CBA 100M-110 User Manual
CBA 100M-110
10 KHZ to 100 MHZ
100 wAtt AMplifier
user MAnuAl
1 Safety information 5
2 Introduction 7
2.1 CBA 100M-110 Introduction 7
3 Unpacking and installation 9
3.1 Unpacking 9
3.2 Installation 9
4 Operation 10
4.1 Front panel 10
4.2 Rear panel 11
5 Specications 12
6 Warranty 14
7 Adresses 16
Contents
5
This apparatus has been designed and tested in accordance with BS EN 61010-1,
and has been supplied in a safe condition. This manual contains some information warnings which must be followed to ensure safe operation, and to retain
the apparatus in a safe condition.
This apparatus does not incorporate components liable to explode or implode
during normal operating conditions.
In normal operating conditions this apparatus does not liberate injurious or
poisonous gases.
Sound levels of this apparatus after installation in a rack are below 85 dBA,
as required by EN 61010-1. However local regulations may have a lower limit
or the system as a whole may exceed the local limit. In this case appropriate
action should be taken, ie of use of any protective equipment required by local
regulations.
This apparatus is of Installation category 2.
1 sAfety inforMAtion
6
CBA 100M-110 User Manual
This apparatus is capable of delivering harmful levels of
radio frequency power. Ensure at all times during operation that the RF output is properly terminated with an
adequately rated termination or transducer, and that the
cables and connectors attached to the apparatus are in
good condition.
The mains plug shall only be inserted in a socket outlet
provided with a protective earth contact. The protective
action must not be negated by the use of an extension
cord without a protective conductor.
The opening of covers or removal of parts is likely to
expose live parts.
This apparatus must be disconnected from all voltage
sources before it is opened for adjustment, replacement,
maintenance or repair.
Make sure that only fuses of the required rated current
andofthespeciedtypeareusedforreplacement.The
use of makeshift fuses and the short-circuiting of fuse
holders is prohibited.
7
CBA 100M-110 Introduction
The CBA 100M-110 is an amplier capable of supplying 110 W into a 50 ohm load
over the frequency range 10 kHz to 100 MHz, during the course of EMC tests on
electrical equipment. The amplier is designed with sufcient gain such that it
may be used with normal output levels of signal sources. A safety interlock on
the rear panel is also provided, which will mute the amplier when grounded.
The unit is powered from a switched mode power supply for high efciency,
high power factor and wide voltage range operation. The unit is air cooled with
integral fans, and is protected against faulty cooling by excess temperature
sensing.
A front panel indicator is provided to indicate over-temperature. The amplier is
designed for rugged operation into a variety of loads. The amplier is primarily
intended for use as a power source for EMC susceptibility testing, but is also
applicable to other systems requiring a wide-band linear amplier.
This amplier is designated as ‘professional equipment’ and should not be
operated by untrained staff.
As this product has the capability to generate high levels of RF energy it is not
intended for use in a residential environment.
Potential or theoretical hazards.
2 introduCtion
8
CBA 100M-110 User Manual
Threat Precaution
Exposure of personnel to high RF elds
produced by an antenna connected to
the output of the amplier
Ensure that the antenna is inside a
screened enclosure and t an interlock
to the entry door to prevent access
while the amplier is operating
RF burns caused by contact with the
antenna connected to the output of
the amplier
Ensure that the antenna is inside a
screened enclosure and t an interlock
to the entry door to prevent access
while the amplier is operating
Amplier self oscillation caused by
feedback from un-terminated connectors
This is an unlikely but theoretical
possibility. Always ensure that the
amplier input is terminated either
by the system signal generator or by
a suitable RF load/attenuator before
switching the amplier on.
Arcing due to high RF voltages present
at the output connector
Always ensure that the output of the
amplier is terminated either by the
system antenna or a suitable high
power RF load or attenuator.
9
If any signs of damage are found, no attempt should be made to install the
instrument, which should be returned to Teseq or their agent. If the shipping
carton has been damaged, retain the shipping carton and packing material
for the carrier’s inspection. Check that the equipment is complete as in the
packing list above.
3.2 Installation
3 unpACKing And instAllAtion
10 kHz to 100 MHz amplier CBA 100M-110
Power cable (UK)
Power cable (USA / JAPAN)
Power cable (EUROPE)
Spare fuse T 6.3 A time delay 20 mm
CBA 100M-110 Operating manual (this document)
Calibration report
3.1 Unpacking
The CBA 100M-110 package should contain:
This instrument must be earthed.
10
CBA 100M-110 User Manual
4 operAtion
4.1 Front panel
Mains switch
Operating the mains switch will apply power to the amplier gain stages and
fan.
Power indicator
This indicator will illuminate when the mains switch is turned on, and power is
available from the mains.
Fault indicator
Should the amplier be subject to a failing in the cooling system, either by a
fan failure, inadequate air supply or excess ambient temperature, this indicator
will illuminate and the amplier gain stages will all be turned off. This action is
non-latching, so the gain stages will switch on again when the amplier has
cooled down.
RF input (depending on model)
The RF input will accept a signal from an rf generator. This input must be within
the operating frequency range of the amplier. An amplitude of up to 0 dBm will
be sufcient to saturate the amplier. Operation outside the specied frequency
range should not be attempted, and may subject the amplier to undue internal
stress.
RF output (depending on model)
This connector must be suitably terminated at all times during operation. Ensure
that the cable and load are all capable of handling the power available, which
may be as much as 170 W. On no account operate the amplier without a proper
termination or with defective cables or connectors. The centre conductor of
the RF output represents a severe burn hazard to personnel.
11Air inlet
The amplier depends upon a free air supply for cooling. Ensure that the front
air inlet is not restricted.
4.2 Rear panel
Mains input
The mains input is an IEC 60320 type. The cable attached to the mains input
must be rated at 10 A to ensure proper operation at the minimum line voltage
of 85 Vac. The fuse-holder is integral with this mains connector. Use 6.3 A
anti-surge (T).
Input/output connectors (depending on model)
The rf input and output connectors may optionally be placed on the rear
panel.
Fan outlet
The amplier depends upon a free air supply for cooling. Ensure that the fan
outlets are not restricted.
12
CBA 100M-110 User Manual
The following specication applies over the operational temperature and frequency range unless otherwise stated, and does not include the characteristics
of connecting cables.
5 speCifiCAtion
Frequency range (instantaneous) 0.01–100 MHz
Rated output power 100 W minimum
Output power at 1 dB gain compression 90 W minimum
Gain 51 dB
Third order intercept point 61 dBm
Gain variation with frequency ±2 dB
Harmonics at 90 W output power Better than -20 dBc
Output impedance 50 Ohms
Stability Unconditional
Output VSWR tolerance Innity:1
Input VSWR 2:1
RF connector style Type N female
Safety interlock BNC female, s/c to mute
USB interface Optional
EMC and safety
Conducted and radiated emissions EN 61326 class A
Conducted and radiated immunity EN 61326: 1997 table 1
Mains harmonic currents EN 61000-3-2
Voltage uctuations and icker EN 61000-3-3
Safety EN 61010-1
13Power
Supply voltage (1-phase) 85-264 Vac
Supply frequency range 45-63 Hz
Supply power <500 VA
Mains connector IEC 320
Environmental
Operating temperature range 0-40°C
Mechanical
Case dimensions 19 inch, 4U case, 440 mm deep
Weight 20 kg
Options (select at time of ordering)
341-715 Bench model with front panel mounted input/output connectors
341-815 Rack mountable with front panel mounted input/output connectors
341-925 Rack mountable with rear panel mounted input/output connectors
Notes
1 The third order intercept point is a nominal value, as its calculation depends
upon the power level at which distortion measurements are made.
2 Output VSWR tolerance is specied for excitation within the permitted levels
and frequency range.
14
CBA 100M-110 User Manual
6 wArrAnty
Teseq limited (the company) warrants its ampliers to be free from defects in
workmanship and materials, under normal use and service, for three years from
the date of purchase from the company or its authorized agent.
If a product does not operate as warranted during the warranty period, the
company shall, at its option, repair the defective product or part, deliver an
equivalent product or part to replace the defective item, or refund the purchase
price paid for the defective product. Transportation of the defective product or
part to the factory or service centre is to be pre-paid by the customer. All products that are replaced will become the property of the company. Any replaced
or repaired product or part has a ninety (90) day warranty or the remainder of
the initial warranty period, whichever is longer.
All information in this manual is given in good faith. However, the company shall
not be liable for any loss or damage whatsoever arising from the use of this
manual, the product described in it or any errors or omissions in either.
Hardware
15
notes
16
