TEXAS INSTRUMENTS-PRODUCTION DATA
Stellaris® LM3S1165 Microcontroller
DATA SHEET
DS-LM3S1165-7787
Copyright © 2007-2010 Texas Instruments
Incorporated
Copyright
Copyright ©2007-2010 Texas Instruments Incorporated All rights reserved. Stellaris and StellarisWare are registered trademarks of Texas Instruments
Incorporated. ARM and Thumb are registered trademarks and Cortex is a trademark of ARM Limited. Other names and brands may be claimed as the
property of others.
PRODUCTION DATA information is current as of publication date. Products conform to specications per the terms of Texas Instruments standard
warranty. Production processing does not necessarily include testing of all parameters.
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas Instruments semiconductor
products and disclaimers thereto appears at the end of this data sheet.
Texas Instruments Incorporated
108 Wild Basin, Suite 350
Austin, TX 78746
http://www.ti.com/stellaris
http://www-k.ext.ti.com/sc/technical-support/product-information-centers.htm
Texas Instruments-Production Data
September 04, 20102
Stellaris® LM3S1165 Microcontroller
Table of Contents
Revision History ............................................................................................................................. 23
About This Document .................................................................................................................... 27
Audience .............................................................................................................................................. 27
About This Manual ................................................................................................................................ 27
Related Documents ............................................................................................................................... 27
Documentation Conventions .................................................................................................................. 28
1 Architectural Overview .......................................................................................... 30
1.1 Product Features .......................................................................................................... 30
1.2 Target Applications ........................................................................................................ 38
1.3 High-Level Block Diagram ............................................................................................. 38
1.4 Functional Overview ...................................................................................................... 40
1.4.1 ARM Cortex™-M3 ......................................................................................................... 40
1.4.2 Motor Control Peripherals .............................................................................................. 41
1.4.3 Analog Peripherals ........................................................................................................ 41
1.4.4 Serial Communications Peripherals ................................................................................ 42
1.4.5 System Peripherals ....................................................................................................... 43
1.4.6 Memory Peripherals ...................................................................................................... 44
1.4.7 Additional Features ....................................................................................................... 45
1.4.8 Hardware Details .......................................................................................................... 45
2 The Cortex-M3 Processor ...................................................................................... 46
2.1 Block Diagram .............................................................................................................. 47
2.2 Overview ...................................................................................................................... 48
2.2.1 System-Level Interface .................................................................................................. 48
2.2.2 Integrated Configurable Debug ...................................................................................... 48
2.2.3 Trace Port Interface Unit (TPIU) ..................................................................................... 49
2.2.4 Cortex-M3 System Component Details ........................................................................... 49
2.3 Programming Model ...................................................................................................... 50
2.3.1 Processor Mode and Privilege Levels for Software Execution ........................................... 50
2.3.2 Stacks .......................................................................................................................... 50
2.3.3 Register Map ................................................................................................................ 51
2.3.4 Register Descriptions .................................................................................................... 52
2.3.5 Exceptions and Interrupts .............................................................................................. 65
2.3.6 Data Types ................................................................................................................... 65
2.4 Memory Model .............................................................................................................. 65
2.4.1 Memory Regions, Types and Attributes ........................................................................... 67
2.4.2 Memory System Ordering of Memory Accesses .............................................................. 67
2.4.3 Behavior of Memory Accesses ....................................................................................... 67
2.4.4 Software Ordering of Memory Accesses ......................................................................... 68
2.4.5 Bit-Banding ................................................................................................................... 69
2.4.6 Data Storage ................................................................................................................ 71
2.4.7 Synchronization Primitives ............................................................................................. 72
2.5 Exception Model ........................................................................................................... 73
2.5.1 Exception States ........................................................................................................... 73
2.5.2 Exception Types ............................................................................................................ 74
2.5.3 Exception Handlers ....................................................................................................... 77
Texas Instruments-Production Data
3September 04, 2010
Table of Contents
2.5.4 Vector Table .................................................................................................................. 77
2.5.5 Exception Priorities ....................................................................................................... 78
2.5.6 Interrupt Priority Grouping .............................................................................................. 79
2.5.7 Exception Entry and Return ........................................................................................... 79
2.6 Fault Handling .............................................................................................................. 81
2.6.1 Fault Types ................................................................................................................... 82
2.6.2 Fault Escalation and Hard Faults .................................................................................... 82
2.6.3 Fault Status Registers and Fault Address Registers ........................................................ 83
2.6.4 Lockup ......................................................................................................................... 83
2.7 Power Management ...................................................................................................... 83
2.7.1 Entering Sleep Modes ................................................................................................... 84
2.7.2 Wake Up from Sleep Mode ............................................................................................ 84
2.8 Instruction Set Summary ............................................................................................... 85
3 Cortex-M3 Peripherals ........................................................................................... 88
3.1 Functional Description ................................................................................................... 88
3.1.1 System Timer (SysTick) ................................................................................................. 88
3.1.2 Nested Vectored Interrupt Controller (NVIC) .................................................................... 89
3.1.3 System Control Block (SCB) .......................................................................................... 91
3.1.4 Memory Protection Unit (MPU) ....................................................................................... 91
3.2 Register Map ................................................................................................................ 96
3.3 System Timer (SysTick) Register Descriptions ................................................................ 98
3.4 NVIC Register Descriptions .......................................................................................... 102
3.5 System Control Block (SCB) Register Descriptions ........................................................ 115
3.6 Memory Protection Unit (MPU) Register Descriptions .................................................... 144
4 JTAG Interface ...................................................................................................... 154
4.1 Block Diagram ............................................................................................................ 155
4.2 Functional Description ................................................................................................. 155
4.2.1 JTAG Interface Pins ..................................................................................................... 155
4.2.2 JTAG TAP Controller ................................................................................................... 157
4.2.3 Shift Registers ............................................................................................................ 158
4.2.4 Operational Considerations .......................................................................................... 158
4.3 Initialization and Configuration ..................................................................................... 161
4.4 Register Descriptions .................................................................................................. 161
4.4.1 Instruction Register (IR) ............................................................................................... 161
4.4.2 Data Registers ............................................................................................................ 163
5 System Control ..................................................................................................... 166
5.1 Functional Description ................................................................................................. 166
5.1.1 Device Identification .................................................................................................... 166
5.1.2 Reset Control .............................................................................................................. 166
5.1.3 Power Control ............................................................................................................. 169
5.1.4 Clock Control .............................................................................................................. 170
5.1.5 System Control ........................................................................................................... 176
5.2 Initialization and Configuration ..................................................................................... 177
5.3 Register Map .............................................................................................................. 177
5.4 Register Descriptions .................................................................................................. 179
6 Hibernation Module .............................................................................................. 232
6.1 Block Diagram ............................................................................................................ 233
Texas Instruments-Production Data
September 04, 20104
Stellaris® LM3S1165 Microcontroller
6.2 Functional Description ................................................................................................. 233
6.2.1 Register Access Timing ............................................................................................... 233
6.2.2 Clock Source .............................................................................................................. 234
6.2.3 Battery Management ................................................................................................... 235
6.2.4 Real-Time Clock .......................................................................................................... 236
6.2.5 Non-Volatile Memory ................................................................................................... 236
6.2.6 Power Control ............................................................................................................. 236
6.2.7 Initiating Hibernate ...................................................................................................... 237
6.2.8 Interrupts and Status ................................................................................................... 237
6.3 Initialization and Configuration ..................................................................................... 237
6.3.1 Initialization ................................................................................................................. 238
6.3.2 RTC Match Functionality (No Hibernation) .................................................................... 238
6.3.3 RTC Match/Wake-Up from Hibernation ......................................................................... 238
6.3.4 External Wake-Up from Hibernation .............................................................................. 238
6.3.5 RTC/External Wake-Up from Hibernation ...................................................................... 239
6.4 Register Map .............................................................................................................. 239
6.5 Register Descriptions .................................................................................................. 239
7 Internal Memory ................................................................................................... 252
7.1 Block Diagram ............................................................................................................ 252
7.2 Functional Description ................................................................................................. 252
7.2.1 SRAM Memory ............................................................................................................ 252
7.2.2 Flash Memory ............................................................................................................. 253
7.3 Flash Memory Initialization and Configuration ............................................................... 254
7.3.1 Flash Programming ..................................................................................................... 254
7.3.2 Nonvolatile Register Programming ............................................................................... 255
7.4 Register Map .............................................................................................................. 256
7.5 Flash Register Descriptions (Flash Control Offset) ......................................................... 257
7.6 Flash Register Descriptions (System Control Offset) ...................................................... 265
8 General-Purpose Input/Outputs (GPIOs) ........................................................... 278
8.1 Functional Description ................................................................................................. 278
8.1.1 Data Control ............................................................................................................... 279
8.1.2 Interrupt Control .......................................................................................................... 280
8.1.3 Mode Control .............................................................................................................. 281
8.1.4 Commit Control ........................................................................................................... 281
8.1.5 Pad Control ................................................................................................................. 281
8.1.6 Identification ............................................................................................................... 282
8.2 Initialization and Configuration ..................................................................................... 282
8.3 Register Map .............................................................................................................. 283
8.4 Register Descriptions .................................................................................................. 285
9 General-Purpose Timers ...................................................................................... 320
9.1 Block Diagram ............................................................................................................ 321
9.2 Functional Description ................................................................................................. 322
9.2.1 GPTM Reset Conditions .............................................................................................. 322
9.2.2 32-Bit Timer Operating Modes ...................................................................................... 322
9.2.3 16-Bit Timer Operating Modes ...................................................................................... 323
9.3 Initialization and Configuration ..................................................................................... 327
9.3.1 32-Bit One-Shot/Periodic Timer Mode ........................................................................... 327
9.3.2 32-Bit Real-Time Clock (RTC) Mode ............................................................................. 328
Texas Instruments-Production Data
5September 04, 2010
Table of Contents
9.3.3 16-Bit One-Shot/Periodic Timer Mode ........................................................................... 328
9.3.4 16-Bit Input Edge Count Mode ..................................................................................... 329
9.3.5 16-Bit Input Edge Timing Mode .................................................................................... 329
9.3.6 16-Bit PWM Mode ....................................................................................................... 330
9.4 Register Map .............................................................................................................. 330
9.5 Register Descriptions .................................................................................................. 331
10 Watchdog Timer ................................................................................................... 356
10.1 Block Diagram ............................................................................................................ 357
10.2 Functional Description ................................................................................................. 357
10.3 Initialization and Configuration ..................................................................................... 358
10.4 Register Map .............................................................................................................. 358
10.5 Register Descriptions .................................................................................................. 359
11 Analog-to-Digital Converter (ADC) ..................................................................... 380
11.1 Block Diagram ............................................................................................................ 380
11.2 Functional Description ................................................................................................. 381
11.2.1 Sample Sequencers .................................................................................................... 381
11.2.2 Module Control ............................................................................................................ 382
11.2.3 Hardware Sample Averaging Circuit ............................................................................. 383
11.2.4 Analog-to-Digital Converter .......................................................................................... 383
11.2.5 Differential Sampling ................................................................................................... 383
11.2.6 Test Modes ................................................................................................................. 385
11.2.7 Internal Temperature Sensor ........................................................................................ 386
11.3 Initialization and Configuration ..................................................................................... 386
11.3.1 Module Initialization ..................................................................................................... 386
11.3.2 Sample Sequencer Configuration ................................................................................. 387
11.4 Register Map .............................................................................................................. 387
11.5 Register Descriptions .................................................................................................. 388
12 Universal Asynchronous Receivers/Transmitters (UARTs) ............................. 417
12.1 Block Diagram ............................................................................................................ 418
12.2 Functional Description ................................................................................................. 418
12.2.1 Transmit/Receive Logic ............................................................................................... 418
12.2.2 Baud-Rate Generation ................................................................................................. 419
12.2.3 Data Transmission ...................................................................................................... 420
12.2.4 Serial IR (SIR) ............................................................................................................. 420
12.2.5 FIFO Operation ........................................................................................................... 421
12.2.6 Interrupts .................................................................................................................... 421
12.2.7 Loopback Operation .................................................................................................... 422
12.2.8 IrDA SIR block ............................................................................................................ 422
12.3 Initialization and Configuration ..................................................................................... 422
12.4 Register Map .............................................................................................................. 423
12.5 Register Descriptions .................................................................................................. 424
13 Synchronous Serial Interface (SSI) .................................................................... 458
13.1 Block Diagram ............................................................................................................ 458
13.2 Functional Description ................................................................................................. 459
13.2.1 Bit Rate Generation ..................................................................................................... 459
13.2.2 FIFO Operation ........................................................................................................... 459
13.2.3 Interrupts .................................................................................................................... 459
Texas Instruments-Production Data
September 04, 20106
Stellaris® LM3S1165 Microcontroller
13.2.4 Frame Formats ........................................................................................................... 460
13.3 Initialization and Configuration ..................................................................................... 467
13.4 Register Map .............................................................................................................. 468
13.5 Register Descriptions .................................................................................................. 469
14 Inter-Integrated Circuit (I2C) Interface ................................................................ 495
14.1 Block Diagram ............................................................................................................ 496
14.2 Functional Description ................................................................................................. 496
14.2.1 I2C Bus Functional Overview ........................................................................................ 496
14.2.2 Available Speed Modes ............................................................................................... 498
14.2.3 Interrupts .................................................................................................................... 499
14.2.4 Loopback Operation .................................................................................................... 500
14.2.5 Command Sequence Flow Charts ................................................................................ 500
14.3 Initialization and Configuration ..................................................................................... 507
14.4 Register Map .............................................................................................................. 508
14.5 Register Descriptions (I2C Master) ............................................................................... 509
14.6 Register Descriptions (I2C Slave) ................................................................................. 522
15 Analog Comparator .............................................................................................. 531
15.1 Block Diagram ............................................................................................................ 531
15.2 Functional Description ................................................................................................. 531
15.2.1 Internal Reference Programming .................................................................................. 532
15.3 Initialization and Configuration ..................................................................................... 533
15.4 Register Map .............................................................................................................. 533
15.5 Register Descriptions .................................................................................................. 534
16 Pulse Width Modulator (PWM) ............................................................................ 542
16.1 Block Diagram ............................................................................................................ 543
16.2 Functional Description ................................................................................................. 544
16.2.1 PWM Timer ................................................................................................................. 544
16.2.2 PWM Comparators ...................................................................................................... 544
16.2.3 PWM Signal Generator ................................................................................................ 545
16.2.4 Dead-Band Generator ................................................................................................. 546
16.2.5 Interrupt/ADC-Trigger Selector ..................................................................................... 546
16.2.6 Synchronization Methods ............................................................................................ 547
16.2.7 Fault Conditions .......................................................................................................... 547
16.2.8 Output Control Block ................................................................................................... 547
16.3 Initialization and Configuration ..................................................................................... 547
16.4 Register Map .............................................................................................................. 548
16.5 Register Descriptions .................................................................................................. 550
17 Pin Diagram .......................................................................................................... 580
18 Signal Tables ........................................................................................................ 582
18.1 100-Pin LQFP Package Pin Tables ............................................................................... 582
18.2 108-Pin BGA Package Pin Tables ................................................................................ 594
18.3 Connections for Unused Signals ................................................................................... 606
19 Operating Characteristics ................................................................................... 608
20 Electrical Characteristics .................................................................................... 609
20.1 DC Characteristics ...................................................................................................... 609
20.1.1 Maximum Ratings ....................................................................................................... 609
Texas Instruments-Production Data
7September 04, 2010
Table of Contents
20.1.2 Recommended DC Operating Conditions ...................................................................... 609
20.1.3 On-Chip Low Drop-Out (LDO) Regulator Characteristics ................................................ 610
20.1.4 GPIO Module Characteristics ....................................................................................... 610
20.1.5 Power Specifications ................................................................................................... 610
20.1.6 Flash Memory Characteristics ...................................................................................... 612
20.1.7 Hibernation ................................................................................................................. 612
20.2 AC Characteristics ....................................................................................................... 612
20.2.1 Load Conditions .......................................................................................................... 612
20.2.2 Clocks ........................................................................................................................ 613
20.2.3 JTAG and Boundary Scan ............................................................................................ 614
20.2.4 Reset ......................................................................................................................... 616
20.2.5 Sleep Modes ............................................................................................................... 618
20.2.6 Hibernation Module ..................................................................................................... 618
20.2.7 General-Purpose I/O (GPIO) ........................................................................................ 619
20.2.8 Analog-to-Digital Converter .......................................................................................... 619
20.2.9 Synchronous Serial Interface (SSI) ............................................................................... 620
20.2.10 Inter-Integrated Circuit (I2C) Interface ........................................................................... 622
20.2.11 Analog Comparator ..................................................................................................... 623
A Serial Flash Loader .............................................................................................. 624
A.1 Serial Flash Loader ..................................................................................................... 624
A.2 Interfaces ................................................................................................................... 624
A.2.1 UART ......................................................................................................................... 624
A.2.2 SSI ............................................................................................................................. 624
A.3 Packet Handling .......................................................................................................... 625
A.3.1 Packet Format ............................................................................................................ 625
A.3.2 Sending Packets ......................................................................................................... 625
A.3.3 Receiving Packets ....................................................................................................... 625
A.4 Commands ................................................................................................................. 626
A.4.1 COMMAND_PING (0X20) ............................................................................................ 626
A.4.2 COMMAND_GET_STATUS (0x23) ............................................................................... 626
A.4.3 COMMAND_DOWNLOAD (0x21) ................................................................................. 626
A.4.4 COMMAND_SEND_DATA (0x24) ................................................................................. 627
A.4.5 COMMAND_RUN (0x22) ............................................................................................. 627
A.4.6 COMMAND_RESET (0x25) ......................................................................................... 627
B Register Quick Reference ................................................................................... 629
C Ordering and Contact Information ..................................................................... 651
C.1 Ordering Information .................................................................................................... 651
C.2 Part Markings .............................................................................................................. 651
C.3 Kits ............................................................................................................................. 652
C.4 Support Information ..................................................................................................... 652
D Package Information ............................................................................................ 653
D.1 108-Ball BGA Package ................................................................................................ 653
D.1.1 Package Dimensions ................................................................................................... 653
D.1.2 Tray Dimensions ......................................................................................................... 655
D.1.3 Tape and Reel Dimensions .......................................................................................... 656
D.2 100-Pin LQFP Package ............................................................................................... 657
D.2.1 Package Dimensions ................................................................................................... 657
Texas Instruments-Production Data
September 04, 20108
Stellaris® LM3S1165 Microcontroller
D.2.2 Tray Dimensions ......................................................................................................... 659
D.2.3 Tape and Reel Dimensions .......................................................................................... 660
Texas Instruments-Production Data
9September 04, 2010
Table of Contents
List of Figures
Figure 1-1. Stellaris®LM3S1165 Microcontroller High-Level Block Diagram ............................. 39
Figure 2-1. CPU Block Diagram ............................................................................................. 48
Figure 2-2. TPIU Block Diagram ............................................................................................ 49
Figure 2-3. Cortex-M3 Register Set ........................................................................................ 51
Figure 2-4. Bit-Band Mapping ................................................................................................ 71
Figure 2-5. Data Storage ....................................................................................................... 72
Figure 2-6. Vector table ......................................................................................................... 78
Figure 2-7. Exception Stack Frame ........................................................................................ 80
Figure 3-1. SRD Use Example ............................................................................................... 94
Figure 4-1. JTAG Module Block Diagram .............................................................................. 155
Figure 4-2. Test Access Port State Machine ......................................................................... 158
Figure 4-3. IDCODE Register Format ................................................................................... 164
Figure 4-4. BYPASS Register Format ................................................................................... 164
Figure 4-5. Boundary Scan Register Format ......................................................................... 165
Figure 5-1. Basic RST Configuration .................................................................................... 167
Figure 5-2. External Circuitry to Extend Power-On Reset ....................................................... 168
Figure 5-3. Reset Circuit Controlled by Switch ...................................................................... 168
Figure 5-4. Power Architecture ............................................................................................ 170
Figure 5-5. Main Clock Tree ................................................................................................ 173
Figure 6-1. Hibernation Module Block Diagram ..................................................................... 233
Figure 6-2. Clock Source Using Crystal ................................................................................ 235
Figure 6-3. Clock Source Using Dedicated Oscillator ............................................................. 235
Figure 7-1. Flash Block Diagram .......................................................................................... 252
Figure 8-1. GPIO Port Block Diagram ................................................................................... 279
Figure 8-2. GPIODATA Write Example ................................................................................. 280
Figure 8-3. GPIODATA Read Example ................................................................................. 280
Figure 9-1. GPTM Module Block Diagram ............................................................................ 321
Figure 9-2. 16-Bit Input Edge Count Mode Example .............................................................. 325
Figure 9-3. 16-Bit Input Edge Time Mode Example ............................................................... 326
Figure 9-4. 16-Bit PWM Mode Example ................................................................................ 327
Figure 10-1. WDT Module Block Diagram .............................................................................. 357
Figure 11-1. ADC Module Block Diagram ............................................................................... 381
Figure 11-2. Differential Sampling Range, V
Figure 11-3. Differential Sampling Range, V
Figure 11-4. Differential Sampling Range, V
Figure 11-5. Internal Temperature Sensor Characteristic ......................................................... 386
Figure 12-1. UART Module Block Diagram ............................................................................. 418
Figure 12-2. UART Character Frame ..................................................................................... 419
Figure 12-3. IrDA Data Modulation ......................................................................................... 421
Figure 13-1. SSI Module Block Diagram ................................................................................. 458
Figure 13-2. TI Synchronous Serial Frame Format (Single Transfer) ........................................ 461
Figure 13-3. TI Synchronous Serial Frame Format (Continuous Transfer) ................................ 461
Figure 13-4. Freescale SPI Format (Single Transfer) with SPO=0 and SPH=0 .......................... 462
Figure 13-5. Freescale SPI Format (Continuous Transfer) with SPO=0 and SPH=0 .................. 462
Figure 13-6. Freescale SPI Frame Format with SPO=0 and SPH=1 ......................................... 463
IN_ODD
IN_ODD
IN_ODD
= 1.5 V ...................................................... 384
= 0.75 V .................................................... 385
= 2.25 V .................................................... 385
Texas Instruments-Production Data
September 04, 201010
Stellaris® LM3S1165 Microcontroller
Figure 13-7. Freescale SPI Frame Format (Single Transfer) with SPO=1 and SPH=0 ............... 464
Figure 13-8. Freescale SPI Frame Format (Continuous Transfer) with SPO=1 and SPH=0 ........ 464
Figure 13-9. Freescale SPI Frame Format with SPO=1 and SPH=1 ......................................... 465
Figure 13-10. MICROWIRE Frame Format (Single Frame) ........................................................ 466
Figure 13-11. MICROWIRE Frame Format (Continuous Transfer) ............................................. 467
Figure 13-12. MICROWIRE Frame Format, SSIFss Input Setup and Hold Requirements ............ 467
Figure 14-1. I2C Block Diagram ............................................................................................. 496
Figure 14-2. I2C Bus Configuration ........................................................................................ 496
Figure 14-3. START and STOP Conditions ............................................................................. 497
Figure 14-4. Complete Data Transfer with a 7-Bit Address ....................................................... 497
Figure 14-5. R/S Bit in First Byte ............................................................................................ 497
Figure 14-6. Data Validity During Bit Transfer on the I2C Bus ................................................... 498
Figure 14-7. Master Single SEND .......................................................................................... 501
Figure 14-8. Master Single RECEIVE ..................................................................................... 502
Figure 14-9. Master Burst SEND ........................................................................................... 503
Figure 14-10. Master Burst RECEIVE ...................................................................................... 504
Figure 14-11. Master Burst RECEIVE after Burst SEND ............................................................ 505
Figure 14-12. Master Burst SEND after Burst RECEIVE ............................................................ 506
Figure 14-13. Slave Command Sequence ................................................................................ 507
Figure 15-1. Analog Comparator Module Block Diagram ......................................................... 531
Figure 15-2. Structure of Comparator Unit .............................................................................. 532
Figure 15-3. Comparator Internal Reference Structure ............................................................ 532
Figure 16-1. PWM Unit Diagram ............................................................................................ 543
Figure 16-2. PWM Module Block Diagram .............................................................................. 544
Figure 16-3. PWM Count-Down Mode .................................................................................... 545
Figure 16-4. PWM Count-Up/Down Mode .............................................................................. 545
Figure 16-5. PWM Generation Example In Count-Up/Down Mode ........................................... 546
Figure 16-6. PWM Dead-Band Generator ............................................................................... 546
Figure 17-1. 100-Pin LQFP Package Pin Diagram .................................................................. 580
Figure 17-2. 108-Ball BGA Package Pin Diagram (Top View) ................................................... 581
Figure 20-1. Load Conditions ................................................................................................ 613
Figure 20-2. JTAG Test Clock Input Timing ............................................................................. 615
Figure 20-3. JTAG Test Access Port (TAP) Timing .................................................................. 616
Figure 20-4. JTAG TRST Timing ............................................................................................ 616
Figure 20-5. External Reset Timing (RST) .............................................................................. 617
Figure 20-6. Power-On Reset Timing ..................................................................................... 617
Figure 20-7. Brown-Out Reset Timing .................................................................................... 617
Figure 20-8. Software Reset Timing ....................................................................................... 617
Figure 20-9. Watchdog Reset Timing ..................................................................................... 618
Figure 20-10. Hibernation Module Timing ................................................................................. 619
Figure 20-11. ADC Input Equivalency Diagram ......................................................................... 620
Figure 20-12. SSI Timing for TI Frame Format (FRF=01), Single Transfer Timing
Measurement .................................................................................................... 621
Figure 20-13. SSI Timing for MICROWIRE Frame Format (FRF=10), Single Transfer ................. 621
Figure 20-14. SSI Timing for SPI Frame Format (FRF=00), with SPH=1 ..................................... 622
Figure 20-15. I2C Timing ......................................................................................................... 623
Figure D-1. 108-Ball BGA Package Dimensions .................................................................... 653
Figure D-2. 108-Ball BGA Tray Dimensions ........................................................................... 655
Texas Instruments-Production Data
11September 04, 2010
Table of Contents
Figure D-3. 108-Ball BGA Tape and Reel Dimensions ............................................................ 656
Figure D-4. 100-Pin LQFP Package Dimensions ................................................................... 657
Figure D-5. 100-Pin LQFP Tray Dimensions .......................................................................... 659
Figure D-6. 100-Pin LQFP Tape and Reel Dimensions ........................................................... 660
Texas Instruments-Production Data
September 04, 201012
List of Tables
Table 1. Revision History .................................................................................................. 23
Table 2. Documentation Conventions ................................................................................ 28
Table 2-1. Summary of Processor Mode, Privilege Level, and Stack Use ................................ 51
Table 2-2. Processor Register Map ....................................................................................... 52
Table 2-3. PSR Register Combinations ................................................................................. 57
Table 2-4. Memory Map ....................................................................................................... 65
Table 2-5. Memory Access Behavior ..................................................................................... 67
Table 2-6. SRAM Memory Bit-Banding Regions .................................................................... 69
Table 2-7. Peripheral Memory Bit-Banding Regions ............................................................... 70
Table 2-8. Exception Types .................................................................................................. 75
Table 2-9. Interrupts ............................................................................................................ 76
Table 2-10. Exception Return Behavior ................................................................................... 81
Table 2-11. Faults ................................................................................................................. 82
Table 2-12. Fault Status and Fault Address Registers .............................................................. 83
Table 2-13. Cortex-M3 Instruction Summary ........................................................................... 85
Table 3-1. Core Peripheral Register Regions ......................................................................... 88
Table 3-2. Memory Attributes Summary ................................................................................ 91
Table 3-3. TEX, S, C, and B Bit Field Encoding ..................................................................... 94
Table 3-4. Cache Policy for Memory Attribute Encoding ......................................................... 95
Table 3-5. AP Bit Field Encoding .......................................................................................... 95
Table 3-6. Memory Region Attributes for Stellaris®Microcontrollers ........................................ 95
Table 3-7. Peripherals Register Map ..................................................................................... 96
Table 3-8. Interrupt Priority Levels ...................................................................................... 122
Table 3-9. Example SIZE Field Values ................................................................................ 151
Table 4-1. JTAG Port Pins Reset State ............................................................................... 156
Table 4-2. JTAG Instruction Register Commands ................................................................. 161
Table 5-1. Clock Source Options ........................................................................................ 171
Table 5-2. Possible System Clock Frequencies Using the SYSDIV Field ............................... 174
Table 5-3. Examples of Possible System Clock Frequencies Using the SYSDIV2 Field .......... 174
Table 5-4. System Control Register Map ............................................................................. 178
Table 5-5. RCC2 Fields that Override RCC fields ................................................................. 193
Table 6-1. Hibernation Module Register Map ....................................................................... 239
Table 7-1. Flash Protection Policy Combinations ................................................................. 253
Table 7-2. User-Programmable Flash Memory Resident Registers ....................................... 255
Table 7-3. Flash Register Map ............................................................................................ 256
Table 8-1. GPIO Pad Configuration Examples ..................................................................... 282
Table 8-2. GPIO Interrupt Configuration Example ................................................................ 282
Table 8-3. GPIO Register Map ........................................................................................... 284
Table 9-1. Available CCP Pins ............................................................................................ 321
Table 9-2. 16-Bit Timer With Prescaler Configurations ......................................................... 324
Table 9-3. Timers Register Map .......................................................................................... 330
Table 10-1. Watchdog Timer Register Map ............................................................................ 358
Table 11-1. Samples and FIFO Depth of Sequencers ............................................................ 381
Table 11-2. Differential Sampling Pairs ................................................................................. 383
Table 11-3. ADC Register Map ............................................................................................. 387
Table 12-1. UART Register Map ........................................................................................... 423
Stellaris® LM3S1165 Microcontroller
Texas Instruments-Production Data
13September 04, 2010
Table of Contents
Table 13-1. SSI Register Map .............................................................................................. 468
Table 14-1. Examples of I2C Master Timer Period versus Speed Mode ................................... 499
Table 14-2. Inter-Integrated Circuit (I2C) Interface Register Map ............................................. 508
Table 14-3. Write Field Decoding for I2CMCS[3:0] Field (Sheet 1 of 3) .................................... 513
Table 15-1. Internal Reference Voltage and ACREFCTL Field Values ..................................... 533
Table 15-2. Analog Comparators Register Map ..................................................................... 534
Table 16-1. PWM Register Map ............................................................................................ 548
Table 18-1. Signals by Pin Number ....................................................................................... 582
Table 18-2. Signals by Signal Name ..................................................................................... 586
Table 18-3. Signals by Function, Except for GPIO ................................................................. 590
Table 18-4. GPIO Pins and Alternate Functions ..................................................................... 593
Table 18-5. Signals by Pin Number ....................................................................................... 594
Table 18-6. Signals by Signal Name ..................................................................................... 599
Table 18-7. Signals by Function, Except for GPIO ................................................................. 603
Table 18-8. GPIO Pins and Alternate Functions ..................................................................... 605
Table 18-9. Connections for Unused Signals (100-pin LQFP) ................................................. 607
Table 18-10. Connections for Unused Signals, 108-pin BGA .................................................... 607
Table 19-1. Temperature Characteristics ............................................................................... 608
Table 19-2. Thermal Characteristics ..................................................................................... 608
Table 19-3. ESD Absolute Maximum Ratings ........................................................................ 608
Table 20-1. Maximum Ratings .............................................................................................. 609
Table 20-2. Recommended DC Operating Conditions ............................................................ 609
Table 20-3. LDO Regulator Characteristics ........................................................................... 610
Table 20-4. GPIO Module DC Characteristics ........................................................................ 610
Table 20-5. Detailed Power Specifications ............................................................................ 611
Table 20-6. Flash Memory Characteristics ............................................................................ 612
Table 20-7. Hibernation Module DC Characteristics ............................................................... 612
Table 20-8. Phase Locked Loop (PLL) Characteristics ........................................................... 613
Table 20-9. Actual PLL Frequency ........................................................................................ 613
Table 20-10. Clock Characteristics ......................................................................................... 613
Table 20-11. Crystal Characteristics ....................................................................................... 614
Table 20-12. System Clock Characteristics with ADC Operation ............................................... 614
Table 20-13. JTAG Characteristics ......................................................................................... 614
Table 20-14. Reset Characteristics ......................................................................................... 616
Table 20-15. Sleep Modes AC Characteristics ......................................................................... 618
Table 20-16. Hibernation Module AC Characteristics ............................................................... 618
Table 20-17. GPIO Characteristics ......................................................................................... 619
Table 20-18. ADC Characteristics ........................................................................................... 619
Table 20-19. ADC Module Internal Reference Characteristics .................................................. 620
Table 20-20. SSI Characteristics ............................................................................................ 620
Table 20-21. I2C Characteristics ............................................................................................. 622
Table 20-22. Analog Comparator Characteristics ..................................................................... 623
Table 20-23. Analog Comparator Voltage Reference Characteristics ........................................ 623
Table C-1. Part Ordering Information ................................................................................... 651
Texas Instruments-Production Data
September 04, 201014
Stellaris® LM3S1165 Microcontroller
List of Registers
The Cortex-M3 Processor ............................................................................................................. 46
Register 1: Cortex General-Purpose Register 0 (R0) ........................................................................... 53
Register 2: Cortex General-Purpose Register 1 (R1) ........................................................................... 53
Register 3: Cortex General-Purpose Register 2 (R2) ........................................................................... 53
Register 4: Cortex General-Purpose Register 3 (R3) ........................................................................... 53
Register 5: Cortex General-Purpose Register 4 (R4) ........................................................................... 53
Register 6: Cortex General-Purpose Register 5 (R5) ........................................................................... 53
Register 7: Cortex General-Purpose Register 6 (R6) ........................................................................... 53
Register 8: Cortex General-Purpose Register 7 (R7) ........................................................................... 53
Register 9: Cortex General-Purpose Register 8 (R8) ........................................................................... 53
Register 10: Cortex General-Purpose Register 9 (R9) ........................................................................... 53
Register 11: Cortex General-Purpose Register 10 (R10) ....................................................................... 53
Register 12: Cortex General-Purpose Register 11 (R11) ........................................................................ 53
Register 13: Cortex General-Purpose Register 12 (R12) ....................................................................... 53
Register 14: Stack Pointer (SP) ........................................................................................................... 54
Register 15: Link Register (LR) ............................................................................................................ 55
Register 16: Program Counter (PC) ..................................................................................................... 56
Register 17: Program Status Register (PSR) ........................................................................................ 57
Register 18: Priority Mask Register (PRIMASK) .................................................................................... 61
Register 19: Fault Mask Register (FAULTMASK) .................................................................................. 62
Register 20: Base Priority Mask Register (BASEPRI) ............................................................................ 63
Register 21: Control Register (CONTROL) ........................................................................................... 64
Cortex-M3 Peripherals ................................................................................................................... 88
Register 1: SysTick Control and Status Register (STCTRL), offset 0x010 ............................................. 99
Register 2: SysTick Reload Value Register (STRELOAD), offset 0x014 .............................................. 101
Register 3: SysTick Current Value Register (STCURRENT), offset 0x018 ........................................... 102
Register 4: Interrupt 0-31 Set Enable (EN0), offset 0x100 .................................................................. 103
Register 5: Interrupt 32-43 Set Enable (EN1), offset 0x104 ................................................................ 104
Register 6: Interrupt 0-31 Clear Enable (DIS0), offset 0x180 .............................................................. 105
Register 7: Interrupt 32-43 Clear Enable (DIS1), offset 0x184 ............................................................ 106
Register 8: Interrupt 0-31 Set Pending (PEND0), offset 0x200 ........................................................... 107
Register 9: Interrupt 32-43 Set Pending (PEND1), offset 0x204 ......................................................... 108
Register 10: Interrupt 0-31 Clear Pending (UNPEND0), offset 0x280 ................................................... 109
Register 11: Interrupt 32-43 Clear Pending (UNPEND1), offset 0x284 .................................................. 110
Register 12: Interrupt 0-31 Active Bit (ACTIVE0), offset 0x300 ............................................................. 111
Register 13: Interrupt 32-43 Active Bit (ACTIVE1), offset 0x304 ........................................................... 112
Register 14: Interrupt 0-3 Priority (PRI0), offset 0x400 ......................................................................... 113
Register 15: Interrupt 4-7 Priority (PRI1), offset 0x404 ......................................................................... 113
Register 16: Interrupt 8-11 Priority (PRI2), offset 0x408 ....................................................................... 113
Register 17: Interrupt 12-15 Priority (PRI3), offset 0x40C .................................................................... 113
Register 18: Interrupt 16-19 Priority (PRI4), offset 0x410 ..................................................................... 113
Register 19: Interrupt 20-23 Priority (PRI5), offset 0x414 ..................................................................... 113
Register 20: Interrupt 24-27 Priority (PRI6), offset 0x418 ..................................................................... 113
Register 21: Interrupt 28-31 Priority (PRI7), offset 0x41C .................................................................... 113
Register 22: Interrupt 32-35 Priority (PRI8), offset 0x420 ..................................................................... 113
Texas Instruments-Production Data
15September 04, 2010
Table of Contents
Register 23: Interrupt 36-39 Priority (PRI9), offset 0x424 ..................................................................... 113
Register 24: Interrupt 40-43 Priority (PRI10), offset 0x428 ................................................................... 113
Register 25: Software Trigger Interrupt (SWTRIG), offset 0xF00 .......................................................... 115
Register 26: CPU ID Base (CPUID), offset 0xD00 ............................................................................... 116
Register 27: Interrupt Control and State (INTCTRL), offset 0xD04 ........................................................ 117
Register 28: Vector Table Offset (VTABLE), offset 0xD08 .................................................................... 121
Register 29: Application Interrupt and Reset Control (APINT), offset 0xD0C ......................................... 122
Register 30: System Control (SYSCTRL), offset 0xD10 ....................................................................... 124
Register 31: Configuration and Control (CFGCTRL), offset 0xD14 ....................................................... 126
Register 32: System Handler Priority 1 (SYSPRI1), offset 0xD18 ......................................................... 128
Register 33: System Handler Priority 2 (SYSPRI2), offset 0xD1C ........................................................ 129
Register 34: System Handler Priority 3 (SYSPRI3), offset 0xD20 ......................................................... 130
Register 35: System Handler Control and State (SYSHNDCTRL), offset 0xD24 .................................... 131
Register 36: Configurable Fault Status (FAULTSTAT), offset 0xD28 ..................................................... 135
Register 37: Hard Fault Status (HFAULTSTAT), offset 0xD2C .............................................................. 141
Register 38: Memory Management Fault Address (MMADDR), offset 0xD34 ........................................ 143
Register 39: Bus Fault Address (FAULTADDR), offset 0xD38 .............................................................. 144
Register 40: MPU Type (MPUTYPE), offset 0xD90 ............................................................................. 145
Register 41: MPU Control (MPUCTRL), offset 0xD94 .......................................................................... 146
Register 42: MPU Region Number (MPUNUMBER), offset 0xD98 ....................................................... 148
Register 43: MPU Region Base Address (MPUBASE), offset 0xD9C ................................................... 149
Register 44: MPU Region Base Address Alias 1 (MPUBASE1), offset 0xDA4 ....................................... 149
Register 45: MPU Region Base Address Alias 2 (MPUBASE2), offset 0xDAC ...................................... 149
Register 46: MPU Region Base Address Alias 3 (MPUBASE3), offset 0xDB4 ....................................... 149
Register 47: MPU Region Attribute and Size (MPUATTR), offset 0xDA0 ............................................... 151
Register 48: MPU Region Attribute and Size Alias 1 (MPUATTR1), offset 0xDA8 .................................. 151
Register 49: MPU Region Attribute and Size Alias 2 (MPUATTR2), offset 0xDB0 .................................. 151
Register 50: MPU Region Attribute and Size Alias 3 (MPUATTR3), offset 0xDB8 .................................. 151
System Control ............................................................................................................................ 166
Register 1: Device Identification 0 (DID0), offset 0x000 ..................................................................... 180
Register 2: Brown-Out Reset Control (PBORCTL), offset 0x030 ........................................................ 182
Register 3: LDO Power Control (LDOPCTL), offset 0x034 ................................................................. 183
Register 4: Raw Interrupt Status (RIS), offset 0x050 .......................................................................... 184
Register 5: Interrupt Mask Control (IMC), offset 0x054 ...................................................................... 185
Register 6: Masked Interrupt Status and Clear (MISC), offset 0x058 .................................................. 186
Register 7: Reset Cause (RESC), offset 0x05C ................................................................................ 187
Register 8: Run-Mode Clock Configuration (RCC), offset 0x060 ......................................................... 188
Register 9: XTAL to PLL Translation (PLLCFG), offset 0x064 ............................................................. 192
Register 10: Run-Mode Clock Configuration 2 (RCC2), offset 0x070 .................................................... 193
Register 11: Deep Sleep Clock Configuration (DSLPCLKCFG), offset 0x144 ........................................ 195
Register 12: Device Identification 1 (DID1), offset 0x004 ..................................................................... 196
Register 13: Device Capabilities 0 (DC0), offset 0x008 ........................................................................ 198
Register 14: Device Capabilities 1 (DC1), offset 0x010 ........................................................................ 199
Register 15: Device Capabilities 2 (DC2), offset 0x014 ........................................................................ 201
Register 16: Device Capabilities 3 (DC3), offset 0x018 ........................................................................ 203
Register 17: Device Capabilities 4 (DC4), offset 0x01C ....................................................................... 205
Register 18: Run Mode Clock Gating Control Register 0 (RCGC0), offset 0x100 ................................... 207
Register 19: Sleep Mode Clock Gating Control Register 0 (SCGC0), offset 0x110 ................................. 209
Texas Instruments-Production Data
September 04, 201016
Stellaris® LM3S1165 Microcontroller
Register 20: Deep Sleep Mode Clock Gating Control Register 0 (DCGC0), offset 0x120 ....................... 211
Register 21: Run Mode Clock Gating Control Register 1 (RCGC1), offset 0x104 ................................... 213
Register 22: Sleep Mode Clock Gating Control Register 1 (SCGC1), offset 0x114 ................................. 216
Register 23: Deep Sleep Mode Clock Gating Control Register 1 (DCGC1), offset 0x124 ....................... 219
Register 24: Run Mode Clock Gating Control Register 2 (RCGC2), offset 0x108 ................................... 222
Register 25: Sleep Mode Clock Gating Control Register 2 (SCGC2), offset 0x118 ................................. 224
Register 26: Deep Sleep Mode Clock Gating Control Register 2 (DCGC2), offset 0x128 ....................... 226
Register 27: Software Reset Control 0 (SRCR0), offset 0x040 ............................................................. 228
Register 28: Software Reset Control 1 (SRCR1), offset 0x044 ............................................................. 229
Register 29: Software Reset Control 2 (SRCR2), offset 0x048 ............................................................. 231
Hibernation Module ..................................................................................................................... 232
Register 1: Hibernation RTC Counter (HIBRTCC), offset 0x000 ......................................................... 240
Register 2: Hibernation RTC Match 0 (HIBRTCM0), offset 0x004 ....................................................... 241
Register 3: Hibernation RTC Match 1 (HIBRTCM1), offset 0x008 ....................................................... 242
Register 4: Hibernation RTC Load (HIBRTCLD), offset 0x00C ........................................................... 243
Register 5: Hibernation Control (HIBCTL), offset 0x010 ..................................................................... 244
Register 6: Hibernation Interrupt Mask (HIBIM), offset 0x014 ............................................................. 246
Register 7: Hibernation Raw Interrupt Status (HIBRIS), offset 0x018 .................................................. 247
Register 8: Hibernation Masked Interrupt Status (HIBMIS), offset 0x01C ............................................ 248
Register 9: Hibernation Interrupt Clear (HIBIC), offset 0x020 ............................................................. 249
Register 10: Hibernation RTC Trim (HIBRTCT), offset 0x024 ............................................................... 250
Register 11: Hibernation Data (HIBDATA), offset 0x030-0x12C ............................................................ 251
Internal Memory ........................................................................................................................... 252
Register 1: Flash Memory Address (FMA), offset 0x000 .................................................................... 258
Register 2: Flash Memory Data (FMD), offset 0x004 ......................................................................... 259
Register 3: Flash Memory Control (FMC), offset 0x008 ..................................................................... 260
Register 4: Flash Controller Raw Interrupt Status (FCRIS), offset 0x00C ............................................ 262
Register 5: Flash Controller Interrupt Mask (FCIM), offset 0x010 ........................................................ 263
Register 6: Flash Controller Masked Interrupt Status and Clear (FCMISC), offset 0x014 ..................... 264
Register 7: USec Reload (USECRL), offset 0x140 ............................................................................ 266
Register 8: Flash Memory Protection Read Enable 0 (FMPRE0), offset 0x130 and 0x200 ................... 267
Register 9: Flash Memory Protection Program Enable 0 (FMPPE0), offset 0x134 and 0x400 ............... 268
Register 10: User Debug (USER_DBG), offset 0x1D0 ......................................................................... 269
Register 11: User Register 0 (USER_REG0), offset 0x1E0 .................................................................. 270
Register 12: User Register 1 (USER_REG1), offset 0x1E4 .................................................................. 271
Register 13: Flash Memory Protection Read Enable 1 (FMPRE1), offset 0x204 .................................... 272
Register 14: Flash Memory Protection Read Enable 2 (FMPRE2), offset 0x208 .................................... 273
Register 15: Flash Memory Protection Read Enable 3 (FMPRE3), offset 0x20C ................................... 274
Register 16: Flash Memory Protection Program Enable 1 (FMPPE1), offset 0x404 ............................... 275
Register 17: Flash Memory Protection Program Enable 2 (FMPPE2), offset 0x408 ............................... 276
Register 18: Flash Memory Protection Program Enable 3 (FMPPE3), offset 0x40C ............................... 277
General-Purpose Input/Outputs (GPIOs) ................................................................................... 278
Register 1: GPIO Data (GPIODATA), offset 0x000 ............................................................................ 286
Register 2: GPIO Direction (GPIODIR), offset 0x400 ......................................................................... 287
Register 3: GPIO Interrupt Sense (GPIOIS), offset 0x404 .................................................................. 288
Register 4: GPIO Interrupt Both Edges (GPIOIBE), offset 0x408 ........................................................ 289
Register 5: GPIO Interrupt Event (GPIOIEV), offset 0x40C ................................................................ 290
Register 6: GPIO Interrupt Mask (GPIOIM), offset 0x410 ................................................................... 291
Texas Instruments-Production Data
17September 04, 2010
Table of Contents
Register 7: GPIO Raw Interrupt Status (GPIORIS), offset 0x414 ........................................................ 292
Register 8: GPIO Masked Interrupt Status (GPIOMIS), offset 0x418 ................................................... 293
Register 9: GPIO Interrupt Clear (GPIOICR), offset 0x41C ................................................................ 294
Register 10: GPIO Alternate Function Select (GPIOAFSEL), offset 0x420 ............................................ 295
Register 11: GPIO 2-mA Drive Select (GPIODR2R), offset 0x500 ........................................................ 297
Register 12: GPIO 4-mA Drive Select (GPIODR4R), offset 0x504 ........................................................ 298
Register 13: GPIO 8-mA Drive Select (GPIODR8R), offset 0x508 ........................................................ 299
Register 14: GPIO Open Drain Select (GPIOODR), offset 0x50C ......................................................... 300
Register 15: GPIO Pull-Up Select (GPIOPUR), offset 0x510 ................................................................ 301
Register 16: GPIO Pull-Down Select (GPIOPDR), offset 0x514 ........................................................... 302
Register 17: GPIO Slew Rate Control Select (GPIOSLR), offset 0x518 ................................................ 303
Register 18: GPIO Digital Enable (GPIODEN), offset 0x51C ................................................................ 304
Register 19: GPIO Lock (GPIOLOCK), offset 0x520 ............................................................................ 305
Register 20: GPIO Commit (GPIOCR), offset 0x524 ............................................................................ 306
Register 21: GPIO Peripheral Identification 4 (GPIOPeriphID4), offset 0xFD0 ....................................... 308
Register 22: GPIO Peripheral Identification 5 (GPIOPeriphID5), offset 0xFD4 ....................................... 309
Register 23: GPIO Peripheral Identification 6 (GPIOPeriphID6), offset 0xFD8 ....................................... 310
Register 24: GPIO Peripheral Identification 7 (GPIOPeriphID7), offset 0xFDC ...................................... 311
Register 25: GPIO Peripheral Identification 0 (GPIOPeriphID0), offset 0xFE0 ....................................... 312
Register 26: GPIO Peripheral Identification 1 (GPIOPeriphID1), offset 0xFE4 ....................................... 313
Register 27: GPIO Peripheral Identification 2 (GPIOPeriphID2), offset 0xFE8 ....................................... 314
Register 28: GPIO Peripheral Identification 3 (GPIOPeriphID3), offset 0xFEC ...................................... 315
Register 29: GPIO PrimeCell Identification 0 (GPIOPCellID0), offset 0xFF0 .......................................... 316
Register 30: GPIO PrimeCell Identification 1 (GPIOPCellID1), offset 0xFF4 .......................................... 317
Register 31: GPIO PrimeCell Identification 2 (GPIOPCellID2), offset 0xFF8 .......................................... 318
Register 32: GPIO PrimeCell Identification 3 (GPIOPCellID3), offset 0xFFC ......................................... 319
General-Purpose Timers ............................................................................................................. 320
Register 1: GPTM Configuration (GPTMCFG), offset 0x000 .............................................................. 332
Register 2: GPTM TimerA Mode (GPTMTAMR), offset 0x004 ............................................................ 333
Register 3: GPTM TimerB Mode (GPTMTBMR), offset 0x008 ............................................................ 335
Register 4: GPTM Control (GPTMCTL), offset 0x00C ........................................................................ 337
Register 5: GPTM Interrupt Mask (GPTMIMR), offset 0x018 .............................................................. 340
Register 6: GPTM Raw Interrupt Status (GPTMRIS), offset 0x01C ..................................................... 342
Register 7: GPTM Masked Interrupt Status (GPTMMIS), offset 0x020 ................................................ 343
Register 8: GPTM Interrupt Clear (GPTMICR), offset 0x024 .............................................................. 344
Register 9: GPTM TimerA Interval Load (GPTMTAILR), offset 0x028 ................................................. 346
Register 10: GPTM TimerB Interval Load (GPTMTBILR), offset 0x02C ................................................ 347
Register 11: GPTM TimerA Match (GPTMTAMATCHR), offset 0x030 ................................................... 348
Register 12: GPTM TimerB Match (GPTMTBMATCHR), offset 0x034 .................................................. 349
Register 13: GPTM TimerA Prescale (GPTMTAPR), offset 0x038 ........................................................ 350
Register 14: GPTM TimerB Prescale (GPTMTBPR), offset 0x03C ....................................................... 351
Register 15: GPTM TimerA Prescale Match (GPTMTAPMR), offset 0x040 ........................................... 352
Register 16: GPTM TimerB Prescale Match (GPTMTBPMR), offset 0x044 ........................................... 353
Register 17: GPTM TimerA (GPTMTAR), offset 0x048 ........................................................................ 354
Register 18: GPTM TimerB (GPTMTBR), offset 0x04C ....................................................................... 355
Watchdog Timer ........................................................................................................................... 356
Register 1: Watchdog Load (WDTLOAD), offset 0x000 ...................................................................... 360
Register 2: Watchdog Value (WDTVALUE), offset 0x004 ................................................................... 361
Texas Instruments-Production Data
September 04, 201018
Stellaris® LM3S1165 Microcontroller
Register 3: Watchdog Control (WDTCTL), offset 0x008 ..................................................................... 362
Register 4: Watchdog Interrupt Clear (WDTICR), offset 0x00C .......................................................... 363
Register 5: Watchdog Raw Interrupt Status (WDTRIS), offset 0x010 .................................................. 364
Register 6: Watchdog Masked Interrupt Status (WDTMIS), offset 0x014 ............................................. 365
Register 7: Watchdog Test (WDTTEST), offset 0x418 ....................................................................... 366
Register 8: Watchdog Lock (WDTLOCK), offset 0xC00 ..................................................................... 367
Register 9: Watchdog Peripheral Identification 4 (WDTPeriphID4), offset 0xFD0 ................................. 368
Register 10: Watchdog Peripheral Identification 5 (WDTPeriphID5), offset 0xFD4 ................................. 369
Register 11: Watchdog Peripheral Identification 6 (WDTPeriphID6), offset 0xFD8 ................................. 370
Register 12: Watchdog Peripheral Identification 7 (WDTPeriphID7), offset 0xFDC ................................ 371
Register 13: Watchdog Peripheral Identification 0 (WDTPeriphID0), offset 0xFE0 ................................. 372
Register 14: Watchdog Peripheral Identification 1 (WDTPeriphID1), offset 0xFE4 ................................. 373
Register 15: Watchdog Peripheral Identification 2 (WDTPeriphID2), offset 0xFE8 ................................. 374
Register 16: Watchdog Peripheral Identification 3 (WDTPeriphID3), offset 0xFEC ................................. 375
Register 17: Watchdog PrimeCell Identification 0 (WDTPCellID0), offset 0xFF0 .................................... 376
Register 18: Watchdog PrimeCell Identification 1 (WDTPCellID1), offset 0xFF4 .................................... 377
Register 19: Watchdog PrimeCell Identification 2 (WDTPCellID2), offset 0xFF8 .................................... 378
Register 20: Watchdog PrimeCell Identification 3 (WDTPCellID3 ), offset 0xFFC .................................. 379
Analog-to-Digital Converter (ADC) ............................................................................................. 380
Register 1: ADC Active Sample Sequencer (ADCACTSS), offset 0x000 ............................................. 389
Register 2: ADC Raw Interrupt Status (ADCRIS), offset 0x004 ........................................................... 390
Register 3: ADC Interrupt Mask (ADCIM), offset 0x008 ..................................................................... 391
Register 4: ADC Interrupt Status and Clear (ADCISC), offset 0x00C .................................................. 392
Register 5: ADC Overflow Status (ADCOSTAT), offset 0x010 ............................................................ 394
Register 6: ADC Event Multiplexer Select (ADCEMUX), offset 0x014 ................................................. 395
Register 7: ADC Underflow Status (ADCUSTAT), offset 0x018 ........................................................... 399
Register 8: ADC Sample Sequencer Priority (ADCSSPRI), offset 0x020 ............................................. 400
Register 9: ADC Processor Sample Sequence Initiate (ADCPSSI), offset 0x028 ................................. 402
Register 10: ADC Sample Averaging Control (ADCSAC), offset 0x030 ................................................. 403
Register 11: ADC Sample Sequence Input Multiplexer Select 0 (ADCSSMUX0), offset 0x040 ............... 404
Register 12: ADC Sample Sequence Control 0 (ADCSSCTL0), offset 0x044 ........................................ 406
Register 13: ADC Sample Sequence Result FIFO 0 (ADCSSFIFO0), offset 0x048 ................................ 409
Register 14: ADC Sample Sequence Result FIFO 1 (ADCSSFIFO1), offset 0x068 ................................ 409
Register 15: ADC Sample Sequence Result FIFO 2 (ADCSSFIFO2), offset 0x088 ................................ 409
Register 16: ADC Sample Sequence Result FIFO 3 (ADCSSFIFO3), offset 0x0A8 ............................... 409
Register 17: ADC Sample Sequence FIFO 0 Status (ADCSSFSTAT0), offset 0x04C ............................. 410
Register 18: ADC Sample Sequence FIFO 1 Status (ADCSSFSTAT1), offset 0x06C ............................. 410
Register 19: ADC Sample Sequence FIFO 2 Status (ADCSSFSTAT2), offset 0x08C ............................ 410
Register 20: ADC Sample Sequence FIFO 3 Status (ADCSSFSTAT3), offset 0x0AC ............................ 410
Register 21: ADC Sample Sequence Input Multiplexer Select 1 (ADCSSMUX1), offset 0x060 ............... 411
Register 22: ADC Sample Sequence Input Multiplexer Select 2 (ADCSSMUX2), offset 0x080 ............... 411
Register 23: ADC Sample Sequence Control 1 (ADCSSCTL1), offset 0x064 ........................................ 412
Register 24: ADC Sample Sequence Control 2 (ADCSSCTL2), offset 0x084 ........................................ 412
Register 25: ADC Sample Sequence Input Multiplexer Select 3 (ADCSSMUX3), offset 0x0A0 ............... 414
Register 26: ADC Sample Sequence Control 3 (ADCSSCTL3), offset 0x0A4 ........................................ 415
Register 27: ADC Test Mode Loopback (ADCTMLB), offset 0x100 ....................................................... 416
Universal Asynchronous Receivers/Transmitters (UARTs) ..................................................... 417
Register 1: UART Data (UARTDR), offset 0x000 ............................................................................... 425
Texas Instruments-Production Data
19September 04, 2010
Table of Contents
Register 2: UART Receive Status/Error Clear (UARTRSR/UARTECR), offset 0x004 ........................... 427
Register 3: UART Flag (UARTFR), offset 0x018 ................................................................................ 429
Register 4: UART IrDA Low-Power Register (UARTILPR), offset 0x020 ............................................. 431
Register 5: UART Integer Baud-Rate Divisor (UARTIBRD), offset 0x024 ............................................ 432
Register 6: UART Fractional Baud-Rate Divisor (UARTFBRD), offset 0x028 ....................................... 433
Register 7: UART Line Control (UARTLCRH), offset 0x02C ............................................................... 434
Register 8: UART Control (UARTCTL), offset 0x030 ......................................................................... 436
Register 9: UART Interrupt FIFO Level Select (UARTIFLS), offset 0x034 ........................................... 438
Register 10: UART Interrupt Mask (UARTIM), offset 0x038 ................................................................. 440
Register 11: UART Raw Interrupt Status (UARTRIS), offset 0x03C ...................................................... 442
Register 12: UART Masked Interrupt Status (UARTMIS), offset 0x040 ................................................. 443
Register 13: UART Interrupt Clear (UARTICR), offset 0x044 ............................................................... 444
Register 14: UART Peripheral Identification 4 (UARTPeriphID4), offset 0xFD0 ..................................... 446
Register 15: UART Peripheral Identification 5 (UARTPeriphID5), offset 0xFD4 ..................................... 447
Register 16: UART Peripheral Identification 6 (UARTPeriphID6), offset 0xFD8 ..................................... 448
Register 17: UART Peripheral Identification 7 (UARTPeriphID7), offset 0xFDC ..................................... 449
Register 18: UART Peripheral Identification 0 (UARTPeriphID0), offset 0xFE0 ...................................... 450
Register 19: UART Peripheral Identification 1 (UARTPeriphID1), offset 0xFE4 ...................................... 451
Register 20: UART Peripheral Identification 2 (UARTPeriphID2), offset 0xFE8 ...................................... 452
Register 21: UART Peripheral Identification 3 (UARTPeriphID3), offset 0xFEC ..................................... 453
Register 22: UART PrimeCell Identification 0 (UARTPCellID0), offset 0xFF0 ........................................ 454
Register 23: UART PrimeCell Identification 1 (UARTPCellID1), offset 0xFF4 ........................................ 455
Register 24: UART PrimeCell Identification 2 (UARTPCellID2), offset 0xFF8 ........................................ 456
Register 25: UART PrimeCell Identification 3 (UARTPCellID3), offset 0xFFC ........................................ 457
Synchronous Serial Interface (SSI) ............................................................................................ 458
Register 1: SSI Control 0 (SSICR0), offset 0x000 .............................................................................. 470
Register 2: SSI Control 1 (SSICR1), offset 0x004 .............................................................................. 472
Register 3: SSI Data (SSIDR), offset 0x008 ...................................................................................... 474
Register 4: SSI Status (SSISR), offset 0x00C ................................................................................... 475
Register 5: SSI Clock Prescale (SSICPSR), offset 0x010 .................................................................. 477
Register 6: SSI Interrupt Mask (SSIIM), offset 0x014 ......................................................................... 478
Register 7: SSI Raw Interrupt Status (SSIRIS), offset 0x018 .............................................................. 480
Register 8: SSI Masked Interrupt Status (SSIMIS), offset 0x01C ........................................................ 481
Register 9: SSI Interrupt Clear (SSIICR), offset 0x020 ....................................................................... 482
Register 10: SSI Peripheral Identification 4 (SSIPeriphID4), offset 0xFD0 ............................................. 483
Register 11: SSI Peripheral Identification 5 (SSIPeriphID5), offset 0xFD4 ............................................. 484
Register 12: SSI Peripheral Identification 6 (SSIPeriphID6), offset 0xFD8 ............................................. 485
Register 13: SSI Peripheral Identification 7 (SSIPeriphID7), offset 0xFDC ............................................ 486
Register 14: SSI Peripheral Identification 0 (SSIPeriphID0), offset 0xFE0 ............................................. 487
Register 15: SSI Peripheral Identification 1 (SSIPeriphID1), offset 0xFE4 ............................................. 488
Register 16: SSI Peripheral Identification 2 (SSIPeriphID2), offset 0xFE8 ............................................. 489
Register 17: SSI Peripheral Identification 3 (SSIPeriphID3), offset 0xFEC ............................................ 490
Register 18: SSI PrimeCell Identification 0 (SSIPCellID0), offset 0xFF0 ............................................... 491
Register 19: SSI PrimeCell Identification 1 (SSIPCellID1), offset 0xFF4 ............................................... 492
Register 20: SSI PrimeCell Identification 2 (SSIPCellID2), offset 0xFF8 ............................................... 493
Register 21: SSI PrimeCell Identification 3 (SSIPCellID3), offset 0xFFC ............................................... 494
Inter-Integrated Circuit (I2C) Interface ........................................................................................ 495
Register 1: I2C Master Slave Address (I2CMSA), offset 0x000 ........................................................... 510
Texas Instruments-Production Data
September 04, 201020
Stellaris® LM3S1165 Microcontroller
Register 2: I2C Master Control/Status (I2CMCS), offset 0x004 ........................................................... 511
Register 3: I2C Master Data (I2CMDR), offset 0x008 ......................................................................... 515
Register 4: I2C Master Timer Period (I2CMTPR), offset 0x00C ........................................................... 516
Register 5: I2C Master Interrupt Mask (I2CMIMR), offset 0x010 ......................................................... 517
Register 6: I2C Master Raw Interrupt Status (I2CMRIS), offset 0x014 ................................................. 518
Register 7: I2C Master Masked Interrupt Status (I2CMMIS), offset 0x018 ........................................... 519
Register 8: I2C Master Interrupt Clear (I2CMICR), offset 0x01C ......................................................... 520
Register 9: I2C Master Configuration (I2CMCR), offset 0x020 ............................................................ 521
Register 10: I2C Slave Own Address (I2CSOAR), offset 0x000 ............................................................ 523
Register 11: I2C Slave Control/Status (I2CSCSR), offset 0x004 ........................................................... 524
Register 12: I2C Slave Data (I2CSDR), offset 0x008 ........................................................................... 526
Register 13: I2C Slave Interrupt Mask (I2CSIMR), offset 0x00C ........................................................... 527
Register 14: I2C Slave Raw Interrupt Status (I2CSRIS), offset 0x010 ................................................... 528
Register 15: I2C Slave Masked Interrupt Status (I2CSMIS), offset 0x014 .............................................. 529
Register 16: I2C Slave Interrupt Clear (I2CSICR), offset 0x018 ............................................................ 530
Analog Comparator ..................................................................................................................... 531
Register 1: Analog Comparator Masked Interrupt Status (ACMIS), offset 0x000 .................................. 535
Register 2: Analog Comparator Raw Interrupt Status (ACRIS), offset 0x004 ....................................... 536
Register 3: Analog Comparator Interrupt Enable (ACINTEN), offset 0x008 ......................................... 537
Register 4: Analog Comparator Reference Voltage Control (ACREFCTL), offset 0x010 ....................... 538
Register 5: Analog Comparator Status 0 (ACSTAT0), offset 0x020 ..................................................... 539
Register 6: Analog Comparator Control 0 (ACCTL0), offset 0x024 ..................................................... 540
Pulse Width Modulator (PWM) .................................................................................................... 542
Register 1: PWM Master Control (PWMCTL), offset 0x000 ................................................................ 551
Register 2: PWM Time Base Sync (PWMSYNC), offset 0x004 ........................................................... 552
Register 3: PWM Output Enable (PWMENABLE), offset 0x008 .......................................................... 553
Register 4: PWM Output Inversion (PWMINVERT), offset 0x00C ....................................................... 554
Register 5: PWM Output Fault (PWMFAULT), offset 0x010 ................................................................ 555
Register 6: PWM Interrupt Enable (PWMINTEN), offset 0x014 ........................................................... 556
Register 7: PWM Raw Interrupt Status (PWMRIS), offset 0x018 ........................................................ 557
Register 8: PWM Interrupt Status and Clear (PWMISC), offset 0x01C ................................................ 558
Register 9: PWM Status (PWMSTATUS), offset 0x020 ...................................................................... 559
Register 10: PWM0 Control (PWM0CTL), offset 0x040 ....................................................................... 560
Register 11: PWM1 Control (PWM1CTL), offset 0x080 ....................................................................... 560
Register 12: PWM2 Control (PWM2CTL), offset 0x0C0 ...................................................................... 560
Register 13: PWM0 Interrupt and Trigger Enable (PWM0INTEN), offset 0x044 .................................... 562
Register 14: PWM1 Interrupt and Trigger Enable (PWM1INTEN), offset 0x084 .................................... 562
Register 15: PWM2 Interrupt and Trigger Enable (PWM2INTEN), offset 0x0C4 .................................... 562
Register 16: PWM0 Raw Interrupt Status (PWM0RIS), offset 0x048 .................................................... 565
Register 17: PWM1 Raw Interrupt Status (PWM1RIS), offset 0x088 .................................................... 565
Register 18: PWM2 Raw Interrupt Status (PWM2RIS), offset 0x0C8 ................................................... 565
Register 19: PWM0 Interrupt Status and Clear (PWM0ISC), offset 0x04C ........................................... 566
Register 20: PWM1 Interrupt Status and Clear (PWM1ISC), offset 0x08C ........................................... 566
Register 21: PWM2 Interrupt Status and Clear (PWM2ISC), offset 0x0CC ........................................... 566
Register 22: PWM0 Load (PWM0LOAD), offset 0x050 ....................................................................... 567
Register 23: PWM1 Load (PWM1LOAD), offset 0x090 ....................................................................... 567
Register 24: PWM2 Load (PWM2LOAD), offset 0x0D0 ....................................................................... 567
Texas Instruments-Production Data
21September 04, 2010
Table of Contents
Register 25: PWM0 Counter (PWM0COUNT), offset 0x054 ................................................................ 568
Register 26: PWM1 Counter (PWM1COUNT), offset 0x094 ................................................................ 568
Register 27: PWM2 Counter (PWM2COUNT), offset 0x0D4 ............................................................... 568
Register 28: PWM0 Compare A (PWM0CMPA), offset 0x058 ............................................................. 569
Register 29: PWM1 Compare A (PWM1CMPA), offset 0x098 ............................................................. 569
Register 30: PWM2 Compare A (PWM2CMPA), offset 0x0D8 ............................................................. 569
Register 31: PWM0 Compare B (PWM0CMPB), offset 0x05C ............................................................. 570
Register 32: PWM1 Compare B (PWM1CMPB), offset 0x09C ............................................................. 570
Register 33: PWM2 Compare B (PWM2CMPB), offset 0x0DC ............................................................ 570
Register 34: PWM0 Generator A Control (PWM0GENA), offset 0x060 ................................................ 571
Register 35: PWM1 Generator A Control (PWM1GENA), offset 0x0A0 ................................................ 571
Register 36: PWM2 Generator A Control (PWM2GENA), offset 0x0E0 ................................................ 571
Register 37: PWM0 Generator B Control (PWM0GENB), offset 0x064 ................................................ 574
Register 38: PWM1 Generator B Control (PWM1GENB), offset 0x0A4 ................................................ 574
Register 39: PWM2 Generator B Control (PWM2GENB), offset 0x0E4 ................................................ 574
Register 40: PWM0 Dead-Band Control (PWM0DBCTL), offset 0x068 ................................................ 577
Register 41: PWM1 Dead-Band Control (PWM1DBCTL), offset 0x0A8 ................................................. 577
Register 42: PWM2 Dead-Band Control (PWM2DBCTL), offset 0x0E8 ................................................ 577
Register 43: PWM0 Dead-Band Rising-Edge Delay (PWM0DBRISE), offset 0x06C ............................. 578
Register 44: PWM1 Dead-Band Rising-Edge Delay (PWM1DBRISE), offset 0x0AC ............................. 578
Register 45: PWM2 Dead-Band Rising-Edge Delay (PWM2DBRISE), offset 0x0EC ............................. 578
Register 46: PWM0 Dead-Band Falling-Edge-Delay (PWM0DBFALL), offset 0x070 ............................. 579
Register 47: PWM1 Dead-Band Falling-Edge-Delay (PWM1DBFALL), offset 0x0B0 ............................. 579
Register 48: PWM2 Dead-Band Falling-Edge-Delay (PWM2DBFALL), offset 0x0F0 ............................. 579
Texas Instruments-Production Data
September 04, 201022
Revision History
The revision history table notes changes made between the indicated revisions of the LM3S1165
data sheet.
Table 1. Revision History
DescriptionRevisionDate
7787September 2010
■ Reorganized ARM Cortex-M3 Processor Core, Memory Map and Interrupts chapters, creating two
■ Changed register names to be consistent with StellarisWare®names: the Cortex-M3 Interrupt
■ Added clarification of instruction execution during Flash operations.
■ Modified Figure 8-1 on page 279 to clarify operation of the GPIO inputs when used as an alternate
■ Corrected GPIOAMSEL bit field in GPIO Analog Mode Select (GPIOAMSEL) register to be eight-bits
Stellaris® LM3S1165 Microcontroller
new chapters, The Cortex-M3 Processor and Cortex-M3 Peripherals. Much additional content was
added, including all the Cortex-M3 registers.
Control and Status (ICSR) register to the Interrupt Control and State (INTCTRL) register, and
the Cortex-M3 Interrupt Set Enable (SETNA) register to the Interrupt 0-31 Set Enable (EN0)
register.
function.
wide, bits[7:0].
■ Added caution not to apply a Low value to PB7 when debugging; a Low value on the pin causes
the JTAG controller to be reset, resulting in a loss of JTAG communication.
■ In General-Purpose Timers chapter, clarified operation of the 32-bit RTC mode.
■ In Electrical Characteristics chapter:
– Added I
– Corrected values for t
■ Added dimensions for Tray and Tape and Reel shipping mediums.
7393June 2010
7007April 2010
■ Corrected base address for SRAM in architectural overview chapter.
■ Clarified system clock operation, adding content to “Clock Control” on page 170.
■ In Signal Tables chapter, added table "Connections for Unused Signals."
■ In "Thermal Characteristics" table, corrected thermal resistance value from 34 to 32.
■ In "Reset Characteristics" table, corrected value for supply voltage (VDD) rise time.
■ Additional minor data sheet clarifications and corrections.
■ Added caution note to the I2C Master Timer Period (I2CMTPR) register description and changed
field width to 7 bits.
■ Removed erroneous text about restoring the Flash Protection registers.
■ Added note about RST signal routing.
■ Clarified the function of the TnSTALL bit in the GPTMCTL register.
parameter (GPIO input leakage current) to Table 20-4 on page 610.
LKG
parameter (SSIClk rise/fall time) in Table 20-20 on page 620.
CLKRF
■ Additional minor data sheet clarifications and corrections.
Texas Instruments-Production Data
23September 04, 2010
Revision History
Table 1. Revision History (continued)
DescriptionRevisionDate
6712January 2010
■ In "System Control" section, clarified Debug Access Port operation after Sleep modes.
■ Clarified wording on Flash memory access errors.
■ Added section on Flash interrupts.
■ Changed the reset value of the ADC Sample Sequence Result FIFO n (ADCSSFIFOn) registers
to be indeterminate.
■ Clarified operation of SSI transmit FIFO.
■ Made these changes to the Operating Characteristics chapter:
– Added storage temperature ratings to "Temperature Characteristics" table
– Added "ESD Absolute Maximum Ratings" table
■ Made these changes to the Electrical Characteristics chapter:
– In "Flash Memory Characteristics" table, corrected Mass erase time
– Added sleep and deep-sleep wake-up times ("Sleep Modes AC Characteristics" table)
– In "Reset Characteristics" table, corrected units for supply voltage (VDD) rise time
6462October 2009
■ Deleted MAXADCSPD bit field from DCGC0 register as it is not applicable in Deep-Sleep mode.
■ Removed erroneous reference to the WRC bit in the Hibernation chapter.
■ Deleted reset value for 16-bit mode from GPTMTAILR, GPTMTAMATCHR, and GPTMTAR registers
because the module resets in 32-bit mode.
■ Clarified PWM source for ADC triggering.
■ Made these changes to the Electrical Characteristics chapter:
– Removed V
SIH
and V
parameters from Operating Conditions table.
SIL
– Added table showing actual PLL frequency depending on input crystal.
– Changed the name of the t
HIB_REG_WRITE
parameter to t
HIB_REG_ACCESS
.
– Revised ADC electrical specifications to clarify, including reorganizing and adding new data.
– Changed SSI set up and hold times to be expressed in system clocks, not ns.
Corrected ordering numbers.5920July 2009
5902July 2009
■ Clarified Power-on reset and RST pin operation; added new diagrams.
■ Corrected the reset value of the Hibernation Data (HIBDATA) and Hibernation Control (HIBCTL)
registers.
■ Clarified explanation of nonvolatile register programming in Internal Memory chapter.
■ Added explanation of reset value to FMPRE0/1/2/3, FMPPE0/1/2/3, USER_DBG, and USER_REG0/1
registers.
■ Changed buffer type for WAKE pin to TTL and HIB pin to OD.
■ In ADC characteristics table, changed Max value for GAIN parameter from ±1 to ±3 and added E
(Internal voltage reference error) parameter.
■ Additional minor data sheet clarifications and corrections.
September 04, 201024
Texas Instruments-Production Data
IR
Table 1. Revision History (continued)
DescriptionRevisionDate
5367April 2009
■ Added JTAG/SWD clarification (see “Communication with JTAG/SWD” on page 160).
■ Added clarification that the PLL operates at 400 MHz, but is divided by two prior to the application
of the output divisor.
■ Added "GPIO Module DC Characteristics" table (see Table 20-4 on page 610).
■ Additional minor data sheet clarifications and corrections.
Stellaris® LM3S1165 Microcontroller
4660January 2009
4283November 2008
4149October 2008
3447August 2008
2972May 2008
■ Corrected bit type for RELOAD bit field in SysTick Reload Value register; changed to R/W.
■ Clarification added as to what happens when the SSI in slave mode is required to transmit but there
is no data in the TX FIFO.
■ Additional minor data sheet clarifications and corrections.
■ Revised High-Level Block Diagram.
■ Additional minor data sheet clarifications and corrections were made.
■ Corrected values for DSOSCSRC bit field in Deep Sleep Clock Configuration (DSLPCLKCFG)
register.
■ The FMA value for the FMPRE3 register was incorrect in the Flash Resident Registers table in the
Internal Memory chapter. The correct value is 0x0000.0006.
■ Incorrect Comparator Operating Modes tables were removed from the Analog Comparators chapter.
■ Added note on clearing interrupts to Interrupts chapter.
■ Added Power Architecture diagram to System Control chapter.
■ Additional minor data sheet clarifications and corrections.
■ Additional minor data sheet clarifications and corrections.3108July 2008
■ The 108-Ball BGA pin diagram and pin tables had an error. The following signals were erroneously
indicated as available and have now been changed to a No Connect (NC):
– Ball C1: Changed PE7 to NC
– Ball C2: Changed PE6 to NC
– Ball D2: Changed PE5 to NC
– Ball D1: Changed PE4 to NC
■ As noted in the PCN, the option to provide VDD25 power from external sources was removed. Use
the LDO output as the source of VDD25 input.
■ Additional minor data sheet clarifications and corrections.
2881April 2008 ■ The ΘJAvalue was changed from 55.3 to 34 in the "Thermal Characteristics" table in the Operating
Characteristics chapter.
■ Bit 31 of the DC3 register was incorrectly described in prior versions of the data sheet. A reset of
1 indicates that an even CCP pin is present and can be used as a 32-KHz input clock.
■ Values for I
Characteristics" chapter.
DD_HIBERNATE
were added to the "Detailed Power Specifications" table in the "Electrical
25September 04, 2010
Texas Instruments-Production Data
Revision History
Table 1. Revision History (continued)
DescriptionRevisionDate
■ The "Hibernation Module DC Electricals" table was added to the "Electrical Characteristics" chapter.
■ The T
was changed from a max of 100 to 250.
■ The maximum value on Core supply voltage (V
Characteristics" chapter was changed from 4 to 3.
■ The operational frequency of the internal 30-kHz oscillator clock source is 30 kHz ± 50% (prior data
sheets incorrectly noted it as 30 kHz ± 30%).
■ A value of 0x3 in bits 5:4 of the MISC register (OSCSRC) indicates the 30-KHz internal oscillator is
the input source for the oscillator. Prior data sheets incorrectly noted 0x3 as a reserved value.
■ The reset for bits 6:4 of the RCC2 register (OSCSRC2) is 0x1 (IOSC). Prior data sheets incorrectly
noted the reset was 0x0 (MOSC).
■ Two figures on clock source were added to the "Hibernation Module":
– Clock Source Using Crystal
– Clock Source Using Dedicated Oscillator
■ The following notes on battery management were added to the "Hibernation Module" chapter:
– Battery voltage is not measured while in Hibernate mode.
– System level factors may affect the accuracy of the low battery detect circuit. The designer
should consider battery type, discharge characteristics, and a test load during battery voltage
measurements.
■ A note on high-current applications was added to the GPIO chapter:
For special high-current applications, the GPIO output buffers may be used with the following
restrictions. With the GPIO pins configured as 8-mA output drivers, a total of four GPIO outputs may
be used to sink current loads up to 18 mA each. At 18-mA sink current loading, the VOL value is
specified as 1.2 V. The high-current GPIO package pins must be selected such that there are only
a maximum of two per side of the physical package or BGA pin group with the total number of
high-current GPIO outputs not exceeding four for the entire package.
parameter in the "Reset Characteristics" table in the "Electrical Characteristics" chapter
VDDRISE
) in the "Maximum Ratings" table in the "Electrical
DD25
■ A note on Schmitt inputs was added to the GPIO chapter:
Pins configured as digital inputs are Schmitt-triggered.
■ The Buffer type on the WAKE pin changed from OD to - in the Signal Tables.
■ The "Differential Sampling Range" figures in the ADC chapter were clarified.
■ The last revision of the data sheet (revision 2550) introduced two errors that have now been corrected:
– The LQFP pin diagrams and pin tables were missing the comparator positive and negative input
pins.
– The base address was listed incorrectly in the FMPRE0 and FMPPE0 register bit diagrams.
■ Additional minor data sheet clarifications and corrections.
Started tracking revision history.2550March 2008
September 04, 201026
Texas Instruments-Production Data
About This Document
This data sheet provides reference information for the LM3S1165 microcontroller, describing the
functional blocks of the system-on-chip (SoC) device designed around the ARM® Cortex™-M3
core.
Audience
This manual is intended for system software developers, hardware designers, and application
developers.
About This Manual
This document is organized into sections that correspond to each major feature.
Related Documents
The following related documents are available on the Stellaris®web site at www.ti.com/stellaris:
■
Stellaris® Errata
Stellaris® LM3S1165 Microcontroller
■
ARM® Cortex™-M3 Errata
■
Cortex™-M3 Instruction Set Technical User's Manual
■
Stellaris® Graphics Library User's Guide
■
Stellaris® Peripheral Driver Library User's Guide
The following related documents are also referenced:
■
ARM® Debug Interface V5 Architecture Specification
■
IEEE Standard 1149.1-Test Access Port and Boundary-Scan Architecture
This documentation list was current as of publication date. Please check the web site for additional
documentation, including application notes and white papers.
Texas Instruments-Production Data
27September 04, 2010
About This Document
Documentation Conventions
This document uses the conventions shown in Table 2 on page 28.
Table 2. Documentation Conventions
MeaningNotation
General Register Notation
REGISTER
offset 0xnnn
Register N
reserved
yy:xx
Register Bit/Field
Types
R/W1C
R/W1S
W1C
Reset Value
Pin/Signal Notation
APB registers are indicated in uppercase bold. For example, PBORCTL is the Power-On and
Brown-Out Reset Control register. If a register name contains a lowercase n, it represents more
than one register. For example, SRCRn represents any (or all) of the three Software Reset Control
registers: SRCR0, SRCR1 , and SRCR2.
A single bit in a register.bit
Two or more consecutive and related bits.bit field
A hexadecimal increment to a register's address, relative to that module's base address as specified
in Table 2-4 on page 65.
Registers are numbered consecutively throughout the document to aid in referencing them. The
register number has no meaning to software.
Register bits marked reserved are reserved for future use. In most cases, reserved bits are set to
0; however, user software should not rely on the value of a reserved bit. To provide software
compatibility with future products, the value of a reserved bit should be preserved across a
read-modify-write operation.
The range of register bits inclusive from xx to yy. For example, 31:15 means bits 15 through 31 in
that register.
This value in the register bit diagram indicates whether software running on the controller can
change the value of the bit field.
Software can read this field. The bit or field is cleared by hardware after reading the bit/field.RC
Software can read this field. Always write the chip reset value.RO
Software can read or write this field.R/W
Software can read or write this field. Writing to it with any value clears the register.R/WC
Software can read or write this field. A write of a 0 to a W1C bit does not affect the bit value in the
register. A write of a 1 clears the value of the bit in the register; the remaining bits remain unchanged.
This register type is primarily used for clearing interrupt status bits where the read operation
provides the interrupt status and the write of the read value clears only the interrupts being reported
at the time the register was read.
Software can read or write a 1 to this field. A write of a 0 to a R/W1S bit does not affect the bit
value in the register.
Software can write this field. A write of a 0 to a W1C bit does not affect the bit value in the register.
A write of a 1 clears the value of the bit in the register; the remaining bits remain unchanged. A
read of the register returns no meaningful data.
This register is typically used to clear the corresponding bit in an interrupt register.
Only a write by software is valid; a read of the register returns no meaningful data.WO
This value in the register bit diagram shows the bit/field value after any reset, unless noted.Register Bit/Field
Bit cleared to 0 on chip reset.0
Bit set to 1 on chip reset.1
Nondeterministic.-
Pin alternate function; a pin defaults to the signal without the brackets.[ ]
Refers to the physical connection on the package.pin
Texas Instruments-Production Data
September 04, 201028
Table 2. Documentation Conventions (continued)
MeaningNotation
Refers to the electrical signal encoding of a pin.signal
assert a signal
SIGNAL
SIGNAL
Numbers
X
0x
Change the value of the signal from the logically False state to the logically True state. For active
High signals, the asserted signal value is 1 (High); for active Low signals, the asserted signal value
is 0 (Low). The active polarity (High or Low) is defined by the signal name (see SIGNAL and SIGNAL
below).
Change the value of the signal from the logically True state to the logically False state.deassert a signal
Signal names are in uppercase and in the Courier font. An overbar on a signal name indicates that
it is active Low. To assert SIGNAL is to drive it Low; to deassert SIGNAL is to drive it High.
Signal names are in uppercase and in the Courier font. An active High signal has no overbar. To
assert SIGNAL is to drive it High; to deassert SIGNAL is to drive it Low.
An uppercase X indicates any of several values is allowed, where X can be any legal pattern. For
example, a binary value of 0X00 can be either 0100 or 0000, a hex value of 0xX is 0x0 or 0x1, and
so on.
Hexadecimal numbers have a prefix of 0x. For example, 0x00FF is the hexadecimal number FF.
All other numbers within register tables are assumed to be binary. Within conceptual information,
binary numbers are indicated with a b suffix, for example, 1011b, and decimal numbers are written
without a prefix or suffix.
Stellaris® LM3S1165 Microcontroller
Texas Instruments-Production Data
29September 04, 2010
Architectural Overview
1 Architectural Overview
The Stellaris®family of microcontrollers—the first ARM® Cortex™-M3 based controllers—brings
high-performance 32-bit computing to cost-sensitive embedded microcontroller applications. These
pioneering parts deliver customers 32-bit performance at a cost equivalent to legacy 8- and 16-bit
devices, all in a package with a small footprint.
The Stellaris®family offers efficient performance and extensive integration, favorably positioning
the device into cost-conscious applications requiring significant control-processing and connectivity
capabilities. The Stellaris®LM3S1000 series extends the Stellaris®family with larger on-chip
memories, enhanced power management, and expanded I/O and control capabilities.
The LM3S1165 microcontroller is targeted for industrial applications, including remote monitoring,
electronic point-of-sale machines, test and measurement equipment, network appliances and
switches, factory automation, HVAC and building control, gaming equipment, motion control, medical
instrumentation, and fire and security.
For applications requiring extreme conservation of power, the LM3S1165 microcontroller features
a battery-backed Hibernation module to efficiently power down the LM3S1165 to a low-power state
during extended periods of inactivity. With a power-up/power-down sequencer, a continuous time
counter (RTC), a pair of match registers, an APB interface to the system bus, and dedicated
non-volatile memory, the Hibernation module positions the LM3S1165 microcontroller perfectly for
battery applications.
In addition, the LM3S1165 microcontroller offers the advantages of ARM's widely available
development tools, System-on-Chip (SoC) infrastructure IP applications, and a large user community.
Additionally, the microcontroller uses ARM's Thumb®-compatible Thumb-2 instruction set to reduce
memory requirements and, thereby, cost. Finally, the LM3S1165 microcontroller is code-compatible
to all members of the extensive Stellaris®family; providing flexibility to fit our customers' precise
needs.
Texas Instruments offers a complete solution to get to market quickly, with evaluation and
development boards, white papers and application notes, an easy-to-use peripheral driver library,
and a strong support, sales, and distributor network. See “Ordering and Contact
Information” on page 651 for ordering information for Stellaris®family devices.
1.1 Product Features
The LM3S1165 microcontroller includes the following product features:
■ 32-Bit RISC Performance
– 32-bit ARM® Cortex™-M3 v7M architecture optimized for small-footprint embedded
applications
– System timer (SysTick), providing a simple, 24-bit clear-on-write, decrementing, wrap-on-zero
counter with a flexible control mechanism
– Thumb®-compatible Thumb-2-only instruction set processor core for high code density
– 50-MHz operation
– Hardware-division and single-cycle-multiplication
Texas Instruments-Production Data
September 04, 201030
Stellaris® LM3S1165 Microcontroller
– Integrated Nested Vectored Interrupt Controller (NVIC) providing deterministic interrupt
handling
– 35 interrupts with eight priority levels
– Memory protection unit (MPU), providing a privileged mode for protected operating system
functionality
– Unaligned data access, enabling data to be efficiently packed into memory
– Atomic bit manipulation (bit-banding), delivering maximum memory utilization and streamlined
peripheral control
■ ARM® Cortex™-M3 Processor Core
– Compact core.
– Thumb-2 instruction set, delivering the high-performance expected of an ARM core in the
memory size usually associated with 8- and 16-bit devices; typically in the range of a few
kilobytes of memory for microcontroller class applications.
– Rapid application execution through Harvard architecture characterized by separate buses
for instruction and data.
– Exceptional interrupt handling, by implementing the register manipulations required for handling
an interrupt in hardware.
– Deterministic, fast interrupt processing: always 12 cycles, or just 6 cycles with tail-chaining
– Memory protection unit (MPU) to provide a privileged mode of operation for complex
applications.
– Migration from the ARM7™ processor family for better performance and power efficiency.
– Full-featured debug solution
• Serial Wire JTAG Debug Port (SWJ-DP)
• Flash Patch and Breakpoint (FPB) unit for implementing breakpoints
• Data Watchpoint and Trigger (DWT) unit for implementing watchpoints, trigger resources,
and system profiling
• Instrumentation Trace Macrocell (ITM) for support of printf style debugging
• Trace Port Interface Unit (TPIU) for bridging to a Trace Port Analyzer
– Optimized for single-cycle flash usage
– Three sleep modes with clock gating for low power
– Single-cycle multiply instruction and hardware divide
– Atomic operations
– ARM Thumb2 mixed 16-/32-bit instruction set
Texas Instruments-Production Data
31September 04, 2010
Architectural Overview
– 1.25 DMIPS/MHz
■ JTAG
– IEEE 1149.1-1990 compatible Test Access Port (TAP) controller
– Four-bit Instruction Register (IR) chain for storing JTAG instructions
– IEEE standard instructions: BYPASS, IDCODE, SAMPLE/PRELOAD, EXTEST and INTEST
– ARM additional instructions: APACC, DPACC and ABORT
– Integrated ARM Serial Wire Debug (SWD)
■ Hibernation
– System power control using discrete external regulator
– Dedicated pin for waking from an external signal
– Low-battery detection, signaling, and interrupt generation
– 32-bit real-time clock (RTC)
– Two 32-bit RTC match registers for timed wake-up and interrupt generation
– Clock source from a 32.768-kHz external oscillator or a 4.194304-MHz crystal
– RTC predivider trim for making fine adjustments to the clock rate
– 64 32-bit words of non-volatile memory
– Programmable interrupts for RTC match, external wake, and low battery events
■ Internal Memory
– 64 KB single-cycle flash
• User-managed flash block protection on a 2-KB block basis
• User-managed flash data programming
• User-defined and managed flash-protection block
– 16 KB single-cycle SRAM
■ GPIOs
– 4-43 GPIOs, depending on configuration
– 5-V-tolerant in input configuration
– Programmable control for GPIO interrupts
• Interrupt generation masking
• Edge-triggered on rising, falling, or both
Texas Instruments-Production Data
September 04, 201032
Stellaris® LM3S1165 Microcontroller
• Level-sensitive on High or Low values
– Bit masking in both read and write operations through address lines
– Can initiate an ADC sample sequence
– Pins configured as digital inputs are Schmitt-triggered.
– Programmable control for GPIO pad configuration
• Weak pull-up or pull-down resistors
• 2-mA, 4-mA, and 8-mA pad drive for digital communication; up to four pads can be
configured with an 18-mA pad drive for high-current applications
• Slew rate control for the 8-mA drive
• Open drain enables
• Digital input enables
■ General-Purpose Timers
– Four General-Purpose Timer Modules (GPTM), each of which provides two 16-bit
timers/counters. Each GPTM can be configured to operate independently:
• As a single 32-bit timer
• As one 32-bit Real-Time Clock (RTC) to event capture
• For Pulse Width Modulation (PWM)
• To trigger analog-to-digital conversions
– 32-bit Timer modes
• Programmable one-shot timer
• Programmable periodic timer
• Real-Time Clock when using an external 32.768-KHz clock as the input
• User-enabled stalling when the controller asserts CPU Halt flag during debug
• ADC event trigger
– 16-bit Timer modes
• General-purpose timer function with an 8-bit prescaler (for one-shot and periodic modes
only)
• Programmable one-shot timer
• Programmable periodic timer
• User-enabled stalling when the controller asserts CPU Halt flag during debug
Texas Instruments-Production Data
33September 04, 2010
Architectural Overview
• ADC event trigger
– 16-bit Input Capture modes
• Input edge count capture
• Input edge time capture
– 16-bit PWM mode
• Simple PWM mode with software-programmable output inversion of the PWM signal
■ ARM FiRM-compliant Watchdog Timer
– 32-bit down counter with a programmable load register
– Separate watchdog clock with an enable
– Programmable interrupt generation logic with interrupt masking
– Lock register protection from runaway software
– Reset generation logic with an enable/disable
– User-enabled stalling when the controller asserts the CPU Halt flag during debug
■ ADC
– Four analog input channels
– Single-ended and differential-input configurations
– On-chip internal temperature sensor
– Sample rate of 500 thousand samples/second
– Flexible, configurable analog-to-digital conversion
– Four programmable sample conversion sequences from one to eight entries long, with
corresponding conversion result FIFOs
– Flexible trigger control
• Controller (software)
• Timers
• Analog Comparators
• PWM
• GPIO
– Hardware averaging of up to 64 samples for improved accuracy
– Converter uses an internal 3-V reference
Texas Instruments-Production Data
September 04, 201034
Stellaris® LM3S1165 Microcontroller
– Power and ground for the analog circuitry is separate from the digital power and ground
■ UART
– Three fully programmable 16C550-type UARTs with IrDA support
– Separate 16x8 transmit (TX) and receive (RX) FIFOs to reduce CPU interrupt service loading
– Programmable baud-rate generator allowing speeds up to 3.125 Mbps
– Programmable FIFO length, including 1-byte deep operation providing conventional
double-buffered interface
– FIFO trigger levels of 1/8, 1/4, 1/2, 3/4, and 7/8
– Standard asynchronous communication bits for start, stop, and parity
– False-start bit detection
– Line-break generation and detection
– Fully programmable serial interface characteristics
• 5, 6, 7, or 8 data bits
• Even, odd, stick, or no-parity bit generation/detection
• 1 or 2 stop bit generation
– IrDA serial-IR (SIR) encoder/decoder providing
• Programmable use of IrDA Serial Infrared (SIR) or UART input/output
• Support of IrDA SIR encoder/decoder functions for data rates up to 115.2 Kbps half-duplex
• Support of normal 3/16 and low-power (1.41-2.23 μs) bit durations
• Programmable internal clock generator enabling division of reference clock by 1 to 256
for low-power mode bit duration
■ Synchronous Serial Interface (SSI)
– Two SSI modules, each with the following features:
– Master or slave operation
– Programmable clock bit rate and prescale
– Separate transmit and receive FIFOs, 16 bits wide, 8 locations deep
– Programmable interface operation for Freescale SPI, MICROWIRE, or Texas Instruments
synchronous serial interfaces
– Programmable data frame size from 4 to 16 bits
– Internal loopback test mode for diagnostic/debug testing
Texas Instruments-Production Data
35September 04, 2010
Architectural Overview
■ I2C
– Devices on the I2C bus can be designated as either a master or a slave
• Supports both sending and receiving data as either a master or a slave
• Supports simultaneous master and slave operation
– Four I2C modes
• Master transmit
• Master receive
• Slave transmit
• Slave receive
– Two transmission speeds: Standard (100 Kbps) and Fast (400 Kbps)
– Master and slave interrupt generation
• Master generates interrupts when a transmit or receive operation completes (or aborts
due to an error)
• Slave generates interrupts when data has been sent or requested by a master
– Master with arbitration and clock synchronization, multimaster support, and 7-bit addressing
mode
■ Analog Comparators
– One integrated analog comparator
– Configurable for output to drive an output pin, generate an interrupt, or initiate an ADC sample
sequence
– Compare external pin input to external pin input or to internal programmable voltage reference
– Compare a test voltage against any one of these voltages
• An individual external reference voltage
• A shared single external reference voltage
• A shared internal reference voltage
■ PWM
– Three PWM generator blocks, each with one 16-bit counter, two PWM comparators, a PWM
signal generator, a dead-band generator, and an interrupt/ADC-trigger selector
– One fault input in hardware to promote low-latency shutdown
– One 16-bit counter
September 04, 201036
Texas Instruments-Production Data
Stellaris® LM3S1165 Microcontroller
• Runs in Down or Up/Down mode
• Output frequency controlled by a 16-bit load value
• Load value updates can be synchronized
• Produces output signals at zero and load value
– Two PWM comparators
• Comparator value updates can be synchronized
• Produces output signals on match
– PWM generator
• Output PWM signal is constructed based on actions taken as a result of the counter and
PWM comparator output signals
• Produces two independent PWM signals
– Dead-band generator
• Produces two PWM signals with programmable dead-band delays suitable for driving a
half-H bridge
• Can be bypassed, leaving input PWM signals unmodified
– Flexible output control block with PWM output enable of each PWM signal
• PWM output enable of each PWM signal
• Optional output inversion of each PWM signal (polarity control)
• Optional fault handling for each PWM signal
• Synchronization of timers in the PWM generator blocks
• Synchronization of timer/comparator updates across the PWM generator blocks
• Interrupt status summary of the PWM generator blocks
– Can initiate an ADC sample sequence
■ Power
– On-chip Low Drop-Out (LDO) voltage regulator, with programmable output user-adjustable
from 2.25 V to 2.75 V
– Hibernation module handles the power-up/down 3.3 V sequencing and control for the core
digital logic and analog circuits
– Low-power options on controller: Sleep and Deep-sleep modes
– Low-power options for peripherals: software controls shutdown of individual peripherals
– 3.3-V supply brown-out detection and reporting via interrupt or reset
Texas Instruments-Production Data
37September 04, 2010
Architectural Overview
■ Flexible Reset Sources
– Power-on reset (POR)
– Reset pin assertion
– Brown-out (BOR) detector alerts to system power drops
– Software reset
– Watchdog timer reset
– Internal low drop-out (LDO) regulator output goes unregulated
■ Industrial and extended temperature 100-pin RoHS-compliant LQFP package
■ Industrial-range 108-ball RoHS-compliant BGA package
1.2 Target Applications
■ Remote monitoring
■ Electronic point-of-sale (POS) machines
■ Test and measurement equipment
■ Network appliances and switches
■ Factory automation
■ HVAC and building control
■ Gaming equipment
■ Motion control
■ Medical instrumentation
■ Fire and security
■ Power and energy
■ Transportation
1.3 High-Level Block Diagram
Figure 1-1 on page 39 depicts the features on the Stellaris®LM3S1165 microcontroller.
Texas Instruments-Production Data
September 04, 201038
LM3S1165
ARM®
Cortex™-M3
(50 MHz)
NVIC MPU
Flash
(64 KB)
DCode bus
ICode bus
JTAG/SWD
System
Control and
Clocks
Bus Matrix
System Bus
SRAM
(16 KB)
SYSTEM PERIPHERALS
Watchdog
Timer
(1)
Hibernation
Module
General-
Purpose
Timers (4)
GPIOs
(4-43)
SERIAL PERIPHERALS
UARTs
(3)
I2C
(1)
SSI
(2)
ANALOG PERIPHERALS
ADC
Channels
(4)
Analog
Comparator
(1)
MOTION CONTROL PERIPHERALS
PWM
(6)
Advanced Peripheral Bus (APB)
Stellaris® LM3S1165 Microcontroller
Figure 1-1. Stellaris®LM3S1165 Microcontroller High-Level Block Diagram
Texas Instruments-Production Data
39September 04, 2010
Architectural Overview
1.4 Functional Overview
The following sections provide an overview of the features of the LM3S1165 microcontroller. The
page number in parenthesis indicates where that feature is discussed in detail. Ordering and support
information can be found in “Ordering and Contact Information” on page 651.
1.4.1 ARM Cortex™-M3
1.4.1.1 Processor Core (see page 46)
All members of the Stellaris®product family, including the LM3S1165 microcontroller, are designed
around an ARM Cortex™-M3 processor core. The ARM Cortex-M3 processor provides the core for
a high-performance, low-cost platform that meets the needs of minimal memory implementation,
reduced pin count, and low-power consumption, while delivering outstanding computational
performance and exceptional system response to interrupts.
1.4.1.2 Memory Map (see page 65)
A memory map lists the location of instructions and data in memory. The memory map for the
LM3S1165 controller can be found in Table 2-4 on page 65. Register addresses are given as a
hexadecimal increment, relative to the module's base address as shown in the memory map.
1.4.1.3 System Timer (SysTick) (see page 88)
Cortex-M3 includes an integrated system timer, SysTick. SysTick provides a simple, 24-bit
clear-on-write, decrementing, wrap-on-zero counter with a flexible control mechanism. The counter
can be used in several different ways, for example:
■ An RTOS tick timer which fires at a programmable rate (for example, 100 Hz) and invokes a
SysTick routine.
■ A high-speed alarm timer using the system clock.
■ A variable rate alarm or signal timer—the duration is range-dependent on the reference clock
used and the dynamic range of the counter.
■ A simple counter. Software can use this to measure time to completion and time used.
■ An internal clock source control based on missing/meeting durations. The COUNTFLAG bit-field
in the control and status register can be used to determine if an action completed within a set
duration, as part of a dynamic clock management control loop.
1.4.1.4 Nested Vectored Interrupt Controller (NVIC) (see page 89)
The LM3S1165 controller includes the ARM Nested Vectored Interrupt Controller (NVIC) on the
ARM® Cortex™-M3 core. The NVIC and Cortex-M3 prioritize and handle all exceptions. All exceptions
are handled in Handler Mode. The processor state is automatically stored to the stack on an
exception, and automatically restored from the stack at the end of the Interrupt Service Routine
(ISR). The vector is fetched in parallel to the state saving, which enables efficient interrupt entry.
The processor supports tail-chaining, which enables back-to-back interrupts to be performed without
the overhead of state saving and restoration. Software can set eight priority levels on 7 exceptions
(system handlers) and 35 interrupts.
Texas Instruments-Production Data
September 04, 201040
1.4.1.5 System Control Block (SCB) (see page 91)
The SCB provides system implementation information and system control, including configuration,
control, and reporting of system exceptions.
1.4.1.6 Memory Protection Unit (MPU) (see page 91)
The MPU supports the standard ARMv7 Protected Memory System Architecture (PMSA) model.
The MPU provides full support for protection regions, overlapping protection regions, access
permissions, and exporting memory attributes to the system.
1.4.2 Motor Control Peripherals
To enhance motor control, the LM3S1165 controller features Pulse Width Modulation (PWM) outputs.
1.4.2.1 PWM
Pulse width modulation (PWM) is a powerful technique for digitally encoding analog signal levels.
High-resolution counters are used to generate a square wave, and the duty cycle of the square
wave is modulated to encode an analog signal. Typical applications include switching power supplies
and motor control.
On the LM3S1165, PWM motion control functionality can be achieved through:
Stellaris® LM3S1165 Microcontroller
■ Dedicated, flexible motion control hardware using the PWM pins
■ The motion control features of the general-purpose timers using the CCP pins
PWM Pins (see page 542)
The LM3S1165 PWM module consists of three PWM generator blocks and a control block. Each
PWM generator block contains one timer (16-bit down or up/down counter), two comparators, a
PWM signal generator, a dead-band generator, and an interrupt/ADC-trigger selector. The control
block determines the polarity of the PWM signals, and which signals are passed through to the pins.
Each PWM generator block produces two PWM signals that can either be independent signals or
a single pair of complementary signals with dead-band delays inserted. The output of the PWM
generation blocks are managed by the output control block before being passed to the device pins.
CCP Pins (see page 326)
The General-Purpose Timer Module's CCP (Capture Compare PWM) pins are software programmable
to support a simple PWM mode with a software-programmable output inversion of the PWM signal.
Fault Pin (see page 547)
The LM3S1165 PWM module includes one fault-condition handling input to quickly provide low-latency
shutdown and prevent damage to the motor being controlled.
1.4.3 Analog Peripherals
To handle analog signals, the LM3S1165 microcontroller offers an Analog-to-Digital Converter
(ADC).
For support of analog signals, the LM3S1165 microcontroller offers one analog comparator.
Texas Instruments-Production Data
41September 04, 2010
Architectural Overview
1.4.3.1 ADC (see page 380)
An analog-to-digital converter (ADC) is a peripheral that converts a continuous analog voltage to a
discrete digital number.
The LM3S1165 ADC module features 10-bit conversion resolution and supports four input channels,
plus an internal temperature sensor. Four buffered sample sequences allow rapid sampling of up
to eight analog input sources without controller intervention. Each sample sequence provides flexible
programming with fully configurable input source, trigger events, interrupt generation, and sequence
priority.
1.4.3.2 Analog Comparators (see page 531)
An analog comparator is a peripheral that compares two analog voltages, and provides a logical
output that signals the comparison result.
The LM3S1165 microcontroller provides one analog comparator that can be configured to drive an
output or generate an interrupt or ADC event.
A comparator can compare a test voltage against any one of these voltages:
■ An individual external reference voltage
■ A shared single external reference voltage
■ A shared internal reference voltage
The comparator can provide its output to a device pin, acting as a replacement for an analog
comparator on the board, or it can be used to signal the application via interrupts or triggers to the
ADC to cause it to start capturing a sample sequence. The interrupt generation and ADC triggering
logic is separate. This means, for example, that an interrupt can be generated on a rising edge and
the ADC triggered on a falling edge.
1.4.4 Serial Communications Peripherals
The LM3S1165 controller supports both asynchronous and synchronous serial communications
with:
■ Three fully programmable 16C550-type UARTs
■ Two SSI modules
■ One I2C module
1.4.4.1 UART (see page 417)
A Universal Asynchronous Receiver/Transmitter (UART) is an integrated circuit used for RS-232C
serial communications, containing a transmitter (parallel-to-serial converter) and a receiver
(serial-to-parallel converter), each clocked separately.
The LM3S1165 controller includes three fully programmable 16C550-type UARTs that support data
transfer speeds up to 3.125 Mbps. (Although similar in functionality to a 16C550 UART, it is not
register-compatible.) In addition, each UART is capable of supporting IrDA.
Separate 16x8 transmit (TX) and receive (RX) FIFOs reduce CPU interrupt service loading. The
UART can generate individually masked interrupts from the RX, TX, modem status, and error
conditions. The module provides a single combined interrupt when any of the interrupts are asserted
and are unmasked.
September 04, 201042
Texas Instruments-Production Data
1.4.4.2 SSI (see page 458)
Synchronous Serial Interface (SSI) is a four-wire bi-directional full and low-speed communications
interface.
The LM3S1165 controller includes two SSI modules that provide the functionality for synchronous
serial communications with peripheral devices, and can be configured to use the Freescale SPI,
MICROWIRE, or TI synchronous serial interface frame formats. The size of the data frame is also
configurable, and can be set between 4 and 16 bits, inclusive.
Each SSI module performs serial-to-parallel conversion on data received from a peripheral device,
and parallel-to-serial conversion on data transmitted to a peripheral device. The TX and RX paths
are buffered with internal FIFOs, allowing up to eight 16-bit values to be stored independently.
Each SSI module can be configured as either a master or slave device. As a slave device, the SSI
module can also be configured to disable its output, which allows a master device to be coupled
with multiple slave devices.
Each SSI module also includes a programmable bit rate clock divider and prescaler to generate the
output serial clock derived from the SSI module's input clock. Bit rates are generated based on the
input clock and the maximum bit rate is determined by the connected peripheral.
1.4.4.3 I2C (see page 495)
Stellaris® LM3S1165 Microcontroller
The Inter-Integrated Circuit (I2C) bus provides bi-directional data transfer through a two-wire design
(a serial data line SDA and a serial clock line SCL).
The I2C bus interfaces to external I2C devices such as serial memory (RAMs and ROMs), networking
devices, LCDs, tone generators, and so on. The I2C bus may also be used for system testing and
diagnostic purposes in product development and manufacture.
The LM3S1165 controller includes one I2C module that provides the ability to communicate to other
IC devices over an I2C bus. The I2C bus supports devices that can both transmit and receive (write
and read) data.
Devices on the I2C bus can be designated as either a master or a slave. The I2C module supports
both sending and receiving data as either a master or a slave, and also supports the simultaneous
operation as both a master and a slave. The four I2C modes are: Master Transmit, Master Receive,
Slave Transmit, and Slave Receive.
A Stellaris®I2C module can operate at two speeds: Standard (100 Kbps) and Fast (400 Kbps).
Both the I2C master and slave can generate interrupts. The I2C master generates interrupts when
a transmit or receive operation completes (or aborts due to an error). The I2C slave generates
interrupts when data has been sent or requested by a master.
1.4.5 System Peripherals
1.4.5.1 Programmable GPIOs (see page 278)
General-purpose input/output (GPIO) pins offer flexibility for a variety of connections.
The Stellaris®GPIO module is comprised of eight physical GPIO blocks, each corresponding to an
individual GPIO port. The GPIO module is FiRM-compliant (compliant to the ARM Foundation IP
for Real-Time Microcontrollers specification) and supports 4-43 programmable input/output pins.
The number of GPIOs available depends on the peripherals being used (see “Signal
Tables” on page 582 for the signals available to each GPIO pin).
43September 04, 2010
Texas Instruments-Production Data
Architectural Overview
The GPIO module features programmable interrupt generation as either edge-triggered or
level-sensitive on all pins, programmable control for GPIO pad configuration, and bit masking in
both read and write operations through address lines. Pins configured as digital inputs are
Schmitt-triggered.
1.4.5.2 Four Programmable Timers (see page 320)
Programmable timers can be used to count or time external events that drive the Timer input pins.
The Stellaris®General-Purpose Timer Module (GPTM) contains four GPTM blocks. Each GPTM
block provides two 16-bit timers/counters that can be configured to operate independently as timers
or event counters, or configured to operate as one 32-bit timer or one 32-bit Real-Time Clock (RTC).
Timers can also be used to trigger analog-to-digital (ADC) conversions.
When configured in 32-bit mode, a timer can run as a Real-Time Clock (RTC), one-shot timer or
periodic timer. When in 16-bit mode, a timer can run as a one-shot timer or periodic timer, and can
extend its precision by using an 8-bit prescaler. A 16-bit timer can also be configured for event
capture or Pulse Width Modulation (PWM) generation.
1.4.5.3 Watchdog Timer (see page 356)
A watchdog timer can generate an interrupt or a reset when a time-out value is reached. The
watchdog timer is used to regain control when a system has failed due to a software error or to the
failure of an external device to respond in the expected way.
The Stellaris®Watchdog Timer module consists of a 32-bit down counter, a programmable load
register, interrupt generation logic, and a locking register.
The Watchdog Timer can be configured to generate an interrupt to the controller on its first time-out,
and to generate a reset signal on its second time-out. Once the Watchdog Timer has been configured,
the lock register can be written to prevent the timer configuration from being inadvertently altered.
1.4.6 Memory Peripherals
The LM3S1165 controller offers both single-cycle SRAM and single-cycle Flash memory.
1.4.6.1 SRAM (see page 252)
The LM3S1165 static random access memory (SRAM) controller supports 16 KB SRAM. The internal
SRAM of the Stellaris®devices starts at base address 0x2000.0000 of the device memory map. To
reduce the number of time-consuming read-modify-write (RMW) operations, ARM has introduced
bit-banding technology in the new Cortex-M3 processor. With a bit-band-enabled processor, certain
regions in the memory map (SRAM and peripheral space) can use address aliases to access
individual bits in a single, atomic operation.
1.4.6.2 Flash (see page 253)
The LM3S1165 Flash controller supports 64 KB of flash memory. The flash is organized as a set
of 1-KB blocks that can be individually erased. Erasing a block causes the entire contents of the
block to be reset to all 1s. These blocks are paired into a set of 2-KB blocks that can be individually
protected. The blocks can be marked as read-only or execute-only, providing different levels of code
protection. Read-only blocks cannot be erased or programmed, protecting the contents of those
blocks from being modified. Execute-only blocks cannot be erased or programmed, and can only
be read by the controller instruction fetch mechanism, protecting the contents of those blocks from
being read by either the controller or by a debugger.
Texas Instruments-Production Data
September 04, 201044
1.4.7 Additional Features
1.4.7.1 JTAG TAP Controller (see page 154)
The Joint Test Action Group (JTAG) port is an IEEE standard that defines a Test Access Port and
Boundary Scan Architecture for digital integrated circuits and provides a standardized serial interface
for controlling the associated test logic. The TAP, Instruction Register (IR), and Data Registers (DR)
can be used to test the interconnections of assembled printed circuit boards and obtain manufacturing
information on the components. The JTAG Port also provides a means of accessing and controlling
design-for-test features such as I/O pin observation and control, scan testing, and debugging.
The JTAG port is composed of the standard five pins: TRST, TCK, TMS, TDI, and TDO. Data is
transmitted serially into the controller on TDI and out of the controller on TDO. The interpretation of
this data is dependent on the current state of the TAP controller. For detailed information on the
operation of the JTAG port and TAP controller, please refer to the IEEE Standard 1149.1-Test
Access Port and Boundary-Scan Architecture.
The Stellaris®JTAG controller works with the ARM JTAG controller built into the Cortex-M3 core.
This is implemented by multiplexing the TDO outputs from both JTAG controllers. ARM JTAG
instructions select the ARM TDO output while Stellaris®JTAG instructions select the Stellaris®TDO
outputs. The multiplexer is controlled by the Stellaris®JTAG controller, which has comprehensive
programming for the ARM, Stellaris®, and unimplemented JTAG instructions.
Stellaris® LM3S1165 Microcontroller
1.4.7.2 System Control and Clocks (see page 166)
System control determines the overall operation of the device. It provides information about the
device, controls the clocking of the device and individual peripherals, and handles reset detection
and reporting.
1.4.7.3 Hibernation Module (see page 232)
The Hibernation module provides logic to switch power off to the main processor and peripherals,
and to wake on external or time-based events. The Hibernation module includes power-sequencing
logic, a real-time clock with a pair of match registers, low-battery detection circuitry, and interrupt
signalling to the processor. It also includes 64 32-bit words of non-volatile memory that can be used
for saving state during hibernation.
1.4.8 Hardware Details
Details on the pins and package can be found in the following sections:
■ “Pin Diagram” on page 580
■ “Signal Tables” on page 582
■ “Operating Characteristics” on page 608
■ “Electrical Characteristics” on page 609
■ “Package Information” on page 653
Texas Instruments-Production Data
45September 04, 2010
The Cortex-M3 Processor
2 The Cortex-M3 Processor
The ARM® Cortex™-M3 processor provides a high-performance, low-cost platform that meets the
system requirements of minimal memory implementation, reduced pin count, and low power
consumption, while delivering outstanding computational performance and exceptional system
response to interrupts. Features include:
■ Compact core.
■ Thumb-2 instruction set, delivering the high-performance expected of an ARM core in the memory
size usually associated with 8- and 16-bit devices; typically in the range of a few kilobytes of
memory for microcontroller class applications.
■ Rapid application execution through Harvard architecture characterized by separate buses for
instruction and data.
■ Exceptional interrupt handling, by implementing the register manipulations required for handling
an interrupt in hardware.
■ Deterministic, fast interrupt processing: always 12 cycles, or just 6 cycles with tail-chaining
■ Memory protection unit (MPU) to provide a privileged mode of operation for complex applications.
■ Migration from the ARM7™ processor family for better performance and power efficiency.
■ Full-featured debug solution
– Serial Wire JTAG Debug Port (SWJ-DP)
– Flash Patch and Breakpoint (FPB) unit for implementing breakpoints
– Data Watchpoint and Trigger (DWT) unit for implementing watchpoints, trigger resources,
and system profiling
– Instrumentation Trace Macrocell (ITM) for support of printf style debugging
– Trace Port Interface Unit (TPIU) for bridging to a Trace Port Analyzer
■ Optimized for single-cycle flash usage
■ Three sleep modes with clock gating for low power
■ Single-cycle multiply instruction and hardware divide
■ Atomic operations
■ ARM Thumb2 mixed 16-/32-bit instruction set
■ 1.25 DMIPS/MHz
The Stellaris®family of microcontrollers builds on this core to bring high-performance 32-bit computing
to cost-sensitive embedded microcontroller applications, such as factory automation and control,
industrial control power devices, building and home automation, and stepper motor control.
September 04, 201046
Texas Instruments-Production Data
This chapter provides information on the Stellaris®implementation of the Cortex-M3 processor,
including the programming model, the memory model, the exception model, fault handling, and
power management.
For technical details on the instruction set, see the Cortex™-M3 Instruction Set Technical User's
Manual.
2.1 Block Diagram
The Cortex-M3 processor is built on a high-performance processor core, with a 3-stage pipeline
Harvard architecture, making it ideal for demanding embedded applications. The processor delivers
exceptional power efficiency through an efficient instruction set and extensively optimized design,
providing high-end processing hardware including single-cycle 32x32 multiplication and dedicated
hardware division.
To facilitate the design of cost-sensitive devices, the Cortex-M3 processor implements tightly coupled
system components that reduce processor area while significantly improving interrupt handling and
system debug capabilities. The Cortex-M3 processor implements a version of the Thumb® instruction
set, ensuring high code density and reduced program memory requirements. The Cortex-M3
instruction set provides the exceptional performance expected of a modern 32-bit architecture, with
the high code density of 8-bit and 16-bit microcontrollers.
Stellaris® LM3S1165 Microcontroller
The Cortex-M3 processor closely integrates a nested interrupt controller (NVIC), to deliver
industry-leading interrupt performance. The Stellaris®NVIC includes a non-maskable interrupt (NMI)
and provides eight interrupt priority levels. The tight integration of the processor core and NVIC
provides fast execution of interrupt service routines (ISRs), dramatically reducing interrupt latency.
The hardware stacking of registers and the ability to suspend load-multiple and store-multiple
operations further reduce interrupt latency. Interrupt handlers do not require any assembler stubs
which removes code overhead from the ISRs. Tail-chaining optimization also significantly reduces
the overhead when switching from one ISR to another. To optimize low-power designs, the NVIC
integrates with the sleep modes, including Deep-sleep mode, which enables the entire device to be
rapidly powered down.
Texas Instruments-Production Data
47September 04, 2010
Private Peripheral
Bus
(internal)
Data
Watchpoint
and Trace
Interrupts
Debug
Sleep
Instrumentation
Trace Macrocell
Trace
Port
Interface
Unit
CM3 Core
Instructions Data
Flash
Patch and
Breakpoint
Memory
Protection
Unit
Debug
Access Port
Nested
Vectored
Interrupt
Controller
Serial Wire JTAG
Debug Port
Bus
Matrix
Adv. Peripheral
Bus
I-code bus
D-code bus
System bus
ROM
Table
Serial
Wire
Output
Trace
Port
(SWO)
ARM
Cortex-M3
The Cortex-M3 Processor
Figure 2-1. CPU Block Diagram
2.2 Overview
2.2.1 System-Level Interface
The Cortex-M3 processor provides multiple interfaces using AMBA® technology to provide
high-speed, low-latency memory accesses. The core supports unaligned data accesses and
implements atomic bit manipulation that enables faster peripheral controls, system spinlocks, and
thread-safe Boolean data handling.
The Cortex-M3 processor has a memory protection unit (MPU) that provides fine-grain memory
control, enabling applications to implement security privilege levels and separate code, data and
stack on a task-by-task basis.
2.2.2 Integrated Configurable Debug
The Cortex-M3 processor implements a complete hardware debug solution, providing high system
visibility of the processor and memory through either a traditional JTAG port or a 2-pin Serial Wire
Debug (SWD) port that is ideal for microcontrollers and other small package devices. The Stellaris
implementation replaces the ARM SW-DP and JTAG-DP with the ARM CoreSight™-compliant
Serial Wire JTAG Debug Port (SWJ-DP) interface. The SWJ-DP interface combines the SWD and
JTAG debug ports into one module. See the ARM® Debug Interface V5 Architecture Specification
for details on SWJ-DP.
For system trace, the processor integrates an Instrumentation Trace Macrocell (ITM) alongside data
watchpoints and a profiling unit. To enable simple and cost-effective profiling of the system trace
events, a Serial Wire Viewer (SWV) can export a stream of software-generated messages, data
trace, and profiling information through a single pin.
Texas Instruments-Production Data
®
September 04, 201048
The Flash Patch and Breakpoint Unit (FPB) provides up to eight hardware breakpoint comparators
ATB
Interface
Asynchronous FIFO
APB
Interface
Trace Out
(serializer)
Debug
ATB
Slave
Port
APB
Slave
Port
Serial Wire
Trace Port
(SWO)
that debuggers can use. The comparators in the FPB also provide remap functions of up to eight
words in the program code in the CODE memory region. This enables applications stored in a
read-only area of Flash memory to be patched in another area of on-chip SRAM or Flash memory.
If a patch is required, the application programs the FPB to remap a number of addresses. When
those addresses are accessed, the accesses are redirected to a remap table specified in the FPB
configuration.
For more information on the Cortex-M3 debug capabilities, see theARM® Debug Interface V5
Architecture Specification.
2.2.3 Trace Port Interface Unit (TPIU)
The TPIU acts as a bridge between the Cortex-M3 trace data from the ITM, and an off-chip Trace
Port Analyzer, as shown in Figure 2-2 on page 49.
Figure 2-2. TPIU Block Diagram
Stellaris® LM3S1165 Microcontroller
2.2.4 Cortex-M3 System Component Details
The Cortex-M3 includes the following system components:
■ SysTick
A 24-bit count-down timer that can be used as a Real-Time Operating System (RTOS) tick timer
or as a simple counter (see “System Timer (SysTick)” on page 88).
■ Nested Vectored Interrupt Controller (NVIC)
An embedded interrupt controller that supports low latency interrupt processing (see “Nested
Vectored Interrupt Controller (NVIC)” on page 89).
■ System Control Block (SCB)
Texas Instruments-Production Data
49September 04, 2010
The Cortex-M3 Processor
The programming model interface to the processor. The SCB provides system implementation
information and system control, including configuration, control, and reporting of system
exceptions( see “System Control Block (SCB)” on page 91).
■ Memory Protection Unit (MPU)
Improves system reliability by defining the memory attributes for different memory regions. The
MPU provides up to eight different regions and an optional predefined background region (see
“Memory Protection Unit (MPU)” on page 91).
2.3 Programming Model
This section describes the Cortex-M3 programming model. In addition to the individual core register
descriptions, information about the processor modes and privilege levels for software execution and
stacks is included.
2.3.1 Processor Mode and Privilege Levels for Software Execution
The Cortex-M3 has two modes of operation:
■ Thread mode
Used to execute application software. The processor enters Thread mode when it comes out of
reset.
■ Handler mode
Used to handle exceptions. When the processor has finished exception processing, it returns to
Thread mode.
In addition, the Cortex-M3 has two privilege levels:
■ Unprivileged
In this mode, software has the following restrictions:
– Limited access to the MSR and MRS instructions and no use of the CPS instruction
– No access to the system timer, NVIC, or system control block
– Possibly restricted access to memory or peripherals
■ Privileged
In this mode, software can use all the instructions and has access to all resources.
In Thread mode, the CONTROL register (see page 64) controls whether software execution is
privileged or unprivileged. In Handler mode, software execution is always privileged.
Only privileged software can write to the CONTROL register to change the privilege level for software
execution in Thread mode. Unprivileged software can use the SVC instruction to make a supervisor
call to transfer control to privileged software.
2.3.2 Stacks
The processor uses a full descending stack, meaning that the stack pointer indicates the last stacked
item on the stack memory. When the processor pushes a new item onto the stack, it decrements
the stack pointer and then writes the item to the new memory location. The processor implements
September 04, 201050
Texas Instruments-Production Data
two stacks: the main stack and the process stack, with independent copies of the stack pointer (see
SP (R13)
LR (R14)
PC (R15)
R5
R6
R7
R0
R1
R3
R4
R2
R10
R11
R12
R8
R9
Low registers
High registers
MSP
‡
PSP
‡
PSR
PRIMASK
FAULTMASK
BASEPRI
CONTROL
General-purpose registers
Stack Pointer
Link Register
Program Counter
Program status register
Exception mask registers
CONTROL register
Special registers
‡
Banked version of SP
the SP register on page 54).
In Thread mode, the CONTROL register (see page 64) controls whether the processor uses the
main stack or the process stack. In Handler mode, the processor always uses the main stack. The
options for processor operations are shown in Table 2-1 on page 51.
Table 2-1. Summary of Processor Mode, Privilege Level, and Stack Use
a. See page 64.
2.3.3 Register Map
Figure 2-3 on page 51 shows the Cortex-M3 register set. Table 2-2 on page 52 lists the Core
registers. The core registers are not memory mapped and are accessed by register name, so the
base address is n/a (not applicable) and there is no offset.
Figure 2-3. Cortex-M3 Register Set
Stellaris® LM3S1165 Microcontroller
Stack UsedPrivilege LevelUseProcessor Mode
ApplicationsThread
Privileged or unprivileged
a
Main stack or process stack
Main stackAlways privilegedException handlersHandler
a
Texas Instruments-Production Data
51September 04, 2010
The Cortex-M3 Processor
Table 2-2. Processor Register Map
DescriptionResetTypeNameOffset
See
page
53Cortex General-Purpose Register 0-R/WR0-
53Cortex General-Purpose Register 1-R/WR1-
53Cortex General-Purpose Register 2-R/WR2-
53Cortex General-Purpose Register 3-R/WR3-
53Cortex General-Purpose Register 4-R/WR4-
53Cortex General-Purpose Register 5-R/WR5-
53Cortex General-Purpose Register 6-R/WR6-
53Cortex General-Purpose Register 7-R/WR7-
53Cortex General-Purpose Register 8-R/WR8-
53Cortex General-Purpose Register 9-R/WR9-
53Cortex General-Purpose Register 10-R/WR10-
53Cortex General-Purpose Register 11-R/WR11-
53Cortex General-Purpose Register 12-R/WR12-
54Stack Pointer-R/WSP-
55Link Register0xFFFF.FFFFR/WLR-
2.3.4 Register Descriptions
This section lists and describes the Cortex-M3 registers, in the order shown in Figure 2-3 on page 51.
The core registers are not memory mapped and are accessed by register name rather than offset.
Note: The register type shown in the register descriptions refers to type during program execution
in Thread mode and Handler mode. Debug access can differ.
56Program Counter-R/WPC-
57Program Status Register0x0100.0000R/WPSR-
61Priority Mask Register0x0000.0000R/WPRIMASK-
62Fault Mask Register0x0000.0000R/WFAULTMASK-
63Base Priority Mask Register0x0000.0000R/WBASEPRI-
64Control Register0x0000.0000R/WCONTROL-
Texas Instruments-Production Data
September 04, 201052
Stellaris® LM3S1165 Microcontroller
Register 1: Cortex General-Purpose Register 0 (R0)
Register 2: Cortex General-Purpose Register 1 (R1)
Register 3: Cortex General-Purpose Register 2 (R2)
Register 4: Cortex General-Purpose Register 3 (R3)
Register 5: Cortex General-Purpose Register 4 (R4)
Register 6: Cortex General-Purpose Register 5 (R5)
Register 7: Cortex General-Purpose Register 6 (R6)
Register 8: Cortex General-Purpose Register 7 (R7)
Register 9: Cortex General-Purpose Register 8 (R8)
Register 10: Cortex General-Purpose Register 9 (R9)
Register 11: Cortex General-Purpose Register 10 (R10)
Register 12: Cortex General-Purpose Register 11 (R11)
Register 13: Cortex General-Purpose Register 12 (R12)
The Rn registers are 32-bit general-purpose registers for data operations and can be accessed
from either privileged or unprivileged mode.
Cortex General-Purpose Register 0 (R0)
Type R/W, reset -
16171819202122232425262728293031
DATA
R/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WType
----------------Reset
0123456789101112131415
DATA
R/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WType
----------------Reset
DescriptionResetTypeNameBit/Field
Register data.-R/WDATA31:0
Texas Instruments-Production Data
53September 04, 2010
The Cortex-M3 Processor
Register 14: Stack Pointer (SP)
The Stack Pointer (SP) is register R13. In Thread mode, the function of this register changes
depending on the ASP bit in the Control Register (CONTROL) register. When the ASP bit is clear,
this register is the Main Stack Pointer (MSP). When the ASP bit is set, this register is the Process
Stack Pointer (PSP). On reset, the ASP bit is clear, and the processor loads the MSP with the value
from address 0x0000.0000. The MSP can only be accessed in privileged mode; the PSP can be
accessed in either privileged or unprivileged mode.
Stack Pointer (SP)
Type R/W, reset -
SP
SP
16171819202122232425262728293031
R/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WType
----------------Reset
0123456789101112131415
R/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WType
----------------Reset
DescriptionResetTypeNameBit/Field
This field is the address of the stack pointer.-R/WSP31:0
Texas Instruments-Production Data
September 04, 201054
Register 15: Link Register (LR)
The Link Register (LR) is register R14, and it stores the return information for subroutines, function
calls, and exceptions. LR can be accessed from either privileged or unprivileged mode.
EXC_RETURN is loaded into LR on exception entry. See Table 2-10 on page 81 for the values and
description.
Link Register (LR)
Type R/W, reset 0xFFFF.FFFF
Stellaris® LM3S1165 Microcontroller
16171819202122232425262728293031
LINK
R/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WType
1111111111111111Reset
0123456789101112131415
LINK
R/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WType
1111111111111111Reset
DescriptionResetTypeNameBit/Field
This field is the return address.0xFFFF.FFFFR/WLINK31:0
Texas Instruments-Production Data
55September 04, 2010
The Cortex-M3 Processor
Register 16: Program Counter (PC)
The Program Counter (PC) is register R15, and it contains the current program address. On reset,
the processor loads the PC with the value of the reset vector, which is at address 0x0000.0004. Bit
0 of the reset vector is loaded into the THUMB bit of the EPSR at reset and must be 1. The PC register
can be accessed in either privileged or unprivileged mode.
Program Counter (PC)
Type R/W, reset -
16171819202122232425262728293031
PC
R/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WType
----------------Reset
0123456789101112131415
PC
R/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WR/WType
----------------Reset
DescriptionResetTypeNameBit/Field
This field is the current program address.-R/WPC31:0
Texas Instruments-Production Data
September 04, 201056
Stellaris® LM3S1165 Microcontroller
Register 17: Program Status Register (PSR)
Note: This register is also referred to as xPSR.
The Program Status Register (PSR) has three functions, and the register bits are assigned to the
different functions:
■ Application Program Status Register (APSR), bits 31:27,
■ Execution Program Status Register (EPSR), bits 26:24, 15:10
■ Interrupt Program Status Register (IPSR), bits 5:0
The PSR, IPSR, and EPSR registers can only be accessed in privileged mode; the APSR register
can be accessed in either privileged or unprivileged mode.
APSR contains the current state of the condition flags from previous instruction executions.
EPSR contains the Thumb state bit and the execution state bits for the If-Then (IT) instruction or
the Interruptible-Continuable Instruction (ICI) field for an interrupted load multiple or store multiple
instruction. Attempts to read the EPSR directly through application software using the MSR instruction
always return zero. Attempts to write the EPSR using the MSR instruction in application software
are always ignored. Fault handlers can examine the EPSR value in the stacked PSR to determine
the operation that faulted (see “Exception Entry and Return” on page 79).
IPSR contains the exception type number of the current Interrupt Service Routine (ISR).
These registers can be accessed individually or as a combination of any two or all three registers,
using the register name as an argument to the MSR or MRS instructions. For example, all of the
registers can be read using PSR with the MRS instruction, or APSR only can be written to using
APSR with the MSR instruction. page 57 shows the possible register combinations for the PSR. See
the MRS and MSR instruction descriptions in the Cortex™-M3 Instruction Set Technical User's Manual
for more information about how to access the program status registers.
Table 2-3. PSR Register Combinations
PSR
IAPSR
EAPSR
a. The processor ignores writes to the IPSR bits.
b. Reads of the EPSR bits return zero, and the processor ignores writes to these bits.
Program Status Register (PSR)
Type R/W, reset 0x0100.0000
a,b
a
b
CombinationTypeRegister
APSR, EPSR, and IPSRR/W
EPSR and IPSRROIEPSR
APSR and IPSRR/W
APSR and EPSRR/W
16171819202122232425262728293031
reservedTHUMBICI / ITQVCZN
ROROROROROROROROROROROR/WR/WR/WR/WR/WType
0000000010000000Reset
0123456789101112131415
ISRNUMreservedICI / IT
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
Texas Instruments-Production Data
57September 04, 2010
The Cortex-M3 Processor
DescriptionResetTypeNameBit/Field
0R/WN31
0R/WZ30
0R/WC29
APSR Negative or Less Flag
DescriptionValue
The previous operation result was negative or less than.1
The previous operation result was positive, zero, greater than,
0
or equal.
The value of this bit is only meaningful when accessing PSR or APSR.
APSR Zero Flag
DescriptionValue
The previous operation result was zero.1
The previous operation result was non-zero.0
The value of this bit is only meaningful when accessing PSR or APSR.
APSR Carry or Borrow Flag
DescriptionValue
The previous add operation resulted in a carry bit or the previous
1
subtract operation did not result in a borrow bit.
The previous add operation did not result in a carry bit or the
0
previous subtract operation resulted in a borrow bit.
The value of this bit is only meaningful when accessing PSR or APSR.
0R/WV28
0R/WQ27
APSR Overflow Flag
DescriptionValue
The previous operation resulted in an overflow.1
The previous operation did not result in an overflow.0
The value of this bit is only meaningful when accessing PSR or APSR.
APSR DSP Overflow and Saturation Flag
DescriptionValue
DSP Overflow or saturation has occurred.1
DSP overflow or saturation has not occurred since reset or since
0
the bit was last cleared.
The value of this bit is only meaningful when accessing PSR or APSR.
This bit is cleared by software using an MRS instruction.
Texas Instruments-Production Data
September 04, 201058
Stellaris® LM3S1165 Microcontroller
DescriptionResetTypeNameBit/Field
0x0ROICI / IT26:25
1ROTHUMB24
EPSR ICI / IT status
These bits, along with bits 15:10, contain the Interruptible-Continuable
Instruction (ICI) field for an interrupted load multiple or store multiple
instruction or the execution state bits of the IT instruction.
When EPSR holds the ICI execution state, bits 26:25 are zero.
The If-Then block contains up to four instructions following a 16-bit IT
instruction. Each instruction in the block is conditional. The conditions
for the instructions are either all the same, or some can be the inverse
of others. See the Cortex™-M3 Instruction Set Technical User's Manual
for more information.
The value of this field is only meaningful when accessing PSR or EPSR.
EPSR Thumb State
This bit indicates the Thumb state and should always be set.
The following can clear the THUMB bit:
■ The BLX, BX and POP{PC} instructions
■ Restoration from the stacked xPSR value on an exception return
■ Bit 0 of the vector value on an exception entry
Attempting to execute instructions when this bit is clear results in a fault
or lockup. See “Lockup” on page 83 for more information.
The value of this bit is only meaningful when accessing PSR or EPSR.
0x00ROreserved23:16
0x0ROICI / IT15:10
0x0ROreserved9:6
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
EPSR ICI / IT status
These bits, along with bits 26:25, contain the Interruptible-Continuable
Instruction (ICI) field for an interrupted load multiple or store multiple
instruction or the execution state bits of the IT instruction.
When an interrupt occurs during the execution of an LDM, STM, PUSH
or POP instruction, the processor stops the load multiple or store multiple
instruction operation temporarily and stores the next register operand
in the multiple operation to bits 15:12. After servicing the interrupt, the
processor returns to the register pointed to by bits 15:12 and resumes
execution of the multiple load or store instruction. When EPSR holds
the ICI execution state, bits 11:10 are zero.
The If-Then block contains up to four instructions following a 16-bit IT
instruction. Each instruction in the block is conditional. The conditions
for the instructions are either all the same, or some can be the inverse
of others. See the Cortex™-M3 Instruction Set Technical User's Manual
for more information.
The value of this field is only meaningful when accessing PSR or EPSR.
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
Texas Instruments-Production Data
59September 04, 2010
The Cortex-M3 Processor
DescriptionResetTypeNameBit/Field
0x00ROISRNUM5:0
IPSR ISR Number
This field contains the exception type number of the current Interrupt
Service Routine (ISR).
DescriptionValue
Thread mode0x00
Reserved0x01
NMI0x02
Hard fault0x03
Memory management fault0x04
Bus fault0x05
Usage fault0x06
Reserved0x07-0x0A
SVCall0x0B
Reserved for Debug0x0C
Reserved0x0D
PendSV0x0E
SysTick0x0F
Interrupt Vector 00x10
Interrupt Vector 10x11
......
Interrupt Vector 430x3B
Reserved0x3C-0x3F
See “Exception Types” on page 74 for more information.
The value of this field is only meaningful when accessing PSR or IPSR.
Texas Instruments-Production Data
September 04, 201060
Register 18: Priority Mask Register (PRIMASK)
The PRIMASK register prevents activation of all exceptions with programmable priority. Reset,
non-maskable interrupt (NMI), and hard fault are the only exceptions with fixed priority. Exceptions
should be disabled when they might impact the timing of critical tasks. This register is only accessible
in privileged mode. The MSR and MRS instructions are used to access the PRIMASK register, and
the CPS instruction may be used to change the value of the PRIMASK register. See the Cortex™-M3
Instruction Set Technical User's Manual for more information on these instructions. For more
information on exception priority levels, see “Exception Types” on page 74.
Priority Mask Register (PRIMASK)
Type R/W, reset 0x0000.0000
reserved
Stellaris® LM3S1165 Microcontroller
16171819202122232425262728293031
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
PRIMASKreserved
R/WROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
0x0000.000ROreserved31:1
0R/WPRIMASK0
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
Priority Mask
DescriptionValue
Prevents the activation of all exceptions with configurable
1
priority.
No effect.0
Texas Instruments-Production Data
61September 04, 2010
The Cortex-M3 Processor
Register 19: Fault Mask Register (FAULTMASK)
The FAULTMASK register prevents activation of all exceptions except for the Non-Maskable Interrupt
(NMI). Exceptions should be disabled when they might impact the timing of critical tasks. This register
is only accessible in privileged mode. The MSR and MRS instructions are used to access the
FAULTMASK register, and the CPS instruction may be used to change the value of the FAULTMASK
register. See the Cortex™-M3 Instruction Set Technical User's Manual for more information on
these instructions. For more information on exception priority levels, see “Exception
Types” on page 74.
Fault Mask Register (FAULTMASK)
Type R/W, reset 0x0000.0000
reserved
reserved
16171819202122232425262728293031
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
FAULTMASK
R/WROROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
0x0000.000ROreserved31:1
0R/WFAULTMASK0
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
Fault Mask
DescriptionValue
Prevents the activation of all exceptions except for NMI.1
No effect.0
The processor clears the FAULTMASK bit on exit from any exception
handler except the NMI handler.
Texas Instruments-Production Data
September 04, 201062
Register 20: Base Priority Mask Register (BASEPRI)
The BASEPRI register defines the minimum priority for exception processing. When BASEPRI is
set to a nonzero value, it prevents the activation of all exceptions with the same or lower priority
level as the BASEPRI value. Exceptions should be disabled when they might impact the timing of
critical tasks. This register is only accessible in privileged mode. For more information on exception
priority levels, see “Exception Types” on page 74.
Base Priority Mask Register (BASEPRI)
Type R/W, reset 0x0000.0000
reserved
DescriptionResetTypeNameBit/Field
Stellaris® LM3S1165 Microcontroller
16171819202122232425262728293031
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
reservedBASEPRIreserved
ROROROROROR/WR/WR/WROROROROROROROROType
0000000000000000Reset
0x0000.00ROreserved31:8
0x0R/WBASEPRI7:5
0x0ROreserved4:0
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
Base Priority
Any exception that has a programmable priority level with the same or
lower priority as the value of this field is masked. The PRIMASK register
can be used to mask all exceptions with programmable priority levels.
Higher priority exceptions have lower priority levels.
DescriptionValue
All exceptions are unmasked.0x0
All exceptions with priority level 1-7 are masked.0x1
All exceptions with priority level 2-7 are masked.0x2
All exceptions with priority level 3-7 are masked.0x3
All exceptions with priority level 4-7 are masked.0x4
All exceptions with priority level 5-7 are masked.0x5
All exceptions with priority level 6-7 are masked.0x6
All exceptions with priority level 7 are masked.0x7
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
Texas Instruments-Production Data
63September 04, 2010
The Cortex-M3 Processor
Register 21: Control Register (CONTROL)
The CONTROL register controls the stack used and the privilege level for software execution when
the processor is in Thread mode. This register is only accessible in privileged mode.
Handler mode always uses MSP, so the processor ignores explicit writes to the ASP bit of the
CONTROL register when in Handler mode. The exception entry and return mechanisms automatically
update the CONTROL register based on the EXC_RETURN value (see Table 2-10 on page 81).
In an OS environment, threads running in Thread mode should use the process stack and the kernel
and exception handlers should use the main stack. By default, Thread mode uses MSP. To switch
the stack pointer used in Thread mode to PSP, either use the MSR instruction to set the ASP bit, as
detailed in the Cortex™-M3 Instruction Set Technical User's Manual, or perform an exception return
to Thread mode with the appropriate EXC_RETURN value, as shown in Table 2-10 on page 81.
Note: When changing the stack pointer, software must use an ISB instruction immediately after
the MSR instruction, ensuring that instructions after the ISB execute use the new stack
pointer. See the Cortex™-M3 Instruction Set Technical User's Manual.
Control Register (CONTROL)
Type R/W, reset 0x0000.0000
reserved
16171819202122232425262728293031
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
TMPLASPreserved
R/WR/WROROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
0x0000.000ROreserved31:2
0R/WASP1
0R/WTMPL0
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
Active Stack Pointer
DescriptionValue
PSP is the current stack pointer.1
MSP is the current stack pointer0
In Handler mode, this bit reads as zero and ignores writes. The
Cortex-M3 updates this bit automatically on exception return.
Thread Mode Privilege Level
DescriptionValue
Unprivileged software can be executed in Thread mode.1
Only privileged software can be executed in Thread mode.0
Texas Instruments-Production Data
September 04, 201064
2.3.5 Exceptions and Interrupts
The Cortex-M3 processor supports interrupts and system exceptions. The processor and the Nested
Vectored Interrupt Controller (NVIC) prioritize and handle all exceptions. An exception changes the
normal flow of software control. The processor uses Handler mode to handle all exceptions except
for reset. See “Exception Entry and Return” on page 79 for more information.
The NVIC registers control interrupt handling. See “Nested Vectored Interrupt Controller
(NVIC)” on page 89 for more information.
2.3.6 Data Types
The Cortex-M3 supports 32-bit words, 16-bit halfwords, and 8-bit bytes. The processor also supports
64-bit data transfer instructions. All instruction and data memory accesses are little endian. See
“Memory Regions, Types and Attributes” on page 67 for more information.
2.4 Memory Model
This section describes the processor memory map, the behavior of memory accesses, and the
bit-banding features. The processor has a fixed memory map that provides up to 4 GB of addressable
memory.
The memory map for the LM3S1165 controller is provided in Table 2-4 on page 65. In this manual,
register addresses are given as a hexadecimal increment, relative to the module’s base address
as shown in the memory map.
Stellaris® LM3S1165 Microcontroller
The regions for SRAM and peripherals include bit-band regions. Bit-banding provides atomic
operations to bit data (see “Bit-Banding” on page 69).
The processor reserves regions of the Private peripheral bus (PPB) address range for core peripheral
registers (see “Cortex-M3 Peripherals” on page 88).
Note: Within the memory map, all reserved space returns a bus fault when read or written.
Table 2-4. Memory Map
Memory
FiRM Peripherals
DescriptionEndStart
Reserved0x3FFF.FFFF0x2208.0000
For details,
see page ...
253On-chip Flash0x0000.FFFF0x0000.0000
-Reserved0x1FFF.FFFF0x0001.0000
252Bit-banded on-chip SRAM0x2000.3FFF0x2000.0000
-Reserved0x21FF.FFFF0x2000.4000
252Bit-band alias of 0x2000.0000 through 0x200F.FFFF0x2207.FFFF0x2200.0000
-
359Watchdog timer 00x4000.0FFF0x4000.0000
-Reserved0x4000.3FFF0x4000.1000
285GPIO Port A0x4000.4FFF0x4000.4000
285GPIO Port B0x4000.5FFF0x4000.5000
285GPIO Port C0x4000.6FFF0x4000.6000
285GPIO Port D0x4000.7FFF0x4000.7000
469SSI00x4000.8FFF0x4000.8000
Texas Instruments-Production Data
65September 04, 2010
The Cortex-M3 Processor
Table 2-4. Memory Map (continued)
Peripherals
Private Peripheral Bus
DescriptionEndStart
Reserved0x4001.FFFF0x4000.F000
Reserved0xDFFF.FFFF0x4400.0000
Reserved0xFFFF.FFFF0xE004.1000
For details,
see page ...
469SSI10x4000.9FFF0x4000.9000
-Reserved0x4000.BFFF0x4000.A000
424UART00x4000.CFFF0x4000.C000
424UART10x4000.DFFF0x4000.D000
424UART20x4000.EFFF0x4000.E000
-
509I2C Master 00x4002.07FF0x4002.0000
522I2C Slave 00x4002.0FFF0x4002.0800
-Reserved0x4002.3FFF0x4002.1000
285GPIO Port E0x4002.4FFF0x4002.4000
285GPIO Port F0x4002.5FFF0x4002.5000
285GPIO Port G0x4002.6FFF0x4002.6000
285GPIO Port H0x4002.7FFF0x4002.7000
550PWM0x4002.8FFF0x4002.8000
-Reserved0x4002.FFFF0x4002.9000
331Timer 00x4003.0FFF0x4003.0000
331Timer 10x4003.1FFF0x4003.1000
331Timer 20x4003.2FFF0x4003.2000
331Timer 30x4003.3FFF0x4003.3000
-Reserved0x4003.7FFF0x4003.4000
388ADC00x4003.8FFF0x4003.8000
-Reserved0x4003.BFFF0x4003.9000
531Analog Comparators0x4003.CFFF0x4003.C000
-Reserved0x400F.BFFF0x4003.D000
239Hibernation Module0x400F.CFFF0x400F.C000
257Flash memory control0x400F.DFFF0x400F.D000
179System control0x400F.EFFF0x400F.E000
-Reserved0x41FF.FFFF0x400F.F000
-Bit-banded alias of 0x4000.0000 through 0x400F.FFFF0x43FF.FFFF0x4200.0000
-
48Instrumentation Trace Macrocell (ITM)0xE000.0FFF0xE000.0000
48Data Watchpoint and Trace (DWT)0xE000.1FFF0xE000.1000
48Flash Patch and Breakpoint (FPB)0xE000.2FFF0xE000.2000
-Reserved0xE000.DFFF0xE000.3000
73Cortex-M3 Peripherals (SysTick, NVIC, SCB and MPU)0xE000.EFFF0xE000.E000
-Reserved0xE003.FFFF0xE000.F000
49Trace Port Interface Unit (TPIU)0xE004.0FFF0xE004.0000
-
Texas Instruments-Production Data
September 04, 201066
2.4.1 Memory Regions, Types and Attributes
The memory map and the programming of the MPU split the memory map into regions. Each region
has a defined memory type, and some regions have additional memory attributes. The memory
type and attributes determine the behavior of accesses to the region.
The memory types are:
■ Normal: The processor can re-order transactions for efficiency and perform speculative reads.
■ Device: The processor preserves transaction order relative to other transactions to Device or
Strongly Ordered memory.
■ Strongly Ordered: The processor preserves transaction order relative to all other transactions.
The different ordering requirements for Device and Strongly Ordered memory mean that the memory
system can buffer a write to Device memory but must not buffer a write to Strongly Ordered memory.
An additional memory attribute is Execute Never (XN), which means the processor prevents
instruction accesses. A fault exception is generated only on execution of an instruction executed
from an XN region.
Stellaris® LM3S1165 Microcontroller
2.4.2 Memory System Ordering of Memory Accesses
For most memory accesses caused by explicit memory access instructions, the memory system
does not guarantee that the order in which the accesses complete matches the program order of
the instructions, providing the order does not affect the behavior of the instruction sequence. Normally,
if correct program execution depends on two memory accesses completing in program order,
software must insert a memory barrier instruction between the memory access instructions (see
“Software Ordering of Memory Accesses” on page 68).
However, the memory system does guarantee ordering of accesses to Device and Strongly Ordered
memory. For two memory access instructions A1 and A2, if both A1 and A2 are accesses to either
Device or Strongly Ordered memory, and if A1 occurs before A2 in program order, A1 is always
observed before A2.
2.4.3 Behavior of Memory Accesses
Table 2-5 on page 67 shows the behavior of accesses to each region in the memory map. See
“Memory Regions, Types and Attributes” on page 67 for more information on memory types and
the XN attribute. Stellaris®devices may have reserved memory areas within the address ranges
shown below (refer to Table 2-4 on page 65 for more information).
Table 2-5. Memory Access Behavior
Memory TypeMemory RegionAddress Range
Never
(XN)
-NormalCode0x0000.0000 - 0x1FFF.FFFF
-NormalSRAM0x2000.0000 - 0x3FFF.FFFF
XNDevicePeripheral0x4000.0000 - 0x5FFF.FFFF
DescriptionExecute
This executable region is for program code.
Data can also be stored here.
This executable region is for data. Code
can also be stored here. This region
includes bit band and bit band alias areas
(see Table 2-6 on page 69).
This region includes bit band and bit band
alias areas (see Table 2-7 on page 70).
Texas Instruments-Production Data
67September 04, 2010
The Cortex-M3 Processor
Table 2-5. Memory Access Behavior (continued)
Memory TypeMemory RegionAddress Range
0xE000.0000- 0xE00F.FFFF
Private peripheral
bus
Ordered
The Code, SRAM, and external RAM regions can hold programs. However, it is recommended that
programs always use the Code region because the Cortex-M3 has separate buses that can perform
instruction fetches and data accesses simultaneously.
The MPU can override the default memory access behavior described in this section. For more
information, see “Memory Protection Unit (MPU)” on page 91.
The Cortex-M3 prefetches instructions ahead of execution and speculatively prefetches from branch
target addresses.
2.4.4 Software Ordering of Memory Accesses
The order of instructions in the program flow does not always guarantee the order of the
corresponding memory transactions for the following reasons:
■ The processor can reorder some memory accesses to improve efficiency, providing this does
not affect the behavior of the instruction sequence.
Never
(XN)
XNStrongly
DescriptionExecute
This executable region is for data.-NormalExternal RAM0x6000.0000 - 0x9FFF.FFFF
This region is for external device memory.XNDeviceExternal device0xA000.0000 - 0xDFFF.FFFF
This region includes the NVIC, system
timer, and system control block.
---Reserved0xE010.0000- 0xFFFF.FFFF
■ The processor has multiple bus interfaces.
■ Memory or devices in the memory map have different wait states.
■ Some memory accesses are buffered or speculative.
“Memory System Ordering of Memory Accesses” on page 67 describes the cases where the memory
system guarantees the order of memory accesses. Otherwise, if the order of memory accesses is
critical, software must include memory barrier instructions to force that ordering. The Cortex-M3
has the following memory barrier instructions:
■ The Data Memory Barrier (DMB) instruction ensures that outstanding memory transactions
complete before subsequent memory transactions.
■ The Data Synchronization Barrier (DSB) instruction ensures that outstanding memory transactions
complete before subsequent instructions execute.
■ The Instruction Synchronization Barrier (ISB) instruction ensures that the effect of all completed
memory transactions is recognizable by subsequent instructions.
Memory barrier instructions can be used in the following situations:
■ MPU programming
– If the MPU settings are changed and the change must be effective on the very next instruction,
use a DSB instruction to ensure the effect of the MPU takes place immediately at the end of
context switching.
Texas Instruments-Production Data
September 04, 201068
Stellaris® LM3S1165 Microcontroller
– Use an ISB instruction to ensure the new MPU setting takes effect immediately after
programming the MPU region or regions, if the MPU configuration code was accessed using
a branch or call. If the MPU configuration code is entered using exception mechanisms, then
an ISB instruction is not required.
■ Vector table
If the program changes an entry in the vector table and then enables the corresponding exception,
use a DMB instruction between the operations. The DMB instruction ensures that if the exception
is taken immediately after being enabled, the processor uses the new exception vector.
■ Self-modifying code
If a program contains self-modifying code, use an ISB instruction immediately after the code
modification in the program. The ISB instruction ensures subsequent instruction execution uses
the updated program.
■ Memory map switching
If the system contains a memory map switching mechanism, use a DSB instruction after switching
the memory map in the program. The DSB instruction ensures subsequent instruction execution
uses the updated memory map.
■ Dynamic exception priority change
When an exception priority has to change when the exception is pending or active, use DSB
instructions after the change. The change then takes effect on completion of the DSB instruction.
Memory accesses to Strongly Ordered memory, such as the System Control Block, do not require
the use of DMB instructions.
For more information on the memory barrier instructions, see the Cortex™-M3 Instruction Set
Technical User's Manual.
2.4.5 Bit-Banding
A bit-band region maps each word in a bit-band alias region to a single bit in the bit-band region.
The bit-band regions occupy the lowest 1 MB of the SRAM and peripheral memory regions. Accesses
to the 32-MB SRAM alias region map to the 1-MB SRAM bit-band region, as shown in Table
2-6 on page 69. Accesses to the 32-MB peripheral alias region map to the 1-MB peripheral bit-band
region, as shown in Table 2-7 on page 70. For the specific address range of the bit-band regions,
see Table 2-4 on page 65.
Note: A word access to the SRAM or the peripheral bit-band alias region maps to a single bit in
the SRAM or peripheral bit-band region.
A word access to a bit band address results in a word access to the underlying memory,
and similarly for halfword and byte accesses. This allows bit band accesses to match the
access requirements of the underlying peripheral.
Table 2-6. SRAM Memory Bit-Banding Regions
Instruction and Data AccessesMemory RegionAddress Range
SRAM bit-band region0x2000.0000 - 0x200F.FFFF
Texas Instruments-Production Data
Direct accesses to this memory range behave as SRAM memory
accesses, but this region is also bit addressable through bit-band
alias.
69September 04, 2010
The Cortex-M3 Processor
Table 2-6. SRAM Memory Bit-Banding Regions (continued)
Table 2-7. Peripheral Memory Bit-Banding Regions
The following formula shows how the alias region maps onto the bit-band region:
bit_word_offset = (byte_offset x 32) + (bit_number x 4)
bit_word_addr = bit_band_base + bit_word_offset
Instruction and Data AccessesMemory RegionAddress Range
SRAM bit-band alias0x2200.0000 - 0x23FF.FFFF
Peripheral bit-band region0x4000.0000 - 0x400F.FFFF
Peripheral bit-band alias0x4200.0000 - 0x43FF.FFFF
Data accesses to this region are remapped to bit band region.
A write operation is performed as read-modify-write. Instruction
accesses are not remapped.
Instruction and Data AccessesMemory RegionAddress Range
Direct accesses to this memory range behave as peripheral
memory accesses, but this region is also bit addressable through
bit-band alias.
Data accesses to this region are remapped to bit band region.
A write operation is performed as read-modify-write. Instruction
accesses are not permitted.
where:
bit_word_offset
The position of the target bit in the bit-band memory region.
bit_word_addr
The address of the word in the alias memory region that maps to the targeted bit.
bit_band_base
The starting address of the alias region.
byte_offset
The number of the byte in the bit-band region that contains the targeted bit.
bit_number
The bit position, 0-7, of the targeted bit.
Figure 2-4 on page 71 shows examples of bit-band mapping between the SRAM bit-band alias
region and the SRAM bit-band region:
■ The alias word at 0x23FF.FFE0 maps to bit 0 of the bit-band byte at 0x200F.FFFF:
0x23FF.FFE0 = 0x2200.0000 + (0x000F.FFFF*32) + (0*4)
■ The alias word at 0x23FF.FFFC maps to bit 7 of the bit-band byte at 0x200F.FFFF:
0x23FF.FFFC = 0x2200.0000 + (0x000F.FFFF*32) + (7*4)
■ The alias word at 0x2200.0000 maps to bit 0 of the bit-band byte at 0x2000.0000:
0x2200.0000 = 0x2200.0000 + (0*32) + (0*4)
September 04, 201070
Texas Instruments-Production Data
0x23FF.FFE4
0x2200.0004
0x23FF.FFE00x23FF.FFE80x23FF.FFEC0x23FF.FFF00x23FF.FFF40x23FF.FFF80x23FF.FFFC
0x2200.00000x2200.00140x2200.00180x2200.001C 0x2200.00080x2200.0010 0x2200.000C
32-MB Alias Region
0
7 0
07
0x2000.00000x2000.00010x2000.00020x2000.0003
6 5 4 3 2 1 07 6 5 4 3 2 1 7 6 5 4 3 2 1 07 6 5 4 3 2 1
07 6 5 4 3 2 1 6 5 4 3 2 107 6 5 4 3 2 1 07 6 5 4 3 2 1
0x200F.FFFC0x200F.FFFD0x200F.FFFE0x200F.FFFF
1-MB SRAM Bit-Band Region
Stellaris® LM3S1165 Microcontroller
■ The alias word at 0x2200.001C maps to bit 7 of the bit-band byte at 0x2000.0000:
0x2200.001C = 0x2200.0000+ (0*32) + (7*4)
Figure 2-4. Bit-Band Mapping
2.4.5.1 Directly Accessing an Alias Region
Writing to a word in the alias region updates a single bit in the bit-band region.
Bit 0 of the value written to a word in the alias region determines the value written to the targeted
bit in the bit-band region. Writing a value with bit 0 set writes a 1 to the bit-band bit, and writing a
value with bit 0 clear writes a 0 to the bit-band bit.
Bits 31:1 of the alias word have no effect on the bit-band bit. Writing 0x01 has the same effect as
writing 0xFF. Writing 0x00 has the same effect as writing 0x0E.
When reading a word in the alias region, 0x0000.0000 indicates that the targeted bit in the bit-band
region is clear and 0x0000.0001 indicates that the targeted bit in the bit-band region is set.
2.4.5.2 Directly Accessing a Bit-Band Region
“Behavior of Memory Accesses” on page 67 describes the behavior of direct byte, halfword, or word
accesses to the bit-band regions.
2.4.6 Data Storage
The processor views memory as a linear collection of bytes numbered in ascending order from zero.
For example, bytes 0-3 hold the first stored word, and bytes 4-7 hold the second stored word. Data
is stored in little-endian format, with the least-significant byte (lsbyte) of a word stored at the
lowest-numbered byte, and the most-significant byte (msbyte) stored at the highest-numbered byte.
Figure 2-5 on page 72 illustrates how data is stored.
Texas Instruments-Production Data
71September 04, 2010
Memory Register
Address A
A+1
lsbyte
msbyte
A+2
A+3
07
B0B1B3 B2
31 24 23 16 15 8 7 0
B0
B1
B2
B3
The Cortex-M3 Processor
Figure 2-5. Data Storage
2.4.7 Synchronization Primitives
The Cortex-M3 instruction set includes pairs of synchronization primitives which provide a
non-blocking mechanism that a thread or process can use to obtain exclusive access to a memory
location. Software can use these primitives to perform a guaranteed read-modify-write memory
update sequence or for a semaphore mechanism.
A pair of synchronization primitives consists of:
■ A Load-Exclusive instruction, which is used to read the value of a memory location and requests
exclusive access to that location.
■ A Store-Exclusive instruction, which is used to attempt to write to the same memory location and
returns a status bit to a register. If this status bit is clear, it indicates that the thread or process
gained exclusive access to the memory and the write succeeds; if this status bit is set, it indicates
that the thread or process did not gain exclusive access to the memory and no write is performed.
The pairs of Load-Exclusive and Store-Exclusive instructions are:
■ The word instructions LDREX and STREX
■ The halfword instructions LDREXH and STREXH
■ The byte instructions LDREXB and STREXB
Software must use a Load-Exclusive instruction with the corresponding Store-Exclusive instruction.
To perform a guaranteed read-modify-write of a memory location, software must:
1. Use a Load-Exclusive instruction to read the value of the location.
2. Update the value, as required.
3. Use a Store-Exclusive instruction to attempt to write the new value back to the memory location,
and test the returned status bit. If the status bit is clear, the read-modify-write completed
successfully; if the status bit is set, no write was performed, which indicates that the value
returned at step 1 might be out of date. The software must retry the read-modify-write sequence.
Software can use the synchronization primitives to implement a semaphore as follows:
1. Use a Load-Exclusive instruction to read from the semaphore address to check whether the
semaphore is free.
September 04, 201072
Texas Instruments-Production Data
2. If the semaphore is free, use a Store-Exclusive to write the claim value to the semaphore
address.
3. If the returned status bit from step 2 indicates that the Store-Exclusive succeeded, then the
software has claimed the semaphore. However, if the Store-Exclusive failed, another process
might have claimed the semaphore after the software performed step 1.
The Cortex-M3 includes an exclusive access monitor that tags the fact that the processor has
executed a Load-Exclusive instruction. The processor removes its exclusive access tag if:
■ It executes a CLREX instruction.
■ It executes a Store-Exclusive instruction, regardless of whether the write succeeds.
■ An exception occurs, which means the processor can resolve semaphore conflicts between
different threads.
For more information about the synchronization primitive instructions, see the Cortex™-M3 Instruction
Set Technical User's Manual.
2.5 Exception Model
Stellaris® LM3S1165 Microcontroller
The ARM Cortex-M3 processor and the Nested Vectored Interrupt Controller (NVIC) prioritize and
handle all exceptions in Handler Mode. The processor state is automatically stored to the stack on
an exception and automatically restored from the stack at the end of the Interrupt Service Routine
(ISR). The vector is fetched in parallel to the state saving, enabling efficient interrupt entry. The
processor supports tail-chaining, which enables back-to-back interrupts to be performed without the
overhead of state saving and restoration.
Table 2-8 on page 75 lists all exception types. Software can set eight priority levels on seven of
these exceptions (system handlers) as well as on 35 interrupts (listed in Table 2-9 on page 76).
Priorities on the system handlers are set with the NVIC System Handler Priority n (SYSPRIn)
registers. Interrupts are enabled through the NVIC Interrupt Set Enable n (ENn) register and
prioritized with the NVIC Interrupt Priority n (PRIn) registers. Priorities can be grouped by splitting
priority levels into preemption priorities and subpriorities. All the interrupt registers are described in
“Nested Vectored Interrupt Controller (NVIC)” on page 89.
Internally, the highest user-programmable priority (0) is treated as fourth priority, after a Reset,
Non-Maskable Interrupt (NMI), and a Hard Fault, in that order. Note that 0 is the default priority for
all the programmable priorities.
Important: After a write to clear an interrupt source, it may take several processor cycles for the
NVIC to see the interrupt source de-assert. Thus if the interrupt clear is done as the
last action in an interrupt handler, it is possible for the interrupt handler to complete
while the NVIC sees the interrupt as still asserted, causing the interrupt handler to be
re-entered errantly. This situation can be avoided by either clearing the interrupt source
at the beginning of the interrupt handler or by performing a read or write after the write
to clear the interrupt source (and flush the write buffer).
See “Nested Vectored Interrupt Controller (NVIC)” on page 89 for more information on exceptions
and interrupts.
2.5.1 Exception States
Each exception is in one of the following states:
73September 04, 2010
Texas Instruments-Production Data
The Cortex-M3 Processor
■ Inactive. The exception is not active and not pending.
■ Pending. The exception is waiting to be serviced by the processor. An interrupt request from a
peripheral or from software can change the state of the corresponding interrupt to pending.
■ Active. An exception that is being serviced by the processor but has not completed.
Note: An exception handler can interrupt the execution of another exception handler. In this
case, both exceptions are in the active state.
■ Active and Pending. The exception is being serviced by the processor, and there is a pending
exception from the same source.
2.5.2 Exception Types
The exception types are:
■ Reset. Reset is invoked on power up or a warm reset. The exception model treats reset as a
special form of exception. When reset is asserted, the operation of the processor stops, potentially
at any point in an instruction. When reset is deasserted, execution restarts from the address
provided by the reset entry in the vector table. Execution restarts as privileged execution in
Thread mode.
■ NMI. A non-maskable Interrupt (NMI) can be signaled using the NMI signal or triggered by
software using the Interrupt Control and State (INTCTRL) register. This exception has the
highest priority other than reset. NMI is permanently enabled and has a fixed priority of -2. NMIs
cannot be masked or prevented from activation by any other exception or preempted by any
exception other than reset.
■ Hard Fault. A hard fault is an exception that occurs because of an error during exception
processing, or because an exception cannot be managed by any other exception mechanism.
Hard faults have a fixed priority of -1, meaning they have higher priority than any exception with
configurable priority.
■ Memory Management Fault. A memory management fault is an exception that occurs because
of a memory protection related fault, including access violation and no match. The MPU or the
fixed memory protection constraints determine this fault, for both instruction and data memory
transactions. This fault is used to abort instruction accesses to Execute Never (XN) memory
regions, even if the MPU is disabled.
■ Bus Fault. A bus fault is an exception that occurs because of a memory-related fault for an
instruction or data memory transaction such as a prefetch fault or a memory access fault. This
fault can be enabled or disabled.
■ Usage Fault. A usage fault is an exception that occurs because of a fault related to instruction
execution, such as:
– An undefined instruction
– An illegal unaligned access
– Invalid state on instruction execution
– An error on exception return
Texas Instruments-Production Data
September 04, 201074
Stellaris® LM3S1165 Microcontroller
An unaligned address on a word or halfword memory access or division by zero can cause a
usage fault when the core is properly configured.
■ SVCall. A supervisor call (SVC) is an exception that is triggered by the SVC instruction. In an
OS environment, applications can use SVC instructions to access OS kernel functions and device
drivers.
■ Debug Monitor. This exception is caused by the debug monitor (when not halting). This exception
is only active when enabled. This exception does not activate if it is a lower priority than the
current activation.
■ PendSV. PendSV is a pendable, interrupt-driven request for system-level service. In an OS
environment, use PendSV for context switching when no other exception is active. PendSV is
triggered using the Interrupt Control and State (INTCTRL) register.
■ SysTick. A SysTick exception is an exception that the system timer generates when it reaches
zero when it is enabled to generate an interrupt. Software can also generate a SysTick exception
using the Interrupt Control and State (INTCTRL) register. In an OS environment, the processor
can use this exception as system tick.
■ Interrupt (IRQ). An interrupt, or IRQ, is an exception signaled by a peripheral or generated by
a software request and fed through the NVIC (prioritized). All interrupts are asynchronous to
instruction execution. In the system, peripherals use interrupts to communicate with the processor.
Table 2-9 on page 76 lists the interrupts on the LM3S1165 controller.
For an asynchronous exception, other than reset, the processor can execute another instruction
between when the exception is triggered and when the processor enters the exception handler.
Privileged software can disable the exceptions that Table 2-8 on page 75 shows as having
configurable priority (see the SYSHNDCTRL register on page 131 and the DIS0 register on page 105).
For more information about hard faults, memory management faults, bus faults, and usage faults,
see “Fault Handling” on page 81.
Table 2-8. Exception Types
Exception Type
(NMI)
Vector
Number
4Memory Management
5Bus Fault
6Usage Fault
11SVCall
12Debug Monitor
14PendSV
Priority
a
b
Offset
0x0000.0000-0-
c
c
c
c
c
c
0x0000.0014programmable
ActivationVector Address or
Stack top is loaded from the first
entry of the vector table on reset.
Asynchronous0x0000.0004-3 (highest)1Reset
Asynchronous0x0000.0008-22Non-Maskable Interrupt
-0x0000.000C-13Hard Fault
Synchronous0x0000.0010programmable
Synchronous when precise and
asynchronous when imprecise
Synchronous0x0000.0018programmable
Reserved--7-10-
Synchronous0x0000.002Cprogrammable
Synchronous0x0000.0030programmable
Reserved--13-
Asynchronous0x0000.0038programmable
Texas Instruments-Production Data
75September 04, 2010
The Cortex-M3 Processor
Table 2-8. Exception Types (continued)
Exception Type
a. 0 is the default priority for all the programmable priorities.
b. See “Vector Table” on page 77.
c. See page 128.
d. See page 128.
e. See page 113.
Table 2-9. Interrupts
Vector
Number
16 and aboveInterrupts
a
Priority
15SysTick
d
e
Offset
b
ActivationVector Address or
Asynchronous0x0000.003Cprogrammable
Asynchronous0x0000.0040 and aboveprogrammable
Vector Number
Interrupt Number (Bit
in Interrupt Registers)
-0-15
DescriptionVector Address or
Offset
Processor exceptions0x0000.0000 -
0x0000.003C
GPIO Port A0x0000.0040016
GPIO Port B0x0000.0044117
GPIO Port C0x0000.0048218
GPIO Port D0x0000.004C319
GPIO Port E0x0000.0050420
UART00x0000.0054521
UART10x0000.0058622
SSI00x0000.005C723
I2C00x0000.0060824
Reserved925
PWM Generator 00x0000.00681026
PWM Generator 10x0000.006C1127
PWM Generator 20x0000.00701228
Reserved1329
ADC0 Sequence 00x0000.00781430
ADC0 Sequence 10x0000.007C1531
ADC0 Sequence 20x0000.00801632
ADC0 Sequence 30x0000.00841733
Watchdog Timer 00x0000.00881834
Timer 0A0x0000.008C1935
Timer 0B0x0000.00902036
Timer 1A0x0000.00942137
Timer 1B0x0000.00982238
Timer 2A0x0000.009C2339
Timer 2B0x0000.00A02440
Analog Comparator 00x0000.00A42541
Reserved26-2742-43
System Control0x0000.00B02844
Flash Memory Control0x0000.00B42945
Texas Instruments-Production Data
September 04, 201076
Table 2-9. Interrupts (continued)
Stellaris® LM3S1165 Microcontroller
Vector Number
Interrupt Number (Bit
in Interrupt Registers)
2.5.3 Exception Handlers
The processor handles exceptions using:
■ Interrupt Service Routines (ISRs). Interrupts (IRQx) are the exceptions handled by ISRs.
■ Fault Handlers. Hard fault, memory management fault, usage fault, and bus fault are fault
exceptions handled by the fault handlers.
■ System Handlers. NMI, PendSV, SVCall, SysTick, and the fault exceptions are all system
exceptions that are handled by system handlers.
DescriptionVector Address or
Offset
GPIO Port F0x0000.00B83046
GPIO Port G0x0000.00BC3147
GPIO Port H0x0000.00C03248
UART20x0000.00C43349
SSI10x0000.00C83450
Timer 3A0x0000.00CC3551
Timer 3B0x0000.00D03652
Reserved37-4253-58
Hibernation Module0x0000.00EC4359
Reserved44-5460-70
2.5.4 Vector Table
The vector table contains the reset value of the stack pointer and the start addresses, also called
exception vectors, for all exception handlers. The vector table is constructed using the vector address
or offset shown in Table 2-8 on page 75. Figure 2-6 on page 78 shows the order of the exception
vectors in the vector table. The least-significant bit of each vector must be 1, indicating that the
exception handler is Thumb code
Texas Instruments-Production Data
77September 04, 2010
Initial SP value
Reset
Hard fault
NMI
Memory management fault
Usage fault
Bus fault
0x0000
0x0004
0x0008
0x000C
0x0010
0x0014
0x0018
Reserved
SVCall
PendSV
Reserved for Debug
Systick
IRQ0
Reserved
0x002C
0x0038
0x003C
0x0040
OffsetException number
2
3
4
5
6
11
12
14
15
16
18
13
7
10
1
Vector
.
.
.
8
9
IRQ1
IRQ2
0x0044
IRQ43
17
0x0048
0x004C
59
.
.
.
.
.
.
0x00EC
IRQ number
-14
-13
-12
-11
-10
-5
-2
-1
0
2
1
43
The Cortex-M3 Processor
Figure 2-6. Vector table
2.5.5 Exception Priorities
On system reset, the vector table is fixed at address 0x0000.0000. Privileged software can write to
the Vector Table Offset (VTABLE) register to relocate the vector table start address to a different
memory location, in the range 0x0000.0100 to 0x3FFF.FF00 (see “Vector Table” on page 77). Note
that when configuring the VTABLE register, the offset must be aligned on a 256-byte boundary.
As Table 2-8 on page 75 shows, all exceptions have an associated priority, with a lower priority
value indicating a higher priority and configurable priorities for all exceptions except Reset, Hard
fault, and NMI. If software does not configure any priorities, then all exceptions with a configurable
priority have a priority of 0. For information about configuring exception priorities, see page 128 and
page 113.
Note: Configurable priority values for the Stellaris®implementation are in the range 0-7. This
For example, assigning a higher priority value to IRQ[0] and a lower priority value to IRQ[1] means
that IRQ[1] has higher priority than IRQ[0]. If both IRQ[1] and IRQ[0] are asserted, IRQ[1] is processed
before IRQ[0].
means that the Reset, Hard fault, and NMI exceptions, with fixed negative priority values,
always have higher priority than any other exception.
Texas Instruments-Production Data
September 04, 201078
If multiple pending exceptions have the same priority, the pending exception with the lowest exception
number takes precedence. For example, if both IRQ[0] and IRQ[1] are pending and have the same
priority, then IRQ[0] is processed before IRQ[1].
When the processor is executing an exception handler, the exception handler is preempted if a
higher priority exception occurs. If an exception occurs with the same priority as the exception being
handled, the handler is not preempted, irrespective of the exception number. However, the status
of the new interrupt changes to pending.
2.5.6 Interrupt Priority Grouping
To increase priority control in systems with interrupts, the NVIC supports priority grouping. This
grouping divides each interrupt priority register entry into two fields:
■ An upper field that defines the group priority
■ A lower field that defines a subpriority within the group
Only the group priority determines preemption of interrupt exceptions. When the processor is
executing an interrupt exception handler, another interrupt with the same group priority as the
interrupt being handled does not preempt the handler.
Stellaris® LM3S1165 Microcontroller
If multiple pending interrupts have the same group priority, the subpriority field determines the order
in which they are processed. If multiple pending interrupts have the same group priority and
subpriority, the interrupt with the lowest IRQ number is processed first.
For information about splitting the interrupt priority fields into group priority and subpriority, see
page 122.
2.5.7 Exception Entry and Return
Descriptions of exception handling use the following terms:
■ Preemption. When the processor is executing an exception handler, an exception can preempt
the exception handler if its priority is higher than the priority of the exception being handled. See
“Interrupt Priority Grouping” on page 79 for more information about preemption by an interrupt.
When one exception preempts another, the exceptions are called nested exceptions. See
“Exception Entry” on page 80 more information.
■ Return. Return occurs when the exception handler is completed, and there is no pending
exception with sufficient priority to be serviced and the completed exception handler was not
handling a late-arriving exception. The processor pops the stack and restores the processor
state to the state it had before the interrupt occurred. See “Exception Return” on page 81 for
more information.
■ Tail-Chaining. This mechanism speeds up exception servicing. On completion of an exception
handler, if there is a pending exception that meets the requirements for exception entry, the
stack pop is skipped and control transfers to the new exception handler.
■ Late-Arriving. This mechanism speeds up preemption. If a higher priority exception occurs
during state saving for a previous exception, the processor switches to handle the higher priority
exception and initiates the vector fetch for that exception. State saving is not affected by late
arrival because the state saved is the same for both exceptions. Therefore, the state saving
continues uninterrupted. The processor can accept a late arriving exception until the first instruction
of the exception handler of the original exception enters the execute stage of the processor. On
Texas Instruments-Production Data
79September 04, 2010
Pre-IRQ top of stack
xPSR
PC
LR
R12
R3
R2
R1
R0
{aligner}
IRQ top of stack
...
The Cortex-M3 Processor
return from the exception handler of the late-arriving exception, the normal tail-chaining rules
apply.
2.5.7.1 Exception Entry
Exception entry occurs when there is a pending exception with sufficient priority and either the
processor is in Thread mode or the new exception is of higher priority than the exception being
handled, in which case the new exception preempts the original exception.
When one exception preempts another, the exceptions are nested.
Sufficient priority means the exception has more priority than any limits set by the mask registers
(see PRIMASK on page 61, FAULTMASK on page 62, and BASEPRI on page 63). An exception
with less priority than this is pending but is not handled by the processor.
When the processor takes an exception, unless the exception is a tail-chained or a late-arriving
exception, the processor pushes information onto the current stack. This operation is referred to as
stacking and the structure of eight data words is referred to as stack frame.
Figure 2-7. Exception Stack Frame
Immediately after stacking, the stack pointer indicates the lowest address in the stack frame. Unless
stack alignment is disabled, the stack frame is aligned to a double-word address. If the STKALIGN
bit of the Configuration Control (CCR) register is set, stack align adjustment is performed during
stacking.
The stack frame includes the return address, which is the address of the next instruction in the
interrupted program. This value is restored to the PC at exception return so that the interrupted
program resumes.
In parallel to the stacking operation, the processor performs a vector fetch that reads the exception
handler start address from the vector table. When stacking is complete, the processor starts executing
the exception handler. At the same time, the processor writes an EXC_RETURN value to the LR,
indicating which stack pointer corresponds to the stack frame and what operation mode the processor
was in before the entry occurred.
If no higher-priority exception occurs during exception entry, the processor starts executing the
exception handler and automatically changes the status of the corresponding pending interrupt to
active.
If another higher-priority exception occurs during exception entry, known as late arrival, the processor
starts executing the exception handler for this exception and does not change the pending status
of the earlier exception.
September 04, 201080
Texas Instruments-Production Data
2.5.7.2 Exception Return
Exception return occurs when the processor is in Handler mode and executes one of the following
instructions to load the EXC_RETURN value into the PC:
■ An LDM or POP instruction that loads the PC
■ A BX instruction using any register
■ An LDR instruction with the PC as the destination
EXC_RETURN is the value loaded into the LR on exception entry. The exception mechanism relies
on this value to detect when the processor has completed an exception handler. The lowest four
bits of this value provide information on the return stack and processor mode. Table 2-10 on page 81
shows the EXC_RETURN values with a description of the exception return behavior.
EXC_RETURN bits 31:4 are all set. When this value is loaded into the PC, it indicates to the processor
that the exception is complete, and the processor initiates the appropriate exception return sequence.
Table 2-10. Exception Return Behavior
0xFFFF.FFF1
0xFFFF.FFF9
0xFFFF.FFFD
Stellaris® LM3S1165 Microcontroller
DescriptionEXC_RETURN[31:0]
Reserved0xFFFF.FFF0
Return to Handler mode.
Exception return uses state from MSP.
Execution uses MSP after return.
Reserved0xFFFF.FFF2 - 0xFFFF.FFF8
Return to Thread mode.
Exception return uses state from MSP.
Execution uses MSP after return.
Reserved0xFFFF.FFFA - 0xFFFF.FFFC
Return to Thread mode.
Exception return uses state from PSP.
Execution uses PSP after return.
Reserved0xFFFF.FFFE - 0xFFFF.FFFF
2.6 Fault Handling
Faults are a subset of the exceptions (see “Exception Model” on page 73). The following conditions
generate a fault:
■ A bus error on an instruction fetch or vector table load or a data access.
■ An internally detected error such as an undefined instruction or an attempt to change state with
a BX instruction.
■ Attempting to execute an instruction from a memory region marked as Non-Executable (XN).
■ An MPU fault because of a privilege violation or an attempt to access an unmanaged region.
81September 04, 2010
Texas Instruments-Production Data
The Cortex-M3 Processor
2.6.1 Fault Types
Table 2-11 on page 82 shows the types of fault, the handler used for the fault, the corresponding
fault status register, and the register bit that indicates the fault has occurred. See page 135 for more
information about the fault status registers.
Table 2-11. Faults
MPU or default memory mismatch on
instruction access
MPU or default memory mismatch on
data access
MPU or default memory mismatch on
exception stacking
MPU or default memory mismatch on
exception unstacking
set state
a. Occurs on an access to an XN region even if the MPU is disabled.
b. Attempting to use an instruction set other than the Thumb instruction set, or returning to a non load-store-multiple instruction
b
with ICI continuation.
Memory management
fault
Memory management
fault
Memory management
fault
Memory management
fault
Memory Management Fault Status
(MFAULTSTAT)
(MFAULTSTAT)
(MFAULTSTAT)
(MFAULTSTAT)
Bit NameFault Status RegisterHandlerFault
VECTHard Fault Status (HFAULTSTAT)Hard faultBus error on a vector read
FORCEDHard Fault Status (HFAULTSTAT)Hard faultFault escalated to a hard fault
IERR
DERRMemory Management Fault Status
MSTKEMemory Management Fault Status
MUSTKEMemory Management Fault Status
BSTKEBus Fault Status (BFAULTSTAT)Bus faultBus error during exception stacking
BUSTKEBus Fault Status (BFAULTSTAT)Bus faultBus error during exception unstacking
IBUSBus Fault Status (BFAULTSTAT)Bus faultBus error during instruction prefetch
PRECISEBus Fault Status (BFAULTSTAT)Bus faultPrecise data bus error
IMPREBus Fault Status (BFAULTSTAT)Bus faultImprecise data bus error
NOCPUsage Fault Status (UFAULTSTAT)Usage faultAttempt to access a coprocessor
UNDEFUsage Fault Status (UFAULTSTAT)Usage faultUndefined instruction
INVSTATUsage Fault Status (UFAULTSTAT)Usage faultAttempt to enter an invalid instruction
INVPCUsage Fault Status (UFAULTSTAT)Usage faultInvalid EXC_RETURN value
UNALIGNUsage Fault Status (UFAULTSTAT)Usage faultIllegal unaligned load or store
DIV0Usage Fault Status (UFAULTSTAT)Usage faultDivide by 0
a
2.6.2 Fault Escalation and Hard Faults
All fault exceptions except for hard fault have configurable exception priority (see SYSPRI1 on
page 128). Software can disable execution of the handlers for these faults (see SYSHNDCTRL on
page 131).
Usually, the exception priority, together with the values of the exception mask registers, determines
whether the processor enters the fault handler, and whether a fault handler can preempt another
fault handler as described in “Exception Model” on page 73.
In some situations, a fault with configurable priority is treated as a hard fault. This process is called
priority escalation, and the fault is described as escalated to hard fault. Escalation to hard fault
occurs when:
■ A fault handler causes the same kind of fault as the one it is servicing. This escalation to hard
fault occurs because a fault handler cannot preempt itself because it must have the same priority
as the current priority level.
Texas Instruments-Production Data
September 04, 201082
Stellaris® LM3S1165 Microcontroller
■ A fault handler causes a fault with the same or lower priority as the fault it is servicing. This
situation happens because the handler for the new fault cannot preempt the currently executing
fault handler.
■ An exception handler causes a fault for which the priority is the same as or lower than the currently
executing exception.
■ A fault occurs and the handler for that fault is not enabled.
If a bus fault occurs during a stack push when entering a bus fault handler, the bus fault does not
escalate to a hard fault. Thus if a corrupted stack causes a fault, the fault handler executes even
though the stack push for the handler failed. The fault handler operates but the stack contents are
corrupted.
Note: Only Reset and NMI can preempt the fixed priority hard fault. A hard fault can preempt any
exception other than Reset, NMI, or another hard fault.
2.6.3 Fault Status Registers and Fault Address Registers
The fault status registers indicate the cause of a fault. For bus faults and memory management
faults, the fault address register indicates the address accessed by the operation that caused the
fault, as shown in Table 2-12 on page 83.
Table 2-12. Fault Status and Fault Address Registers
Memory management
fault
Memory Management Fault Status
(MFAULTSTAT)
Bus Fault Status (BFAULTSTAT)Bus fault
2.6.4 Lockup
The processor enters a lockup state if a hard fault occurs when executing the NMI or hard fault
handlers. When the processor is in the lockup state, it does not execute any instructions. The
processor remains in lockup state until it is reset or an NMI occurs.
Note: If the lockup state occurs from the NMI handler, a subsequent NMI does not cause the
processor to leave the lockup state.
2.7 Power Management
The Cortex-M3 processor sleep modes reduce power consumption:
■ Sleep mode stops the processor clock.
Memory Management Fault
Address (MMADDR)
Bus Fault Address
(FAULTADDR)
Register DescriptionAddress Register NameStatus Register NameHandler
page 141-Hard Fault Status (HFAULTSTAT)Hard fault
page 135
page 143
page 135
page 144
page 135-Usage Fault Status (UFAULTSTAT)Usage fault
■ Deep-sleep mode stops the system clock and switches off the PLL and Flash memory.
The SLEEPDEEP bit of the System Control (SYSCTRL) register selects which sleep mode is used
(see page 124). For more information about the behavior of the sleep modes, see “System
Control” on page 176.
83September 04, 2010
Texas Instruments-Production Data
The Cortex-M3 Processor
This section describes the mechanisms for entering sleep mode and the conditions for waking up
from sleep mode, both of which apply to Sleep mode and Deep-sleep mode.
2.7.1 Entering Sleep Modes
This section describes the mechanisms software can use to put the processor into one of the sleep
modes.
The system can generate spurious wake-up events, for example a debug operation wakes up the
processor. Therefore, software must be able to put the processor back into sleep mode after such
an event. A program might have an idle loop to put the processor back to sleep mode.
2.7.1.1 Wait for Interrupt
The wait for interrupt instruction, WFI, causes immediate entry to sleep mode unless the wake-up
condition is true (see “Wake Up from WFI or Sleep-on-Exit” on page 84). When the processor
executes a WFI instruction, it stops executing instructions and enters sleep mode. See the
Cortex™-M3 Instruction Set Technical User's Manual for more information.
2.7.1.2 Wait for Event
The wait for event instruction, WFE, causes entry to sleep mode conditional on the value of a one-bit
event register. When the processor executes a WFE instruction, it checks the event register. If the
register is 0, the processor stops executing instructions and enters sleep mode. If the register is 1,
the processor clears the register and continues executing instructions without entering sleep mode.
If the event register is 1, the processor must not enter sleep mode on execution of a WFE instruction.
Typically, this situation occurs if an SEV instruction has been executed. Software cannot access
this register directly.
See the Cortex™-M3 Instruction Set Technical User's Manual for more information.
2.7.1.3 Sleep-on-Exit
If the SLEEPEXIT bit of SYSCTRL is set, when the processor completes the execution of an
exception handler, it returns to Thread mode and immediately enters sleep mode. This mechanism
can be used in applications that only require the processor to run when an exception occurs.
2.7.2 Wake Up from Sleep Mode
The conditions for the processor to wake up depend on the mechanism that cause it to enter sleep
mode.
2.7.2.1 Wake Up from WFI or Sleep-on-Exit
Normally, the processor wakes up only when it detects an exception with sufficient priority to cause
exception entry. Some embedded systems might have to execute system restore tasks after the
processor wakes up and before executing an interrupt handler. Entry to the interrupt handler can
be delayed by setting the PRIMASK bit and clearing the FAULTMASK bit. If an interrupt arrives that
is enabled and has a higher priority than current exception priority, the processor wakes up but does
not execute the interrupt handler until the processor clears PRIMASK. For more information about
PRIMASK and FAULTMASK, see page 61 and page 62.
2.7.2.2 Wake Up from WFE
The processor wakes up if it detects an exception with sufficient priority to cause exception entry.
September 04, 201084
Texas Instruments-Production Data
In addition, if the SEVONPEND bit in the SYSCTRL register is set, any new pending interrupt triggers
an event and wakes up the processor, even if the interrupt is disabled or has insufficient priority to
cause exception entry. For more information about SYSCTRL, see page 124.
2.8 Instruction Set Summary
The processor implements a version of the Thumb instruction set. Table 2-13 on page 85 lists the
supported instructions.
Note: In Table 2-13 on page 85:
■ Angle brackets, <>, enclose alternative forms of the operand
■ Braces, {}, enclose optional operands
■ The Operands column is not exhaustive
■ Op2 is a flexible second operand that can be either a register or a constant
■ Most instructions can use an optional condition code suffix
For more information on the instructions and operands, see the instruction descriptions in
the Cortex™-M3 Instruction Set Technical User's Manual.
Table 2-13. Cortex-M3 Instruction Summary
Stellaris® LM3S1165 Microcontroller
FlagsBrief DescriptionOperandsMnemonic
N,Z,C,VAdd with carry{Rd,} Rn , Op2ADC, ADCS
N,Z,C,VAdd{Rd,} Rn , Op2ADD, ADDS
N,Z,C,VAdd{Rd,} Rn , #imm12ADD, ADDW
-Load PC-relative addressRd , labelADR
N,Z,CLogical AND{Rd ,} Rn , Op2AND, ANDS
N,Z,CArithmetic shift rightRd , Rm , <Rs|#n>ASR, ASRS
-BranchlabelB
-Bit field clearRd , #lsb , #widthBFC
-Bit field insertRd , Rn , #lsb , #widthBFI
N,Z,CBit clear{Rd ,} Rn , Op2BIC, BICS
-Breakpoint#immBKPT
-Branch with linklabelBL
-Branch indirect with linkRmBLX
-Branch indirectRmBX
-Compare and branch if non-zeroRn , labelCBNZ
-Compare and branch if zeroRn , labelCBZ
-Clear exclusive-CLREX
-Count leading zerosRd , RmCLZ
N,Z,C,VCompare negativeRn , Op2CMN
N,Z,C,VCompareRn , Op2CMP
iflagsCPSID
interrupts
iflagsCPSIE
interrupts
-Change processor state, disable
-Change processor state, enable
-Data memory barrier-DMB
-Data synchronization barrier-DSB
Texas Instruments-Production Data
85September 04, 2010
The Cortex-M3 Processor
Table 2-13. Cortex-M3 Instruction Summary (continued)
FlagsBrief DescriptionOperandsMnemonic
N,Z,CExclusive OR{Rd ,} Rn , Op2EOR, EORS
-Instruction synchronization barrier-ISB
-If-Then condition block-IT
-Load multiple registers, increment afterRn{!} , reglistLDM
Rn{!} , reglistLDMDB, LDMEA
before
Rd , spec_regMRS
register
spec_reg , R nMSR
register
Rd , RnREVSH
and sign extend
-Load multiple registers, decrement
-Load multiple registers, increment afterRn{!} , reglistLDMFD, LDMIA
-Load register with wordRt , [ Rn {, #offset}]LDR
-Load register with byteRt , [ Rn {, #offset}]LDRB, LDRBT
-Load register with two wordsRt , Rt2 , [ Rn {, #offset}]LDRD
-Load register exclusiveRt , [ Rn , #offset ]LDREX
-Load register exclusive with byteRt, [Rn]LDREXB
-Load register exclusive with halfwordRt , [Rn]LDREXH
-Load register with halfwordRt , [ Rn{ , #offset}]LDRH, LDRHT
-Load register with signed byteRt , [ Rn{ , #offset}]LDRSB, LDRSBT
-Load register with signed halfwordRt , [ Rn {, #offset}]LDRSH, LDRSHT
-Load register with wordRt , [ Rn {, #offset}]LDRT
N,Z,CLogical shift leftRd , Rm , <Rs|#n>LSL, LSLS
N,Z,CLogical shift rightRd , Rm , <Rs|#n>LSR, LSRS
-Multiply with accumulate, 32-bit resultRd , Rn , Rm, RaMLA
-Multiply and subtract, 32-bit resultRd , Rn , Rm, RaMLS
N,Z,CMoveRd , Op2MOV, MOVS
N,Z,CMove 16-bit constantRd , #imm16MOV, MOVW
-Move topRd , #imm16MOVT
-Move from special register to general
N,Z,C,VMove from general register to special
N,ZMultiply, 32-bit result{Rd,} Rn , RmMUL, MULS
N,Z,CMove NOTRd , Op2MVN, MVNS
-No operation-NOP
N,Z,CLogical OR NOT{Rd,} Rn , Op2ORN, ORNS
N,Z,CLogical OR{Rd,} Rn , Op2ORR, ORRS
-Pop registers from stackreglistPOP
-Push registers onto stackreglistPUSH
-Reverse bitsRd , RnRBIT
-Reverse byte order in a wordRd , RnREV
-Reverse byte order in each halfwordRd , RnREV16
-Reverse byte order in bottom halfword
N,Z,CRotate rightRd , Rm , <Rs|#n>ROR, RORS
N,Z,CRotate right with extendRd , RmRRX, RRXS
Texas Instruments-Production Data
September 04, 201086
Table 2-13. Cortex-M3 Instruction Summary (continued)
RdLo, RdHi, Rn, RmSMLAL
(32x32+64), 64-bit result
Rn{!} , reglistSTMDB, STMEA
before
RdLo, RdHi, Rn, RmUMLAL
(32x32+64), 64-bit result
Stellaris® LM3S1165 Microcontroller
FlagsBrief DescriptionOperandsMnemonic
N,Z,C,VReverse subtract{Rd,} Rn , Op2RSB, RSBS
N,Z,C,VSubtract with carry{Rd,} Rn , Op2SBC, SBCS
-Signed bit field extractRd , Rn , #lsb , #widthSBFX
-Signed divide{Rd ,} Rn , RmSDIV
-Send event-SEV
-Signed multiply with accumulate
-Signed multiply (32x32), 64-bit resultRdLo, RdHi, Rn, RmSMULL
QSigned saturateRd, #n, Rm {,shift #s}SSAT
-Store multiple registers, increment afterRn{!} , reglistSTM
-Store multiple registers, decrement
-Store multiple registers, increment afterRn{!} , reglistSTMFD, STMIA
-Store register wordRt , [ Rn {, #offset}]STR
-Store register byteRt , [ Rn {, #offset}]STRB, STRBT
-Store register two wordsRt , Rt2 , [ Rn {, #offset}]STRD
-Store register exclusiveRd , Rt , [ Rn , #offset ]STREX
-Store register exclusive byteRd , Rt , [Rn]STREXB
-Store register exclusive halfwordRd , Rt , [Rn]STREXH
-Store register halfwordRt , [ Rn {, #offset}]STRH, STRHT
-Store register signed byteRt , [ Rn {, #offset}]STRSB, STRSBT
-Store register signed halfwordRt , [ Rn {, #offset}]STRSH, STRSHT
-Store register wordRt , [ Rn {, #offset}]STRT
N,Z,C,VSubtract{Rd,} Rn , Op2SUB, SUBS
N,Z,C,VSubtract 12-bit constant{Rd,} Rn , #imm12SUB, SUBW
-Supervisor call#immSVC
-Sign extend a byte{Rd,} Rm {,ROR #n}SXTB
-Sign extend a halfword{Rd,} Rm {,ROR #n}SXTH
-Table branch byte[Rn, Rm]TBB
-Table branch halfword[Rn, Rm, LSL #1]TBH
N,Z,CTest equivalenceRn, Op2TEQ
N,Z,CTestRn, Op2TST
-Unsigned bit field extractRd , Rn , #lsb , #widthUBFX
-Unsigned divide{Rd,} Rn , RmUDIV
-Unsigned multiply with accumulate
-Unsigned multiply (32x 2), 64-bit resultRdLo, RdHi, Rn, RmUMULL
QUnsigned saturateRd, #n, Rm {,shift #s}USAT
-Zero extend a byte{Rd,} Rm {,ROR #n}UXTB
-Zero extend a halfword{Rd,} Rm {,ROR #n}UXTH
-Wait for event-WFE
-Wait for interrupt-WFI
Texas Instruments-Production Data
87September 04, 2010
Cortex-M3 Peripherals
3 Cortex-M3 Peripherals
This chapter provides information on the Stellaris®implementation of the Cortex-M3 processor
peripherals, including:
■ SysTick (see 88)
Provides a simple, 24-bit clear-on-write, decrementing, wrap-on-zero counter with a flexible
control mechanism.
■ Nested Vectored Interrupt Controller (NVIC)
– Facilitates low-latency exception and interrupt handling
– Controls power management
– Implements system control registers
■ System Control Block (SCB) (see 89)
Provides system implementation information and system control, including configuration, control,
and reporting of system exceptions.
■ Memory Protection Unit (MPU) (see 91)
Supports the standard ARMv7 Protected Memory System Architecture (PMSA) model. The MPU
provides full support for protection regions, overlapping protection regions, access permissions,
and exporting memory attributes to the system.
Table 3-1 on page 88 shows the address map of the Private Peripheral Bus (PPB). Some peripheral
register regions are split into two address regions, as indicated by two addresses listed.
Table 3-1. Core Peripheral Register Regions
0xE000.EF00-0xE000.EF03
3.1 Functional Description
This chapter provides information on the Stellaris®implementation of the Cortex-M3 processor
peripherals: SysTick, NVIC, SCB and MPU.
3.1.1 System Timer (SysTick)
Cortex-M3 includes an integrated system timer, SysTick, which provides a simple, 24-bit
clear-on-write, decrementing, wrap-on-zero counter with a flexible control mechanism. The counter
can be used in several different ways, for example as:
DescriptionCore PeripheralAddress
88System Timer0xE000.E010-0xE000.E01F
89Nested Vectored Interrupt Controller0xE000.E100-0xE000.E4EF
91System Control Block0xE000.ED00-0xE000.ED3F
91Memory Protection Unit0xE000.ED90-0xE000.EDB8
■ An RTOS tick timer that fires at a programmable rate (for example, 100 Hz) and invokes a SysTick
routine.
■ A high-speed alarm timer using the system clock.
September 04, 201088
Texas Instruments-Production Data
Stellaris® LM3S1165 Microcontroller
■ A variable rate alarm or signal timer—the duration is range-dependent on the reference clock
used and the dynamic range of the counter.
■ A simple counter used to measure time to completion and time used.
■ An internal clock source control based on missing/meeting durations. The COUNT bit in the
STCTRL control and status register can be used to determine if an action completed within a
set duration, as part of a dynamic clock management control loop.
The timer consists of three registers:
■ SysTick Control and Status (STCTRL): A control and status counter to configure its clock,
enable the counter, enable the SysTick interrupt, and determine counter status.
■ SysTick Reload Value (STRELOAD): The reload value for the counter, used to provide the
counter's wrap value.
■ SysTick Current Value (STCURRENT): The current value of the counter.
When enabled, the timer counts down on each clock from the reload value to zero, reloads (wraps)
to the value in the STRELOAD register on the next clock edge, then decrements on subsequent
clocks. Clearing the STRELOAD register disables the counter on the next wrap. When the counter
reaches zero, the COUNT status bit is set. The COUNT bit clears on reads.
Writing to the STCURRENT register clears the register and the COUNT status bit. The write does
not trigger the SysTick exception logic. On a read, the current value is the value of the register at
the time the register is accessed.
The SysTick counter runs on the processor clock. If this clock signal is stopped for low power mode,
the SysTick counter stops. Ensure software uses aligned word accesses to access the SysTick
registers.
Note: When the processor is halted for debugging, the counter does not decrement.
3.1.2 Nested Vectored Interrupt Controller (NVIC)
This section describes the Nested Vectored Interrupt Controller (NVIC) and the registers it uses.
The NVIC supports:
■ 35 interrupts.
■ A programmable priority level of 0-7 for each interrupt. A higher level corresponds to a lower
priority, so level 0 is the highest interrupt priority.
■ Low-latency exception and interrupt handling.
■ Level and pulse detection of interrupt signals.
■ Dynamic reprioritization of interrupts.
■ Grouping of priority values into group priority and subpriority fields.
■ Interrupt tail-chaining.
■ An external Non-maskable interrupt (NMI).
Texas Instruments-Production Data
89September 04, 2010
Cortex-M3 Peripherals
The processor automatically stacks its state on exception entry and unstacks this state on exception
exit, with no instruction overhead, providing low latency exception handling.
3.1.2.1 Level-Sensitive and Pulse Interrupts
The processor supports both level-sensitive and pulse interrupts. Pulse interrupts are also described
as edge-triggered interrupts.
A level-sensitive interrupt is held asserted until the peripheral deasserts the interrupt signal. Typically
this happens because the ISR accesses the peripheral, causing it to clear the interrupt request. A
pulse interrupt is an interrupt signal sampled synchronously on the rising edge of the processor
clock. To ensure the NVIC detects the interrupt, the peripheral must assert the interrupt signal for
at least one clock cycle, during which the NVIC detects the pulse and latches the interrupt.
When the processor enters the ISR, it automatically removes the pending state from the interrupt
(see “Hardware and Software Control of Interrupts” on page 90 for more information). For a
level-sensitive interrupt, if the signal is not deasserted before the processor returns from the ISR,
the interrupt becomes pending again, and the processor must execute its ISR again. As a result,
the peripheral can hold the interrupt signal asserted until it no longer needs servicing.
3.1.2.2 Hardware and Software Control of Interrupts
The Cortex-M3 latches all interrupts. A peripheral interrupt becomes pending for one of the following
reasons:
■ The NVIC detects that the interrupt signal is High and the interrupt is not active.
■ The NVIC detects a rising edge on the interrupt signal.
■ Software writes to the corresponding interrupt set-pending register bit, or to the Software Trigger
Interrupt (SWTRIG) register to make a Software-Generated Interrupt pending. See the INT bit
in the PEND0 register on page 107 or SWTRIG on page 115.
A pending interrupt remains pending until one of the following:
■ The processor enters the ISR for the interrupt, changing the state of the interrupt from pending
to active. Then:
– For a level-sensitive interrupt, when the processor returns from the ISR, the NVIC samples
the interrupt signal. If the signal is asserted, the state of the interrupt changes to pending,
which might cause the processor to immediately re-enter the ISR. Otherwise, the state of the
interrupt changes to inactive.
– For a pulse interrupt, the NVIC continues to monitor the interrupt signal, and if this is pulsed
the state of the interrupt changes to pending and active. In this case, when the processor
returns from the ISR the state of the interrupt changes to pending, which might cause the
processor to immediately re-enter the ISR.
If the interrupt signal is not pulsed while the processor is in the ISR, when the processor
returns from the ISR the state of the interrupt changes to inactive.
■ Software writes to the corresponding interrupt clear-pending register bit
– For a level-sensitive interrupt, if the interrupt signal is still asserted, the state of the interrupt
does not change. Otherwise, the state of the interrupt changes to inactive.
September 04, 201090
Texas Instruments-Production Data
– For a pulse interrupt, the state of the interrupt changes to inactive, if the state was pending
or to active, if the state was active and pending.
3.1.3 System Control Block (SCB)
The System Control Block (SCB) provides system implementation information and system control,
including configuration, control, and reporting of the system exceptions.
3.1.4 Memory Protection Unit (MPU)
This section describes the Memory protection unit (MPU). The MPU divides the memory map into
a number of regions and defines the location, size, access permissions, and memory attributes of
each region. The MPU supports independent attribute settings for each region, overlapping regions,
and export of memory attributes to the system.
The memory attributes affect the behavior of memory accesses to the region. The Cortex-M3 MPU
defines eight separate memory regions, 0-7, and a background region.
When memory regions overlap, a memory access is affected by the attributes of the region with the
highest number. For example, the attributes for region 7 take precedence over the attributes of any
region that overlaps region 7.
The background region has the same memory access attributes as the default memory map, but is
accessible from privileged software only.
Stellaris® LM3S1165 Microcontroller
The Cortex-M3 MPU memory map is unified, meaning that instruction accesses and data accesses
have the same region settings.
If a program accesses a memory location that is prohibited by the MPU, the processor generates
a memory management fault, causing a fault exception and possibly causing termination of the
process in an OS environment. In an OS environment, the kernel can update the MPU region setting
dynamically based on the process to be executed. Typically, an embedded OS uses the MPU for
memory protection.
Configuration of MPU regions is based on memory types (see “Memory Regions, Types and
Attributes” on page 67 for more information).
Table 3-2 on page 91 shows the possible MPU region attributes. See the section called “MPU
Configuration for a Stellaris®Microcontroller” on page 95 for guidelines for programming a
microcontroller implementation.
Table 3-2. Memory Attributes Summary
DescriptionMemory Type
All accesses to Strongly Ordered memory occur in program order.Strongly Ordered
Memory-mapped peripheralsDevice
Normal memoryNormal
To avoid unexpected behavior, disable the interrupts before updating the attributes of a region that
the interrupt handlers might access.
Ensure software uses aligned accesses of the correct size to access MPU registers:
■ Except for the MPU Region Attribute and Size (MPUATTR) register, all MPU registers must
be accessed with aligned word accesses.
■ The MPUATTR register can be accessed with byte or aligned halfword or word accesses.
Texas Instruments-Production Data
91September 04, 2010
Cortex-M3 Peripherals
The processor does not support unaligned accesses to MPU registers.
When setting up the MPU, and if the MPU has previously been programmed, disable unused regions
to prevent any previous region settings from affecting the new MPU setup.
3.1.4.1 Updating an MPU Region
To update the attributes for an MPU region, the MPU Region Number (MPUNUMBER), MPU
Region Base Address (MPUBASE) and MPUATTR registers must be updated. Each register can
be programmed separately or with a multiple-word write to program all of these registers. You can
use the MPUBASEx and MPUATTRx aliases to program up to four regions simultaneously using
an STM instruction.
Updating an MPU Region Using Separate Words
This example simple code configures one region:
; R1 = region number
; R2 = size/enable
; R3 = attributes
; R4 = address
LDR R0,=MPUNUMBER ; 0xE000ED98, MPU region number register
STR R1, [R0, #0x0] ; Region Number
STR R4, [R0, #0x4] ; Region Base Address
STRH R2, [R0, #0x8] ; Region Size and Enable
STRH R3, [R0, #0xA] ; Region Attribute
Disable a region before writing new region settings to the MPU if you have previously enabled the
region being changed. For example:
; R1 = region number
; R2 = size/enable
; R3 = attributes
; R4 = address
LDR R0,=MPUNUMBER ; 0xE000ED98, MPU region number register
STR R1, [R0, #0x0] ; Region Number
BIC R2, R2, #1 ; Disable
STRH R2, [R0, #0x8] ; Region Size and Enable
STR R4, [R0, #0x4] ; Region Base Address
STRH R3, [R0, #0xA] ; Region Attribute
ORR R2, #1 ; Enable
STRH R2, [R0, #0x8] ; Region Size and Enable
Software must use memory barrier instructions:
■ Before MPU setup, if there might be outstanding memory transfers, such as buffered writes, that
might be affected by the change in MPU settings.
■ After MPU setup, if it includes memory transfers that must use the new MPU settings.
However, memory barrier instructions are not required if the MPU setup process starts by entering
an exception handler, or is followed by an exception return, because the exception entry and
exception return mechanism cause memory barrier behavior.
Software does not need any memory barrier instructions during MPU setup, because it accesses
the MPU through the Private Peripheral Bus (PPB), which is a Strongly Ordered memory region.
September 04, 201092
Texas Instruments-Production Data
Stellaris® LM3S1165 Microcontroller
For example, if all of the memory access behavior is intended to take effect immediately after the
programming sequence, then a DSB instruction and an ISB instruction should be used. A DSB is
required after changing MPU settings, such as at the end of context switch. An ISB is required if
the code that programs the MPU region or regions is entered using a branch or call. If the
programming sequence is entered using a return from exception, or by taking an exception, then
an ISB is not required.
Updating an MPU Region Using Multi-Word Writes
The MPU can be programmed directly using multi-word writes, depending how the information is
divided. Consider the following reprogramming:
; R1 = region number
; R2 = address
; R3 = size, attributes in one
LDR R0, =MPUNUMBER ; 0xE000ED98, MPU region number register
STR R1, [R0, #0x0] ; Region Number
STR R2, [R0, #0x4] ; Region Base Address
STR R3, [R0, #0x8] ; Region Attribute, Size and Enable
An STM instruction can be used to optimize this:
; R1 = region number
; R2 = address
; R3 = size, attributes in one
LDR R0, =MPUNUMBER ; 0xE000ED98, MPU region number register
STM R0, {R1-R3} ; Region number, address, attribute, size and enable
This operation can be done in two words for pre-packed information, meaning that the MPU Region
Base Address (MPUBASE) register (see page 149) contains the required region number and has
the VALID bit set. This method can be used when the data is statically packed, for example in a
boot loader:
; R1 = address and region number in one
; R2 = size and attributes in one
LDR R0, =MPUBASE ; 0xE000ED9C, MPU Region Base register
STR R1, [R0, #0x0] ; Region base address and region number combined
; with VALID (bit 4) set
STR R2, [R0, #0x4] ; Region Attribute, Size and Enable
An STM instruction can be used to optimize this:
; R1 = address and region number in one
; R2 = size and attributes in one
LDR R0,=MPUBASE ; 0xE000ED9C, MPU Region Base register
STM R0, {R1-R2} ; Region base address, region number and VALID bit,
; and Region Attribute, Size and Enable
Subregions
Regions of 256 bytes or more are divided into eight equal-sized subregions. Set the corresponding
bit in the SRD field of the MPU Region Attribute and Size (MPUATTR) register (see page 151) to
disable a subregion. The least-significant bit of the SRD field controls the first subregion, and the
most-significant bit controls the last subregion. Disabling a subregion means another region
93September 04, 2010
Texas Instruments-Production Data
Region 1
Disabled subregion
Disabled subregion
Region 2, with
subregions
Base address of both regions
Offset from
base address
0
64KB
128KB
192KB
256KB
320KB
384KB
448KB
512KB
Cortex-M3 Peripherals
overlapping the disabled range matches instead. If no other enabled region overlaps the disabled
subregion, the MPU issues a fault.
Regions of 32, 64, and 128 bytes do not support subregions. With regions of these sizes, the SRD
field must be configured to 0x00, otherwise the MPU behavior is unpredictable.
Example of SRD Use
Two regions with the same base address overlap. Region one is 128 KB, and region two is 512 KB.
To ensure the attributes from region one apply to the first 128 KB region, configure the SRD field for
region two to 0x03 to disable the first two subregions, as Figure 3-1 on page 94 shows.
Figure 3-1. SRD Use Example
3.1.4.2 MPU Access Permission Attributes
The access permission bits, TEX, S, C, B, AP, and XN of the MPUATTR register, control access to
the corresponding memory region. If an access is made to an area of memory without the required
permissions, then the MPU generates a permission fault.
Table 3-3 on page 94 shows the encodings for the TEX, C, B, and S access permission bits. All
encodings are shown for completeness, however the current implementation of the Cortex-M3 does
not support the concept of cacheability or shareability. Refer to the section called “MPU Configuration
for a Stellaris®Microcontroller” on page 95 for information on programming the MPU for Stellaris
®
implementations.
Table 3-3. TEX, S, C, and B Bit Field Encoding
Other AttributesShareabilityMemory TypeBCSTEX
000b
000
001
001
a
a
a
a
Texas Instruments-Production Data
Not shareableNormal010000
ShareableNormal011000
Not shareableNormal110000
ShareableNormal111000
Not shareableNormal000001
ShareableNormal001001
Not shareableNormal110001
ShareableNormal111001
-ShareableStrongly Ordered00x
-ShareableDevice10x
Outer and inner
write-through. No write
allocate.
Outer and inner
noncacheable.
--Reserved encoding10x
--Reserved encoding01x
Outer and inner
write-back. Write and
read allocate.
September 04, 201094
Stellaris® LM3S1165 Microcontroller
Table 3-3. TEX, S, C, and B Bit Field Encoding (continued)
Other AttributesShareabilityMemory TypeBCSTEX
010
010
010
a. The MPU ignores the value of this bit.
a
a
a
1x
a
Not shareableNormalAA01BB
ShareableNormalAA11BB
Nonshared Device.Not shareableDevice00x
--Reserved encoding10x
--Reserved encodingx
Cached memory (BB =
outer policy, AA = inner
policy).
See Table 3-4 for the
encoding of the AA and
BB bits.
Table 3-4 on page 95 shows the cache policy for memory attribute encodings with a TEX value in
the range of 0x4-0x7.
Table 3-4. Cache Policy for Memory Attribute Encoding
Corresponding Cache PolicyEncoding, AA or BB
Non-cacheable00
Write back, write and read allocate01
Write through, no write allocate10
Write back, no write allocate11
Table 3-5 on page 95 shows the AP encodings in the MPUATTR register that define the access
permissions for privileged and unprivileged software.
Table 3-5. AP Bit Field Encoding
AP Bit Field
Privileged
Permissions
Permissions
ROR/W010
DescriptionUnprivileged
All accesses generate a permission fault.No accessNo access000
Access from privileged software only.No accessR/W001
Writes by unprivileged software generate a
permission fault.
Full access.R/WR/W011
Reserved.UnpredictableUnpredictable100
Reads by privileged software only.No accessRO101
Read-only, by privileged or unprivileged software.RORO110
Read-only, by privileged or unprivileged software.RORO111
MPU Configuration for a Stellaris®Microcontroller
Stellaris®microcontrollers have only a single processor and no caches. As a result, the MPU should
be programmed as shown in Table 3-6 on page 95.
Table 3-6. Memory Region Attributes for Stellaris®Microcontrollers
Memory Type and AttributesBCSTEXMemory Region
Normal memory, non-shareable, write-through010000bFlash memory
Normal memory, shareable, write-through011000bInternal SRAM
Texas Instruments-Production Data
95September 04, 2010
Cortex-M3 Peripherals
Table 3-6. Memory Region Attributes for Stellaris®Microcontrollers (continued)
In current Stellaris®microcontroller implementations, the shareability and cache policy attributes do
not affect the system behavior. However, using these settings for the MPU regions can make the
application code more portable. The values given are for typical situations.
3.1.4.3 MPU Mismatch
When an access violates the MPU permissions, the processor generates a memory management
fault (see “Exceptions and Interrupts” on page 65 for more information). The MFAULTSTAT register
indicates the cause of the fault. See page 135 for more information.
3.2 Register Map
Table 3-7 on page 96 lists the Cortex-M3 Peripheral SysTick, NVIC, SCB and MPU registers. The
offset listed is a hexadecimal increment to the register's address, relative to the Core Peripherals
base address of 0xE000.E000.
Memory Type and AttributesBCSTEXMemory Region
111000bExternal SRAM
Normal memory, shareable, write-back,
write-allocate
Device memory, shareable101000bPeripherals
Note: Register spaces that are not used are reserved for future or internal use. Software should
not modify any reserved memory address.
Table 3-7. Peripherals Register Map
System Timer (SysTick) Registers
Nested Vectored Interrupt Controller (NVIC) Registers
DescriptionResetTypeNameOffset
See
page
99SysTick Control and Status Register0x0000.0000R/WSTCTRL0x010
101SysTick Reload Value Register0x0000.0000R/WSTRELOAD0x014
102SysTick Current Value Register0x0000.0000R/WCSTCURRENT0x018
103Interrupt 0-31 Set Enable0x0000.0000R/WEN00x100
104Interrupt 32-43 Set Enable0x0000.0000R/WEN10x104
105Interrupt 0-31 Clear Enable0x0000.0000R/WDIS00x180
106Interrupt 32-43 Clear Enable0x0000.0000R/WDIS10x184
107Interrupt 0-31 Set Pending0x0000.0000R/WPEND00x200
108Interrupt 32-43 Set Pending0x0000.0000R/WPEND10x204
109Interrupt 0-31 Clear Pending0x0000.0000R/WUNPEND00x280
Texas Instruments-Production Data
110Interrupt 32-43 Clear Pending0x0000.0000R/WUNPEND10x284
111Interrupt 0-31 Active Bit0x0000.0000ROACTIVE00x300
112Interrupt 32-43 Active Bit0x0000.0000ROACTIVE10x304
113Interrupt 0-3 Priority0x0000.0000R/WPRI00x400
September 04, 201096
Table 3-7. Peripherals Register Map (continued)
Stellaris® LM3S1165 Microcontroller
System Control Block (SCB) Registers
DescriptionResetTypeNameOffset
See
page
113Interrupt 4-7 Priority0x0000.0000R/WPRI10x404
113Interrupt 8-11 Priority0x0000.0000R/WPRI20x408
113Interrupt 12-15 Priority0x0000.0000R/WPRI30x40C
113Interrupt 16-19 Priority0x0000.0000R/WPRI40x410
113Interrupt 20-23 Priority0x0000.0000R/WPRI50x414
113Interrupt 24-27 Priority0x0000.0000R/WPRI60x418
113Interrupt 28-31 Priority0x0000.0000R/WPRI70x41C
113Interrupt 32-35 Priority0x0000.0000R/WPRI80x420
113Interrupt 36-39 Priority0x0000.0000R/WPRI90x424
113Interrupt 40-43 Priority0x0000.0000R/WPRI100x428
115Software Trigger Interrupt0x0000.0000WOSWTRIG0xF00
116CPU ID Base0x411F.C231ROCPUID0xD00
117Interrupt Control and State0x0000.0000R/WINTCTRL0xD04
121Vector Table Offset0x0000.0000R/WVTABLE0xD08
Memory Protection Unit (MPU) Registers
122Application Interrupt and Reset Control0xFA05.0000R/WAPINT0xD0C
124System Control0x0000.0000R/WSYSCTRL0xD10
126Configuration and Control0x0000.0000R/WCFGCTRL0xD14
128System Handler Priority 10x0000.0000R/WSYSPRI10xD18
129System Handler Priority 20x0000.0000R/WSYSPRI20xD1C
130System Handler Priority 30x0000.0000R/WSYSPRI30xD20
131System Handler Control and State0x0000.0000R/WSYSHNDCTRL0xD24
135Configurable Fault Status0x0000.0000R/W1CFAULTSTAT0xD28
141Hard Fault Status0x0000.0000R/W1CHFAULTSTAT0xD2C
143Memory Management Fault Address-R/WMMADDR0xD34
144Bus Fault Address-R/WFAULTADDR0xD38
145MPU Type0x0000.0800ROMPUTYPE0xD90
146MPU Control0x0000.0000R/WMPUCTRL0xD94
148MPU Region Number0x0000.0000R/WMPUNUMBER0xD98
149MPU Region Base Address0x0000.0000R/WMPUBASE0xD9C
151MPU Region Attribute and Size0x0000.0000R/WMPUATTR0xDA0
Texas Instruments-Production Data
97September 04, 2010
Cortex-M3 Peripherals
Table 3-7. Peripherals Register Map (continued)
DescriptionResetTypeNameOffset
3.3 System Timer (SysTick) Register Descriptions
This section lists and describes the System Timer registers, in numerical order by address offset.
See
page
149MPU Region Base Address Alias 10x0000.0000R/WMPUBASE10xDA4
151MPU Region Attribute and Size Alias 10x0000.0000R/WMPUATTR10xDA8
149MPU Region Base Address Alias 20x0000.0000R/WMPUBASE20xDAC
151MPU Region Attribute and Size Alias 20x0000.0000R/WMPUATTR20xDB0
149MPU Region Base Address Alias 30x0000.0000R/WMPUBASE30xDB4
151MPU Region Attribute and Size Alias 30x0000.0000R/WMPUATTR30xDB8
Texas Instruments-Production Data
September 04, 201098
Register 1: SysTick Control and Status Register (STCTRL), offset 0x010
Note: This register can only be accessed from privileged mode.
The SysTick STCTRL register enables the SysTick features.
SysTick Control and Status Register (STCTRL)
Base 0xE000.E000
Offset 0x010
Type R/W, reset 0x0000.0000
Stellaris® LM3S1165 Microcontroller
16171819202122232425262728293031
COUNTreserved
ROROROROROROROROROROROROROROROROType
0000000000000000Reset
0123456789101112131415
ENABLEINTENCLK_SRCreserved
R/WR/WR/WROROROROROROROROROROROROROType
0000000000000000Reset
DescriptionResetTypeNameBit/Field
0x000ROreserved31:17
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0ROCOUNT16
Count Flag
DescriptionValue
0
The SysTick timer has not counted to 0 since the last time
this bit was read.
1
The SysTick timer has counted to 0 since the last time
this bit was read.
This bit is cleared by a read of the register or if the STCURRENT register
is written with any value.
If read by the debugger using the DAP, this bit is cleared only if the
MasterType bit in the AHB-AP Control Register is clear. Otherwise,
the COUNT bit is not changed by the debugger read. See the ARM®
Debug Interface V5 Architecture Specification for more information on
MasterType.
0x000ROreserved15:3
Software should not rely on the value of a reserved bit. To provide
compatibility with future products, the value of a reserved bit should be
preserved across a read-modify-write operation.
0R/WCLK_SRC2
Clock Source
DescriptionValue
External reference clock. (Not implemented for Stellaris
0
®
microcontrollers.)
System clock1
Because an external reference clock is not implemented, this bit must
be set in order for SysTick to operate.
Texas Instruments-Production Data
99September 04, 2010
Cortex-M3 Peripherals
DescriptionResetTypeNameBit/Field
0R/WINTEN1
0R/WENABLE0
Interrupt Enable
DescriptionValue
0
1
Enable
1
Interrupt generation is disabled. Software can use the
COUNT bit to determine if the counter has ever reached 0.
An interrupt is generated to the NVIC when SysTick counts
to 0.
DescriptionValue
The counter is disabled.0
Enables SysTick to operate in a multi-shot way. That is, the
counter loads the RELOAD value and begins counting down.
On reaching 0, the COUNT bit is set and an interrupt is
generated if enabled by INTEN. The counter then loads the
RELOAD value again and begins counting.
Texas Instruments-Production Data
September 04, 2010100
Loading...
