DAC7512

DAC7512

DAC7512

SBAS156B – JULY 2002

Low-Power, Rail-to-Rail Output, 12-Bit Serial Input

DIGITAL-TO-ANALOG CONVERTER

FEATURES

● microPOWER OPERATION:

● POWER-DOWN: 200nA at 5V, 50nA at 3V

● POWER SUPPLY: +2.7V to +5.5V

●

TESTED MONOTONIC BY DESIGN

● POWER-ON RESET TO 0V

● THREE POWER-DOWN FUNCTIONS

● LOW POWER SERIAL INTERFACE WITH

SCHMITT-TRIGGERED INPUTS

● ON-CHIP OUTPUT BUFFER AMPLIFIER,

RAIL-TO-RAIL OPERATION

● SYNC INTERRUPT FACILITY

● SOT23-6 AND MSOP-8 PACKAGES

135µA at 5V

APPLICATIONS

● PORTABLE BATTERY-POWERED

INSTRUMENTS

● DIGITAL GAIN AND OFFSET

ADJUSTMENT

● PROGRAMMABLE VOLTAGE AND

CURRENT SOURCES

DESCRIPTION

The DAC7512 is a low-power, single, 12-bit buffered voltage
output Digital-to-Analog Converter (DAC). Its on-chip preci­sion output amplifier allows rail-to-rail output swing to be
achieved. The DAC7512 uses a versatile three-wire serial
interface that operates at clock rates up to 30MHz and is
compatible with standard SPI
DSP interfaces.

The reference for the DAC7512 is derived from the power
supply, resulting in the widest dynamic output range possible.
The DAC7512 incorporates a power-on reset circuit that
ensures that the DAC output powers up at 0V and remains
there until a valid write takes place in the device. The
DAC7512 contains a power-down feature, accessed over the
serial interface, that can reduce the current consumption of
the device to 50nA at 5V.

The low power consumption of this part in normal operation
makes it ideally suited to portable battery-operated equip­ment. The power consumption is 0.7mW at 5V reducing to
1µW in power-down mode.

The DAC7512 is available in a SOT23-6 package and an
MSOP-8 package.

SPI and QSPI are registered trademarks of Motorola.
Microwire is a registered trademark of National Semiconductor.

™

, QSPI™, Microwire™, and

SYNC

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of
Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas Instruments
standard warranty. Production processing does not necessarily include
testing of all parameters.

Power-On

Reset

DAC

Register

Input

Control

Logic

SCLK D

V

GND

DD

REF (+) REF (–)

12-Bit

DAC

Power-Down
Control Logic

IN

www.ti.com

Output

Buffer

V

OUT

Resistor
Network

Copyright © 2002, Texas Instruments Incorporated

ABSOLUTE MAXIMUM RATINGS

V

to GND ........................................................................... –0.3V to +6V

DD

Digital Input Voltage to GND .................................. –0.3V to +VDD + 0.3V

V

to GND ........................................................... –0.3V to +VDD + 0.3V

OUT

Operating Temperature Range ..................................... –40°C to +105°C

Storage Temperature Range ......................................... –65°C to +150°C

Junction Temperature Range (TJ max) ......................................... +150°C

SOT23 Package:

Power Dissipation .................................................. (TJ max — TA)/



Thermal Impedance .........................................................240°C/W

JA

Lead Temperature, Soldering:

Vapor Phase (60s) ............................................................... +215°C

Infrared (15s) ........................................................................ +220°C

MSOP Package:

Power Dissipation ........................................................ (T



Thermal Impedance .........................................................206°C/W

JA



Thermal Impedance ........................................................... 44°C/W

JC

Lead Temperature, Soldering:

Vapor Phase (60s) ............................................................... +215°C

Infrared (15s) ........................................................................ +220°C

NOTE: (1) Stresses above those listed under “Absolute Maximum Ratings”
may cause permanent damage to the device. Exposure to absolute maximum
conditions for extended periods may affect device reliability.

(1)

ELECTROSTATIC
DISCHARGE SENSITIVITY

This integrated circuit can be damaged by ESD. Texas Instru­ments recommends that all integrated circuits be handled with
appropriate precautions. Failure to observe proper handling
and installation procedures can cause damage.

ESD damage can range from subtle performance degradation
to complete device failure. Precision integrated circuits may be
more susceptible to damage because very small parametric
changes could cause the device not to meet its published
specifications.

max — TA)/

J



JA



JA

PACKAGE/ORDERING INFORMATION

MINIMUM

RELATIVE DIFFERENTIAL SPECIFIED

PRODUCT (LSB) (LSB) PACKAGE-LEAD DESIGNATOR

ACCURACY NONLINEARITY PACKAGE TEMPERATURE PACKAGE ORDERING TRANSPORT

DAC7512E ±8 ±1 MSOP-8 DGK –40°C to +105°C D12E DAC7512E/250 Tape and Reel, 250

"" " " " " "

DAC7512N ±8 ±1 SOT23-6 DBV –40°C to +105°C D12N DAC7512N/250 Tape and Reel, 250

"" " " " " "

NOTES: (1) For the most current specifications and package information, refer to our web site at www.ti.com. (2) Models with a slash (/) are available only in Tape
and Reel in the quantities indicated (e.g., /2K5 indicates 2500 devices per reel). Ordering 2500 pieces of “DAC7512E/2K5” will get a single 2500-piece Tape and Reel.

(1)

RANGE MARKING NUMBER

(1)

MEDIA, QUANTITY

DAC7512E/2K5 Tape and Reel, 2500

DAC7512N/3K Tape and Reel, 3000

PIN CONFIGURATIONS

Top View SOT23-6

1

V

OUT

2

GND

V

DD

V

NC

NC

V

OUT

DD

DAC7512

3

MSOP-8

1

2

DAC7512

3

4

NC = No Internal Connection

DAC7512N LOT TRACE LOCATION

Top View

D12N

PIN DESCRIPTION (SOT23-6)

PIN NAME DESCRIPTION

6

SYNC

5

SCLK

4

D

IN

8

GND

7

D

IN

6

SCLK

5

SYNC

Pin 1

1V

2 GND Ground reference point for all circuitry on the part.
3VDDPower Supply Input, +2.7V to 5.5V.
4DINSerial Data Input. Data is clocked into the 16-bit

5 SCLK Serial Clock Input. Data can be transferred at rates

6 SYNC Level triggered control input (active LOW). This is

Bottom View

OUT

Analog output voltage from DAC. The output ampli­fier has rail-to-rail operation.

input shift register on the falling edge of the serial
clock input.

up to 30MHz.

the frame sychronization signal for the input data.
When SYNC goes LOW, it enables the input shift
register and data is transferred in on the falling
edges of the following clocks. The DAC is updated
following the 16th clock cycle unless SYNC is taken
HIGH before this edge, in which case the rising
edge of SYNC acts as an interrupt and the write
sequence is ignored by the DAC7512.

YMLL

Pin 1

2

www.ti.com

Lot Trace Code

DAC7512

SBAS156B

ELECTRICAL CHARACTERISTICS

VDD = +2.7V to +5.5V; RL = 2ký to GND; CL = 200pF to GND.

DAC7512E, N

PARAMETER CONDITIONS MIN TYP MAX UNITS
STATIC PERFORMANCE

Resolution 12 Bits
Relative Accuracy ±8 LSB
Differential Nonlinearity Tested Monotonic by Design ±1 LSB
Zero Code Error All Zeroes Loaded to DAC Register +5 +20 mV
Full-Scale Error All Ones Loaded to DAC Register –0.15 –1.25 % of FSR
Gain Error ±1.25 % of FSR
Zero Code Error Drift –20 µV/°C
Gain Temperature Coefficient –5 ppm of FSR/°C

OUTPUT CHARACTERISTICS

Output Voltage Range 0V
Output Voltage Settling Time 1/4 Scale to 3/4 Scale Change

Slew Rate 1 V/µs

(1)

(2)

DD

(400

to C00H)810µs

R

L

H

= 2kΩ; 0pF < CL < 200pF

R

= 2kΩ; CL = 500pF 12 µs

L

V

Capacitive Load Stability R

Code Change Glitch Impulse 1LSB Change Around Major Carry 20 nV-s

= × 470 pF

L

R

= 2kΩ 1000 pF

L

Digital Feedthrough 0.5 nV-s
DC Output Impedance 1 Ω
Short-Circuit Current V

Power-Up Time Coming Out of Power-Down Mode

Coming Out of Power-Down Mode

LOGIC INPUTS

(2)

= +5V 50 mA

DD

V

= +3V 20 mA

DD

V

= +5V 2.5 µs

DD

V

= +3V 5 µs

DD

Input Current ±1 µA
V

L, Input Low Voltage VDD = +5V 0.8 V

IN

V

L, Input Low Voltage VDD = +3V 0.6 V

IN

V

H, Input High Voltage VDD = +5V 2.4 V

IN

V

H, Input High Voltage VDD = +3V 2.1 V

IN

Pin Capacitance 3pF

POWER REQUIREMENTS

V

DD

I

(normal mode)

DD

VDD = +3.6V to +5.5V VIH = VDD and VIL = GND 135 200 µA
V

= +2.7V to +3.6V VIH = VDD and VIL = GND 115 160 µA

DD

I

(all power-down modes)

DD

V

= +3.6V to +5.5V VIH = VDD and VIL = GND 0.2 1 µ A

DD

V

= +2.7V to +3.6V VIH = VDD and VIL = GND 0.05 1 µA

DD

DAC Active and Excluding Load Current

2.7 5.5 V

POWER EFFICIENCY

I

OUT/IDD

I

= 2mA. VDD = +5V 93 %

LOAD

TEMPERATURE RANGE

Specified Performance –40 +105 °C

NOTES: (1) Linearity calculated using a reduced code range of 48 to 4047; output unloaded. (2) Guaranteed by design and characterization, not production tested.

DAC7512

SBAS156B

www.ti.com

3

TIMING CHARACTERISTICS

(1, 2)

VDD = +2.7V to +5.5V; all specifications –40°C to +105°C, unless otherwise noted.

DAC7512E, N

PARAMETER DESCRIPTION CONDITIONS MIN TYP MAX UNITS

(3)

t

1

t

2

t

3

t

4

t

5

t

6

t

7

t

8

NOTES: (1) All input signals are specified with t
diagram, below. (3) Maximum SCLK frequency is 30MHz at V

SCLK Cycle Time

SCLK HIGH Time

SCLK LOW Time

SYNC to SCLK Rising

Edge Setup Time

Data Setup Time

Data Hold Time

SCLK Falling Edge to

SYNC Rising Edge

Minimum SYNC HIGH Time

V

= 2.7V to 3.6V 50 ns

DD

V

= 3.6V to 5.5V 33 ns

DD

V

= 2.7V to 3.6V 13 ns

DD

V

= 3.6V to 5.5V 13 ns

DD

V

= 2.7V to 3.6V 22.5 ns

DD

V

= 3.6V to 5.5V 13 ns

DD

V

= 2.7V to 3.6V 0 ns

DD

V

= 3.6V to 5.5V 0 ns

DD

V

= 2.7V to 3.6V 5 ns

DD

V

= 3.6V to 5.5V 5 ns

DD

V

= 2.7V to 3.6V 4.5 ns

DD

V

= 3.6V to 5.5V 4.5 ns

DD

V

= 2.7V to 3.6V 0 ns

DD

V

= 3.6V to 5.5V 0 ns

DD

V

= 2.7V to 3.6V 50 ns

DD

V

= 3.6V to 5.5V 33 ns

DD

= tF = 5ns (10% to 90% of VDD) and timed from a voltage level of (VIL + VIH)/2. (2) See Serial Write Operation timing

R

= +3.6V to +5.5V and 20MHz at VDD = +2.7V to +3.6V.

DD

SERIAL WRITE OPERATION

SCLK

t

SYNC

D

8

IN

t

4

DB15 DB0

t

1

t

t

3

t

6

t

5

2

t

7

4

www.ti.com

DAC7512

SBAS156B

TYPICAL CHARACTERISTICS: VDD = +5V

FULL-SCALE ERROR vs TEMPERATURE

–40

Error (mV)

Temperature (°C)

0 40 80 120

30

20

10

0

–10

–20

–30

TYPICAL TOTAL UNADJUSTED ERROR

0

TUE (LSBs)

CODE

200

H

400H600H800HA00HC00HE00HFFF

H

16

8

0

–8

–16

At TA = +25°C, +VDD = +5V, unless otherwise noted.

DIFFERENTIAL LINEARITY ERROR vs CODE

16.0

12.0

8.0

4.0

0.0

–4.0

LE (LSB)

–8.0
–12.0
–16.0

1.0

0.5

0.0

DLE (LSB)

–0.5

–1.0

0 200H400H600H800

DIFFERENTIAL LINEARITY ERROR vs CODE

16.0

12.0

8.0

4.0

0.0

–4.0

LE (LSB)

–8.0
–12.0
–16.0

1.0

0.5

0.0

DLE (LSB)

–0.5

–1.0

0 200H400H600H800

LINEARITY ERROR AND

(–40°C)

A00

H

H

CODE

LINEARITY ERROR AND

(+105°C)

A00

H

H

CODE

C00HE00HFFF

C00HE00HFFF

DIFFERENTIAL LINEARITY ERROR vs CODE

LINEARITY ERROR AND

(+25°C)

16.0

12.0

8.0

4.0

0.0

–4.0

LE (LSB)

–8.0
–12.0
–16.0

1.0

0.5

0.0

DLE (LSB)

–0.5

–1.0

H

0 200H400H600H800

A00

H

C00HE00HFFF

H

H

CODE

H

30

ZERO-SCALE ERROR vs TEMPERATURE

20

10

0

Error (mV)

–10

–20

–30

–40

0 40 80 120

DAC7512

SBAS156B

Temperature (°C)

www.ti.com

5

TYPICAL CHARACTERISTICS: VDD = +5V (Cont.)

At TA = +25°C, +VDD = +5V, unless otherwise noted.

3000

2500

2000

1500

Frequency

1000

500

0

500

400

300

(µA)

DD

I

200

100

5060708090

SUPPLY CURRENT vs CODE

IDD HISTOGRAM

100

110

120

130

IDD (µA)

140

150

160

170

180

190

(V)
V

(µA)
I

OUT

DD

300

250

200

150

100

5

SOURCE AND SINK CURRENT CAPABILITY

4

DAC Loaded with FFF

H

3

2

1

DAC Loaded with 000

H

0

0

51015

I

SOURCE/SINK

(mA)

SUPPLY CURRENT vs TEMPERATURE

50

300

0

0

200

400H600H800HA00HC00HE00HFFF

H

H

CODE

SUPPLY CURRENT vs SUPPLY VOLTAGE

0

–40

0 40 80 120

Temperature (°C)

POWER-DOWN CURRENT vs SUPPLY VOLTAGE

100

90

250

200

150

(µA)

DD

I

100

50

0

2.7

3.2 3.7 4.2 4.7 5.2 5.7
V

(V)

DD

(nA)

DD

I

80
70
60

+105°C

50
40

–40°C
30
20
10

+25°C

0

2.7

3.2 3.7 4.2 4.7 5.2 5.7
VDD (V)

6

www.ti.com

DAC7512

SBAS156B

TYPICAL CHARACTERISTICS: VDD = +5V (Cont.)

POWER-ON RESET TO 0V

Time (20µs/div)

Loaded with 2kΩ to V

DD

.

VDD (1V/div)

V

OUT

(1V/div)

HALF-SCALE SETTLING TIME

Time (1µs/div)

CLK (5V/div)

V

OUT

(1V/div)

Half-Scale Code Change

400

H

to C00

H

Output Loaded with

2kΩ and 200pF to GND

FULL-SCALE SETTLING TIME

CLK (5V/div)

V

OUT

(1V/div)

Time (1µs/div)

Full-Scale Code Change

000

H

to FFF

H

Output Loaded with

2kΩ and 200pF to GND

At TA = +25°C, +VDD = +5V, unless otherwise noted.

(µA)
I

DD

2500

2000

1500

1000

500

SUPPLY CURRENT vs LOGIC INPUT VOLTAGE

0

0

12345

V

(V)

LOGIC

FULL-SCALE SETTLING TIME

CLK (5V/div)

Full-Scale Code Change

FFF

to 000

H

Output Loaded with

2kΩ and 200pF to GND

H

V

(1V/div)

OUT

Time (1µs/div)

HALF-SCALE SETTLING TIME

CLK (5V/div)

Half-Scale Code Change

C00

to 400

H

Output Loaded with

H

2kΩ and 200pF to GND

V

(1V/div)

OUT

Time (1µs/div)

DAC7512

SBAS156B

www.ti.com

7
