SN74LVC541
OCTAL BUFFER/DRIVER
WITH 3-STATE OUTPUTS
SCAS298B – JANUARY 1993 – REVISED JUL Y 1995
D
EPIC
(Enhanced-Performance Implanted
CMOS) Submicron Process
D
Typical V
< 0.8 V at V
D
Typical V
(Output Ground Bounce)
OLP
= 3.3 V, TA = 25°C
CC
(Output VOH Undershoot)
OHV
> 2 V at VCC = 3.3 V, TA = 25°C
D
Latch-Up Performance Exceeds 250 mA
Per JEDEC Standard JESD-17
D
Package Options Include Plastic
Small-Outline (DW), Shrink Small-Outline
(DB), and Thin Shrink Small-Outline (PW)
Packages
DB, DW, OR PW PACKAGE
(TOP VIEW)
OE1
A1
A2
A3
A4
A5
A6
A7
A8
GND
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
V
CC
OE2
Y1
Y2
Y3
Y4
Y5
Y6
Y7
Y8
description
This octal buffer/driver is designed for 2.7-V to 3.6-V VCC operation.
The SN74LVC541 is ideal for driving bus lines or buffering memory address registers. The device features
inputs and outputs on opposite sides of the package to facilitate printed-circuit-board layout.
The 3-state control gate is a 2-input AND gate with active-low inputs so that if either output enable (OE1 or OE2)
input is high, all eight outputs are in the high-impedance state.
T o ensure the high-impedance state during power up or power down, OE
resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.
should be tied to VCC through a pullup
The SN74LVC541 is characterized for operation from –40°C to 85°C.
FUNCTION TABLE
INPUTS
OE1 OE2 A
L L L L
L LH H
H XX Z
X H X Z
OUTPUT
Y
Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.
EPIC is a trademark of Texas Instruments Incorporated.
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas Instruments
standard warranty. Production processing does not necessarily include
testing of all parameters.
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
Copyright 1995, Texas Instruments Incorporated
1
SN74LVC541
OCTAL BUFFER/DRIVER
WITH 3-STATE OUTPUTS
SCAS298B – JANUARY 1993 – REVISED JUL Y 1995
1
19
2
3
4
5
6
7
8
9
†
&
EN
1
18
17
16
15
14
13
12
11
logic diagram (positive logic)
1
OE1
19
OE2
2
Y1
Y2
Y3
Y4
Y5
Y6
Y7
Y8
A1
18
Y1
To Seven Other Channels
logic symbol
OE1
OE2
A1
A2
A3
A4
A5
A6
A7
A8
†
This symbol is in accordance with ANSI/IEEE Std 91-1984
and IEC Publication 617-12.
absolute maximum ratings over operating free-air temperature range (unless otherwise noted)
Supply voltage range, VCC –0.5 V to 4.6 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input voltage range, VI (see Note 1) –0.5 V to 6.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output voltage range, V
Input clamp current, IIK (VI < 0) –50 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output clamp current, IOK (VO < 0 or VO > VCC) ±50 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Continuous output current, IO (VO = 0 to VCC) ±50 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Continuous current through VCC or GND ±100 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum power dissipation at T
Storage temperature range, T
‡
Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
NOTES: 1. The input and output negative-voltage ratings may be exceeded if the input and output clamp-current ratings are observed.
2. This value is limited to 4.6 V maximum.
3. The maximum package power dissipation is calculated using a junction temperature of 150°C and a board trace length of 750 mils.
For more information, refer to the
Data Book
, literature number SCBD002B.
(see Notes 1 and 2) –0.5 V to VCC + 0.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
O
= 55°C (in still air) (see Note 3): DB package 0.6 W. . . . . . . . . . . . . . . . .
A
DW package 1.6 W. . . . . . . . . . . . . . . . .
PW package 0.7 W. . . . . . . . . . . . . . . . .
–65°C to 150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
stg
Package Thermal Considerations
application note in the 1994
ABT Advanced BiCMOS T echnology
‡
2
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
