TEXAS INSTRUMENTS TAS5026A Technical data

l

查询TAS5026A供应商



    

TM

Data M anua

January 2004 DAV Digital Audio/Speaker

SLES068A

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications,
enhancements, improvements, and other changes to its products and services at any time and to discontinue
any product or service without notice. Customers should obtain the latest relevant information before placing
orders and should verify that such information is current and complete. All products are sold subject to TI’s terms
and conditions of sale supplied at the time of order acknowledgment.

TI warrants performance of its hardware products to the specifications applicable at the time of sale in
accordance with TI’s standard warranty. Testing and other quality control techniques are used to the extent TI
deems necessary to support this warranty . Except where mandated by government requirements, testing of all
parameters of each product is not necessarily performed.

TI assumes no liability for applications assistance or customer product design. Customers are responsible for
their products and applications using TI components. To minimize the risks associated with customer products
and applications, customers should provide adequate design and operating safeguards.

TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right,
copyright, mask work right, or other TI intellectual property right relating to any combination, machine, or process
in which TI products or services are used. Information published by TI regarding third-party products or services
does not constitute a license from TI to use such products or services or a warranty or endorsement thereof.
Use of such information may require a license from a third party under the patents or other intellectual property
of the third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of information in TI data books or data sheets is permissible only if reproduction is without
alteration and is accompanied by all associated warranties, conditions, limitations, and notices. Reproduction
of this information with alteration is an unfair and deceptive business practice. TI is not responsible or liable for
such altered documentation.

Resale of TI products or services with statements different from or beyond the parameters stated by TI for that
product or service voids all express and any implied warranties for the associated TI product or service and is
an unfair and deceptive business practice. TI is not responsible or liable for any such statements.

Following are URLs where you can obtain information on other Texas Instruments products and application
solutions:

Products Applications

Amplifiers amplifier.ti.com Audio www.ti.com/audio
Data Converters dataconverter.ti.com Automotive www.ti.com/automotive

DSP dsp.ti.com Broadband www.ti.com/broadband
Interface interface.ti.com Digital Control www.ti.com/digitalcontrol
Logic logic.ti.com Military www.ti.com/military
Power Mgmt power.ti.com Optical Networking www.ti.com/opticalnetwork
Microcontrollers microcontroller.ti.com Security www.ti.com/security

Telephony www.ti.com/telephony
Video & Imaging www.ti.com/video
Wireless www.ti.com/wireless

Mailing Address: Texas Instruments

Post Office Box 655303, Dallas, Texas 75265

Copyright  2004, Texas Instruments Incorporated

Contents

Contents

Section Page

1 Introduction 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.1 Features 1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.2 Functional Block Diagram 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.3 Terminal Assignments 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.4 Ordering Information 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1.5 Terminal Functions 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2 Architecture Overview 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1 Clock and Serial Data Interface 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.1 Normal-Speed, Double-Speed, and Quad-Speed Selection 7. . . . . . . . . . . . . . . . . . . . . . . . .

2.1.2 Clock Master/Slave Mode (M_S) 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.3 Clock Master Mode 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.4 Clock Slave Mode 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.5 PLL Filter 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.6 DCLK 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.1.7 Serial Data Interface 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2 Reset, Power Down, and Status 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2.1 Reset—RESET 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2.2 Power Down—PDN 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2.3 General Status Registers 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.2.4 Error Status Register 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3 Signal Processing 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3.1 Volume Control 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3.2 Mute 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3.3 Automute 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3.4 Individual Channel Mute 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.3.5 De-Emphasis Filter 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4 Pulse Width Modulator (PWM) 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4.1 Clipping Indicator 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4.2 Error Recovery 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4.3 Individual Channel Error Recovery 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4.4 PWM DC-Offset Correction 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4.5 Interchannel Delay 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.4.6 PWM/H-Bridge and Discrete H-Bridge Driver Interface 22. . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.5 I2C Serial Control Interface 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.5.1 Single-Byte Write 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.5.2 Multiple-Byte Write 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.5.3 Single-Byte Read 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2.5.4 Multiple-Byte Read 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3 Serial Control Interface Register Definitions 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.1 General Status Register (0x00) 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.2 Error Status Register (0x01) 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.3 System Control Register 0 (0x02) 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.4 System Control Register 1 (0x03) 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.5 Error Recovery Register (0x04) 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.6 Automute Delay Register (0x05) 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.7 DC-Offset Control Registers (0x06−0x0B) 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

February 2003—Revised January 2004 SLES068A

iii

List of Illustrations

3.8 Interchannel Delay Registers (0x0C−0x11) 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3.9 Individual Channel Mute Register (0x19) 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4 System Procedures for Initialization, Changing Data Rates, and Switching Between Master

and Slave Modes 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.1 System Initialization 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.2 Data Sample Rate 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4.3 Changing Between Master and Slave Modes 35. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5 Specifications 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.1 Absolute Maximum Ratings Over Operating Temperature Ranges 37. . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.2 Recommended Operating Conditions 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.3 Electrical Characteristics Over Recommended Operating Conditions 37. . . . . . . . . . . . . . . . . . . . . . . . .

5.3.1 Static Digital Specifications Over Recommended Operating Conditions 37. . . . . . . . . . . . . .

5.3.2 Digital Interpolation Filter and PWM Modulator Over Recommended

Operating Conditions (Fs = 48 kHz) 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.3.3 TAS5026A/TAS5110 System Performance Measured at the Speaker

Terminals Over Recommended Operating Conditions (Fs = 48 kHz) 38. . . . . . . . . . . . . . . .

5.4 Switching Characteristics 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.4.1 Command Sequence Timing 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5.4.2 Serial Audio Port 42. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2

5.4.3 Serial Control Port—I

6 Application Information 47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.1 Serial Audio Interface Clock Master and Slave Interface Configuration 48. . . . . . . . . . . . . . . . . . . . . . . .

6.1.1 Slave Configuration 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6.1.2 Master Configuration 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7 Mechanical Data 49. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Appendix A—Volume Table 51. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C Operation 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

List of Illustrations

Figure Title Page

2−1 Crystal Circuit 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−2 External PLL Loop Filter 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−3 I2S 64-Fs Format 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−4 I2S 48-Fs Format 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−5 Left-Justified 64-Fs Format 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−6 Left-Justified 48-Fs Format 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−7 Right-Justified 64-Fs Format 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−8 Right-Justified 48-Fs Format 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−9 DSP Format 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−10 Attenuation Curve 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−11 De-Emphasis Filter Characteristics 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−12 PWM Outputs and H-Bridge Driven in BTL Configuration 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−13 Typical I2C Sequence 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−14 Single-Byte Write Transfer 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−15 Multiple-Byte Write Transfer 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−16 Single-Byte Read 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

iv

February 2003—Revised January 2004SLES068A

List of Tables

2−17 Multiple-Byte Read 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−1 RESET

4−2 Extending the I2C Write Interval Following Low-to-High Transition of RESET Terminal 32. . . . . . . . . . . . . . . . .

4−3 Changing the Data Sample Rate Using the DBSPD Terminal 33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−4 Changing the Data Sample Rate Using the I2C33. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4−5 Changing the Data Sample Rate With an Unstable MCLK_IN Using the DBSPD Terminal 34. . . . . . . . . . . . . .

4−6 Changing the Data Sample Rate With an Unstable MCLK_IN Using the I2C35. . . . . . . . . . . . . . . . . . . . . . . . . .

4−7 Changing Between Master and Slave Clock Modes 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−1 RESET Timing 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−2 Power-Down and Power-Up Timing—RESET Preceding PDN 39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−3 Power-Down and Power-Up Timing—RESET Following PDN 40. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−4 Error Recovery Timing 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−5 Mute Timing 41. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−6 Right-Justified, I2S, Left-Justified Serial-Protocol Timing 42. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−7 Right, Left, and I2S Serial-Mode Timing Requirement 43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−8 Serial Audio Ports Master-Mode Timing 43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−9 DSP Serial-Port Timing 43. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−10 DSP Serial-Port Expanded Timing 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−11 DSP Absolute Timing 44. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−12 SCL and SDA Timing 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5−13 Start and Stop Conditions Timing 45. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6−1 Typical TAS5026A Application 47. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6−2 TAS5026A Serial Audio Port—Slave-Mode Connection Diagram 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6−3 TAS5026A Serial Audio Port—Master-Mode Connection Diagram 48. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

During System Initialization 31. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

List of Tables

Table Title Page

2−1 Normal-Speed, Double-Speed, and Quad-Speed Operation 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−2 Master and Slave Clock Modes 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−3 LRCLK and MCLK_IN Rates 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−4 DCLK 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−5 Supported Word Lengths 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−6 Device Outputs During Reset 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−7 Values Set During Reset 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−8 Device Outputs During Power Down 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−9 Volume Register 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−10 De-Emphasis Filter Characteristics 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2−11 Device Outputs During Error Recovery 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−1 I2C Register Map 25. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−2 General Status Register (Read Only) 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−3 Error Status Register 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−4 System Control Register 0 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−5 System Control Register 1 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−6 Error Recovery Register 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

February 2003—Revised January 2004 SLES068A

v

List of Tables

3−7 Automute Delay Register 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−8 DC-Offset Control Registers 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−9 Six Interchannel Delay Registers 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3−10 Individual Channel Mute Register 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

vi

February 2003—Revised January 2004SLES068A

1 Introduction

The TAS5026A is an innovative, cost-effective, high-performance 24-bit six-channel digital pulse-width
modulator (PWM) based on Equibit technology. Combined with a TI PurePath Digital audio amplifier power
stage, these devices use noise-shaping and sophisticated error correction algorithms to achieve high power
efficiency and high-performance digital audio reproduction. The TAS5026A is designed to drive up to six digital
power devices to provide six channels of digital audio amplification. The digital power devices can be six
conventional monolithic power stages (such as T AS5110) or six discrete differential power stages using gate
drivers and MOSFETs.

The TAS5026A has six independent volume controls and mute. The device operates in AD mode. This
all-digital audio system contains only two analog components in the signal chain—an LC low-pass filter at each
speaker terminal and can provide up to 96-dB SNR at the speaker terminals. The T AS5026A has a wide variety
of serial input options including right justified (16, 20, or 24 bit), I2S (16, 20, or 24 bit) left justified, or DSP
(16-bit) data formats. The device is fully compatible with AES standard sampling rates of 44.1 kHz, 48 kHz,

88.2 kHz, 96 kHz, 176.4 kHz, and 192 kHz including de-emphasis for 44.1-kHz and 48-kHz sample rates. The

TAS5026A was designed for home theater applications such as DVD minicomponent systems, home theater
in a box (HTIB), DVD receiver, A/V receiver, or TV sets.

1.1 Features

• TI PurePath Digital Audio Amplifier

• High Quality Audio

− 96-dB SNR

− <0.1% THD+N

• Six-Channel Volume Control

− Patented Soft Volume

− Patented Soft Mute

• 16-, 20-, or 24-Bit Input Data

• Sampling Rates: 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, and 192 kHz

• Supports Master and Slave Modes

• 3.3-V Power Supply Operation

• Economical 64-Pin TQFP Package

• Digital De-Emphasis: 32 kHz, 44.1 kHz, and 48 kHz

• Clock Oscillator Circuit for Master Modes

• Low Jitter Internal PLL

• Soft Volume and Mute Update

Introduction

Equibit and PurePath Digital are trademarks of Texas Instruments.
Other trademarks are the property of their respective owners.

SLES068A—February 2003—Revised January 2004 TAS5026A

1

Introduction

1.2 Functional Block Diagram

AVDD_PLL

AVSS_PLL

VREGA_CAP

VREGB_CAP

VREGC_CAP

DVDD_RCL

DVSS_RCL

DVDD_PWM

DVSS_PWM

MCLK_IN

XTAL_OUT

XTAL_IN

DBSPD

M_S

PLL_FLT_OUT

PLL_FLT_RET

SCLK

LRCLK

MCLKOUT

SDIN1
SDIN2

SDIN3
DM_SEL1
DM_SEL2

SDA
SCL

CSO

RESET

PDN

CLIP

MUTE

ERR_RCVRY

Clock,

PLL
and

Serial

Data

I/F

Serial

Control

I/F

Reset,

Pwr Dwn

and

Status

Power Supply

Signal

Processing

Auto Mute

De-Emphasis

Soft Volume

Error Recovery

Soft Mute

Clip Detect

PWM

Section

PWM Ch.

PWM Ch.

PWM Ch.

PWM Ch.

PWM Ch.

PWM Ch.

Output Control

PWM_AP_1
PWM_AM_1
VALID_1

PWM_AP_2
PWM_AM_2
VALID_2

PWM AP_3
PWM AM_3
VALID_3

PWM_AP_4
PWM_AM_4
VALID_4

PWM_AP_5
PWM_AM_5
VALID_5

PWM_AP_6
PWM_AM_6
VALID_6

2

SLES068A—February 2003—Revised January 2004TAS5026A

1.3 Terminal Assignments

1

NC

NC

2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

MCLK_IN

AVDD_PLL

PLL_FLT_OUT

PLL_FLT_RET

AVSS_PLL

DVSS1

RST

ERR_RCVRY

MUTE

PDN
SDA

SCL
CS0

DVSS1

PAG PACKAGE

(TOP VIEW)

AVDD_OSC

XTL_IN

XTL_OUT

AVSS_OSC

DVSS

PWM_AP_1

PWM_AM_1

VALID_1

PWM_AP_2

PWM_AM_2

VALID_2

PWM_AP_3

PWM_AM_3

VALID_3NCNC

64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49

17

18 19 21 22 23 24 25 26 27 28 29 30 31 32

20

48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33

Introduction

DVDD_RCL
DVSS_RCL
NC
DVDD_PWM
DVSS_PWM
PWM_AP_4
PWM_AM_4
VALID_4
PWM_AP_5
PWM_AM_5
VALID_5
PWM_AP_6
PWM_AM_6
VALID_6
NC
NC

CLIP

DBSPD

SDIN1

SDIN2

SCLK

SDIN3

MCLK_OUT

DVDD

LRCLK

NC

DVSS1

M_S

DVSS1

DEM_SEL2

DEM_SEL1

DVSS1

SLES068A—February 2003—Revised January 2004 TAS5026A

3

Introduction

FUNCTION

†

DESCRIPTION

1.4 Ordering Information
T AS

5026A PAG

Texas Instruments

Audio Solutions

Device Number

Package Type

AVAILABLE OPTIONS

PACKAGE

T

A

0°C to 70°C TAS5026APAG

PLASTIC 64-PIN TQFP

(PAG)

1.5 Terminal Functions

TERMINAL

NAME NO.

AVDD_OSC 64 P Analog power supply for internal oscillator cells
AVDD_PLL 3 P 3.3-V analog power supply for PLL
AVSS_OSC 61 O Analog ground for internal oscillator cells
AVSS_PLL 6 P Analog ground for PLL
CLIP 18 O Digital clipping indicator, active low
CS0 15 I I2C device address select. This is an active high pin.
DBSPD 17 I Sample rate is double speed (88.2 kHz or 96 kHz), active high
DM_SEL1 29 I De-emphasis select bit 1 (0 = none, 01 = 32 kHz, 10 = 44.1 kHz
DM_SEL2 28 I De-emphasis select bit 2, 10 = 48 kHz, 11 = undefined (none)
DVDD_PWM 45 P 3.3-V digital power supply for PWM
DVDD_RCL 48 P 3.3-V digital power supply for re-clocker
DVDD 25 P 3.3-V digital power supply for digital core and most of I/O buffers
DVSS 60 I Voltage regulator enable, active low
DVSS_PWM 44 P Digital ground for PWM
DVSS_RCL 47 P Digital ground for re-clocker
DVSS1 8, 26,

ERR_RCVRY 10 I Error recovery, active low
LRCLK 24 I/O Serial audio data left/right clock (sampling rate clock) (input when M_S = 0; output when

M_S 30 I Master/slave mode input signal (master = 1, slave = 0)
MCLK_IN 2 I MCLK input, slave mode
MCLK_OUT 22 O MCLK output buffered system clock output M_S = 1; otherwise set to 0
MUTE 11 I Mute input signal, active low

†

I = input; O = output; I/O = input/output; P = power

31, 32

P Digital ground for digital core and most of I/O buffers

M_S = 1)

4

SLES068A—February 2003—Revised January 2004TAS5026A

TERMINAL

FUNCTION

†

DESCRIPTION

NAME NO.

NC 1, 7,

PDN 12 I Power down. This signal is active low.
PLL_FLT_OUT 4 I PLL external filter
PLL_FLT_RET 5 I PLL external filter
PWM_AM_1 58 O PWM 1 output (differential -); {Positive H-bridge side}
PWM_AM_2 55 O PWM 2 output (differential -); {Positive H-bridge side}
PWM_AM_3 52 O PWM 3 output (differential -); {Positive H-bridge side}
PWM_AM_4 42 O PWM 4 output (differential -); {Positive H-bridge side}
PWM_AM_5 39 O PWM 5 output (differential -); {Positive H-bridge side}
PWM_AM_6 36 O PWM 6 output (differential -); {Positive H-bridge side}
PWM_AP_1 59 O PWM 1 output (differential +); {Positive H-bridge side}
PWM_AP_2 56 O PWM 2 output (differential +); {Positive H-bridge side}
PWM_AP_3 53 O PWM 3 output (differential +); {Positive H-bridge side}
PWM_AP_4 43 O PWM 4 output (differential +); {Positive H-bridge side}
PWM_AP_5 40 O PWM 5 output (differential +); {Positive H-bridge side}
PWM_AP_6 37 O PWM 6 output (differential +); {Positive H-bridge side}
RST 9 I System reset input. This signal is an active low.
SCL 14 I I2C clock signal
SCLK 23 I/O Serial audio data clock (master mode = output, slave mode = input)
SDA 13 I/O I2C data signal
SDIN1 19 I Serial audio data 1 input
SDIN2 20 I Serial audio data 2 input
SDIN3 21 I Serial audio data 3 input
VALID_1 57 O Output indicating validity of PWM outputs, channel 1, active high
VALID_2 54 O Output indicating validity of PWM outputs, channel 2, active high
VALID_3 51 O Output indicating validity of PWM outputs, channel 3, active high
VALID_4 41 O Output indicating validity of PWM outputs, channel 4, active high
VALID_5 38 O Output indicating validity of PWM outputs, channel 5, active high
VALID_6 35 O Output indicating validity of PWM outputs, channel 6, active high
XTL_IN 63 I Crystal or TTL level clock input
XTL_OUT 62 O Crystal output (not for external usage)

†

I = input; O = output; I/O = input/output; P = power

27, 33,
34, 36,

49, 50

— No connection

Introduction

SLES068A—February 2003—Revised January 2004 TAS5026A

5

Introduction

6

SLES068A—February 2003—Revised January 2004TAS5026A

2 Architecture Overview

The TAS5026A is composed of six functional elements:

• Clock, PLL, and serial data interface (I

• Reset/power-down circuitry

• Serial control interface (I2C)

• Signal processing unit

• Pulse-width modulator (PWM)

• Power supply

2.1 Clock and Serial Data Interface

The TAS5026A clock and serial data interface contain an input serial data slave and the clock master/ slave
interface. The serial data slave interface receives information from a digital source such as a DSP, S/PDIF
receiver, analog-to-digital converter (ADC), digital audio processor (DAP), or other serial bus master. The
serial data interface has three serial data inputs that can accept up to six channels of data at data sample rates
of 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, and 192 kHz. The serial data interfaces support
left justified and right justified for 16-, 20-, and 24-bits. In addition, the serial data interface supports the DSP
protocol for 16 bits and the I

The TAS5026A can function as a receiver or a generator for the MCLK_IN (master clock), SCLK (shift clock),
and LRCLK (left/right clock) signals that control the flow of data on the three serial data interfaces. The
T AS5026A i s a clock master when it generates these clocks and is a clock slave when it receives these clocks.

The TAS5026A is a synchronous design that relies upon the master clock to provide a reference clock for all
of the device operations and communication via the I2C. When operating as a slave, this reference clock is
MCLK_IN. When operating as a master , the reference clock is either a TTL clock input t o X TAL_IN or a crystal
attached across XTAL_IN and XTAL_OUT.

2

S protocol for 24 bits.

Architecture Overview

2

S)

The clock and serial data interface has two control parameters: data sample rate and clock master or slave.

2.1.1 Normal-Speed, Double-Speed, and Quad-Speed Selection

The data sample rate is selected through a terminal (DBSPD) or the serial control register 0 (X02). The data
sample rate control sets the frequencies of the SCLK and LRCLK in clock slave mode and the output
frequencies of SCLK and LRCLK in clock master mode. There are three data rates: normal speed, double
speed, and quad speed.

Normal-speed mode supports data rates of 32 kHz, 44.1 kHz, and 48 kHz. Normal speed is supported in the
master and slave modes. Double-speed mode is used to support sampling rates of 88.2 kHz and 96 kHz.
Double speed is supported in master and slave modes. Quad-speed mode is used to support sampling rates
of 176.4 kHz and 192 kHz.

The PWM is placed in normal speed by setting the DBSPD terminal low or by setting the normal mode bits
in the system control register 0 (x02) through the serial control interface. The PWM is placed in double speed
mode by setting the DBSPD terminal high or by setting the double speed bits in the system control register.
Quad-speed mode is auto detected supported in slave mode and invoked using the I
in master mode. In slave mode, if the TAS5026A is not in double speed mode, quad-speed mode is
automatically detected when MCLK_IN is 128Fs. In master mode, the PWM is placed in quad-speed mode
by setting the quad-speed bit in the system control register through the serial control interface.

If the master clock is well behaved during the frequency transition (the high or low clock periods are not less
than 20 ns), then a simple speed selection is simply performed by setting the DBSPD terminal or the serial
control register.

When the sample rate is changed, the TAS5026A temporarily suspends processing, places the PWM outputs
in a hard mute (PWM P outputs low; PWM M outputs high, and all VALID signals low), resets all internal
processes, and suspends all I
noiselessly restarts the PWM output. The TAS5026A preserves all control register settings throughout this
sequence. If desired, the sample rate change can be performed while mute is active to provide a completely
silent transition. The timing of this control sequence is shown in Section 4.

2

C operations. The TAS5026A then performs a partial re-initialization and

2

C serial control interface

SLES068A—February 2003—Revised January 2004 TAS5026A

7

Architecture Overview

If the master clock input can encounter a high clock or low clock period of less than 20 ns while the data rates
are changing, then RESET

should be applied during this time There are two recommended control procedures
for this case, depending upon whether the DBSPD terminal or the serial control interface is used. These
control sequences are shown in Section 4.

Table 2−1. Normal-Speed, Double-Speed, and Quad-Speed Operation

QUAD-SPEED CONTROL

REGISTER BIT

0 0 Master or slave Normal speed
0 1 Master or slave Double speed
1 0 Master or slave Quad speed
0 0 Slave Quad speed if MCLK_IN = 128 Fs
1 1 Master or slave Error

DBSPD TERMINAL OR

CONTROL REGISTER BIT

2.1.2 Clock Master/Slave Mode (M_S)

Clock master and slave mode can be invoked using the M_S (master slave) terminal.
This terminal specifies the default mode that is set immediately following a device RESET. The serial data

interface setting permits the clock generation mode to be changed during normal operation.
The transition to master mode occurs:

• Following a RESET when M_S terminal has a logic high applied

MODE SPEED SELECTION

The transition to slave mode occurs:

• Following a RESET when M_S terminal has a logic low applied

2.1.3 Clock Master Mode

When M_S = 1 following a RESET, the TAS5026A provides the master clock, SCLK, and LRCLK to the rest
of the system. In the master mode, the TAS5026A outputs the audio system clocks MCLK_OUT, SCLK, and
LRCLK.

The TAS5026A device generates these clocks plus its internal clocks from the internal phase-locked loop
(PLL). The reference clock for the PLL can be provided by either an external clock source (attached to
XT AL_IN) or a crystal (connected across terminals XTAL_IN and XTAL_OUT). The external source attached
to MCLK_IN is 256 times (128 in quad mode) the data sample rate (Fs). The SCLK frequency is 64 times the
data sample rate and the SCLK frequency of 48 times the data sample rate is not supported in the master
mode. The LRCLK frequency is the data sample rate.

2.1.3.1 Crystal Type and Circuit

In clock master mode the TAS5026A can derive the MCLKOUT, SCLK, and LRCLK from a crystal. In this case,
the TAS5026A uses a parallel-mode fundamental-mode crystal. This crystal is connected to the TAS5026A
as shown in Figure 2−1.

8

SLES068A—February 2003—Revised January 2004TAS5026A

TAS5026A

Architecture Overview

rd = Drive level control resistor − crystal vendor specified
CL = Crystal load capacitance (capacitance of circuitry between the two terminals of the crystal)
CL = (C1 x C2 )/(C1 + C2 ) + CS (where CS = board stray capacitance ~ 3 pF)
Example: Vendor recommended CL = 18 pF, CS = 3 pF ≥ C1 = C2 = 2 x (18−3) = 30 pF

2.1.4 Clock Slave Mode

In the slave mode (M_S = 0), the master clock, LRCLK, and SCLK are inputs to the TAS5026A. The master
clock is supplied through the MCLK_IN terminal.

C

1

C

2

r

d

OSC

MACRO

XO

XI

AVSS

Figure 2−1. Crystal Circuit

As in the master mode, the TAS5026A device develops its internal timing from the internal phase-locked loop
(PLL). The reference clock for the PLL is provided by the input to the MCLK_IN terminal. This input is at a
frequency of 256 times (128 in quad mode) the input data rate. The SCLK frequency is 48 or 64 times the data
sample rate. The LRCLK frequency is the data sample rate. The TAS5026A does not require any specific
phase relationship between SRCLK and MCLK_IN, but there must be synchronization. The TAS5026A
monitors the relationship between MCLK, SCLK and LRCLK. The TAS5026A detects if any of the three clocks
are absent, if the LRCLK rate changes more than 10 MCLK cycles since the last device reset or clock error,
or if the MCLK frequency is changing substantially with respect to the PLL frequency.

When a clock error is detected, the TAS5026A performs a clock error management sequence.
The clock error management sequence temporarily suspends processing, places the PWM outputs in a hard

mute (PWM_P outputs are low; PWM_M outputs are high, and all VALID signals are low), resets all internal
processes, sets the volumes to mute, and suspends all I

2

C operations.

When the error condition is corrected, the TAS5026A exits the clock error sequence by performing a partial
re-initialization, noiselessly restarting the PWM output, and ramping the volume up to the level specified in
the volume control registers. This sequence is performed over a 60-ms interval. The TAS5026A preserves
all control register settings that were set prior to the clock interruption.

If a clock error occurs while the ERR_RCVRY

terminal is asserted (low), the TAS5026A performs the error
management sequence up to the unmute sequence. In this case, the volume remains at full attenuation with
the PWM output at a 50% duty cycle. The volume can be restored from this latched mute state by triggering
a mute/unmute sequence by asserting and releasing MUTE

either by using the terminal, the system control

register X01 D4, or the individual channel mute register D5−D0.
Alternatively, the TAS5026A can be prevented from entering the latched mute state following a clock error

when the ERR_RCVRY

terminal or the error recovery I2C command (register X03 bit D2) is active by writing

x7F to the individual error recovery register (x04) and a x84 to x1F (a feature enable register).

SLES068A—February 2003—Revised January 2004 TAS5026A

9

Architecture Overview

Table 2−2. Master and Slave Clock Modes

DESCRIPTION M_S DBSPD

Internal PLL, master, normal speed 1 0 8.192 - 2.048 32 8.192
Internal PLL, master, normal speed 1 0 11.2896 - 2.8224 44.1 11.2896
Internal PLL, master, normal speed 1 0 12.288 - 3.072 48 12.288
Internal PLL, master, double speed 1 1 - 22.5792
Internal PLL, master, double speed 1 1 - 24.576
Internal PLL, master, quad speed 1 0 - 22.5792 11.2896 176.4 22.5792
Internal PLL, master, quad speed 1 0 - 24.576 12.288 192 24.576
Internal PLL, slave, normal speed 0 0 - 8.192§ 2.0484 32 Digital GND
Internal PLL, slave, normal speed 0 0 - 11.2896
Internal PLL, slave, normal speed 0 0 - 12.288§ 3.072 48 Digital GND
Internal PLL, slave, double speed 0 1 - 22.5792 5.6448 88.2 Digital GND
Internal PLL, slave, double speed 0 1 - 24.576§ 6.144 96 Digital GND
Internal PLL, slave, quad speed
Internal PLL, slave, quad speed

†

A crystal oscillator is connected to XTL_IN.

‡

MCLK_IN tied low when input to XTL_IN is provided; XTL_IN tied low when MCLK_IN_IN is provided.

§

External MCLK_IN connected to MCLK_IN_IN input

¶

SCLK and LRCLK are outputs when M_S = 1, and inputs when M_S = 0.

#

MCLK_OUT is driven low when M_S = 0.

||

Quad-speed mode is detected automatically.

||
||

0 0 - 22.5792
0 0 - 24.576§ 12.288 192 Digital GND

XTL_IN

(MHz)

k SCLK can be 48 or 64 times Fs

†

MCLK_IN

‡

(MHz)

SCLK

(MHz)

k

§

§

§

§

5.6448 88.2 22.5792

6.144 96 24.576

2.8224 44.1 Digital GND

11.2896 176 Digital GND

LRCLK

(kHz)

¶

MCLK_OUT

(MHz)

#

Table 2−3. LRCLK and MCLK_IN Rates

NORMAL SPEED (kHz) DOUBLE SPEED (kHz) QUAD SPEED (kHz)

LRCLK 1 Fs 32 44.1 48 1 Fs 64 88.2 96 1 Fs 176.4 192

MCLK_IN 256 Fs 8,192 11,289.6 12,288 256 Fs 16,384 22,579.2 24,576 128 Fs 22,579.2 24,576

2.1.5 PLL External Filter

A low jitter PLL produces the internal timing of the TAS5026A (when in master mode), the master clock, SCLK,
and LRCLK. Connections for the PLL external filter are provided through PLL_FL T_OUT and PLL_FLT_RET
as shown in Figure 2−2.

PLL_FLT_OUT

220 Ω

4.7 nF

TAS5026A

PLL_FLT_RET

Figure 2−2. PLL External Filter

47 nF

10

SLES068A—February 2003—Revised January 2004TAS5026A

2.1.6 DCLK

DCLK is the internal high frequency clock that is produced by the PLL circuitry from MCLK. The TAS5026A
uses the DCLK to control all internal operations. DCLK is 8 times the speed of MCLK in normal speed mode,
4 times MCLK in double speed, and 2 times MCLK in quad speed. With respect to the I
registers, DCLK clock cycles are used to specify interchannel delay and to detect when the MCLK frequency
is drifting. Table 2−4 DCLK shows the relationship between Sample Rate, MCLK, and DCLK.

Table 2−4. DCLK

Architecture Overview

2

C addressable

Fs

(kHz)

32 8.1920 65.5360 15.3

44.1 11.2896 90.3168 11.1
48 12.2880 98.3040 10.2
88 22.5280 90.1120 11.1
96 24.5760 98.3040 10.2

192 49.1520 98.3040 10.2

2.1.7 Serial Data Interface

The TAS5026A operates as a slave only/receive only serial data interface in all modes. The TAS5026A has
three PCM serial data interfaces to accept six channels of digital data though the SDIN1, SDIN2, SDIN3 inputs.
The serial audio data is in MSB first; 2s complement format.

The serial data interfaces of the T AS5026A can be configured in right justified, I
This interface supports 32-kHz, 44.1-kHz, 48-kHz, 88-kHz, 96-kHz, 176.4-kHz, and 192-kHz data sample
rates. The serial data interface format is specified using the data interface control register . The supported word
lengths are shown in Table 2−5.

During normal operating conditions if the serial data interface settings change state, an error recovery
sequence is initiated.

DATA MODES

Right justified, MSB first 16 0 0 0
Right justified, MSB first 20 0 0 1
Right justified, MSB first 24 0 1 0

Left justified, MSB first 24 1 1 0

DSP frame 16 1 1 1

MCLK
(MHz)

DCLK
(MHz)

DCLK Period

(ns)

2

S, left-justified, or DSP modes.

Table 2−5. Supported Word Lengths

WORD

LENGTHS

I2S 16 0 1 1
I2S 20 1 0 0
I2S 24 1 0 1

MOD2 MOD1 MOD0

SLES068A—February 2003—Revised January 2004 TAS5026A

11

Architecture Overview

2.1.7.1 I2S Timing

I2S timing uses an LRCLK to define when the data being transmitted is for the left channel and when it is for
the right channel. The LRCLK is low for the left channel and high for the right channel. A bit clock running at
48 or 64 times Fs is used to clock in the data. There is a delay of one bit clock from the time the LRCLK signal
changes state to the first bit of data on the data lines. The data is written MSB first and is valid on the rising
edge of the bit clock. The TAS5026A masks unused trailing data bit positions. Master mode only supports a
64 times Fs bit clock.

2-Channel I2S (Philips Format) Stereo Input

32 Clks

32 Clks

LRCLK (Note Reversed Phase) Left Channel

SCLK

MSB LSB

24-Bit Mode

23 22

20-Bit Mode

19 18

16-Bit Mode

9 8 5 4 1 0

5 4 1 0

1 015 14

Figure 2−3. I2S 64-Fs Format

2-Channel I2S Stereo Input/Output (24-Bit Transfer Word Size)

24 Clks

LRCLK

Left Channel

Right Channel

SCLK

MSB LSB

23 22

19 18 5 4 1 0

9 8 5 4 1 0

1 015 14

24 Clks

Right Channel

SCLK

MSB LSB

24-Bit Mode

22

23

20-Bit Mode

19 18

16-Bit Mode

20 19 8 7 2 1

16 15 1 0

12

11

13

4

517

1 015 14

4 3521

Figure 2−4. I2S 48-Fs Format

12

SCLK

MSB LSB

23 22

0

19 18 16 15 1 0

20 19 8 7 2 1

4

517

13

11

12

SLES068A—February 2003—Revised January 2004TAS5026A

1 015 14

4 3521

2.1.7.2 Left-Justified Timing

2-Channel Left-Justified Stereo Input

2-Channel Left-Justified Stereo Input/Output (24-Bit Transfer Word Size)

Left-justified (LJ) timing uses an LRCLK to define when the data being transmitted is for the left channel and
when it is for the right channel. The LRCLK is high for the left channel and low for the right channel. A bit clock
running at 48 or 64 times Fs is used to clock in the data. The first bit of data appears on the data lines at the
same time the LRCLK toggles. The data is written MSB first and is valid on the rising edge of the bit clock.
The TAS5026A masks unused trailing data bit positions. Master mode only supports a 64 times Fs bit clock.

Architecture Overview

32 Clks

LRCLK

Left Channel

SCLK

MSB LSB

24-Bit Mode

23 22

NOTE: All data presented in 2s complement form with MSB first.

9 8 5 4 1 0

Figure 2−5. Left-Justified 64-Fs Format

24 Clks

LRCLK

Left Channel

32 Clks

LRCLK

Right Channel

MSB LSB

23 22

9 8 5 4 1 0

24 Clks

Right Channel

SCLK

MSB LSB

24-Bit Mode

22 21

19 9 8 1 0

3 242023 22 21

Figure 2−6. Left-Justified 48-Fs Format

2.1.7.3 Right-Justified Timing

Right-justified (RJ) timing uses an LRCLK to define when the data being transmitted is for the left channel and
when it is for the right channel. The LRCLK is high for the left channel and low for the right channel. A bit clock
running at 48 or 64 times Fs is used to clock in the data. The first bit of data appears on the data 8-bit clock
periods (for 24-bit data) after LRCLK toggles. In RJ mode, the last bit clock before LRCLK transitions always
clocks the LSB of data. The data is written MSB first and is valid on the rising edge of the bit clock. The
TAS5026A masks unused leading data bit positions. Master mode only supports a 64 times Fs bit clock.

SLES068A—February 2003—Revised January 2004 TAS5026A

MSB LSB

19 9 8 1 0

5

3 2420235

13

Architecture Overview

2-Channel Right-Justified (Sony Format) Stereo Input

2-Channel Right-Justified Stereo Input/Output (24-Bit Transfer Word Size)

32 Clks

LRCLK

Left Channel

SCLK

MSB LSB

24-Bit Mode

23

22

20-Bit Mode

16-Bit Mode

NOTE: All data presented in 2s complement form with MSB first.

19 18 15 14 1 0

19 18

15 14 1 0

1 015 14

Figure 2−7. Right-Justified 64-Fs Format

32 Clks

Right Channel

MSB LSB

23 22

19 18 15 14 1 0

19 18 15 14 1 0

1 015 14

24 Clks

LRCLK

Left Channel

SCLK

MSB LSB

24-Bit Mode

22 21

20-Bit Mode

16-Bit Mode

NOTE: All data presented in 2s complement form with MSB first.

19 1 0

2023

18

18 89

19 1 0

15 14 22 21

15 14

89

8915 14

1 0

Figure 2−8. Right-Justified 48-Fs Format

24 Clks

Right Channel

MSB LSB

19 1 0

2023

18

18 89

19 1 0

15 14

15 14

89

8915 14

1 0

14

SLES068A—February 2003—Revised January 2004TAS5026A

2.1.7.4 DSP Mode Timing

DSP mode timing uses an LRCLK to define when data is to be transmitted for both channels. A bit clock running
at 64 × Fs is used to clock in the data. The first bit of the left channel data appears on the data lines following
the LRCLK transition. The data is written MSB first and is valid on the rising edge of the bit clock. The
TAS5026A masks unused trailing data bit positions.

SCLK

LRCLK

Architecture Overview

64 SCLKS

LSBMSB

SDIN

16 Bits

Left

Channel

Figure 2−9. DSP Format

2.2 Reset, Power Down, and Status

The reset, power down, and status circuitry provides the necessary controls to bring the TAS5026A to the initial
inactive condition, achieve low power standby, and report system status.

2.2.1 Reset—RESET

The TAS5026A is placed in the reset mode by setting the RESET terminal low.
RESET

1−6 outputs low, and places the PWM in the hard mute state. Volume is immediately set to full attenuation
(there is no ramp down).

As long as the RESET
bus operations are ignored. Table 2−6 shows the device output signals while RESET

is an asynchronous control signal that restores the TAS5026A to its default conditions, sets the valid

terminal is held low, the device is in the reset state. During reset, all I2C and serial data

16 Bits

Right

Channel

LSBMSB

32 Bits Unused

is active.

Upon the release of RESET

, if POWER_DWN is high, the system performs a 4-ms to 5-ms device initialization
and then ramps the volume up to 0 db using a soft volume update sequence. If MCLK_IN is not active when
RESET is released high, then a 4-ms to 5-ms initialization sequence is produced once MCLK_IN becomes
active.

During device initialization all controls are reset to their initial states. Table 2−7 shows the control settings that
are changed during initialization.

RESET

SLES068A—February 2003—Revised January 2004 TAS5026A

should be applied during power-up initialization or while changing the master slave clock states.

15

Architecture Overview

Because the RESET is an asynchronous control signal, small clicks and pops can be produced during the
application (the leading edge) of this control. However, when RESET
mute state back to normal operation is performed synchronously using a quiet sequence.

Table 2−6. Device Outputs During Reset

SIGNAL MODE SIGNAL STATE

Valid 1−Valid 6 All Low
PWM P-outputs All Low
PWM M-outputs All Low
MCLKOUT All Low
SCLK Master Low
SCLK Slave Signal input
LRCLK Master Low
LRCLK Slave Signal input
SDA All Signal input
CLIP All High

is released, the transition from the hard

If a completely quiet reset sequence is desired, MUTE

CONTROL SETTING

Volume 0 dB
MCLK_IN frequency 256
Master/slave mode M_S terminal state
Automute Enabled
De-emphasis None
DC offset 0
Interchannel delay Each channel is set to a default value

2.2.2 Power Down—PDN

The T AS5026A can be placed into the power-down mode by holding the PDN terminal low. When power-down
mode is entered, both the PLL and the oscillator are shut down. Volume is immediately set to full attenuation
(there is no ramp down). The valid 1−6 outputs are immediately asserted low and the PWM outputs are placed
in the hard mute state. PDN
is held low—the device is in the power-down (hard mute) state.

During power down, all I
signals while PDN

To place the device in total power-down mode, both RESET and power-down modes must be enabled. Prior
to bringing PDN

is active.

high, RESET must be brought low for a minimum of 50 ns.

should be applied before applying RESET.

Table 2−7. Values Set During Reset

initiates device power down without clock inputs. As long as the PDN terminal

2

C and serial data bus operations are ignored. Table 2−8 shows the device output

Table 2−8. Device Outputs During Power Down

SIGNAL MODE SIGNAL STATE

Valid 1−Valid 6 All Low
PWM P-outputs All Low
PWM M-outputs All Low
MCLKOUT All Low
SCLK Master Low
SCLK Slave Signal input
LRCLK Master Low
LRCLK Slave Signal input
SDA All Signal input
CLIP All High

16

SLES068A—February 2003—Revised January 2004TAS5026A

Because PDN is an asynchronous control signal, small clicks and pops can be produced during the application
(the leading edge) of this control. However, when PDN
to normal operation is performed synchronously using a quiet sequence.

If a completely quiet reset sequence is desired, MUTE

2.2.2.1 Recovery Time Options

To support the requirements of various system configurations, the TAS5026A can come up to the normal state
after either a long (100 ms) or a short (5 ms) delay.

1. In the first case, a slow system (95 ms to 100 ms) start-up occurs at the end of the power-down sequence

when:

RESET

2. Otherwise a fast (4 ms to 5 ms) start-up occurs.

NOTE: If MCLK_IN is not active when both of these signals are released high, then a fast

(4 ms to 5 ms) start-up occurs once MCLK_IN becomes active.

is high for at least 16 MCLK_IN periods before PDN goes high.

2.2.3 General Status Registers

The general status register is a read only register. This register provides an indication when a volume update
is in progress or one of the channels is inactive. The device id can be read using this register.

Volume update is in progress—Whenever a volume change is in progress due to a volume update
command or mute, this status bit is high.

Device identification code—The device identification code, 1 0011, is displayed.
No internal errors (all valid signals are high)—When there are no internal errors in the TAS5026A and all

outputs are valid, this status bit is high.
One or more valid signals are inactive—If low, one or more channels of the TAS5026A are not outputting

data. The Valid signals for those channels are inactive.

Architecture Overview

is released, the transition from the hard mute state back

should be applied before applying PDN.

This can be produced by one of three causes:

• One or more of the clock signals are in error

• Error

• The automute has silenced one or more channels that are receiving 0 inputs

• Mute

• Volume control has been set to full attenuation

If this signal is high, the TAS5026A is outputting data on all channels.

recover is active (low)
has been set

2.2.4 Error Status Register

The error status register indicates historical information on control signal changes and clock errors. This
register latches these indications when they occur. The indications are cleared by writing a 00(Hex) to the
register.

This register is intended as a diagnostic tool to be used only when the system is not operating correctly . This
is because the error status bits are set when the data rate, serial data interface format, or master/slave mode
is changed. As a result, this register indicates an error condition even though the system is operating normally.
This register should only be used while diagnosing transient error conditions.

Any clock error or control signal terminal change which occurs since the last time the error status register was
cleared is displayed. In using this register, the first step is to initialize the device and ve rify that all of the clock
signals are active. Then this register should be cleared by writing a 00(Hex). At this point, the register indicates
any errors or control signal changes.

SLES068A—February 2003—Revised January 2004 TAS5026A

17

Architecture Overview

This register indicates an error condition by a high for the following conditions:

• FS ERROR

• A control terminal change has occurred (M_S

• LRCLK error

• MCLK_IN count error

• DCLK phase error with respect to MCLK_IN

• MCLK_IN phase error with respect to DCLK

• PWM timing error

If all bits of the register are low, no errors have occurred and no control terminals changed.
There is no one-to-one correspondence of clock error indication to a system error condition. A particular

system error can be indicated by one or more error indications in this register. The system error conditions
and the reported errors are as follows:

There is no correct number of MCLKs per LRCLK:

• FS error has occurred

• LRCLK error

• MCLK_IN count error

LRCLK is absent:

• LRCLK error

, DBLSPD)

MCLK is the wrong frequency, changing frequency, or absent:

• DCLK phase error with respect to MCLK

• MCLK phase error with respect to DCLK

• PWM timing error

SCLK is the wrong frequency or absent:

• SCLK error

2.3 Signal Processing

This section contains the signal processing functions that are contained in the TAS5026A. The signal
processing is performed using a high-speed 24-bit signal processing architecture. The TAS5026A performs
the following signal processing features:

• Individual channel soft volume with a range of 24 dB to −114 dB plus mute

• Soft mute

• Automute

• 50-µs/15-µs de-emphasis filter supported in the sampling rates 32 kHz, 44.1 kHz, and 48 kHz

2.3.1 Volume Control

The gain of each output can be adjusted by a soft digital volume control for each channel. Volume adjustments
are performed using a soft gain update s-curve, which is approximated using a second order filter fit. The curve
fit is performed over a transition interval between 41 ms and 65 ms.

18

The volume of each channel can be adjusted from mute to −114 dB to 24 dB in 0.5 dB steps. Because of the
numerical representation that is used to control the volume, at very low volume levels the step size increases
for gains that are less than −96 dB. The default volume setting following power up or reset is 0 dB for all
channels. The step size adjustment is linear down to approximately −90 dB, see see Figure 2−10.

SLES068A—February 2003—Revised January 2004TAS5026A

STEP SIZE

vs

ATTENUATION (GAIN)

6.0

5.5

5.0

4.5

4.0

3.5

3.0

2.5

Step Size − dB

2.0

1.5

1.0

0.5

0.0

−110 −100 −90 −80 −70 −60 −50 −40 −30 −20 −10 0 10 20
Attenuation (Gain) − dB

Figure 2−10. Attenuation Curve

Architecture Overview

The volume control format for each channel is expressed in 8 bits. The volume for each channel is set by writing
8 bits via the serial control interface. The MSB bit is written first as in the bit position 0 (LSB position).

The volume for each channel can be set using a single or multiple address write operation to the volume control
register via the serial control interface. Changing the volume of all six channels requires that 6 registers be
updated.

To coordinate the volume adjustment of multiple channels simultaneously, the TAS5026A performs a delayed
volume update upon receiving a volume change command. Following the completion of the register volume
write operations, the TAS5026A waits for 5 ms for another volume command to be given. If no volume
command is issued in that period of time, the TAS5026A starts adjusting the volume of the channels that
received volume settings.

While a volume update is being performed, the system status register indicates that the update is in progress.
During the up d a t e , a l l s u b s e q u e n t v o l u m e c ontrol setting requests that are sent to the TAS5026A are received
and stored as a single next value for a subsequent update. If more than one volume setting request is sent,
only the last is retained.

2.3.2 Mute

Table 2−9. V olume Register

VOLUME REGISTER

D7 D6 D5 D4 D3 D2 D1 D0

Vol

Bit 7

Vol

Bit 6

Vol

Bit 5

Vol

Bit 4

Vol

Bit 3

Vol

Bit 2

Vol

Bit 1

Vol

Bit 0

The application of mute ramps the volume from any setting to noiseless hard mute state. There are two
methods in which the TAS5026A can be placed into mute. The TAS5026A is placed in the noiseless mute when
the MUTE

terminal is asserted low for a minimum of 3 MCLK_IN cycles. Alternatively , the mute mode can be
initiated by setting the mute bit in the system control register through the serial control interface. The
T AS5026A i s held in mute state as long as the terminal is low or I

2

C mute setting is active. This command uses

quiet entry and exit sequences to and from the hard mute state.

SLES068A—February 2003—Revised January 2004 TAS5026A

19

Architecture Overview

If an error recovery (described in the PWM section) occurs after a mute request has been received, the device
returns from error recovery with the channel volume set as specified by the mute command.

2.3.3 Automute

Automute is an automatic sequence that can be enabled or disabled via the serial control interface. The default
for this control is enabled. When enabled, the PWM automutes an individual channel when a channel receives
from 5 ms to 50 ms of consecutive zeros. This time interval can be selectable using the automute delay
register. The default interval is 5 ms at 48 kHz. This duration is independent of the sample rate. The automute
state is exited when two consecutive samples of nonzero data are received. The TAS5026A exit from
automute is performed quickly and preserves all music information.

This mode uses the valid low to provide a low-noise floor while maintaining a short start-up time. Noise free
entry and exit is achieved by using the PWM quiet start and stop sequences.

2.3.4 Individual Channel Mute

Individual channel mute is invoked through the serial interface. Individual channel mute permits each channel
of the T AS5026A to be individually muted and unmuted. The operation that is performed is identical to the mute
operation; however, it is performed on a per channel basis. A TAS5026A channel is held in the mute state as
long as the serial interface mute setting for that channel is set.

2.3.5 De-Emphasis Filter

For audio sources that have been pre-emphasized, a precision 50-µs/15-µs de-emphasis filter is provided to
support the sampling rates of 32 kHz, 44.1 kHz, and 48 kHz. See Figure 2−11 for a graph showing the
de-emphasis filtering characteristics. De-emphasis is set using two bits in the system control register.

Table 2−10. De-Emphasis Filter Characteristics

DEM_SEL2 (MSB) DEM_SEL1 DESCRIPTION

0 0 De-emphasis disabled
0 1 De-emphasis enabled for Fs = 48 kHz
1 0 De-emphasis enabled for Fs = 44 kHz
1 1 De-emphasis enabled for Fs = 32 kHz

Following the change of state of the de-emphasis bits, the PWM outputs go into the soft mute state. After 128
LRCLK periods for initialization, the PWM outputs are driven to the normal (unmuted) mode.

0

−10

Response − dB

3.18 (50 µs) 10.6 (15 µs)

Figure 2−11. De-Emphasis Filter Characteristics

2.4 Pulse-Width Modulator (PWM)

The TAS5026A contains six channels of high performance digital Equibit PWM modulators that are designed
to drive switching output stages (back ends) in both single-ended (SE) and H-bridge (bridge tied load)
configuration. The TAS5026A device uses noise shaping and sophisticated error correction algorithms to
achieve high power efficiency and high-performance digital audio reproduction.

The PWM provides six pseudo-differential outputs to drive six monolithic power stages (such as TAS5110)
or six discrete differential power stages using of gate drivers (such as the TAS5182) and MOSFETs in
single-ended or bridged configurations. The T AS5026A also provides a high performance differential output
that can be used to drive an external analog headphone amplifier.

De-Emphasis

f − Frequency − kHz

20

SLES068A—February 2003—Revised January 2004TAS5026A

2.4.1 Clipping Indicator

The clipping output is designed to indicate clipping. When any of the six PWM outputs exceeds the maximum
allowable amplitude, the clipping indicator is asserted. The clipping indicator is cleared every 10 ms.

2.4.2 Error Recovery

Error recovery is used to provide error management and to permit the PWM output to be reset while preserving
all intervolume, interchannel delay, dc offsets, and the other internal settings. Error recovery is initiated by
bringing the ERR_RCVRY
in control register 1. Error recovery is a level sensitive signal.

The device also performs an error recovery automatically:

• When the speed configuration is changed to normal, double, or quad speed

• Following a change in the serial data bus interface configuration

Architecture Overview

terminal low for a minimum 5 MCLK_IN cycles or by setting the error recovery bit

When ERR_RCVRY
there are any pending speed configurations, these changes are then performed. When ERR_RCVRY

is brought low, all valid signals go low, and the PWM-P and PWM-M outputs go low. If

is
brought high, a delay of 4 ms to 5 ms is performed before the system starts the output re-initialization
sequence. After the initialization time, the TAS5026A begins normal operation. During error recovery, all
controls and device settings that were not updated are maintained in their current configurations.

To permit error recovery to be used to provide TAS5100 error management and recovery, the delay between
the start of (falling edge) error recovery and the falling edge of valid 1 though valid 6 is selectable. This delay
can be selected to be either 6 µs or 47 µs.

During error recovery all serial data bus operations are ignored. At the conclusion of the sequence, the error
recovery register bit is returned to normal operation state. Table 2−1 1 shows the device output signal states
while during error recovery.

Table 2−11. Device Outputs During Error Recovery

SIGNAL MODE SIGNAL STATE

Valid 1−Valid 6 All Low
PWM P-outputs All Low
PWM M-outputs All Low
MCLKOUT All Low
SCLK Master Low
SCLK Slave Signal input
LRCLK Master Low
LRCLK Slave Signal input
SDA All Signal input
CLIP All High

The transitions are done using a quiet entrance and exit sequence to prevent pops and clicks.

2.4.3 Individual Channel Error Recovery

Individual channel error recovery is used to provide error management and to permit the PWM output to be
turned off. Error recovery is initiated by setting one or more of the six error recovery bits in the error recovery
register to low.

While the error recover bits are brought low , the valid signals go to the low state. When the error recovery bits
are brought high, a delay of 4 ms to 5 ms occurs before the channels are returned to normal operation.

The delay between the falling edge of the error recover bit and the falling edge of valid 1 though valid 6 is
selectable. This delay can be selected to be either 6 µs or 47 µs.

The TAS5026A controls the relative timing of the pseudo-differential drive control signals plus the valid signal
to minimize the production of system noise during error recovery operations. The transitions to valid low and
valid high are done using an almost quiet entrance and exit sequence to prevent pops and clicks.

SLES068A—February 2003—Revised January 2004 TAS5026A

21

Architecture Overview

2.4.4 PWM DC-Offset Correction

An 8-bit value can be programmed to each of the six PWM offset correction registers to correct for any offset
present in the output stages. The offset correction is divided into 256 intervals with a total offset correction of
±1.56% of full scale. The default value is zero correction represented by 00 (hex). These values can be
changed at any time through the serial control interface.

2.4.5 Interchannel Delay

An 8-bit value can be programmed to each of the six PWM interchannel delay registers to add a delay per
channel from 0 to 255 clock cycles. The delays correspond to cycles of the high-speed internal clock, DCLK.
Each subsequent channel has a default value that is N DCLKs larger than the preceding channel. The default
values are 0 for the first channel and 76 for each successive channel.

These values can be updated upon power up through the serial control interface. This delay is generated in
the PWM block with the appropriate control signals generated in the CTL block.

These values can be changed at any time through the serial control interface.

NOTE:

The performance of a PurePath Digital amplifier system is optimized by setting the PWM
timing based upon the type of back-end device that is used and the layout. These values are
set during initialization using the I

2

C serial interface.

2.4.6 PWM/H-Bridge and Discrete H-Bridge Driver Interface

The TAS5026A provides six PWM outputs, which are designed to drive switching output stages (back-ends)
in both single-ended (SE) and H-bridge (bridge tied load) configuration. The back-ends may be monolithic
power stages (such as the T AS5110) or six discrete differential power stages using gate drivers (such as the
the TAS55182) and MOSFETs in single-ended or bridged configurations.

The TAS5110 device is optimized for bridge tied load (BTL) configurations. These devices require a pure
differential PWM signal with a third signal (VALID) to control the MUTE state. In the MUTE state, the TAS5110
OUTA and OUTB are both low.

One Channel
of TAS5026A

PWM_AP

PWM_AM

VALID

Figure 2−12. PWM Outputs and H-Bridge Driven in BTL Configuration

2.5 I2C Serial Control Interface

MCLK must be active for the TAS5026A to support I2C bus transactions. The TAS5026A has a bidirectional
serial control interface that is compatible with the I
400 kbps data transfer rates for single and multiple byte write and read operations. This is a slave only device
that does not support a multi-master bus environment or wait state insertion. The control interface is used to
program the registers of the device and to read device status.

TAS5110

AP
AM
RESET
BP
BM

2

C (Inter IC) bus protocol and supports both 100 KBPS and

OUTA

Speaker

OUTB

The TAS5026A supports the standard-mode I
operation (400 kHz maximum). The TAS5026A performs all I

PurePath Digital is a trademark of Texas Instruments.

22

2

C bus operation (100 kHz maximum) and the fast I2C bus

2

C operations without I2C wait cycles.

SLES068A—February 2003—Revised January 2004TAS5026A

Architecture Overview

p

The I2C bus employs two signals; SDA (data) and SCL (clock), to communicate between integrated circuits
in a system. Data is transferred on the bus serially one bit at a time. The address and data are transferred in
byte (8 bit) format with the most significant bit (MSB) transferred first. In addition, each byte transferred on the
bus is acknowledged by the receiving device with an acknowledge bit. Each transfer operation begins with
the master device driving a start condition on the bus and ends with the master device driving a stop condition
on the bus. The bus uses transitions on the data terminal (SDA) while the clock is high to indicate start and
stop conditions. A high-to-low transition on SDA indicates a start, and a low-to-high transition indicates a stop.
Normal data bit transitions must occur within the low time of the clock period. These conditions are shown in
Figure 2−13. The master generates the 7-bit slave address and the read/write (R/W) bit to open
communication with another device and then waits for an acknowledge condition. The T AS5026A holds SDA
low during acknowledge clock period to indicate an acknowledgement. When this occurs, the master transmits
the next byte of the sequence. Each device is addressed by a unique 7-bit slave address plus R/W bit (1 byte).
All compatible devices share the same signals via a bidirectional bus using a wired-AND connection. I

2

C An

external pullup resistor must be used for the SDA and SCL signals to set the high level for the bus.

SDA

SCL

7 Bit Slave Address

7 6 5 4 3 2 1 0 7 6 5 4 3 2 1 0A7 6 5 4 3 2 1 0

Start Sto

There are no limits on the number of bytes that can be transmitted between start and stop conditions. When
the last word transfers, the master generates a stop condition to release the bus. A generic data transfer
sequence is also shown in Figure 2−13.

The 7-bit address for the TAS5026A is 001101X, where X is a programmable address bit. Using the CS0
terminal on the device, the LSB address bit is programmable to permit two devices to be used in a system.
These two addresses are licensed I
To communicate with the TAS5026A, the I
addition to the 7-bit device address, an 8-bit register address is used to direct communication to the proper
register location within the device interface.

Read and write operations to the TAS5026A can be done using single byte or multiple byte data transfers.

2.5.1 Single-Byte Write

R/

8 Bit Register Address (N)A

W

8 Bit Register Data For

Address (N)

8 Bit Register Data For

AA

Address (N)

7 6 5 4 3 2 1 0

Figure 2−13. Typical I2C Sequence

2

C addresses and do not conflict with other licensed I2C audio devices.

2

C master uses 0011010 if CS0 = 0 and 0011011 if CS0 = 1. In

As shown in Figure 2−14, a single byte data write transfer begins with the master device transmitting a start
condition followed by the I
of the data transfer. For a write data transfer, the read/write bit is 0. After receiving the correct I

2

C device address and the read/write bit. The read/write bit determines the direction

2

address and the read/write bit, the TAS5026A device responds with an acknowledge bit. Next, the master
transmits the address byte or bytes corresponding to the TAS5026A internal memory address being
accessed. After receiving the address byte, the TAS5026A again responds with an acknowledge bit. Next, the
master device transmits the data byte to be written to the memory address being accessed. After receiving
the data byte, the TAS5026A again responds with an acknowledge bit. Finally, the master device transmits
a stop condition to complete the single byte data write transfer.

SLES068A—February 2003—Revised January 2004 TAS5026A

C device

23

Architecture Overview

Start

Condition

A6 A5 A4 A3 A2 A1 A0

I2C Device Address and

Read/Write Bit

2.5.2 Multiple-Byte Write

A multiple byte data write transfer is identical to a single byte data write transfer except that multiple data bytes
are transmitted by the master device to TAS5026A as shown in Figure 2−15. After receiving each data byte,
the TAS5026A responds with an acknowledge bit.

Start

Condition

A6 A5 A1 A0

I2C Device Address and

Read/Write Bit

Acknowledge Acknowledge Acknowledge

R/W

2.5.3 Single-Byte Read

As shown in Figure 2−16, a single byte data read transfer begins with the master device transmitting a start
condition followed by the I
by a read are actually done. Initially, a write is done to transfer the address byte or bytes of the internal memory
address to b e read. As a result, the read/write bit is 0. After receiving the TAS5026A address and the read/write
bit, the TAS5026A responds with an acknowledge bit. Also, after sending the internal memory address byte
or bytes, the master device transmits another start condition followed by the TAS5026A address and the
read/write bit again. This time the read/write bit is a 1 indicating a read transfer . After receiving the TAS5026A
and the read/write bit, the TAS5026A again responds with an acknowledge bit. Next, the TAS5026A transmits
the data byte from the memory address being read. After receiving the data byte, the master device transmits
a not acknowledge followed by a stop condition to complete the single byte data read transfer.

Start

Condition

Acknowledge Acknowledge Acknowledge

Acknowledge Acknowledge Acknowledge

R/W

ACK A7 A6 A5 A4 A3 A2 A1 A0 ACK D7 D6 D5 D4 D3 D2 D1 D0 ACK

Register Address Data Byte

Figure 2−14. Single-Byte Write Transfer

Acknowledge

ACK A7 A5 A1 A0 ACK D7 D6 D1 D0 ACK

A4 A3A6

Register Address Last Data Byte

First Data Byte

D7 D6 D1 D0 ACK

Other

Data Bytes

Figure 2−15. Multiple-Byte Write Transfer

2

C device address and the read/write bit. For the data read transfer, a write followed

Repeat Start Condition

Not

Acknowledge

Stop

Condition

Stop

Condition

A6 A5 A0 R/W ACK A7 A6 A5 A4 A0 ACK A6 A5 A0 ACK

I2C Device Address and

Read/Write Bit

2.5.4 Multiple-Byte Read

A multiple byte data read transfer is identical to a single byte data read transfer except that multiple data bytes
are transmitted by the TAS5026A to the master device as shown in Figure 2−17. Except for the last data byte,
the master device responds with an acknowledge bit after receiving each data byte.

24

Start

Condition

I2C Device Address and

Read/Write Bit

Acknowledge Acknowledge Acknowledge

A7 A6 A5

Register Address Other

R/WA1 A1

Register Address Data Byte

I2C Device Address and

Read/Write Bit

D7 D6 D1 D0 ACK

Figure 2−16. Single-Byte Read

Repeat Start Condition

Acknowledge

A6 A0 ACK

I2C Device Address and

Read/Write Bit

R/WA6 A0 R/W ACK A4 A0 ACK D7 D0 ACK

First Data Byte

D7 D6 D1 D0 ACK

Data Bytes

Last Data Byte

Figure 2−17. Multiple-Byte Read

SLES068A—February 2003—Revised January 2004TAS5026A

Condition

Not

Acknowledge

Stop

Stop

Condition

3 Serial Control Interface Register Definitions

Table 3−1 shows the register map for the TAS5026A. Default values in this section are in bold.

2

T able 3−1. I

ADDR HEX DESCRIPTION

00 General status register
01 Error status register
02 System control register 0
03 System control register 1
04 Error recovery register
05 Automute delay
06 DC-offset control register channel 1
07 DC-offset control register channel 2
08 DC-offset control register channel 3
09 DC-offset control register channel 4
0A DC-offset control register channel 5
0B DC-offset control register channel 6
0C Interchannel delay register channel 1
0D Interchannel delay register channel 2
0E Interchannel delay register channel 3
0F Interchannel delay register channel 4
10 Interchannel delay register channel 5
11 Interchannel delay register channel 6
12 Reserved
13 Volume control register channel 1
14 Volume control register channel 2
15 Volume control register channel 3
16 Volume control register channel 4
17 Volume control register channel 5
18 Volume control register channel 6
19 Individual channel mute

C Register Map

Serial Control Interface Register Definitions

The volume table is contained in Appendix A.
Default values are shown in bold in the following tables.

SLES068A—February 2003—Revised January 2004 TAS5026A

25

Serial Control Interface Register Definitions

3.1 General Status Register (0x00)

Table 3−2. General Status Register (Read Only)

D7 D6 D5 D4 D3 D2 D1 D0 FUNCTION

0 - - - - - - - No volume update is in progress.

1 - - - - - - - Volume update is in progress.

- 0 - - - - - - Always 0

- - 1 0 0 1 1 - Device identification code

- - - - - - - 0 Any valid signal is inactive (see status register (0x03)) (see Note 1).

- - - - - - - 1 No internal errors (all valid signals are high)

NOTE 1: This bit is reset automatically when one or more channels are active.

3.2 Error Status Register (0x01)

Table 3−3. Error Status Register

D7 D6 D5 D4 D3 D2 D1 D0 FUNCTION

1 - - - - - - - FS error has occurred

- 1 - - - - - - Control pin change has occurred

- - - 1 - - - - LRCLK error

- - - - 1 - - - MCLK_IN count error

- - - - - 1 - - DCLK phase error with respect to MCLK_IN

- - - - - - 1 - MCLK_IN phase error with respect to DCLK

- - - - - - - 1 PWM timing error

0 0 0 0 0 0 0 0 No errors—no control pins changed

NOTE 2: Write 00 hex to clear error indications in error status register.

3.3 System Control Register 0 (0x02)

Table 3−4. System Control Register 0

D7 D6 D5 D4 D3 D2 D1 D0 FUNCTION

0 0 - - - - - - Normal mode (in slave mode—quad speed detected if MCLK_IN = 128 Fs)

0 1 - - - - - - Double speed
1 0 - - - - - - Quad speed
1 1 - - - - - - Illegal

- - 0 - - - - - Use de-emphasis pin controls

- - 1 - - - - - Use de-emphasis I2C controls

- - - 0 0 - - - No de-emphasis

- - - 0 1 - - - De-emphasis for Fs = 32 kHz

- - - 1 0 - - - De-emphasis for Fs = 44.1 kHz

- - - 1 1 - - - De-emphasis for Fs = 48 kHz

- - - - - 0 0 0 16 bit, MSB first; right justified

- - - - - 0 0 1 20 bit, MSB first; right justified

- - - - - 0 1 0 24 bit, MSB first; right justified

- - - - - 0 1 1 16-bit I2S

- - - - - 1 0 0 20-bit I2S

- - - - - 1 0 1 24-bit I2S

- - - - - 1 1 0 16-bit MSB first

- - - - - 1 1 1 16-bit DSP Frame

26

SLES068A—February 2003—Revised January 2004TAS5026A

Serial Control Interface Register Definitions

3.4 System Control Register 1 (0x03)

Table 3−5. System Control Register 1

D7 D6 D5 D4 D3 D2 D1 D0 FUNCTION

0 - - - - - - - Reserved

- 0 - - - - - - Valid remains high during automute.

- 1 - - - - - - Valid goes low during automute.

- - 0 - - - - - Valid remains high during mute.

- - 1 - - - - - Valid goes low during mute.

- - - 0 - - - - Mute

- - - 1 - - - - Normal mode

- - - - 0 - - - Set error recovery delay at 6 µs

- - - - 1 - - - Set error recovery delay at 47 µs

- - - - - 0 - - Error recovery (forces error recovery initialization sequence)

- - - - - 1 - - Normal mode

- - - - - - 0 - Automute disabled

- - - - - - 1 - Automute enabled

- - - - - - - 1 Reserved

3.5 Error Recovery Register (0x04)

Table 3−6. Error Recovery Register

D7 D6 D5 D4 D3 D2 D1 D0 FUNCTION

1 1 − − − − − − Set to 11 under default conditions and when x00 is written into 0x1F

0 − − − − − − − if 0x84 is written into 0x1F –

Enable volume ramp up after an error recovery sequence initiated by the
ERR_RCVRY

1 − − − − − − − if 0x84 is written into 0x1F –

Disable volume ramp up after an error recovery sequence initiated by the
ERR_RCVRY

− 0 − − − − − − if 0x84 is written into 0x1F –
Enable volume ramp up after error recovery sequence initiated by register bits

D5–D0 of this register.

− 1 − − − − − − if 0x84 is written into 0x1F –
Enable volume ramp up after error recovery sequence initiated by register bits

D5–D0 of this register.

− − 0 − − − − − Put channel 6 into error recovery mode

− − − 0 − − − − Put channel 5 into error recovery mode

− − − − 0 − − − Put channel 4 into error recovery mode

− − − − − 0 − − Put channel 3 into error recovery mode

− − − − − − 0 − Put channel 2 into error recovery mode

− − − − − − − 0 Put channel 1 into error recovery mode

− − 1 1 1 1 1 1 Normal operation

terminal or the I2C error recovery command (register 0x03 bit D2).

terminal or the I2C error recovery command (register 0x03 bit D2)

SLES068A—February 2003—Revised January 2004 TAS5026A

27

Serial Control Interface Register Definitions

3.6 Automute Delay Register (0x05)

Table 3−7. Automute Delay Register

D7 D6 D5 D4 D3 D2 D1 D0 FUNCTION

0 0 0 0 - - - - Reserved

- - - - 0 0 0 0 Set automute delay at 5 ms

- - - - 0 0 0 1 Set automute delay at 10 ms

- - - - 0 0 1 0 Set automute delay at 15 ms

- - - - 0 0 1 1 Set automute delay at 20 ms

- - - - 0 1 0 0 Set automute delay at 25 ms

- - - - 0 1 0 1 Set automute delay at 30 ms

- - - - 0 1 1 0 Set automute delay at 35 ms

- - - - 0 1 1 1 Set automute delay at 40 ms

- - - - 1 - - 0 Set automute delay at 45 ms

- - - - 1 - - 1 Set automute delay at 50 ms

3.7 DC-Offset Control Registers (0x06−0x0B)

Channels 1, 2, 3, 4, 5, and 6 are mapped into (0x06, 0x07, 0x08, 0x09, 0x0A, and 0x0B).

Table 3−8. DC-Offset Control Registers

D7 D6 D5 D4 D3 D2 D1 D0 FUNCTION

1 0 0 0 0 0 0 0 Maximum correction for positive dc offset (–1.56% FS)
0 0 0 0 0 0 0 0 No dc-offset correction
0 1 1 1 1 1 1 1 Maximum correction for negative dc offset (1.56% FS)

3.8 Interchannel Delay Registers (0x0C−0x11)

Channels 1, 2, 3, 4, 5, and 6 are mapped into (0x0C, 0x0D, 0x0E, 0x0F, 0x10, and 0x11).
The first channel delay is set at 0. Each subsequent channel has a default value that is 76 DCLKs larger than

the preceding channel.

Table 3−9. Six Interchannel Delay Registers

D7 D6 D5 D4 D3 D2 D1 D0 FUNCTION

0 0 0 0 0 0 0 0 Minimum absolute delay, 0 DCLK cycles, default for channel 1
0 1 0 0 1 1 0 0 Default for channel 2
1 0 0 1 1 0 0 0 Default for channel 3
1 1 1 0 0 1 0 0 Default for channel 4
0 0 1 1 0 0 0 0 Default for channel 5
0 1 1 1 1 1 0 0 Default for channel 6

1 1 1 1 1 1 1 1 Maximum absolute delay, 255 DCLK cycles

28

SLES068A—February 2003—Revised January 2004TAS5026A

Serial Control Interface Register Definitions

3.9 Individual Channel Mute Register (0x19)

Table 3−10. Individual Channel Mute Register

D7 D6 D5 D4 D3 D2 D1 D0 FUNCTION

1 1 - - - - - - Reserved

- - 1 1 1 1 1 1 No channels are muted

- - - - - - - 0 Mute channel 1

- - - - - - 0 - Mute channel 2

- - - - - 0 - - Mute channel 3

- - - - 0 - - - Mute channel 4

- - - 0 - - - - Mute channel 5

- - 0 - - - - - Mute channel 6

SLES068A—February 2003—Revised January 2004 TAS5026A

29

Serial Control Interface Register Definitions

30

SLES068A—February 2003—Revised January 2004TAS5026A

System Procedures for Initialization, Changing Data Rates, and Switching Between Master and Slave Modes

4 System Procedures for Initialization, Changing Data Rates, and

Switching Between Master and Slave Modes

4.1 System Initialization

Reset is used during system initialization to hold the TAS5026A inactive while power (VDD), the master clock
(MCLK_IN), the device control, and the data signals become stable. The recommended initialization
sequence is to hold RESET
signals (MUTE

, PDN, M_S, ERR_RCVRY, DBSPD, and CS0) are stable.

low for 24 MCLK_IN cycles after VDD has reached 3 V and the other control

Figure 4−1 shows the recommended sequence and timing for the RESET

terminal relative to system VDD

voltage and MCLK.

3 V

VDD

RESET

24 MCLK_IN Cycles

MCLK

Figure 4−1. RESET During System Initialization

Within the first 2 ms following the low to high transition of the RESET
should be set in the serial data interface control register using the I

terminal, the serial data interface format

2

C serial control interface. If the data rate
setting is other than the setting specified by the DBSPD terminal, then the data rate should be set using the
DBSPD terminal or I

2

C interface within 2 ms, following the low to high transition of the RESET terminal.

2

The time available to set the I
extended using the ERR_RCVRY
inactive. Once the I

2

C control registers are set, the ERR_RCVRY terminal can be released and the T AS5026A
starts operation. Figure 4−2 shows how ERR_RCVRY
necessary to set the I

SLES068A—February 2003—Revised January 2004 TAS5026A

2

C registers following the low-to-high transition of the RESET terminal.

C registers following the low to high transition of the RESET terminal can be

terminal. While ERR_RCVRY is low, the TAS5026A outputs are held

terminal can be used to extend the interval as long as

31

System Procedures for Initialization, Changing Data Rates, and Switching Between Master and Slave Modes

E

MCLK

RESET

< 2 ms

RR_RCVRY

MUTE

ERR_RCVRY and MUTE can
be set at any time prior to 2 ms
following the low-to-high
transition of RESET

Wait a minimum of 100 µs

after the low-to-high

transition of RESET

Set serial interface format, data

rate, volume, ... via I2C

> 5 ms

Release ERR_RCVRY and
then MUTE
registers are programmed

when I2C

Volume ramp
up 120 ms

Figure 4−2. Extending the I2C Write Interval Following Low-to-High Transition of RESET Terminal

The operation of the TAS5026A can be tailored as desired to meet specific operating requirements by
adjusting the following:

• Volume

• Data sample rate

• Emphasis/deemphasis settings

• Individual channel mute

• Automute delay register

• DC-offset control registers

If desired, the TAS5026A can be set to perform an unmute sequence following the low-to-high transition of
the ERR_RCVRY

terminal or the error recovery I2C command (register X03 bit D2). This capability is set by

writing x7F to the individual error recovery register (x04) and an x84 to x1F (a feature enable register).

4.2 Data Sample Rate

If the master clock is well-behaved during the frequency transition (no MCLK_IN high or low clock periods less
than 20 ns), then a simple speed selection is performed by setting the DBSPD terminal or the serial control
register. If it is known at least 60 ms in advance that the sample rate changes, mute can be used to provide
a completely silent transition. The timing of this control sequence is shown in Figure 4−3 and Figure 4−4.

32

SLES068A—February 2003—Revised January 2004TAS5026A

System Procedures for Initialization, Changing Data Rates, and Switching Between Master and Slave Modes

Clock Transition

E

MCLK

MUTE

Terminal

DBSPD

Terminal

Change from a 96-kHz data rate

MCLK_IN = 24.576 MHz

Volume Ramp

Down 42 − 65 ms

Set within 2 ms

of transition

< 2 ms < 2 ms

> 5 ms

Change to a 48-kHz data rate

MCLK_IN = 12.288 MHz

Volume Ramp
Up 42 − 65 ms

Figure 4−3. Changing the Data Sample Rate Using the DBSPD Terminal

Clock Transition

MCLK

MUTE

Terminal

RR_RCVRY

Terminal

Change from a 96-kHz data rate

MCLK_IN = 24.576 MHz

Volume Ramp

Down 42 − 65 ms

< 2 ms

Set data rate via I2C

register 0x02, D7 and D6

Hold ERR_RCVRY low

to give additional timeset registers

Change to a 48-kHz data rate

MCLK_IN = 12.288 MHz

> 5 ms

Volume Ramp
Up 42 − 65 ms

< 2 ms

Figure 4−4. Changing the Data Sample Rate Using the I2C

However, if the master clock input can encounter a high clock or low clock period of less than 20 ns, then
RESET

should be applied during this time. There are two recommended control procedures for this case,
depending upon whether the DBSPD terminal or the serial control interface is used. These control sequences
are shown in Figure 4−5 and Figure 4−6.

Because this sequence employs the RESET

terminal, the internal register settings are set to the default

values.

SLES068A—February 2003—Revised January 2004 TAS5026A

33

System Procedures for Initialization, Changing Data Rates, and Switching Between Master and Slave Modes

E

Clock unstable during transition.

Figure 4−5 shows the procedure to change the data rate using the DBSPD terminal and then to restore the
register settings. In this example, the ERR_RCVRY
RESET

is released. This permits the system controller to have as much additional time as necessary to restore

terminal is used to hold off system re-initialization after

the register settings.
Once the data rate is set, the ERR_RCVRY

re-initializes.

HIGH and LOW intervals < 20 ns

Change from a 96-kHz data rate

MCLK_IN = 24.576 MHz

MCLK

MUTE

Terminal

Volume Ramp

Down 60 ms

RESET

Terminal

DBSPD

Terminal

and MUTE terminal signals are set high and the system

Change to a 48-kHz data rate

MCLK_IN = 12.288 MHz

> 5 ms

Volume Ramp

Up 120 ms

Wait a minimum of

100 µs to set DBSPD

RR_RCVRY

Terminal

ERR_RCVRY can be set at

any time within this interval

Wait a minimum of 100 µs after the

LOW to HIGH transition of RESET

< 2 ms

Restore register

settings via I2C

Release ERR_RCVRY and
then MUTE
registers are programmed

when I2C

Figure 4−5. Changing the Data Sample Rate With an Unstable MCLK_IN Using the DBSPD Terminal

Because this sequence employs the RESET

terminal, the internal register settings are set to the default

values.
Figure 4−5 shows the procedure to change the data rate using register 0x02 bits D7 and D6 and then to restore

the other register settings. In this example, the ERR_RCVRY terminal is used to hold off system re-initialization
after RESET
restore the register settings.

Once the data rate is set, the ERR_RCVRY

is released. This permits the system controller to have as much additional time as necessary to

and MUTE terminal signals are set high and the system

re-initializes.

34

SLES068A—February 2003—Revised January 2004TAS5026A

System Procedures for Initialization, Changing Data Rates, and Switching Between Master and Slave Modes

E

Clock unstable during transition.

HIGH and LOW intervals < 20 ns

MCLK

MUTE

Terminal

RESET

Terminal

RR_RCVRY

Terminal

Change from a 96-kHz data rate

MCLK_IN = 24.576 MHz

Volume Ramp

Down 60 ms

ERR_RCVRY can be set at

any time within this interval

Wait a minimum of 100 µs after the

LOW to HIGH transition of RESET

< 2 ms

Change to a 48-kHz data rate

MCLK_IN = 12.288 MHz

> 5 ms

Volume Ramp

Up 120 ms

Set data rate and

restore other

register settings

via I2C

Release ERR_RCVRY and
then MUTE
registers are programmed

when I2C

Figure 4−6. Changing the Data Sample Rate With an Unstable MCLK_IN Using the I2C

4.3 Changing Between Master and Slave Modes

The master and slave mode is set while the RESET terminal is active. Because this sequence employs the
RESET

Figure 4−7 shows the procedure to switch between master and slave modes and then restore the register
settings. In this example, the ERR_RCVRY
is released. This permits the system controller to have as much additional time as necessary to restore the
register settings.

Once the data rate is set, the ERR_RCVRY
re-initializes.

SLES068A—February 2003—Revised January 2004 TAS5026A

terminal the internal register settings are set to the default values.

terminal is used to hold off system re-initialization after RESET

and MUTE terminal signals are set high and the system

35

System Procedures for Initialization, Changing Data Rates, and Switching Between Master and Slave Modes

E

Clock unstable during transition.

MCLK

MUTE

Terminal

RESET

Terminal

M_S

Terminal

Change from Master Mode

Volume Ramp

Down 60 ms

Wait a minimum of

100 µs to set M_S

Change to Slave Mode

> 5 ms

Volume Ramp

Up 120 ms

< 2 ms

RR_RCVRY

Terminal

Release ERR_RCVRY and

ERR_RCVRY can be set at

any time within this interval

Wait a minimum of 100 µs after the

LOW to HIGH transition of RESET

then MUTE
registers are programmed

Restore register

settings via I2C

when I2C

Figure 4−7. Changing Between Master and Slave Clock Modes

36

SLES068A—February 2003—Revised January 2004TAS5026A

5 Specifications

Specifications

5.1 Absolute Maximum Ratings Over Operating Temperature Ranges (Unless
Otherwise Noted)

Digital supply voltage range: DVDD_CORE, DVDD_PWM, DVDD_RCL −0.3 V to 4.2 V. . . . . . . . . . . . . . . . . .

Analog supply voltage range: AVDD_PLL, ADD_OSC −0.3 V to 4.2 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Digital input voltage range, V

Operating free-air temperature, TAS5026A 0°C to 70°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Storage temperature range, T

ESD 2000 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

†

Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only , and
functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.

†

−0.3 V to DVDDX + 0.3 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

I

−65°C to 150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

stg

5.2 Recommended Operating Conditions

MIN TYP MAX UNIT

Supply voltage Digital DV

Supply current Digital

Power dissipation Digital
Supply voltage Analog AV

Supply current Analog

Power dissipation Analog

NOTES: 3. DVDD_CORE, DVDD_PWM, DVDD_RCL

4. If the clocks are turned off.

5. AVDD_PLL, AVDD_OSC

, See Note 1 3 3.3 3.6 V

DDX

Operating 60 mA
Power down, See Note 2 25 µA
Operating 200 mW
Power down 100 µW

, See Note 3 3 3.3 3.6 V

DDX

Operating 10 mA
Power down, See Note 2 25 µA
Operating 35 mW
Power down, See Note 2 100 µW

5.3 Electrical Characteristics Over Recommended Operating Conditions

5.3.1 Static Digital Specifications Over Recommended Operating Conditions (Unless

Otherwise Noted)

PARAMETER TEST CONDITIONS MIN MAX UNIT

V
V
V
V
I

IH
IL
OH
OL

lkg

High-level input voltage 2 DVDD1 V
Low-level input voltage 0 0.8 V
High-level output voltage IO = −1 mA 2.4 V
Low-level output voltage IO = 4 mA 0.4 V
Input leakage current −10 10 µA

5.3.2 Digital Interpolation Filter and PWM Modulator Over Recommended Operating

Conditions (Unless Otherwise Noted) (Fs = 48 kHz)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

Pass band 0 20 kHz
Pass band ripple ±0.012 dB
Stop band 24.1 kHz
Stop band attenuation 24.1 kHz to 152.3 kHz 50 dB
Group delay 700 µs
PWM modulation index (gain) 0.93%

SLES068A—February 2003—Revised January 2004 TAS5026A

37

Specifications

5.3.3 TAS5026A/TAS5110 System Performance Measured at the Speaker Terminals
Over Recommended Operating Conditions (Unless Otherwise Noted),
(Fs = 48 kHz)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

SNR (EIAJ) A-weighted 93 dB
Dynamic range A-weighted, -60 dB, f = 1 kHz, 20 Hz−20 kHz 94 dB
THD+N 0 dB, 1 kHz, 20 Hz−20 kHz 0.09%

5.4 Switching Characteristics

5.4.1 Command Sequence Timing

5.4.1.1 Reset Timing—RESET

CONTROL SIGNAL PARAMETERS OVER RECOMMENDED OPERATING CONDITIONS (UNLESS OTHERWISE NOTED)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

t

w(RESET)

t

p(VALID_LOW)

t

p(VALID_HIGH)

t

d(VOLUME)

Pulses duration, RESET active 50 ns
Propagation delay 1 µs
Propagation delay 4 5 ms
Delay time 42 65 ms

RESET

VALID 1−6

VOLUME 1−6

t

p(VALID_LOW)

t

w(RESET)

Figure 5−1. RESET Timing

t

d(VOLUME)

t

p(VALID_HIGH)

38

SLES068A—February 2003—Revised January 2004TAS5026A

5.4.1.2 Power-Down Timing—PDN

5.4.1.2.1 Long Recovery

CONTROL SIGNAL PARAMETERS OVER RECOMMENDED OPERATING CONDITIONS (UNLESS OTHERWISE NOTED)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

t

w(PDN)

t

d(R PDNR)

t

p(VALID_LOW)

t

p(VALID_HIGH)

t

d(VOLUME)

RESET

Pulse duration, PDN active 50 ns
Reset high to PDN rising edge 16 MCLKs ns

85 100 ms
42 65 ms

t

d(R PDNR)

PDN

t

w(PDN)

Specifications

1 µs

VALID 1−6

VOLUME 1−6

Normal
Operation

t

p(VALID_HIGH)

t

p(VALID_LOW)

t

d(VOLUME)

Figure 5−2. Power-Down and Power-Up Timing—RESET Preceding PDN

Normal
Operation

SLES068A—February 2003—Revised January 2004 TAS5026A

39

Specifications

5.4.1.2.2 Short Recovery

CONTROL SIGNAL PARAMETERS OVER RECOMMENDED OPERATING CONDITIONS (UNLESS OTHERWISE NOTED)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

t

w(PDN)

t

d(R PDNR)

t

p(VALID_LOW)

t

p(VALID_HIGH)

t

d(VOLUME)

RESET

Pulse duration, PDN active 50 ns
PDN high to reset rising edge 16 MCLKs ns

4 5 ms

42 65 ms

t

d(R PDNR)

PDN

t

w(PDN)

1 µs

VALID 1−6

VOLUME 1−6

Normal
Operation

t

p(VALID_HIGH)

t

p(VALID_LOW)

t

d(VOLUME)

Figure 5−3. Power-Down and Power-Up Timing—RESET Following PDN

5.4.1.3 Error Recovery Timing—ERR_RCVRY

CONTROL SIGNAL PARAMETERS OVER RECOMMENDED OPERATING CONDITIONS (UNLESS OTHERWISE NOTED)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

t

w(ER)

t

p(VALID_LOW)

t

p(VALID_HIGH)

Pulse duration, ERR_RCVRY active 5 MCLKs ns
Selectable for minimum or maximum 6 47 µs

4 5 ms

Normal
Operation

40

SLES068A—February 2003—Revised January 2004TAS5026A

ERR_RCVRY

t

w(ER)

Specifications

VALID 1−6

Normal
Operation

t

p(VALID_LOW)

t

p(VALID_HIGH)

Figure 5−4. Error Recovery Timing

5.4.1.4 MUTE Timing—MUTE

CONTROL SIGNAL PARAMETERS OVER RECOMMENDED OPERATING CONDITIONS (UNLESS OTHERWISE NOTED)

PARAMETER TEST CONDITIONS MIN TYP MAX UNIT

t

w(MUTE)

t

d(VOL)

VOLUME

MUTE

Pulse duration, PDN active 3 MCLKs ns

42 ms

t

w(MUTE)

Normal
Operation

VALID 1−6

Normal
Operation

t

d(VOL)

t

d(VOL)

Normal
Operation

Figure 5−5. Mute Timing

SLES068A—February 2003—Revised January 2004 TAS5026A

41

Specifications

5.4.2 Serial Audio Port

5.4.2.1 Serial Audio Ports Slave Mode Over Recommended Operating Conditions (Unless

Otherwise Noted)

PARAMETER MIN TYP MAX UNIT

f

(SCLK)

t

su(SDIN)

t

h(SDIN)

f

(LRCLK)

t

su(LRCLK)

5.4.2.2 Serial Audio Ports Master Mode, Load Conditions 50 pF Over Recommended

t

(MSD)

t

(MLRD)

Frequency, SCLK 12.288 MHz
SDIN setup time before SCLK rising edge 20 ns
SDIN hold time before SCLK rising edge 10 ns
LRCLK frequency 32 48 192 kHz
MCLK_IN duty cycle 50%
SCLK duty cycle 50%
LRCLK duty cycle 50%
LRCLK setup time before SCLK rising edge 20 ns
MCLK high and low time 20 ns

Operating Conditions (Unless Otherwise Noted)

PARAMETER MIN TYP MAX UNIT

MCLK_IN to SCLK 0 5 ns
MCLK_IN to LRCLK 0 5 ns

5.4.2.3 DSP Serial Interface Mode Over Recommended Operating Conditions (Unless

Otherwise Noted)

PARAMETER MIN TYP MAX UNIT

f

(SCLK)

t

d(FS)

t

w(FSHIGH

t

su(SDIN)

t

h(SDIN)

) Pulse duration, sync 1/(64×Fs) ns

SCLK

SDIN

SCLK frequency 12.288 MHz
Delay time, SCLK rising to Fs ns

SDIN and LRCLK setup time before SCLK falling edge 20 ns
SDIN and LRCLK hold time from SCLK falling edge 10 ns
SCLK duty cycle 50%

t

h(SDIN)

t

su(SDIN)

Figure 5−6. Right-Justified, I2S, Left-Justified Serial-Protocol Timing

42

SLES068A—February 2003—Revised January 2004TAS5026A

SCLK

t

su(LRCLK)

LRCLK

NOTE: Serial data is sampled with the rising edge of SCLK (setup time = 20 ns and hold time = 10 ns).

Figure 5−7. Right, Left, and I2S Serial-Mode Timing Requirement

SCLK

LRCLK

t

(MRLD)

Specifications

MCLK

SCLK

LRCLK

SDIN

t

(MSD)

t

su(LRCLK)

Figure 5−8. Serial Audio Ports Master-Mode Timing

t

h(LRCLK)

t

w(FSHIGH)

t

su(SDIN)

t

h(SDIN)

Figure 5−9. DSP Serial-Port Timing

SLES068A—February 2003—Revised January 2004 TAS5026A

43

Specifications

SCLK

LRCLK

SDIN

t

w(FSHIGH)

64 SCLKS

SCLK

SDIN

t

su(SDIN)

16 Bits

Left

Channel

= 20 ns

16 Bits

Right

Channel

32 Bits Unused

Figure 5−10. DSP Serial-Port Expanded Timing

t

h(SDIN)

= 10 ns

Figure 5−11. DSP Absolute Timing

44

SLES068A—February 2003—Revised January 2004TAS5026A

Specifications

PARAMETER

TEST CONDITIONS

UNIT

PARAMETER

TEST CONDITIONS

UNIT

5.4.3 Serial Control Port—I2C Operation

5.4.3.1 Timing Characteristics for I2C Interface Signals Over Recommended Operating
Conditions (Unless Otherwise Noted)

f

SCL

t

w(H)

t

w(L)

t

r

t

f

t

su1

t

h1

t

(buf)

t

su2

t

h2

t

su3

C

L

STANDARD

MODE

MIN MAX MIN MAX

Frequency, SCL 0 100 0 400 kHz
Pulse duration, SCL high 4 0.6 µs
Pulse duration, SCL low 4.7 1.3 µs
Rise time, SCL and SDA 1000 300 ns
Fall time, SCL and SDA 300 300 ns
Setup time, SDA to SCL 250 100 ns
Hold time, SCL to SDA 0 0 ns
Bus free time between stop and start condition 4.7 1.3 µs
Setup time, SCL to start condition 4.7 0.6 µs
Hold time, start condition to SCL 4 0.6 µs
Setup time, SCL to stop condition 4 0.6 µs
Load capacitance for each bus line 400 400 pF

FAST MODE

SCLK

SDA

SCLK

t

w(H)

t

w(L)

t

su

Figure 5−12. SCL and SDA Timing

t

h2

t

su2

t

r

t

h1

t

(buf)

t

su3

t

f

SLES068A—February 2003—Revised January 2004 TAS5026A

SDA

Start Condition Stop Condition

Figure 5−13. Start and Stop Conditions Timing

45

Specifications

46

SLES068A—February 2003—Revised January 2004TAS5026A

6 Application Information

Application Information

DVSS_PWM
DVDD_PWM
DVSS_RCL

DVDD_RCL

VREGC_CAP
VREGB_CAP
VREGA_CAP

AVSS_PLL

AVDD_PLL

Power Supply

PWM

Section

TAS5110

H-Bridge

SHUTDOWN

PWAP

PWBM

PWAM

PWBP

PWM_AP_1

VALID_1

PWM_AM_1

PWM Ch.

RESET

TAS5110

H-Bridge

SHUTDOWN

PWAP

PWBM

PWAM

PWBP

PWM_AP_2

VALID_2

PWM_AM_2

PWM Ch.

Signal

Processing

RESET

TAS5110

H-Bridge

SHUTDOWN

PWAP

PWBM

PWAM

PWBP

PWM AP_3

VALID_3

PWM AM_3

PWM Ch.

TAS5110

RESET

PWAP

PWM_AP_4

Auto Mute

De-Emphasis

H-Bridge

SHUTDOWN

PWBM

PWAM

PWBP

RESET

VALID_4

PWM_AM_4

Output Control

PWM Ch.

Soft Mute

Clip Detect

Soft Volume

Error Recovery

TAS5110

H-Bridge

SHUTDOWN

PWAP

PWBM

PWAM

PWBP

PWM_AP_5

VALID_5

PWM_AM_5

PWM Ch.

RESET

TAS5110

H-Bridge

SHUTDOWN

PWAP

PWBM

PWAM

PWBP

PWM_AP_6

VALID_6

PWM_AM_6

PWM Ch.

RESET

I/F

Serial

Control

SCL

SDA

CSO

P1.5/IA1/TDI

P1.4/SMCLK/TCK

MSP430

Reset,

Pwr Dwn

RESET

P1.0

and

PDN

P1.1

Status

P1.2

CLIP

P1.3

MUTE

ERR_RCVRY

P2.0

XTAL_IN

MCLK_IN

XTAL_OUT

CLKOUT

M_S

DSP

DA610

Clock,

PLL_FLT_1

PLL

PLL_FLT_2

and

Serial

SCLK

ACLKX

I/F

Data

LRCLK

MCLKOUT

AFSX

SDIN1

SDIN2

ALKX1

ALKX0

SDIN3

DM_SEL1

ALKX2

DBSPD

DM_SEL2

Figure 6−1. Typical TAS5026A Application

SLES068A—February 2003—Revised January 2004 TAS5026A

47

Application Information

6.1 Serial Audio Interface Clock Master and Slave Interface Configuration

6.1.1 Slave Configuration

Other Digital

Audio Sources

PCM1800

ADC

Left
Analog

Right
Analog

DOUT

BCK

LRCK

SYSCLK

Figure 6−2. TAS5026A Serial Audio Port—Slave-Mode Connection Diagram

6.1.2 Master Configuration

Other Digital

Audio Sources

DA610 DSP

(Master Mode)

ALKR0

ALKR1
ALKR2

ACLKR
AFSR

CLKIN

DA610 DSP

OSCI

OSCO

ALKX0
ALKX1
ALKX2

ACLKX

AFSX

CLKOUT

12.288

MHz XTAL

GND

TAS5026A

(Slave Mode)

XTALI

XTALO

SDIN1
SDIN2
SDIN3

SCLK
LRCK
MCLKO

TAS5026A

(Master Mode)

MCLKO

NC

Left
Analog

Right
Analog

PCM1800

ADC

SYSCLK

DOUT

BCK

LRCK

ALKR0

ALKR1
ALKR2

ACLKR
AFSR

CLKIN

ALKX0
ALKX1
ALKX2

ACLKX

AFSX

CLKOUT

12.288

MHz XTAL

GND

XTALI

XTALO

SDIN1
SDIN2
SDIN3

MCLKO

Figure 6−3. TAS5026A Serial Audio Port—Master-Mode Connection Diagram

SCLK
LRCK

MCLKO

48

SLES068A—February 2003—Revised January 2004TAS5026A

Mechanical Data

7 Mechanical Data

PAG (S-PQFP-G64) PLASTIC QUAD FLATPACK

49

64

0,50

1,05
0,95

48

0,27
0,17

33

32

17

1

7,50 TYP

10,20

SQ

9,80

12,20

SQ

11,80

16

M

0,08

0,05 MIN

Seating Plane

0,13 NOM

Gage Plane

0,25

0°−ā 7°

0,75
0,45

1,20 MAX

NOTES: A. All linear dimensions are in millimeters.

B. This drawing is subject to change without notice.
C. Falls within JEDEC MS-026

SLES068A—February 2003—Revised January 2004 TAS5026A

0,08

4040282/C 11/96

49

Mechanical Data

50

SLES068A—February 2003—Revised January 2004TAS5026A

Appendix A—Volume Table

VOLUME
SETTING

249 1111 1001 24
248 1111 1000 23.5
247 1111 0111 23
246 1111 0110 22.5
245 1111 0101 22
244 1111 0100 21.5
243 1111 0011 21
242 1111 0010 20.5
241 1111 0001 20
240 1111 0000 19.5
239 1110 1111 19
238 1110 1110 18.5
237 1110 1101 18
236 1110 1100 17.5
235 11101011 170
234 1110 1010 16.5
233 1110 1001 16
232 1110 1000 15.5
231 1110 0111 15
230 1110 0110 14.5
229 1110 0101 14
228 1110 0100 13.5
227 11100011 13
226 1110 0010 12.5
225 1110 0001 12
224 1110 0000 11.5
223 1101 1111 11
222 1101 1110 10.5
221 1101 1101 10
220 1101 1100 9.5
219 1101 1011 9
218 11011010 8.5
217 11011001 8
216 11011000 7.5
215 1101 0111 7
214 1101 0110 6.5
213 11010101 6
212 11010100 5.5
211 11010011 5
210 11010010 4.5
209 11010001 4
208 11010000 3.5
207 1100 1111 3
206 1100 1110 2.5

REGISTER VOLUME

(BIN)

D7 − D0

GAIN dB

Appendix A—Volume Table

VOLUME
SETTING

205 1100 1101 2
204 1100 1100 1.5
203 1100 1011 1
202 11001010 0.5
201 11001001 0
200 11001000 −0.5
199 1100 0111 −1
198 1100 0110 −1.5
197 11000101 −2
196 11000100 −2.5
195 1100 0011 −3
194 11000010 −3.5
193 11000001 −4
192 11000000 −4.5
191 1011 1111 −5
190 1011 1110 −5.5
189 1011 1101 −6
188 1011 1100 −6.5
187 1011 1011 −7
186 10111010 −7.5
185 10111001 −8
184 10111000 −8.5
183 1011 0111 −9
182 1011 0110 −9.5
181 10110101 −10
180 10110100 −10.5
179 1011 0011 −11
178 10110010 −11.5
177 10110001 −12
176 10110000 −12.5
175 1010 1111 −13
174 1010 1110 −13.5
173 1010 1101 −14
172 1010 1100 −14.5
171 1010 1011 −15
170 1010 1010 −15.5
169 1010 1001 −16
168 1010 1000 −16.5
167 1010 0111 −17
166 1010 0110 −17.5
165 1010 0101 −18
164 1010 0100 −18.5
163 1010 0011 −19
162 1010 0010 −19.5

REGISTER VOLUME

(BIN)

D7 − D0

GAIN dB

SLES068A—February 2003—Revised January 2004 TAS5026A

51

Appendix A—Volume Table

VOLUME
SETTING

161 1010 0001 −20
160 1010 0000 −20.5
159 1001 1111 −21
158 1001 1110 −21.5
157 1001 1101 −22
156 1001 1100 −22.5
155 1001 1011 −23
154 1001 1010 −23.5
153 1001 1001 −24
152 1001 1000 −24.5
151 1001 0111 −25
150 1001 0110 −25.5
149 1001 0101 −26
148 1001 0100 −26.5
147 1001 0011 −27
146 1001 0010 −27.5
145 1001 0001 −28
144 1001 0000 −28.5
143 1000 1111 −29
142 1000 1110 −29.5
141 1000 1101 −30
140 1000 1100 −30.5
139 1000 1011 −31
138 1000 1010 −31.5
137 1000 1001 −32
136 1000 1000 −32.5
135 1000 0111 −33
134 1000 0110 −33.5
133 1000 0101 −34
132 1000 0100 −34.5
131 1000 0011 −35
130 1000 0010 −35.5
129 1000 0001 −36
128 1000 0000 −36.5
127 0111 1111 −37
126 0111 1110 −37.5
125 01111101 −38
124 01111100 −38.5
123 01111011 −39
122 0111 1010 −39.5
121 0111 1001 −40
120 0111 1000 −40.5

119 01110111 −41
118 0111 0110 −41.5
117 0111 0101 −42

REGISTER VOLUME

(BIN)

D7 − D0

GAIN dB

VOLUME

SETTING

116 0111 0100 −42.5
115 0111 0011 −43
114 0111 0010 −43.5
113 0111 0001 −44
112 0111 0000 −44.5
111 0110 1111 −45

110 0110 1110 −45.5
109 0110 1101 −46
108 0110 1100 −46.5
107 0110 1011 −47
106 01101010 −47.5
105 01101001 −48
104 01101000 −48.5
103 0110 0111 −49
102 0110 0110 −49.5
101 01100101 −50
100 01100100 −50.5

99 0110 0011 −51
98 0110 0010 −51.5
97 0110 0001 −52
96 0110 0000 −52.5
95 0101 1111 −53
94 01011110 −53.5
93 0101 1101 −54
92 0101 1100 −54.5
91 0101 1011 −55
90 0101 1010 −55.5
89 0101 1001 −56
88 0101 1000 −56.5
87 01010111 −57
86 0101 0110 −57.5
85 0101 0101 −58
84 0101 0100 −58.5
83 0101 0011 −59
82 0101 0010 −59.5
81 0101 0001 −60
80 0101 0000 −60.5
79 0100 1111 −61
78 01001110 −61.5
77 0100 1101 −62
76 0100 1100 −62.5
75 0100 1011 −63
74 0100 1010 −63.5
73 0100 1001 −64
72 0100 1000 −64.5

REGISTER VOLUME

(BIN)

D7 − D0

GAIN dB

52

SLES068A—February 2003—Revised January 2004TAS5026A

Appendix A—Volume Table

VOLUME
SETTING

71 01000111 −65
70 0100 0110 −65.5
69 0100 0101 −66
68 0100 0100 −66.5
67 0100 0011 −67
66 0100 0010 −67.5
65 0100 0001 −68
64 0100 0000 −68.5
63 0011 1111 −69
62 0011 1110 −69.5
61 0011 1101 −70
60 0011 1100 −70.5
59 0011 1011 −71
58 0011 1010 −71.5
57 0011 1001 −72
56 0011 1000 −72.5
55 0011 0111 −73
54 0011 0110 −73.5
53 0011 0101 −74
52 0011 0100 −74.5
51 0011 0011 −75
50 0011 0010 −75.5
49 0011 0001 −76
48 0011 0000 −76.6
47 0010 1111 −77
46 00101110 −77.5
45 0010 1101 −78
44 0010 1100 −78.5
43 0010 1011 −79
42 0010 1010 −79.6
41 0010 1001 −80.1
40 0010 1000 −80.6
39 00100111 −81.1
38 0010 0110 −81.5
37 0010 0101 −82.1

REGISTER VOLUME

(BIN)

D7 − D0

GAIN dB

VOLUME
SETTING

36 0010 0100 −82.6
35 0010 0011 −83
34 0010 0010 −83.5
33 0010 0001 −84
32 0010 0000 −84.6
31 0001 1111 −85.1
30 00011110 −85.8
29 0001 1101 −86.1
28 0001 1100 −86.8
27 0001 1011 −87.2
26 0001 1010 −87.5
25 0001 1001 −88.4
24 0001 1000 −88.8
23 00010111 −89.3
22 0001 0110 −89.8
21 0001 0101 −90.3
20 0001 0100 −90.9
19 0001 0011 −91.5
18 0001 0010 −92.1
17 0001 0001 −92.8
16 0001 0000 −93.6
15 0000 1111 −94.4
14 00001110 −95.3
13 0000 1101 −96.3
12 0000 1100 −97.5
11 0000 1011 −98.8
10 0000 1010 −100.4

9 0000 1001 −102.4
8 0000 1000 −104.9
7 0000 0111 −108.4
6 0000 0110 −114.4
5 0000 0101 MUTE
4 0000 0100 MUTE
3 0000 0011 MUTE
2 0000 0010 MUTE
1 0000 0001 MUTE
0 0000 0000 MUTE

REGISTER VOLUME

(BIN)

D7 − D0

GAIN dB

SLES068A—February 2003—Revised January 2004 TAS5026A

53

Appendix A—Volume Table

54

SLES068A—February 2003—Revised January 2004TAS5026A

PACKAGE OPTION ADDENDUM

www.ti.com

11-Feb-2005

PACKAGING INFORMATION

Orderable Device Status

(1)

Package

Type

Package

Drawing

Pins Package

Qty

Eco Plan

TAS5026APAG ACTIVE TQFP PAG 64 160 Green (RoHS &

no Sb/Br)

TAS5026APAGR ACTIVE TQFP PAG 64 1500 None CU NIPDAU Level-2-235C-1 YEAR

TAS5026APAGRG4 ACTIVE TQFP PAG 64 1500 Green (RoHS &

no Sb/Br)

(1)

The marketing status values are defined as follows:

ACTIVE: Product device recommended for new designs.
LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect.
NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in

a new design.

PREVIEW: Device has been announced but is not in production. Samples may or may not be available.
OBSOLETE: TI has discontinued the production of the device.

(2)

Eco Plan - May not be currently available - please check http://www.ti.com/productcontent for the latest availability information and additional

product content details.

None: Not yet available Lead (Pb-Free).
Pb-Free (RoHS): TI's terms "Lead-Free" or "Pb-Free" mean semiconductor products that are compatible with the current RoHS requirements

for all 6 substances, including the requirement that lead not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered
at high temperatures, TI Pb-Free products are suitable for use in specified lead-free processes.
Green (RoHS & no Sb/Br): TI defines "Green" to mean "Pb-Free" and in addition, uses package materials that do not contain halogens,
including bromine (Br) or antimony (Sb) above 0.1% of total product weight.

(2)

Lead/Ball Finish MSL Peak Temp

CU NIPDAU Level-4-260C-72 HR

CU NIPDAU Level-4-260C-72 HR

(3)

(3)

MSL, Peak Temp. -- The Moisture Sensitivity Level rating according to the JEDECindustry standard classifications, and peak solder

temperature.

Important Information and Disclaimer:The information provided on this page represents TI's knowledge and belief as of the date that it is
provided. TI bases its knowledge and belief on information provided by third parties, and makes no representation or warranty as to the
accuracy of such information. Efforts are underway to better integrate information from third parties. TI has taken and continues to take
reasonable steps to provide representative and accurate information but may not have conducted destructive testing or chemical analysis on
incoming materials and chemicals. TI and TI suppliers consider certain information to be proprietary, and thus CAS numbers and other limited
information may not be available for release.

In no event shall TI's liability arising out of such information exceed the total purchase price of the TI part(s) at issue in this document sold by TI
to Customer on an annual basis.

Addendum-Page 1

MECHANICAL DATA

MTQF006A – JANUARY 1995 – REVISED DECEMBER 1996

PAG (S-PQFP-G64) PLASTIC QUAD FLATPACK

49

64

0,50

1,05

0,95

48

0,27
0,17

33

32

17

1

7,50 TYP

10,20

SQ

9,80

12,20

SQ

11,80

16

M

0,08

0,05 MIN

Seating Plane

0,13 NOM

Gage Plane

0,25

0°–7°

0,75
0,45

1,20 MAX

NOTES: A. All linear dimensions are in millimeters.

B. This drawing is subject to change without notice.
C. Falls within JEDEC MS-026

0,08

4040282/C 11/96

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

1
