Page 1
Technical Description and
Operating Instructions
Active subwoofer
US 5305/6
General notes and information
Proper use
Only use the unit as described in these operating instructions. Any other use will be deemed as not in accordance with
the instructions and may lead to damage of property or even
persons. The manufacturer accepts no liability for damage
caused by use not in accordance with the
is intended for private use.
Before operating the speakers please read the safety
notes and operating instructions carefully. This is the
only way to use all functions safely and reliably. Keep
the operating instructions safe and pass them on to anyone
who may own the unit after you.
Notice
The information in this document may change without prior
notice and in no way constitutes any liability on the part of
Lautsprecher Teufel GmbH. No part of these instructions may
be reproduced in any form or be broadcasted in any way electronically, mechanically, by photocopy or recording without the
written permission of Lautsprecher Teufel GmbH.
instructions. The unit
... makes you happy
Original packaging
If you wish to exercise your eight-week right of return, we ask
that you be absolutely sure to hold onto the packaging. We can
only accept the return of a device WITH THE ORIGINAL PACKAGING. Empty boxes are not available!
Complaints
In case of a complaint we implicitly need your invoice number
and the serial or lot number for processing. The serial number
can be found on the back side of the device.
Many thanks for your support!
Contact
For questions, suggestions or criticism please contact our
customer service department:
Lautsprecher Teufel GmbH
Gewerbehof Buelowbogen
Buelowstrasse 66
10783 Berlin (Germany)
Phone 00800 - 200 300 40 (free of charge)
Fax: +49 (0)30 / 300 930 930
E-mail: [email protected]
www.teufelaudio.com
Page 2
Safety notes
Caution icons
You will fi nd the following caution icons in these instructions:
Danger
Attention
Danger
shocks.
• The device is only suitable for use with a power supply volt-
• Check the unit regularly for damage.
• If the unit emits smoke or smells of burning or other
• The standby button does not disconnect the unit from the
• Never open the unit’s housing.
• Use only accessories specifi ed by the manufacturer.
• Do not insert any objects through the vent slots in the
• Never touch the power plug with damp hands.
Danger
• Do not allow children to play with the unit or the packing
• Ensure that children do not remove small parts from the
High risk ! Failure to observe the warning may result
=
in severe personal injury or death.
Moderate risk ! Failure to observe the warning may
=
r e s u l t i n p r o p e r t y d a m a g e .
Minor risk! Points which should be observed when
=
handling the unit.
Risk of electric shock!
Faulty installation of electrical equipment or
mains voltage which is too high can cause electric
age of 230 V ~ / 50 Hz. Make sure that the mains voltage
is correct. For more information, refer to the nameplate.
If the unit’s case or mains cable is defective or shows
other signs of visible damage, disconnect the power plug
immediately from the socket and do not operate the
device.
unusual odours, disconnect it immediately from the power
supply and do not operate it.
power supply. For this reason, connect it to an easily accessible socket so that you can quickly disconnect it from
the power supply in the event of faults.
Repairs may only be carried out by an authorised specialist workshop. Only parts which conform with the original
unit specifi cations may be used in this case. There are
electrical and mechanical parts in this unit which are necessary in order to avoid exposure to sources of danger.
housing.
Danger to children!
Children can become trapped in the packing fi lm
when playing and suffocate.
fi lm. Danger of suffocation.
unit or take them off of the unit (e.g. control knobs or plug
adapters). They could swallow the parts and choke. Never
allow children to operate electrical devices unsupervised.
Danger to hearing
Loud noise may lead to hearing loss.
Particularly when the subwoofer has been set
to maximum volume and the unit is activated, very high
noise pressure may suddenly be produced. This may have
psychological consequences and also cause physical injury.
Children and pets are particularly at risk.
• Set your signal source unit volume control to a low setting.
• When the volume is set high, always keep a certain dis-
tance from the unit and never place your ear directly on
the speaker.
• To avoid damage to health, avoid extended listening at
high volume.
Danger
• Never use the subwoofer unmounted in vehicles, in unsta-
• Place the subwoofer on the ground only.
• Place the speaker in such a way th at it cannot be knocked
• Do not place the unit near sources of heat (e.g. heaters,
Attention
• Do not place open fl ames such as burning candles or
• Ensure suffi cient ventilation.
• Do not place the unit in direct sunlight.
• Only use the unit in indoor areas.
• Do not operate the unit in moist areas and protect it from
Danger of injury/damage!
Incorrect location may result in damage.
ble locations, on wobbly stands or furniture, on underdimensioned brackets etc. The subwoofer could tip or fall
down and cause injury to persons or be damaged.
over unseen and make sure that the cables do not pose a
trip hazard.
ovens, other heat generating equipment such as amplifi ers etc.).
Fire hazard!
Improper use may lead to damage or fi re.
similar on the unit.
drops of water and splash water.
Also take care not to stand vases or other containers
fi lled with liquid on or near the unit in order to avoid liquid
getting into the housing. If water or other foreign objects
penetrate the case, immediately disconnect the power
plug. Send the unit to our service address in this case.
2
Page 3
햲 1 x active subwoofer US 5305/6
햳 1 x power cord
햴 4 x stands with screws
햵 4 x blind plugs
햶 3 x stereo cinch cord
햷 speaker cable
Check that all items have been delivered and that nothing is damaged. If you fi nd damage, do not operate the
device; instead contact our service department.
Product contents
햳
햲
햴
햵
햶
햷
Dimensions (WxHxD) 210 x 492 x 500 mm (incl. stands)
Weight 17.6 kg
Operating voltage: 230 V~/50 Hz
Max. power consumption 350 watts
Technical changes reserved!
You can fi nd further technical data on our website.
Mounting the speaker stands
The speaker stands ensure a safe stand of the subwoofer, they
minimise vibrations and create suffi cient
1. Depending on whether you want to arrange your subwoofer in
a horizontal or vertical position, screw-tighten the 4 speaker
stands 햴 on the bottom side or on the side wall of the subwoofer using the enclosed screws.
2. Insert the 4 blind plugs 햵 in the unused holes.
3. When arranging the subwoofer, make sure that it has a stable position to prevent vibrations.
4. The Teufel logo magnetically adheres to the subwoofer and
can easily be removed. Reposition it in case of a lying arrangement.
distance to the fl oor.
Technical data
This product conforms with Council of the European
Union guidelines 2004/108/EC and 2006/95/EC.
Preparation
햵
햴
3
Page 4
Control elements and connections
12345
Item Name Description
1Line In Analogue 5.1 audio input jacks
2 Auto On Level
Subwoofer
3
Volume
4Power Mode
5– Power LED
6 Speaker Output jacks for satellite speakers
7
Power On/Off
–
8
9
–
6
Set the sensitivity for automatic
activation
Volume control for the subwoofer
Automatic activation/deactivation
or permanently activated
Mains switch
Connection jack for power cord
Fuse holder
햳
4
7
8
9
Page 5
Setup notes
• Select a stable, level base.
• Make sure that the environment is clean and free from dust.
• Avoid placing the unit close to sources of heat or in direct
sunlight.
• Arrange the connector cables so that they do not pose a trip
hazard.
• Do not place any heavy objects on the cables or the speakers.
• The location of the subwoofer can be freely selected and
does not infl uence the other speakers. However, do not place
it in the corner of a room as this may cause uncontrollable
frequency overloads. A location between the front speakers
is often ideal.
Connecting
Danger
Subwoofer
1. Pull the power plugs of all devices to be connected out of the
socket so that inadvertent switch-on is excluded.
Danger of injury/damage!
Arrange the cables so that they do not pose a
trip hazard.
Setup and connection
6
• The terminal 6 for connecting the satellite speakers is lo-
cated on the back side of the subwoofer.
• Here you can connect the speaker cables directly or with
pin plugs. We only describe the direct connection in these
instructions.
1. Lay the included speaker cables from your subwoofer to
each of the speakers.
Little hint: Label the cables on the subwoofer side – this will
help when taking down and setting up your audio equipment.
Analogue
5.1 source
e.g. sound card
Pre Out
Front
CenterRear Front CenterRear
Left
Right
Front SubRear Front SubRear Coaxial 2 Optical 1
5.1 In
Analogue
sources
Stereo In Digital In
Aux CD TV Coaxial 1
Digital
sources
DecoderStation
Subwoofer
US 5305/6
1
2. Connect the LINE IN jacks 1 of the subwoofer with the 5.1
output jacks of a preamplifi er such as a decoder station using
the included RCA cable.
Satellite speakers
Make sure the polarity is correct!
Connect the like coloured terminals. Otherwise the
sound quality will suffer.
The strands of the speaker cables are marked with different
colours or shapes.
2. Split the single wire down to approx. 30 mm on both ends
and strip approx. 10 mm of insulation off of each cord.
3. Twist the stripped single wire ends together so that no wire
protrudes. Tin coating is not necessary.
4. Turn the connector terminal counterclockwise until loose.
Run the stripped cable end into the now visible hole. Close
the terminal by turning it counterclockwise. The cable has
now been clamped in place.
5. Connect the other cable ends to your satellite speakers. The
operating instructions of the speakers should contain notes
on this.
Connection to the grid
7
8
1. Ensure that the mains switch 7 “Power” on the subwoofer is
switched off (“OFF” position).
2. Connect the mains connector jack 8 with a mains socket using the power cord 햳.
3. Also plug the mains plug of your AV receiver back into the
socket.
4. Turn the mains switch 7 “Power” on the subwoofer to “ON”.
5
Page 6
Use
Activating and deactivating
With the switch 7 “Power” you can turn the
power supply on or off. If the subwoofer is
7
activated, the power LED 5 is illuminated in
green. In standby mode it is illuminated in red.
Auto On Level
You can adjust the sensitivity for the activation of the subwoofer with the control “AUTO ON LEVEL” 2. Turning the control
in a clockwise direction increases the sensitivity of the auto-on
function. This means that the subwoofer will already be activated by a very low audio signal.
Subwoofer volume
With the control “SUBWOOFER VOLUME” 3 you can set the
volume of the subwoofer
Cleaning and care
Clean the subwoofer regularly with a soft, damp microfi ber
cloth. If possible, only use plain water without any additives. In
case of stubborn marks, a mild soap solution may be used.
Please be absolutely sure to observe the following notes in the
process:
Danger
• Make sure that no liquid penetrates the unit.
• Disconnect the mains plug before cleaning.
Risk of electric shock!
In contact with live parts, water can lead to electric
shock or short circuit.
Automatic activation/deactivation
12345
With the switch 4 “POWER MODE” you can switch the operating
state:
Auto On: The subwoofer activates as soon as an audio signal
is present on the input jack 1 “LINE IN”. If there is no
audio signal for some period of time, the subwoofer
switches to standby.
On: The subwoofer is continually activated.
Attention
• If possible, only use plain water without any additives.
• In no circumstances should caustic cleaning products,
Risk of damage!
Using the wrong cleaning materials may damage
the delicate surface of the case.
In case of stubborn marks, a mild soap solution may be
used.
white spirit, thinners, petrol or similar be used for cleaning.
6
Page 7
Troubleshooting
The following notes and further detailed information on our website should help you to rectify malfunctions. If this does not lead
to success, please contact our hotline
Problem Possible cause Solution
The subwoofer isn’t working. The subwoofer is off or doesn’t have any
00800 - 200 300 40 (free of charge). Please also observe the warranty notes.
Activate the switch 7 (“On”). Check the power cord and
power.
Fuse is defective. Replace the fuse:
socket.
1. Disconnect the power cord.
2. Carefully pull the fuse holder 9
on the mains connection jack 8
out.
3. Push the old fuse down and out.
Insert a new fuse (2 A time-lag
fuse).
4. Close the holder.
The subwoofer doesn’t emit
basses.
The subwoofer hums. The subwoofer is connected to another
The switch 4 “AUTO ON LEVEL” is set to
Auto On but the input signal is too weak.
circuit than the rest of the system.
The buzzing is caused by problems with the
power supply.
The buzzing is caused by a multiple socket. Use another multi-outlet power strip or connect the
Protecting the environment
Disposal of the unit
Used units must not be disposed of with
household waste.
If the unit is no longer operational, every consumer
is required by law to dispose of used devices
separately from household waste, e.g. at a collec-
tion point run by the communal authority borough. In this way
Increase the input sensitivity by turning the control 2
“AUTO ON LEVEL” to the right. Alternatively you can set
the switch 4 “AUTO ON LEVEL” to “ON”.
Connect the subwoofer and the rest of the system to
the same circuit.
Buy a line fi lter and connect both devices to it.
subwoofer directly to the wall socket. It may also help to
insert the power plug the other way around.
it is ensured, that used devices are properly recycled and that
negative consequences on the environment are avoided. For
this reason, electrical equipment is labelled with the displayed
symbol.
7
Page 8
Lautsprecher Teufel GmbH
Gewerbehof Buelowbogen - Aufgang D1
Buelowstr. 66, 10783 Berlin (Germany)
www.teufelaudio.com
Tel.: 00800 - 200 300 40
(free of charge)
Fax: +49 (0)30 / 300 930 930
... makes you happy
No respon sibility is assumed for the corre ctnes s of this information. Technical changes, typogr aphical errors and other errors reserved. Instruction No. 92094 GB 20120301 / HC -HAM
Loading...
