Short manual testo 410-1

Short manual testo 410-1

 Protection cap: Park position
 Impeller
 Temperature sensor
 Display
 Control keys
 Battery compartment (on rear)

Basic ssettings
Instrument off >press and hold 2s > select with ( ),

confirm with ( ):

Unit of temperature: °C, °F > Unit of velocity: m/s, km/h, fpm, mph, kts, Beau >
Auto off-Funktion: OFF, ON

Switching tthe iinstrument oon
Press .

Switching tthe ddisplay llight oon ((for 110s)
Instrument on > press .

Select ddisplay ssize
Instrument on > select with :

Velocity, chill temperature ( )

Select ddisplay mmode
Instrument on > select with :

Current reading > Hold: Readings are held > Max: Maximum values > Min: Minimum
values > Hold Avg: Timed mean value calculation, see below

Timed mmean vvalue ccalculation ffor fflow
Press several times, until

Hold and Avg appear > Hold down

until

---- appears > Releasing starts mean value calculation,

the current readings are displayed > End measurement: press

,

the mean value is displayed.
Switching tthe iinstrument ooff:
Instrument on > press and hold 2s.

fresitptsvnl????

Safet

Safety and the environment

About this document

i Please read this documentation through carefully and

familiarise yourself with the product before putting it to use.
Keep this document to hand so that you can refer to it when
necessary. Hand this documentation on to any subsequent
users of the product.

i Pay particular attention to information emphasised by the

following symbols:

Important.

Avoid personal injury/damage to equipment

i Only operate the measuring instrument properly, for its

intended purpose and within the parameters specified in the
technical data. Do not use force.

i Never store the product together with solvents, acids or other

aggressive substances.

i Only carry out the maintenance and repair work that is

described in the documentation. Follow the prescribed steps
when doing so. Use only OEM spare parts from Testo.

Protecting the environment

i Take faulty rechargeable batteries as well as spent batteries to

the collection points provided for them.

i Send the product back to Testo at the end of its useful life. We

will ensure that it is disposed of in an environmentally friendly
manner.

y and the enviroment

Test Equipment Depot - 800.517.8431

99 Washington Street Melrose,

TestEquipmentDepot.com

MA 02176

Specifications

Specifications

The testo 410-1 is a flow/temperature measuring instrument. It is
normally used to measure the air speed at ventilation outlets. In
addition to the measurement of temperature, climatic conditions
can also be analysed.

Technical data

Measurement data

· Sensors:
Plastic impeller,

NTC temperature sensor

· Parameters:

m/s, km/h, fpm, mph, kts, Beaufort,
°C, °F, wind chill

· Measuring ranges:

0.4...20 m/s, 80... 4000 fpm,

-10...50 °C, 14...122 °F

· Resolutions:

0.1 m/s, 1 fpm, 0.1 °C, 0.1 °F

· Accuracies

(Nominal temperatue 22 °C, ±1 Digit):
±(0.2 m/s +2 % of reading),
±(40 fpm +2 % of reading),
±0.5 °C, ±0.9 °F

· Measuring rate:

0.5 s

Further instrument data

· Protection class: IP10

· Ambient conditions:

-10...50 °C, 14...122 °F

· Storage/transport conditions:

-40...70 °C, -40...158 °F

· Voltage supply:
2x 1.5 V type AAA

· Battery life:
100 h (without display light)

· Dimensions:
133x46x25 mm (inc. protection cap)

· Weight: 110 g (inc. batteries and
protection cap)

Directives, standards and tests

· EC Directive: 89/336/EEC

Warranty

· Duration: 2 years

· Warranty conditions: see guarantee
card

fresitptsvnl????

Product description

Product description

At a glance

 Protection cap: Park position
 Impeller
 Temperature sensor
 Display
 Control keys
 Battery compartment (on rear)

First steps

²

Inserting bbatteries:
1 To open the battery compartment, push the battery cover

down.

2 Insert batteries (2x 1.5 V type AAA). Observe the polarity!
3 To close the battery compartment, push the battery cover

back on.

²

Basic ssettings ((configuration mmode):

Adjustable functions

· Unit of temperature: °C, °F

· Unit of velocity: m/s, km/h, fpm, mph, kts, Beau

· Auto off function: OFF, ON (instrument switches off automatically if no key is

pressed for 10 minutes)

1 When switching the instrument on, press and hold until

and appear on the display (configuration mode).

- The adjustable function is displayed. The current setting
flashes.

2 Press ( ) several times until the desired setting flashes.

Test Equipment Depot - 800.517.8431

99 Washington Street Melrose, MA 0

TestEquipmentDepot.com

2176

Using the product

3 Press ( ) to confirm the input.
4 Repeat steps 2 and 3 for all functions.

- The instrument changes to measuring mode.

Using the product

To ensure correct readings, align the instrument so that it has
its back to the flow.

²

Switching tthe iinstrument oon:
i Press .

- Measuring mode is opened.

²

Switching tthe ddisplay llight oon:

 The instrument is switched on.
i Press .

- The display light goes out automatically if no key is
pressed for 10 seconds.

²

Changing tthe pparameter:

The parameter in the top display line can be changed. The
bottom display line always shows the temperature.

Adjustable parameters

· Velocity

· Wind chill temperature ( ): perceived temperature (only deviates from
ambient temperature at temperatures <10°C / <50°F and wind speeds
>1.34m/s / >264 fpm)

i Press several times until the desired parameter appears.

²

Changing tthe ddisplay vview:

Adjustable views

· Current reading

· Hold: Readings are held.

· Max: Maximum values since the instrument was last switched on or last reset.

· Min: Minimum values since the instrument was last switched on or last reset.

· Hold Avg: Timed mean value calculation, see below.

i Press several times until the desired view appears.

fresitptsvnl????

Using the product

²

Timed mmean vvalue ccalculation ffor fflow:

1 Press several times, until

Hold and Avg appear in the

display. The last result of mean value calculation is
displayed.

2 Hold down until

---- appears. Releasing starts mean

value calculation automatically, the current readings are
displayed.

3 End measurement: press . The mean value is displayed.
4 For further mean value calculation: hold down .
5 End mean value calculation: press briefly.

²

Resetting MMax/Min values:

1 Press several times until the desired view appears.
2 Press and hold until

---- appears.

3 Repeat steps 1 and 2 for all values that are to be reset.

²

Switching tthe iinstrument ooff:
i Press and hold until the display goes out.

Test Equipment Depot - 800.517.8431

99 Washington Street Melrose, MA 02176

TestEquipmentDepot.com

Maintaining the product

Maintaining the product

±

Changing bbatteries:
1 To open the battery compartment, push the battery cover

down.

2 Remove used batteries and insert new batteries

(2x 1.5 V type AAA). Observe the polarity!

3 To close the battery compartment, push the battery cover

back on.

±

Cleaning tthe hhousing:
i Clean the housing with a moist cloth (soap suds) if it is dirty.

Do not use aggressive cleaning agents or solvents!

Tips and assistance

Questions and answers

Question Possible causes/solutions

Hi or Lo · Readings outside the measuring range (too high, too

low): Keep to the permitted measuring range.

· Residual capacity <10 min: Change batteries.

fresitptsvnl????

Notes
