Texas Instruments PCI1251BGFN, PCI1251BGJG Datasheet

(PCI) Power Management 1.0 Compliant

ACPI 1.0 Compliant

Packaged in GFN 256-Pin BGA or GJG MicroStar BGA

PCI Local Bus Specification Revision 2.2 Compliant

1997 PC Card Standard Compliant

PC 99 Compliant

3.3-V Core Logic With Universal PCI Interfaces Compatible With 3.3-V and 5-V PCI Signaling Environments

Mix-and-Match 5-V/3.3-V PC Card16 Cards and 3.3-V CardBus Cards

Supports Two PC Card or CardBus Slots With Hot Insertion and Removal

Uses Serial Interface to TI TPS2206 Dual Power Switch

Supports Burst Transfers to Maximize Data Throughput on the PCI Bus and the CardBus Bus

Supports Serialized Interrupt Request (IRQ) With PCI Interrupts

8-Way Legacy IRQ Multiplexing

System Interrupts Can Be Programmed as PCI Style or Industry Standard Architecture (ISA-IRQ) Style

ISA-IRQ Interrupts Can Be Serialized Onto a Single IRQ Serial (IRQSER) Pin

EEPROM Interface for Loading Subsystem ID and Subsystem Vendor ID

PCI1251B GFN/GJG

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

Pipelined Architecture Allows Greater Than 130M-Bytes-Per-Second Throughput From CardBus to PCI and From PCI to CardBus

Supports Zoomed Video With Internal Buffering

Four General Purpose I/Os

Multifunction PCI Device With Separate Configuration Space for Each Socket

Five PCI Memory Windows and T wo I/O Windows Available for Each PC Card16 Socket

Two I/O Windows and Two Memory Windows Available to Each CardBus Socket

Exchangeable Card Architecture (ExCA) Compatible Registers Are Mappable in Memory and I/O Space

Supports Distributed DMA (DDMA) and PC/PCI DMA

Intel 82365SL-DF Register Compatible

Supports 16-Bit DMA on Both PC Card Sockets

Supports Ring Indicate, SUSPEND, PCI CLKRUN, and CardBus CCLKRUN

Advanced Submicron, Low-Power CMOS T echnology

Provides VGA/Palette Memory and I/O and Subtractive Decoding Options

LED Activity Pins

Supports PCI Bus Lock (LOCK)

Table of Contents

Description 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

System Block Diagram 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Signal Name/Terminal Number Sort Tables 4. . . . . . . . . . . . . . . . .

Terminal Functions 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power Supply Sequencing 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

I/O Characteristics 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Clamping Voltages 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PCI Interface 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PC Card Applications 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Programmable Interrupt Subsystem 32. . . . . . . . . . . . . . . . . . . . . .

Power Management Overview 36. . . . . . . . . . . . . . . . . . . . . . . . . .

PC Card Controller Programming Model 40. . . . . . . . . . . . . . . . . .

PCI Configuration Registers (Functions 0 and 1) 40. . . . . . . . . . .

ExCA Compatibility Registers (Functions 0 and 1) 76. . . . . . . . .

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

Intel is a trademark of Intel Corporation. PC Card is a trademark of Personal Computer Memory Card International Association (PCMCIA). TI is a trademark of Texas Instruments Incorporated.

PRODUCTION DATA information is current as of publication date. Products conform to specifications per the terms of Texas Instruments standard warranty. Production processing does not necessarily include testing of all parameters.

CardBus Socket Registers (Functions 0 and 1) 100. . . . . . . . . . . . . .

Distributed DMA (DDMA) Registers 108. . . . . . . . . . . . . . . . . . . . . . . .

Absolute Maximum Ratings 114. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Recommended Operating Conditions 115. . . . . . . . . . . . . . . . . . . . . .

Electrical Characteristics 116. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

PCI Clock/Reset Timing Requirements 117. . . . . . . . . . . . . . . . . . . . .

PCI Timing Requirements 117. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Parameter Measurement Information 118. . . . . . . . . . . . . . . . . . . . . . .

PCI Bus Parameter Measurement Information 119. . . . . . . . . . . . . . .

PC Card Cycle Timing 120. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Timing Requirements, (Memory Cycles) 121. . . . . . . . . . . . . . . . . . . .

Timing Requirements, (I/O Cycles) 121. . . . . . . . . . . . . . . . . . . . . . . . .

Switching Characteristics (Miscellaneous) 122. . . . . . . . . . . . . . . . . .

PC Card Parameter Measurement Information 122. . . . . . . . . . . . . . .

Mechanical Data 124. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

description

The TI PCI1251B is a high-performance PC Card controller with a 32-bit PCI interface. The device supports two independent PC Card sockets compliant with the 1997 PC Card Standard. The PCI1251B provides features that make it the best choice for bridging between PCI and PC Cards in both notebook and desktop computers. The 1997 PC Card Standard retains the 16-bit PC Card specification defined in PCMCIA Release 2.2, and defines the new 32-bit PC Card, CardBus, capable of full 32-bit data transfers at 33 MHz. The PCI1251B supports any combination of 16-bit and CardBus PC Cards in the two sockets, powered at 5 V or 3.3 V, as required.

The PCI1251B is compliant with the latest the PCI Local Bus Specification 2.2, and its PCI interface can act as either a PCI master device or a PCI slave device. The PCI bus mastering is initiated during 16-bit PC Card direct memory access (DMA) transfers or CardBus PC Card bridging transactions.

Multiple system-interrupt signaling options are provided and they include:

Parallel PCI interrupts

Parallel ISA interrupts

Serialized ISA interrupts

Serialized ISA and PCI interrupts

Additionally, general-purpose inputs and outputs are provided for the board designer to implement sideband functions.

All card signals are internally buffered to allow hot insertion and removal without external buffering. The PCI1251B is register compatible with the Intel 82365SL-DF ExCA controller . The PCI1251B internal data path logic allows the host to access 8-, 16-, and 32-bit cards using full 32-bit PCI cycles for maximum performance. Independent buffering and a pipeline architecture provide an unsurpassed performance level with sustained bursting. The PCI1251B can also be programmed to accept fast posted writes to improve system-bus utilization.

The PCI1251B provides an internally buffered zoomed video (ZV) path. This reduces the design effort of PC board manufacturers to add a ZV-compatible solution and guarantees compliance with the CardBus loading specifications. Many other features, such as socket activity light-emitting diode (LED) outputs, are designed into the PCI1251B. These features are discussed in detail throughout the design specification.

An advanced complementary metal-oxide semiconductor (CMOS) process is used to achieve low system-power consumption while operating at PCI clock rates up to 33 MHz. Several low-power modes enable the host power management system to further reduce power consumption.

PCI Bus Power Management Specification

. It is also compliant with

Unused PCI1251B inputs must be pulled up using a 43 kW resistor.

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

system block diagram

A simplified system block diagram using the PCI1251B is provided below. The zoomed video (ZV) capability can be used to route the ZV data directly to the VGA controller.

The PCI interface includes all address/data and control signals for PCI protocol. The 68-pin PC Card interface includes all address/data and control signals for CardBus and 16-bit (R2) protocols. When zoomed video (ZV) is enabled (in 16-bit PC Card mode), 23 of the 68 signals are redefined to support the ZV protocol.

The interrupt interface includes terminals for parallel PCI, parallel ISA, and serialized PCI and ISA signaling. The ring indicate terminal is included in the interrupt interface because its function is to perform system wake up on incoming PC Card modem rings. Other miscellaneous system interface terminals available on the PCI1251B include:

Programmable general purpose multifunction terminals

SUSPEND, RI_OUT/PME (power management control signal)

SPKROUT

PCI Bus

Activity LED’s

CLKRUN

TPS2206

Power

Switch

PC Card

Socket A

PC Card

Socket B

NOTE: The PC Card interface is 68 pins for CardBus and 16-bit PC Cards. In zoomed-video

mode, 23 pins are used for routing the zoomed video signals to the VGA controller.

23 for ZV

(See Note)

23 for ZV

PCI1251B

Enable

IRQSER

†

DMA PME

Zoomed Video

South Bridge

19 Video

4 Audio

†

Interrupt Routing Options:

1) Serialized, including PCI and ISA

2) Serialized ISA and parallel PCI

3) Parallel PCI and parallel ISA

4) Parallel PCI interrupts only

Embedded

Controller

VGA

Controller

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

signal names and terminal assignments

Signal names and their terminal assignments are shown in Tables 1 through 4 sorted alphanumerically by the assigned terminal.

Table 1. GFN Terminals Sorted Alphanumerically for CardBus and 16-Bit Signals

GFN SIGNAL NAME GFN SIGNAL NAME GFN SIGNAL NAME

A1 A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12 A13 A14 A15 A16 A17 A18 A19 A20 B1 B2 B3 B4 B5 B6 B7 B8 B9 B10 B11 B12 B13 B14 B15 B16 B17 B18 B19 B20 C1 C2 C3 C4 C5 C6 C7 C8

GND ZV_UV3 ZV_Y7 V

CCZ

ZV_Y1 ZV_HREF B_RSVD//B_D2 B_CAD28//B_D8 B_CSTSCHG//B_BVD1(STSCHG B_CINT

//B_READY(IREQ) B_CVS1//B_VS1 B_CAD24//B_A2 B_CAD22//B_A4 B_CAD20//B_A6 B_CAD18//B_A7 B_CIRDY B_CCLK//B_A16 B_CDEVSEL B_CPAR//B_A13 B_RSVD//B_A18 ZV_UV5 ZV_UV4 ZV_UV1 ZV_Y6 ZV_Y4 ZV_Y0 B_CAD31//B_D10 B_CAD29//B_D1 B_CCLKRUN B_CSERR B_CAD25//B_A1 B_CC/BE3 B_CAD21//B_A5 B_CVS2//B_VS2 B_CAD17//B_A24 V B_CPERR B_CBLOCK B_CC/BE1 B_CAD14//B_A9 ZV_RSVD1 ZV_SCLK ZV_UV6 ZV_UV2 ZV_Y5 ZV_Y3 ZV_VSYNC B_CAD30//B_D9

//B_A15

//B_A21

//B_WP(IOIS16)

//B_WAIT

//B_REG

CCB

//B_A14

//B_A19

//B_A8

/RI)

B_CCD2//B_CD2 V

C10 C11 C12 C13 C14 C15 C16 C17 C18 C19 C20 D1 D2 D3 D4 D5 D6 D7 D8 D9 D10 D11 D12 D13 D14 D15 D16 D17 D18 D19 D20 E1 E2 E3 E4 E17 E18 E19 E20 F4 F17 F18 F19 F20 G1 G2 G3

CCB

B_CAD26//B_A0 B_CAD23//B_A3 B_CRST B_CAD19//B_A25 B_CFRAME B_CTRDY B_CSTOP B_CAD16//B_A17 B_CAD15//B_IOWR B_CAD11//B_OE V ZV_UV7 ZV_MCLK GND ZV_UV0 V ZV_Y2 GND B_CAD27//B_D0 B_CAUDIO//B_BVD2(SPKR V B_CREQ GND B_CC/BE2 V B_CGNT GND B_CAD12//B_A11 B_CAD10//B_CE2 B_CC/BE0//B_CE1 ZV_PCLK ZV_SDATA ZV_LRCLK ZV_RSVD0 B_CAD13//B_IORD B_CAD9//B_A10 B_CAD8//B_D15 B_RSVD//B_D14 V V V B_CAD5//B_D6 B_CAD3//B_D5 A_CAD2//A_D11 A_CAD0//A_D3 A_CCD1

//B_RESET

CCZ

CC CC CCB

//A_CD1

//B_A23 //B_A22 //B_A20

//B_INPACK

//B_A12

//B_WE

G17

B_CAD7//B_D7 B_CAD6//B_D13

G18

B_CAD4//B_D12

G19

B_CAD1//B_D4

G20

A_CAD3//A_D5

A_CAD4//A_D12

A_CAD1//A_D4

GND

H17

B_CAD2//B_D11

H18

B_CAD0//B_D3

H19

B_CCD1

H20 J1

A_CAD7//A_D7

A_RSVD//A_D14

A_CAD5//A_D6

A_CAD6//A_D13

J17

PCLK

J18

CLKRUN

J19

PRST

J20

GNT

A_CC/BE0//A_CE1

)

A_CAD8//A_D15

K17

REQ

K18

AD31

K19

AD30

K20

A_CAD9//A_A10

A_CAD10//A_CE2

A_CAD11//A_OE

A_CAD13//A_IORD

L17

L18

AD28

L19

AD27

L20

AD29

A_CAD12//A_A11

A_CAD15//A_IOWR

A_CAD14//A_A9

A_CAD16//A_A17

M17

C/BE3

M18

AD24

M19

AD25

M20

AD26

A_CC/BE1

A_RSVD//A_A18

A_CPAR//A_A13

//B_CD1

CCA

CCP

//A_A8

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

signal names and terminal assignments (continued)

Table 1. GFN Terminals Sorted Alphanumerically for CardBus and 16-Bit Signals (Continued)

GFN SIGNAL NAME GFN SIGNAL NAME GFN SIGNAL NAME

N4 N17 N18 N19 N20 P1 P2 P3 P4 P17 P18 P19 P20 R1 R2 R3 R4 R17 R18 R19 R20 T1 T2 T3 T4 T17 T18 T19 T20 U1 U2 U3 U4 U5 U6 U7 U8

GND GND AD22 AD23 IDSEL A_CBLOCK A_CPERR A_CGNT A_CTRDY//A_A22 AD17 V

CCP

AD20 AD21 A_CSTOP A_CDEVSEL V

CCA

AD16 AD18 AD19 A_CCLK//A_A16 A_CIRDY A_CC/BE2 A_CAD19//A_A25 STOP IRDY FRAME C/BE2 A_CFRAME//A_A23 A_CAD17//A_A24 A_CVS2//A_VS2 GND A_CAD26//A_A0 V

A_CCLKRUN GND

//A_A19

//A_A14

//A_WE

//A_A20

//A_A21

//A_A15

//A_A12

//A_WP(IOIS16)

IRQMUX1

U10

PCGNT/IRQMUX6

U11

CLOCK

U12

GND

U13

AD6

U14

U15 U16 U17 U18 U19 U20 V1 V2 V3 V4 V5 V6 V7 V8 V9 V10 V11 V12 V13 V14 V15 V16 V17 V18 V19 V20 W1 W2 W3 W4 W5

AD11 GND PERR SERR TRDY A_CAD18//A_A7 A_CAD20//A_A6 A_CAD21//A_A5 A_CAD25//A_A1 A_CSERR A_CSTSCHG//A_BVD1(STSCHG/RI) A_CAD28//A_D8 A_RSVD//A_D2 IRQMUX2 V

CCI

GPIO0/LEDA1 DATA GPIO3/INTA AD3 V

CCP

AD8 AD12 AD15 GPIO2/LOCK DEVSEL A_CRST//A_RESET A_CAD22//A_A4 A_CAD23//A_A3 A_CAD24//A_A2 V

CCA

//A_WAIT

A_CCD2//A_CD2 A_CAD29//A_D1

A_CAD31//A_D10

IRQMUX3

IRQMUX5

W10

GPIO1/LEDA2

W11

LATCH

W12

IRQSER/INTB

W13

AD1

W14

AD4

W15

AD7

W16

AD9

W17

AD13

W18

C/BE1

W19

W20 Y1 Y2 Y3 Y4 Y5 Y6 Y7 Y8 Y9 Y10 Y11 Y12 Y13 Y14 Y15 Y16 Y17 Y18 Y19 Y20

CCP

A_CREQ A_CC/BE3//A_REG A_CVS1//A_VS1 A_CINT//A_READY(IREQ) A_CAUDIO//A_BVD2(SPKR A_CAD27//A_D0 A_CAD30//A_D9 IRQMUX0 IRQMUX4 SPKROUT SUSPEND PCREQ/IRQMUX7

/PME

RI_OUT AD0 AD2 AD5 C/BE0 AD10 AD14 PAR

//A_INPACK

)

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

signal names and terminal assignments (continued)

Table 2. GJG Terminals Sorted Alphanumerically for CardBus and 16-bit Signals

NO. SIGNAL NAME NO. SIGNAL NAME NO. SIGNAL NAME

A2 A3 A4 A5 A6 A7 A8 A9 A10 A11 A12 A13 A14 A15 A16 A17 A18 B1 B2 B3 B4 B5 B6 B7 B8 B9 B10 B11 B12 B13 B14 B15 B16 B17 B18 B19 C1 C2 C18 C19 D1 D2 D4 D5 D6 D7 D8 D9 D10 D11

ZV_UV6 ZV_UV4 ZV_UV2 ZV_Y6 ZV_Y3 ZV_VSYNC V

B_CCLKRUN B_CSERR B_CAD24//B_A2 B_CAD21//B_A5 B_CAD20//B_A6 B_CAD17//B_A24 V

CCB

B_CGNT B_CPERR//B_A14 B_CBLOCK ZV_SCLK ZV_UV5 ZV_UV3 ZV_UV1 ZV_Y7 ZV_Y4 ZV_Y0 B_CAD30//B_D9 B_CCD2 V

CCB

B_CAD25//B_A1 B_CAD22//B_A4 B_CVS2//B_VS2 GND B_CIRDY B_CDEVSEL B_CSTOP B_CPAR//B_A13 B_RSVD//B_A18 ZV_UV7 ZV_MCLK B_CC/BE1 B_CAD14//B_A9 ZV_RSVD0 ZV_RSVD1 GND ZV_UV0 V

CCZ

GND B_RSVD//B_D2 B_CAD27//B_D0 B_CAUDIO//B_BVD2(SPKR B_CC/BE3

//B_WP(IOIS16)

//B_WAIT

//B_WE

//B_A19

//B_CD2

//B_A15

//B_A21

//B_A20

//B_A8

//B_REG

D12

B_CREQ//B_INPACK B_CRST//B_RESET

D13

B_CC/BE2

D14

B_CCLK//B_A16

D15

B_CAD16//B_A17

D16

B_CAD15//B_IOWR

D18 D19

B_CAD12//B_A11

ZV_SDATA

ZV_PCLK

V E5 E6 E7 E8 E9 E10 E11 E12 E13 E14 E15 E16 E18 E19 F1 F2 F4 F5 F6 F7 F8 F9 F10 F11 F12 F13 F14 F15 F16 F18 F19 G1 G2 G4 G5 G6 G7 G13

)

G14 G15

CCZ

ZV_LRCLK

ZV_Y5

ZV_Y1

B_CAD31//B_D10

B_CAD28//B_D8

B_CSTSCHG//B_BVD1(STSCHG/RI

B_CAD26//B_A0

B_CAD23//B_A3

B_CAD19//B_A25

B_CFRAME

B_CTRDY

B_CAD13//B_IORD

B_CAD11//B_OE

B_CAD10//B_CE2

A_CCD1//A_CD1

A_CAD0//A_D3

GND

ZV_Y2

B_CAD29//B_D1

GND

B_CINT

B_CVS1//B_VS1

B_CAD18//B_A7

VCC

B_CAD9//B_A10

B_CC/BE0

B_CAD8//B_D15

CCB

A_CAD4//A_D12

A_CAD3//A_D5

A_CAD1//A_D4

A_CAD2//A_D11

ZV_HREF

B_CAD3//B_D5

B_CAD7//B_D7

B_RSVD//B_D14

//B_A12

//B_A23

//B_A22

//B_READY(IREQ)

//B_CE1

G16

GND

G18

B_CAD5//B_D6

G19

B_CAD6//B_D13

A_CAD5//A_D6

A_RSVD//A_D14

A_CAD7//A_D7

GND

A_CAD6//A_D13

H14

B_CCD1

H15

B_CAD4//B_D12

H16

B_CAD1//B_D4

H18

B_CAD2//B_D11

H19

B_CAD0//B_D3

A_CAD8//A_D15

A_CC/BE0

)

A_CAD9//A_A10

J14

GNT

J15

PCLK

J16

CLKRUN

J18

PRST

J19

GND

A_CAD11//A_OE

A_CAD13//A_IORD

A_CAD12//A_A11

GND

A_CAD10//A_CE2

K14

K15

REQ

K16

AD31

K18

AD30

K19

A_CAD14//A_A9

A_CAD16//A_A17

A_CC/BE1

A_RSVD//A_A18

A_CAD15//A_IOWR

L14

AD29

L15

AD28

L16

AD25

L18

AD27

L19

AD26

A_CPAR//A_A13

A_CBLOCK

A_CPERR

A_CSTOP

M14

AD22

M15

AD24

//B_CD1

//A_CE1

CCA

CCP

//A_A8

//A_A19 //A_A14 //A_A20

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

signal names and terminal assignments (continued)

Table 2. GJG Terminals Sorted Alphanumerically for CardBus and 16-bit Signals. (Continued)

NO. SIGNAL NAME NO. SIGNAL NAME NO. SIGNAL NAME

M16 M18 M19 N1 N2 N4 N5 N6 N7 N13 N14 N15 N16 N18 N19 P1 P2 P4 P5 P6 P7 P8 P9 P10 P11 P12 P13 P14 P15 P16 P18 P19 R1 R2 R4 R5

CBE3 IDSEL AD23 A_CDEVSEL GND A_CCLK//A_A16 A_CTRDY V

CCA

A_CGNT AD1 GND AD19 AD21 V

CCP

AD20 A_CIRDY A_CFRAME A_CC/BE2 V

A_CAD17//A_A24 A_CAD27//A_D0 V

CCI

SPKROUT PCREQ/IRQMUX7 RI_OUT AD5 AD8 C/BE2 AD16 AD18 AD17 A_CAD18//A_A7 A_CAD19//A_A25 A_CVS2//A_VS2 A_CSERR//A_WAIT

//A_A21

//A_A22

//A_WE

//A_A15

//A_A23

//A_A12

/PME

A_CSTSCHG//A_BVD1(STSCHG/RI)

A_CAD28//A_D8

IRQMUX2

IRQMUX5 R10 R11 R12 R13 R14 R15 R16 R18 R19 T1 T2 T4 T5 T6 T7 T8 T9 T10 T11 T12 T13 T14 T15 T16 T18 T19 U1 U2 U18 U19 V1 V2

/IRQMUX6

PCGNT

CLOCK

AD0

GND

C/BE0

TRDY

FRAME

IRDY

A_CAD20//A_A6

A_CRST

A_CAD21//A_A5

A_CINT

A_CCLKRUN

A_RSVD//A_D2

IRQMUX1

IRQMUX3

GPIO0/LEDA1

DATA

GPI03/INTA

AD4

AD7

AD11

AD15

DEVSEL

STOP

GND

A_CAD22//A_A4

PERR

SERR

A_CREQ//A_INPACK

A_CAD23//A_A3

//A_RESET

//A_READY(IREQ)

//A_WP(IOIS16)

A_CAD25//A_A1

A_CVS1//A_VS1 A_CAUDIO//A_BVD2(SPKR)

GND

A_CAD29//A_D1

IRQMUX0

GND

GPI01/LEDA2

V10

LATCH

V11

V12 V13 V14 V15 V16 V17 V18 V19 W2 W3 W4 W5 W6 W7 W8 W9 W10 W11 W12 W13 W14 W15 W16 W17 W18

AD3 V

CCP

AD10 AD13 C/BE1 V

CCP

GPI02/LOCK A_CC/BE3//A_REG A_CAD24//A_A2 A_CAD26//A_A0 V

CCA

A_CCD2 A_CAD30//A_D9 A_CAD31//A_D10 IRQMUX4 SUSPEND GND IRQSER/INTB AD2 AD6 AD9 AD12 AD14 PAR

//A_CD2

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

signal names and terminal assignments (continued)

Table 3. CardBus Signal Names Sorted Alphanumerically for GFN and GJG Pins

SIGNAL NAME GFN GJG SIGNAL NAME GFN GJG SIGNAL NAME GFN GJG

A_CAD0 A_CAD1 A_CAD2 A_CAD3 A_CAD4 A_CAD5 A_CAD6 A_CAD7 A_CAD8 A_CAD9 A_CAD10 A_CAD11 A_CAD12 A_CAD13 A_CAD14 A_CAD15 A_CAD16 A_CAD17 A_CAD18 A_CAD19 A_CAD20 A_CAD21 A_CAD22 A_CAD23 A_CAD24 A_CAD25 A_CAD26 A_CAD27 A_CAD28 A_CAD29 A_CAD30 A_CAD31 A_CAUDIO A_CBLOCK A_CC/BE0 A_CC/BE1 A_CC/BE2 A_CC/BE3 A_CCD1 A_CCD2

G2 H3 G1 H1 H2 J3 J4 J1 K3 L1 L2 L3 M1 L4 M3 M2 M4 U2 V1 T4 V2 V3 W2 W3 W4 V4 U5 Y6 V7 W7 Y7 W8 Y5 P1 K1 N1 T3 Y2 G3 W6

F2 G5 G6 G4 G1 H1 H6 H4 J1 J5 K6 K1 K4 K2 L1 L6 L2 P6 R1 R2 T1 T4 U2 V2 W3 V3 W4 P7 R7 V7 W7 W8 V5 M2 J2 L4 P4 W2 F1 W6

A_CCLK A_CCLKRUN A_CDEVSEL A_CFRAME A_CGNT A_CINT A_CIRDY A_CPAR A_CPERR A_CREQ A_CRST A_CSERR A_CSTOP A_CSTSCHG A_CTRDY A_CVS1 A_CVS2 A_RSVD A_RSVD A_RSVD B_CAD00 B_CAD01 B_CAD02 B_CAD03 B_CAD04 B_CAD05 B_CAD06 B_CAD07 B_CAD08 B_CAD09 B_CAD10 B_CAD11 B_CAD12 B_CAD13 B_CAD14 B_CAD15 B_CAD16 B_CAD17 B_CAD18 B_CAD19

T1 U7 R2 U1 P3 Y4 T2 N3 P2 Y1 W1 V5 R1 V6 P4 Y3 U3 J2 N2 V8 H19 G20 H18 F20 G19 F19 G18 G17 E19 E18 D19 C20 D18 E17 B20 C19 C18 B15 A15 C14

N4 T6 N1 P2 N7 T5 P1 M1 M4 V1 T2 R5 M5 R6 N5 V4 R4 H2 L5 T7 H19 H16 H18 G13 H15 G18 G19 G14 F18 F15 E19 E18 D19 E16 C19 D18 D16 A14 F13 E13

B_CAD20 B_CAD21 B_CAD22 B_CAD23 B_CAD24 B_CAD25 B_CAD26 B_CAD27 B_CAD28 B_CAD29 B_CAD30 B_CAD31 B_CAUDIO B_CBLOCK B_CCBE0 B_CCBE1 B_CCBE2 B_CCBE3 B_CCD1 B_CCD2 B_CCLK B_CCLKRUN B_CDEVSEL B_CFRAME B_CGNT B_CINT B_CIRDY B_CPAR B_CPERR B_CREQ B_CRST B_CSERR B_CSTOP B_CSTSCHG B_CTRDY B_CVS1 B_CVS2 B_RSVD B_RSVD B_RSVD

A14 B13 A13 C12 A12 B11 C11 D9 A8 B8 C8 B7 D10 B18 D20 B19 D14 B12 H20 C9 A17 B9 A18 C15 D16 A10 A16 A19 B17 D12 C13 B10 C17 A9 C16 A11 B14 A20 A7 E20

A13 A12 B12 E12 A11 B11 E11 D9 E9 F8 B8 E8 D10 A18 F16 C18 D14 D11 H14 B9 D15 A9 B16 E14 A16 F10 B15 B18 A17 D12 D13 A10 B17 E10 E15 F11 B13 B19 D8 G15

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

signal names and terminal assignments (continued)

Table 4. 16 Bit Signal Names Sorted Alphanumerically for GFN and GJG Pins

SIGNAL NAME GFN GJG SIGNAL NAME GFN GJG SIGNAL NAME GFN GJG

A_A00 A_A01 A_A02 A_A03 A_A04 A_A05 A_A06 A_A07 A_A08 A_A09 A_A10 A_A11 A_A12 A_A13 A_A14 A_A15 A_A16 A_A17 A_A18 A_A19 A_A20 A_A21 A_A22 A_A23 A_A24 A_A25 A_BVD1 A_BVD2 A_CD1 A_CD2 A_CE1 A_CE2 A_D00 A_D01 A_D02 A_D03 A_D04 A_D05 A_D06 A_D07

U5 V4 W4 W3 W2 V3 V2 V1 N1 M3 L1 M1 T3 N3 P2 T2 T1 M4 N2 P1 R1 R2 P4 U1 U2 T4 V6 Y5 G3 W6 K1 L2 Y6 W7 V8 G2 H3 H1 J3 J1

W4 V3 W3 V2 U2 T4 T1 R1 L4 L1 J5 K4 P4 M1 M4 P1 N4 L2 L5 M2 M5 N1 N5 P2 P6 R2 R6 V5 F1 W6 J2 K6 P7 V7 T7 F2 G5 G4 H1 H4

A_D08 A_D09 A_D10 A_D11 A_D12 A_D13 A_D14 A_D15 A_INPACK A_IORD A_IOWR A_OE A_READY A_REG A_RESET A_VS1 A_VS2 A_WAIT A_WE A_WP B_A00 B_A01 B_A02 B_A03 B_A04 B_A05 B_A06 B_A07 B_A08 B_A09 B_A10 B_A11 B_A12 B_A13 B_A14 B_A15 B_A16 B_A17 B_A18 B_A19

V7 Y7 W8 G1 H2 J4 J2 K3 Y1 L4 M2 L3 Y4 Y2 W1 Y3 U3 V5 P3 U7 C11 B11 A12 C12 A13 B13 A14 A15 B19 B20 E18 D18 D14 A19 B17 A16 A17 C18 A20 B18

R7 W7 W8 G6 G1 H6 H2 J1 V1 K2 L6 K1 T5 W2 T2 V4 R4 R5 N7 T6 E11 B11 A11 E12 B12 A12 A13 F13 C18 C19 F15 D19 D14 B18 A17 B15 D15 D16 B19 A18

B_A20 B_A21 B_A22 B_A23 B_A24 B_A25 B_BVD1 B_BVD2 B_CD1 B_CD2 B_CE1 B_CE2 B_D00 B_D01 B_D02 B_D03 B_D04 B_D05 B_D06 B_D07 B_D08 B_D09 B_D10 B_D11 B_D12 B_D13 B_D14 B_D15 B_INPACK B_IORD B_IOWR B_OE B_READY B_REG B_RESET B_VS1 B_VS2 B_WAIT B_WE B_WP

C17 A18 C16 C15 B15 C14 A9 D10 H20 C9 D20 D19 D9 B8 A7 H19 G20 F20 F19 G17 A8 C8 B7 H18 G19 G18 E20 E19 D12 E17 C19 C20 A10 B12 C13 A11 B14 B10 D16 B9

B17 B16 E15 E14 A14 E13 E10 D10 H14 B9 F16 E19 D9 F8 D8 H19 H16 G13 G18 G14 E9 B8 E8 H18 H15 G19 G15 F18 D12 E16 D18 E18 F10 D11 D13 F11 B13 A10 A16 A9

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG

FUNCTION

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

Terminal Functions

The terminals are grouped in tables by functionality, such as PCI system function, power-supply function, etc. The terminal numbers are also listed for convenient reference.

Table 5. Power Supply

TERMINAL

NAME GFN NO. GJG NO.

B14, D4, D7, F5, F9, G16, H5,

J19, K5, N2, N14, R13, U1, V6,

V9, W11

A8, F6, F12, F14, G2, J6, K19,

M6, P5, P8, R15, V12

Device ground terminals

Power supply terminal for core logic (3.3 V)

Clamping voltage for interrupt subsystem interface and miscellaneous I/O. Indicates signaling level of the following inputs and shared outputs: IRQSER, PCGNT SUSPEND INTA

, SPKROUT, GPIO1:0, IRQMUX7–IRQMUX0,

, INTB, CLOCK, DATA, LATCH, and RI_OUT.

, PCREQ,

GND

CCA

CCB

CCI

CCP

CCZ

A1, D4, D8, D13, D17, H4, H17,

N4, N17, U4, U8, U13, U17

D6, D11, D15, F4, F17, K4, L17,

R4, R17, U6, U10, U15

K2, R3, W5 J4, N6, W5 Clamping voltage for PC Card A interface.

B16, C10, F18, A15, B10, F19 Clamping voltage for PC Card B interface.

V10 P9

K20, P18, V15, W20 K14, N18, V14, V18 Clamping voltage for PCI signaling (3.3 V or 5 V)

A4, D1 D6, E4 Clamping voltage for zoomed video interface (3.3 V or 5 V)

TERMINAL

NAME GFN NO. GJG NO.

CLOCK U12 R11 I/O

DATA V12 T11 O

LATCH W12 V11 O

I/O

TYPE

Table 6. PC Card Power Switch

3-line power switch clock. Information on the DA TA line is sampled at the rising edge of CLOCK. CLOCK defaults to an input, but can be changed to a PCI1251B output by using the P2CCLK bit in the system control register. The TPS2206 defines the maximum frequency of this signal to be 2 MHz. If a system design defines this terminal as an output, then CLOCK requires an external pulldown resistor. The frequency of the PCI1251B output CLOCK is derived by dividing the PCI CLK by 36.

3-line power switch data. DA TA is used to serially communicate socket power control information to the power switch.

3-line power switch latch. LATCH is asserted by the PCI1251B to indicate to the PC Card power switch that the data on the DATA line is valid.

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

FUNCTION

Terminal Functions (Continued)

PCI1251B GFN/GJG

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

T able 7. PCI System

TERMINAL

NAME GFN NO. GJG NO.

CLKRUN

PCLK J17 J15 I

PRST

J18 J16 I/O

J19 J18 I

I/O

TYPE

PCI clock run. CLKRUN is used by the central resource to request permission to stop the PCI clock or to slow it down, and the PCI1251B responds accordingly. If CLKRUN implemented, then this pin should be tied low. CLKRUN (KEEPCLK) in the system control register.

PCI bus clock. PCLK provides timing for all transactions on the PCI bus. All PCI signals are sampled at the rising edge of PCLK.

PCI reset. When the PCI bus reset is asserted, PRST causes the PCI1251B to place all output buffers in a high-impedance state and reset all internal registers. When PRST asserted, the device is completely nonfunctional. After PRST is in its default state. When the SUSPEND the PRST high-impedance state, but the contents of the registers are preserved.

, and the internal registers are preserved. All outputs are placed in a

mode is enabled, the device is protected from

is enabled by default by bit 1

is deasserted, the PCI1251B

is not

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG

FUNCTION

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

Terminal Functions (Continued)

Table 8. PCI Address and Data

TERMINAL

NAME GFN NO. GJG NO.

AD31 AD30 AD29 AD28 AD27 AD26 AD25 AD24 AD23 AD22 AD21 AD20 AD19 AD18 AD17 AD16 AD15 AD14 AD13 AD12 AD11 AD10

AD9 AD8 AD7 AD6 AD5 AD4 AD3 AD2 AD1 AD0

C/BE3 C/BE2 C/BE1 C/BE0

PAR Y20 W18 I/O

K18 K19 L20 L18

L19 M20 M19 M18 N19 N18 P20 P19 R20 R19 P17 R18 V18 Y19 W18 V17 U16 Y18 W17 V16 W16 U14 Y16 W15 V14 Y15 W14 Y14

M17

T20 W19 Y17

K16 K18

L14 L15 L18 L19

L16 M15 M19 M14 N16 N19 N15 P18 P19 P16 T16

W17

V16

W16

T15 V15

W15

P14 T14

W14

P13 T13 V13

W13

N13 R12

M16 P15 V17 R14

TYPE

I/O

PCI address/data bus. These signals make up the multiplexed PCI address and data bus on the primary interface. During the address phase of a primary bus PCI cycle, AD31–AD0 contain a 32-bit

I/O

address or other destination information. During the data phase, AD31–AD0 contain data.

PCI bus commands and byte enables. These signals are multiplexed on the same PCI terminals. During the address phase of a primary bus PCI cycle, C/BE3 During the data phase, this 4-bit bus is used as byte enables. The byte enables determine which

I/O

byte paths of the full 32-bit data bus carry meaningful data. C/BE0 C/BE1

applies to byte 1 (AD15–AD8), C/BE2 applies to byte 2 (AD23–AD16), and C/BE3 applies

to byte 3 (AD31–AD24). PCI bus parity. In all PCI bus read and write cycles, the PCI1251B calculates even parity across

the AD31–AD0 and C/BE3 this parity indicator with a one-PCLK delay. As a target during PCI cycles, the calculated parity is compared to the initiator’s parity indicator. A compare error results in the assertion of a parity error (PERR

–C/BE0 buses. As an initiator during PCI cycles, the PCI1251B outputs

–C/BE0 define the bus command.

applies to byte 0 (AD7–AD0),

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

FUNCTION

Terminal Functions (Continued)

PCI1251B GFN/GJG

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

Table 9. PCI Interface Control

TERMINAL

NAME GFN NO. GJG NO.

DEVSEL

FRAME

GNT

GPIO2/LOCK

IDSEL N20 M18 I

IRDY

PERR

REQ

SERR

STOP

TRDY

V20 T18 I/O

T19 R18 I/O

J20 J14 I

V19 V19 I/O

T18 R19 I/O

U18 U18 I/O

K17 K15 O

U19 U19 O

T17 T19 I/O

U20 R16 I/O

I/O

TYPE

PCI device select. The PCI1251B asserts DEVSEL to claim a PCI cycle as the target device. As a PCI initiator on the bus, the PCI1251B monitors DEVSEL target responds before timeout occurs, then the PCI1251B terminates the cycle with an initiator abort.

PCI cycle frame. FRAME is driven by the initiator of a bus cycle. FRAME is asserted to indicate that a bus transaction is beginning, and data transfers continue while this signal is asserted. When FRAME

PCI bus grant. GNT is driven by the PCI bus arbiter to grant the PCI1251B access to the PCI bus after the current data transaction has completed. GNT bus request, depending on the PCI bus parking algorithm.

PCI bus general-purpose I/O pins or PCI bus lock. GPIO2/LOCK can be configured as PCI

and used to gain exclusive access downstream. Since this functionality is not typically

LOCK used, a general-purpose I/O may be accessed through this terminal. GPIO2/LOCK to a general-purpose input and can be configured through the GPIO2 control register.

Initialization device select. IDSEL selects the PCI1251B during configuration space accesses. IDSEL can be connected to one of the upper 24 PCI address lines on the PCI bus.

PCI initiator ready. IRDY indicates the PCI bus initiator’s ability to complete the current data phase of the transaction. A data phase is completed on a rising edge of PCLK where both

and TRDY are asserted. Until IRDY and TRDY are both sampled asserted, wait states

IRDY are inserted.

PCI parity error indicator. PERR is driven by a PCI device to indicate that calculated parity does not match PAR when PERR

PCI bus request. REQ is asserted by the PCI1251B to request access to the PCI bus as an initiator.

PCI system error. SERR is an output that is pulsed from the PCI1251B when enabled through the command register, indicating a system error has occurred. The PCI1251B need not be the target of the PCI cycle to assert this signal. When SERR control register, this signal also pulses, indicating that an address parity error has occurred on a CardBus interface.

PCI cycle stop signal. STOP is driven by a PCI target to request the initiator to stop the current PCI bus transaction. STOP by target devices that do not support burst data transfers.

PCI target ready. TRDY indicates the primary bus target’s ability to complete the current data phase of the transaction. A data phase is completed on a rising edge of PCLK when both IRDY inserted.

and TRDY are asserted. Until both IRDY and TRDY are asserted, wait states are

is deasserted, the PCI bus transaction is in the final data phase.

is enabled through bit 6 of the command register.

is used for target disconnects and is commonly asserted

until a target responds. If no

may or may not follow a PCI

defaults

is enabled in the bridge

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG

FUNCTION

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

Terminal Functions (Continued)

Table 10. System Interrupt

TERMINAL

NAME GFN NO. GJG NO.

GPIO3/INTA

IRQSER/INTB W13 W12 I/O

IRQMUX7 IRQMUX6 IRQMUX5 IRQMUX4 IRQMUX3 IRQMUX2 IRQMUX1 IRQMUX0

RI_OUT/PME Y13 P12 O

NAME GFN NO. GJG NO.

PCGNT/

IRQMUX6

PCREQ/

IRQMUX7

V13 T12 I/O

Y12 U11

W10

V9 U9 Y8

TERMINAL

U11 R10 I/O

Y12 P11 O

P11 R10

T9 R8 T8 V8

I/O

TYPE

I/O

TYPE

Parallel PCI interrupt. INT A can be optionally mapped to GPI03 when parallel PCI interrupts are used.

programmable interrupt subsystem

See GPIO3/INTA

Serial interrupt signal. IRQSER provides the IRQSER-style serial interrupting scheme. Serialized PCI interrupts can also be sent in the IRQSER stream. See

interrupt subsystem

to signal PCI INTB register.

Interrupt request/secondary functions multiplexed. The primary function of these terminals is to provide the ISA-type IRQ signaling supported by the PCI1251B. These interrupt multiplexer outputs can be mapped to any of 15 IRQs. The device control register must be programmed for the ISA IRQ interrupt mode and the IRQMUX routing register must have the IRQ routing programmed before these terminals are enabled.

All of these terminals have secondary functions, such as PCI INTB request/grant, ring indicate output, and zoomed video status, that can be selected with the appropriate programming of this register. When the secondary functions are enabled, the respective terminals are not available for IRQ routing.

See the Ring indicate out and power management event output. Terminal provides an output for

ring-indicate or PME

defaults to a general-purpose input.

on page 32 for details on interrupt signaling. This terminal can be used

when one of the parallel interrupt modes is selected in the device control

IRQMUX routing register

signals.

on page 32 for details on interrupt signaling.

programmable

, PC/PCI DMA

for programming options.

T able 11. PC/PCI DMA

PC/PCI DMA grant. PCGNT is used to grant the DMA channel to a requester in a system supporting the PC/PCI DMA scheme.

Interrupt request MUX 6. When configured for IRQMUX6, this terminal provides the IRQMUX6 interrupt output of the interrupt multiplexer, and can be mapped to any of 15 ISA-type IRQs. IRQMUX6 takes precedence over PCGNT PC/PCI DMA.

This terminal is also used for the serial EEPROM interface. PC/PCI DMA request. PCREQ is used to request DMA transfers as DREQ in a system

supporting the PC/PCI DMA scheme. Interrupt request MUX 7. When configured for IRQMUX7, this terminal provides the IRQMUX7

interrupt output of the interrupt multiplexer, and can be mapped to any of 15 ISA-type IRQs. IRQMUX7 takes precedence over PCREQ PC/PCI DMA.

This terminal is also used for the serial EEPROM interface.

, and should not be enabled in a system using

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

I/O

Terminal Functions (Continued)

PCI1251B GFN/GJG

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

Table 12. Zoomed Video

TERMINAL

NAME

ZV_HREF

ZV_VSYNC

ZV_Y7 ZV_Y6 ZV_Y5 ZV_Y4 ZV_Y3 ZV_Y2 ZV_Y1 ZV_Y0

ZV_UV7 ZV_UV6 ZV_UV5 ZV_UV4 ZV_UV3 ZV_UV2 ZV_UV1 ZV_UV0

ZV_SCLK C2 B1 A7 O Audio SCLK PCM

ZV_MCLK D3 C2 A6 O Audio MCLK PCM

ZV_PCLK E1 E2 IOIS16 O Pixel clock to the zoomed video port ZV_LRCLK E3 E5 INPACK O Audio LRCLK PCM ZV_SDATA E2 E1 SPKR O Audio SDATA PCM

NC F1 F4 O Reserved. No connection.

ZV_RSVD1 ZV_RSVD0

GFN

GJG NO.

NO.

A6 G7 A10 O C7 A7 A11 O A3

B4 C5 B5 C6 D7 A5 B6

D2 C3 B1 B2 A2 C4 B3 D5

C1 E4

B5 A5 E6 B6 A6 F7 E7 B7

C1 A2 B2 A3 B3 A4 B4 D5

D2 D1

I/O AND MEMORY

INTERFACE

SIGNAL

A20 A14 A19 A13 A18

A17

A25 A12 A24 A15 A23 A16 A22 A21

A5 A4

TYPE

Horizontal sync to the zoomed video port Vertical sync to the zoomed video port

O Video data to the zoomed video port in YV:4:2:2 format

Reserved. No connection in the PC Card. ZV_RSVD1 and ZV_RSVD0

are put into the high-impedance state by host adapter.

FUNCTION

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG

I/O

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

Terminal Functions (Continued)

TERMINAL

NAME GFN NO.

GPIO0/LEDA1 V11 T10 I/O

GPIO1/LEDA2 W11 V10 I/O

SPKROUT

SUSPEND

Y10 P10 O

Y11 W10 I

GJG

NO.

TYPE

Table 13. Miscellaneous

FUNCTION

GPIO0/socket activity LED indicator 1. When GPIO0/LEDA1 is configured as LEDA1, it provides an output indicating PC Card socket 0 activity. Otherwise, GPIO0/LEDA1 can be configured as a general-purpose input and output, GPIO0. The zoomed video enable signal (ZV_STAT) can also be routed to this signal through the GPIO0 control register. GPIO0/LEDA1 defaults to a general-purpose input.

GPIO1/socket activity LED indicator 2. When GPIO1/LEDA2 is configured as LEDA2, it provides an output indicating PC Card socket 1 activity. Otherwise, GPIO1/LEDA2 can be configured as a general-purpose input and output, GPIO1. A CSC interrupt can be generated on a GPDATA change, and this input can be used for power switch overcurrent (OC) sensing. See to a general-purpose input.

Speaker output. SPKROUT is the output to the host system that can carry SPKR or CAUDIO through the PCI1251B from the PC Card interface. SPKROUT is driven as the exclusive-OR combination of card SPKR

Suspend. SUSPEND is used to protect the internal registers from clearing when PRST is asserted. See

GPIO1 control register

suspend mode

for details.

for programming details. GPIO1/LEDA2 defaults

//CAUDIO inputs.

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

FUNCTION

Terminal Functions (Continued)

Table 14. 16-bit PC Card Address and Data (slots A and B)

TERMINAL

GFN NO. GJG NO.

NAME

†

Terminal name for slot A is preceded with A_. For example, the full name for terminal T4 is A_A25.

‡

Terminal name for slot B is preceded with B_. For example, the full name for terminal C14 is B_A25.

A25 A24 A23 A22 A21 A20 A19 A18 A17 A16 A15 A14 A13 A12 A11 A10

A9 A8 A7 A6 A5 A4 A3 A2 A1 A0

D15 D14 D13 D12

D11

D10

D9 D8 D7 D6 D5 D4 D3 D2 D1 D0

SLOT

†

T4 U2 U1 P4 R2 R1 P1 N2 M4 T1 T2 P2 N3 T3 M1

L1 M3 N1 V1 V2 V3

W2 W3 W4

V4 U5

J4 H2 G1

Y7 V7

J3 H1 H3 G2 V8

SLOT

‡

C14 B15 C15 C16 A18 C17 B18 A20 C18 A17 A16 B17 A19 D14 D18 E18 B20 B19 A15 A14 B13 A13 C12 A12 B11 C11

E19

E20 G18 G19

H18

B7 C8 A8

G17

F19

F20 G20

H19

A7 B8 D9

SLOT

†

R2 P6 P2 N5 N1 M5 M2

L2 N4 P1 M4 M1 P4 K4

L4 R1 T1 T4 U2 V2

J1 H2 H6

G1 G6 W8 W7

R7 H4 H1

G4 G5

F2 T7 V7 P7

SLOT

E13 A14 E14 E15 B16 B17 A18 B19 D16 D15 B15 A17 B18 D14 D19 F15 C19 C18 F13 A13 A12 B12 E12 A11 B11 E11

F18 G15 G19 H15 H18

E8 B8

E9 G14 G18 G13 H16 H19

I/O

TYPE

‡

O PC Card address. 16-bit PC Card address lines. A25 is the most significant bit.

I/O PC Card data. 16-bit PC Card data lines. D15 is the most significant bit.

PCI1251B GFN/GJG

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG

FUNCTION

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

Terminal Functions (Continued)

Table 15. 16-bit PC Card Interface Control (slots A and B)

TERMINAL

GFN NO. GJG NO.

NAME

BVD1

(STSCHG

BVD2

(SPKR

CD1 CD2

CE1 CE2

INPACK Y1 D12 V1 D12 I

IORD

IOWR

SLOT

/RI)

)

SLOT

†

V6 A9 R6 E10 I

Y5 D10 V5 D10 I

G3W6H20C9F1W6H14

K1L2D20

L4 E17 K2 E16 O

M2 C19 L6 D18 O

SLOT

‡

D19J2K6

SLOT

†

F16 E19

I/O

TYPE

‡

Battery voltage detect 1. BVD1 is generated by 16-bit memory PC Cards that include batteries. BVD1 is used with BVD2 as an indication of the condition of the batteries on a memory PC Card. Both BVD1 and BVD2 are kept high when the battery is good. When BVD2 is low and BVD1 is high, the battery is weak and should be replaced. When BVD1 is low, the battery is no longer serviceable and the data in the memory PC Card is lost. See

configuration register

on page 84 and the

status bits for this signal. Status change. STSCHG

write protect, or battery voltage dead condition of a 16-bit I/O PC Card. Ring indicate. RI is used by 16-bit modem cards to indicate a ring detection.

Battery voltage detect 2. BVD2 is generated by 16-bit memory PC Cards that include batteries. BVD2 is used with BVD1 as an indication of the condition of the batteries on a memory PC Card. Both BVD1 and BVD2 are high when the battery is good. When BVD2 is low and BVD1 is high, the battery is weak and should be replaced. When BVD1 is low, the battery is no longer serviceable and the data in the memory PC Card is lost. See

on page 85 for enable bits. See

page 84 this signal.

Speaker. SPKR and socket have been configured for the 16-bit I/O interface. The audio signals from cards A and B are combined by the PCI1251B and are output on SPKROUT .

DMA request. BVD2 can be used as the DMA request signal during DMA operations to a 16-bit PC Card that supports DMA. The PC Card asserts BVD2 to indicate a request for a DMA operation.

PC Card detect 1 and PC Card detect 2. CD1 and CD2 are internally connected to ground on the PC Card. When a PC Card is inserted into a socket, CD1

CD2 81

Card enable 1 and card enable 2. CE1 and CE2 enable even- and odd-numbered address bytes. CE1

odd-numbered address bytes. Input acknowledge. INP ACK is asserted by the PC Card when it can respond to

an I/O read cycle at the current address. DMA request. INPACK can be used as the DMA request signal during DMA

operations from a 16-bit PC Card that supports DMA. If used as a strobe, then the PC Card asserts this signal to indicate a request for a DMA operation.

I/O read. IORD is asserted by the PCI1251B to enable 16-bit I/O PC Card data output during host I/O read cycles.

DMA write. IORD is used as the DMA write strobe during DMA operations from a 16-bit PC Card that supports DMA. The PCI1251B asserts IORD transfers from the PC Card to host memory.

I/O write. IOWR is driven low by the PCI1251B to strobe write data into 16-bit I/O PC Cards during host I/O write cycles.

DMA read. IOWR a 16-bit PC Card that supports DMA. The PCI1251B asserts IOWR during transfers from host memory to the PC Card.

and the

are pulled low. For signal status, see

on page 85 for enable bits. See

ExCA interface status register

is used to alert the system to a change in the READY,

ExCA card status-change interrupt configuration

ExCA interface status register

is an optional binary audio signal available only when the card

enables even-numbered address bytes, and CE2 enables

is used as the DMA write strobe during DMA operations from

ExCA card status-change interrupt

ExCA card status-change register

ExCA interface status register

ExCA card status-change

on page 81 for the

on page 81 for the status bits for

on page

during DMA

and

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

FUNCTION

PCI1251B GFN/GJG

PC CARD CONTROLLER

Terminal Functions (Continued)

Table 15. 16-bit PC Card Interface Control (slots A and B) (continued)

TERMINAL

GFN NO. GJG NO.

NAME

OE L3 C20 K1 E18 O

READY

(IREQ

REG

RESET W1 C13 T2 D13 O PC Card reset. RESET forces a hard reset to a 16-bit PC Card.

WAIT

WE P3 D16 N7 A16 O

(IOIS16

VS1 VS2

†

Terminal name for slot A is preceded with A_. For example, the full name for terminal P3 is A_WE.

‡

Terminal name for slot B is preceded with B_. For example, the full name for terminal D16 is B_WE

SLOT

†

)

Y4 A10 T5 F10 I

Y2 B12 W2 D11 O

V5 B10 R5 A10 I

U7 B9 T6 A9 I

)

Y3U3A11

SLOT

‡

B14V4R4

SLOT

†

F11

B13

I/O

TYPE

‡

Output enable. OE is driven low by the PCI1251B to enable 16-bit memory PC Card data output during host memory read cycles.

DMA terminal count. OE to a 16-bit PC Card that supports DMA. The PCI1251B asserts OE for a DMA write operation.

Ready. The ready function is provided by READY when the 16-bit PC Card and the host socket are configured for the memory-only interface. READY is driven low by the 16-bit memory PC Cards to indicate that the memory card circuits are busy processing a previous write command. READY is driven high when the 16-bit memory PC Card is ready to accept a new data transfer command.

Interrupt request. IREQ that a device on the 16-bit I /O PC Card requires service by the host software.

is high (deasserted) when no interrupt is requested.

IREQ Attribute memory select. REG remains high for all common memory accesses.

When REG and to the I/O space (IORD accessed section of card memory and is generally used to record card capacity and other configuration and attribute information.

DMA acknowledge. REG operations to a 16-bit PC Card that supports DMA. The PCI1251B asserts REG to indicate a DMA operation. REG is used in conjunction with the DMA read (IOWR

Bus cycle wait. WAIT is driven by a 16-bit PC Card to delay the completion of (i.e., extend) the memory or I/O cycle in progress.

Write enable. WE is used to strobe memory write data into 16-bit memory PC Cards. WE is also used for memory PC Cards that employ programmable memory technologies.

DMA terminal count. WE that supports DMA. The PCI1251B asserts WE to indicate TC for a DMA read operation.

Write protect. WP applies to 16-bit memory PC Cards. WP reflects the status of the write-protect switch on 16-bit memory PC Cards. For 16-bit I/O cards, WP is used for the 16-bit port (IOIS16) function.

I/O is 16 bits. IOIS16 16-bit PC Card when the address on the bus corresponds to an address to which the 16-bit PC Card responds, and the I/O port that is addressed is capable of 16-bit accesses.

DMA request. WP can be used as the DMA request signal during DMA operations to a 16-bit PC Card that supports DMA. If used, the PC Card asserts WP to indicate a request for a DMA operation.

Voltage sense 1 and voltage sense 2. VS1 and VS2, when used in conjunction

I/O

with each other, determine the operating voltage of the 16-bit PC Card.

is asserted, access is limited to attribute memory (OE or WE active)

) or DMA write (IORD) strobes to transfer data.

is used as terminal count (TC) during DMA operations

is asserted by a 16-bit I/O PC Card to indicate to the host

or IOWR active). Attribute memory is a separately

is used as a DMA acknowledge (DACK) during DMA

is used as TC during DMA operations to a 16-bit PC Card

applies to 16-bit I/O PC Cards. IOIS16 is asserted by the

SCPS043A – OCTOBER 1998

to indicate TC

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG

FUNCTION

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

Terminal Functions (Continued)

Table 16. CardBus PC Card Interface System (slots A and B)

TERMINAL GFN NO. GJG NO.

NAME

CCLK T1 A17 N4 D15 O

CCLKRUN

CRST

†

Terminal name for slot A is preceded with A_. For example, the full name for terminal T1 is A_CCLK.

‡

Terminal name for slot B is preceded with B_. For example, the full name for terminal A17 is B_CCLK.

SLOT

†

U7 B9 T6 A9 O

W1 C13 T2 D13 I/O

SLOT

‡

SLOT

†

I/O

TYPE

‡

CardBus PC Card clock. CCLK provides synchronous timing for all transactions on the CardBus interface. All signals except CRST CAUDIO, CCD1 and all timing parameters are defined with the rising edge of this signal. CCLK operates at the PCI bus clock frequency, but it can be stopped in the low state or slowed down for power savings.

CardBus PC Card clock run. CCLKRUN is used by a CardBus PC Card to request an increase in the CCLK frequency, and by the PCI1251B to indicate that the CCLK frequency is decreased. CardBus clock run (CCLKRUN (CLKRUN

CardBus PC Card reset. CRST is used to bring CardBus PC Card-specific registers, sequencers, and signals to a known state. When CRST CardBus PC Card signals must be placed in a high impedance state, and the PCI1251B drives these signals to a valid logic level. Assertion can be asynchronous to CCLK, but deassertion must be synchronous to CCLK.

, CCD2, and CVS2–CVS1 are sampled on the rising edge of CCLK,

)

, CCLKRUN, CINT, CSTSCHG,

) follows the PCI clock run

is asserted, all

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

FUNCTION

Terminal Functions (Continued)

Table 17. CardBus PC Card Address and Data (slots A and B)

TERMINAL

E8 B8 F8 E9 D9

I/O

TYPE

‡

PC Card address and data. These signals make up the multiplexed CardBus address and data bus on the CardBus interface. During the address phase of a CardBus cycle,

I/O

CAD31–CAD0 contain a 32-bit address. During the data phase of a CardBus cycle, CAD31–CAD0 contain data. CAD31 is the most significant bit.

CardBus bus commands and byte enables. CC/BE3–CC/BE0 are multiplexed on the same CardBus terminals. During the address phase of a CardBus cycle,

–CC/BE0 defines the bus command. During the data phase, this 4-bit bus is

CC/BE3 used as byte enables. The byte enables determine which byte paths of the full 32-bit

I/O

data bus carry meaningful data. CC/BE0 applies to byte 1 (CAD15–CAD8), CC/BE2 applies to byte 2 (CAD23–CAD8), and CC/BE3

applies to byte 3 (CAD31–CAD24).

CardBus parity. In all CardBus read and write cycles, the PCI1251B calculates even parity across the CAD and CC/BE PCI1251B outputs CP AR with a one-CCLK delay . As a target during CardBus cycles, when the calculated parity is compared to the initiator’s parity indicator; a compare error results in a parity error assertion.

applies to byte 0 (CAD7–CAD0), CC/BE1

buses. As an initiator during CardBus cycles, the

GFN NO. GJG NO.

NAME

CAD31 CAD30 CAD29 CAD28 CAD27 CAD26 CAD25 CAD24 CAD23 CAD22 CAD21 CAD20 CAD19 CAD18 CAD17 CAD16 CAD15 CAD14 CAD13 CAD12 CAD11 CAD10

CAD9 CAD8 CAD7 CAD6 CAD5 CAD4 CAD3 CAD2 CAD1 CAD0

CC/BE3 CC/BE2 CC/BE1 CC/BE0

CPAR N3 A19 M1 B18 I/O

†

Terminal name for slot A is preceded with A_. For example, the full name for terminal N3 is A_CPAR.

‡

Terminal name for slot B is preceded with B_. For example, the full name for terminal A19 is B_CPAR.

SLOT

†

V7 Y6 U5

V4 W4 W3 W2

U2 M4 M2 M3

L3 L2 L1

J1 J4

J3 H2 H1 G1 H3 G2

Y2 T3 N1 K1

SLOT

‡

B7 C8 B8 A8

D9 C11 B11 A12 C12 A13 B13 A14 C14 A15 B15 C18 C19 B20 E17 D18 C20 D19 E18 E19 G17 G18 F19 G19 F20 H18 G20 H19

B12 D14 B19 D20

SLOT

†

W8 W7

V7 R7 P7

V2 U2 T4 T1 R2 R1 P6

L2 L6

L1 K2 K4 K1 K6

J1 H4 H6 H1 G1 G4 G6 G5 F2

SLOT

E11 B11

A11 E12 B12 A12 A13 E13

F13 A14 D16 D18 C19 E16 D19 E18 E19

F15

F18 G14 G19 G18 H15 G13 H18 H16 H19

D11 D14 C18

F16

PCI1251B GFN/GJG

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG

FUNCTION

ith CVS1

CVS2 to identif

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

Terminal Functions (Continued)

Table 18. CardBus PC Card Interface Control (slots A and B)

TERMINAL GFN NO. GJG NO.

NAME

CAUDIO Y5 D10 V5 D10 I

CBLOCK

CCD1 CCD2

CDEVSEL

CFRAME

CGNT

CINT

CIRDY

CPERR

CREQ

CSERR

CSTOP

CSTSCHG

CTRDY

CVS1 CVS2

†

Terminal name for slot A is preceded with A_. For example, the full name for terminal Y5 is A_CAUDIO.

‡

Terminal name for slot B is preceded with B_. For example, the full name for terminal D10 is B_CAUDIO.

SLOT

†

P1 B18 M2 A18 I/O

G3 H20 F1 H14 W6 C9 W6 B9

R2 A18 N1 B16 I/O

U1 C15 P2 E14 I/O

P3 D16 N7 A16 I

Y4 A10 T5 F10 I

T2 A16 P1 B15 I/O

P2 B17 M4 A17 I/O

Y1 D12 V1 D12 I

V5 B10 R5 A10 I

R1 C17 M5 B17 I/O

V6 A9 R6 E10 I

P4 C16 N5 E15 I/O

Y3U3A11

SLOT

‡

B14V4R4

SLOT

†

F11

B13

I/O

TYPE

‡

CardBus audio. CAUDIO is a digital input signal from a PC Card to the system speaker. The PCI1251B supports the binary audio mode and outputs a binary signal from the card to SPKROUT.

CardBus lock. CBLOCK is used to gain exclusive access to a target. CardBus detect 1 and CardBus detect 2. CCD1 and CCD2 are used in conjunction

w the operating voltage and card type.

CardBus device select. The PCI1251B asserts CDEVSEL to claim a CardBus cycle as the target device. As a CardBus initiator on the bus, the PCI1251B monitors CDEVSEL the PCI1251B terminates the cycle with an initiator abort.

CardBus cycle frame. CFRAME is driven by the initiator of a CardBus bus cycle. CFRAME transfers continue while this signal is asserted. When CFRAME CardBus bus transaction is in the final data phase.

CardBus bus grant. CGNT is driven by the PCI1251B to grant a CardBus PC Card access to the CardBus bus after the current data transaction has been completed.

CardBus interrupt. CINT is asserted low by a CardBus PC Card to request interrupt servicing from the host.

CardBus initiator ready. CIRDY indicates the CardBus initiator’s ability to complete the current data phase of the transaction. A data phase is completed on a rising edge of CCLK when both CIRDY CTRDY

CardBus parity error. CPERR is used to report parity errors during CardBus transactions, except during special cycles. It is driven low by a target two clocks following that data when a parity error is detected.

CardBus request. CREQ indicates to the arbiter that the CardBus PC Card desires use of the CardBus bus as an initiator.

CardBus system error. CSERR reports address parity errors and other system errors that could lead to catastrophic results. CSERR synchronous to CCLK, but deasserted by a weak pullup, and may take several CCLK periods. The PCI1251B can report CSERR SERR

CardBus stop. CSTOP is driven by a CardBus target to request the initiator to stop the current CardBus transaction. CSTOP commonly asserted by target devices that do not support burst data transfers.

CardBus status change. CSTSCHG is used to alert the system to a change in the card’s status and is used as a wake-up mechanism.

CardBus target ready. CTRDY indicates the CardBus target’ s ability to complete the current data phase of the transaction. A data phase is completed on a rising edge of CCLK, when both CIRDY are inserted.

CardBus voltage sense 1 and CardBus voltage sense 2. CVS1 and CVS2 are used

I/O

in conjunction with CCD1 to determine the operating voltage and card type.

and

until a target responds. If no target responds before timeout occurs, then

is asserted to indicate that a bus transaction is beginning, and data

are both sampled asserted, wait states are inserted.

on the PCI interface.

y card insertion and interrogate cards to determine

and CTRDY are asserted. Until CIRDY and

and CTRDY are asserted; until this time, wait states

and CCD2 to identify card insertion and interrogate cards

is deasserted, the

is driven by the card

to the system by assertion of

is used for target disconnects, and is

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

power supply sequencing

The PCI1251B contains 3.3-V I/O buffers with 5-V tolerance requiring a core power supply and clamping voltage. The core power supply is always 3.3 V. The clamping voltage can be either 3.3 V or 5 V, depending on the interface. The following power-up and power-down sequences are recommended.

The power-up sequence is:

1. Apply 3.3-V power to the core.

2. Assert PRST

to the device to disable the outputs during power up. Output drivers must be powered up in

the high-impedance state to prevent high current levels through the clamping diodes to the 5-V supply.

3. Apply the clamping voltage. The power-down sequence is:

1. Use PRST to switch outputs to a high-impedance state.

2. Remove the clamping voltage.

3. Remove the 3.3-V power from the core.

I/O characteristics

Figure 1 shows a 3-state bidirectional buffer. The provides the electrical characteristics of the inputs and outputs. The PCI1251B meets the ac specifications of the

1997 PC Card Standard

and

PCI Local Bus Specification Rev. 2.2

Tied for Open Drain

Figure 1. 3-State Bidirectional Buffer

recommended operating conditions

CCP

Pad

table, on page 115,

NOTE:

Unused pins (input or I/O) must be held high or low to prevent them from floating.

clamping voltages

The clamping voltages are set to match whatever external environment the PCI1251B will be working with: 3.3 V or 5 V. The I/O sites can be pulled through a clamping diode to a voltage that protects the core from external signals. The core power supply is always 3.3 V and is independent of the clamping voltages. For example, PCI signaling can be either 3.3 V or 5 V, and the PCI1251B must reliably accommodate both voltage levels. This is accomplished by using a 3.3-V I/O buffer that is 5-V tolerant, with the applicable clamping voltage applied. If a system designer desires a 5-V PCI bus, then V

The PCI1251B requires five separate clamping voltages because it supports a wide range of features. The five voltages are listed and defined in the

recommended operating conditions

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

can be connected to a 5-V power supply.

CCP

table, on page 115.

PCI1251B GFN/GJG PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

PCI interface

This section describes the PCI interface of the PCI1251B and how the device responds and participates in PCI bus cycles. The PCI1251B provides all required signals for PCI master/slave devices. The PCI1251B can operate in either 5-V or 3.3-V PCI signaling environments by connecting the V signaling level.

PCI bus lock (LOCK)

The bus-locking protocol defined in the PCI specification is not highly recommended, but is provided on the PCI1251B as an additional compatibility feature. The PCI LOCK terminal is multiplexed with GPIO2, and the terminal function defaults to a general-purpose input (GPI). The use of LOCK is only supported by PCI-to-CardBus bridges in the downstream direction (away from the processor).

PCI LOCK indicates an atomic operation that may require multiple transactions to complete. When LOCK is asserted, nonexclusive transactions can proceed to an address that is not currently locked. A grant to start a transaction on the PCI bus does not guarantee control of LOCK; control of LOCK is obtained under its own protocol. It is possible for different initiators to use the PCI bus while a single master retains ownership of LOCK. To avoid confusion with the bus clock, the CardBus signal for this protocol is CBLOCK

An agent may need to do an exclusive operation because a critical access to memory might be broken into several transactions, but the master wants exclusive rights to a region of memory. The granularity of the lock is defined by PCI to be 16 bytes, aligned. The lock protocol defined by PCI allows a resource lock without interfering with nonexclusive real-time data transfer, such as video.

terminals to the desired

CCP

loading the subsystem identification (EEPROM interface)

The subsystem vendor ID register and subsystem ID register make up a doubleword of PCI configuration space located at offset 40h for functions 0 and 1. This doubleword register is used for system and option card (mobile dock) identification purposes and is required by some operating systems. Implementation of this unique identifier register is a PC ’95 requirement.

The PCI1251B offers two mechanisms to load a read-only value into the subsystem registers. The first mechanism relies upon the system BIOS providing the subsystem ID value. The default access mode to the subsystem registers is read-only, but can be made read/write by clearing the SUBSYSRW bit in the system control register (bit 5, offset 80h). Once this bit is cleared (0), the BIOS can write a subsystem identification value into the registers at offset 40h. The BIOS must set the SUBSYSRW bit such that the subsystem vendor ID register and subsystem ID register is limited to read-only access. This approach saves the added cost of implementing the serial EEPROM.

In some conditions, such as in a docking environment, the subsystem vendor ID register and subsystem ID register must be loaded with a unique identifier through a serial EEPROM interface. The PCI1251B loads the doubleword of data from the serial EEPROM after a reset of the primary bus. The SUSPEND PCI reset from the entire PCI1251B core, including the serial EEPROM state machine (see page 37, for details on using SUSPEND). The PCI1251B provides a two-line serial bus interface to a serial EEPROM.

The system designer must implement a pulldown resistor on the PCI1251B LA TCH terminal to indicate the serial EEPROM mode. Only when this pulldown resistor is present will the PCI1251B attempt to load data through the serial EEPROM interface. The serial EEPROM interface is a two-pin interface with one data signal (SDA) and one clock signal (SCL). SDA is mapped to the PCI1251B IRQMUX6 terminal and SCL is mapped to the PCI1251B IRQMUX7 terminal. Figure 2 shows a typical PCI1251B application using the serial EEPROM interface.

input gates the

suspend mode

, on

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

loading the subsystem identification (EEPROM interface) (continued)

Serial

EEPROM

PCI1251B GFN/GJG

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

PCI1251B

A0 A1 A2

SCL

SDA

IRQMUX7 IRQMUX6

LATCH

Figure 2. Serial EEPROM Application

When the PCI1251B is reset, the subsystem data is read automatically from the EEPROM. The PCI1251B masters the serial EEPROM bus and reads four bytes, as shown in Figure 3.

The EEPROM is addressed at word address 00h, as shown in Figure 3, and the address automatically increments after each byte transfer according to the protocol. Thus, to provide the subsystem register with data AABBCCDDh, the EEPROM should be programmed with address 0 = AAh, 1 = BBh, 2 = CCh, and 3 = DDh.

Slave Address Word Address

Sb6 b4b5 b3 b2 b1 b0 0 b7 b6 b5 b4 b3 b2 b1 b0AA

R/W

Data Byte 0 M

Data Byte 1 Data Byte 2 Data Byte 3 M PMM

M = Master acknowledgement

Sb6 b4b5 b3 b2 b1 b0 1 A

Restart

S/P = Start/stop conditionA = Slave acknowledgement

Slave Address

R/W

Figure 3. EEPROM Interface Subsystem Data Collection

The serial EEPROM is addressed at slave address 1010000b by the PCI1251B. All hardware address bits for the EEPROM should be tied to the appropriate level to achieve this address. The serial EEPROM chip in the sample application circuit (Figure 2) assumes the 1010b high address nibble. The lower three address bits are terminal inputs to the chip, and the sample application shows these terminal inputs tied to GND.

The serial EEPROM interface signals require pullup resistors, and the protocol is defined for the bidirectional transfers. Both SCL and SDA are placed in a high-impedance state and pulled high when the bus is not active. A high-to-low transition of the SDA line defines the start condition (S). A low-to-high transition of SDA while SCL is high is defined as the stop condition (P). One bit is transferred during each clock pulse. The data on the SDA line must remain stable during the high period of the clock pulse, as changes in the data line at this time are interpreted as a control signal. Data is valid and stable during the clock high period. Figure 4 illustrates this protocol.

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

loading the subsystem identification (EEPROM interface) (continued)

SDA

SCL

Start

Condition

Stop

Condition

Change of

Data Allowed

Data Line Stable,

Data Valid

Figure 4. Serial EEPROM Start/Stop Conditions and Bit Transfers

Each address byte and data transfer is followed by an acknowledge bit, as indicated in Figure 3. When the PCI1251B transmits the addresses, it returns SDA to the high state and places the line in a high-impedance state. The PCI1251B then generates an SCL clock cycle and expects the EEPROM to pull down SDA during the acknowledge pulse. This procedure is referred to as a slave acknowledge with the PCI1251B transmitter and EEPROM receiver . Figure 5 illustrates the general acknowledges.

During the data byte transfers from the serial EEPROM to the PCI1251B, the EEPROM clocks the SCL signal. After the EEPROM transmits the data to the PCI1251B, it returns the SDA signal to the high state and places the line in a high-impedance state. The EEPROM then generates an SCL clock cycle and expects the PCI1251B to pull down SDA during the acknowledge pulse. This procedure is referred to as a master acknowledge with the EEPROM transmitter and PCI1251B receiver. Figure 5 illustrates the general acknowledges.

SCL From

Master

SDA Output

By Transmitter

123 789

SDA Output

By Receiver

Figure 5. Serial EEPROM Protocol – Acknowledge

EEPROM interface status information is communicated through the general status register located at PCI offset 85h. The EEDETECT bit in this register indicates whether or not the PCI1251B serial EEPROM circuitry detects the pulldown resistor on LA TCH. An error condition, such as a missing acknowledge, results in the DATAERR bit being set. The EEBUSY bit is set while the subsystem ID register is loading (serial EEPROM interface is busy).

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

PC Card applications

This section describes the following PC Card interfaces: PC Card recognition (which details the card interrogation procedure), card-powering procedure (including the protocol of the P2C power switch interface), internal zoomed video (ZV) buffering provided by the PCI1251B and programming model, standard PC Card register models, and a brief discussion of the PC Card software protocol layers.

PC Card insertion/removal and recognition

The 1997 PC Card Standard addresses the card-detection and recognition process through an interrogation procedure that the socket must initiate on card insertion into a cold, unpowered socket. Through this interrogation, card voltage requirements and interface (16-bit versus CardBus) are determined.

The scheme uses the CD1

, CD2, VS1, and VS2 signals (CCD1, CCD2, CVS1, and CVS2 for CardBus). A PC Card designer connects these four terminals in prescribed configuration determined by the type of card and the supply voltage. The encoding scheme for this, defined in the

1997 PC Card Standard

, is shown in T able 19.

Table 19. PC Card Card-Detect and Voltage-Sense Connections

CD2//CCD2 CD1//CCD1 VS2//CVS2 VS1//CVS1 KEY INTERFACE VOLTAGE

Ground Ground Open Open 5 V 16-bit PC Card 5 V Ground Ground Open Ground 5 V 16-bit PC Card 5 V and 3.3 V Ground Ground Ground Ground 5 V 16-bit PC Card 5 V, 3.3 V, and X.X V Ground Ground Open Ground LV 16-bit PC Card 3.3 V Ground Connect to CVS1 Open Connect to CCD1 LV CardBus PC Card 3.3 V Ground Ground Ground Ground LV 16-bit PC Card 3.3 V and X.X V

Connect to CVS2 Ground Connect to CCD2 Ground LV CardBus PC Card 3.3 V and X.X V Connect to CVS1 Ground Ground Connect to CCD2 LV CardBus PC Card 3.3 V, X.X V, and Y.Y V

Ground Ground Ground Open LV 16-bit PC Card Y.Y V

Connect to CVS2 Ground Connect to CCD2 Open LV CardBus PC Card Y.Y V

Ground Connect to CVS2 Connect to CCD1 Open LV CardBus PC Card X.X V and Y.Y V

Connect to CVS1 Ground Open Connect to CCD2 LV CardBus PC Card Y.Y V

Ground Connect to CVS1 Ground Connect to CCD1 Reserved Ground Connect to CVS2 Connect to CCD1 Ground Reserved

P2C power switch interface (TPS2206)

A power switch with a PCMCIA-to-peripheral control (P2C) interface is required for the PC Card powering interface. The TI TPS2206 dual-slot PC Card power interface switch provides the P2C interface to the CLOCK, DATA, and LATCH terminals of the PCI1251B. Figure 6 shows the terminal assignments of the TPS2206. Figure 7 illustrates a typical application where the PCI1251B represents the PCMCIA controller.

The CLOCK terminal on the PCI1251B can be an input or an output depending on whether bit 27 of the system control register is a 0 or a 1. The default is for the CLOCK terminal to be an input to control the serial interface and the PCI1251B internal state machine. The P2CCLK bit in the system control register can be set by the system BIOS to enable the PCI1251B to internally generate and drive the CLOCK from the PCI clock. When the system design implements CLOCK as an output from the PCI1251B, an external pulldown resistor is required since the CLOCK terminal defaults to an input.

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

P2C power switch interface (TPS2206) (continued)

Power Supply

12 V

5 V

3.3 V

Supervisor

5V 5V

DATA

CLOCK

LATCH

RESET

12V

AVPP AVCC AVCC AVCC

GND

RESET

3.3V

NC – No internal connection

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

5V NC NC NC NC NC 12V BVPP BVCC BVCC BVCC NC OC

3.3V

Figure 6. TPS2206 Terminal Assignments

TPS2206

12V 5V

3.3V

RESET RESET

AVPP

AVCC AVCC

AVCC

V V V V

PP1 PP2 CC CC

PC Card

PCMCIA

Controller

Serial Interface

BVPP

BVCC BVCC BVCC

Figure 7. TPS2206 Typical Application

V V V V

PP1 PP2 CC CC

PC Card

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG

PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

zoomed video support

The ZV port on the PCI1251B provides an internally buffered 16-bit ZV PC Card data path. This internal routing is programmed through the multimedia control register. Figure 8 shows the zoomed video subsystem implemented in the PCI1251B and details the bit functions found in the multimedia control register.

An output port (PORTSEL) is always selected. The PCI1251B defaults to socket 0 (see the

on page 58). When ZVOUTEN is asserted, the zoomed video output terminals are enabled to allow the

multimedia control

PCI1251B to route the zoomed video data. However , no data is transmitted unless either ZVEN0 or ZVEN1 is enabled in the multimedia control register. When the PORTSEL maps to a card port that is disabled (ZVEN0 or ZVEN1), then the zoomed video port is driven low; that is, no data is transmitted.

Zoomed Video Subsystem

ZVEN0

ZVOUTEN

ZVSTAT (see Note A)

VGA

PORTSEL

Zoomed Video

Port

PC Card

Socket 0

PC Card

Socket 1

Card Output Enable

Logic

PC Card

Interface

PC Card

Interface

Card Output Enable

Logic

NOTES: A. ZVSTAT must be enabled through the GPIO control register.

ZVEN1

Figure 8. Zoomed Video Subsystem

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

PCI1251B GFN/GJG PC CARD CONTROLLER

SCPS043A – OCTOBER 1998

SPKROUT usage

SPKROUT carries the digital audio signal from the PC Card to the system. When a 16-bit PC Card is configured for I/O mode, the BVD2 pin becomes SPKR. This terminal, also used in CardBus applications, is referred to as CAUDIO. SPKR passes a TTL-level digital audio signal to the PCI1251B. The CardBus CAUDIO signal also can pass a single-amplitude binary waveform. The binary audio signals from the two PC Card sockets are XORed in the PCI1251B to produce SPKROUT. Figure 9 shows the SPKROUT connection.

Bit 1, Card Control Register (offset 91h)

Card A SPKROUT Enable

Card A SPKR

SPKROUT

Bit 1, Card Control Register (offset 91h)

Card B SPKROUT Enable

Card B SPKR

Card A SPKROUT Enable Card B SPKROUT Enable

Figure 9. SPKROUT Connection to Speaker Driver

Speaker

Driver

The SPKROUT signal is typically driven only by modem PC Cards. To verify SPKROUT on the PCI1251B, a sample circuit was constructed, and this simplified schematic is shown in Figure 10.

NOTE:

Earlier versions of the PC Card controller multiplexed SUSPEND/SPKROUT on the same pin, which meant that a pullup resistor was needed to differentiate the signals. Because the PCI1251B does not multiplex this or any other function on SPKROUT, this terminal does not require a pullup resistor.

SPKROUT

3 7 2

+ –

LM386

Speaker

Figure 10. Simplified Test Schematic

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

+ 96 hidden pages
