Highly accurate humidity / temperature probe 0636.9741
Application information en
Only specific humidity sensors with a special basic capacity are used for the
highly accurate humidity / temperature probe.
The probe undergoes comprehensive calibration and testing procedures. It
is tested before delivery in the Testo laboratory and a calibration certificate is
issued.
Note
The calibration buttons are sealed with a calibration sticker.
The precision probe can be tested using the monitoring and adjustment set.
The salt containers are not suitable for calibrating the probes.
We recommend an annual calibration by Testo.
Heavy electromagnetic load (interfering irradiation from external sources) can
lead to incorrect measurements. With the enclosed folding ferrite the probe
complies with the guidelines in accor dance with 2004/108/EEC.
Attach the folding-ferrite to the connection cable:
300mm
Instrument
plug
The cable can also be used for other Testo probes.
www.GlobalTestSupply.com
Technical data
Feature Values
Measuring range 0 to 100%RH, -20 to +70°C
Accuracy ±1%RH at 10 to 90%RH, +15 to +30°C
±2%RH in the rem. range plus Tk
Consistency better 0.3%RH
Long-term stability 1% guaranteed for 2 years
under normal conditions
Typical lifetime 10 years
Warranty 1 year
Ordering data
Name Item no..
Highly accurate humidity/temperature probe without
connection cable (including calibration certificate) 0636.9741
Plug-in head connection cable (1,5m) for testo 445/645 0430.0143
Plug-in head connection cable (5m) for testo 445/645 0430.0145
Telescope (1m) with connection cable (2,5m)
for testo 445/645 0430.0144
Standard calibration certificate for humidity 0520.0006
Special calibration certificate for humidity 0520.0106
DKD calibration certificate for humidity 0520.0206
