 2 Capture 3

QEP1 QEP2

QEPI1

Direction

External Clock

EVA EVB

T1PWM/T1CMP T2PWM/T2CMP

PWM1/2 PWM3/4 PWM5/6

CAP1 CAP2 CAP3

QEP1 QEP2

TDIRA

TCLKINA

C1TRIP C2TRIP C3TRIP

T1CTRIP_PDPINTA

T2CTRIP

pin functions as PDPINTA and the T3CTRIP_PDPINTB pin functions as PDPINTB.

/EVASOC

†

GP Timer 3 GP Timer 4

Compare 4 Compare 5 Compare 6

Capture 4 Capture 5 Capture 6

QEP3 QEP4

QEPI2

Direction

External Clock

Compare

T3PWM/T3CMP T4PWM/T4CMP

PWM7/8

PWM9/10

PWM11/12

CAP4 CAP5 CAP6

QEP3 QEP4

TDIRB

TCLKINB

C4TRIP C5TRIP C6TRIP

T3CTRIP_PDPINTB

T4CTRIP

/EVBSOC

†

June 2004 − Revised June 2006SPRS257C

Peripherals

Table 4−3. EVA Registers

NAME ADDRESS

GPTCONA 0x00 7400 1 GP Timer Control Register A

T1CNT 0x00 7401 1 GP Timer 1 Counter Register

T1CMPR 0x00 7402 1 GP Timer 1 Compare Register

T1PR 0x00 7403 1 GP Timer 1 Period Register

T1CON 0x00 7404 1 GP Timer 1 Control Register

T2CNT 0x00 7405 1 GP Timer 2 Counter Register

T2CMPR 0x00 7406 1 GP Timer 2 Compare Register

T2PR 0x00 7407 1 GP Timer 2 Period Register

T2CON 0x00 7408 1 GP Timer 2 Control Register

EXTCONA

COMCONA 0x00 7411 1 Compare Control Register A

ACTRA 0x00 7413 1 Compare Action Control Register A

DBTCONA 0x00 7415 1 Dead-Band Timer Control Register A

CMPR1 0x00 7417 1 Compare Register 1 CMPR2 0x00 7418 1 Compare Register 2

CMPR3 0x00 7419 1 Compare Register 3 CAPCONA 0x00 7420 1 Capture Control Register A CAPFIFOA 0x00 7422 1 Capture FIFO Status Register A

CAP1FIFO 0x00 7423 1 T wo-Level Deep Capture FIFO Stack 1 CAP2FIFO 0x00 7424 1 T wo-Level Deep Capture FIFO Stack 2

CAP3FIFO 0x00 7425 1 T wo-Level Deep Capture FIFO Stack 3 CAP1FBOT 0x00 7427 1 Bottom Register Of Capture FIFO Stack 1 CAP2FBOT 0x00 7428 1 Bottom Register Of Capture FIFO Stack 2 CAP3FBOT 0x00 7429 1 Bottom Register Of Capture FIFO Stack 3

EVAIMRA 0x00 742C 1 Interrupt Mask Register A EVAIMRB 0x00 742D 1 Interrupt Mask Register B EVAIMRC 0x00 742E 1 Interrupt Mask Register C

EVAIFRA 0x00 742F 1 Interrupt Flag Register A EVAIFRB 0x00 7430 1 Interrupt Flag Register B

EVAIFRC 0x00 7431 1 Interrupt Flag Register C

†

The EV-B register set is identical except the address range is from 0x00−7500 to 0x00−753F. The above registers are mapped to Zone 2. This space allows only 16-bit accesses. 32-bit accesses produce undefined results.

‡

New register compared to 24x/240x

‡

0x00 7409 1 GP Extension Control Register A

SIZE

(x16)

†

DESCRIPTION

June 2004 − Revised June 2006 SPRS257C

Peripherals

Peripheral Write Bus

MXINT

To CPU

LSPCLK

MRINT

To CPU

TX Interrupt Logic

McBSP Transmit

Interrupt Select Logic

McBSP Registers

and Control Logic

McBSP

McBSP Receive

Interrupt Select Logic

RX Interrupt Logic

TX FIFO

Interrupt

RX FIFO Interrupt

TX FIFO _15

— TX FIFO _1 TX FIFO _0

TX FIFO Registers

DXR2 Transmit Buffer

XSR2

RSR2

DRR2 Receive Buffer

RX FIFO _15

—

RX FIFO _1 RX FIFO _0

RX FIFO Registers

TX FIFO _15

— TX FIFO _1 TX FIFO _0

DXR1 Transmit Buffer

Compand Logic

XSR1

RSR1

Expand Logic

RBR1 RegisterRBR2 Register

DRR1 Receive Buffer

RX FIFO _15

— RX FIFO _1 RX FIFO _0

FSX

CLKX

CLKR

FSR

Figure 4−3. Event Manager A Functional Block Diagram (See Note A)

4.2.1 General-Purpose (GP) Timers

There are two GP timers. The GP timer x (x = 1 or 2 for EVA; x = 3 or 4 for EVB) includes:

• A 16-bit timer, up-/down-counter, TxCNT, for reads or writes

• A 16-bit timer-compare register, TxCMPR (double-buffered with shadow register), for reads or writes

• A 16-bit timer-period register, TxPR (double-buffered with shadow register), for reads or writes

• A 16-bit timer-control register,TxCON, for reads or writes

• Selectable internal or external input clocks

Peripheral Read Bus

June 2004 − Revised June 2006SPRS257C

• A programmable prescaler for internal or external clock inputs

• Control and interrupt logic, for four maskable interrupts: underflow, overflow, timer compare, and period

interrupts

• A selectable direction input pin (TDIRx) (to count up or down when directional up- /down-count mode is selected)

The GP timers can be operated independently or synchronized with each other. The compare register associated with each GP timer can be used for compare function and PWM-waveform generation. There are three continuous modes of operations for each GP timer in up- or up/down-counting operations. Internal or external input clocks with programmable prescaler are used for each GP timer. GP timers also provide the time base for the other event-manager submodules: GP timer 1 for all the compares and PWM circuits, GP timer 2/1 for the capture units and the quadrature-pulse counting operations. Double-buffering of the period and compare registers allows programmable change of the timer (PWM) period and the compare/PWM pulse width as needed.

4.2.2 Full-Compare Units

There are three full-compare units on each event manager. These compare units use GP timer1 as the time base and generate six outputs for compare and PWM-waveform generation using programmable deadband circuit. The state of each of the six outputs is configured independently. The compare registers of the compare units are double-buffered, allowing programmable change of the compare/PWM pulse widths as needed.

4.2.3 Programmable Deadband Generator

Peripherals

Deadband generation can be enabled/disabled for each compare unit output individually. The deadband-generator circuit produces two outputs (with or without deadband zone) for each compare unit output signal. The output states of the deadband generator are configurable and changeable as needed by way of the double-buffered ACTRx register.

4.2.4 PWM Waveform Generation

Up to eight PWM waveforms (outputs) can be generated simultaneously by each event manager: three independent pairs (six outputs) by the three full-compare units with programmable deadbands, and two independent PWMs by the GP-timer compares.

4.2.5 Double Update PWM Mode

The R281x Event Manager supports “Double Update PWM Mode.” This mode refers to a PWM operation mode in which the position of the leading edge and the position of the trailing edge of a PWM pulse are independently modifiable in each PWM period. To support this mode, the compare register that determines the position of the edges of a PWM pulse must allow (buffered) compare value update once at the beginning of a PWM period and another time in the middle of a PWM period. The compare registers in R281x Event Managers are all buffered and support three compare value reload/update (value in buffer becoming active) modes. These modes have earlier been documented as compare value reload conditions. The reload condition that supports double update PWM mode is reloaded on Underflow (beginning of PWM period) OR Period (middle of PWM period). Double update PWM mode can be achieved by using this condition for compare value reload.

4.2.6 PWM Characteristics

Characteristics of the PWMs are as follows:

• 16-bit registers

• Wide range of programmable deadband for the PWM output pairs

• Change of the PWM carrier frequency for PWM frequency wobbling as needed

June 2004 − Revised June 2006 SPRS257C

Peripherals

• Change of the PWM pulse widths within and after each PWM period as needed

• External-maskable power and drive-protection interrupts

• Pulse-pattern-generator circuit, for programmable generation of asymmetric, symmetric, and four-space

• Minimized CPU overhead using auto-reload of the compare and period registers

vector PWM waveforms

• The PWM pins are driven to a high-impedance state when the PDPINTx PDPINTx

signal qualification. The PDPINTx pin (after qualification) is reflected in bit 8 of the COMCONx

− PDPINTA

− PDPINTB

• EXTCON register bits provide options to individually trip control for each PWM pair of signals

4.2.7 Capture Unit

The capture unit provides a logging function for different events or transitions. The values of the selected GP timer counter is captured and stored in the two-level-deep FIFO stacks when selected transitions are detected on capture input pins, CAPx (x = 1, 2, or 3 for EVA; and x = 4, 5, or 6 for EVB). The capture unit consists of three capture circuits.

• Capture units include the following features:

− One 16-bit capture control register, CAPCONx (R/W)

− One 16-bit capture FIFO status register, CAPFIFOx

− Selection of GP timer 1/2 (for EVA) or 3/4 (for EVB) as the time base

− Three 16-bit 2-level-deep FIFO stacks, one for each capture unit

− Three capture input pins (CAP1/2/3 for EVA, CAP4/5/6 for EVB)—one input pin per capture unit. [All

inputs are synchronized with the device (CPU) clock. In order for a transition to be captured, the input must hold at its current level to meet the input qualification circuitry requirements. The input pins CAP1/2 and CAP4/5 can also be used as QEP inputs to the QEP circuit.]

pin is driven low and after

pin status is reflected in bit 8 of COMCONA register.

pin status is reflected in bit 8 of COMCONB register.

− User-specified transition (rising edge, falling edge, or both edges) detection

− Three maskable interrupt flags, one for each capture unit

− The capture pins can also be used as general-purpose interrupt pins, if they are not used for the

capture function.

4.2.8 Quadrature-Encoder Pulse (QEP) Circuit

Two capture inputs (CAP1 and CAP2 for EVA; CAP4 and CAP5 for EVB) can be used to interface the on-chip QEP circuit with a quadrature encoder pulse. Full synchronization of these inputs is performed on-chip. Direction or leading-quadrature pulse sequence is detected, and GP timer 2/4 is incremented or decremented by the rising and falling edges of the two input signals (four times the frequency of either input pulse).

With EXTCONA register bits, the EVA QEP circuit can use CAP3 as a capture index pin as well. Similarly, with EXTCONB register bits, the EVB QEP circuit can use CAP6 as a capture index pin.

4.2.9 External ADC Start-of-Conversion

EVA/EVB start-of-conversion (SOC) can be sent to an external pin (EVASOC/EVBSOC) for external ADC interface. EVASOC

and EVBSOC are MUXed with T2CTRIP and T4CTRIP, respectively.

June 2004 − Revised June 2006SPRS257C

4.3 Enhanced Analog-to-Digital Converter (ADC) Module

when input ≤ 0 V

A simplified functional block diagram of the ADC module is shown in Figure 4−4. The ADC module consists of a 12-bit ADC with a built-in sample-and-hold (S/H) circuit. Functions of the ADC module include:

• 12-bit ADC core with built-in S/H

• Analog input: 0.0 V to 3.0 V (Voltages above 3.0 V produce full-scale conversion results.)

• Fast conversion rate: 80 ns at 25-MHz ADC clock, 12.5 MSPS

• 16-channel, MUXed inputs

• Autosequencing capability provides up to 16 “autoconversions” in a single session. Each conversion can

be programmed to select any 1 of 16 input channels

• Sequencer can be operated as two independent 8-state sequencers or as one large 16-state sequencer (i.e., two cascaded 8-state sequencers)

• Sixteen result registers (individually addressable) to store conversion values

− The digital value of the input analog voltage is derived by:

igital Value + 0,

Input Analog Voltage * ADCLO

Digital Value + 4096

Digital Value + 4095 Digital Value + 4095,

Input Analog Voltage * ADCLO

Peripherals

, when 0 V < input < 3 V

when input ≥ 3 V

• Multiple triggers as sources for the start-of-conversion (SOC) sequence

− S/W − software immediate start

− EVA − Event manager A (multiple event sources within EVA)

− EVB − Event manager B (multiple event sources within EVB)

• Flexible interrupt control allows interrupt request on every end-of-sequence (EOS) or every other EOS

• Sequencer can operate in “start/stop” mode, allowing multiple “time-sequenced triggers” to synchronize

conversions

• EVA and EVB triggers can operate independently in dual-sequencer mode

• Sample-and-hold (S/H) acquisition time window has separate prescale control

The ADC module in R281x has been enhanced to provide flexible interface to event managers A and B. The ADC interface is built around a fast, 12-bit ADC module with a fast conversion rate of 80 ns at 25-MHz ADC clock. The ADC module has 16 channels, configurable as two independent 8-channel modules to service event managers A and B. The two independent 8-channel modules can be cascaded to form a 16-channel module. Although there are multiple input channels and two sequencers, there is only one converter in the ADC module. Figure 4−4 shows the block diagram of the R281x ADC module.

The two 8-channel modules have the capability to autosequence a series of conversions, each module has the choice of selecting any one of the respective eight channels available through an analog MUX. In the cascaded mode, the autosequencer functions as a single 16-channel sequencer. On each sequencer, once the conversion is complete, the selected channel value is stored in its respective RESULT register. Autosequencing allows the system to convert the same channel multiple times, allowing the user to perform oversampling algorithms. This gives increased resolution over traditional single-sampled conversion results.

June 2004 − Revised June 2006 SPRS257C

Peripherals

ADCINA0

ADCINA7

ADCINB0

ADCINB7

ADCSOC

S/W

EVA

Analog

MUX

S/H

Sequencer 1

System

Control Block

12-Bit

ADC

Module

ADC Control Registers

High-Speed

Prescaler

HSPCLKADCENCLK

Sequencer 2

SYSCLKOUT

Result Registers

Result Reg 0 Result Reg 1

Result Reg 7 Result Reg 8

Result Reg 15

C28x

70A8h

70AFh 70B0h

70B7h

SOCSOC

S/W EVB

Figure 4−4. Block Diagram of the R281x ADC Module

To obtain the specified accuracy of the ADC, proper board layout is very critical. T o the best extent possible, traces leading to the ADCIN pins should not run in close proximity to the digital signal paths. This is to minimize switching noise on the digital lines from getting coupled to the ADC inputs. Furthermore, proper isolation techniques must be used to isolate the ADC module power pins (V

DDA1/VDDA2

, A V

DDREFBG

) from the digital

supply. Figure 4−5 shows the ADC pin connections for R281x devices.

Notes:

1. The ADC registers are accessed at the SYSCLKOUT rate. The internal timing of the ADC module is controlled by the high-speed peripheral clock (HSPCLK).

2. The behavior of the ADC module based on the state of the ADCENCLK and HAL T signals is as follows: ADCENCLK: On reset, this signal will be low . While reset is active-low (XRS

) the clock to the register will still function. This is necessary to make sure all registers and modes go into their default reset state. The analog module will however be in a low-power inactive state. As soon as reset goes high, then the clock to the registers will be disabled. When the user sets the ADCENCLK signal high, then the clocks to the registers will be enabled and the analog module will be enabled. There will be a certain time delay (ms range) before the ADC is stable and can be used.

HALT: This signal only affects the analog module. It does not affect the registers. If low, the ADC module is powered. If high, the ADC module goes into low-power mode. The HAL T mode will stop the clock to the CPU, which will stop the HSPCLK. Therefore the ADC register logic will be turned off indirectly.

Figure 4−5 shows the ADC pin-biasing for internal reference and Figure 4−6 shows the ADC pin-biasing for external reference.

June 2004 − Revised June 2006SPRS257C

Peripherals

ADC 16-Channel Analog Inputs

Test Pin

ADC External Current Bias Resistor ADCRESEXT

ADC Reference Positive Output

ADC Analog Power

ADC Reference Power

ADC Analog I/O Power

ADC Digital Power

†

Provide access to this pin in PCB layouts. Intended for test purposes only.

‡

TAIYO YUDEN EMK325F106ZH, EMK325BJ106MD, or equivalent ceramic capacitor

24.9-kΩ resistor is applicable for the full range of the ADC.

NOTES: A. External decoupling capacitors are recommended on all power pins.

B. Analog inputs must be driven from an operational amplifier that does not degrade the ADC performance.

ADCINA[7:0] ADCINB[7:0]

ADCLO

ADCBGREFIN

ADCREFP

ADCREFMADC Reference Medium Output

DDA1

DDA2

SSA1

SSA2

AVDDREFBG

AVSSREFBG

DDAIO

SSAIO

DD1

SS1

Analog input 0−3 V with respect to ADCLO

†

Connect to Analog Ground

24.9 kW ‡

10 mF

‡

10 mF

Digital Ground

ADCREFP and ADCREFM should not be loaded by external circuitry

Analog 3.3 V Analog 3.3 V

Analog 3.3 V

Analog 3.3 V Analog Ground

1.8 V

can use the same 1.8 V (or 1.9 V) supply as the digital core but separate the two with a ferrite bead or a filter

Figure 4−5. ADC Pin Connections With Internal Reference (See Notes A and B)

NOTE:

The temperature rating of any recommended component must match the rating of the end product.

June 2004 − Revised June 2006 SPRS257C

Peripherals

ADC 16-Channel Analog Inputs

Test Pin

ADC External Current Bias Resistor ADCRESEXT

ADC Reference Positive Input

ADC Analog Power

ADC Reference Power

ADC Analog I/O Power

ADC Digital Power

NOTES: A. External decoupling capacitors are recommended on all power pins.

B. Analog inputs must be driven from an operational amplifier that does not degrade the ADC performance.

C. It is recommended that buffered external references be provided with a voltage difference of (ADCREFP−ADCREFM)

= 1 V $ 0.1% or better.

ADCINA[7:0] ADCINB[7:0]

ADCLO

ADCBGREFIN

ADCREFP

ADCREFMADC Reference Medium Input

DDA1

DDA2

SSA1

SSA2

AVDDREFBG

AVSSREFBG

DDAIO

SSAIO

DD1

SS1

Analog Input 0−3 V With Respect to ADCLO Connect to Analog Ground

24.9 kW

1 mF − 10 mF

Analog 3.3 V Analog 3.3 V

Analog 3.3 V

Analog 3.3 V Analog Ground

1.8 V Can use the same 1.8-V (or 1.9-V)

Digital Ground

(See

2 V

Note C)

1 V

1 mF −10 mF

supply as the digital core but separate the two with a ferrite bead or a filter

External reference is enabled using bit 8 in the ADCTRL3 Register at ADC power up. In this mode, the accuracy of external reference is critical for overall gain. The voltage ADCREFP−ADCREFM will determine the overall accuracy . Do not enable internal references when external references are connected to ADCREFP and ADCREFM. See the TMS320F28x DSP Analog-to-Digital Converter (ADC) Reference Guide (literature number SPRU060) for more information.

Figure 4−6. ADC Pin Connections With External Reference

June 2004 − Revised June 2006SPRS257C

The ADC operation is configured, controlled, and monitored by the registers listed in Table 4−4.

Peripherals

Table 4−4. ADC Registers

NAME ADDRESS

ADCTRL1 0x00 7100 1 ADC Control Register 1 ADCTRL2 0x00 7101 1 ADC Control Register 2

ADCMAXCONV 0x00 7102 1 ADC Maximum Conversion Channels Register ADCCHSELSEQ1 0x00 7103 1 ADC Channel Select Sequencing Control Register 1 ADCCHSELSEQ2 0x00 7104 1 ADC Channel Select Sequencing Control Register 2 ADCCHSELSEQ3 0x00 7105 1 ADC Channel Select Sequencing Control Register 3 ADCCHSELSEQ4 0x00 7106 1 ADC Channel Select Sequencing Control Register 4

ADCASEQSR 0x00 7107 1 ADC Auto-Sequence Status Register ADCRESULT0 0x00 7108 1 ADC Conversion Result Buffer Register 0 ADCRESULT1 0x00 7109 1 ADC Conversion Result Buffer Register 1 ADCRESULT2 0x00 710A 1 ADC Conversion Result Buffer Register 2 ADCRESULT3 0x00 710B 1 ADC Conversion Result Buffer Register 3 ADCRESULT4 0x00 710C 1 ADC Conversion Result Buffer Register 4 ADCRESULT5 0x00 710D 1 ADC Conversion Result Buffer Register 5 ADCRESULT6 0x00 710E 1 ADC Conversion Result Buffer Register 6 ADCRESULT7 0x00 710F 1 ADC Conversion Result Buffer Register 7 ADCRESULT8 0x00 7110 1 ADC Conversion Result Buffer Register 8 ADCRESULT9 0x00 7111 1 ADC Conversion Result Buffer Register 9

ADCRESULT10 0x00 7112 1 ADC Conversion Result Buffer Register 10 ADCRESULT11 0x00 7113 1 ADC Conversion Result Buffer Register 11 ADCRESULT12 0x00 7114 1 ADC Conversion Result Buffer Register 12 ADCRESULT13 0x00 7115 1 ADC Conversion Result Buffer Register 13 ADCRESULT14 0x00 7116 1 ADC Conversion Result Buffer Register 14 ADCRESULT15 0x00 7117 1 ADC Conversion Result Buffer Register 15

ADCTRL3 0x00 7118 1 ADC Control Register 3

ADCST 0x00 7119 1 ADC Status Register

reserved

†

The above registers are Peripheral Frame 2 Registers.

0x00 711C 0x00 711F

SIZE (x16)

†

DESCRIPTION

June 2004 − Revised June 2006 SPRS257C

Peripherals

4.4 Enhanced Controller Area Network (eCAN) Module

The CAN module has the following features:

• Fully compliant with CAN protocol, version 2.0B

• Supports data rates up to 1 Mbps

• Thirty-two mailboxes, each with the following properties:

− Configurable as receive or transmit

− Configurable with standard or extended identifier

− Has a programmable receive mask

− Supports data and remote frame

− Composed of 0 to 8 bytes of data

− Uses a 32-bit time stamp on receive and transmit message

− Protects against reception of new message

− Holds the dynamically programmable priority of transmit message

− Employs a programmable interrupt scheme with two interrupt levels

− Employs a programmable alarm on transmission or reception time-out

• Low-power mode

• Programmable wake-up on bus activity

• Automatic reply to a remote request message

• Automatic retransmission of a frame in case of loss of arbitration or error

• 32-bit local network time counter synchronized by a specific message (communication in conjunction with

mailbox 16)

• Self-test mode

− Operates in a loopback mode receiving its own message. A “dummy” acknowledge is provided, thereby eliminating the need for another node to provide the acknowledge bit.

NOTE: For a SYSCLKOUT of 150 MHz, the smallest bit rate possible is 23.4 kbps. The 28x CAN has passed the conformance test per ISO/DIS 16845. Contact TI for further details.

June 2004 − Revised June 2006SPRS257C

Peripherals

eCAN1INTeCAN0INT

Enhanced CAN Controller

Message Controller

Mailbox RAM

(512 Bytes)

32-Message Mailbox

of 4 × 32-Bit Words

eCAN Protocol Kernel

Controls

32 32

32 3232 3232 32

Address Data

Memory Management

Unit

CPU Interface,

Receive Control Unit,

Timer Management Unit

Receive Buffer

Transmit Buffer

Control Buffer

Status Buffer

eCAN Memory

(512 Bytes)

Registers and Message

Objects Control

SN65HVD23x

3.3-V CAN Transceiver

CAN Bus

Figure 4−7. eCAN Block Diagram and Interface Circuit

Table 4−5. 3.3-V eCAN Transceivers for the R281x DSPs

PART NUMBER SUPPLY

VOLTAGE

SN65HVD230 3.3 V Standby Adjustable Yes −− −40°C to 85°C

SN65HVD230Q 3.3 V Standby Adjustable Yes −− −40°C to 125°C

SN65HVD231 3.3 V Sleep Adjustable Yes −− −40°C to 85°C

SN65HVD231Q 3.3 V Sleep Adjustable Yes −− −40°C to 125°C

SN65HVD232 3.3 V None None None −− −40°C to 85°C

SN65HVD232Q 3.3 V None None None −− −40°C to 125°C

SN65HVD233 3.3 V Standby Adjustable None Diagnostic

LOW-POWER

MODE

SLOPE

CONTROL

VREF OTHER T

−40°C to 125°C

Loopback

June 2004 − Revised June 2006 SPRS257C

Peripherals

Table 4−5. 3.3-V eCAN Transceivers for the TMS320R281x DSPs (Continued)

PART NUMBER SUPPLY

SN65HVD234 3.3 V Standby & Sleep Adjustable None −− −40°C to 125°C SN65HVD235 3.3 V Standby Adjustable None Autobaud

6000h 603Fh 6040h 607Fh 6080h

60BFh

60C0h 60FFh

6100h−6107h 6108h−610Fh

6110h−6117h

6118h−611Fh

6120h−6127h

Message Object Time Stamps (MOTS)

VOLTAGE

eCAN Memory (512 Bytes)

Control and Status Registers

Local Acceptance Masks (LAM)

(32 × 32-Bit RAM)

Message Object Time-Out (MOTO)

(32 × 32-Bit RAM)

eCAN Memory RAM (512 Bytes)

Mailbox 0 Mailbox 1 Mailbox 2 Mailbox 3 Mailbox 4

LOW-POWER

MODE

SLOPE

CONTROL

VREF OTHER T

−40°C to 125°C

Loopback

eCAN Control and Status Registers

Mailbox Enable − CANME

Mailbox Direction − CANMD

Transmission Request Set − CANTRS

Transmission Request Reset − CANTRR

Transmission Acknowledge − CANTA

Abort Acknowledge − CANAA

Received Message Pending − CANRMP

Received Message Lost − CANRML

Remote Frame Pending − CANRFP

Global Acceptance Mask − CANGAM

Master Control − CANMC

Bit-Timing Configuration − CANBTC

Error and Status − CANES

Transmit Error Counter − CANTEC

Receive Error Counter − CANREC Global Interrupt Flag 0 − CANGIF0

Global Interrupt Mask − CANGIM Global Interrupt Flag 1 − CANGIF1 Mailbox Interrupt Mask − CANMIM

Mailbox Interrupt Level − CANMIL

Overwrite Protection Control − CANOPC

TX I/O Control − CANTIOC

RX I/O Control − CANRIOC

Time Stamp Counter − CANTSC

Time-Out Control − CANTOC

Time-Out Status − CANTOS

61E0h−61E7h 61E8h−61EFh

61F0h−61F7h 61F8h−61FFh

Mailbox 28 Mailbox 29 Mailbox 30 Mailbox 31

61E8h−61E9h 61EAh−61EBh 61ECh−61EDh

61EEh−61EFh

Figure 4−8. eCAN Memory Map

Reserved

Message Mailbox (16 Bytes)

Message Identifier − MSGID

Message Control − MSGCTRL

Message Data Low − MDL

Message Data High − MDH

June 2004 − Revised June 2006SPRS257C

Peripherals

The CAN registers listed in Table 4−6 are used by the CPU to configure and control the CAN controller and the message objects. eCAN control registers only support 32-bit read/write operations. Mailbox RAM can be accessed as 16 bits or 32 bits. 32-bit accesses are aligned to an even boundary.

CANME 0x00 6000 1 Mailbox enable

CANMD 0x00 6002 1 Mailbox direction CANTRS 0x00 6004 1 Transmit request set CANTRR 0x00 6006 1 Transmit request reset

CANTA 0x00 6008 1 Transmission acknowledge

CANAA 0x00 600A 1 Abort acknowledge

CANRMP 0x00 600C 1 Receive message pending

CANRML 0x00 600E 1 Receive message lost CANRFP 0x00 6010 1 Remote frame pending

CANGAM 0x00 6012 1 Global acceptance mask

CANMC 0x00 6014 1 Master control CANBTC 0x00 6016 1 Bit-timing configuration

CANES 0x00 6018 1 Error and status CANTEC 0x00 601A 1 Transmit error counter CANREC 0x00 601C 1 Receive error counter

CANGIF0 0x00 601E 1 Global interrupt flag 0

CANGIM 0x00 6020 1 Global interrupt mask

CANGIF1 0x00 6022 1 Global interrupt flag 1

CANMIM 0x00 6024 1 Mailbox interrupt mask

CANMIL 0x00 6026 1 Mailbox interrupt level

CANOPC 0x00 6028 1 Overwrite protection control

CANTIOC 0x00 602A 1 TX I/O control CANRIOC 0x00 602C 1 RX I/O control

CANTSC 0x00 602E 1 Time stamp counter (Reserved in SCC mode) CANTOC 0x00 6030 1 Time-out control (Reserved in SCC mode) CANTOS 0x00 6032 1 Time-out status (Reserved in SCC mode)

†

These registers are mapped to Peripheral Frame 1.

Table 4−6. CAN Registers Map

SIZE

(x32)

†

DESCRIPTION

June 2004 − Revised June 2006 SPRS257C

Peripherals

4.5 Multichannel Buffered Serial Port (McBSP) Module

The McBSP module has the following features:

• Compatible to McBSP in TMS320C54x /TMS320C55x DSP devices, except the DMA features

• Full-duplex communication

• Double-buffered data registers which allow a continuous data stream

• Independent framing and clocking for receive and transmit

• External shift clock generation or an internal programmable frequency shift clock

• A wide selection of data sizes including 8-, 12-, 16-, 20-, 24-, or 32-bits

• 8-bit data transfers with LSB or MSB first

• Programmable polarity for both frame synchronization and data clocks

• HIghly programmable internal clock and frame generation

• Support A-bis mode

• Direct interface to industry-standard CODECs, Analog Interface Chips (AICs), and other serially

connected A/D and D/A devices

• Works with SPI-compatible devices

• Two 16 x 16-level FIFO for Transmit channel

• Two 16 x 16-level FIFO for Receive channel

The following application interfaces can be supported on the McBSP:

• T1/E1 framers

• MVIP switching-compatible and ST-BUS-compliant devices including:

− MVIP framers

− H.100 framers

− SCSA framers

− IOM-2 compliant devices

− AC97-compliant devices (the necessary multiphase frame synchronization capability is provided.)

− IIS-compliant devices

• McBSP clock rate = CLKG =

CLKSRG

(1 ) CLKGDIV)

, where CLKSRG source could be LSPCLK, CLKX, or CLKR.

Serial port performance is limited by I/O buffer switching speed. Internal prescalers must be adjusted such that the peripheral speed is less than the I/O buffer speed limit—20-MHz maximum.

Figure 4−9 shows the block diagram of the McBSP module with FIFO, interfaced to the R281x version of Peripheral Frame 2.

TMS320C54x and TMS320C55x are trademarks of Texas Instruments.

June 2004 − Revised June 2006SPRS257C

Peripheral Write Bus

Peripherals

MXINT

To CPU

LSPCLK

MRINT

To CPU

TX Interrupt Logic

McBSP Transmit

Interrupt Select Logic

McBSP Registers

and Control Logic

McBSP

McBSP Receive

Interrupt Select Logic

RX Interrupt Logic

TX FIFO

Interrupt

RX FIFO

Interrupt

TX FIFO _15

— TX FIFO _1 TX FIFO _0

TX FIFO Registers

DXR2 Transmit Buffer

XSR2

RSR2

DRR2 Receive Buffer

RX FIFO _15

— RX FIFO _1 RX FIFO _0

RX FIFO Registers

TX FIFO _15

— TX FIFO _1 TX FIFO _0

DXR1 Transmit Buffer

Compand Logic

XSR1

RSR1

Expand Logic

RBR1 RegisterRBR2 Register

DRR1 Receive Buffer

RX FIFO _15

— RX FIFO _1 RX FIFO _0

FSX

CLKX

CLKR

FSR

Peripheral Read Bus

Figure 4−9. McBSP Module With FIFO

June 2004 − Revised June 2006 SPRS257C

Peripherals

Table 4−7 provides a summary of the McBSP registers.

Table 4−7. McBSP Register Summary

NAME

− − − 0x0000 McBSP Receive Buffer Register

− − − 0x0000 McBSP Receive Shift Register

− − − 0x0000 McBSP Transmit Shift Register

DRR2 00 R 0x0000

DRR1 01 R 0x0000

DXR2 02 W 0x0000

DXR1 03 W 0x0000

SPCR2 04 R/W 0x0000 McBSP Serial Port Control Register 2 SPCR1 05 R/W 0x0000 McBSP Serial Port Control Register 1

RCR2 06 R/W 0x0000 McBSP Receive Control Register 2 RCR1 07 R/W 0x0000 McBSP Receive Control Register 1 XCR2 08 R/W 0x0000 McBSP Transmit Control Register 2

XCR1 09 R/W 0x0000 McBSP Transmit Control Register 1 SRGR2 0A R/W 0x0000 McBSP Sample Rate Generator Register 2 SRGR1 0B R/W 0x0000 McBSP Sample Rate Generator Register 1

MCR2 0C R/W 0x0000 McBSP Multichannel Register 2

MCR1 0D R/W 0x0000 McBSP Multichannel Register 1 RCERA 0E R/W 0x0000 McBSP Receive Channel Enable Register Partition A RCERB 0F R/W 0x0000 McBSP Receive Channel Enable Register Partition B XCERA 10 R/W 0x0000 McBSP Transmit Channel Enable Register Partition A XCERB 11 R/W 0x0000 McBSP Transmit Channel Enable Register Partition B

PCR 12 R/W 0x0000 McBSP Pin Control Register RCERC 13 R/W 0x0000 McBSP Receive Channel Enable Register Partition C RCERD 14 R/W 0x0000 McBSP Receive Channel Enable Register Partition D XCERC 15 R/W 0x0000 McBSP Transmit Channel Enable Register Partition C XCERD 16 R/W 0x0000 McBSP Transmit Channel Enable Register Partition D

†

DRR2/DRR1 and DXR2/DXR1 share the same addresses of receive and transmit FIFO registers in FIFO mode.

‡

FIFO pointers advancing is based on order of access to DRR2/DRR1 and DXR2/DXR1 registers.

ADDRESS

0x00 78xxh

TYPE (R/W)

DATA REGISTERS, RECEIVE, TRANSMIT

McBSP CONTROL REGISTERS

MULTICHANNEL CONTROL REGISTERS

RESET VALUE

(HEX)

McBSP Data Receive Register 2

− Read First if the word size is greater than 16 bits, else ignore DRR2

McBSP Data Receive Register 1

− Read Second if the word size is greater than 16 bits, else read DRR1 only

McBSP Data Transmit Register 2

− Write First if the word size is greater than 16 bits, else ignore DXR2

McBSP Data Transmit Register 1

− Write Second if the word size is greater than 16 bits, else write to DXR1 only

DESCRIPTION

†

June 2004 − Revised June 2006SPRS257C

Table 4−7. McBSP Register Summary (Continued)

Peripherals

NAME

RCERE 17 R/W 0x0000 McBSP Receive Channel Enable Register Partition E RCERF 18 R/W 0x0000 McBSP Receive Channel Enable Register Partition F XCERE 19 R/W 0x0000 McBSP Transmit Channel Enable Register Partition E

XCERF 1A R/W 0x0000 McBSP Transmit Channel Enable Register Partition F

RCERG 1B R/W 0x0000 McBSP Receive Channel Enable Register Partition G

RCERH 1C R/W 0x0000 McBSP Receive Channel Enable Register Partition H XCERG 1D R/W 0x0000 McBSP Transmit Channel Enable Register Partition G XCERH 1E R/W 0x0000 McBSP Transmit Channel Enable Register Partition H

DRR2 00 R 0x0000

DRR1 01 R 0x0000

DXR2 02 W 0x0000

DXR1 03 W 0x0000

MFFTX 20 R/W 0xA000 McBSP Transmit FIFO Register

MFFRX 21 R/W 0x201F McBSP Receive FIFO Register

MFFCT 22 R/W 0x0000 McBSP FIFO Control Register

MFFINT 23 R/W 0x0000 McBSP FIFO Interrupt Register

MFFST 24 R/W 0x0000 McBSP FIFO Status Register

†

DRR2/DRR1 and DXR2/DXR1 share the same addresses of receive and transmit FIFO registers in FIFO mode.

‡

FIFO pointers advancing is based on order of access to DRR2/DRR1 and DXR2/DXR1 registers.

ADDRESS

0x00 78xxh

TYPE (R/W)

MULTICHANNEL CONTROL REGISTERS (CONTINUED)

FIFO MODE REGISTERS (applicable only in FIFO mode)

RESET VALUE

(HEX)

FIFO Data Registers

FIFO Control Registers

‡

McBSP Data Receive Register 2 − Top of receive FIFO

− Read First FIFO pointers will not advance McBSP Data Receive Register 1 − Top of receive FIFO

− Read Second for FIFO pointers to advance McBSP Data Transmit Register 2 − Top of transmit FIFO

− Write First FIFO pointers will not advance McBSP Data Transmit Register 1 − Top of transmit FIFO

− Write Second for FIFO pointers to advance

DESCRIPTION

4.6 Serial Communications Interface (SCI) Module

R281x devices include two serial communications interface (SCI) modules. The SCI modules support digital communications between the CPU and other asynchronous peripherals that use the standard non-return-to-zero (NRZ) format. The SCI receiver and transmitter are double-buffered, and each has its own separate enable and interrupt bits. Both can be operated independently or simultaneously in the full-duplex mode. To ensure data integrity, the SCI checks received data for break detection, parity, overrun, and framing errors. The bit rate is programmable to over 65000 different speeds through a 16-bit baud-select register.

Features of each SCI module include:

• Two external pins:

− SCITXD: SCI transmit-output pin

− SCIRXD: SCI receive-input pin NOTE: Both pins can be used as GPIO if not used for SCI.

June 2004 − Revised June 2006 SPRS257C

Peripherals

• Baud rate programmable to 64K different rates

− Baud rate =

LSPCLK (BRR ) 1) * 8 LSPCLK

, when BRR ≠ 0

, when BRR = 0

Serial port performance is limited by I/O buffer switching speed. Internal prescalers must be adjusted such that the peripheral speed is less than the I/O buffer speed limit—20 MHz maximum.

• Data-word format

− One start bit

− Data-word length programmable from one to eight bits

− Optional even/odd/no parity bit

− One or two stop bits

• Four error-detection flags: parity, overrun, framing, and break detection

• Two wake-up multiprocessor modes: idle-line and address bit

• Half- or full-duplex operation

• Double-buffered receive and transmit functions

• Transmitter and receiver operations can be accomplished through interrupt-driven or polled algorithms

with status flags.

− Transmitter: TXRDY flag (transmitter-buffer register is ready to receive another character) and TX EMPTY flag (transmitter-shift register is empty)

− Receiver: RXRDY flag (receiver-buffer register is ready to receive another character), BRKDT flag (break condition occurred), and RX ERROR flag (monitoring four interrupt conditions)

• Separate enable bits for transmitter and receiver interrupts (except BRKDT)

• Max bit rate +

150 MHz

2 8

+ 9.375 106bńs

• NRZ (non-return-to-zero) format

• Ten SCI module control registers located in the control register frame beginning at address 7050h

All registers in this module are 8-bit registers that are connected to Peripheral Frame 2. When a register is accessed, the register data is in the lower byte (7−0), and the upper byte (15−8) is read as zeros. Writing to the upper byte has no effect.

Enhanced features:

• Auto baud-detect hardware logic

• 16-level transmit/receive FIFO

June 2004 − Revised June 2006SPRS257C

Figure 4−10 shows the SCI module block diagram.

Frame Format and Mode

Parity

Even/Odd Enable

SCICCR.6 SCICCR.5

SCIHBAUD. 15 − 8

LSPCLK

SCILBAUD. 7 − 0

SCIRXST.7

RX Error

TXWAKE

SCICTL1.3

WUT

Baud Rate

MSbyte

Baud Rate

LSbyte

SCIRXST. 4 − 2

RX Error

PEFE OE

TXSHF

Transmitter−Data

Buffer Register

TX FIFO _0 TX FIFO _1

−−−−−

TX FIFO _15

SCITXBUF.7−0

TX FIFO registers

SCIFFENA

SCIFFTX.14

RXSHF Register

RXENA

Receive Data Buffer register SCIRXBUF.7−0

RX FIFO _15

−−−−−

RX FIFO_1

RX FIFO _0

SCIRXBUF.7−0

RX FIFO registers

RXFFOVF

SCIFFRX.15

RX ERR INT ENA

SCICTL1.6

SCICTL1.0

SCICTL1.1

TXENA

TX FIFO Interrupts

RX FIFO Interrupts

SCITXD

TX EMPTY

SCICTL2.6

TXRDY

SCICTL2.7

TX INT ENA

SCICTL2.0

TX Interrupt

Logic

SCI TX Interrupt select logic

AutoBaud Detect logic

SCIRXD

RXWAKE

SCIRXST.1

SCICTL2.1

RXRDY

RX/BK INT ENA

SCIRXST.6

BRKDT

SCIRXST.5

RX Interrupt

Logic

SCI RX Interrupt select logic

Peripherals

SCITXD

TXINT

To CPU

SCIRXD

RXINT

To CPU

Figure 4−10. Serial Communications Interface (SCI) Module Block Diagram

June 2004 − Revised June 2006 SPRS257C

Peripherals

The SCI port operation is configured and controlled by the registers listed in Table 4−8 and Table 4−9.

Table 4−8. SCI-A Registers

NAME ADDRESS SIZE (x16) DESCRIPTION

SCICCRA 0x00 7050 1 SCI-A Communications Control Register

SCICTL1A 0x00 7051 1 SCI-A Control Register 1 SCIHBAUDA 0x00 7052 1 SCI-A Baud Register, High Bits SCILBAUDA 0x00 7053 1 SCI-A Baud Register, Low Bits

SCICTL2A 0x00 7054 1 SCI-A Control Register 2

SCIRXSTA 0x00 7055 1 SCI-A Receive Status Register

SCIRXEMUA 0x00 7056 1 SCI-A Receive Emulation Data Buffer Register

SCIRXBUFA 0x00 7057 1 SCI-A Receive Data Buffer Register

SCITXBUFA 0x00 7059 1 SCI-A Transmit Data Buffer Register

SCIFFTXA 0x00 705A 1 SCI-A FIFO Transmit Register

SCIFFRXA 0x00 705B 1 SCI-A FIFO Receive Register

SCIFFCTA 0x00 705C 1 SCI-A FIFO Control Register

SCIPRIA 0x00 705F 1 SCI-A Priority Control Register

†

Shaded registers are new registers for the FIFO mode.

Table 4−9. SCI-B Registers

NAME ADDRESS SIZE (x16) DESCRIPTION

SCICCRB 0x00 7750 1 SCI-B Communications Control Register

SCICTL1B 0x00 7751 1 SCI-B Control Register 1 SCIHBAUDB 0x00 7752 1 SCI-B Baud Register, High Bits SCILBAUDB 0x00 7753 1 SCI-B Baud Register, Low Bits

SCICTL2B 0x00 7754 1 SCI-B Control Register 2

SCIRXSTB 0x00 7755 1 SCI-B Receive Status Register

SCIRXEMUB 0x00 7756 1 SCI-B Receive Emulation Data Buffer Register

SCIRXBUFB 0x00 7757 1 SCI-B Receive Data Buffer Register

SCITXBUFB 0x00 7759 1 SCI-B Transmit Data Buffer Register

SCIFFTXB 0x00 775A 1 SCI-B FIFO Transmit Register

SCIFFRXB 0x00 775B 1 SCI-B FIFO Receive Register SCIFFCTB 0x00 775C 1 SCI-B FIFO Control Register

SCIPRIB 0x00 775F 1 SCI-B Priority Control Register

†

†‡

†

Shaded registers are new registers for the FIFO mode.

‡

Registers in this table are mapped to peripheral bus 16 space. This space only allows 16-bit accesses. 32-bit accesses produce undefined results.

4.7 Serial Peripheral Interface (SPI) Module

R281x devices include the four-pin serial peripheral interface (SPI) module. The SPI is a high-speed, synchronous serial I/O port that allows a serial bit stream of programmed length (one to sixteen bits) to be shifted into and out of the device at a programmable bit-transfer rate. Normally, the SPI is used for communications between the DSP controller and external peripherals or another processor. Typical applications include external I/O or peripheral expansion through devices such as shift registers, display drivers, and ADCs. Multidevice communications are supported by the master/slave operation of the SPI.

June 2004 − Revised June 2006SPRS257C

The SPI module features include:

• Four external pins:

− SPISOMI: SPI slave-output/master-input pin

− SPISIMO: SPI slave-input/master-output pin

Peripherals

− SPISTE

: SPI slave transmit-enable pin

− SPICLK: SPI serial-clock pin

NOTE: All four pins can be used as GPIO, if the SPI module is not used.

• Two operational modes: master and slave

• Baud rate: 125 different programmable rates

− Baud rate =

LSPCLK (SPIBRR ) 1) LSPCLK

, when BRR ≠ 0

, when BRR = 0, 1, 2, 3

Serial port performance is limited by I/O buffer switching speed. Internal prescalers must be adjusted such that the peripheral speed is less than the I/O buffer speed limit—20 MHz maximum.

• Data word length: one to sixteen data bits

• Four clocking schemes (controlled by clock polarity and clock phase bits) include:

− Falling edge without phase delay: SPICLK active-high. SPI transmits data on the falling edge of the SPICLK signal and receives data on the rising edge of the SPICLK signal.

− Falling edge with phase delay: SPICLK active-high. SPI transmits data one half-cycle ahead of the falling edge of the SPICLK signal and receives data on the falling edge of the SPICLK signal.

− Rising edge without phase delay: SPICLK inactive-low. SPI transmits data on the rising edge of the SPICLK signal and receives data on the falling edge of the SPICLK signal.

− Rising edge with phase delay: SPICLK inactive-low. SPI transmits data one half-cycle ahead of the falling edge of the SPICLK signal and receives data on the rising edge of the SPICLK signal.

• Simultaneous receive and transmit operation (transmit function can be disabled in software)

• Transmitter and receiver operations are accomplished through either interrupt-driven or polled

algorithms.

• Nine SPI module control registers: Located in control register frame beginning at address 7040h. All registers in this module are 16-bit registers that are connected to Peripheral Frame 2. When a register

is accessed, the register data is in the lower byte (7−0), and the upper byte (15−8) is read as zeros. Writing to the upper byte has no effect.

Enhanced feature:

• 16-level transmit/receive FIFO

• Delayed transmit control

June 2004 − Revised June 2006 SPRS257C

Peripherals

The SPI port operation is configured and controlled by the registers listed in Table 4−10.

Table 4−10. SPI Registers

NAME ADDRESS SIZE (x16) DESCRIPTION

SPICCR 0x00 7040 1 SPI Configuration Control Register

SPICTL 0x00 7041 1 SPI Operation Control Register SPISTS 0x00 7042 1 SPI Status Register

SPIBRR 0x00 7044 1 SPI Baud Rate Register

SPIRXEMU 0x00 7046 1 SPI Receive Emulation Buffer Register

SPIRXBUF 0x00 7047 1 SPI Serial Input Buffer Register SPITXBUF 0x00 7048 1 SPI Serial Output Buffer Register

SPIDAT 0x00 7049 1 SPI Serial Data Register SPIFFTX 0x00 704A 1 SPI FIFO Transmit Register SPIFFRX 0x00 704B 1 SPI FIFO Receive Register SPIFFCT 0x00 704C 1 SPI FIFO Control Register

SPIPRI 0x00 704F 1 SPI Priority Control Register

NOTE: The registers in this table are mapped to Peripheral Frame 2. This space only allows 16-bit accesses. 32-bit accesses produce undefined

results.

June 2004 − Revised June 2006SPRS257C

Figure 4−11 is a block diagram of the SPI in slave mode.

Peripherals

SPIFFTX.14

RX FIFO registers

SPIRXBUF

RX FIFO _0 RX FIFO _1

−−−−−

RX FIFO _15

SPIRXBUF

Buffer Register

Data Register

SPIDAT.15 − 0

SPI Char

LSPCLK

SPIFFENA

TX FIFO registers

SPITXBUF

TX FIFO _15

−−−−−

TX FIFO _1 TX FIFO _0

SPITXBUF

Buffer Register

SPIDAT

Talk

SPICTL.1

State Control

SPICCR.3 − 0

SPI Bit Rate

SPIBRR.6 − 0

4561230

RX FIFO Interrupt

TX FIFO Interrupt

0123

Receiver

Overrun Flag

SPISTS.7

SPIFFOVF FLAG

SPIFFRX.15

SPI INT FLAG

SPISTS.6

SW1

SW2

Overrun INT ENA

SPICTL.4

RX Interrupt

Logic

TX Interrupt

Logic

SPI INT

ENA

SPICTL.0

Master/Slave

SPICTL.2

SW3

Clock

Polarity

SPICCR.6 SPICTL.3

SPIINT/SPIRXINT

To CPU

SPITXINT

Clock

Phase

SPISIMO

SPISOMI

SPISTE

SPICLK

†

SPISTE

is driven low by the master for a slave device.

Figure 4−11. Serial Peripheral Interface Module Block Diagram (Slave Mode)

June 2004 − Revised June 2006 SPRS257C

Peripherals

4.8 GPIO MUX

The GPIO MUX registers, are used to select the operation of shared pins on R281x devices. The pins can be individually selected to operate as “Digital I/O” or connected to “Peripheral I/O” signals (via the GPxMUX registers). If selected for “Digital I/O” mode, registers are provided to configure the pin direction (via the GPxDIR registers) and to qualify the input signal to remove unwanted noise (via the GPxQUAL) registers). Table 4−11 lists the GPIO MUX Registers.

Table 4−11. GPIO MUX Registers

NAME ADDRESS SIZE (x16) REGISTER DESCRIPTION

GPAMUX 0x00 70C0 1 GPIO A MUX Control Register

GPADIR 0x00 70C1 1 GPIO A Direction Control Register

GPAQUAL 0x00 70C2 1 GPIO A Input Qualification Control Register

reserved 0x00 70C3 1

GPBMUX 0x00 70C4 1 GPIO B MUX Control Register

GPBDIR 0x00 70C5 1 GPIO B Direction Control Register

GPBQUAL 0x00 70C6 1 GPIO B Input Qualification Control Register

reserved 0x00 70C7 1 reserved 0x00 70C8 1 reserved 0x00 70C9 1 reserved 0x00 70CA 1 reserved 0x00 70CB 1

GPDMUX 0x00 70CC 1 GPIO D MUX Control Register

GPDDIR 0x00 70CD 1 GPIO D Direction Control Register

GPDQUAL 0x00 70CE 1 GPIO D Input Qualification Control Register

reserved 0x00 70CF 1

GPEMUX 0x00 70D0 1 GPIO E MUX Control Register

GPEDIR 0x00 70D1 1 GPIO E Direction Control Register

GPEQUAL 0x00 70D2 1 GPIO E Input Qualification Control Register

reserved 0x00 70D3 1

GPFMUX 0x00 70D4 1 GPIO F MUX Control Register

GPFDIR 0x00 70D5 1 GPIO F Direction Control Register reserved 0x00 70D6 1 reserved 0x00 70D7 1

GPGMUX 0x00 70D8 1 GPIO G MUX Control Register

GPGDIR 0x00 70D9 1 GPIO G Direction Control Register reserved 0x00 70DA 1 reserved 0x00 70DB 1

reserved

†

Reserved locations will return undefined values and writes will be ignored.

‡

Not all inputs will support input signal qualification.

These registers are EALLOW protected. This prevents spurious writes from overwriting the contents and corrupting the system.

0x00 70DC 0x00 70DF

†‡§

June 2004 − Revised June 2006SPRS257C

Peripherals

If configured for digital I/O mode, additional registers are provided for setting individual I/O signals (via the GPxSET registers), for clearing individual I/O signals (via the GPxCLEAR registers), for toggling individual I/O signals (via the GPxTOGGLE registers), or for reading/writing to the individual I/O signals (via the GPxDAT registers). Table 4−12 lists the GPIO Data Registers. For more information, see the TMS320F28x System Control and Interrupts Reference Guide (literature number SPRU078).

Table 4−12. GPIO Data Registers

NAME ADDRESS SIZE (x16) REGISTER DESCRIPTION

GPADAT 0x00 70E0 1 GPIO A Data Register GPASET 0x00 70E1 1 GPIO A Set Register

GPACLEAR 0x00 70E2 1 GPIO A Clear Register

GPATOGGLE 0x00 70E3 1 GPIO A Toggle Register

GPBDAT 0x00 70E4 1 GPIO B Data Register GPBSET 0x00 70E5 1 GPIO B Set Register

GPBCLEAR 0x00 70E6 1 GPIO B Clear Register

GPBTOGGLE 0x00 70E7 1 GPIO B Toggle Register

reserved 0x00 70E8 1 reserved 0x00 70E9 1 reserved 0x00 70EA 1

reserved 0x00 70EB 1 GPDDAT 0x00 70EC 1 GPIO D Data Register GPDSET 0x00 70ED 1 GPIO D Set Register

GPDCLEAR 0x00 70EE 1 GPIO D Clear Register

GPDTOGGLE 0x00 70EF 1 GPIO D Toggle Register

GPEDAT 0x00 70F0 1 GPIO E Data Register GPESET 0x00 70F1 1 GPIO E Set Register

GPECLEAR 0x00 70F2 1 GPIO E Clear Register

GPETOGGLE 0x00 70F3 1 GPIO E Toggle Register

GPFDAT 0x00 70F4 1 GPIO F Data Register GPFSET 0x00 70F5 1 GPIO F Set Register

GPFCLEAR 0x00 70F6 1 GPIO F Clear Register

GPFTOGGLE 0x00 70F7 1 GPIO F Toggle Register

GPGDAT 0x00 70F8 1 GPIO G Data Register GPGSET 0x00 70F9 1 GPIO G Set Register

GPGCLEAR 0x00 70FA 1 GPIO G Clear Register

GPGTOGGLE 0x00 70FB 1 GPIO G Toggle Register

reserved

†

Reserved locations will return undefined values and writes will be ignored.

‡

These registers are NOT EALLOW protected. The above registers will typically be accessed regularly by the user.

0x00 70FC

0x00 70FF

†‡

June 2004 − Revised June 2006 SPRS257C

Peripherals

Figure 4−12 shows how the various register bits select the various modes of operation for GPIO function.

GPxQUAL

GPxDAT/SET/CLEAR/TOGGLE

MUX

Input Qualification

Digital I/O

GPxMUX

High-Impedance Enable (1)

GPxDIR

MUX

Peripheral I/O

High-

Impedance

Control

SYSCLKOUT

XRS

Internal (Pullup or Pulldown)

NOTES: A. In the GPIO mode, when the GPIO pin is configured for output operation, reading the GPxDAT data register only gives the value

written, not the value at the pin. In the peripheral mode, the state of the pin can be read through the GPxDAT register, provided the corresponding direction bit is zero (input mode).

B. Some selected input signals are qualified by the SYSCLKOUT. The GPxQUAL register specifies the qualification sampling period.

The sampling window is 6 samples wide and the output is only changed when all samples are the same (all 0’s or all 1’s). This feature removes unwanted spikes from the input signal.

Figure 4−12. GPIO/Peripheral Pin MUXing

NOTE:

The input function of the GPIO pin and the input path to the peripheral are always enabled. It is the output function of the GPIO pin that is multiplexed with the output path of the primary (peripheral) function. Since the output buffer of a pin connects back to the input buffer, any GPIO signal present at the pin will be propagated to the peripheral module as well. Therefore, when a pin is configured for GPIO operation, the corresponding peripheral functionality (and interrupt-generating capability) must be disabled. Otherwise, interrupts may be inadvertently triggered. This is especially critical when the PDPINT A pins, since a value of zero for GPDDAT.0 or GPDDAT.5 (PDPINTx high-impedance state. The CxTRIP

and TxCTRIP pins will also put the corresponding PWM

and PDPINTB pins are used as GPIO

) will put PWM pins in a

pins in high impedance, if they are driven low (as GPIO pins) and bit EXTCONx.0 = 1.

June 2004 − Revised June 2006SPRS257C

5 Development Support

Texas Instruments (TI) offers an extensive line of development tools for the C28x generation of DSPs, including tools to evaluate the performance of the processors, generate code, develop algorithm implementations, and fully integrate and debug software and hardware modules.

The following products support development of R281x-based applications:

Software Development Tools

• Code Composer Studio Integrated Development Environment (IDE)

− C/C++ Compiler

− Code generation tools

− Assembler/Linker

− Cycle Accurate Simulator

• Application algorithms

• Sample applications code

Hardware Development Tools

• R2812 eZdsp

Development Support

• JTAG-based emulators − SPI515, XDS510PP, XDS510PP Plus, XDS510 USB

• Universal 5-V dc power supply

• Documentation and cables

5.1 Device and Development Support Tool Nomenclature

To designate the stages in the product development cycle, TI assigns prefixes to the part numbers of all [TMS320] DSP devices and support tools. Each [TMS320] DSP commercial family member has one of three prefixes: TMX, TMP, or TMS (e.g., TMS320R2812GHH). Texas Instruments recommends two of three possible prefix designators for its support tools: TMDX and TMDS. These prefixes represent evolutionary stages of product development from engineering prototypes (TMX/TMDX) through fully qualified production devices/tools (TMS/TMDS).

TMX Experimental device that is not necessarily representative of the final device’ s electrical specifications TMP Final silicon die that conforms to the device’s electrical specifications but has not completed quality

and reliability verification

TMS Fully qualified production device

Support tool development evolutionary flow: TMDX Development-support product that has not yet completed Texas Instruments internal qualification

testing.

TMDS Fully qualified development-support product TMX and TMP devices and TMDX development−support tools are shipped against the following disclaimer:

“Developmental product is intended for internal evaluation purposes.“ TMS devices and TMDS development-support tools have been characterized fully, and the quality and

reliability of the device have been demonstrated fully. TI’s standard warranty applies.

TMS320 is a trademark of Texas Instruments.

June 2004 − Revised June 2006 SPRS257C

Development Support

Predictions show that prototype devices (TMX or TMP) have a greater failure rate than the standard production devices. Texas Instruments recommends that these devices not be used in any production system because their expected end-use failure rate still is undefined. Only qualified production devices are to be used.

TI device nomenclature also includes a suffix with the device family name. This suffix indicates the package type (for example, PBK) and temperature range (for example, A). Figure 5−1 provides a legend for reading the complete device name for any TMS320x28x family member.

PREFIX

TMX = experimental device TMP = prototype device TMS = qualified device

DEVICE FAMILY

320 = TMS320

TECHNOLOGY

F = Flash EEPROM (1.8-V/1.9-V Core/3.3-V I/O) C = ROM (1.8-V/1.9-V Core/3.3-V I/O) R = RAM only (1.8-V/1.9-V Core/3.3-V I/O)

†

BGA = Ball Grid Array LQFP = Low-Profile Quad Flatpack

‡

LQFP package not yet available lead (Pb)-free. For estimated conversion dates, go to www.ti.com/leadfree

Figure 5−1. TMS320x28x Device Nomenclature

5.2 Documentation Support

Extensive documentation supports all of the TMS320 DSP family generations of devices from product announcement through applications development. The types of documentation available include: data sheets and data manuals, with design specifications; and hardware and software applications. Useful reference documentation includes:

TMS 320 R 2812 PBK

DSP Family

TEMPERATURE RANGE

A = −40°C to 85°C S = −40°C to 125°C Q = −40°C to 125°C − Q100

PACKAGE TYPE

GHH = 179-ball MicroStar BGA ZHH = 179-ball MicroStar BGA (lead-free) PGF = 176-pin LQFP PBK = 128-pin LQFP

DEVICE

2811 2812

fault grading

†‡

TMS320C28x DSP CPU and Instruction Set Reference Guide (literature number SPRU430) describes the central processing unit (CPU) and the assembly language instructions of the TMS320C28x fixed-point digital signal processors (DSPs). It also describes emulation features available on these DSPs.

TMS320x281x Analog-to-Digital Converter (ADC) Reference Guide (literature number SPRU060) describes the ADC module. The module is a 12-bit pipelined ADC. The analog circuits of this converter, referred to as the core in this document, include the front-end analog multiplexers (MUXs), sample-and-hold (S/H) circuits, the conversion core, voltage regulators, and other analog supporting circuits. Digital circuits, referred to as the wrapper in this document, include programmable conversion sequencer, result registers, interface to analog circuits, interface to device peripheral bus, and interface to other on-chip modules.

TMS320x281x Boot ROM Reference Guide (literature number SPRU095) describes the purpose and features of the bootloader (factory-programmed boot-loading software). It also describes other contents of the device on-chip boot ROM and identifies where all of the information is located within that memory.

TMS320x281x Event Manager (EV) Reference Guide (literature number SPRU065) describes the EV modules that provide a broad range of functions and features that are particularly useful in motion control and motor control applications. The EV modules include general-purpose (GP) timers, full-compare/PWM units, capture units, and quadrature-encoder pulse (QEP) circuits.

June 2004 − Revised June 2006SPRS257C

Development Support

TMS320x281x External Interface (XINTF) Reference Guide (literature number SPRU067) describes the external interface (XINTF) of the 281x digital signal processors (DSPs).

TMS320x281x Multi-channel Buffered Serial Ports (McBSPs) Reference Guide (literature number SPRU061) describes the McBSP) available on the 281x devices. The McBSPs allow direct interface between a DSP and other devices in a system.

TMS320x281x System Control and Interrupts Reference Guide (literature number SPRU078) describes the various interrupts and system control features of the 281x digital signal processors (DSPs).

TMS320x281x, 280x Enhanced Controller Area Network (eCAN) Reference Guide (literature number SPRU074) describes the eCAN that uses established protocol to communicate serially with other controllers in electrically noisy environments. With 32 fully configurable mailboxes and time-stamping feature, the eCAN module provides a versatile and robust serial communication interface. The eCAN module implemented in the C28x DSP is compatible with the CAN 2.0B standard (active).

TMS320x281x, 280x Peripheral Reference Guide (literature number SPRU566) describes the peripheral reference guides of the 28x digital signal processors (DSPs).

TMS320x281x, 280x Serial Communication Interface (SCI) Reference Guide (literature number SPRU051) describes the SCI that is a two-wire asynchronous serial port, commonly known as a UART. The SCI modules support digital communications between the CPU and other asynchronous peripherals that use the standard non-return-to-zero (NRZ) format.

TMS320x281x, 280x Serial Peripheral Interface (SPI) Reference Guide (literature number SPRU059) describes the SPI − a high-speed synchronous serial input/output (I/O) port that allows a serial bit stream of programmed length (one to sixteen bits) to be shifted into and out of the device at a programmed bit-transfer rate. The SPI is used for communications between the DSP controller and external peripherals or another controller.

3.3 V DSP for Digital Motor Control Application Report (literature number SPRA550). New generations of motor control digital signal processors (DSPs) lower their supply voltages from 5 V to 3.3 V to offer higher performance at lower cost. Replacing traditional 5-V digital control circuitry by 3.3-V designs introduce no additional system cost and no significant complication in interfacing with TTL and CMOS compatible components, as well as with mixed voltage ICs such as power transistor gate drivers. Just like 5-V based designs, good engineering practice should be exercised to minimize noise and EMI effects by proper component layout and PCB design when 3.3-V DSP, ADC, and digital circuitry are used in a mixed signal environment, with high and low voltage analog and switching signals, such as a motor control system. In addition, software techniques such as Random PWM method can be used by special features of the Texas Instruments (TI) TMS320x24xx DSP controllers to significantly reduce noise effects caused by EMI radiation.

This application report reviews designs of 3.3-V DSP versus 5-V DSP for low HP motor control applications. The application report first describes a scenario of a 3.3-V-only motor controller indicating that for most applications, no significant issue of interfacing between 3.3 V and 5 V exists. Cost-effective 3.3-V − 5-V interfacing techniques are then discussed for the situations where such interfacing is needed. On-chip 3.3-V ADC versus 5-V ADC is also discussed. Sensitivity and noise effects in 3.3-V and 5-V ADC conversions are addressed. Guidelines for component layout and printed circuit board (PCB) design that can reduce system’s noise and EMI effects are summarized in the last section.

The TMS320C28x Instruction Set Simulator Technical Overview (literature number SPRU608) describes the simulator, available within the Code Composer Studio for TMS320C2000 IDE, that simulates the instruction set of the C28x core.

TMS320C28x DSP/BIOS Application Programming Interface (API) Reference Guide (literature number SPRU625) describes development using DSP/BIOS.

June 2004 − Revised June 2006 SPRS257C

Development Support

TMS320C28x Assembly Language Tools User’s Guide (literature number SPRU513) describes the assembly language tools (assembler and other tools used to develop assembly language code), assembler directives, macros, common object file format, and symbolic debugging directives for the TMS320C28x device.

TMS320C28x Optimizing C Compiler User’s Guide (literature number SPRU514) describes the TMS320C28x C/C++ compiler. This compiler accepts ANSI standard C/C++ source code and produces TMS320 DSP assembly language source code for the TMS320C28x device.

Programming Examples for the TMS320F281x eCAN (literature number SPRA876) contains several programming examples to illustrate how the eCAN module is set up for different modes of operation. The objective is to help you come up to speed quickly in programming the eCAN. All programs have been extensively commented to aid easy understanding. The CANalyzer tool from Vector CANtech, Inc. was used to monitor and control the bus operation. All projects and CANalyzer configuration files are included in the attached SPRA876.zip file.

TMS320F2810, TMS320F2811, TMS320F2812 ADC Calibration (literature number SPRA989) describes a method for improving the absolute accuracy of the 12-bit analog-to-digital converter (ADC) found on the F2810/F2811/F2812 devices. Due to inherent gain and offset errors, the absolute accuracy of the ADC is impacted. The methods described in this application note can improve the absolute accuracy of the ADC to achieve levels better than 0.5%. This application note is accompanied by an example program (ADCcalibration.zip) that executes from RAM on the F2812 EzDSP.

A series of DSP textbooks is published by Prentice-Hall and John Wiley & Sons to support digital signal processing research and education. The TMS320 DSP newsletter, Details on Signal Processing, is published quarterly and distributed to update TMS320 DSP customers on product information.

Updated information on the TMS320 DSP controllers can be found on the worldwide web at: http://www.ti.com.

To send comments regarding this data manual, use the comments@books.sc.ti.com email address, which is a repository for feedback. For questions and support, contact the Product Information Center listed at the http://www.ti.com/sc/docs/pic/home.htm site.

June 2004 − Revised June 2006SPRS257C

6 Electrical Specifications

This section provides the absolute maximum ratings and the recommended operating conditions for the TMS320R281x DSPs.

6.1 Absolute Maximum Ratings

Unless otherwise noted, the list of absolute maximum ratings are specified over operating temperature ranges. Stresses beyond those listed under Absolute Maximum Ratings may cause permanent damage to the device. These are stress ratings only, and functional operation of the device at these or any other conditions beyond those indicated under Section 6.2 is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability. All voltage values are with respect to V

Electrical Specifications

Supply voltage range, V Supply voltage range, V

DDIO

, V

DD1

DDA1

, V

DDA2

, V

DDAIO

, and AV

DDREFBG

− 0.3 V to 4.6 V. . . . . . . . . . . . .

− 0.5 V to 2.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Input voltage range, VIN − 0.3 V to 4.6 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Output voltage range, V Input clamp current, I Output clamp current, I Operating ambient temperature ranges, T

− 0.3 V to 4.6 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

(VIN < 0 or VIN > V

(VO < 0 or VO > V

)† ± 20 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DDIO

) ± 20 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DDIO

: A version (GHH, ZHH, PGF, PBK)‡ − 40°C to 85°C. . . . . . . . .

: S/Q version (GHH, ZHH, PGF, PBK)‡ − 40°C to 125°C. . . . .

TA: Q version (PGF, PBK)‡ − 40°C to 125°C. . . . . . . . . . . . . . . . . .

†

Storage temperature range, T

Continuous clamp current per pin is± 2 mA

‡

Long-term high-temperature storage and/or extended use at maximum temperature conditions may result in a reduction of overall device life. For additional information, see IC Package Thermal Metrics Application Report (literature number SPRA953) and Reliability Data for TMS320LF24x and TMS320F281x Devices Application Report (literature number SPRA963).

Replaced by Q temperature option from silicon revision E onwards

− 65°C to 150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

stg

June 2004 − Revised June 2006 SPRS257C

Electrical Specifications

Device clock frequency

DDIO

High-level output source current,

High-level output source current, Low-level output sink current,

Low-level output sink current, Ambient

Ambient

High-level output voltage

current

µA

current

µA

Input V

= 3.3 V,

current

)

DDIO

= 3.3 V,

µA

6.2 Recommended Operating Conditions†

DDIO

VDD, V

DD1

, V

DDA1

DDREFBG

SYSCLKOUT

†

See Section 6.7 for power sequencing of V

‡

Group 2 pins are as follows: XINTF pins, T1CTRIP_PDPINTA

DDA2

, V

DDAIO

Device supply voltage, I/O 3.14 3.3 3.47 V

Device supply voltage, CPU Supply ground 0 V ADC supply voltage 3.14 3.3 3.47 V

(system clock)

High-level input voltage

Low-level input voltage

VOH = 2.4 V

VOL = VOL MAX

A version − 40 85 °C

temperature

Q version − 40 125 °C

DDIO

, V

DDAIO

, VDD, V

MIN NOM MAX UNIT

1.8 V (135 MHz) 1.71 1.8 1.89

1.9 V (150 MHz)

VDD = 1.9 V ± 5% 2 150 VDD = 1.8 V ± 5% All inputs except X1/XCLKIN 2 V X1/XCLKIN (@ 50 µA max) All inputs except X1/XCLKIN 0.8 X1/XCLKIN (@ 50 µA max) All I/Os except Group 2 − 4

‡

Group 2 All I/Os except Group 2 4

‡

Group 2

DDA1, VDDA2, and

, TDO, XCLKOUT, XF, EMU0, and EMU1.

DDREFBG

1.81 1.9 2

2 135

0.7V

0.3V

MHz

− 8

6.3 Electrical Characteristics Over Recommended Operating Conditions (Unless Otherwise Noted)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

IOH = IOHMAX 2.4

The following pins have no internal PU/PD: GPIOE0, GPIOE1, GPIOF0, GPIOF1, GPIOF2, GPIOF3, GPIOF12, GPIOG4, and GPIOG5.

The following pins have an internal pulldown: XMP/MC

Low-level output voltage IOL = IOLMAX 0.4 V Input

(low level) Input

current (high level

Output current, high-impedance state (off-state)

Input capacitance 2 pF Output capacitance 3 pF

With pullup With pulldown

With pullup V

With pulldown

IOH = 50 µA V

= 3.3 V,

DDIO

VIN = 0 V V

= 3.3 V, VIN = 0 V ±2

DDIO

= 3.3 V, VIN = V

DDIO

VIN = V

VO = V

or 0 V ±2 µA

DDIO

, TESTSEL, and TRST.

− 0.2

DDIO

−80 −140 −190

28 50 80

±2

µA

June 2004 − Revised June 2006SPRS257C

Electrical Specifications

MODE

TEST CONDITIONS

6.4 Current Consumption by Power-Supply Pins Over Recommended Operating Conditions During Low-Power Modes at 150-MHz SYSCLKOUT (TMS320R281x)

All peripheral clocks are enabled. All PWM pins are toggled at 100 kHz.

Operational

IDLE

STANDBY

HALT

†

includes current into V

DDA

‡

MAX numbers are at 125°C, and max voltage (VDD = 2.0 V; V

Data is continuously transmitted out of the SCIA, SCIB, and CAN ports. The hardware multiplier is exercised. Code is running out of internal SARAM.

− XCLKOUT is turned off

− All peripheral clocks are on, except ADC

− Peripheral clocks are turned off

− Pins without an internal PU/PD are tied high/low

− Peripheral clocks are turned off

− Pins without an internal PU/PD are tied high/low

− Input clock is disabled DDA1

, V

DDA2

, V

DD1

, AV

DDREFBG

HALT and STANDBY modes cannot be used when the PLL is disabled.

6.5 Current Consumption Graphs

250

, and V

DDIO

NOTE:

, V

DDAIO

DDA

TYP MAX

210 mA 260 mA 20 mA 30mA 40 mA 50 mA

140 mA 155 mA 20 mA 30 mA 5 µA 10 µA

5 mA 10 mA 5 µA 20 µA 5 µA 10 µA

70 µA 5 µA 10 µA 1 µA

pins.

= 3.6 V).

‡

DDIO

TYP MAX

‡

TYP MAX

DDA

†

‡

200

150

100

Current (mA)

0 20 40 60 80 100 120 140 160

SYSCLKOUT (MHz)

IDD

NOTES: A. Test conditions are as defined in Table 6−4 for operational currents.

B. IDD represents the total current drawn from the 1.8-V rail (VDD). It includes a small amount of current (<1 mA) drawn

by V C. IDDA represents the current drawn by VDDA1 and VDDA2 rails. D. Total 3.3-V current is the sum of I

DD1

DDIO

IDDIO

and I

IDDA T otal 3.3−V current

. It includes a trivial amount of current (<1 mA) drawn by VDDAIO.

DDA

Figure 6−1. Typical Current Consumption Over Frequency

June 2004 − Revised June 2006 SPRS257C

Electrical Specifications

600

500

400

300

Power (mW)

200

100

0 20 40 60 80 100 120 140 160

SYSCLKOUT (MHz)

Total Power

Figure 6−2. Typical Power Consumption Over Frequency

6.6 Reducing Current Consumption

28x DSPs incorporate a unique method to reduce the device current consumption. A reduction in current consumption can be achieved by turning off the clock to any peripheral module which is not used in a given application. Table 6−1 indicates the typical reduction in current consumption achieved by turning off the clocks to various peripherals.

Table 6−1. Typical Current Consumption by Various Peripherals (at 150 MHz)

PERIPHERAL MODULE IDD CURRENT REDUCTION (mA)

eCAN

EVA 6 EVB

ADC 8

SCI

SPI 5

McBSP 13

†

All peripheral clocks are disabled upon reset. Writing to/reading from peripheral registers is possible only after the peripheral clocks are turned on.

‡

This number represents the current drawn by the digital portion of the ADC module. Turning off the clock to the ADC module results in the elimination of the current drawn by the analog portion of the ADC (I

DDA

) as well.

‡

†

6.7 Power Sequencing Requirements

Power sequencing is not required on the R281x devices. In other words, 3.3-V and 1.8-V (or 1.9-V) can ramp together. R281x can also be used on boards that have F281x power sequencing implemented; however, if the 1.8-V (or 1.9-V) rail lags the 3.3-V rail, the GPIO pins are undefined until the 1.8-V rail reaches at least 1 V.

June 2004 − Revised June 2006SPRS257C

6.8 Signal Transition Levels

Some of the signals use different reference voltages, see the recommended operating conditions table. Output levels are driven to a minimum logic-high level of 2.4 V and to a maximum logic-low level of 0.4 V.

Figure 6−3 shows output levels.

Output transition times are specified as follows:

• For a high-to-low transition, the level at which the output is said to be no longer high is below 80% of the total voltage range and lower and the level at which the output is said to be low is 20% of the total voltage range and lower.

• For a low-to-high transition, the level at which the output is said to be no longer low is 20% of the total voltage range and higher and the level at which the output is said to be high is 80% of the total voltage range and higher.

Figure 6−4 shows the input levels.

Figure 6−3. Output Levels

2.4 V (VOH) 80%

20%

0.4 V (VOL)

2.0 V (VIH) 90%

Electrical Specifications

10%

0.8 V (VIL)

Figure 6−4. Input Levels

Input transition times are specified as follows:

• For a high-to-low transition on an input signal, the level at which the input is said to be no longer high is 90% of the total voltage range and lower and the level at which the input is said to be low is 10% of the total voltage range and lower.

• For a low-to-high transition on an input signal, the level at which the input is said to be no longer low is 10% of the total voltage range and higher and the level at which the input is said to be high is 90% of the total voltage range and higher.

NOTE: See the individual timing diagrams for levels used for testing timing parameters.

June 2004 − Revised June 2006 SPRS257C

Electrical Specifications

6.9 Timing Parameter Symbology

Timing parameter symbols used are created in accordance with JEDEC Standard 100. To shorten the symbols, some of the pin names and other related terminology have been abbreviated as follows:

Lowercase subscripts and their meanings: Letters and symbols and their meanings: a access time H High c cycle time (period) L Low d delay time V Valid f fall time X Unknown, changing, or don’t care level h hold time Z High impedance r rise time su setup time t transition time v valid time w pulse duration (width)

6.10 General Notes on Timing Parameters

All output signals from the 28x devices (including XCLKOUT) are derived from an internal clock such that all output transitions for a given half-cycle occur with a minimum of skewing relative to each other.

The signal combinations shown in the following timing diagrams may not necessarily represent actual cycles. For actual cycle examples, see the appropriate cycle description section of this document.

6.11 Test Load Circuit

This test load circuit is used to measure all switching characteristics provided in this document.

Tester Pin Electronics

42 Ω 3.5 nH

4.0 pF 1.85 pF

NOTE: The data sheet provides timing at the device pin. For output timing analysis, the tester pin electronics and its transmission line effects

must be taken into account. A transmission line with a delay of 2 ns or longer can be used to produce the desired transmission line effect. The transmission line is intended as a load only. It is not necessary to add or subtract the transmission line delay (2 ns or longer) from the data sheet timing.

Input requirements in this data sheet are tested with an input slew rate of < 4 Volts per nanosecond (4 V/ns) at the device pin.

Transmission Line

Z0 = 50 Ω (see note)

Figure 6−5. 3.3-V Test Load Circuit

Data Sheet Timing Reference Point

Output Under Test

Device Pin (see note)

June 2004 − Revised June 2006SPRS257C

Electrical Specifications

On-chip oscillator clock

XCLKIN

SYSCLKOUT

XCLKOUT

HSPCLK

LSPCLK

ADC clock

SPI clock

McBSP

XTIMCLK

6.12 Device Clock Table

This section provides the timing requirements and switching characteristics for the various clock options available on R281x DSPs. Table 6−2 lists the cycle times of various clocks.

Table 6−2. TMS320R281x Clock Table and Nomenclature

MIN NOM MAX UNIT

t Frequency 20 35 MHz t Frequency 4 150 MHz t Frequency 2 150 MHz t Frequency 0.5 150 MHz t Frequency 75 t Frequency 37.5 t Frequency 25 MHz t Frequency 20 MHz t Frequency 20 MHz t Frequency 150 MHz

†

The maximum value for ADCCLK frequency is 25 MHz. For SYSCLKOUT values of 25 MHz or lower, ADCCLK has to be SYSCLKOUT/2 or lower. ADCCLK = SYSCLKOUT is not a valid mode for any value of SYSCLKOUT.

‡

This is the default reset value if SYSCLKOUT = 150 MHz.

, Cycle time 28.6 50 ns

c(OSC)

, Cycle time 6.67 250 ns

c(CI)

, Cycle time 6.67 500 ns

c(SCO)

, Cycle time 6.67 2000 ns

c(XCO)

, Cycle time 6.67 13.3

c(HCO)

, Cycle time 13.3 26.6

c(LCO)

c(ADCCLK)

c(SPC)

c(CKG)

c(XTIM)

, Cycle time

, Cycle time 50 ns

, Cycle time 6.67 ns

†

40 ns

‡ ‡ ‡ ‡

150 MHz

75 MHz

6.13 Clock Requirements and Characteristics

6.13.1 Input Clock Requirements

June 2004 − Revised June 2006 SPRS257C

The clock provided at the XCLKIN pin generates the internal CPU clock cycle.

Table 6−3. Input Clock Frequency

PARAMETER MIN TYP MAX UNIT

Resonator 20 35

Input clock frequency

Limp mode clock frequency

Crystal 20 35

XCLKIN

Without PLL 4 150 With PLL 5 100

MHz

2 MHz

Electrical Specifications

C10

Rise time, XCLKIN

C10

Rise time, XCLKIN

C11

Pulse duration, X1/XCLKIN low as a percentage of t

C12

)

Pulse duration, X1/XCLKIN high as a percentage of t

Table 6−4. XCLKIN Timing Requirements − PLL Bypassed or Enabled

NO. MIN MAX UNIT

C8 t

C9 t

C11 t C12 t

c(CI)

f(CI)

r(CI)

w(CIL) w(CIH)

Cycle time, XCLKIN 6.67 250 ns

Fall time, XCLKIN

Pulse duration, X1/XCLKIN low as a percentage of t Pulse duration, X1/XCLKIN high as a percentage of t

c(CI)

Up to 30 MHz 6 30 MHz to 150 MHz Up to 30 MHz 6

30 MHz to 150 MHz 2

40 60 % 40 60 %

Table 6−5. XCLKIN Timing Requirements − PLL Disabled

NO. MIN MAX UNIT

C8 t

C9 t

c(CI)

f(CI)

r(CI)

w(CIL)

w(CIH

Cycle time, XCLKIN 6.67 250 ns

Fall time, XCLKIN

c(CI)

Up to 30 MHz 6 30 MHz to 150 MHz Up to 30 MHz 6 30 MHz to 150 MHz 2 XCLKIN ≤ 120 MHz 40 60 120 < XCLKIN ≤ 150 MHz

XCLKIN ≤ 120 MHz 40 60 120 < XCLKIN ≤ 150 MHz 45 55

45 55

Table 6−6. Possible PLL Configuration Modes

PLL MODE REMARKS SYSCLKOUT

Invoked by tying XPLLDIS pin low upon reset. PLL block is completely

PLL Disabled

PLL Bypassed

PLL Enabled

disabled. Clock input to the CPU (CLKIN) is directly derived from the clock signal present at the X1/XCLKIN pin.

Achieved by writing a non-zero value “n” into PLLCR register. The /2 module in the PLL block now divides the output of the PLL by two before feeding it to the CPU.

XCLKIN

XCLKIN/2

(XCLKIN * n) / 2

June 2004 − Revised June 2006SPRS257C

Electrical Specifications

Pulse duration, XRS low

cycles

6.13.2 Output Clock Characteristics

Table 6−7. XCLKOUT Switching Characteristics (PLL Bypassed or Enabled)

No. PARAMETER MIN TYP MAX UNIT

C1 t

c(XCO)

C3 t

f(XCO)

C4 t

r(XCO)

C5 t

w(XCOL)

C6 t

w(XCOH)

C7 t

†

A load of 40 pF is assumed for these parameters.

‡

H = 0.5t

c(XCO)

The PLL must be used for maximum frequency operation.

Cycle time, XCLKOUT 6.67 Fall time, XCLKOUT 2 ns Rise time, XCLKOUT 2 ns Pulse duration, XCLKOUT low H−2 H+2 ns Pulse duration, XCLKOUT high H−2 H+2 ns

PLL lock time 131072t

†‡

c(CI)

C10

XCLKIN

(see Note A)

XCLKOUT

(see Note B)

NOTES: A. The relationship of XCLKIN to XCLKOUT depends on the divide factor chosen. The waveform relationship shown in Figure 6−6 is

intended to illustrate the timing parameters only and may differ based on configuration.

B. XCLKOUT configured to reflect SYSCLKOUT.

Figure 6−6. Clock Timing

6.14 Reset Timing

Table 6−8. Reset (XRS) Timing Requirements

w(RSL1)

w(RSL2)

w(WDRS)

d(EX)

‡

OSCST

su(XPLLDIS)

h(XPLLDIS)

h(XMP/MC)

h(boot-mode)

†

If external oscillator/clock source are used, reset time has to be low at least for 1 ms after VDD reaches 1.5 V.

‡

Dependent on crystal/resonator and board design.

Pulse duration, stable XCLKIN to XRS high

Warm reset 8t

WD-initiated reset 512t Pulse duration, reset pulse generated by watchdog 512t Delay time, address/data valid after XRS high

Oscillator start-up time Setup time for XPLLDIS pin Hold time for XPLLDIS pin Hold time for XMP/MC pin Hold time for boot-mode pins

†

MIN NOM MAX UNIT

c(CI) c(CI)

32t

c(CI)

1 10 ms

16t

c(CI)

16t

c(CI)

16t

c(CI)

2520t

cycles

cycles cycles

cycles cycles cycles cycles

June 2004 − Revised June 2006 SPRS257C

Electrical Specifications

, V

†

DDIO

(1.8 V (or 1.9 V))

DDAn

(3.3 V)

DDAIO

(See Note A)

VDD, V

XCLKIN

DD1

2.5 V

0.3 V

XCLKOUT

XRS

Address/Data/

Control

XF/XPLLDIS

XMP/MC

Boot-Mode Pins

See Note D

I/O Pins

XCLKIN/8 (See Note B)

OSCST

Address/Data Valid. Internal Boot-ROM Code Execution Phase

XPLLDIS

(Don’t Care)

GPIO Pins as Input

Boot-ROM Execution Starts

GPIO Pins as Input (State Depends on Internal PU/PD)

w(RSL1)

su(XPLLDIS)

Sampling

h(XMP/MC)

h(boot-mode) see Note C)

(

d(EX)

User-Code Dependent

User-Code Execution Phase

User-Code Dependent

h(XPLLDIS)

GPIOF14

(Don’t Care)

User-Code Dependent

Peripheral/GPIO Function Based on Boot Code

NOTES: A. V

− V

DDAn

B. Upon power up, SYSCLKOUT is XCLKIN/2 if the PLL is enabled. Since both the XTIMCLK and CLKMODE bits in the

XINTCNF2 register come up with a reset state of 1, SYSCLKOUT is further divided by 4 before it appears at XCLKOUT. This explains why XCLKOUT = XCLKIN/8 during this phase.

C. After reset, the Boot ROM code executes instructions for 1260 SYSCLKOUT cycles (SYSCLKOUT = XCLKIN/2) and then

samples BOOT Mode pins. Based on the status of the Boot Mode pin, the boot code branches to destination memory or boot code function in ROM. The BOOT Mode pins should be held high/low for at least 2520 XCLKIN cycles from boot ROM execution time for proper selection of Boot modes. If Boot ROM code executes after power-on conditions (in debugger environment), the Boot code execution time is based on the current SYSCLKOUT speed. The SYSCLKOUT will be based on user environment and could be with or without PLL enabled.

D. The state of the GPIO pins is undefined (i.e., they could be input or output) until the 1.8-V (or 1.9-V) supply reaches at least

1 V and 3.3-V supply reaches 2.5 V.

DDA1/VDDA2

and AV

DDREFBG

User-Code Dependent

Figure 6−7. Power-on Reset in Microcomputer Mode (XMP/MC = 0)

June 2004 − Revised June 2006SPRS257C

DDIO

DDAIO

VDD, V

Address/Data/

, V

DDAn

(3.3 V)

(1.8 V (or

DD1

1.9 V))

XCLKIN

XCLKOUT

XRS

Control

XF/XPLLDIS

XMP/MC

Electrical Specifications

2.5 V

0.3 V

OSCST

(Don’t Care)

XPLLDIS

(Don’t Care)

XCLKIN/8 (See Note A)

w(RSL)

d(EX)

Sampling

su(XPLLDIS)

h(XMP/MC)

User-Code Dependent

Address/Data/Control Valid Execution

Begins From External Boot Address 0x3FFFC0

h(XPLLDIS)

GPIOF14/XF (User-Code Dependent)

(Don’t Care)

I/O Pins

See Note B

NOTES: A. Upon power up, SYSCLKOUT is XCLKIN/2 if the PLL is enabled. Since both the XTIMCLK and CLKMODE bits in the XINTCNF2

register come up with a reset state of 1, SYSCLKOUT is further divided by 4 before it appears at XCLKOUT. This explains why XCLKOUT = XCLKIN/8 during this phase.

B. The state of the GPIO pins is undefined (i.e., they could be input or output) until the 1.8-V (or 1.9-V) supply reaches at least 1 V

and 3.3-V supply reaches 2.5 V..

Input Configuration (State Depends on Internal PU/PD)

User-Code Dependent

Figure 6−8. Power-on Reset in Microprocessor Mode (XMP/MC = 1)

June 2004 − Revised June 2006 SPRS257C

Electrical Specifications

XCLKIN

XCLKOUT

(XCLKIN * 5)

XRS

Address/Data/

Control

XF/XPLLDIS

XMP/MC

Boot-Mode Pins

I/O Pins

†

After reset, the Boot ROM code executes instructions for 1260 SYSCLKOUT cycles (SYSCLKOUT = XCLKIN/2) and then samples BOOT Mode pins. Based on the status of the Boot Mode pin, the boot code branches to destination memory or boot code function in ROM. The BOOT Mode pins should be held high/low for at least 2520 XCLKIN cycles from boot ROM execution time for proper selection of Boot modes. If Boot ROM code executes after power-on conditions (in debugger environment), the Boot code execution time is based on the current SYSCLKOUT speed. The SYSCLKOUT will be based on user environment and could be with or without PLL enabled.

User-Code Execution

GPIOF14/XF

(Don’t Care)

Boot-ROM Execution Starts

Peripheral/GPIO Function

User-Code Dependent

w(RSL2)

d(EX)

(Don’t Care)

su(XPLLDIS)

(Don’t Care)

XPLLDIS

Sampling

h(XMP/MC)

GPIO Pins as Input

GPIO Pins as Input (State Depends on Internal PU/PD)

XCLKIN/8

User-Code Dependent

User-Code Execution Phase

h(XPLLDIS)

GPIOF14

User-Code Dependent

(Don’t Care)

h(boot-mode)

Peripheral/GPIO Function

User-Code Execution Starts

User-Code Dependent

†

Figure 6−9. Warm Reset in Microcomputer Mode

June 2004 − Revised June 2006SPRS257C

X1/XCLKIN

SYSCLKOUT

Electrical Specifications

Write to PLLCR

XCLKIN*2

(Current CPU

Frequency)

Figure 6−10. Effect of Writing Into PLLCR Register

XCLKIN/2

(CPU Frequency While PLL is Stabilizing

With the Desired Frequency. This Period

(PLL Lock-up Time, tp) is

131072 XCLKIN Cycles Long.)

XCLKIN*4

(Changed CPU Frequency)

June 2004 − Revised June 2006 SPRS257C

Electrical Specifications

Pulse duration, external wake-up

)

Pulse duration, external

)

Pulse duration, external

d(WAKE-STBY)

6.15 Low-Power Mode Wakeup Timing

Table 6−9. IDLE Mode Timing Requirements

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

w(WAKE-INT)

†

Input Qualification Time (IQT) = [t

signal

 2  QUALPRD]  5 + [t

c(SCO)

Without input qualifier 2*t With input qualifier 1*t

 2  QUALPRD].

c(SCO)

c(SCO) + IQT

†

Table 6−10. IDLE Mode Switching Characteristics

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

Delay time, external wake signal to

d(WAKE-IDLE

†

Input Qualification Time (IQT) = [t

‡

This is the time taken to begin execution of the instruction that immediately follows the IDLE instruction. Execution of an ISR (triggered by the wake-up) signal involves additional latency.

A0−A15

program execution resume

− Wake-up from SARAM Without input qualifier 8 * t

− Wake-up from SARAM With input qualifier 8 * t c(SCO)

‡

 2  QUALPRD]  5 + [t

 2  QUALPRD].

c(SCO)

d(WAKE−IDLE)

c(SCO) + IQT†Cycles

c(SCO)

Cycles Cycles

Cycles

XCLKOUT

WAKE INT

†

XCLKOUT = SYSCLKOUT

‡

WAKE INT can be any enabled interrupt, WDINT

†

w(WAKE−INT)

‡

, XNMI, or XRS.

Figure 6−11. IDLE Entry and Exit Timing

Table 6−11. STANDBY Mode Timing Requirements

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

w(WAKE-INT

†

QUALSTDBY is a 6-bit field in the LPMCR0 register.

wake-up signal

Without input qualifier 12 * t With input qualifier (2 + QUALSTDBY)† * t

c(CI) c(CI)

Cycles Cycles

Table 6−12. STANDBY Mode Switching Characteristics

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

d(IDLE-XCOH)

†

QUALSTDBY is a 6-bit field in the LPMCR0 register.

‡

This is the time taken to begin execution of the instruction that immediately follows the IDLE instruction. Execution of an ISR (triggered by the wake-up) signal involves additional latency.

Delay time, IDLE instruction executed to XCLKOUT high

Delay time, external wake signal to program execution

‡

resume

− Wake-up from SARAM Without input qualifier 12 * t

− Wake-up from SARAM With input qualifier 12 * t

32 *

c(SCO)

45 *t

c(SCO)

c(CI)

+ t

w(WAKE-INT)

c(CI)

Cycles

Cycles Cycles

100

June 2004 − Revised June 2006SPRS257C

TEXAS INSTRUMENTS TMS320R2811, TMS320R2812 Technical data

Specifications and Main Features

Frequently Asked Questions

User Manual
