Crystal or

Clock Input

GND

Vctr

DDOUT

S2/S1/S0or

SDA/SCL

VCXO

LVCMOS

CMOS

PLL1

withSSC

CMOS

PLL2

withSSC

CMOS

PLL3

withSSC

CMOS

PLL4

withSSC

Xin/Clk 1 24 Xout

S0 2 23 S1/SDA Vdd 3 22 S2/SCL Vctr 4 21 Y1

GND 5 20 GND

Vddout 6 19 Y2

Y4 7 18 Y3

Y5 8 17 Vddout

GND 9 16 Y6

Vddout 10 15 Y7

Y8 11 14 GND

Y9 12 13 Vdd

Divider

and Output Control

EEPROM

Programming

and

ControlRegister

Programmable 4-PLL VCXO Clock Synthesizer with 1.8V and 3.3V I/Os

CDCE949

CDCEL949

SCAS844 – JUNE 2007

FEATURES

• Member of Programmable Clock Generator

Family – CDCE949/CDCEL949: 4 PLLs, 9 Outputs – CDCE937/CDCEL937: 3 PLLs, 7 Outputs – CDCE925/CDCEL925: 2 PLLs, 5 Outputs – CDCE913/CDCEL913: 1 PLLs, 3 Outputs

• In-System Programmability and EEPROM

– Serial Programmable Volatile Register – Non-Volatile EEPROM to Store Customer

Settings

• Very Flexible Input Clocking Concept

– External Crystal: 8 to 32 MHz – On-Chip VCXO: Pull-Range ± 150 ppm – Single-Ended LVCMOS up to 160 MHz

• Selectable Output Frequency up to 230 MHz

• Very Low-Noise PLL Core

– Integrated PLL Loop Filter Components – Very Low Period Jitter (typ 60 ps)

• Highly Flexible Clock Driver

– Three User-Definable Control Inputs

[S0/S1/S2] e.g. SSC-Selection, Frequency

Switching, Output Enable or Power Down – Programmable SSC Modulation – Enables 0-PPM Clock Generation – Generates Common Clock Frequencies

Used with TI DaVinci™, OMAP™, DSPs – Generates Highly-Accurate Clocks for

Video, Audio, USB, IEEE1394, RFID,

BlueTooth™, WLAN, Ethernet and GPS

• 1.8 V Device Power Supply

• Separate Output Supply Pins

– CDCE949: 3.3 V and 2.5 V – CDCEL949: 1.8 V

• Wide Temperature Range –40 ° C to 85 ° C

• Packaged in TSSOP

• Development and Programming Kit for Ease

PLL Design and Programming (TI-Pro Clock)

APPLICATIONS

• D-TV, HD-TV, STB, IP-STB, DVD-Player,

DVD-Recorder, Printer

• General Purpose Frequency Synthesizing

Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.

DaVinci, OMAP, Pro Clock are trademarks of Texas Instruments. BlueTooth is a trademark of Bluetooth SIG, Inc. I2C is a trademark of Philips Electronics.

PRODUCTION DATA information is current as of publication date. Products conform to specifications per the terms of the Texas Instruments standard warranty. Production processing does not necessarily include testing of all parameters.

www.ti.com

CDCE949 CDCEL949

SCAS844 – JUNE 2007

These devices have limited built-in ESD protection. The leads should be shorted together or the device placed in conductive foam during storage or handling to prevent electrostatic damage to the MOS gates.

DESCRIPTION

The CDCE949 and CDCEL949 are modular PLL-based low cost, high-performance, programmable clock synthesizers, multipliers and dividers. They generate up to 9 output clocks from a single input frequency. Each output can be programmed in-system for any clock frequency up to 230 MHz, using up to four independent configurable PLLs.

The CDCx949 has separate output supply pins, V CDC E949.

The input accepts an external crystal or LVCMOS clock signal. If an external crystal is used, an on-chip load capacitor is adequate for most applications. The value of the load capacitor is programmable from 0 to 20 pF. Additionally, an on-chip VCXO is selectable, allowing synchronization of the output frequency to an external control signal, i.e. a PWM signal.

The deep M/N divider ratio allows the generation of zero-ppm audio/video, networking (WLAN, BlueTooth™, Ethernet, GPS) or Interface (USB, IEEE1394, Memory Stick) clocks from a reference input frequency such as 27-MHz.

All PLLs support SSC (Spread-Spectrum Clocking). SSC can be Center-Spread or Down-Spread clocking. This is a common technique to reduce electro-magnetic interference (EMI).

Based on the PLL frequency and the divider settings, the internal loop-filter components are automatically adjusted to achieve high stability, and to optimize the jitter-transfer characteristics of each PLL.

The device supports non-volatile EEPROM programming for easy customization of the device to the application. It is preset to a factory-default configuration (see the Default Device Configuration section). It can be reprogrammed to a different application configuration before PCB assembly, or reprogrammed by in-system programming. All device settings are programmable through the SDA/SCL bus, a 2-wire serial interface.

Three programmable control inputs, S0, S1 and S2, can be used to control various aspects of operation including frequency selection, changing the SSC parameters to lower EMI, PLL bypass, power down, and choosing between low level or 3-state for the output-disable function.

The CDCx949 operates in a 1.8-V environment. It is characterized for operation from –40 ° C to 85 ° C.

, 1.8 V for the CDC EL949, and 2.5 V to 3.3 V for

DDOUT

DEVICE INFORMATION

TERMINAL FUNCTIONS

TERMINAL

NAME NO. (TSSOP24)

Y1, Y2, ...Y9 O LVCMOS outputs Xin/CLK 1 I Crystal oscillator input or LVCMOS clock input (selectable via SDA/SCL bus)

Xout 24 O Crystal oscillator output (leave open or pull up when not used) V

Ctrl

DDOUT

GND 5, 9, 14, 20 Ground Ground S0 2 I User-programmable control input S0; LVCMOS inputs; internal pull-up 500 k Ω

SDA / S1 23 I/O / I pull-up 500 k Ω ; or

SCL / S2 22 I

21, 19, 18, 7, 8,

16, 15, 11, 12

4 I VCXO control voltage (leave open or pull up when not used)

3, 13 Power 1.8V power supply for the device

6, 10, 17 Power

I/O

CDCEL949: 1.8 V supply for all outputs CDCE949: 3.3 V or 2.5 V supply for all outputs

SDA: Bi-directional serial data input/output (default configuration), LVCMOS; internal S1: User-programmable control input; LVCMOS inputs; internal pull-up 500 k Ω

SCL: Serial clock input (default configuration), LVCMOS; internal pull-up 500 k Ω ; or S2: User-programmable control input; LVCMOS inputs; internal pull-up 500 k Ω

Submit Documentation Feedback

www.ti.com

EEPROM

Xin/CLK

Xout

GND

Vctr

DDOUT

VCXO

LVCMOS

CMOS

Pdiv1

10-Bit

CMOS

Pdiv9

7-Bit

Pdiv8

7-Bit

CMOS

Pdiv7

7-Bit

Pdiv6

7-Bit

CMOS

Pdiv5

7-Bit

Pdiv4

7-Bit

CMOS

Pdiv3

7-Bit

Pdiv2

7-Bit

CMOS

Programming

and

SDA/SCL

InputClock

PLL Bypass

PLL 1

withSSC

MUX1

PLL Bypass

PLL 2

withSSC

MUX2

PLL Bypass

PLL 3

withSSC

MUX3

PLL Bypass

PLL 4

withSSC

S0 S1/SDA S2/SCL

FUNCTIONAL BLOCK DIAGRAM

CDCE949

CDCEL949

SCAS844 – JUNE 2007

ABSOLUTE MAXIMUM RATINGS

over operating free-air temperature range (unless otherwise noted)

V V V I

stg

(1) Stresses beyond those listed under absolute maximum ratings may cause permanent damage to the device. These are stress ratings

(2) The input and output negative voltage ratings may be exceeded if the input and output clamp–current ratings are observed.

Supply voltage range –0.5 to 2.5 V

Input voltage range

Output voltage range

Input current (Vi< 0, Vi> VDD) 20 mA Continuous output current 50 mA Storage temperature range –65 to 150 ° C Maximum junction temperature 125 ° C

only and functional operation of the device at these or any other conditions beyond those indicated under recommended operating conditions is not implied. Exposure to absolute–maximum–rated conditions for extended periods may affect device reliability.

(2)

Submit Documentation Feedback

(1)

VALUE UNIT

–0.5 to V

+ 0.5 V

DDOUT

www.ti.com

CDCE949 CDCEL949

SCAS844 – JUNE 2007

THERMAL RESISTANCE FOR TSSOP (PW) PACKAGE

PARAMETER

Thermal Resistance Junction to Ambient

Thermal Resistance Junction to Case — 26

(1) The package thermal impedance is calculated in accordance with JESD 51 and JEDEC2S2P (high-k board).

RECOMMENDED OPERATING CONDITIONS

V V V

IOH/I

C T

DD(OUT)

IL IH I(thresh)

ICLK

Device supply voltage 1.7 1.8 1.9 V Output Yx supply

voltage

CDCE949 2.3 3.6

CDCEL949 1.7 1.9 Low level input voltage LVCMOS 0.3 × V High level input voltage LVCMOS 0.7 × V Input voltage threshold LVCMOS 0.5 × V Input voltage range S0 0 1.9 Input voltage range S1, V

S2, SDA, SCL

= 0.5 V

Ithresh

Input voltage range CLK 0 1.9 V

= 3.3 V ± 12 mA

DDout

Output current V

= 2.5 V ± 10 mA

DDout

= 1.8 V ± 8 mA

DDout

Output load LVCMOS 10 pF Operating free-air temperature –40 85 ° C

(1)

AIRFLOW TSSOP24

(lfm) ° C/W

0 85 150 80 250 78 500 76

MIN NOM MAX UNIT

0 3.6

V V V

RECOMMENDED CRYSTAL/VCXO SPECIFICATIONS

(1)

MIN NOM MAX UNIT

Xtal

Crystal Input frequency range (fundamental mode) 8 27 32 MHz ESR Effective series resistance 100 Ω f

(Ctrl)

C0/C C

Pulling range (0 V ≤ V

Ctrl

Frequency control voltage 0 V

Pullability ratio 220

On-chip load capacitance at Xin and Xout 0 20 pF

≤ 1.8 V)

(2)

± 120 ± 150 ppm

(1) For more information about VCXO configuration and crystal recommendation see application report SCAA085 . (2) Pulling range depends on crystal type, on-chip crystal load capacitance and PCB stray capacitance; pulling range of min ± 120 ppm

applies for crystal listed in the application report SCAA085 .

EEPROM SPECIFICATION

MIN TYP MAX UNIT

EEcyc EEcyc programming cycles of EEPROM 1000 cycles EEret EEret data retention 10 years

Submit Documentation Feedback

www.ti.com

TIMING REQUIREMENTS

over recommended ranges of supply voltage, load and operating free-air temperature

CLK_IN Requirements MIN NOM MAX UNIT

tr/ t duty

f t t t t t t t t t t

(CLK)

CLK

LVCMOS clock input frequency MHz

Rise and fall time CLK signal (20% to 80%) 3 ns Duty cycle CLK at V

/ 2 40% 60%

SDA/SCL TIMING REQUIREMENTS (see Figure 12 ) UNIT

(SCL) su(START) h(START) w(SCLL) w(SCLH) h(SDA) su(SDA) r f su(STOP) BUF

SCL clock frequency 0 100 0 400 kHz START setup time (SCL high before SDA low) 4.7 0.6 μ s START hold time (SCL low after SDA low) 4 0.6 μ s SCL low-pulse duration 4.7 1.3 μ s SCL high-pulse duration 4 0.6 μ s SDA hold time (SDA valid after SCL low) 0 3.45 0 0.9 μ s SDA setup time 250 100 ns SCL/SDA input rise time 1000 300 ns SCL/SDA input fall time 300 300 ns STOP setup time 4.0 0.6 μ s Bus free time between a STOP and START condition 4.7 1.3 μ s

PLL Bypass Mode 0 160 PLL Mode 8 160

CDCE949

CDCEL949

SCAS844 – JUNE 2007

STANDARD FAST

MODE MODE

MIN MAX MIN MAX

DEVICE CHARACTERISTICS

over recommended operating free-air temperature range (unless otherwise noted)

PARAMETER TEST CONDITIONS MIN TYP

OVERALL PARAMETER

DD(OUT)

DD(PD)

V f

VCO

OUT

Supply current (see Figure 3 ) mA

Supply current (see Figure 4 and No load, all outputs on,

Figure 5 ) f

Power down current. Every circuit powered down except SDA/SCL

Supply voltage Vdd threshold for power

(PUC)

up control circuit VCO frequency range of PLL 80 230 MHz LVCMOS output frequency 230 MHz

LVCMOS PARAMETER

V I

LVCMOS input voltage VDD = 1.7 V; II = –18 mA –1.2 V

LVCMOS input current VI= 0 V or VDD; V LVCMOS input current for S0/S1/S2 VI= VDD; V LVCMOS input current for S0/S1/S2 VI= 0 V; V Input capacitance at Xin/Clk V

Input capacitance at Xout V

Input capacitance at S0/S1/S2 VIS= 0 V or V

(1) All typical values are at respective nominal VDD.

All outputs off, f MHz, f

out

= 135 MHz;

VCO

= 27 MHz

fIN= 0 MHz, V

= 0 V or V

ICLK

= 0 V or V

IXout

= 27

CLK

= 1.9 V 50 μ A

= 1.9 V ± 5 μ A

= 1.9 V 5 μ A

= 1.9 V –4 μ A

All PLLs on 38 Per PLL 9 CDCE949

=3.3 V

DDOUT

CDCEL949 V

=1.8 V

DDOUT

0.85 1.45 V

(1)

MAX UNIT

6 2 pF 3

Submit Documentation Feedback

www.ti.com

CDCE949 CDCEL949

SCAS844 – JUNE 2007

DEVICE CHARACTERISTICS (Continued)

over recommended operating free-air temperature range (unless otherwise noted)

PARAMETER TEST CONDITIONS MIN TYP

CDCE949 – LVCMOS PARAMETER FOR V

PLH

PHL

tr/t

jit(cc)

jit(per)

sk(o)

odc Output duty cycle

LVCMOS high-level output voltage V

LVCMOS low-level output voltage V

Propagation delay PLL bypass 3.2 ns Rise and fall time V

Cycle-to-cycle jitter

Peak-to-peak period jitter

Output skew

(2) (3)

(4)

(5)

CDCE949 – LVCMOS PARAMETER FOR V

PLH

PHL

tr/t

jit(cc)

jit(per)

sk(o)

odc Output duty cycle

LVCMOS high-level output voltage V

LVCMOS low-level output voltage V

Propagation delay PLL bypass 3.4 ns Rise and fall time V

Cycle-to-cycle jitter

Peak-to-peak period jitter

Output skew

(2) (3)

(4)

(5)

= 3.3 V – MODE

DDOUT

= 3 V, IOH= –0.1 mA 2.9

DDOUT

= 3 V, IOH= –8 mA 2.4 V

DDOUT

= 3 V, IOH= –12 mA 2.2

DDOUT

= 3 V, IOL= 0.1 mA 0.1

DDOUT

= 3 V, IOL= 8 mA 0.5 V

DDOUT

= 3 V, IOL= 12 mA 0.8

DDOUT

= 3.3 V (20%–80%) 0.6 ns

DDOUT

1 PLL switching, Y2-to-Y3 60 90 4 PLLs switching, Y2-to-Y9 120 170 1 PLL switching, Y2-to-Y3 70 100 4 PLLs switching, Y2-to-Y9 130 180 f

= 50 MHz; Y1-to-Y3 60

OUT

= 50 MHz; Y2-to-Y5 or Y6-to-Y9 160

OUT

= 100 MHz; Pdiv = 1 45 55 %

VCO

= 2.5 V – MODE

DDOUT

= 2.3 V, IOH= –0.1 mA 2.2

DDOUT

= 2.3 V, IOH= –6 mA 1.7 V

DDOUT

= 2.3 V, IOH= –10 mA 1.6

DDOUT

= 2.3 V, IOL= 0.1 mA 0.1

DDOUT

= 2.3 V, IOL= 6 mA 0.5 V

DDOUT

= 2.3 V, IOL= 10 mA 0.7

DDOUT

= 2.5 V (20%–80%) 0.8 ns

DDOUT

1 PLL switching, Y2-to-Y3 60 90 ps 4 PLLs switching, Y2-to-Y9 120 170 1 PLL switching, Y2-to-Y3 70 100 ps 4 PLLs switching, Y2-to-Y9 130 180 f

= 50 MHz; Y1-to-Y3 60

OUT

= 50 MHz; Y2-to-Y5 or Y6-to-Y9 160

OUT

= 100 MHz; Pdiv = 1 45 55 %

VCO

(1) All typical values are at respective nominal VDD. (2) 10000 cycles. (3) Jitter depends on device configuration. Data is taken under the following conditions: 1-PLL: fIN= 27 MHz, Y2/3 = 27 MHz, (measured at

Y2), 4-PLL: fIN= 27 MHz, Y2/3 = 27 MHz, (manured at Y2), Y4/5 = 16.384 MHz, Y6/7 = 74.25 MHz, Y8/9 = 48 MHz.

(4) The t

sampled on rising edge (tr).

specification is only valid for equal loading of each bank of outputs and outputs are generated from the same divider; data

sk(o)

(5) odc depends on output rise- and fall-time (tr/tf).

(1)

MAX UNIT

Submit Documentation Feedback

www.ti.com

10pF

1kW

LVCMOS

CDCE949

CDCEL949

1kW

LVCMOS LVCMOS

CDCE949

CDCEL949

Driver

Impedance

~50 W

LineImpedance

Zo=50 W

Series

Termination

(Optional)

CDCE949

CDCEL949

SCAS844 – JUNE 2007

DEVICE CHARACTERISTICS (Continued)

over recommended operating free-air temperature range (unless otherwise noted)

PARAMETER TEST CONDITIONS MIN TYP

SAVE THIS CDCEL949 – LVCMOS PARAMETER FOR V

DDOUT

PLH

PHL

tr/t

jit(cc)

jit(per)

sk(o)

odc Output duty cycle

LVCMOS high-level output voltage V

LVCMOS low-level output voltage V

Propagation delay PLL bypass 2.6 ns Rise and fall time V

Cycle-to-cycle jitter

Peak-to-peak period jitter

Output skew

(2) (3)

(4)

(5)

DDOUT

DDOUT DDOUT

DDOUT

1 PLL switching, Y2-to-Y3 70 120 ps 4 PLLs switching, Y2-to-Y9 120 170 1 PLL switching, Y2-to-Y3 90 140 ps 4 PLLs switching, Y2-to-Y9 130 190 f

OUT

VCO

= 50 MHz; Y1-to-Y3 60 ps = 50 MHz; Y2-to-Y5 or Y6-to-Y9 160 = 100 MHz; Pdiv = 1 45 55 %

= 1.8 V – MODE

DDOUT

= 1.7 V, IOH= –0.1 mA 1.6 = 1.7 V, IOH= –4 mA 1.4 V = 1.7 V, IOH= –8 mA 1.1 = 1.7 V, IOL= 0.1 mA 0.1 = 1.7 V, IOL= 4 mA 0.3 V = 1.7 V, IOL= 8 mA 0.6

= 1.8 V (20%–80%) 0.7 ns

SDA/SCL PARAMETER

V I

V V

V C

SCL and SDA input clamp voltage V

SCL and SDA input current VI= VDD; V SDA/SCL input high voltage

SDA/SCL input low voltage

SDA low-level output voltage IOL= 3 mA, V

SCL/SDA input capacitance VI= 0 V or V

(6)

= 1.7 V; II= –18 mA –1.2 V

= 1.9 V ± 10 μ A

0.7 V

= 1.7 V V

Y2), 4-PLL: fIN= 27 MHz, Y2/3 = 27 MHz, (measured at Y2), Y4/5 = 16.384 MHz, Y6/7 = 74.25 MHz, Y8/9 = 48 MHz.

(4) The t

sampled on rising edge (tr).

specification is only valid for equal loading of each bank of outputs and outputs are generated from same divider; data

sk(o)

(5) odc depends on output rise- and fall-time (tr/tf). (6) SDA and SCL pins are 3.3-V tolerant.

(1)

MAX UNIT

0.3

0.2

3 10 pF

V V

PARAMETER MEASUREMENT INFORMATION

Figure 1. Test Load Figure 2. Test Load for 50 Ω Board Environment

Submit Documentation Feedback

www.ti.com

100

10 60 110 160 210

PLL -Frequency-MHz

-SupplyCurrent-mA

3PLL on

V =1.8V

allPLL off

1PLL on

4PLL on

2PLL on

10 30 50 70 90 110 130 150 170 190 210 230

f -OutputFrequency-MHz

OUT

I -mA

DOUT

alloutputsoff

9outputson

7outputson

5outputson

3outputson

1outputon

V =1.8V, V =3.3V, NoLoad

DDOUT

10 30 50 70 90 110 130 150 170 190 210 230

f -OutputFrequency-MHz

OUT

I -mA

DOUT

alloutputsoff

9outputson

7outputson

5outputson

3outputson

1outputon

V =1.8V, V =1.8V, NoLoad

DDOUT

CDCE949 CDCEL949

SCAS844 – JUNE 2007

TYPICAL CHARACTERISTICS

CDCE949 AND CDCEL949 SUPPLY CURRENT CDCE949 OUTPUT CURRENT

vs vs

PLL FREQUENCY OUTPUT FREQUENCY

Figure 3. Figure 4.

CDCEL949 OUTPUT CURRENT

OUTPUT FREQUENCY

Figure 5.

Submit Documentation Feedback

www.ti.com

APPLICATION INFORMATION

Control Terminal Configuration

The CDCE949/CDCEL949 has three user-definable control terminals (S0, S1 and S2) which allow external control of device settings. They can be programmed to perform any of the following functions:

• Spread-Spectrum Clocking selection: Spread-type and spread-amount selection

• Frequency selection: Switching between any of two user-defined frequencies

• Output-State selection: Output configuration and power-down control

The user can predefine up to eight different control settings. Table 1 and Table 2 explain these settings.

Table 1. Control Terminal Definition

External Control-Bits PLL1 Setting PLL2 Setting PLL3 Setting PLL4 Setting Y1 Setting

Control Function

CDCE949

CDCEL949

SCAS844 – JUNE 2007

SSC Selection

PLL Frequency Selection

Output Y2/Y3 Selection

SSC Selection

PLL Frequency Selection

Output Y4/Y5 Selection

PLL Frequency Selection

SSC Selection

Output Y6/Y7 Selection

PLL Frequency Selection

SSC Selection

Table 2. PLLx Setting (can be selected for each PLL individual)

SSC Selection (Center/Down)

SSCx [3-bits] Center Down

0 0 0 0% (off) 0% (off) 0 0 1 ± 0.25% –0.25% 0 1 0 ± 0.5% –0.5% 0 1 1 ± 0.75% –0.75% 1 0 0 ± 1.0% –1.0% 1 0 1 ± 1.25% –1.25% 1 1 0 ± 1.5% –1.5% 1 1 1 ± 2.0% –2.0%

FREQUENCY SELECTION

FSx FUNCTION

0 Frequency0 1 Frequency1

OUTPUT SELECTION

YxYx FUNCTION

0 State0 1 State1

(1) Center/Down-Spread, Frequency0/1 and State0/1 are user-definable in PLLx Configuration Register; (2) Frequency0 and Frequency1 can be any frequency within the specified f (3) State0/1 selection is valid for both outputs of the corresponding PLL module and can be power down,

3-state, low or active

(2)

(3)

(Y2 ... Y9)

range.

VCO

Output Y8/Y9 Selection

Output Y1 and Power Down Selection

(1)

Submit Documentation Feedback

EEPROM

Xin

Xout

GND

DDOUT

X-tal

Y2=27MHz

Y1=27MHz

Y3=27MHz

CMOS

Pdiv1=1

Y4=27MHz

Y5=27MHz

Y6=27MHz

Y7=27MHz

Y8=27MHz

Y9=27MHz

CMOS

Pdiv9=1

Pdiv8=1

CMOS

Pdiv7=1

Pdiv6=1

CMOS

Pdiv5=1

Pdiv4=1

CMOS

Pdiv3=1

Pdiv2=1

CMOS

Programming

and

SDA/SCL

InputClock

PLL Bypass

PLL 1

powerdown

MUX1

PLL Bypass

PLL 2

powerdown

MUX2

PLL Bypass

PLL 3

powerdown

MUX3

PLL Bypass

PLL 4

powerdown

MUX4

SDA

SCL

27MHz

Crystal

ProgrammingBus

“1” =outputsenabled

“0” =outputs3-State

CDCE949 CDCEL949

SCAS844 – JUNE 2007

Table 3. Y1 Setting

Y1 SELECTION

Y1 FUNCTION

0 State 0 1 State 1

(1) State0 and State1 are user-definable in Generic Configuration

The S1/SDA and S2/SCL pins of the CDCE949/CDCEL949 are dual-function pins. In the default configuration they are defined as SDA/SCL for the serial interface. They can be programmed as control pins (S1/S2) by setting the appropriate bits in the EEPROM. Note that changes to the Control register (Bit [6] of Byte 02) have no effect until they are written into the EEPROM.

Once they are set as control pins, the serial programming interface is no longer available. However, if V forced to GND, the two control-pins, S1 and S2, temporarily act as serial programming pins (SDA/SCL).

S0 is not a multi-use pin, it is a control pin only.

DEFAULT DEVICE SETTING

The internal EEPROM of CDCE949/CDCEL949 is preconfigured as shown in Figure 6 . (The input frequency is passed through to the output as a default.) This allows the device to operate in default mode without the extra production step of programming it. The default setting appears after power is supplied or after a power-down/up sequence until it is reprogrammed by the user to a different application configuration. A new register setting is programmed via the serial SDA/SCL Interface.

(1)

DDOUT

A different default setting can be programmed upon customer request. Contact Texas Instruments sales or

Figure 6. Default Configuration

marketing representative for more information.

Table 4 shows the default setting for the Control Terminal Register (external control pins). In normal operation,

all 8 register settings are available, but in the default configuration only the first two settings (0 and 1) can be selected with S0, as S1 and S2 are configured as programming pins in default mode.

Submit Documentation Feedback

CDCE949

CDCEL949

SCAS844 – JUNE 2007

Table 4. Factory Default Setting for Control Terminal Register

EXTERNAL

CONTROL-PINS

S2 S1 S0 Y1 FS1 SSC1 Y2Y3 FS2 SSC2 Y4Y5 FS3 SSC3 Y6Y7 FS4 SSC4 Y8Y9

SCL (I2C) SDA (I2C) SCL (I2C) SDA (I2C)

(1) In default mode or when programmed respectively, S1 and S2 act as a serial programming interface, SDA/SCL. In this mode, they have

no control-pin function, but are internally interpreted as if S1=0 and S2=0. S0, however, is a control-pin which in the default mode switches all outputs ON or OFF (as pre-defined above).

(1)

SDA/SCL SERIAL INTERFACE

The CDCE949/CDCEL949 operates as a slave device on the 2-wire serial SDA/SCL bus, compatible with the popular SMBus or I2C™ specification. It operates in the standard-mode transfer (up to 100 kbps) and fast-mode transfer (up to 400 kbps) and supports 7-bit addressing.

The S1/SDA and S2/SCL pins of the CDC9xx are dual-function pins. In the default configuration they are used as SDA/SCL serial programming interface. They can be reprogrammed as general purpose control pins, S1 and S2, by changing the corresponding EEPROM setting, Byte 02, Bit [6].

DATA PROTOCOL

The device supports Byte Write and Byte Read and Block Write and Block Read operations. For Byte Write/Read operations, the system controller can individually access addressed bytes. For Block Write/Read operations, the bytes are accessed in sequential order from lowest to highest byte (with

most significant bit first) with the ability to stop after any complete byte has been transferred. The number of bytes read out is defined by the Byte Count field in the Generic Configuration Register. During a Block Read instruction, the entire number of bytes defined in Byte Count must be read out to correctly finish the read cycle.

When a byte is sent to the device, it is written into the internal register and immediately takes effect. This applies to each transferred byte, whether in a Byte Write or a Block Write sequence.

If the EEPROM Write Cycle is initiated, the internal SDA register contents are written into the EEPROM. During this write cycle, data is not accepted at the SDA/SCL bus until the write cycle is completed. However, data can be read during the programming sequence (Byte Read or Block Read). The programming status can be monitored by reading EEPIP, Byte 01–Bit [6].

The offset of the indexed byte is encoded in the command code, as described in Table 6 .

Y1 PLL1 SETTING PLL2 SETTING PLL3 SETTING PLL4 SETTING

Output Freq. SSC Output Freq. SSC Output Freq. SSC Output Freq. SSC Output

Select Select Sel. Select Select Sel. Select Select Sel. Select Select Sel. Select

0 3-State f 1 enabled f

VCO1_0

off 3-State f off enabled f

VCO2_0

off 3-State f off enabled f

VCO3_0

off 3-State f off enabled f

VCO4_0

off 3-State off enabled

Table 5. Slave Receiver Address (7 bits)

Device A6 A5 A4 A3 A2 A1

CDCE913/CDCEL913 1 1 0 0 1 0 1 1/0 CDCE925/CDCEL925 1 1 0 0 1 0 0 1/0 CDCE937/CDCEL937 1 1 0 1 1 0 1 1/0

CDCE949/CDCEL949 1 1 0 1 1 0 0 1/0

(1) Address bits A0 and A1 are programmable via the SDA/SCL bus (Byte 01, Bit [1:0]. This allows addressing up to 4 devices connected to

the same SDA/SCL bus. The least significant bit of the address byte designates a write or read operation.

Submit Documentation Feedback

(1)

R/ W

1 7 1 1 8 1 1

S Slave Address A DataByte A P

MSB LSB MSB LSB

S StartCondition

Sr RepeatedStartCondition

1=Read(Rd)fromCDCE9xxdevice;0=Write(Wr)totheCDCE9xxx

A Acknowledg(ACK=0andNACK=1)

P StopCondition

MastertoSlave Transmission

SlavetoMaster Transmission

R/W

1 7 1 1 8 1 1 1

S Slave Address Wr A A A PDataByteCommandCode

1 7 1 1 1 1 1 1

S Slave Address Wr A A S Rd A

8 1 1

DataByte A P

CommandCode

8 7

Slave Address

1 7 1 1 1 1

S Slave Address Wr A A A

8 1 1 1 1

DataByte0 A A A P

DataByteN-1…

DataByte1

CommandCode ByteCount=N

CDCE949 CDCEL949

SCAS844 – JUNE 2007

Table 6. Command Code Definition

BIT DESCRIPTION

(6:0) Byte Offset for Byte Read, Block Read, Byte Write and Block Write operation.

Generic Programming Sequence

0 = Block Read or Block Write operation 1 = Byte Read or Byte Write operation

Byte Write Programming Sequence

Byte Read Programming Sequence

Block Write Programming Sequence

Figure 7. Generic Programming Sequence

Figure 8. Byte Write Protocol

Figure 9. Byte Read Protocol

NOTE: Data Byte 0 Bits [7:0] is reserved for Revision Code and Vendor Identification. Also it is used for internal test purpose

and should not be overwritten.

Figure 10. Block Write Programming

Submit Documentation Feedback

Block Read Programming Sequence

1 7 1 1 1 1 1 1

S Slave Address Wr A A Sr Rd A

8 1 1 1 1

ByteCountN A A A PDataByte0 … DataByteN-1

CommandCode

Slave Address

8 8

P S P

(BUS)

w(SCLL)tw(SCLH)

h(START)

SU(SDA)

h(SDA)

SU(STOP)

SU(START)

SCL

SDA

Bit7(MSB)

Bit6 Bit0(LSB)

Master

SDA

SCL

BUS

Slave

CDCE949

CDCEL949

BUS

Figure 11. Block Read Protocol

Timing Diagram for the SDA/SCL Serial Control Interface

CDCE949

CDCEL949

SCAS844 – JUNE 2007

Figure 12. Timing Diagram for the SDA/SCL Serial Control Interface

SDA/SCL Hardware Interface

Figure 13 shows how the CDCE949/CDCEL949 clock synthesizer is connected to the SDA/SCL serial interface

bus. Multiple devices can be connected to the bus but the speed may need to be reduced (400 kHz is the maximum) if many devices are connected.

Note that the pull-up resistor value (R connected devices. The recommended pull-up value is 4.7 k Ω . It must meet the minimum sink current of 3 mA at V

= 0.4 V for the output stages (for more details see the SMBus or I2C Bus specification).

OLmax

) depends on the supply voltage, bus capacitance and number of

Figure 13. SDA/SCL Hardware Interface

Submit Documentation Feedback

CDCE949 CDCEL949

SCAS844 – JUNE 2007

SDA/SCL CONFIGURATION REGISTERS

The clock input, control pins, PLLs and output stages are user configurable. The following tables and explanations describe the programmable functions of the CDCE949/CDCEL949. All settings can be manually written to the device via the SDA/SCL bus, or are easily programmable by using the TI Pro Clock software. TI Pro Clock software allows the user to quickly make all settings and automatically calculates the values for optimized performance at lowest jitter.

Table 7. SDA/SCL Registers

ADDRESS OFFSET REGISTER DESCRIPTION TABLE

00h Generic Configuration Register Table 9 10h PLL1 Configuration Register Table 10 20h PLL2 Configuration Register Table 11 30h PLL3 Configuration Register Table 12 40h PLL4 Configuration Register Table 13

The grey-highlighted Bits described in the Configuration Registers tables on the following pages, belong to the Control Terminal Register. The user can predefine up to eight different control settings. These settings can then be selected by the external control pins, S0, S1, and S2 (See the Control Terminal Configuration section).

Table 8. Configuration Register, External Control Terminals

EXTERNAL

CONTROL

PINS

S2 S1 S0 Y1 FS1 SSC1 Y2Y3 FS2 SSC2 Y4Y5 FS3 SSC3 Y6Y7 FS4 SSC4 Y8Y9

0 0 0 Y1_0 FS1_0 SSC1_0 Y2Y3_0 FS2_0 SSC2_0 Y4Y5_0 FS3_0 SSC3_0 Y6Y7_0 FS4_0 SSC4_0 Y8Y9_0 0 0 1 Y1_1 FS1_1 SSC1_1 Y2Y3_1 FS2_1 SSC2_1 Y4Y5_1 FS3_1 SSC3_1 Y6Y7_1 FS4_1 SSC4_1 Y8Y9_1 0 1 0 Y1_2 FS1_2 SSC1_2 Y2Y3_2 FS2_2 SSC2_2 Y4Y5_2 FS3_2 SSC3_2 Y6Y7_2 FS4_2 SSC4_2 Y8Y9_2 0 1 1 Y1_3 FS1_3 SSC1_3 Y2Y3_3 FS2_3 SSC2_3 Y4Y5_3 FS3_3 SSC3_3 Y6Y7_3 FS4_3 SSC4_3 Y8Y9_3 1 0 0 Y1_4 FS1_4 SSC1_4 Y2Y3_4 FS2_4 SSC2_4 Y4Y5_4 FS3_4 SSC3_4 Y6Y7_4 FS4_4 SSC4_4 Y8Y9_4 1 0 1 Y1_5 FS1_5 SSC1_5 Y2Y3_5 FS2_5 SSC2_5 Y4Y5_5 FS3_5 SSC3_5 Y6Y7_5 FS4_5 SSC4_5 Y8Y9_5 1 1 0 Y1_6 FS1_6 SSC1_6 Y2Y3_6 FS2_6 SSC2_6 Y4Y5_6 FS3_6 SSC3_6 Y6Y7_6 FS4_6 SSC4_6 Y8Y9_6 1 1 1 Y1_7 FS1_7 SSC1_7 Y2Y3_7 FS2_7 SSC2_7 Y4Y5_7 FS3_7 SSC3_7 Y6Y7_7 FS4_7 SSC4_7 Y8Y9_7

Addr.

Offset

(1) Address Offset refers to the byte address in the Configuration Register on following pages.

Y1 PLL1 SETTING PLL2 SETTING PLL3 SETTING PLL4 SETTING

Output Freq. SSC Output Freq. SSC Output Freq. SSC Output Freq. SSC Output

Select Select Select Select Select Select Select Select Select Select Select Select Select

04h 13h 10h-12h 15h 23h 20h-22h 25h 33h 30h-32h 35h 43h 40h-42h 45h

(1)

Submit Documentation Feedback

Xin

Xout

Vctr

VCXO

20pF

i.e.

XCSEL =10pF

Table 9. Generic Configuration Register

(1)

OFFSET

(2)

Bit

Acronym Default

00h 7 E_EL xb Device Identification (read only): ‘1’ is CDCE949 (3.3V), ‘0’ is CDCEL949 (1.8V)

6:4 RID 0h Revision Identification Number (read only) 3:0 VID 1h Vendor Identification Number (read only)

01h 7 – 0b Reserved - always write 0

6 EEPIP 0b

5 EELOCK 0b

4 PWDN 0b

3:2 INCLK 00b 1:0 SLAVE_ADR 00b Programmable Address Bits A0 and A1 of the Slave Receiver Address

02h Clock source selection for output Y1: 0 – input clock

7 M1 1b

6 SPICON 0b

5:4 Y1_ST1 11b Y1-State0/1 Definition (applies to Y1_ST1 and Y1_ST0)

3:2 Y1_ST0 01b

1:0 Pdiv1 [9:8] 10-Bit Y1-Output-Divider Pdiv1: 0 – divider reset and stand-by 03h 7:0 Pdiv1 [7:0] 04h 7 Y1_7 0b Y1_x State Selection

6 Y1_6 0b 0 – State0 (predefined by Y1-State0 Definition [Y1_ST0]) 5 Y1_5 0b 4 Y1_4 0b 3 Y1_3 0b 2 Y1_2 0b 1 Y1_1 1b 0 Y1_0 0b

05h Crystal load capacitor 00h → 0 pF

7:3 XCSEL 0Ah

(3)

EEPROM Programming 0 – EEPROM programming is completed

(4)

Status

: (read only) 1 – EEPROM is in programming mode

Permanently Lock EEPROM 0 – EEPROM is not locked

(5)

Data

: 1 – EEPROM will be permanently locked

DESCRIPTION

Device power down (overwrites S0/S1/S2 setting; configuration register settings are unchanged)

0 – device active (all PLLs and all outputs are enabled) 1 – device power down (all PLLs in power down and all outputs in 3-State)

Input clock selection: 00 – X-tal 10 – LVCMOS

01 – VCXO 11 – reserved

Operation mode selection for pin 22/23

(6)

0 – serial programming interface SDA (pin 23) and SCL (pin 22) 1 – control pins S1 (pin 23) and S2 (pin 22)

00 – device power down (all PLLs in power down and all outputs in 3-state) 01 – Y1 disabled to 3-state 10 – Y1 disabled to low 11 – Y1 enabled (normal operation)

001h

(7)

1-to-1023 – divider value

1 – State1 (predefined by Y1-State1 Definition [Y1_ST1])

(8)

selection

: 01h → 1 pF

02h → 2 pF 14h-to-1Fh → 20 pF

CDCE949

CDCEL949

SCAS844 – JUNE 2007

1 – PLL1 clock

2:0 — 0b Reserved - do not write others than 0

(1) Writing data beyond ‘50h’ may adversely affect device function. (2) All data is transferred MSB-first. (3) Unless custom setting is used. (4) During EEPROM programming, no data is allowed to be sent to the device via the SDA/SCL bus until the programming sequence is

completed. Data, however, can be read during the programming sequence (Byte Read or Block Read).

(5) If this bit is set high in the EEPROM, the actual data in the EEPROM is permanently locked, and no further programming is possible.

Data, however can still be written via SDA/SCL bus to the internal register to change device function on the fly. But new data can no longer be saved to the EEPROM. EELOCK is effective only if written into the EEPROM

(6) Selection of control-pins is effective only if written into the EEPROM. Once written into the EEPROM, the serial programming pins are

no longer available. However, if V (SDA/SCL), and the two slave receiver address bits are reset to A0 = 0 and A1 = 0.

is forced to GND, the two control-pins, S1 and S2, temporally act as serial programming pins

DDOUT

(7) These are the bits of the Control Terminal Register. The user can pre-define up to eight different control settings. These settings can

then be selected by the external control pins, S0, S1, and S2.

(8) The internal load capacitor (C

a fine adjustment of CLby few pF. The value of CLcan be programmed with a resolution of 1 pF for a total crystal load range of 0 pF to

, C2) must be used to achieve the best clock performance. External capacitors should be used only to do

20 pF. For CL> 20 pF use additional external capacitors. Also, the device input capacitance must be considered; this adds 1.5 pF (6pF//2pF) to the selected CL. For more information about VCXO configuration and crystal recommendations, see application report

SCAA085

Submit Documentation Feedback

CDCE949 CDCEL949

SCAS844 – JUNE 2007

Table 9. Generic Configuration Register (continued)

(1)

OFFSET

06h 7-Bit Byte Count (Defines the number of Bytes which will be sent from this device at the next Block

07h-0Fh — — 0h Reserved – do not write others than 0

(2)

Bit

Acronym Default

7:1 BCOUNT 50h

0 EEWRITE 0b

(9) NOTE: The EEPROM WRITE bit must be sent last. This ensures that the content of all internal registers are written into the EEPROM.

The EEWRITE cycle is initiated by the rising edge of the EEWRITE-Bit. A static level high does not trigger an EEPROM WRITE cycle. The EEWRITE-Bit must be reset low after the programming is completed. The programming status can be monitored by readout EEPIP. If EELOCK is set high, no EEPROM programming will be possible.

(3)

Read transfer; all bytes must be read out to correctly finish the read cycle.) Initiate EEPROM Write Cycle

0 – no EEPROM write cycle 1 – start EEPROM write cycle (internal configuration register are saved to the EEPROM)

(4) (9)

DESCRIPTION

Submit Documentation Feedback

SCAS844 – JUNE 2007

Table 10. PLL1 Configuration Register

(1)

OFFSET

10h 7:5 SSC1_7 [2:0] 000b SSC1: PLL1 SSC Selection (Modulation Amount)

11h 7 SSC1_5 [0]

12h 7:6 SSC1_2 [1:0]

13h

14h PLL1 Multiplexer: 0 – PLL1

15h

16h PLL1 SSC down/center selection: 0 – down

17h 7 — 0b Reserved – do not write others than 0

(1) Writing data beyond 50h may adversely affect device function. (2) All data is transferred MSB-first. (3) Unless a custom setting is used (4) The user can pre-define up to eight different control settings. In normal device operation, these settings can be selected by the external

control pins, S0, S1, and S2.

(2)

Bit

4:2 SSC1_6 [2:0] 000b Down Center 1:0 SSC1_5 [2:1]

6:4 SSC1_4 [2:0] 000b 3:1 SSC1_3 [2:0] 000b

0 SSC1_2 [2]

5:3 SSC1_1 [2:0] 000b 2:0 SSC1_0 [2:0] 000b

7 FS1_7 0b 6 FS1_6 0b 0 – f 5 FS1_5 0b 4 FS1_4 0b 3 FS1_3 0b 2 FS1_2 0b 1 FS1_1 0b 0 FS1_0 0b

7 MUX1 1b

6 M2 1b

5:4 M3 10b

3:2 Y2Y3_ST1 11b Y2, 00 – Y2/Y3 disabled to 3-State (PLL1 is in power down)

1:0 Y2Y3_ST0 01b

7 Y2Y3_7 0b 6 Y2Y3_6 0b 0 – state0 (predefined by Y2Y3_ST0) 5 Y2Y3_5 0b 4 Y2Y3_4 0b 3 Y2Y3_3 0b 2 Y2Y3_2 0b 1 Y2Y3_1 1b 0 Y2Y3_0 0b

7 SSC1DC 0b

6:0 Pdiv2 01h

6:0 Pdiv3 01h

Acronym Default

(3)

000 (off) 000 (off)

000b

001 – 0.25% 001 ± 0.25% 010 – 0.5% 010 ± 0.5% 011 – 0.75% 011 ± 0.75% 100 – 1.0% 100 ± 1.0% 101 – 1.25% 101 ± 1.25% 110 – 1.5% 110 ± 1.5% 111 – 2.0% 111 ± 2.0%

FS1_x: PLL1 Frequency Selection

(predefined by PLL1_0 – Multiplier/Divider value)

VCO1_0

1 – f

Output Y2 Multiplexer: 0 – Pdiv1

Output Y3 Multiplexer: 00 – Pdiv1-Divider

Y3-State0/1definition: 01 – Y2/Y3 disabled to 3-State (PLL1 on)

Y2Y3_x Output State Selection

1 – state1 (predefined by Y2Y3_ST1)

7-Bit Y2-Output-Divider Pdiv2: 0 – reset and stand-by

7-Bit Y3-Output-Divider Pdiv3: 0 – reset and stand-by

(predefined by PLL1_1 – Multiplier/Divider value)

VCO1_1

1 – PLL1 Bypass (PLL1 is in power down)

1 – Pdiv2

01 – Pdiv2-Divider 10 – Pdiv3-Divider 11 – reserved

10–Y2/Y3 disabled to low (PLL1 on) 11 – Y2/Y3 enabled (normal operation, PLL1 on)

DESCRIPTION

(4)

1 – center

1-to-127 – divider value

CDCE949

CDCEL949

Submit Documentation Feedback

CDCE949 CDCEL949

SCAS844 – JUNE 2007

Table 10. PLL1 Configuration Register (continued)

(1)

OFFSET

18h 7:0 PLL1_0N [11:4 PLL1_0: 30-Bit Multiplier/Divider value for frequency f 19h 7:4 PLL1_0N [3:0]

1Ah 7:3 PLL1_0R[4:0]

1Bh 7:5 PLL1_0Q [2:0]

1Ch 7:0 PLL1_1N [11:4] PLL1_1: 30-Bit Multiplier/Divider value for frequency f 1Dh 7:4 PLL1_1N [3:0]

1Eh 7:3 PLL1_1R[4:0]

1Fh 7:5 PLL1_1Q [2:0]

(2)

Bit

Acronym Default

3:0 PLL1_0R [8:5]

2:0 PLL1_0Q [5:3]

4:2 PLL1_0P [2:0] 010b

1:0 VCO1_0_RANGE 00b

3:0 PLL1_1R [8:5]

2:0 PLL1_1Q [5:3]

4:2 PLL1_1P [2:0] 010b

1:0 VCO1_1_RANGE 00b

(3)

004h

(for more information see PLL Multiplier/Divider Definition )

000h

10h

range selection: 00 – f

VCO1_0

004h

(for more information see paragraph PLL Multiplier/Divider Definition)

000h

10h

range selection: 00 – f

VCO1_1

DESCRIPTION

< 125 MHz

VCO1_0

01 – 125 MHz ≤ f 10 – 150 MHz ≤ f 11 – f

01 – 125 MHz ≤ f

≥ 175 MHz

VCO1_0

< 125 MHz

VCO1_1

10 – 150 MHz ≤ f 11 – f

≥ 175 MHz

VCO1_1

VCO1_0

< 150 MHz

VCO1_0

< 175 MHz

VCO1_0

VCO1_1

< 150 MHz

VCO1_1

< 175 MHz

VCO1_1

Submit Documentation Feedback

SCAS844 – JUNE 2007

Table 11. PLL2 Configuration Register

(1)

OFFSET

20h 7:5 SSC2_7 [2:0] 000b SSC2: PLL2 SSC Selection (Modulation Amount)

21h 7 SSC2_5 [0]

22h 7:6 SSC2_2 [1:0]

23h

24h PLL2 Multiplexer: 0 – PLL2

25h

26h PLL2 SSC down/center selection: 0 – down

27h 7 — 0b Reserved – do not write others than 0

control pins, S0, S1, and S2.

(2)

Bit

4:2 SSC2_6 [2:0] 000b Down Center 1:0 SSC2_5 [2:1]

6:4 SSC2_4 [2:0] 000b 3:1 SSC2_3 [2:0] 000b

0 SSC2_2 [2]

5:3 SSC2_1 [2:0] 000b 2:0 SSC2_0 [2:0] 000b

7 FS2_7 0b 6 FS2_6 0b 0 – f 5 FS2_5 0b 4 FS2_4 0b 3 FS2_3 0b 2 FS2_2 0b 1 FS2_1 0b 0 FS2_0 0b

7 MUX2 1b

6 M4 1b

5:4 M5 10b

3:2 Y4Y5_ST1 11b Y4, 00 – Y4/Y5 disabled to 3-State (PLL2 is in power down)

1:0 Y4Y5_ST0 01b

7 Y4Y5_7 0b 6 Y4Y5_6 0b 0 – state0 (predefined by Y4Y5_ST0) 5 Y4Y5_5 0b 4 Y4Y5_4 0b 3 Y4Y5_3 0b 2 Y4Y5_2 0b 1 Y4Y5_1 1b 0 Y4Y5_0 0b

7 SSC2DC 0b

6:0 Pdiv4 01h

6:0 Pdiv5 01h

Acronym Default

(3)

000 (off) 000 (off)

000b

001 – 0.25% 001 ± 0.25% 010 – 0.5% 010 ± 0.5% 011 – 0.75% 011 ± 0.75% 100 – 1.0% 100 ± 1.0% 101 – 1.25% 101 ± 1.25% 110 – 1.5% 110 ± 1.5% 111 – 2.0% 111 ± 2.0%

FS2_x: PLL2 Frequency Selection

(predefined by PLL2_0 – Multiplier/Divider value)

VCO2_0

1 – f

Output Y4 Multiplexer: 0 – Pdiv2

Output Y5 Multiplexer: 00 – Pdiv2-Divider

Y5-State0/1definition: 01 – Y4/Y5 disabled to 3-State (PLL2 on)

Y4Y5_x Output State Selection

1 – state1 (predefined by Y4Y5_ST1)

7-Bit Y4-Output-Divider Pdiv4: 0 – reset and stand-by

7-Bit Y5-Output-Divider Pdiv5: 0 – reset and stand-by

(predefined by PLL2_1 – Multiplier/Divider value)

VCO2_1

1 – PLL2 Bypass (PLL2 is in power down)

1 – Pdiv4

01 – Pdiv4-Divider 10 – Pdiv5-Divider 11 – reserved

10–Y4/Y5 disabled to low (PLL2 on) 11 – Y4/Y5 enabled (normal operation, PLL2 on)

DESCRIPTION

(4)

1 – center

1-to-127 – divider value

CDCE949

CDCEL949

Submit Documentation Feedback

CDCE949 CDCEL949

SCAS844 – JUNE 2007

Table 11. PLL2 Configuration Register (continued)

(1)

OFFSET

28h 7:0 PLL2_0N [11:4 PLL2_0: 30-Bit Multiplier/Divider value for frequency f 29h 7:4 PLL2_0N [3:0]

2Ah 7:3 PLL2_0R[4:0]

2Bh 7:5 PLL2_0Q [2:0]

2Ch 7:0 PLL2_1N [11:4] PLL2_1: 30-Bit Multiplier/Divider value for frequency f 2Dh 7:4 PLL2_1N [3:0]

2Eh 7:3 PLL2_1R[4:0]

2Fh 7:5 PLL2_1Q [2:0]

(2)

Bit

Acronym Default

3:0 PLL2_0R [8:5]

2:0 PLL2_0Q [5:3]

4:2 PLL2_0P [2:0] 010b

1:0 VCO2_0_RANGE 00b

3:0 PLL2_1R [8:5]

2:0 PLL2_1Q [5:3]

4:2 PLL2_1P [2:0] 010b

1:0 VCO2_1_RANGE 00b

(3)

004h

(for more information see paragraph PLL Multiplier/Divider Definition)

000h

10h

range selection: 00 – f

VCO2_0

004h

(for more information see paragraph PLL Multiplier/Divider Definition)

000h

10h

range selection: 00 – f

VCO2_1

DESCRIPTION

VCO2_0

01 – 125 MHz ≤ f 10 – 150 MHz ≤ f 11 – f

VCO2_0

VCO2_1

01 – 125 MHz ≤ f 10 – 150 MHz ≤ f 11 – f

VCO2_1

VCO2_0

< 125 MHz

< 150 MHz

VCO2_0

< 175 MHz

VCO2_0

≥ 175 MHz

VCO1_1

< 125 MHz

< 150 MHz

VCO2_1

< 175 MHz

VCO2_1

≥ 175 MHz

Submit Documentation Feedback

SCAS844 – JUNE 2007

Table 12. PLL3 Configuration Register

(1)

OFFSET

30h 7:5 SSC3_7 [2:0] 000b SSC3: PLL3 SSC Selection (Modulation Amount)

31h 7 SSC3_5 [0]

32h 7:6 SSC3_2 [1:0]

33h

34h PLL3 Multiplexer: 0 – PLL3

35h

36h PLL3 SSC down/center selection: 0 – down

37h 7 — 0b Reserved – do not write others than 0

control pins, S0, S1, and S2.

(2)

Bit

4:2 SSC3_6 [2:0] 000b Down Center 1:0 SSC3_5 [2:1]

6:4 SSC3_4 [2:0] 000b 3:1 SSC3_3 [2:0] 000b

0 SSC3_2 [2]

5:3 SSC3_1 [2:0] 000b 2:0 SSC3_0 [2:0] 000b

7 FS3_7 0b 6 FS3_6 0b 0 – f 5 FS3_5 0b 4 FS3_4 0b 3 FS3_3 0b 2 FS3_2 0b 1 FS3_1 0b 0 FS3_0 0b

7 MUX3 1b

6 M6 1b

5:4 M7 10b

3:2 Y6Y7_ST1 11b Y6, 00 – Y6/Y7 disabled to 3-State (PLL3 is in power down)

1:0 Y6Y7_ST0 01b

7 Y6Y7_7 0b 6 Y6Y7_6 0b 0 – state0 (predefined by Y6Y7_ST0) 5 Y6Y7_5 0b 4 Y6Y7_4 0b 3 Y6Y7_3 0b 2 Y6Y7_2 0b 1 Y6Y7_1 1b 0 Y6Y7_0 0b

7 SSC3DC 0b

6:0 Pdiv6 01h

6:0 Pdiv7 01h

Acronym Default

(3)

000 (off) 000 (off)

000b

001 – 0.25% 001 ± 0.25% 010 – 0.5% 010 ± 0.5% 011 – 0.75% 011 ± 0.75% 100 – 1.0% 100 ± 1.0% 101 – 1.25% 101 ± 1.25% 110 – 1.5% 110 ± 1.5% 111 – 2.0% 111 ± 2.0%

FS3_x: PLL3 Frequency Selection

(predefined by PLL3_0 – Multiplier/Divider value)

VCO3_0

1 – f

Output Y6 Multiplexer: 0 – Pdiv4

Output Y7 Multiplexer: 00 – Pdiv4-Divider

Y7-State0/1definition: 01 – Y6/Y7 disabled to 3-State (PLL3 on)

Y6Y7_x Output State Selection

1 – state1 (predefined by Y6Y7_ST1)

7-Bit Y6-Output-Divider Pdiv6: 0 – reset and stand-by

7-Bit Y7-Output-Divider Pdiv7: 0 – reset and stand-by

(predefined by PLL3_1 – Multiplier/Divider value)

VCO3_1

1 – PLL3 Bypass (PLL3 is in power down)

1 – Pdiv6

01 – Pdiv6-Divider 10 – Pdiv7-Divider 11 – reserved

10 –Y6/Y7 disabled to low (PLL3 on) 11 – Y6/Y7 enabled (normal operation, PLL3 on)

DESCRIPTION

(4)

1 – center

1-to-127 – divider value

CDCE949

CDCEL949

Submit Documentation Feedback

CDCE949 CDCEL949

SCAS844 – JUNE 2007

Table 12. PLL3 Configuration Register (continued)

(1)

OFFSET

38h 7:0 PLL3_0N [11:4 PLL3_0: 30-Bit Multiplier/Divider value for frequency f 39h 7:4 PLL3_0N [3:0]

3Ah 7:3 PLL3_0R[4:0]

3Bh 7:5 PLL3_0Q [2:0]

3Ch 7:0 PLL3_1N [11:4] PLL3_1: 30-Bit Multiplier/Divider value for frequency f 3Dh 7:4 PLL3_1N [3:0]

3Eh 7:3 PLL3_1R[4:0]

3Fh 7:5 PLL3_1Q [2:0]

(2)

Bit

Acronym Default

3:0 PLL3_0R [8:5]

2:0 PLL3_0Q [5:3]

4:2 PLL3_0P [2:0] 010b

1:0 VCO3_0_RANGE 00b

3:0 PLL3_1R [8:5]

2:0 PLL3_1Q [5:3]

4:2 PLL3_1P [2:0] 010b

1:0 VCO3_1_RANGE 00b

(3)

004h

(for more information see paragraph PLL Multiplier/Divider Definition)

000h

10h

range selection: 00 – f

VCO3_0

004h

(for more information see paragraph PLL Multiplier/Divider Definition)

000h

10h

range selection: 00 – f

VCO3_1

DESCRIPTION

< 125 MHz

VCO3_0

01 – 125 MHz ≤ f 10 – 150 MHz ≤ f 11 – f

01 – 125 MHz ≤ f

≥ 175 MHz

VCO3_0

< 125 MHz

VCO3_1

10 – 150 MHz ≤ f 11 – f

≥ 175 MHz

VCO3_1

VCO3_0

< 150 MHz

VCO3_0

< 175 MHz

VCO3_0

VCO3_1

< 150 MHz

VCO3_1

< 175 MHz

VCO3_1

Submit Documentation Feedback

SCAS844 – JUNE 2007

Table 13. PLL4 Configuration Register

(1)

OFFSET

40h 7:5 SSC4_7 [2:0] 000b SSC4: PLL4 SSC Selection (Modulation Amount)

41h 7 SSC4_5 [0]

42h 7:6 SSC4_2 [1:0]

43h

44h PLL4 Multiplexer: 0 – PLL4

45h

46h PLL4 SSC down/center selection: 0 – down

47h 7 — 0b Reserved – do not write others than 0

control pins, S0, S1, and S2.

(2)

Bit

4:2 SSC4_6 [2:0] 000b Down Center 1:0 SSC4_5 [2:1]

6:4 SSC4_4 [2:0] 000b 3:1 SSC4_3 [2:0] 000b

0 SSC4_2 [2]

5:3 SSC4_1 [2:0] 000b 2:0 SSC4_0 [2:0] 000b

7 FS4_7 0b 6 FS4_6 0b 0 – f 5 FS4_5 0b 4 FS4_4 0b 3 FS4_3 0b 2 FS4_2 0b 1 FS4_1 0b 0 FS4_0 0b

7 MUX4 1b

6 M8 1b

5:4 M9 10b

3:2 Y8Y9_ST1 11b Y8, 00 – Y8/Y9 disabled to 3-State (PLL4 is in power down)

1:0 Y8Y9_ST0 01b

7 Y8Y9_7 0b 6 Y8Y9_6 0b 0 – state0 (predefined by Y8Y9_ST0) 5 Y8Y9_5 0b 4 Y8Y9_4 0b 3 Y8Y9_3 0b 2 Y8Y9_2 0b 1 Y8Y9_1 1b 0 Y8Y9_0 0b

7 SSC4DC 0b

6:0 Pdiv8 01h

6:0 Pdiv9 01h

Acronym Default

(3)

000 (off) 000 (off)

000b

001 – 0.25% 001 ± 0.25% 010 – 0.5% 010 ± 0.5% 011 – 0.75% 011 ± 0.75% 100 – 1.0% 100 ± 1.0% 101 – 1.25% 101 ± 1.25% 110 – 1.5% 110 ± 1.5% 111 – 2.0% 111 ± 2.0%

FS4_x: PLL4 Frequency Selection

(predefined by PLL4_0 – Multiplier/Divider value)

VCO4_0

1 – f

Output Y8 Multiplexer: 0 – Pdiv6

Output Y9 Multiplexer: 00 – Pdiv6-Divider

Y9-State0/1definition: 01 – Y8/Y9 disabled to 3-State (PLL4 on)

Y8Y9_x Output State Selection

1 – state1 (predefined by Y8Y9_ST1)

7-Bit Y8-Output-Divider Pdiv8: 0 – reset and stand-by

7-Bit Y9-Output-Divider Pdiv9: 0 – reset and stand-by

(predefined by PLL4_1 – Multiplier/Divider value)

VCO4_1

1 – PLL4 Bypass (PLL4 is in power down)

1 – Pdiv8

01 – Pdiv8-Divider 10 – Pdiv9-Divider 11 – reserved

10 –Y8/Y9 disabled to low (PLL4 on) 11 – Y8/Y9 enabled (normal operation, PLL4 on)

DESCRIPTION

(4)

1 – center

1-to-127 – divider value

CDCE949

CDCEL949

Submit Documentation Feedback

CDCE949 CDCEL949

SCAS844 – JUNE 2007

Table 13. PLL4 Configuration Register (continued)

(1)

OFFSET

48h 7:0 PLL4_0N [11:4 PLL4_0: 30-Bit Multiplier/Divider value for frequency f 49h 7:4 PLL4_0N [3:0]

4Ah 7:3 PLL4_0R[4:0]

4Bh 7:5 PLL4_0Q [2:0]

4Ch 7:0 PLL4_1N [11:4] PLL4_1: 30-Bit Multiplier/Divider value for frequency f 4Dh 7:4 PLL4_1N [3:0]

4Eh 7:3 PLL4_1R[4:0]

4Fh 7:5 PLL4_1Q [2:0]

(2)

Bit

Acronym Default

3:0 PLL4_0R [8:5]

2:0 PLL4_0Q [5:3]

4:2 PLL4_0P [2:0] 010b

1:0 VCO4_0_RANGE 00b

3:0 PLL4_1R [8:5]

2:0 PLL4_1Q [5:3]

4:2 PLL4_1P [2:0] 010b

1:0 VCO4_1_RANGE 00b

(3)

004h

(for more information see paragraph PLL Multiplier/Divider Definition)

000h

10h

range selection: 00 – f

VCO4_0

004h

(for more information see paragraph PLL Multiplier/Divider Definition)

000h

10h

range selection: 00 – f

VCO4_1

DESCRIPTION

< 125 MHz

VCO4_0

01 – 125 MHz ≤ f 10 – 150 MHz ≤ f 11 – f

01 – 125 MHz ≤ f

≥ 175 MHz

VCO4_0

< 125 MHz

VCO4_1

10 – 150 MHz ≤ f 11 – f

≥ 175 MHz

VCO4_1

VCO4_0

< 150 MHz

VCO4_0

< 175 MHz

VCO4_0

VCO4_1

< 150 MHz

VCO4_1

< 175 MHz

VCO4_1

Submit Documentation Feedback

PLL MULTIPLIER/DIVIDER DEFINITION

OUT

Pdiv

N M

VCO

+ ƒ

)

int(log4P

)

int(Q =

QM'NR ´-=

At a given input frequency (fIN), the output frequency (f

where

M (1 to 511) and N (1 to 4095) are the multiplier/divider values of the PLL; Pdiv (1 to 127) is the output divider.

The target VCO frequency (f

) of each PLL can be calculated:

VCO

The PLL operates as fractional divider and needs following multiplier/divider settings

{if P < 0 then P = 0}

) of the CDCE949/CDCEL949 can be calculated by:

OUT

CDCE949

CDCEL949

SCAS844 – JUNE 2007

Where:

N’ = N × 2P; N ≥ M; 80 MHz < f

> 230 MHz.

VCO

Example 1: for fIN= 27 MHz; M = 1; N = 4; Pdiv = 2; Example 2: for fIN= 27 MHz; M = 2; N = 11; Pdiv = 2;

→ f → f → P = 4 – int(log

= 54 MHz; → f

OUT

= 108 MHz; → f

VCO

4) = 4 –2 = 2; → P = 4 – int(log

= 75.25 MHz;

OUT

= 148.50 MHz;

VCO

5.5) = 4 – 2 = 2;

→ N’ = 4 × 22= 16; → N’ = 11 × 22= 44; → Q = int(16) = 16; → Q = int(22) = 22; → R = 16 – 16 = 0; → R = 44 – 44 = 0;

The values for P, Q, R and N’ are automatically calculated when using TI Pro Clock™ Software.

Submit Documentation Feedback

PACKAGE OPTION ADDENDUM

www.ti.com

20-Jul-2007

PACKAGING INFORMATION

Orderable Device Status

(1)

Package

Type

Package Drawing

Pins Package

Qty

Eco Plan

CDCE949PW ACTIVE TSSOP PW 24 60 Green (RoHS &

no Sb/Br)

CDCE949PWG4 ACTIVE TSSOP PW 24 60 TBD Call TI Call TI

CDCE949PWR ACTIVE TSSOP PW 24 2000 Green (RoHS &

no Sb/Br)

CDCE949PWRG4 ACTIVE TSSOP PW 24 2000 TBD Call TI Call TI

(1)

The marketing status values are defined as follows:

ACTIVE: Product device recommended for new designs. LIFEBUY: TI has announced that the device will be discontinued, and a lifetime-buy period is in effect. NRND: Not recommended for new designs. Device is in production to support existing customers, but TI does not recommend using this part in

a new design.

PREVIEW: Device has been announced but is not in production. Samples may or may not be available. OBSOLETE: TI has discontinued the production of the device.

(2)

Eco Plan - The planned eco-friendly classification: Pb-Free (RoHS), Pb-Free (RoHS Exempt), or Green (RoHS & no Sb/Br) - please check

http://www.ti.com/productcontent for the latest availability information and additional product content details.

TBD: The Pb-Free/Green conversion plan has not been defined. Pb-Free (RoHS): TI's terms "Lead-Free" or "Pb-Free" mean semiconductor products that are compatible with the current RoHS requirements

for all 6 substances, including the requirement that lead not exceed 0.1% by weight in homogeneous materials. Where designed to be soldered at high temperatures, TI Pb-Free products are suitable for use in specified lead-free processes. Pb-Free (RoHS Exempt): This component has a RoHS exemption for either 1) lead-based flip-chip solder bumps used between the die and package, or 2) lead-based die adhesive used between the die and leadframe. The component is otherwise considered Pb-Free (RoHS compatible) as defined above. Green (RoHS & no Sb/Br): TI defines "Green" to mean Pb-Free (RoHS compatible), and free of Bromine (Br) and Antimony (Sb) based flame retardants (Br or Sb do not exceed 0.1% by weight in homogeneous material)

(2)

Lead/Ball Finish MSL Peak Temp

CU NIPDAU Level-1-260C-UNLIM

(3)

MSL, Peak Temp. -- The Moisture Sensitivity Level rating according to the JEDEC industry standard classifications, and peak solder

temperature.

Important Information and Disclaimer:The information provided on this page represents TI's knowledge and belief as of the date that it is provided. TI bases its knowledge and belief on information provided by third parties, and makes no representation or warranty as to the accuracy of such information. Efforts are underway to better integrate information from third parties. TI has taken and continues to take reasonable steps to provide representative and accurate information but may not have conducted destructive testing or chemical analysis on incoming materials and chemicals. TI and TI suppliers consider certain information to be proprietary, and thus CAS numbers and other limited information may not be available for release.

In no event shall TI's liability arising out of such information exceed the total purchase price of the TI part(s) at issue in this document sold by TI to Customer on an annual basis.

Addendum-Page 1

PACKAGE MATERIALS INFORMATION

www.ti.com

11-Jul-2007

TAPE AND REEL INFORMATION

Pack Materials-Page 1

PACKAGE MATERIALS INFORMATION

www.ti.com

Device Package Pins Site Reel

Diameter

(mm)

CDCE949PWR PW 24 MLA 330 16 6.95 8.3 1.6 8 16 Q1

Reel

Width

(mm)

A0 (mm) B0 (mm) K0 (mm) P1

(mm)W(mm)

11-Jul-2007

Pin1

Quadrant

TAPE AND REEL BOX INFORMATION

Device Package Pins Site Length (mm) Width (mm) Height (mm)

CDCE949PWR PW 24 MLA 346.0 346.0 33.0

Pack Materials-Page 2

MECHANICAL DATA

MTSS001C – JANUARY 1995 – REVISED FEBRUARY 1999

PW (R-PDSO-G**) PLASTIC SMALL-OUTLINE PACKAGE

14 PINS SHOWN

0,65

1,20 MAX

0,30

0,19

4,50 4,30

PINS **

Seating Plane

0,15 0,05

DIM

0,10

6,60 6,20

0,10

0,15 NOM

0°–8°

2016

Gage Plane

0,25

0,75 0,50

A MAX

A MIN

NOTES: A. All linear dimensions are in millimeters.

B. This drawing is subject to change without notice. C. Body dimensions do not include mold flash or protrusion not to exceed 0,15. D. Falls within JEDEC MO-153

3,10

2,90

5,10

4,90

5,10

4,90

6,60

6,40

7,90

7,70

9,80

9,60

4040064/F 01/97

POST OFFICE BOX 655303 • DALLAS, TEXAS 75265

IMPORTANT NOTICE

Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should obtain the latest relevant information before placing orders and should verify that such information is current and complete. All products are sold subject to TI’s terms and conditions of sale supplied at the time of order acknowledgment.

TI warrants performance of its hardware products to the specifications applicable at the time of sale in accordance with TI’s standard warranty. Testing and other quality control techniques are used to the extent TI deems necessary to support this warranty. Except where mandated by government requirements, testing of all parameters of each product is not necessarily performed.

TI assumes no liability for applications assistance or customer product design. Customers are responsible for their products and applications using TI components. To minimize the risks associated with customer products and applications, customers should provide adequate design and operating safeguards.

TI does not warrant or represent that any license, either express or implied, is granted under any TI patent right, copyright, mask work right, or other TI intellectual property right relating to any combination, machine, or process in which TI products or services are used. Information published by TI regarding third-party products or services does not constitute a license from TI to use such products or services or a warranty or endorsement thereof. Use of such information may require a license from a third party under the patents or other intellectual property of the third party, or a license from TI under the patents or other intellectual property of TI.

Reproduction of TI information in TI data books or data sheets is permissible only if reproduction is without alteration and is accompanied by all associated warranties, conditions, limitations, and notices. Reproduction of this information with alteration is an unfair and deceptive business practice. TI is not responsible or liable for such altered documentation. Information of third parties may be subject to additional restrictions.

Resale of TI products or services with statements different from or beyond the parameters stated by TI for that product or service voids all express and any implied warranties for the associated TI product or service and is an unfair and deceptive business practice. TI is not responsible or liable for any such statements.

TI products are not authorized for use in safety-critical applications (such as life support) where a failure of the TI product would reasonably be expected to cause severe personal injury or death, unless officers of the parties have executed an agreement specifically governing such use. Buyers represent that they have all necessary expertise in the safety and regulatory ramifications of their applications, and acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products and any use of TI products in such safety-critical applications, notwithstanding any applications-related information or support that may be provided by TI. Further, Buyers must fully indemnify TI and its representatives against any damages arising out of the use of TI products in such safety-critical applications.

TI products are neither designed nor intended for use in military/aerospace applications or environments unless the TI products are specifically designated by TI as military-grade or "enhanced plastic." Only products designated by TI as military-grade meet military specifications. Buyers acknowledge and agree that any such use of TI products which TI has not designated as military-grade is solely at the Buyer's risk, and that they are solely responsible for compliance with all legal and regulatory requirements in connection with such use.

TI products are neither designed nor intended for use in automotive applications or environments unless the specific TI products are designated by TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree that, if they use any non-designated products in automotive applications, TI will not be responsible for any failure to meet such requirements.

Following are URLs where you can obtain information on other Texas Instruments products and application solutions:

Products Applications

Amplifiers amplifier.ti.com Audio www.ti.com/audio Data Converters dataconverter.ti.com Automotive www.ti.com/automotive DSP dsp.ti.com Broadband www.ti.com/broadband Interface interface.ti.com Digital Control www.ti.com/digitalcontrol Logic logic.ti.com Military www.ti.com/military Power Mgmt power.ti.com Optical Networking www.ti.com/opticalnetwork Microcontrollers microcontroller.ti.com Security www.ti.com/security RFID www.ti-rfid.com Telephony www.ti.com/telephony Low Power www.ti.com/lpw Video & Imaging www.ti.com/video

Wireless

Wireless www.ti.com/wireless

Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265

Texas Instruments CDCEL949PWRG4, CDCE949 Datasheet

Specifications and Main Features

Frequently Asked Questions

User Manual

FEATURES

APPLICATIONS

DESCRIPTION

DEVICE INFORMATION

ABSOLUTE MAXIMUM RATINGS

THERMAL RESISTANCE FOR TSSOP (PW) PACKAGE

RECOMMENDED OPERATING CONDITIONS

RECOMMENDED CRYSTAL/VCXO SPECIFICATIONS

EEPROM SPECIFICATION

TIMING REQUIREMENTS

DEVICE CHARACTERISTICS

DEVICE CHARACTERISTICS (Continued)

DEVICE CHARACTERISTICS (Continued)

PARAMETER MEASUREMENT INFORMATION

TYPICAL CHARACTERISTICS

APPLICATION INFORMATION

Control Terminal Configuration

DEFAULT DEVICE SETTING

SDA/SCL SERIAL INTERFACE

DATA PROTOCOL

Generic Programming Sequence

Byte Write Programming Sequence

Byte Read Programming Sequence

Block Write Programming Sequence

Block Read Programming Sequence

Timing Diagram for the SDA/SCL Serial Control Interface

SDA/SCL Hardware Interface

SDA/SCL CONFIGURATION REGISTERS

PLL MULTIPLIER/DIVIDER DEFINITION
