SN54F157A, SN74F157A
QUADRUPLE 2-LINE TO 1-LINE DATA SELECTORS/MULTIPLEXERS
SDFS053A – MARCH 1987 – REVISED OCTOBER 1993
Copyright 1993, Texas Instruments Incorporated
2–1
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
• Buffered Inputs and Outputs
• Package Options Include Plastic
Small-Outline Packages, Ceramic Chip
Carriers, and Standard Plastic and Ceramic
300-mil DIPs
description
The ′F157A is a quadruple 2-input data
selector/multiplexer featuring a common strobe
(G
) input. When the strobe is high, all outputs are
low. When the strobe is low, a 4-bit word is
selected from one of two sources and is routed to
the four outputs. The ′F157A provides true data.
The SN54F157A is characterized for operation
over the full military temperature range of –55°C
to 125°C. The SN74F157A is characterized for
operation from 0°C to 70°C.
FUNCTION TABLE
INPUTS
OUTPUT
G A/B A B
Y
H X X X L
L LLX L
LLHX H
LHXL L
LHXH H
SN54F157A ...J PACKAGE
SN74F157A ...D OR N PACKAGE
(TOP VIEW)
3212019
910111213
4
5
6
7
8
18
17
16
15
14
4A
4B
NC
4Y
3A
1B
1Y
NC
2A
2B
SN54F157A . . . FK PACKAGE
(TOP VIEW)
1A
A/B
NC
3Y
3B
G
2Y
GND
NC
NC – No internal connection
V
CC
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
A/B
1A
1B
1Y
2A
2B
2Y
GND
V
CC
G
4A
4B
4Y
3A
3B
3Y
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas Instruments
standard warranty. Production processing does not necessarily include
testing of all parameters.
SN54F157A, SN74F157A
QUADRUPLE 2-LINE TO 1-LINE DATA SELECTORS/MULTIPLEXERS
SDFS053A – MARCH 1987 – REVISED OCT OBER 1993
2–2
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
logic symbol
†
logic diagram (positive logic)
G
MUX
2
1A
1
3
1B
EN
15
G1
1
1Y
4
5
2A
6
2B
2Y
7
11
3A
10
3B
3Y
9
14
4A
13
4B
4Y
12
A/B
4Y
3Y
2Y
1Y
12
9
7
4
A
/B
G
4B
4A
3B
3A
2B
2A
1B
1A
1
15
13
14
10
11
6
5
3
2
†
This symbol is in accordance with ANSI/IEEE Std 91-1984 and
IEC Publication 617-12.
1
Pin numbers shown are for the D, J, and N packages.
absolute maximum ratings over operating free-air temperature range (unless otherwise noted)
‡
Supply voltage range, V
CC
–0.5 V to 7 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input voltage range (see Note 1) –1.2 V to 7 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input current range –30 mA to 5 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Voltage range applied to any output in the high state –0.5 V to V
CC
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Current into any output in the low state 40 mA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating free-air temperature range: SN54F157A –55°C to 125°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SN74F157A 0°C to 70°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage temperature range –65°C to 150°C. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
‡
Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. These are stress ratings only and
functional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
NOTE 1: The input voltage rating may be exceeded provided that the input current rating is observed.
recommended operating conditions
SN54F157A SN74F157A
MIN NOM MAX MIN NOM MAX
UNIT
V
CC
Supply voltage 4.5 5 5.5 4.5 5 5.5 V
V
IH
High-level input voltage 2 2 V
V
IL
Low-level input voltage 0.8 0.8 V
I
IK
Input clamp current –18 –18 mA
I
OH
High-level output current –1 –1 mA
I
OL
Low-level output current 20 20 mA
T
A
Operating free-air temperature –55 125 0 70 °C
SN54F157A, SN74F157A
QUADRUPLE 2-LINE TO 1-LINE DATA SELECTORS/MULTIPLEXERS
SDFS053A – MARCH 1987 – REVISED OCTOBER 1993
2–3
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
electrical characteristics over recommended operating free-air temperature range (unless
otherwise noted)
SN54F157A SN74F157A
PARAMETER
TEST CONDITIONS
MIN TYP†MAX MIN TYP†MAX
UNIT
V
IK
VCC = 4.5 V, II = –18 mA –1.2 –1.2 V
VCC = 4.5 V, IOH = – 1 mA 2.5 3.4 2.5 3.4
V
OH
VCC = 4.75 V , IOH = – 1 mA 2.7
V
V
OL
VCC = 4.5 V, IOL = 20 mA 0.3 0.5 0.3 0.5 V
I
I
VCC = 5.5 V, VI = 7 V 0.1 0.1 mA
I
IH
VCC = 5.5 V, VI = 2.7 V 20 20 µA
I
IL
VCC = 5.5 V, VI = 0.5 V – 0.6 – 0.6 mA
I
OS
‡
VCC = 5.5 V, VO = 0 –60 –150 –60 –150 mA
I
CC
VCC = 5.5 V, VI = 4.5 V 15 23 15.5 23 mA
†
All typical values are at VCC = 5 V, TA = 25°C.
‡
Not more than one output should be shorted at a time, and the duration of the short circuit should not exceed one second.
switching characteristics (see Note 2)
PARAMETER
FROM
(INPUT)
TO
(OUTPUT)
VCC = 5 V,
CL = 50 pF,
RL = 500 Ω,
TA = 25°C
VCC = 4.5 V to 5.5 V,
CL = 50 pF,
RL = 500Ω,
TA = MIN to MAX
§
UNIT
()
()
′F157A SN54F157A SN74F157A
MIN TYP MAX MIN MAX MIN MAX
t
PLH
3.2 6.6 10 3.2 12 3.2 11
t
PHL
A/B
Y
2.2 4.6 7 2.2 9 2.2 8
ns
t
PLH
4.2 6.6 9.5 4.2 13 4.2 11
t
PHL
G
Y
1.7 4.1 6.5 1.7 7.5 1.7 7
ns
t
PLH
1.7 4.1 6 1.7 7.5 1.7 6.5
t
PHL
A or B
Y
1.7 3.6 5.5 1 7.5 1.2 7
ns
§
For conditions shown as MIN or MAX, use the appropriate value specified under recommended operating conditions.
NOTE 2: Load circuits and voltage waveforms are shown in Section 1.
