USER MANUAL
Fit - Focus - Flexible
The FIT is a macro lens camera that can be placed as close as
1cm (0.4”) away from an object.
Fit
Power Button
(Long press to power the device on and off.
Short press to adjust the LED brightness)
Battery Level Indicator
(Recharge the device when light drops to first level)
MicroUSB Charging Port
(Home use 5V charger
Up to 1.5A charging current)
Reset Button
(Insert a small object and
hold for 8 seconds)
Camera/LEDs
1. Press the lock button
2. Insert the arm
1
2
To attach arm
The FLEXIBLE is an endoscope that is just 5.5 mm in diameter
and has 6 LEDs on the camera tip.
Flexible
Power Button
Battery Level Indicator
MicroUSB Charging Port
Reset Button
1. Press the lock button
2. Insert the arm
1
2
Flexible probe
with camera
(IP67 waterproof)
To attach arm
The FOCUS microscope features an adjustment wheel that can
zoom up to 150x. It has a backlit tray for a brighter field of
vision and uses two clips to hold the subject.
Focus
Tray with Backlight
(Turn wheel to adjust the tray backlight)
Clamp
Lock Nut
Focus Wheel
(Rotate the head
Clockwise to zoom in
and counter clockwise
to zoom out)
Power Button
Lock Nut
1. Press the lock button
2. Insert the arm
3. Insert the handle into
the lock nut and tighten it.
1
2
Brightness Adjustment
Wheel
Tray with Backlight
Clamp
3
4
5
4. Insert the connector into the
handle.
5. Push the pen through the ring
and tighten the lock nut.
