Texas Instruments CY74FCT16646TPVCT, CY74FCT16646TPVC, CY74FCT16646ETPVCT, CY74FCT16646ETPVC, CY74FCT16646CTPVCT Datasheet

16-Bit Registered Transceivers

CY74FCT16646T

CY74FCT162646T

SCCS060 - August 1994 - Revised March 2000

Data sheet acquired from Cypress Semiconductor Corporation.
Data sheet modified to remove devices not offered.

Copyright © 2000, Texas Instruments Incorporated

Features

• FCT-E speed at 3.8 ns

• Power-off disable outputs permits live insertion

• Edge-rate control circuitry for significantly improved
noise characteristics

• Typical output skew < 250 ps

• ESD > 2000V

• TSSOP (19.6-mil pitch) and SSOP (25-mil pitch)
packages

• Industrial temperature range of −40˚C to +85˚C

•V

CC

= 5V ± 10%

CY74FCT16646T Features:

• 64 mA sink current, 32 mA source current

• Typical V

OLP

(ground bounce) <1.0V at VCC = 5V,

TA = 25˚C

CY74FCT162646T Features:

• Balanced 24 mA output drivers

• Reduced system switching noise

• Typical V

OLP

(ground bounce) <0.6V at VCC = 5V,

TA= 25˚C

Functional Description

The CY74FCT16646T and CY74FCT162646T 16-bit
transceivers are three-state, D-type registers, and control
circuitry arranged for multiplexedtransmission of data directly
from the input bus or from the internal registers. Data on the A
or B bus will be clocked into the registers as the appropriate
clock pin goes to a HIGH logic level. Output Enable (

OE) and
direction pins (DIR) are provided to control the transceiver
function. In the transceiver mode, data present at the high
impedance port may be stored in either the A or B register, or
in both. The select controls can multiplex stored and real-time
(transparent mode) data. The direction control determines
which bus will receive data when the Output Enable (

OE) is

ActiveLOW.In the isolation mode (Output Enable(

OE)HIGH),
A data may be stored in the B register and/or B data may be
stored in the A register. The output buffers are designed with
a power-off disable feature that allows live insertion of boards.

The CY74FCT16646T is ideally suited for driving
high-capacitance loads and low-impedance backplanes.

The CY74FCT162646T has 24-mA balanced output drivers
with current limiting resistors in the outputs. This reduces the
need for external terminating resistors and provides for
minimal undershoot and reduced ground bounce. The
CY74FCT162646T is ideal for driving transmission lines.

Logic Block Diagrams

FCT16646-1

C

D

1

B

1

C

D

1

A

1

TO7 OTHER CHANNELS

1

SAB

1

CLKAB

1

CLKBA

1

DIR

1

SBA

1

OE

B REG

A REG

C

D

2

B

1

C

D

2A1

2

SAB

2

CLKAB

2

CLKBA

2

DIR

2

SBA

2

OE

B REG

FCT16646-2

TO 7 OTHER CHANNELS

A REG

CY74FCT16646T

CY74FCT162646T

2

GND

1

DIR

SSOP/TSSOP

Top View

1

CLKAB

1

SAB

1A1
1A2

1

CLKBA

1

SBA

1B1

1

OE

GND

GND

V

CC

1A3

V

CC

GND

1A4
1A5

1A6
1A7
1A8
2A1
2A2
2A3

2A4

GND

2A5
2A6

V

CC
2A7
2A8

2

SAB

2

CLKAB

1
2

3
4

5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28

56
55

54
53

52
51
50
49
48
47
46
45
44
43
42
41
40
39
38
37
36
35
34
33
32
31
30
29

GND

2

DIR

1B2

1B3
1B4
1B5

1B6
1B7
1B8
2B1
2B2
2B3
GND
2B4
2B5
2B6

V

CC
2B7
2B8
GND
2

SBA

2

CLKBA

2

OE

FCT16646-3

Pin Configuration

Pin Description

Pin Names Description

A Data Register A Inputs

Data Register B Outputs

B Data Register B Inputs

Data Register A Outputs
CLKAB, CLKBA Clock Pulse Inputs
SAB, SBA Output Data Source Select Inputs
DIR Direction
OE Output Enable (Active LOW)

CY74FCT16646T

CY74FCT162646T

3

Function Table

[1]

Inputs Data I/O

[2]

Function

OE DIR CLKAB CLKBA SAB SBA A B

H
H

X
X

H or L H or L X

X

X
X

Input Input Isolation

Store A and B Data

L
L

L
L

X
X

X

H or L

X
X

LHOutput Input Real Time B Data to A Bus

Stored B Data to A Bus

L
L

H
H

X

H or L

X
X

L

H

X
X

Input Output Real Time A Data to Bus

Stored A Data to B Bus

Notes:

1. H = HIGH Voltage Level. L = LOW Voltage Level. X = Don’t Care

. = LOW-to-HIGH Transition

2. The data output functions may beenabledor disabled by various signals at the OE or DIR inputs. Data input functions arealways enabled, i.e., data at the
bus pins will be stored on every LOW-to-HIGH transition on the clock inputs.

3. Cannot transfer data to A-bus and B-bus simultaneously.

BUS BBUS A

DIRLOELCLKAB

X

SAB

X

BUS BBUS A

DIR

H
L
X

OE

L
L
H

CLKAB

X

SAB

X
X
X

SBA

X
X
X

BUS

BBUS A

DIRHOE

L

SAB

L

SBA

X

BUS ABUS A

DIR

L
H

OE

L
L

SAB

X
H

SBA

H
X

Real-Time Transfer

BusB to BusA

Real-TimeTransfer

BusA to BusB

Storagefrom

A and/or B

TransferStoredData

to A and/orB

CLKBA

X

CLKABXCLKBA

X

SBA

L

CLKBA

X

CLKAB

X

HorL

CLKBA

HorL

X

[3]

CY74FCT16646T

CY74FCT162646T

4

Maximum Ratings

[4]

(Above which the useful life may be impaired. For user guide­lines, not tested.)

Storage Temperature .....................Com’l −55°C to +125°C

Ambient Temperature with

Power Applied.................................Com’l −55°C to +125°C

DC Input Voltage .................................................−0.5V to +7.0V

DC Output Voltage..............................................−0.5V to +7.0V

DC Output Current

(Maximum Sink Current/Pin)...........................−60 to +120 mA

Power Dissipation..........................................................1.0W

Static Discharge Voltage............................................>2001V

(per MIL-STD-883, Method 3015)

Operating Range

Range

Ambient

Temperature V

CC

Industrial −40°C to +85°C 5V ± 10%

Electrical Characteristics Over the Operating Range

Parameter Description Test Conditions Min. Typ.

[5]

Max. Unit

V

IH

Input HIGH Voltage 2.0 V

V

IL

Input LOW Voltage 0.8 V

V

H

Input Hysteresis

[6]

100 mV

V

IK

Input Clamp Diode Voltage VCC=Min., IIN=−18 mA −0.7 −1.2 V

I

IH

Input HIGH Current VCC=Max., VI=V

CC

±1 µA

I

IL

Input LOW Current VCC=Max., VI=GND ±1 µA

I

OZH

High Impedance Output Current
(Three-State Output pins)

VCC=Max., V

OUT

=2.7V ±1 µA

I

OZL

High Impedance Output Current
(Three-State Output pins)

VCC=Max., V

OUT

=0.5V ±1 µA

I

OS

Short Circuit Current

[7]

VCC=Max., V

OUT

=GND −80 −140 −200 mA

I

O

Output Drive Current

[7]

VCC=Max., V

OUT

=2.5V −50 −180 mA

I

OFF

Power-Off Disable VCC=0V, V

OUT

≤4.5V

[9]

±1 µA

Output Drive Characteristics for CY74FCT16646T

Parameter Description Test Conditions Min. Typ.

[5]

Max. Unit

V

OH

Output HIGH Voltage VCC=Min., IOH=−3 mA 2.5 3.5 V

VCC=Min., IOH=−15 mA 2.4 3.5 V
VCC=Min., IOH=−32 mA 2.0 3.0 V

V

OL

Output LOW Voltage VCC=Min., IOL=64 mA 0.2 0.55 V

Output Drive Characteristics for CY74FCT162646T

Parameter Description Test Conditions Min. Typ.

[5]

Max. Unit

I

ODL

Output LOW Current

[7]

VCC=5V, VIN=VIH or VIL, V

OUT

=1.5V 60 115 150 mA

I

ODH

Output HIGH Current

[7]

VCC=5V, VIN=VIH or VIL, V

OUT

=1.5V −60 −115 −150 mA

V

OH

Output HIGH Voltage VCC=Min., IOH=−24 mA 2.4 3.3 V

V

OL

Output LOW Voltage VCC=Min., IOL=24 mA 0.3 0.55 V

Notes:

4. Stresses greater thanthose listed under Maximum Ratings maycausepermanent damage tothe device. This is a stressrating only and functional operation
of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied. Exposure to absolute
maximum rating conditions for extended periods may affect reliability.

5. Typical values are at V

CC

= 5.0V, TA= +25˚C ambient.

6. This parameter is specified but not tested.

7. Not more thanone output should be shorted at a time.Duration of short should not exceedone second. The use of high-speed testapparatus and/or sample
and hold techniquesare preferable in orderto minimize internal chip heating and moreaccurately reflect operational values.Otherwise prolonged shorting of
a high outputmay raise the chip temperature wellabove normal and thereby causeinvalid readings in other parametrics tests.In any sequence of parameter
tests, IOS tests should be performed last.

8. This parameter is measured at characterization but not tested.

9. Tested at +25˚C.

CY74FCT16646T

CY74FCT162646T

5

Capacitance (T

A

= +25˚C, f = 1.0 MHz)

Symbol Description

[8]

Conditions Typ. Max. Unit

C

IN

Input Capacitance VIN = 0V 4.5 6.0 pF

C

OUT

Output Capacitance V

OUT

=0V 5.5 8.0 pF

Power Supply Characteristics

Parameter Description Test Conditions

[10]

Min. Typ.

[5]

Max. Unit

I

CC

Quiescent PowerSupply Current VCC=Max. VIN<0.2V

V

IN>VCC

−0.2V

— 5 500 µA

∆I

CC

Quiescent Power Supply Current
TTL Inputs HIGH

VCC = Max.
V

IN

=3.4V

[11]

— 0.5 1.5 mA

I

CCD

Dynamic Power Supply
Current

[12]

VCC=Max.
Outputs Open
DIR=OE=GND
One-Bit Toggling
50% Duty Cycle

VIN=VCCor
V

IN

=GND

— 75 120 µA/MHz

I

C

Total Power Supply Current

[13]

VCC=Max.
Outputs Open
f

o

=10 MHz (CLKBA)
50% Duty Cycle
DIR=

OE=GND
One-Bit Toggling
f

1

=5 MHz

50% Duty Cycle

VIN=VCCor
V

IN

=GND

— 0.8 1.7 mA

VIN=3.4V or
V

IN

=GND

— 1.3 3.2

VCC=Max.
Outputs Open
f

o

=10 MHz (CLKBA)
50% Duty Cycle
DIR=

OE=GND
Sixteen-Bits Toggling
f

1

=2.5 MHz

50% Duty Cycle

VIN=VCCor
V

IN

=GND

— 3.8 6.5

[14]

VIN=3.4V or
V

IN

=GND

— 8.3 20.0

[14]

Notes:

10. For conditions shown as Max. or Min., use appropriate value specified under Electrical Characteristics for the applicable device type.

11. Per TTL driven input (V

IN

=3.4V); all other inputs at VCC or GND.

12. This parameter is not directly testable, but is derived for use in Total Power Supply calculations.

13. I

C

=I

QUIESCENT

+ I

INPUTS

+ I

DYNAMIC

IC=ICC+∆ICCDHNT+I

CCD(f0

/2 + f1N1)

I

CC

= Quiescent Current with CMOS input levels

∆I

CC

= Power Supply Current for a TTL HIGH input (VIN=3.4V)

D

H

= Duty Cycle for TTL inputs HIGH

N

T

= Number of TTL inputs at D

H

I

CCD

= Dynamic Current caused by an input transition pair (HLH or LHL)

f

0

= Clock frequency for registered devices, otherwise zero

f

1

= Input signal frequency

N

1

= Number of inputs changing at f

1

All currents are in milliamps and all frequencies are in megahertz.

14. Values for these conditions are examples of the ICC formula. These limits are specified but not tested.

CY74FCT16646T

CY74FCT162646T

6

Switching Characteristics Over the Operating Range

[15]

Parameter Description

CY74FCT16646T

CY74FCT16646AT

CY74FCT162646AT

UnitMin. Max. Min. Max. Fig. No.

[16]

t

PLH

t

PHL

Propagation Delay
Bus to Bus

1.5 9.0 1.5 6.3 ns 1, 2

t

PZH

t

PZL

Output Enable Time
DIR or

OE to Bus

1.5 14.0 1.5 9.8 ns 1, 7, 8

t

PHZ

t

PLZ

Output Disable Time
DIR or

OE to Bus

1.5 9.0 1.5 6.3 ns 1, 7, 8

t

PLH

t

PHL

Propagation Delay
Clock to Bus

1.5 9.0 1.5 6.3 ns 1, 5

t

PLH

t

PHL

Propagation Delay
SBA or SAB to Bus

1.5 11.0 1.5 7.7 ns 1,5

t

SU

Set-Up Time HIGH or
LOW Bus to Clock

2.0 — 2.0 — ns 4

t

H

Hold Time HIGH or
LOW Bus to Clock

1.5 — 1.5 — ns 4

t

W

Clock Pulse Width
HIGH or LOW

5.0 — 5.0 — ns 6

t

SK(O)

Output Skew

[17]

— 0.5 — 0.5 ns —

Parameter Description

CY74FCT16646CT

CY74FCT162646CT

CY74FCT16646ET

CY74FCT162646ET

UnitMin. Max. Min. Max. Fig. No.

[16]

t

PLH

t

PHL

Propagation Delay
Bus to Bus

1.5 5.4 1.5 3.8 ns 1, 2

t

PZH

t

PZL

Output Enable Time
DIR or

OE to Bus

1.5 7.8 1.5 4.8 ns 1, 7, 8

t

PHZ

t

PLZ

Output Disable Time
DIR or

OE to Bus

1.5 6.3 1.5 4.0 ns 1, 7, 8

t

PLH

t

PHL

Propagation Delay
Clock to Bus

1.5 5.7 1.5 3.8 ns 1, 5

t

PLH

t

PHL

Propagation Delay
SBA or SAB to Bus

1.5 6.2 1.5 4.2 ns 1,5

t

SU

Set-Up Time HIGH or
LOW Bus to Clock

2.0 — 2.0 — ns 4

t

H

Hold Time HIGH or
LOW Bus to Clock

1.5 — 0.0 — ns 4

t

W

Clock Pulse Width
HIGH or LOW

5.0 — 3.0 — ns 6

t

SK(O)

Output Skew

[17]

— 0.5 — 0.5 ns —

Notes:

15. Minimum limits are specified but not tested on Propagation Delays.

16. See “Parameter Measurement Information” in the General Information section.

17. Skew any two outputs of the same package switching in the same direction. This parameter is ensured by design.

CY74FCT16646T

CY74FCT162646T

7

Ordering Information CY74FCT16646

Speed

(ns) Ordering Code

Package

Name Package Type

Operating

Range

3.8 CY74FCT16646ETPVC/PVCT O56 56-Lead (300-Mil) SSOP Industrial

5.4 CY74FCT16646CTPVC/PVCT O56 56-Lead (300-Mil) SSOP Industrial

6.3 CY74FCT16646ATPVC/PVCT O56 56-Lead (300-Mil) SSOP Industrial

9.0 CY74FCT16646TPVC/PVCT O56 56-Lead (300-Mil) SSOP Industrial

Ordering Information CY74FCT162646

Speed

(ns) Ordering Code

Package

Name Package Type

Operating

Range

3.8 74FCT162646ETPACT Z56 56-Lead (240-Mil) TSSOP Industrial
CY74FCT162646ETPVC O56 56-Lead (300-Mil) SSOP
74FCT162646ETPVCT O56 56-Lead (300-Mil) SSOP

5.4 74FCT162646CTPACT Z56 56-Lead (240-Mil) TSSOP Industrial
CY74FCT162646CTPVC O56 56-Lead (300-Mil) SSOP
74FCT162646CTPVCT O56 56-Lead (300-Mil) SSOP

6.3 74FCT162646ATPACT Z56 56-Lead (240-Mil) TSSOP Industrial
CY74FCT162646ATPVC O56 56-Lead (300-Mil) SSOP
74FCT162646ATPVCT O56 56-Lead (300-Mil) SSOP

CY74FCT16646T

CY74FCT162646T

8

Package Diagrams

56-Lead Shrunk Small Outline Package O56

56-Lead Thin Shrunk Small Outline Package Z56

IMPORTANT NOTICE

T exas Instruments and its subsidiaries (TI) reserve the right to make changes to their products or to discontinue
any product or service without notice, and advise customers to obtain the latest version of relevant information
to verify, before placing orders, that information being relied on is current and complete. All products are sold
subject to the terms and conditions of sale supplied at the time of order acknowledgement, including those
pertaining to warranty, patent infringement, and limitation of liability.

TI warrants performance of its semiconductor products to the specifications applicable at the time of sale in
accordance with TI’s standard warranty. Testing and other quality control techniques are utilized to the extent
TI deems necessary to support this warranty. Specific testing of all parameters of each device is not necessarily
performed, except those mandated by government requirements.

CERT AIN APPLICATIONS USING SEMICONDUCTOR PRODUCTS MAY INVOLVE POTENTIAL RISKS OF
DEATH, PERSONAL INJURY, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE (“CRITICAL
APPLICATIONS”). TI SEMICONDUCTOR PRODUCTS ARE NOT DESIGNED, AUTHORIZED, OR
WARRANTED TO BE SUITABLE FOR USE IN LIFE-SUPPORT DEVICES OR SYSTEMS OR OTHER
CRITICAL APPLICATIONS. INCLUSION OF TI PRODUCTS IN SUCH APPLICA TIONS IS UNDERSTOOD T O
BE FULLY AT THE CUSTOMER’S RISK.

In order to minimize risks associated with the customer’s applications, adequate design and operating
safeguards must be provided by the customer to minimize inherent or procedural hazards.

TI assumes no liability for applications assistance or customer product design. TI does not warrant or represent
that any license, either express or implied, is granted under any patent right, copyright, mask work right, or other
intellectual property right of TI covering or relating to any combination, machine, or process in which such
semiconductor products or services might be or are used. TI’s publication of information regarding any third
party’s products or services does not constitute TI’s approval, warranty or endorsement thereof.

Copyright  2000, Texas Instruments Incorporated
