Tevion RS 430 User Manual

USERS MANUAL CORDLESS HEADPHONES

Model: RS 430 11/04

CORDLESS HEADPHONES
TECHNICAL SPECIFICATIONS

Supply Voltage
Carrier Frequency
Maximum Range
Transmission

230-240V ~ AC 50 Hz
434 MHz
100 Meters
Stereo

PACKAGE CONTENTS

1 x 434MHz FM Transmitter
1 x 12V 200mA DC Power Pack (Transmitter)
1 x Rechargeable remote receiver headphones
2 x Ni-Cd Rechargeable Batteries
1 x 3.5mm socket to 0.25” Adaptor
1 x RCA plug to 3.5mm socket Adaptor
1 x Instruction Manual

Confirm all items are present before disposing of carton.

SAFETY INSTRUCTIONS

Carefully read this manual before using this equipment. Make sure that you know how the cordless
headphone functions and how to operate it. Maintain the equipment in accordance with the
instructions to ensure that it functions properly. Keep this manual with the equipment. If the
equipment is to be used by a third party, this instruction manual must be supplied with it. The safety
instructions, by themselves, do not eliminate danger completely, and proper accident prevention
measures must always be used.

BEFORE INITIAL USE

Remove all packaging. For safety do not immerse any part of the cordless headphone or power
adaptor in water or any other liquid. Check for any damage that may have occurred during transit.
Do not use if the equipment is damaged in any way or if the adaptor or supply cord is damaged.
Immediately return to supplier for replacement or repair.

OPERATION

This cordless stereo headphone system has been designed for general home use only. It is not
designed for commercial or industrial use.

Initial set up

Unwind the 12VDC 200mA AC power pack lead fully and plug the power pack into a suitable
electrical wall socket, 230-240V ~.

Plug the AC power pack DC output supply plug into the DC input socket on the rear of the
transmitter.

Remove the cover and install two rechargeable batteries into the right headphone unit, taking note
that only NiCd rechargeable batteries may be used and of the battery installation instruction details
inside. Plug the short recharge lead from the transmitter into the headphone charge socket.

Switch the power ON at the wall and the Headphones to the OFF position while charging. Leave on
charge for 24 hours before initial use to ensure batteries are at full charge. Red light will illuminate
on transmitter when charging in process. When charging is complete, headphones are ready for use.

Use

Unplug the charger cable from the headphones.

Connect the transmitter audio input lead (long lead) into a suitable audio output jack (use one of the
supplied adaptors if required). Ensure that the transmitter has an input signal from the music source,
a green light on the transmitter will indicate that it is receiving signal and is transmitting.

Turn the headphones on and adjust the tune control until a clear signal is received, a green light on
the transmitter will indicate that it is transmitting.

Adjust the volume on the headphones to suit.

When finished ensure that the headphones are turned off and plugged back into the charger lead of
the transmitter to recharge the batteries before storing or reuse.

Interference

If you receive interference/static through the headphone set this can be eliminated by adjusting the
transmitter frequency on the rear of the transmitter (frequency adjust) and re-tuning the headphone
to the new frequency.

ELECTRICAL SAFETY

When using electric equipment always observe safety regulations where applicable to reduce the
risk of fire, electric shock and personal injury.
Always check that the power supply corresponds to the voltage on the rating plate.

Supply cord and plug.

Always fully unwind any cord to avoid overheating. Never allow any supply cord to come in
contact with hot objects. Do not carry the equipment by the cord. Disconnect by first switching off
the mains outlet, grasping the adaptor and pulling it out gently.

If the adaptor or adaptor supply cord is damaged, it must be replaced by the manufacturer, its
service agent or a similarly qualified person in order to avoid a hazard. Only use authorised
replacement parts.

Children.
Caution. Keep out of reach of children.

This appliance is not intended for use by young children or infirm persons without supervision.
Young children must be supervised to ensure that they do not play with the equipment..

Water.
For your safety do not immerse any part of this equipment in water.

Do not use with wet hands or use in damp situations

Handling..
Do not drop the product as this may cause damage or damage internal components. Do not use this
equipment if it has been damaged in any way, immersed in water, the adaptor or supply cord is
damaged or the operation is faulty. Contact with any damaged equipment could result in electric
shock.

Batteries.

Only use the rechargeable NiCd batteries as supplied, seek professional assistance if unsure as to
which batteries are acceptable for use as replacements.
