SN5410, SN54LS10, SN54S10,
SN7410, SN74LS10, SN74S10
TRIPLE 3-INPUT POSITIVE-NAND GATES
SDLS035A – DECEMBER 1983 – REVISED APRIL 2003
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas Instruments
standard warranty. Production processing does not necessarily include
testing of all parameters.
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
Copyright 2003, Texas Instruments Incorporated
1
SN5410, SN54LS10, SN54S10,
SN7410, SN74LS10, SN74S10
TRIPLE 3-INPUT POSITIVE-NAND GATES
SDLS035A – DECEMBER 1983 – REVISED APRIL 2003
2
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
SN5410, SN7410,
TRIPLE 3-INPUT POSITIVE-NAND GATES
SDLS035 – DECEMBER 1983 – REVISED MARCH 1988
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
3
SN54LS10, SN74LS10,
TRIPLE 3-INPUT POSITIVE-NAND GATES
SDLS035 – DECEMBER 1983 – REVISED MARCH 1988
4
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
SN54S10, SN74S10,
TRIPLE 3-INPUT POSITIVE-NAND GATES
SDLS035 – DECEMBER 1983 – REVISED MARCH 1988
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
5
PACKAGE OPTION ADDENDUM
www.ti.com
28-Feb-2005
PACKAGING INFORMATION
Orderable Device Status
JM38510/00103BCA OBSOLETE CDIP J 14 None Call TI Call TI
JM38510/00103BDA OBSOLETE CFP W 14 None Call TI Call TI
JM38510/07005BCA ACTIVE CDIP J 14 1 None Call TI Level-NC-NC-NC
JM38510/07005BDA ACTIVE CFP W 14 1 None Call TI Level-NC-NC-NC
JM38510/30005B2A ACTIVE LCCC FK 20 1 None CallTI Level-NC-NC-NC
JM38510/30005BCA ACTIVE CDIP J 14 1 None Call TI Level-NC-NC-NC
JM38510/30005BDA ACTIVE CFP W 14 1 None Call TI Level-NC-NC-NC
JM38510/30005SCA ACTIVE CDIP J 14 1 None Call TI Level-NC-NC-NC
JM38510/30005SDA ACTIVE CFP W 14 1 None Call TI Level-NC-NC-NC
SN5410J OBSOLETE CDIP J 14 None Call TI Call TI
SN54LS10J ACTIVE CDIP J 14 1 None Call TI Level-NC-NC-NC
SN54S10J ACTIVE CDIP J 14 1 None Call TI Level-NC-NC-NC
SN7410N ACTIVE PDIP N 14 25 Pb-Free
SN7410N3 OBSOLETE PDIP N 14 None Call TI Call TI
SN74LS10D ACTIVE SOIC D 14 50 Pb-Free
SN74LS10DR ACTIVE SOIC D 14 2500 Pb-Free
SN74LS10N ACTIVE PDIP N 14 25 Pb-Free
SN74LS10N3 OBSOLETE PDIP N 14 None Call TI Call TI
SN74LS10NSR ACTIVE SO NS 14 2000 Pb-Free
SN74S10D ACTIVE SOIC D 14 50 Pb-Free
SN74S10N ACTIVE PDIP N 14 25 Pb-Free
SN74S10N3 OBSOLETE PDIP N 14 None Call TI Call TI
SN74S10NSR ACTIVE SO NS 14 2000 Pb-Free
SNJ5410J OBSOLETE CDIP J 14 None Call TI Call TI
SNJ5410W OBSOLETE CFP W 14 None Call TI Call TI
SNJ5410WA OBSOLETE CFP WA 14 None Call TI Call TI
SNJ54LS10FK ACTIVE LCCC FK 20 1 None Call TI Level-NC-NC-NC
SNJ54LS10J ACTIVE CDIP J 14 1 None Call TI Level-NC-NC-NC
SNJ54LS10W ACTIVE CFP W 14 1 None Call TI Level-NC-NC-NC
SNJ54S10FK ACTIVE LCCC FK 20 1 None Call TI Level-NC-NC-NC
SNJ54S10J ACTIVE CDIP J 14 1 None Call TI Level-NC-NC-NC
SNJ54S10W ACTIVE CFP W 14 1 None Call TI Level-NC-NC-NC
(1)
The marketing status values are defined as follows:
ACTIVE: Product device recommended for new designs.
LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect.
NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in
a new design.
(1)
Package
Type
Package
Drawing
Pins Package
Qty
Eco Plan
(RoHS)
(RoHS)
(RoHS)
(RoHS)
(RoHS)
(RoHS)
(RoHS)
(RoHS)
(2)
Lead/Ball Finish MSL Peak Temp
CU NIPDAU Level-NC-NC-NC
CU NIPDAU Level-2-260C-1 YEAR/
CU NIPDAU Level-2-260C-1 YEAR/
CU NIPDAU Level-NC-NC-NC
CU NIPDAU Level-2-260C-1 YEAR/
CU NIPDAU Level-2-260C-1 YEAR/
CU NIPDAU Level-NC-NC-NC
CU NIPDAU Level-2-260C-1 YEAR/
Level-1-235C-UNLIM
Level-1-235C-UNLIM
Level-1-235C-UNLIM
Level-1-235C-UNLIM
Level-1-235C-UNLIM
(3)
Addendum-Page 1
PACKAGE OPTION ADDENDUM
www.ti.com
PREVIEW: Device has been announced but is not in production. Samples may or may not be available.
OBSOLETE: TI has discontinued the production of the device.
(2)
Eco Plan - May not be currently available - please check http://www.ti.com/productcontent for the latest availability information and additional
product content details.
None: Not yet available Lead (Pb-Free).
Pb-Free (RoHS): TI's terms "Lead-Free" or "Pb-Free" mean semiconductor products that are compatible with the current RoHS requirements
for all 6 substances, including the requirement that lead not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered
at high temperatures, TI Pb-Free products are suitable for use in specified lead-free processes.
Green (RoHS & no Sb/Br): TI defines "Green" to mean "Pb-Free" and in addition, uses package materials that do not contain halogens,
including bromine (Br) or antimony (Sb) above 0.1% of total product weight.
(3)
MSL, Peak Temp. -- The Moisture Sensitivity Level rating according to the JEDECindustry standard classifications, and peak solder
temperature.
Important Information and Disclaimer:The information provided on this page represents TI's knowledge and belief as of the date that it is
provided. TI bases its knowledge and belief on information provided by third parties, and makes no representation or warranty as to the
accuracy of such information. Efforts are underway to better integrate information from third parties. TI has taken and continues to take
reasonable steps to provide representative and accurate information but may not have conducted destructive testing or chemical analysis on
incoming materials and chemicals. TI and TI suppliers consider certain information to be proprietary, and thus CAS numbers and other limited
information may not be available for release.
In no event shall TI's liability arising out of such information exceed the total purchase price of the TI part(s) at issue in this document sold by TI
to Customer on an annual basis.
28-Feb-2005
Addendum-Page 2
MECHANICAL DATA
MLCC006B – OCTOBER 1996
FK (S-CQCC-N**) LEADLESS CERAMIC CHIP CARRIER
28 TERMINAL SHOWN
A SQ
B SQ
19
20
21
22
23
24
25
12826 27
12
1314151618 17
0.020 (0,51)
0.010 (0,25)
MIN
0.342
(8,69)
0.442
0.640
0.739
0.938
1.141
A
0.358
(9,09)
0.458
(11,63)
0.660
(16,76)
0.761
(19,32)(18,78)
0.962
(24,43)
1.165
(29,59)
NO. OF
TERMINALS
**
11
10
9
8
7
6
5
432
20
28
44
52
68
84
0.020 (0,51)
0.010 (0,25)
(11,23)
(16,26)
(23,83)
(28,99)
MINMAX
0.307
(7,80)
0.406
(10,31)
0.495
(12,58)
0.495
(12,58)
0.850
(21,6)
1.047
(26,6)
0.080 (2,03)
0.064 (1,63)
B
MAX
0.358
(9,09)
0.458
(11,63)
0.560
(14,22)
0.560
(14,22)
0.858
(21,8)
1.063
(27,0)
0.055 (1,40)
0.045 (1,14)
0.028 (0,71)
0.022 (0,54)
0.050 (1,27)
NOTES: A. All linear dimensions are in inches (millimeters).
B. This drawing is subject to change without notice.
C. This package can be hermetically sealed with a metal lid.
D. The terminals are gold plated.
E. Falls within JEDEC MS-004
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
0.045 (1,14)
0.035 (0,89)
0.045 (1,14)
0.035 (0,89)
4040140/D 10/96
