User’s Guide
SNAU120-April 2012
ADC161S626BEB User’s Guide
LIST OF FIGURES ............................................................................................................. 1
LIST OF TABLES ............................................................................................................... 1
1. INTRODUCTION ......................................................................................................... 1
2. BOARD ASSEMBLY ................................................................................................... 1
3. QUICK START ............................................................................................................ 3
4. FUNCTIONAL DESCRIPTION .................................................................................... 4
5. HARDWARE SCHEMATIC ......................................................................................... 5
6. ADC161S626 EVALU ATIO N BOARD BILL OF MATERIALS ................................... 6
EVALUATION BOARD/KIT/MODULE (EVM).................................................................. 11
LIST OF FIGURES
Figure 1: ADC161S626 Eval board connected to SPIO board. ..................................... 3
LIST OF TABLES
Table 1: Test Points on the ADC161S626 Evaluation Board ........................................ 2
Table 2: Connectors on the ADC161S626 E valuation Board ....................................... 2
Table 3: Jumpers .............................................................................................................. 2
1. Introduction
The ADC161S626BEB Evaluation Board Design Kit (consisting of the ADC161S626BEB board, this users
guide, an optional SPIO4 board and an optional sensor board) is intended to ease evaluation of the
ADC161S626. With the optional SPIO4 board and optional Sensor board, the board allows evaluation of an
entire Sensor AFE system.
The evaluation board can be used in stand alone mode, in which the user interfaces with the part through the
SPIO-GPSI16 connector and applies input signals on the AB12 connector. The board can also be used with
an SPIO4 board in place of an external pattern generator. Finally, in the Sensor AFE system, the
ADC161S626BEB board and the optional sensor board (for example, the LMP91000 Configurable AFE Gas
Sensor board) can be used with an SPIO4 board to evaluate the entire Sensor AFE system.
2. Board Assembly
The ADC161S626BEB evaluation board comes fully assembled and ready for use. Refer to the Bill of
Materials for a description of components and to the schematic at the end of this document. There are
jumper selections for choosing between different power supply and clock configurations.
SNAU120-April 2012 ADC161S626BEB User’s Guide 1
Test Point
Purpose
SCLK,
DOUT, CSB
ADC SPI bus signals. Located below the DUT.
VREF,
If external supplies on the banana jacks are used for VREF, VA,
used, the banana jacks can be used as test points.
Connector
Purpose
SPIOGPSI16
16 pin dual row right angle male header to connect to the SPIO4
board.
GPSI16
16 pin dual row right angle female header. Carries signals from
the SPIO4 board to any optional SensorAFE board.
AB12
12 pin dual row right angle male header. Carries analog bus
to the ADC.
Jumper
Purpose
VREF
SELECT
Selects reference source for VREF. Settings are Vref banana
jack, on board Va or on board LM4120-4.1
VIO SELECT
Allows choice of VIO for the chip, the SPIO interface and
banana jack.
5V from the SPIO connector.
Board Assembly
VDDIO, VA
Table 1: Test Points on the ADC161S626 Evaluation Board
Table 2: Connectors on the ADC161S626 Evaluation Board
VA SELECT Allows choice of VA for the part. Choices are VA banana jack or
VIO EXT the center pins of jumpers VREF SELECT, VIO
SELECT, VA SELECT can be used as a test point for those
signals. If on board power supplies (from the SPIO board) are
signals from an external source or the optional Sensor AFE board
whatever sensor board is connected to the ADC board. Choices
are on board Va, 3.3V from the SPIO connector or the VIO EXT
Table 3: Jumpers
2 ADC161S626BEB User’s Guide SNAU120-April 2012
3. Quick Start
The fastest way to s tart usi ng the ADC 161S626 evaluatio n board is to use it with the SPIO 4 board, a senso r
board such as the LMP91000 and the Sensor AFE software.
3.1 Sensor AFE Setup (LMP91000)
• Install the VA SELEC T jumper between pins 1 and 2 (VA and 5V) . This will power VA from the 5V
supply coming from the SPIO4 board.
• Install the VIO SELECT j um per between pi ns 2 and 3 (VA and VDDIO ) . T his will po wer the IO on t he
chip from the same voltage as VA or 5V. Note, this VDDIO will go on to the LMP91000 board.
• Install the VREF SELECT j umper from pin 2 to 3 (VREF and ON BOAR D REF) . This will connect the
ADC VREF line to the 4.096V on board LM4120 reference.
• Ensure that a 4MHz c r ystal is installed in the socket Y2 an d th at th ere is no s igna l ap pl ied at t he CLK
IN BNC jack.
• Connect the SPIO4 board t o the A DC 1 61 S62 6B EB bo ar d at th e S PI O-G SPI 16 m ale h ead er. Li ne u p
the white arrows on the bottom of the headers.
• Connect the LMP91 000 board to the GPSI16 and AB12 headers. Line up the white arrows at the
bottom of the headers (see Figure 1)
• Connect the SPIO4 board to its power supply and to your computer via the USB cable in that order.
Figure 1: ADC161S626 Eval board connected to SPIO board.
• Start the SensorAFE software on your computer.
3.2 Setup for Other Boards
• Choose the VA supply:
o Install the VA SELECT jum per between pins 1 and 2 (VA and 5V) to power VA f rom the 5V
supply coming from the SPIO4 or SPUSI2 board.
SNAU120-April 2012 ADC161S626BEB User’s Guide 3
o Leave the jumper off to select the VA banana jack
• Choose the VDDIO supply:
o Install the VIO SELECT jumper between pins 1 and 2 (+3.3V and VDDIO) to choose the 3.3V
supply coming from the SPIO4 or SPUSI2 board.
o Install the VIO SELECT jumper between pins 2 and 3 (VA and VDDIO) to choose the IO on
the chip from the same voltage as VA or 5V.
o Leave the jumper off to select the VIO EXT banana jack.
• Choose the VREF supply:
o Install the VREF SELECT jumper from pin 1 to pin 2 (VA and ON BOAR D REF) to connect
the VREF pin to the VA supply.
o Install the VREF SELECT jumper from pin 2 to 3 (VREF and ON BO ARD REF) to connect
the ADC VREF line to the 4.096V on board LM4120 reference.
o Leave the jumper off to select the external reference present on the VREF banana jack.
• Choose the clock source
o Install a 4MHz crystal in the socket Y2 to generate an on board clock that can go to the
SPIO4 board.
o Leave Y2 unpopulated an d att ach a 4 MHz signal to the CLK IN BNC con nec tor to generate a
clock for the SPIO4 board.
o Bring a clock to the SPIO-GPSI16 header from an external board of your choice.
4. Functional Description
4.1 ADC Reference Circuitry
This evaluation board includes three options to source the voltage reference, VREF. The options are
selecting the fixed, on bo ard +4.096V voltag e reference (LM4 120-4.1) to source VREF, connectin g VREF to
VA of the device, or using the ex ternal banana jack to sourc e VREF. To select the +4.1V referenc e, short
pins 2 & 3 of VREF SELECT jumper. To connect VA to VREF, short pins 1 and 2 of the VREF SELECT
jumper. To select the exter nal reference, do not ins tall a jumper. Consult th e data sheet for the accept able
values of VREF.
4.2 SPI Interface
The ADC161S626 requ ires three SPI pins. T he input pins are Serial C lock (SCLK), Chip Select Bar (CSB).
The output pin is data o ut or Master In Slave Out (MISO). T he user must provide input signals for SCLK,
CSB.
4.2.1 Serial Clock (SCLK, CSB, MISO, MOSI)
These signals can be provided b y the SPIO 4 or SPUS I2 board. I n stand a lone mode, t hese signa ls mus t be
provided by the user on the SPIO-GPSI16 header. The signal lev els are TTL and CMOS compatible. The
voltage expected is set by the value of VDDIO that is applied to the board.
4 ADC161S626BEB User’s Guide SNAU120-April 2012
5. Hardware Schematic
SNAU120-April 2012 ADC161S626BEB User’s Guide 5
Item
Designator
Description
Manufacturer
PartNumber
Quanti
ty
1
U7
16-Bit, 50 to 250 kSPS, Differential
Labs Socket MSO10SD
Texas Instruments
ADC161S626CIM
1
2
C18, C20,
C29, C32
CAP, CERM, 0.1uF, 16V, +/-5%,
AVX
0603YC104JAT2A
6
3
C31
CAP, CERM, 470pF, 50V, +/-5%,
C0G/NP0, 0603
AVX
06035A471JAT2A
1 4 C1
CAP, CERM, 56pF, 50V, +/-5%,
C0G/NP0, 0603
AVX
06035A560JAT2A
1
C28
0.45 ohm, 6032-28 SMD
TE3
6
CLK IN
Connector, TH, BNC
Amphenol Connex
112404
1
7
GPSI16
GPSI16 Female Header, 8-Pin,
Sullins Connector
PPTC082LJBN-RC
1
8
AB12,
GPSI16
Header, 6-Pin, Dual row, Right
Dual row, Right Angle
Sullins Connector
PBC36DGAN
2
9
VA
Header, TH, 100mil, 1x2, Gold
Samtec Inc.
TSW-102-07-G-S
1
SELECT
11
U6
IC EEPROM 2KBIT 400KHZ
8TSSOP
ON Semiconductor
CAT24C01WI-GT3
1
12
Y2
OSC 4.000 MHZ 5.0V FULL SIZE
ECS Inc
ECS-100AX-040
1
FOR Y2
4PIN
14
U4
Precision Micropower Low Dropout
Voltage Reference
Texas Instruments
LM4120AIM5-
4.1/NOPB
1
15
AA1
Printed Circuit Board
TBD 1
0EA
17
R30, R34
RES, 20.0 ohm, 1%, 0.1W, 0603
Vishay-Dale
CRCW060320R0F
KEA
2
18
R46
RES, 27.4 ohm, 1%, 0.1W, 0603
Vishay-Dale
CRCW060327R4F
KEA
1
19
R41, R45
RES, 51.1 ohm, 1%, 0.1W, 0603
Vishay-Dale
CRCW060351R1F
KEA
2
VREF
6. ADC161S626 Evaluation Board Bill of Materials
C26, C27,
5 C19, C25,
SPIO-
SELECT
10 VIO
SELECT,
VREF
Input, MicroPower ADC & Rainbow
X7R, 0603
CAP, TANT, 10uF, 16V, +/-10%,
Dual row, Right Angle
Angle, SPIO-GPSI16 Header, 8-Pin,
plated, 230 mil above insulator
Header, TH, 100mil, 1x3, Gold
plated, 230 mil above insulator
M/NOPB
Vishay-Sprague 593D106X9016C2
Solutions
Solutions
Samtec Inc. TSW-103-07-G-S 2
3
13 SOCKET
16 R42 RES, 0 ohm, 5%, 0.1W, 0603 Vishay-Dale CRCW06030000Z
20 GND, VA,
VIO EXT,
OSCILLATOR SOCKET FULL SIZE
Standard Banana Jack,
Uninsulated, 15A
6 ADC161S626BEB User’s Guide SNAU120-April 2012
Aries Electro nic s 1107741 1
1
Johnson
Components
108-0740-001 4
EVALUATION BOARD/KIT/MODULE (EVM) ADDITIONAL TERMS
Texas Instruments (TI) provides the enclosed Evaluation Board/Kit/Module (EVM) under the following conditions:
The user assumes all responsibility and liability for proper and safe handling of the goods. Further, the user
indemnifies TI from all claims arising from the handling or use of the goods.
Should this evaluation boa rd/kit not meet the specifications indicated in th e User’s Guide, the board/ kit may be
returned within 30 da ys fr om the date of deli very for a full refund. THE FO REGO I NG LIMITED WARRANTY IS THE
EXCLUSIVE WARRANTY MADE BY SELLER TO BUYER AND IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESSED, IMPLIED, OR STAT UT O R Y, INCLUDING ANY W AR RAN T Y OF MERCHANTABILITY OR FITNESS
FOR ANY PARTICULAR PURPOSE. EXCEPT TO THE EXTENT OF THE INDEMNITY SET FORTH ABOVE,
NEITHER PARTY SHALL BE LIABLE TO THE OTHER FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES.
Please read the User's G uide and, specifically, the Warnings and Restrictions notice in the User's Guide prior to
handling the product. This notice contains important safety information about temperatures and voltages. For
additional information on TI's environmental and/or safety programs, please visit
No license is granted under any patent right or other intellectual property right of TI covering or relating to any
machine, process, or combin ation in which such TI products or services m ight be or are used. TI currently deals
with a variety of custom ers for produc ts, and therefore our arrangem ent with the user is not ex clusive. T I assumes
no liability for appl ications assistance, custom er product design, sof tware performanc e, or infringement of patents
or services described herein.
Mailing Address: Texas Instruments Post Office Box 655303 Dallas, Texas 75265
Copyright 2012, Texas Instruments Incorporated
REGULATORY COMPLIANCE INFORMATION
As noted in the EVM User ’s G uide a nd/or E VM itself, this EVM and/or acc ompanying h ardware m ay or m ay not be
subject to the Federal Communications Commission (FCC) and Industry Canada (IC) rules.
For EVMs not subject t o the above rules, th is evaluation board/k it/module is intended for use for ENGINEERING
DEVELOPMENT , DEMONSTRAT ION OR EVALUATION PURPO SES ONLY and is not c onsidered by TI to be a
finished end product f it for general cons umer use. It gener ates, uses, a nd can radiate rad io frequency en ergy and
has not been tested for com pliance with the limits of computing devices pursuant to part 15 of FCC or ICES-003
rules, which are designed to pr ovide reasonable protection agai nst radio frequency interference. Operation of the
equipment may cause inter ference with radio comm unications, in which case the user at his own expense will be
required to take whatever measures may be required to correct this interference.
General Statement for EVMs including a radio
User Power/Frequency Use Obligations: This radio is intended for development/professional use only in legally
allocated frequency and p ower limits. Any use of radio frequencies and/or power availability of this EVM and its
development applic ation(s) must com ply with loca l laws governing radio spectrum allocatio n and power limits for
this evaluation m odule. It is the user’s s ole responsibi lity to only operat e this radio in leg ally acceptable f requency
space and within lega lly mandated power limitat ions. An y exceptions to this is strictly proh ibited and u nauthorized
by Texas Instruments unless user has obtained appropriate experimental/development licenses from local
regulatory authorities, which is responsibility of user including its acceptable authorization.
SNAU120-April 2012 ADC161S626BEB User’s Guide 7
www.ti.com/esh or contact TI.
For EVMs annotated as FCC – FEDERAL COMM UNICATIONS COMMISSIO N Part 15 Com p l ia nt
Caution
This device complies w ith part 15 of the FCC Rules. O peration is subject to the f ollowing two conditions: (1) T his
device may not cause harm ful interference, and (2) this device must accept any inter ference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
FCC Interference Statement for Class A EVM devices
This equipment has bee n tested and found to c omply with the limits f or a C las s A di gital de vice, pursuant to par t 1 5
of the FCC Rules. Thes e limits are designed to provi de reasonable protection agains t harmful interference when
the equipment is operat ed in a commercial environment. This equipment generates, uses, and can r adiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio com munications. Operation of thi s equipment in a residential area is l ikely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
FCC Interference Statement for Class B EVM devices
This equipment has bee n tested and found to c omply with the limits f or a C las s B di gital de vice, pursuant to par t 1 5
of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installat ion. This equi pment gener ates, use s and can radi ate radio f requenc y energy and, if not instal led
and used in accordanc e with the instructions, m ay cause harmful int erference to radio comm unications. However ,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interferenc e to radio or televis ion recept ion, which c an be d eterm ined by tur ning the equipm ent off and o n,
the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
For EVMs annotated as IC – INDUSTRY CANADA Compliant
This Class A or B digital apparatus complies with Canadian ICES-003.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
Concerning EVMs including radio transmitters
This device complies with Industry Canada lice nce-exempt RSS standar d(s). Operation is subject to the following
two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
Concerning EVMs including detachable antennas
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and
maximum (or lesser) gain approved for the transmitter by Industry Canada. To reduce potential radio interference to
8 ADC161S626BEB User’s Guide SNAU120-April 2012
other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power
(e.i.r.p.) is not more than that necessary for successful communication.
This radio transm itter has been approved by Industry Canada to operate with the ant enna types listed in the user
guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not inclu ded in this list, having a gain greater than th e maximum gain indicated f or that type, are
strictly prohibited for use with this device.
~
Cet appareil numérique de la classe A ou B est conforme à la norme NMB-003 du Canada.
Les changements ou les modific ations pas ex pressém ent approuvés par la partie r esponsable de la conf ormité ont
pu vider l’autorité de l'utilisateur pour actionner l'équipement.
Concernant les EVMs avec appareils radio
Le présent appareil est c onf orme aux CNR d' Indus trie Canada applica bles aux ap parei ls rad io exem pts de lic ence.
L'exploitation est autor isée aux deux conditions s uivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit acc epter tout brouillage radioélectrique subi, même si le brouillage es t s usc ep tib l e d'e n
compromettre le fonctionnement.
Concernant les EVMs avec antennes détachables
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une
antenne d'un type et d'un gain maximal (ou i nférieur) approuvé p our l'émetteur par Industrie Canada. Da ns le but
de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le type
d'antenne et son gain de sorte que la p uissance isotr ope rayonné e équivalente ( p.i.r.e.) ne dép asse pas l'in tensité
nécessaire à l'établissement d'une communication satisfaisante.
Le présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne
énumérés dans le m anuel d’usage et a yant un gain admis sible maximal et l'im pédance requise pour ch aque type
d'antenne. Les types d' antenne non inclus dans cette liste, ou d ont le gain est supéri eur au gain max imal indiqué,
sont strictement interdits pour l'exploitation de l'émetteur.
Important Notice for Users of this Product in Japan】
This development kit is NOT certified as Confirming to Technical Regulations of Radio
Law of Japan!
If you use this product in Japan, you are required by Radio Law of Japan to follow the instructions below with
respect to this product:
(1) Use this product in a shielded room or any other test f ac ility as def in ed in the notification #173 issued b y
Ministry of Internal Af fairs and Communications on March 28, 20 06, based on Sub-section 1.1 of Artic le 6 of the
Ministry’s Rule for Enforcement of Radio Law of Japan,
(2) Use this product only after you obtained the license of T est Radio Station as prov ided in Radio Law of
Japan with respect to this product, or
(3) Use of this product only after you obtained the Technical Regulations Conformity Certification as
provided in Radio Law of Japan with respect to this product.
Also, please do not transfer this product, unless you give the same notice above to the transferee.
Please note that if you could not f ollow the instructions above, you will be subject to penalties of Radio Law of
Japan.
Texas Instruments Japan Limited
SNAU120-April 2012 ADC161S626BEB User’s Guide 9
(address) 24-1, Nishi-Shinjuku 6 chome, Shinjukku-ku, Tokyo, Japan
http://www.tij.co.jp
【ご使用にあたっての注意】
本開発キットは技術基準適合証明を受けておりません。
本製品のご使用に際しては、電波法遵守のため、以下のいずれかの措置を取っていただく必要がありますのでご注
意ください。
（１）電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗
室等の試験設備でご使用いただく。
（２）実験局の免許を取得後ご使用いただく。
（３）技術基準適合証明を取得後ご使用いただく。
なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないも
のとします。
上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。
日本テキサス・インスツルメンツ株式会社
東京都新宿区西新宿６丁目２４番１号
西新宿三井ビル
http://www.tij.co.jp
10 ADC161S626BEB User’s Guide SNAU120-April 2012
EVALUATION BOARD/KIT/MODULE (EVM)
WARNINGS, RESTRICTIONS AND DISCLAIMERS
For Feasibility Evaluation Only, in Laboratory/Development Environments. Unless otherwise indicated, this
EVM is not a finished electrical equipment and not intended for consumer use. It is intended solely for use for
preliminary feasibility evaluation in laboratory/development environments by technically qualified electronics experts
who are familiar with the dangers and appl ication r isk s ass ociated with handl ing elec trica l m echanica l com ponen ts,
systems and subsystems. It should not be used as all or part of a finished end product.
Your Sole Responsibility and Risk. You acknowledge, represent and agree that:
1. You have unique knowledge concerning Federal, State and local regulatory requirements (including but not
limited to Food and Drug Administration regulations, if applicable) which relate to your products and which
relate to your use (and/or that of your employees, affiliates, contractors or designees) of the EVM for
evaluation, testing and other purposes.
2. You have full and exclusive respons ibility to assure the safet y and compliance of your products with all such
laws and other applicable regulatory requirements, and also to assure the safety of any activities to be
conducted by you a nd/or your employees , aff iliates, contrac tors or designees , using the EVM. Further, you are
responsible to assure that any interfaces (electronic and/or mechanical) between the EVM and any human
body are designed with suit able isolati on and means to safely lim it accessible lea kage c urrents to m inimize the
risk of electrical shock hazard.
3. You will employ reasonable safeguards to ensure that your use of the EVM will not result in any property
damage, injury or death, even if the EVM should fail to perform as described or expected.
4. You will take care of proper disposal and recycling of the EVM’s electronic components and packing materials.
Certain Instructions. It is important to operate this EVM within TI’s recommended specifications and
environmental considerations per the user guidelines. Exceeding the specified EVM ratings (including but not
limited to input and output voltage, current, power, and environmental ranges) may cause property damage,
personal injury or deat h. If there are questions concerning thes e ratings please contact a TI field repres entative
prior to connecting i nterface el ectronic s including input po wer and i ntended l oads. An y loads ap plied outs ide of the
specified output ra nge m ay result in un intended and/or inaccurate o peratio n and/o r possible perm anent dam age to
the EVM and/or interface electronics. Please consult the EVM User's Guide prior to connecting any load to the EVM
output. If there is unc ertainty as to the load spec ification, please contact a T I field representative. During n ormal
operation, some circuit components may have case temperatures greater than 60
are maintained at a norm al ambient operatin g temperature. T hese com ponents include but ar e not limited to li near
regulators, switching transistors, pass transistors, and current sense resistors which can be identified using the
EVM schematic located in the EVM User's Guide. When p lacing measurement probes near these devices during
normal operation, please be aware that these devices may be very warm to the touch. As with all electronic
evaluation tools, only qualified personnel knowledgeable in electronic measurement and diagnostics normally found
in development environments should use these EVMs.
Agreement to Defend, Indemnify and Hold Harmless. You agree to defen d, indemnify and hold T I, its licensors
and their representatives harmless from and against any and all claims, damages, losses, expenses, costs and
liabilities (collective ly, "Claims") arising out of or in connection with any use of the EVM that is not in accordanc e
with the terms of the agr eement. This obligation shal l apply whether Claims ar ise under law of tort or contract or
any other legal theory, and even if the EVM fails to perform as described or expected.
Safety-Critical or Life-Crit ical Applications. If you intend to evaluate the com ponents for possible us e in safety
critical applications (such as life support) where a fa ilure of the T I product wo uld reasonabl y be expecte d to cause
severe personal inj ur y or death, suc h as de vic es wh ich are classif ied as FDA Clas s III or sim ilar cl assif ication, th en
you must specifically notify TI of such intent and enter into a separate Assurance and Indemnity Agreement.
o
C as long as the input and output
SNAU120-April 2012 ADC161S626BEB User’s Guide 11
IMPORTANT NOTICE
Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications,
enhancements, improvem ents, and other changes to its products and s ervices at any time and to dis continue any
product or service without notice. Customers should obtain the latest relevant information bef ore placing orders and
should verify that such information is current and c omplete. All products are sold subject to TI’s terms and conditions
of sale supplied at the time of order acknowledgment.
TI warrants performance of its hardware products t o the specifications applicable at the time of sale in acc ordance
with TI’s standard warranty. Testing and other qualit y control tec hniques are used to the extent T I deems nec essary
to support this warranty. Except where mandated by government requirements, testing of all parameters of each
product is not necessarily performed.
TI assumes no liability for applications assistance or customer product design. Customers are responsible for t heir
products and applications using TI components. To minimize the risks associated with customer products and
applications, customers should provide adequate des i gn and operating saf eguards.
TI does not warrant or represent that any license, either express or im plied, is granted under any TI patent right,
copyright, mask work right, or other TI intellect ual property right relating t o any combination, machi ne, or process in
which TI products or services are used. Information published by TI regarding third-party product s or services does
not constitute a license from TI to use suc h products or services or a warranty or endorsement thereof. Use of such
information may require a license from a third party under the patents or other intellectual property of the third party,
or a license from TI under the patents or other intellectual property of TI. Reproduction of information in TI data
books or data sheets is permissible only if reproduc tion is without alteration and is accompanied by all associated
warranties, conditions, limitations, and notices.
Reproduction of this information with alteration is an unfair and deceptive business practice. TI is not responsible or
liable for such altered documentation. Resale of TI products or services with st atements different from or beyond t he
parameters stated by TI for that product or service voids all express and any implied warranties for the associated TI
product or service and is an unfair and deceptive business practice. TI is not responsible or liable for any such
statements.
TI products are not authorized for use in safety-critical applications (such as life support) where a failure of the TI
product would reasonabl y be expected to cause severe personal i njury or death, unless officers of the parties have
executed an agreement specifically governing such use. Buyers represent that they have all necessary expertise in
the safety and regulatory ramifications of their applications, and acknowledge and agree that they are solely
responsible for all legal, regulatory and safety-related requirem ents concerning their products and any use of TI
products in such safety-critical applications, not withst anding any applications-related information or s upport t hat m ay
be provided by TI. Further, Buyers must fully indemnify TI and its represent at i ves against any damages arising out of
the use of TI products in such safety-critical applications.
TI products are neither designed nor int ended for use in m ilitary/aerospace appl ications or environments unless the
TI products are specifically desi gnated by TI as military-grade or "enhanced plastic. " Only products designated by TI
as military-grade meet military specifications. B uyers ack nowledge and agree that any such use of TI products which
TI has not designated as military-grade is solely at the Buyer's risk, and that they are solely responsible for
compliance with all legal and regulatory requirements in connection with such use.
TI products are neither designed nor intended for use in automotive applications or environments unless the specific
TI products are designat ed by TI as compliant with ISO/TS 16949 requirements. Buyers acknowledge and agree
that, if they use any non-designated products in automotive applications, TI will not be responsi ble for any failure to
meet such requirements.
Following are URLs where you can obtain information on other Texas Instruments products and application
solutions:
Products Applications
Amplifiers amplifier.ti.com Audio www.ti.com/audio
Data Converters dataconverter.ti.com Automotive www.ti.com/automotive
DSP dsp.ti.com Broadband www.ti.com/broadband
Interface interface.ti.com Digital Control www.ti.com/digitalcontrol
Logic logic.ti.com Military www.ti.com/military
Power Mgmt power.ti.com Optical Networking www.ti.com/opticalnetwork
Microcontrollers microcontroller.ti.com Security www.ti.com/security
RFID www.ti-rfid.com Telephony www.ti.com/telephony
Low Power www.ti.com/lpw Video & Imaging www.ti.com/video
Wireless Wireless www.ti.com/wireless
12 ADC161S626BEB User’s Guide SNAU120-April 2012
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2007, Texas Instruments Incorporated
SNAU120-April 2012 ADC161S626BEB User’s Guide 13
Loading...
