Texas instruments TMS320DM6467T Data Manual

TMS320DM6467T
www.ti.com
SPRS605B–JULY 2009–REVISED JULY 2010
TMS320DM6467T
Digital Media System-on-Chip
Check for Samples: TMS320DM6467T

1 Digital Media System-on-Chip (DMSoC)

1.1 Features

• High-Performance Digital Media SoC – 1-GHz C64x+™ Clock Rate – 500-MHz ARM926EJ-S™ Clock Rate – Eight 32-Bit C64x+ Instructions/Cycle – 8000 C64x+ MIPS – Fully Software-Compatible With C64x /
ARM9™
– Industrial Temperature Devices Available
• Advanced Very-Long-Instruction-Word (VLIW) TMS320C64x+™ DSP Core
– Eight Highly Independent Functional Units
Six ALUs (32-/40-Bit), Each Supports Single 32-Bit, Dual 16-Bit, or Quad 8-Bit Arithmetic per Clock Cycle
Two Multipliers Support Four 16 x 16-Bit Multiplies (32-Bit Results) per Clock • Embedded Trace Buffer™ (ETB11™) With 4KB Cycle or Eight 8 x 8-Bit Multiplies (16-Bit Memory for ARM9 Debug Results) per Clock Cycle
– Load-Store Architecture With Non-Aligned
Support – 64 32-Bit General-Purpose Registers – Instruction Packing Reduces Code Size Transcode Operations – All Instructions Conditional H.264, MPEG2, VC1, MPEG4 SP/ASP – Additional C64x+™ Enhancements • 150-MHz Video Port Interface (VPIF)
Protected Mode Operation – Two 8-Bit SD (BT.656), Single 16-Bit HD
Exceptions Support for Error Detection and Program Redirection
Hardware Support for Modulo Loop Operation
• C64x+ Instruction Set Features – Byte-Addressable (8-/16-/32-/64-Bit Data) – 8-Bit Overflow Protection – Bit-Field Extract, Set, Clear – Normalization, Saturation, Bit-Counting – Compact 16-Bit Instructions – Additional Instructions to Support Complex
Multiplies
• C64x+ L1/L2 Memory Architecture – 32K-Byte L1P Program RAM/Cache (Direct
Mapped)
– 32K-Byte L1D Data RAM/Cache (2-Way
Set-Associative)
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
PRODUCTION DATA information is current as of publication date. Products conform to specifications per the terms of the Texas Instruments standard warranty. Production processing does not necessarily include testingof all parameters.
– 128K-Byte L2 Unified Mapped RAM/Cache
(Flexible RAM/Cache Allocation)
• ARM926EJ-S Core – Support for 32-Bit and 16-Bit (Thumb®
Mode) Instruction Sets
– DSP Instruction Extensions and Single Cycle
MAC – ARM® Jazelle® Technology – EmbeddedICE-RT™ Logic for Real-Time
Debug
• ARM9 Memory Architecture – 16K-Byte Instruction Cache – 8K-Byte Data Cache – 32K-Byte RAM – 8K-Byte ROM
• Endianness: Little Endian for ARM and DSP
• Dual Programmable High-Definition Video Image Co-Processor (HDVICP) Engines
– Supports a Range of Encode, Decode, and
(BT.1120), or Single Raw (8-/10-/12-Bit) Video Capture Channels
– Two 8-Bit SD (BT.656) or Single 16-Bit HD
(BT.1120) Video Display Channels
• Video Data Conversion Engine (VDCE) – Horizontal and Vertical Downscaling – Chroma Conversion (4:2:24:2:0)
• Two Transport Stream Interface (TSIF) Modules (One Parallel/Serial and One Serial Only)
– TSIF for MPEG Transport Stream – Simultaneous Synchronous or
Asynchronous Input/Output Streams – Absolute Time Stamp Detection – PID Filter With 7 PID Filter Tables – Corresponding Clock Reference Generator
(CRGEN) Modules for System Time-Clock
Recovery
Copyright © 2009–2010, Texas Instruments Incorporated
TMS320DM6467T
SPRS605B–JULY 2009–REVISED JULY 2010
www.ti.com
• External Memory Interfaces (EMIFs) – CIR With Programmable Data Encoding – Up to 400-MHz 32-Bit DDR2 SDRAM Memory • One Serial Peripheral Interface (SPI) With Two
Controller With 512M-Byte Address Space Chip-Selects (1.8-V I/O)
– Asynchronous16-Bit Wide EMIF (EMIFA)
With 128M-Byte Address Reach
Flash Memory Interfaces – NOR (8-/16-Bit-Wide Data) – NAND (8-/16-Bit-Wide Data)
• Enhanced Direct-Memory-Access (EDMA) Controller (64 Independent Channels)
– Programmable Default Burst Size
• 10/100/1000 Mb/s Ethernet MAC (EMAC) – IEEE 802.3 Compliant (3.3-V I/O Only) – Supports MII and GMII Media Independent
Interfaces
– Management Data I/O (MDIO) Module
• USB Port With Integrated 2.0 PHY – USB 2.0 High-/Full-Speed Client – USB 2.0 High-/Full-/Low-Speed Host
(Mini-Host, Supporting One External Device)
• 32-Bit, 66-MHz, 3.3 V Peripheral Component Interconnect (PCI) Master/Slave Interface
– Conforms to PCI Specification 2.3
• Two 64-Bit General-Purpose Timers (Each Configurable as Two 32-Bit Timers)
• One 64-Bit Watch Dog Timer
• Three Configurable UART/IrDA/CIR Modules (One With Modem Control Signals)
– Supports up to 1.8432 Mbps UART – SIR and MIR (0.576 MBAUD)
• Master/Slave Inter-Integrated Circuit (I2C Bus™)
• Two Multichannel Audio Serial Ports (McASPs) – One Four Serializer Transmit/Receive Port – One Single DIT Transmit Port for S/PDIF
• 32-Bit Host Port Interface (HPI)
• VLYNQ™ Interface (FPGA Interface)
• Two Pulse Width Modulator (PWM) Outputs
• ATA/ATAPI I/F (ATA/ATAPI-6 Specification)
• Up to 33 General-Purpose I/O (GPIO) Pins (Multiplexed With Other Device Functions)
• On-Chip ARM ROM Bootloader (RBL)
• Individual Power-Saving Modes for ARM/DSP
• Flexible PLL Clock Generators
• IEEE-1149.1 (JTAG) Boundary­Scan-Compatible
• 529-Pin Pb-Free BGA Package (ZUT Suffix), 0.8-mm Ball Pitch
• 0.09-mm/7-Level Cu Metal Process (CMOS)
• 3.3-V and 1.8-V I/O, 1.3-V Internal
• Applications: – Video Encode/Decode/Transcode/Transrate – Digital Media – Networked Media Encode/Decode – Video Imaging – Video Infrastructure – Video Conferencing
• Community Resources – TI E2E CommunityTI Embedded Processors Wiki
2 Digital Media System-on-Chip (DMSoC) Copyright © 2009–2010, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
TMS320DM6467T
www.ti.com

1.2 Description

The TMS320DM6467T (also referenced as DM6467T) leverages TI’s DaVinci™ technology to meet the networked media encode and decode application processing needs of next-generation embedded devices.
The DM6467T enables OEMs and ODMs to quickly bring to market devices featuring robust operating systems support, rich user interfaces, high processing performance, and long battery life through the maximum flexibility of a fully integrated mixed processor solution.
The dual-core architecture of the DM6467T provides benefits of both DSP and Reduced Instruction Set Computer (RISC) technologies, incorporating a high-performance TMS320C64x+ DSP core and an ARM926EJ-S core.
The ARM926EJ-S is a 32-bit RISC processor core that performs 32-bit or 16-bit instructions and processes 32-bit, 16-bit, or 8-bit data. The core uses pipelining so that all parts of the processor and memory system can operate continuously.
The ARM core incorporates:
A coprocessor 15 (CP15) and protection module
Data and program Memory Management Units (MMUs) with table look-aside buffers.
Separate 16K-byte instruction and 8K-byte data caches. Both are four-way associative with virtual index virtual tag (VIVT).
The TMS320C64x+™ DSPs are the highest-performance fixed-point DSP generation in the TMS320C6000™ DSP platform. It is based on an enhanced version of the second-generation high-performance, advanced very-long-instruction-word (VLIW) architecture developed by Texas Instruments (TI), making these DSP cores an excellent choice for digital media applications. The C64x is a code-compatible member of the C6000™ DSP platform. The TMS320C64x+ DSP is an enhancement of the C64x+ DSP with added functionality and an expanded instruction set.
SPRS605B–JULY 2009–REVISED JULY 2010
Any reference to the C64x DSP or C64x CPU also applies, unless otherwise noted, to the C64x+ DSP and C64x+ CPU, respectively.
With performance of up to 8000 million instructions per second (MIPS) at a clock rate of 1 GHz, the C64x+ core offers solutions to high-performance DSP programming challenges. The DSP core possesses the operational flexibility of high-speed controllers and the numerical capability of array processors. The C64x+ DSP core processor has 64 general-purpose registers of 32-bit word length and eight highly independent functional units—two multipliers for a 32-bit result and six arithmetic logic units (ALUs). The eight functional units include instructions to accelerate the performance in video and imaging applications. The DSP core can produce four 16-bit multiply-accumulates (MACs) per cycle for a total of 4000 million MACs per second (MMACS), or eight 8-bit MACs per cycle for a total of 8000 MMACS. For more details on the C64x+ DSP, see the TMS320C64x/C64x+ DSP CPU and Instruction Set Reference Guide (literature number SPRU732).
The DM6467T also has application-specific hardware logic, on-chip memory, and additional on-chip peripherals similar to the other C6000 DSP platform devices. The DM6467T core uses a two-level cache-based architecture. The Level 1 program cache (L1P) is a 256K-bit direct mapped cache and the Level 1 data cache (L1D) is a 640K-bit 2-way set-associative cache. The Level 2 memory/cache (L2) consists of an 512K-bit memory space that is shared between program and data space. L2 memory can be configured as mapped memory, cache, or combinations of the two.
The peripheral set includes: a configurable video port; a 10/100/1000 Mb/s Ethernet MAC (EMAC) with a Management Data Input/Output (MDIO) module; a 4-bit transfer/4-bit receive VLYNQ interface; an inter-integrated circuit (I2C) Bus interface; a multichannel audio serial port (McASP0) with 4 serializers; a secondary multichannel audio serial port (McASP1) with a single transmit serializer; 2 64-bit general-purpose timers each configurable as 2 independent 32-bit timers; 1 64-bit watchdog timer; a configurable 32-bit host port interface (HPI); up to 33-pins of general-purpose input/output (GPIO) with
Copyright © 2009–2010, Texas Instruments Incorporated Digital Media System-on-Chip (DMSoC) 3
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
TMS320DM6467T
SPRS605B–JULY 2009–REVISED JULY 2010
programmable interrupt/event generation modes, multiplexed with other peripherals; 3 UART/IrDA/CIR interfaces with modem interface signals on UART0; 2 pulse width modulator (PWM) peripherals; an ATA/ATAPI-6 interface; a 66-MHz peripheral component interface (PCI); and 2 external memory interfaces: an asynchronous external memory interface (EMIFA) for slower memories/peripherals, and a higher speed synchronous memory interface for DDR2.
The Ethernet Media Access Controller (EMAC) provides an efficient interface between the DM6467T and the network. The DM6467T EMAC support both 10Base-T and 100Base-TX, or 10 Mbits/second (Mbps) and 100 Mbps in either half- or full-duplex mode; and 1000Base-TX (1 Gbps) in full-duplex mode with hardware flow control and quality of service (QOS) support.
The Management Data Input/Output (MDIO) module continuously polls all 32 MDIO addresses in order to enumerate all PHY devices in the system. Once a PHY candidate has been selected by the ARM, the MDIO module transparently monitors its link state by reading the PHY status register. Link change events are stored in the MDIO module and can optionally interrupt the ARM, allowing the ARM to poll the link status of the device without continuously performing costly MDIO accesses.
The PCI, HPI, I2C, SPI, USB2.0, and VLYNQ ports allow the DM6467T to easily control peripheral devices and/or communicate with host processors.
The DM6467T also includes a High-Definition Video/Imaging Co-processor (HDVICP) and Video Data Conversion Engine (VDCE) to offload many video and imaging processing tasks from the DSP core, making more DSP MIPS available for common video and imaging algorithms. For more information on the HDVICP enhanced codecs, such as H.264 and MPEG4, please contact your nearest TI sales representative.
www.ti.com
The rich peripheral set provides the ability to control external peripheral devices and communicate with external processors. For details on each of the peripherals, see the related sections later in this document and the associated peripheral reference guides.
The DM6467T has a complete set of development tools for both the ARM and DSP. These include C compilers, a DSP assembly optimizer to simplify programming and scheduling, and a Windows™ debugger interface for visibility into source code execution.
4 Digital Media System-on-Chip (DMSoC) Copyright © 2009–2010, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
JTAGInterface
SystemControl
PLLs/Clock
Generator
Input
Clock(s)
Power/Sleep
Controller
Pin
Multiplexing
ARMSubsystem
ARM926EJ-SCPU
16KB
I-Cache
32KBRAM
8KB
D-Cache
8KBROM
DSP Subsystem
C64x DSP CPU
32KB
L1Pgm
128KBL2RAM
32KB
L1Data
HighDefinition
Video-Imaging
Coprocessor
(HDVICP0)
SwitchedCentralResource(SCR)
Peripherals
EDMA
I2C SPI
UART
SerialInterfaces
DDR2 MemCtlr (16b/32b)
AsyncEMIF/
NAND/
SmartMedia
ATA
Program/DataStorage
Watchdog
Timer
PWM
System
General­Purpose
Timer
USB2.0
PHY
VLYNQ
EMAC
With
MDIO
Connectivity
HPI
McASP
Video
PortI/F
PCI
(66MHz)
TSIF
HighDefinition
Video-Imaging
Coprocessor
(HDVICP1)
CRGEN VDCE
TMS320DM6467T
www.ti.com

1.3 Functional Block Diagram

Figure 1-1 shows the functional block diagram of the device.
SPRS605B–JULY 2009–REVISED JULY 2010
Copyright © 2009–2010, Texas Instruments Incorporated Digital Media System-on-Chip (DMSoC) 5
Figure 1-1. TMS320DM6467T Functional Block Diagram
Submit Documentation Feedback
Product Folder Link(s): TMS320DM6467T
TMS320DM6467T
SPRS605B–JULY 2009–REVISED JULY 2010
www.ti.com
