TETRASCIENCE
Link
Page 2
Parameter
Min
Typ
Max
Unit
DC 5V power input
4.5
5
5.5
V
5V DC Input consumption
1 3
A
Operating temperature
0 70
°C
1) DC jack 2.1 x 5.5 mm
2) LED + push button
3) USB Host x4 Type A
4) microSD
5) RJ45 10/100 Base-T Ethernet
6) USB 2.0 Device micro B
7) WiFi (802.11 b/g/n), Bluetooth LE (4.0) RP-SMA 2.4GHz antenna connector;
only use with supplied antenna
Approvals (pending):
FCC, IC, EN 61326-1, EN 61010-1, EN 60950-1, EN 300 328, EN 301 489-1,
EN 301 489-17
2
Page 3
FCC NOTICE:
The device complies with Part 15 of the FCC Rules. The device meets the requirements for modular transmitter approval as detailed
in FCC public Notice DA00-1407. Transmitter Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) This device must accept an y interference received, including interference that may cause undesired
operation.
CC ID: 2AHL9-LNK001
F
CA
UTION:
The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by
this manufacturer may void the user's authority to operate the equipment. This equipment has been tested and found to comply with
the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limi ts are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment. This equipment
generates,uses, and can radiate radio frequency energy, and if it is not installed and used in accordance with the instruction manual,
it may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the
interference at his own expense.
LA
BELING REQUIREMENTS:
This equipment has been tested and found to comply with t he limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, t here is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user
authority to operate the equipment.
1. T
o comply with FCC RF exposure compliance requirements, a separation di stance of at least 20 cm must be maintained bet ween
the antenna of this device and all persons.
his Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter
2. T
Indus
try Canada (IC) Certification
This device is licensed to meet the regulatory requirements of Industry Canada (IC), License: IC:
Manufacturers of mobile, fixed, or portable devices incorporating this module are advised to clarify any
regulatory questions and ensure compliance for SAR and/or RF exposure limits. Users can obtain
Canadian information on RF exposure and compliance from www.ic.gc.ca.
This device has been designed to operate with the the supplied antenna, having a maximum gain of 1.5
dBi. Antennas not included with this product or having a gain greater than 1.5 dBi are strictly prohibited for
use with this device. The required antenna impedance is 50 ohms. The antenna used for this transmitter
must not be co-located or operating in conjunction with any other antenna or transmitter.
21155-LNK001
IC ID:
21155-LNK001
TICE:
IC NO
3
Page 4
This device complies with Canada RSS-GEN Rules. The device meets the requirements for modular
transmitter approval as detailed in RSS-GEN. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
European R&TTE Declaration of Conformity:
We declare that this device complies with the essential requirements and other relevant provisions of Directive 1999/5/EC. As a
result of the conformity assessment procedure described in Annex III of the Directive 1999/5/EC, the end-customer equipment
should be labeled as follows: All versions of this device
in the specified reference design can be used in the following countries: Austria, Belgium, Cyprus, Czech
Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta,
Poland, Portugal, Slovakia, Slovenia, Spain, Sweden, The Netherlands, the United Kingdom, Switzerland, and Norway.
ESD and EMI Protection
Exposed components require special attention to ESD and electromagnetic interference (EMI).
A grounded conductive layer inside the device enclosure is suggested for EMI and ESD performance. Any openings in the
enclosure near the module should be surrounded by a grounded conductive layer to provide ESD protection and a low-impedance
path to ground.
Device Handling:
These devices have limited built-in ESD protection. Proper ESD protocol must be followed in manufacturing to ensure component
reliability.
Legal Declaration:
Information in this document is believed to be accurate and reliable. However, the publisher does not give any representations or
warranties, expressed or implied, as to the accuracy or completeness of such information and shall have no liability for the
consequences of use of such information.
The publisher takes no responsibility for the content in this document. In no event shall the publisher be li able for any indirect,
incidental, punitive, special or consequential damages (including – without limitation - lost profits, lost savings, business
interruption, costs related to the removal or replacement of any products or rework charges) whether or not such damages are
based on tort (including negligence), warranty, breach of contract or any other legal theory. Notwithstanding any damages that
customer might incur for any reason whatsoever, the publisher’s aggregate and cumulative liability towards customer for the
products described herein shall be limited in accordance with the Terms and conditions of commercial sale of the product.
The publisher reserves the right to make changes to information published in this document, including
without limitation specifications and product descriptions, at any time and without notice.
This document supersedes and replaces all information supplied prior to the publication hereof.
