TEXAS INSTRUMENTS LM124 Technical data

查询LM124供应商
LM124, LM124A, LM224, LM224A
LM324, LM324A, LM324Y, LM2902, LM2902Q
QUADRUPLE OPERATIONAL AMPLIFIERS
SLOS066E– SEPTEMBER 1975 – REVISED FEBRUARY1997
D
Single Supply...3 V to 30 V (LM2902 and LM2902Q 3 V to 26 V), or Dual Supplies
D
Low Supply Current Drain Independent of Supply Voltage . . . 0.8 mA Typ
D
Common-Mode Input Voltage Range Includes Ground Allowing Direct Sensing Near Ground
D
Low Input Bias and Offset Parameters:
Input Offset Voltage ...3 mV Typ A Versions ...2 mV Typ Input Offset Current...2 nA Typ Input Bias Current...20 nA Typ A Versions . . . 15 nA Typ
D
Differential Input Voltage Range Equal to Maximum-Rated Supply Voltage . . . 32 V (26 V for LM2902 and LM2902Q)
D
Open-Loop Differential Voltage Amplification . . . 100 V/mV Typ
D
Internal Frequency Compensation
description
LM124, LM124A ...J OR W PACKAGE
ALL OTHERS . . . D, DB, N OR PW PACKAGE
1OUT
2OUT
LM124, LM124A . . . FK PACKAGE
1IN+
NC
V
CC
NC
2IN+
(TOP VIEW)
1
1IN–
2IN–
2
1IN+
3
V
4
CC
2IN+
5 6 7
(TOP VIEW)
1IN –
1OUT
3212019
4 5 6 7 8
910111213
NC
14 13 12 11 10
9 8
4OUT
4IN –
18 17 16 15 14
4OUT 4IN– 4IN+ GND 3IN+ 3IN– 3OUT
4IN+ NC GND NC 3IN+
These devices consist of four independent high-gain frequency-compensated operational amplifiers that are designed specifically to operate
NC – No internal connection
2IN –
2OUT
NC
3IN –
3OUT
from a single supply over a wide range of voltages. Operation from split supplies is also possible
symbol (each amplifier)
when the difference between the two supplies is 3 V to 30 V (for the LM2902 and LM2902Q, 3 V to 26 V) and V
is at least 1.5 V more positive than
CC
the input common-mode voltage. The low supply current drain is independent of the magnitude of
IN –
IN +
OUT
+
the supply voltage. Applications include transducer amplifiers, dc amplification blocks, and all the conventional operational
amplifier circuits that now can be more easily implemented in single-supply-voltage systems. For example, the LM124 can be operated directly from the standard 5-V supply that is used in digital systems and easily provides the required interface electronics without requiring additional ±15-V supplies.
The LM2902Q is manufactured to demanding automotive requirements. The LM124 and LM124A are characterized for operation over the full military temperature range of –55°C to
125°C. The LM224 and LM224A are characterized for operation from –25°C to 85°C. The LM324 and LM324A are characterized for operation from 0°C to 70°C. The LM2902 and LM2902Q are characterized for operation from –40°C to 125°C.
PRODUCTION DATA information is current as of publication date. Products conform to specifications per the terms of Texas Instruments standard warranty. Production processing does not necessarily include testing of all parameters.
POST OFFICE BOX 655303 DALLAS, TEXAS 75265
Copyright 1997, Texas Instruments Incorporated
3–1
LM124, LM124A, LM224, LM224A
LM324Y
7 mV
LM2902DBLE
LM2902PWLE
LM324, LM324A, LM324Y, LM2902, LM2902Q QUADRUPLE OPERATIONAL AMPLIFIERS
SLOS066E– SEPTEMBER 1975 – REVISED FEBRUARY1997
AVAILABLE OPTIONS
PACKAGED DEVICES
T
0°C to
70°C
–25°C to
85°C
–40°C to
125°C
–55°C to 5 mV
125°C 2 mV
The D package is available taped and reeled. Add the suffix R to the device type (e.g., LM324DR).
The DB and PW packages are only available left-end taped and reeled.
VIOmax
A
AT 25°C
7 mV LM324D LM324DBLE LM324N LM324PWLE — 3 mV LM324AD LM324AN LM324APWLE — 5 mV LM224D LM224N — 3 mV LM224AD LM224AN
SMALL
OUTLINE
(D)
LM2902D LM2902QD
LM124FK LM124J — — LM124AFK LM124AJ
schematic (each amplifier)
VERY
SMALL
OUTLINE
(DB)
CHIP
CARRIER
(FK)
LM2902N — LM2902QN
CERAMIC
DIP
(J)
PLASTIC
DIP
(N)
TSSOP
(PW)
FLAT
PACK
(W)
— —
LM124W
CHIP
FORM
(Y)
V
CC
IN –
IN +
6-µA
Current
Regulator
6-µA
Current
Regulator
100-µA
Current
Regulator
50-µA
Current
Regulator
To Other Amplifiers
OUT
GND
3–2
COMPONENT COUNT
(total device)
Epi-FET Transistors Diodes Resistors Capacitors
POST OFFICE BOX 655303 DALLAS, TEXAS 75265
1
95
4
11
4
LM124, LM124A, LM224, LM224A
LM324, LM324A, LM324Y, LM2902, LM2902Q
QUADRUPLE OPERATIONAL AMPLIFIERS
SLOS066E– SEPTEMBER 1975 – REVISED FEBRUARY1997
LM324Y chip information
This chip, when properly assembled, displays characteristics similar to the LM324. Thermal compression or ultrasonic bonding may be used on the doped-aluminum bonding pads. Chips may be mounted with conductive epoxy or a gold-silicon preform.
BONDING PAD ASSIGNMENTS
V
(3) (2)
(7) (10)
(9) (14)
(11)
CC+
GND
(4)
(1) (5) (6)
(8)
(12) (13)
1OUT 2IN+
2IN– 3OUT
4IN+ 4IN–
62
(2)
(3)
(4)
(5)
(1)
(14)
(13)
(12)
(11)
(10)
1IN+ 1IN–
2OUT
3IN+ 3IN–
4OUT
CHIP THICKNESS: 15 TYPICAL
(6)
(7) (8)
65
(9)
BONDING PADS: 4 × 4 MINIMUM TJmax = 150°C TOLERANCES ARE ± 10%. ALL DIMENSIONS ARE IN MILS. PIN (11) IS INTERNALLY CONNECTED
TO BACKSIDE OF CHIP.
POST OFFICE BOX 655303 DALLAS, TEXAS 75265
3–3
