About This Manual
Contents
Preface

This document provides the information needed to setup and operate the SRC4192EVM evaluation module. For a more detailed description of the SRC4190, SRC4192, or SRC4193 products, please refer to the product data sheets available from the Texas Instruments web site at http://www.ti.com Support documents are listed in the sections of this guide entitled Related Doc­umentation from Texas Instruments and Additional Documentation.
.
How to Use This Manual
Throughout this document, the abbreviation EVM and the term evaluation module are synonymous with the SRC4192EVM. The abbreviation SRC419x refers to the SRC4190, SRC4192. and SRC4193 family of de-
vices. Chapter 1 provides an overview of the SRC419x family of stereo asynchro-
nous sample rate converters. The SRC4192EVM block diagram and prima­ry features are also discussed.
Chapter 2 provides general information regarding EVM handling and un­packing, absolute operating conditions, and the default switch and jumper configuration.
Chapter 3 is the hardware setup guide for the EVM, providing all of the nec­essary information needed to configure the EVM switches and jumpers for product evaluation.
Chapter 4 includes the EVM electrical schematic, PCB layout, and the Bill of Materials.
Information About Cautions and Warnings
This book contains cautions.
This is an example of a caution statement. A caution statement describes a situation that could potentially
damage your software or equipment.
Contents
iii
Contents
This is an example of a warning statement. A warning statement describes a situation that could potentially
cause harm to you
.
The information in a caution or a warning is provided for your protection. Please read each caution and warning carefully.
Related Documentation From Texas Instruments
The following documents provide information regarding Texas Instruments integrated circuits used in the assembly of the SRC4192EVM. These docu­ments are available from the TI web site. The last character of the literature number corresponds to the document revision, which is current at the time of the writing of this User’s Guide. Newer revisions may be available from the TI web site at http://www.ti.com/ Response Center at (800) 477–8924 or the Product Information Center at (972) 644–5580. When ordering, identify the booklet(s) by both title and literature number.
or call the Texas Instruments Literature
Data sheets Literature number
SRC4192/4193 Data Sheet SBFS022 DIT4192 Data Sheet SBOS229 PLL1705 Data Sheet SLES046 REG1117 Data Sheet SBVS001 SN74AHC32 SCLS247G SN74AHC244 SCLS226I SN74AHC1G04 SCLS318L SN74AHC1G14 SCLS321K SN74ALVC125 Data Sheet SCES110E SN74ALVC244 Data Sheet SCES188B SN74ALVC245 Data Sheet SCES271B SN74CBTLV3245A Data Sheet SCDS034J SN74LVC04A Data Sheet SCAS281M SN74LVC1G07 Data Sheet SCES296K SN74LVC1G125 Data Sheet SCES223G
iv
Additional Documentation
The following documents provide information regarding selected non–TI components, which are used in the assembly of the SRC4192EVM. These documents are available from the corresponding manufacturers.
Document Manufacturer
CS8414 Data Sheet Cirrus Logic, http://www.cirrus.com HCM49 Series Crystals Citizen, http://www.citizencrystal.com SC937–02 Data Sheet Scientific Conversion
SC979–03 Data Sheet Scientific Conversion
If You Need Assistance
If you have questions regarding either the use of this evaluation module or the information contained in the accompanying documentation, please con­tact the Texas Instruments Product Information Center at (972) 644–5580 or visit the TI web site at www.ti.com.
FCC Warning
Contents
http://www.scientificonversion.com http://www.scientificonversion.com
Trademarks
This equipment is intended for use in a laboratory test environment only. It generates, uses, and can radiate radio frequency energy and has not been tested for compliance with the limits of computing devices pursuant to sub­part J of part 15 of FCC rules, which are designed to provide reasonable protection against radio frequency interference. Operation of this equip­ment in other environments may cause interference with radio communica­tions, in which case the user at his own expense will be required to take whatever measures may be required to correct this interference.
All trademarks are the property of their respective owners.
Contents
v
Contents

1 Introduction 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 The SRC4190, SRC4192, and SRC4193 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 EVM Block Diagram 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 EVM Features 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Getting Started 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Electrostatic Discharge Warning 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Absolute Maximum Operating Conditions 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Unpacking the EVM 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Default Configuration 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Setup Guide 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Power Supply Configuration 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Device Selection 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Selecting the Input & Output Port Modes 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4 Selecting the Input & Output Data Formats 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.5 Selecting an Input Source and an Output Port 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.6 Selecting the SRC419x Reference Clock Source and Frequency 3-7. . . . . . . . . . . . . . . . . . . .
3.7 Selecting the DIT4192 Master Clock Source and Frequency 3-8. . . . . . . . . . . . . . . . . . . . . . . .
3.8 Miscellaneous Functions 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.9 Reset Functions 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Schematic, PCB Layout and Bill of Materials 4-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 Schematic 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Component Layout 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3 Bill of Materials 4-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents
vii
Contents

Figure 1–1. Functional Block Diagram for the SRC4192 and SRC4193 1-3. . . . . . . . . . . . . . . . . . . . . .
Figure 1–2. Functional Block Diagram for the SRC4192EVM 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure 4–1. SRC4192EVM Schematic Diagram (page 1 of 2) 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure 4–2. SRC4192EVM Schematic Diagram (page 2 of 2) 4-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure 4–3. PCB Silkscreen, Top Layer 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure 4–4. Top Side Layout (Component Side) 4-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Figure 4–5. Bottom Side Layout (Solder Side) 4-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Table 2–1. Absolute Maximum Operating Conditions 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table 2–2. Default Switch and Jumper Settings 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table 3–1. SRC419x Input & Output Port Mode Selection 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table 3–2. SRC419x Input & Output Port Data Format Configuration 3-4. . . . . . . . . . . . . . . . . . . . . . . .
Table 3–3. Digital Audio Receiver Output Data Format Configuration 3-5. . . . . . . . . . . . . . . . . . . . . . . .
Table 3–4. Digital Audio Transmitter Input Data Format Configuration 3-6. . . . . . . . . . . . . . . . . . . . . . .
Table 3–5. PLL Reference Clock Selection for the SRC419x 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table 3–6. DIT4192 Master Clock Selection 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table 3–7. Master Clock Source Selection 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table 3–8. PLL Master Clock Selection for the DIT4192 3-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table 3–9. Low Group Delay Configuration 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table 3–10. Bypass Mode Configuration 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table 3–11. Mute Function Configuration 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table 3–12. DIT4192 Mono Mode Configuration 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Table 4–1. Bill of Materials 4-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
viii
Contents

Electrostatic Discharge Warning 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Contents
ix
Chapter 1

This chapter provides a brief technical overview for the SRC4190, SRC4192, and SRC4193 asynchronous sample rate converters, as well as a general description and feature list for the SRC4192EVM.
Topic Page
1.1 The SRC4190, SRC4192 and SRC4193 1-2. . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 EVM Block Diagram 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 EVM Features 1-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Introduction
1-1
The SRC4190, SRC4192, and SRC4193
1.1 The SRC4190, SRC4192, and SRC4193
The SRC4192 and SRC4193 are stereo asynchronous sample rate convert­ers designed for professional and broadcast audio applications. Operation at input and output sampling frequencies up to 212kHz is supported, with an in­put/output sampling ratio range of 16:1 to 1:16. Excellent dynamic range and THD+N are achieved by employing high performance, linear phase digital fil­tering with better than 140dB of image rejection. The SRC4190 is a lower–cost version of the SRC4192 with reduced performance specifications, but it is functionally equivalent to the SRC4192 and shares the same pin configura­tion.
The SRC4190 and SRC4192 are both stand–alone, pin–programmed de­vices, with control inputs for mode, data format, mute, bypass, and low group delay functions. The SRC4193 includes a three–wire serial peripheral inter­face (SPI) port, which allows access to on–chip control registers for device function configuration. The SPI port can be easily interfaced to microproces­sors or digital signal processors with synchronous serial port interfaces.
All three devices offer filtering options, which allow for lower group delay proc­essing. These options include a low group delay mode for the interpolation function and a direct down–sampling mode (SRC4193 only) for the decimation function.
The audio input and output ports support standard audio data formats, as well as a TDM interface mode. Word lengths of 24–, 20–, 18–, and 16–bits are sup­ported. Both ports may operate in Slave mode, deriving their word (LRCK) and bit (BCK) clocks from external input and output devices. Alternatively, one port may be operated in Master mode while the other remains in Slave mode. In Master mode, the LRCK and BCK clocks are derived from the reference clock (RCKI) input. The flexible configuration of the audio ports allows connection to a wide variety of audio data converters, digital audio interface devices, and digital signal processors.
A bypass mode is also included. This mode allows data to be passed directly from the audio input port to the audio output port, bypassing the sample rate converter function. The bypass option is useful for passing through encoded or compressed audio data, or non–audio control and status data. The input and output port clocks must be synchronous with one another in bypass mode.
A soft mute function is included in all three devices. A digital attenuation func­tion is available only for the SRC4193. Both soft mute and digital attenuation functions provide artifact free operation, while allowing muting or level adjust­ment of the audio output signal. The mute attenuation is typically –144dB for the SRC4192 and SRC4193, and –128dB for the SRC4190. The SRC4193 digital attenuation function is adjustable from 0dB to –127.5dB in 0.5dB steps.
A block diagram of the SRC4192 and SRC4193 is shown in Figure 1–1. The SRC4190 offers the same functionality as the SRC4192.
1-2
The SRC4190, SRC4192, and SRC4193
Figure 1–1.Functional Block Diagram for the SRC4192 and SRC4193
LRCKI
BCKI
SDIN
MODE[2:0]
IFMT[2:0]
OFMT[1:0]
OWL[1:0]
MUTE
BYPAS
LGRP
/RST
MUTE
BYPAS
/RST
/CS
CCLK
CDATA
LRCKO
BCKO
SDOUT
TDMI
RCKI
Audio
Input
Port
Control
Logic
(SRC4192)
SPI and
Control Logic
(SRC4193)
Audio
Output
Port
Reference Clock
f
sIN
LRCKI
LRCKO
MUX
REFCLK
Rate
Estimator
Interpolation
REFCLK
/RDY RATIO (SRC4193 only)
Filters
16f
f
f
sOUT
sOUT
sIN
(SRC4193 only)
Re–Sampler
Decimation
Filters
Direct
Down–Sampler
Power
16f
sOUT
VDD DGND VIO DGND
1.2 EVM Block Diagram
The block diagram for the SRC4192EVM is shown in Figure 1–2. The EVM in­cludes buffered audio input and output ports that support I Right Justified, and TDM data formats. These ports may be connected to ex­ternal receivers and transmitters, data converters, or digital signal processors. An on–board 96kHz receiver is provided, as well as a 192kHz transmitter. The receiver and transmitter provide for convenient connection to both test and commercial audio equipment supporting AES3 or S/PDIF interfaces.
The SRC4192 and DIT4192 have their own external phase locked loop circuits for on–board clock generation. External clock inputs are also available and provide for additional flexibility. The EVM is configured using on–board switches and jumpers, in addition to a buffered host port, which supports the SRC4193 SPI interface. A single +5 volt power supply is all that is needed to power the EVM. A +3.3 volt supply is derived from the +5 volt supply using an on–board voltage regulator.
2
S, Left Justified,
Introduction
1-3
The SRC4190, SRC4192, and SRC4193
1.3 EVM Features
Key features for the SRC4192EVM include:
- Zero Insertion Force (ZIF) socket for easily interchanging SRC4190,
SRC4192 and SRC4193 devices. The Analog Devices AD1895 and AD1896 are also supported for head–to–head testing.
- On–board or external clock generation.
- On–board receiver and transmitter supports AES3 input and output (75
BNC connections provided).
- Buffered audio input and output ports using standard dual in–line headers.
- Buffered Host Port supports connection to an external controller
(SRC4193 only).
- Operation from a single +5 volt power supply.
Figure 1–2.Functional Block Diagram for the SRC4192EVM
GND +5V
+5V
Digital
Input
75 ohm
Digital
Output
75 ohm
REG1117
External
DIT
Clock
+3.3V
Audio
Input
Port
Receiver
CS8414
Audio
Output
Port
Transmitter
DIT4192
Clock
Generator
PLL1705
SRC4192EVM
H
B
D
U
R
F
B U F
B
H
U
D
F
R
B U
F
Sample
Rate
Converter
SRC4192
or
SRC4193
ZIF Socket
Provided
Clock
Generator
PLL1705
Host
H
Interface
D R
SWDIP Switch
Port
(SRC4193 Only)
(SRC4192 Only)
External
SRC
Clock
1-4
Introduction
1-5
Chapter 2
 
This chapter provides information regarding SRC4192EVM handling and unpacking, absolute operating conditions, and a description of the factory default switch and jumper configuration.
Topic Page
2.1 Electrostatic Discharge Warning 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Absolute Maximum Operating Conditions 2-2. . . . . . . . . . . . . . . . . . . . . . .
2.3 Unpacking the EVM 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Default Configuration 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Getting Started
2-1
Absolute Maximum Operating Conditions
2.1 Electrostatic Discharge Warning
Many of the components on the SRC4192EVM are susceptible to damage by electrostatic discharge (ESD). Customers are advised to observe proper ESD handling precautions when unpacking and handling the EVM, including the use of a grounded wrist strap at an approved ESD workstation.
Caution: Failure to observe ESD handling procedures may result in damage to EVM components.
2.2 Absolute Maximum Operating Conditions
The user should be aware of the absolute maximum operating conditions for the SRC4192EVM. Exceeding these conditions may result in damage to the EVM. Table 2–1 summarizes the critical data points.
Table 2–1.Absolute Maximum Operating Conditions
Parameter Maximum Condition
Power Supply +5.5 VDC maximum Audio Input and Output Ports, Host Port,
External SRC Clock, External DIT Clock
V
IH
V
IL
Digital Audio Input (Connector J2)
V
IH
V
IL
2.3 Unpacking the EVM
Upon opening the SRC4192EVM package, please check to make sure that the following items are included:
- One SRC4192EVM.
- One SRC4192IDB installed in the EVM ZIF socket.
+4.0 Volts maximum –0.5 Volts minumum
+12 Volts maximum –12 Volts minumum
2-2
If either of these items are missing, please contact the Texas Instruments Product Information Center nearest you to inquire about a replacement.
2.4 Default Configuration
The factory default switch and jumper settings are shown in Table 2, and result in the following EVM configuration:
- The SRC4192 Input Port is set to Slave mode, with the CS8414 receiver
selected as the input source.
- The SRC4192 Output Port is set to Slave mode, with the DIT4192 trans-
mitter selected as the output device.
- The SRC PLL (U16) is selected as the SRC419x reference clock source
and is set to 24.576MHz.
- The SRC4192 input and output port data formats are set to 24–Bit Left
Justified.
- The CS8414 receiver output format is set to 24–Bit Left Justified
- The DIT4192 transmitter input format is set to 24–Bit Left Justified
- The DIT4192 transmitter MCLK frequency is set to 256fs, with fs = 48kHz.
Default Configuration
- The transmitter PLL (U6) is selected as the DIT4192 MCLK source and is
set to 12.288MHz.
- The DIT4192 transmitter output mode is set to stereo.
- The SRC4192 Low Group Delay, Bypass, and Mute modes are all dis-
abled.
Table 2–2.Default Switch and Jumper Settings
SW1 Set To: SW3 Set To: SW6 Set To: SW7 Set To:
M0 M1 M2
SW9 Set To: SW10 Set To: J8 Set To:
SFS1 SFS2 SSR ~PLL OM/~S ~IPORT MONO MDAT
LO LO LO
LO LO HI LO LO HI LO LO
CLK1 CLK0 FMT0 FMT1
MODE2 MODE1 MODE0 ~PORT OFMT0 OFMT1 OWL0 OWL1
LO HI LO LO
LO LO LO HI LO LO LO LO
TSR TFS2 TFS1 TPLL
1–2 (I2S/RJ) 3–4 (LJ)
LO LO LO LO
LGRP BYPAS IFMT0 IFMT1 IFMT2 MUTE ~4193 IS/M
OPEN SHORT
LO LO LO LO LO LO HI HI
Getting Started
2-3
Chapter 3
 
This chapter provides a step–by–step guide to configuring the SRC4192EVM for device evaluation. Follow the sections to walk through the setup of the SRC4192EVM.
Topic Page
3.1 Power Supply Configuration 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Device Selection 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Selecting the Input & Output Port Modes 3-3. . . . . . . . . . . . . . . . . . . . . . . .
3.4 Selecting the Input & Output Data Format 3-4. . . . . . . . . . . . . . . . . . . . . . .
3.5 Selecting an Input Source and an Output Port 3-5. . . . . . . . . . . . . . . . . . .
3.6 Selecting the SRC419x Reference Clock Source and Frequency 3-7. .
3.7 Selecting the DIT4192 Master Clock Source and Frequency 3-8. . . . . .
3.8 Miscellaneous Functions 3-10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.9 Reset Functions 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Setup Guide
3-1
Power Supply Configuration
3.1 Power Supply Configuration
The SRC4192EVM requires a single +5 volt regulated dc power supply, connected at the +5V terminal of J9. The GND terminal of J9 should be connected to the power supply ground or common terminal. The supply should not be connected to terminal block J9 while hot, as damage may occur to the EVM. At no time should the power supply exceed the absolute maximum rating.
3.2 Device Selection
The ~4193 element of switch SW7 is utilized to select the device under test.
When ~4193 is set to LO, the EVM is configured for the SRC4193. The SRC4193 is a software–controlled device, which employs an SPI port to access internal control registers. The SPI port is accessed through the buffered Host Port at connector J5. The Host Port supports connection to an external microprocessor or DSP for host control.
When ~4193 is set to HI, the EVM is configured for the SRC4190 or SRC4192. These units are stand–alone devices and do not require an ex­ternal host for operation. The user configures the EVM by means of the on–board switches and jumpers. The Analog Devices AD1895 and AD1896 are also supported in this mode, enabling head–to–head comparison test­ing.
3-2
3.3 Selecting the Input & Output Port Modes
The input and output ports of the SRC419x devices support seven modes of operation. Table 3–1 summarizes the mode settings for the SRC419x devices. In Master mode, the LRCK and BCK clocks are outputs, derived from the reference clock (RCKI) input. In Slave mode, the LRCK and BCK clocks are inputs, which are generated by the audio input or output device.
When ~4193 is set to HI, the port modes are selected using the MODE0, MODE1, and MODE2 elements of switch SW10.
When ~SRC4193 is set to LO, the MODE[2:0] bits in Control Register 1 of the SRC4193 are used to select the port modes.
Table 3–1.SRC419x Input & Output Port Mode Selection
MODE2 MODE1 MODE0 Serial Port Mode
LO LO LO Both Input and Output Ports are in Slave mode
Selecting the Input & Output Port Modes
LO LO HI Output Port is in Master mode with RCKI = 128f LO HI LO Output Port is in Master mode with RCKI = 512f LO HI HI Output Port is in Master mode with RCKI = 256f HI LO LO Both Input and Output Ports are in Slave mode HI LO HI Input Port is in Master mode with RCKI = 128f HI HI LO Input Port is in Master mode with RCKI = 512f HI HI HI Input Port is in Master mode with RCKI = 256f
s
s
s s
s s
Setup Guide
3-3
Selecting the Input & Output Data Formats
3.4 Selecting the Input & Output Data Formats
The SRC419x devices support a flexible set of audio data formats. Table 3–2 summarizes the input and output format options for the sample rate convert­ers. Section 3.5 of this chapter describes the format configuration for the digital audio receiver and transmitter devices.
When ~4193 is set to HI, the IFMT0, IFMT1 and IFMT2 elements of switch SW7 are used to select the input port data format. The OFMT0, OFMT1, OWL0, and OWL1 elements of switch SW10 are used to select the output port data format and word length.
When ~4193 is set to LO, Control Register 3 of the SRC4193 is used to select the input and output data formats.
Table 3–2.SRC419x Input & Output Port Data Format Configuration
IFMT2 IFMT1 IFMT0 Input Port Data Format
LO LO LO 24–Bit Left Justified LO LO HI 24–Bit I2S LO HI LO Unused LO HI HI Unused HI LO LO 16–Bit Right Justified HI LO HI 18–Bit Right Justified HI HI LO 20–Bit Right Justified HI
HI HI 24–Bit Right Justified
OFMT1 OFMT0 Output Port Data Format
LO LO Left Justified LO HI I2S HI HI
OWL1 OWL0 Output Port Data Word Length
LO LO 24–Bits LO HI 20–Bits
LO HI
TDM Right Justified
3-4
HI HI
LO HI
18–Bits 16–Bits
Selecting an Input Source and an Output Port
3.5 Selecting an Input Source and an Output Port
The ~IPORT element of switch SW9 is utilized to select the input source. When ~IPORT is set to LO, the buffered Audio Input Port at connector J1 is
selected as the input source. This port is designed to interface to devices that support Left Justified, Right Justified, and I
When selecting the Audio Input Port as the input source, the IS/~M element of switch SW7 must be set to match the mode of the SRC419x input port (Mas­ter or Slave), as described in Section 3.3 of this chapter. The data format of the external audio device must be set to match the format of the Audio Input Port.
When ~IPORT is set to HI, connector J2 at the input of the CS8414 digital audio receiver (U1) is selected as the input source. This port is designed to interface to digital audio signal generators and devices that output AES3 formatted digi­tal audio data. This includes the S/PDIF outputs of CD and DVD players.
When selecting the digital audio receiver (U1) as the input source, the IS/~M element of switch SW7 must be set to LO (Slave mode), and the SRC419x in­put port must be set to Slave mode, as described in Section 3.3 of this chapter. The output data format of the digital audio receiver must be selected using switch SW1 and jumper block J8. The receiver output format must match the input data format of the SRC419x device, as described in Section 3.4 of this chapter. Table 3–3 summarizes the configuration of switch SW1 and jumper block J8 for the supported data formats.
2
S formatted digital audio data.
Table 3–3.Digital Audio Receiver Output Data Format Configuration
M2 M1 M0 J8 Data Format
LO LO HI HI
The ~PORT element of switch SW10 is utilized to select the output port. When ~PORT is set to LO, the buffered Audio Output Port at connector J3 is
selected as the output port. This port is designed to interface to devices that support Left Justified, Right Justified, and I
When selecting the Audio Output Port as the output port, the OM/~S element of switch SW9 must be set to match the mode of the SRC419x output port (Master or Slave), as described in Section 3.3 of this chapter. The data format of the external audio device must be set to match the format of the Audio Out­put Port.
LO HI LO HI
LO LO HI LO
Short 3–4 (LJ) Short 1–2 (I2S/RJ) Short 1–2 (I2S/RJ) Short 1–2 (I2S/RJ)
2
S formatted digital audio data.
Left Justified, 16– to 24–Bits Philips I Right Justified, 16–Bits Right Justified, 18–Bits
2
S, 16– to 24–Bits
Setup Guide
3-5
Selecting an Input Source and an Output Port
When ~PORT = HI, the output of the DIT4192 digital audio transmitter (U5) at connector J4 is selected as the output port. This port is designed to interface to digital audio signal analyzers and devices that accept AES3 formatted digi­tal audio data. This includes the S/PDIF inputs of A/V receivers and digital re­cording devices.
When selecting the digital au dio transmitter (U5) as the output port, the setting of the OM/~S element of switch SW9 will correctly set the Master or Slave mode for both the SRC419x and DIT4192 devices. The input data format of the transmitter must be selected using the FMT0 and FMT1 elements of switch SW3. The format must match the output data format of the SRC419x device, as described in Section 3.4 of this chapter. Table 3–4 summarizes the trans­mitter format configuration options using switch SW3.
Table 3–4.Digital Audio Transmitter Input Data Format Configuration
FMT1 FMT0 Data Format
LO LO HI HI
LO HI LO HI
Left Justified, 16– to 24–Bits Philips I Right Justified, 24–Bits Right Justified, 16–Bits
2
S, 16– to 24–Bits
3-6
Selecting the SRC419x Reference Clock Source and Frequency
3.6 Selecting the SRC419x Reference Clock Source and Frequency
The ~PLL element of switch SW9 is used to select the reference clock source for the SRC419x. The reference clock input is utilized by the SRC419x rate es­timator, as well as the input or output port when configured in Master mode. The Master mode port derives the LRCK and BCK clock outputs from the refer­ence clock input.
When ~PLL is set to LO, the PLL1705 (U16) is selected as the reference clock source for the SRC419x. Table 3–5 summarizes the output rate selections for the PLL1705.
When ~PLL is set to HI, the EXT SRC CLK input (J6) is selected as the refer­ence clock input. The EXT SRC CLK input supports +3.3V CMOS external clock sources with frequencies up to 50MHz.
Table 3–5.PLL Reference Clock Selection for the SRC419x
SSR SFS2 SFS1 PLL Output Rate (MHz)
LO LO LO 12.288 LO LO HI 11.2896 LO HI LO 8.192 LO HI HI Reserved HI LO LO 24.576 HI LO HI 22.5792 HI HI LO 16.384 HI
HI HI Reserved
Setup Guide
3-7
Selecting the DIT4192 Master Clock Source and Frequency
3.7 Selecting the DIT4192 Master Clock Source and Frequency
The OM/~S element of switch SW9 and the ~TPLL element of SW6 are used to select the master clock source for the DIT4192 digital audio transmitter. The master clock (or MCLK) frequency determines the output frame (or sampling) rate of the transmitter, in addition to determining the SYNC and SCLK output rates when the DIT4192 is configured in Master mode. Table 3–6 summarizes the DIT4192 master clock source options.
When OM/~S is set to HI (that is, the SRC419x output port is the Master and the DIT4192 is a Slave), the reference clock source for the SRC419x will also be used as the master clock source for the DIT4192. This ensures synchro­nization between the SRC419x output port and DIT4192 audio serial port.
Table 3–6.DIT4192 Master Clock Selection
~TPLL OM/~S DIT4192 MCLK Source
LO LO PLL1705 (U6) HI LO EXT DIT CLK (J7) X
X = Don’t Care
HI SRC419x Ref Clock
When OM/~S is set to LO (that is, the SRC419x output port is a Slave and the DIT4192 is the Master), the ~TPLL element of switch SW6 is utilized to select the DIT4192 master clock source, as shown in Table 3–6.
When the PLL1705 (U6) is selected as the master clock source, the TSR, TFS1, and TFS2 elements of switch SW6 are utilized to select the PLL output rate. Table 3–7 summarizes the PLL output rate options.
Table 3–7.PLL Master Clock Source Selection for the DIT4192
TSR TFS2 TFS1 PLL Output Rate (MHz)
LO LO LO 12.288 LO LO HI 11.2896 LO HI LO 8.192 LO HI HI Reserved HI LO LO 24.576
3-8
HI LO HI 22.5792 HI HI LO 16.384 HI
HI HI Reserved
Selecting the DIT4192 Master Clock Source and Frequency
When the EXT DIT CLK input at connector J7 is selected as the master clock source, the device will support an external +3.3V CMOS logic level clock source with frequencies up to 25MHz.
In addition to DIT4192 master clock source selection, the DIT4192 master clock divider must be selected using the CLK0 and CLK1 elements of switch SW3. The master clock source frequency will be divided by the factor listed in Table 3–8 to determine the transmitter output frame rate, as well as the SYNC and SCLK clock rate when the DIT4192 is configured in Master mode.
Table 3–8.PLL Master Clock Selection for the DIT4192
CLK1 CLK0 DIT4192 MCLK Divider
LO LO Divide by 128 LO HI Divide by 256 HI LO Divide by 384 HI
HI Divide by 512
Setup Guide
3-9
Miscellaneous Functions
3.8 Miscellaneous Functions
This section provides information regarding several SRC419x and DIT4192 functions not described previously in this chapter.
Low group delay operation is controlled using the LGRP element of switch SW7, or by the LGRP bit in Control Register 2 when using the SRC4193. The low group delay option reduces the overall latency of the interpolation filter by 32/f
, where f
sIN
rizes Low Group Delay operation.
Table 3–9.Low Group Delay Configuration
is the input sampling rate in hertz (Hz). Table 3–9 summa-
sIN
LGRP Low Group Delay Mode
LO Disabled HI Enabled
Bypass mode operation is controlled using the BYPAS element of switch SW7, or by the BYPAS bit in Control Register 1 when using the SRC4193. When By­pass mode is enabled, the audio data is passed directly from the input port to the output port without sample rate conversion. This process is useful for pass­ing through encoded audio or non–audio data. In Bypass mode, the mute, dith­ering, and digital attenuation (SRC4193 only) functions are not available. Table 3–10 summarizes Bypass mode operation.
Table 3–10.Bypass Mode Configuration
BYPAS Bypass Mode
LO Disabled HI Enabled
3-10
The Mute function is controlled using the MUTE element of switch SW7, or by the MUTE bit of Control Register 1 when using the SRC4193. This function employs a soft mute technique, which provides for artifact–free muting of the SRC419x output port. Table 3–11 summarizes Mute function operation.
Table 3–11.Mute Function Configuration
MUTE Soft Mute Function
LO Disabled HI Enabled
A Direct Down–Sampling option is available only when using the SRC4193. It is accessed using the DFLT bit in Control Register 2. Refer to the SRC4192/4193 data sheet for more details regarding the use of this mode.
The DIT4192 digital audio transmitter supports Single Channel Double Fre­quency operation, also referred to as Mono mode in the DIT4192 data sheet. In this mode, the DIT4192 output frame rate is one half the input SYNC clock rate, with two consecutive samples of a single channel replacing the Left and Right channel samples of the normal Stereo mode transmission. This mode is useful when testing 176.4kHz and 192kHz sampling rates on an Audio Preci­sion System T wo Cascade/Cascade Plus Dual Domain system, configured in Dual Channel mode. Only one channel at a time may be tested in this fashion.
Miscellaneous Functions
The MONO and MDA T elements of switch SW9 are utilized to configure Mono mode operation. Table 3–12 summarizes the MONO and MDAT options.
Table 3–12.DIT4192 Mono Mode Configuration
Mono Stereo/Mono Mode Operation
LO Stereo HI Mono
MDAT Audio/Channel Status Data Selection
LO Left Channel Audio Data / Channel A
CS Data
HI Right Channel Audio Data / Channel B
CS Data
Setup Guide
3-11
Reset Functions
3.9 Reset Functions
The SRC4192EVM includes three reset switches, one each for the SRC419x (SW8), the CS8414 receiver (SW2), and the DIT4192 transmitter (SW4). Each switch is a momentary contact, normally open push–button with 10k pull–up resistors to the +3.3V supply. To reset a device, momentarily press, then re­lease, the corresponding reset switch. This allows the user to reset the devices at will, if necessary or desired.
3-12
Chapter 4
  !   " #
This chapter provides the electrical and physical layout information for the SRC4192EVM. The bill of materials is included for component and manufacturer reference.
The schematic diagram is shown, beginning on page 4-2. The printed cir­cuit board layouts are shown on pages 4-4 through 4-6. The bill of materi­als is shown starting on page 4-7.
Topic Page
4.1 Schematic 4-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 PCB Layout 4-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.3 Bill of Materials 4-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Schematic, PCB Layout and Bill of Materials
4-1
Schematic
4.1 Schematic
The complete electrical schematics of for the SRC4192EVM are shown in Figure 4–1 and Figure 4–2.
Figure 4–1.SRC4192EVM Schematic Diagram (page 1 of 2)
4-2
Figure 4–2.SRC4192EVM Schematic Diagram (page 2 of 2)
Schematic
Schematic, PCB Layout and Bill of Materials
4-3
Component Layout
4.2 Component Layout
The printed circuit board plots for the SRC4192EVM are shown in Figure 4–3 through Figure 4–5. The PCB is a two–layer board, with most components mounted on the top (or component) side. The power supply bypass capacitors for U15 are mounted on the bottom (or solder) side of the PCB.
Figure 4–3.PCB Silkscreen, Top Layer
4-4
Figure 4–4.Top Side Layout (Component Side)
Component Layout
Schematic, PCB Layout and Bill of Materials
4-5
Component Layout
Figure 4–5.Bottom Side Layout (Solder Side)
4-6
Bill of Materials
Size = 0805
ECJ–2VC1H180J Chip Capacitor, Ceramic NPO/C0G, 18pF +/– 5%, 50WV,
ECJ–2YB1H683K Chip Capacitor, Ceramic X7R, 68000pF +/–10%, 50WV,
Size = 0805
Size = 0805
Size = 0805
Size = 1206
Size = 1210
Green LED, SMT, Size = 1206
P75AACT–ND Resistor, 75 ohms, +/– 1%, 1/4W, Thick Film Chip,
P47.5FCT–ND Resistor, 47.5 ohms, +/– 1%, 1/8W, Thick Film Chip,
(DK# 67–1357–1–ND)
Size = 0805
Size = 1210
P470CCT–ND Resistor, 470 ohms, +/– 1%, 1/10W, Thick Film Chip,
P150AACT–ND Resistor, 150 ohms, +/– 1%, 1/4W, Thick Film Chip,
Manufacturer Mfg Part Number Description
Qty
Per Bd
C45–C48 4 Panasonic
Designator
1 18pF
Item Value Reference
4.3 Bill of Materials
Table 4–1.Bill of Materials
or equivalent
or equivalent
C52 1 Panasonic
pF
2 68000
3 0.01µF C53, C54 2 Kemet C0805C103K5RACTU Chip Capacitor, Ceramic X7R, 0.01µF +/–10%, 50WV,
4 0.1µF C1—C36 36 Kemet C0805C104K5RACTU Chip Capacitor, Ceramic X7R, 0.1µF +/–10%, 50WV,
5 4.7µF C37—C43 7 Kemet T491A475K010AS Chip Capacitor, Tantalum, 4.7µF +/–10%, 10WV, Size = A
6 22µF C44 1 Kemet T491C226K010AS Chip Capacitor, Tantalum, 22µF +/–10%, 10WV, Size = C
7 J2, J4, J6, J7 4 Kings Electronics KC–79–274–M06 BNC Connector, Female, PC Mount
8 J1, J3, J5 3 Samtec TSW–105–07–G–D Terminal Strip, 10–pin (5x2)
9 J8 1 Samtec TSW–102–07–G–D Terminal Strip, 4–pin (2x2)
11 JMP1 1 Samtec TSW–102–07–G–S Terminal Strip, 2–pin (2x1)
10 J9 1 Weidmuller 1699670000 Terminal Block, 3.5mm PCB, 2 poles
12 LED1 1 LUMEX SML–LX1206GC–TR
or equivalent
or equivalent
13 47.5 R1—R14 14 Panasonic
14 75 R15—R17 3 Panasonic
15 150 R22, R23 2 Panasonic
SRC4192EVM
or equivalent
or equivalent
16 470 R24, R25 2 Panasonic
4-7
(continued on next page)
Bill of Materials
Size = 0805
6 terminal, 5 element
10 terminal, 9 element
P10KCCT–ND Resistor, 10K ohms, +/– 1%, 1/10W, Thick Film Chip,
Manufacturer Mfg Part Number Description
Qty
or equivalent
Per Bd
Designator
SC937–02 SMT Transformer for Digital Interface Receiver
SC979–03 SMT Transformer for Digital Interface Transmitter
Conversion
Conversion
Item Value Reference
Table 4–1.Bill of Materials (continued)
4-8
17 10K R18—R21 4 Panasonic
18 10K RN1, RN2, RN4 3 Bourns 4606X–101–103 Resistor Network, Single–In–Line, ThruHole Bussed,
SRC4192EVM
19 10K RN5—RN7 3 Bourns 4310R–101–103 Resistor Network, Single–In–Line, ThruHole Bussed,
20 SW1, SW3, SW6 3 Grayhill 90HBW04P DIP Switch, SMT Gull Leaded Sealed, 4 position
21 SW7, SW9, SW10 3 Grayhill 90HBW08P DIP Switch, SMT Gull Leaded Sealed, 8 position
22 SW2, SW4, SW8 3 OMRON B3S–1000 Momentary Tact Switch, SMT w/o Ground Terminal
23 T1 1 Scientific
24 T2 1 Scientific
25 U1 1 Cirrus Logic CS8414–CS Digital Audio Receiver
26 U2 1 Texas Instruments SN74AHC1G04DBV Single Inverter
27 U3 1 Texas Instruments SN74AHC32PW Quadruple 2–Input OR Gate
28 U4 1 Texas Instruments SN74AHC1G14DBV Single Schmitt Trigger Inverter
29 U5 1 Texas Instruments DIT4192IPW Digital Audio Interface Transmitter
30 U6, U16 2 Texas Instruments PLL1705DBQ Dual PLL Multiclock Generator
31 U7, U14 2 Texas Instruments SN74ALVC125PW Quad Buffer w/ Tri–State Outputs
32 U8, U13 2 Texas Instruments SN74LVC04APW Hex Inverter
33 U9, U18, U21 3 Texas Instruments SN74ALVC244PW Octal Buffer/Driver
34 U10, U17, U20 3 Texas Instruments SN74ALVC245PW Octal Bus Transceiver
35 U1 1, U19 2 Texas Instruments SN74CBTLV3245APW Octal Bus Switch
36 U12 1 Texas Instruments SN74LVC1G07DBV Single Buffer w/ Open Drain Output
(continued on next page)
Bill of Materials
Manufacturer Mfg Part Number Description
Qty
Per Bd
Designator
Item Value Reference
Table 4–1.Bill of Materials (continued)
37 U15 (DUT) 1 Texas Instruments SRC4192IDB Asynchronous Sample Rate Converter
38 U22 1 Texas Instruments REG1117–3.3 Voltage Regulator, +3.3V
39 U23 1 Texas Instruments SN74AHC244PW Octal Buffer/Driver
40 X1, X2 2 Citizen HCM49–27.000MABJT Quartz Crystal, SMT, 27MHz, +/– 50ppm
41 1 Enplas–Tesco OTS–28(34)–0.65–01 ZIF Socket for SSOP–28, Pinch (2–contact) type
42 4 3M Bumpon SJ–5003 Rubber Feet, Adhesive Backed
43 2 Samtec SNT–100–BK–G–H Shorting Blocks
SRC4192EVM
4-9
Loading...
