HPC3130A
PCI HOT PLUG CONTROLLER
SCPS055 – NOVEMBER 1999
1
POST OFFICE BOX 655303 • DALLAS, TEXAS 75265
D Compliant With PCI Hot-Plug Specification,
Revision 1.0
D Supports up to Four Independently
Controlled Hot-Plug Slots
D Provides Register Accessing Through Both
Generic Parallel Bus and Two-Wire Serial
Interface
D Provides Interrupt and Event Status/Enable
State Compliant With ACPI Specification
1.0
D Provides an Automatic Bus Connection
Sequencing Feature
D Supports 66-MHz PCI Clock Frequency
D Features Two Attention Indicators With
Variable LED Blinking Rates per Slot
D Provides an Easy Scheme to Cascade the
HPC3130A for Compact PCI Applications
D Provides Card Detection Mechanism
Independent of PCI Present Signals for
Advanced Card Protection
D Provides Path to Guarantee Idle State
During PCI Bus Connections
D Fabricated in Advanced Low-Power CMOS
Process
D Features a CBT Switch
†
Control Feature for
REQ64 Implementation
D Package Options:
– 120-pin QFP Package
– 128-pin LQFP Package
– 144-pin LQFP Package
Table of Contents
Description 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66 MHz PCI Support 24. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Functional Block Diagram 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Configuration and Control Registers 25. . . . . . . . . . . . . . . . . . . . . . . . .
Pin Assignments (120-Pin) 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Absolute Maximum Ratings 32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Pin Assignments (128-Pin) 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Recommended Operating Conditions 33. . . . . . . . . . . . . . . . . . . . . . . .
Pin Assignments (144-Pin) 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Serial Bus Interface 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Signal Name/Pin Number Sort Table (120-Pin) 6. . . . . . . . . . . . . . . . . Electrical Characteristics 34. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Signal Name/Pin Number Sort Table (128-Pin) 8. . . . . . . . . . . . . . . . . PCI Clock/Reset Timing Requirements 35. . . . . . . . . . . . . . . . . . . . . . .
Signal Name/Pin Number Sort Table (144-Pin) 10. . . . . . . . . . . . . . . . PCI Timing Requirements 36. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Terminal Functions 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Mechanical Data (120-Pin) 37. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
HPC3130A Applications 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Mechanical Data (128-Pin) 38. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
64-Bit Implementation 23. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Mechanical Data (144-Pin) 39. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
