1
TE210
Household Use Only
Mist outlet
Mist button
Mist is emitted while holding down the Mist
button during operation. While mist is being
emitted, the spatula vibration stops.
Nickel-Metal Hydride
Battery (built-in)
Head inserting block
Body
Body socket
Power switch
Pressing and holding down this switch for 1 sec turns on
the power.
Power switch: Red lamp lights up.
Changeover switch: Green lamp lights up.
Head indicator lamp: Green lamp lights up.
* Lights up according to the inserting head status.
Pressing the switch again turns off the power.
Changeover switch
Changes the peeling strength (HI/LOW).
HI: Blue LOW: Green
Head indicator lamp
Indicates the currently inserted head during
operation.
Battery lamp
[In regular use]
Extinguishes
[Charging in progress]
On: Now charging is in progress.
Off: Charging is complete.
[Low battery]
Flashes for 10 sec and then is
extinguished.
(With warning beep)
Ultrasonic Peeling
Names and Functions of the Components
Names and Functions of the Components
Water tank cap
Water tank cover
Water tank
Ion-exchanger resin
Changes even hard tap
water into soft water.
BODY head
Body cap
Attached to keep the body.
Subcap
Attached to keep the FACE or
BODY head separate.
Spatula
FACE head
List of Voltages and
Plugs by Country
Power cord
Power plug
Plug-to-
appliance
■ Accessories
Power adapter
3
①
②
①
②
Charging the Battery
1
Make sure that the Power switch is off. Then, connect the
power adapter to the body and receptacle.
●
The battery lamp lights up.
●
Do not push the power adapter’s plug-to-appliance into the body’s
socket with excessive force, or tilt it in a forced manner. If you do
so, the socket may break.
●
Make sure that the power supply voltage is 100 to 240 V.
●
The voltage and the plug shape may differ from those of Japan,
depending on the country or region. Use the List of Voltages and
Plugs by Country (accessories).
2
After the battery lamp is extinguished, unplug the power
adapter from the receptacle and body.
●
The standard time for charging is approx. 5 hours.
●
The body and power adapter may become slightly hot; this does not
indicate a failure.
●
A battery fully charged once enables the appliance to operate
approx. six times (approx. 10 min for each session). (The number
of times may decrease, depending on the conditions for use of the
appliance, for example, how you clean the appliance.)
Specifications
Part name Ultrasonic Peeling Rated time 10 min (automatic turn-off)
Part number TE210 Charging time Approx. 5 h
Power adapter AC100-240 V 50/60 Hz
Weight
140 g (body)
175 g (with body of BODY head)
Body
Nickel-Metal Hydride Battery
(DC3.6V, 800mAh) 1set
Accessories
BODY head, FACE head, Power adapter,
Body cap, Subcap, List of Voltages and
Plugs by Country
Dimensions
Height 184 × Width 49 × Depth 46 mm
(with BODY head)
Power supply
Precautions for Use
WARNING
Avoid using this appliance together with the medical electrical equipment below.
Failure to follow these instructions may cause the appliance to malfunction.
●
Implanted medical electrical equipment (e.g. cardiac pacemaker)
●
Wearable medical electrical equipment (e.g. electrocardiograph)
CAUTION
If you apply to one of the following categories, be
sure to consult with a doctor.
Failure to follow these instructions may result in accident or injury.
● A person with cardiac damage
● A person with an acute (painful) illness
● A person with a febrile disease
● A person with abnormal blood pressure
● A person with a communicable disease
● A person with a tuberculous disease
● A person with a malignancy
● A person with facial pain
● A person who is pregnant
● During menstruation
● A person with atopic dermatitis
● A person with allergies
● A person with particularly sensitive skin
● A hemophiliac
● Undergoing dental treatment
● A person with a telangiectatic disease that is due to long-
term use of a steroid hormonal agent or due to liver
function disorder
● A person who has consumed alcohol, taken a drug or is
very tired
This appliance must not be used on any of the
following regions.
Failure to follow these instructions may result in accident or
injury.
● A region that has beeen subjected to cosmetic surgery
● Eye balls and upper eyelids
● W o u n d s
● Melanoderma of face
● Mucosal regions (e.g. inside of mouth)
● Inflamed regions due to comedo or pimples
● Regions that have impairment of pain sensation or
disturbance of perception
● Skin regions under which there is a metallic, plastic,
silicone, or other implant
● Regions that have inflamed pigmented spots due to itch,
flush, physical stimulus, or other
● Inflamed regions due to cosmetics or similar products
If you experience any problems with your skin or body, stop use of the appliance immediately and consult
with a medical specialist.
Failure to follow these instructions may result in accident or adverse effects.
* Skin care with this appliance should be undertaken for no more than twice a day, and the time of use
should be within 7 min for one session.
Do not use the appliance continuously for longer than 7 min to protect your skin from damage.
●
Cleanse your face to wash off any makeup.
●
Wash the makeup off your face using a cleansing agent.
Use this appliance on the skin of your face from which makeup has been removed.
Use the appliance on skin that has been moistened with water or mist.
5
1
Remove the body cap.
2
Install either the BODY or FACE head of the accessories on the body.
Insert the head fully to the rear.
* When you receive the product, the body has the BODY head already installed
on it.
●
Do not remove the head with the power on.
●
If the head is not installed fully or is uninstalled, the power cannot
be turned on.
●
While using the appliance, the power is turned off owing to action
of the safety device if water enters the head inserting block during
replacement of the head or when installation of the head is not fully
completed. This does not indicate a failure.
●
To remove the head, place the appliance sideways as shown in the
figure and pull out the head slowly while holding both sides with
your fingers.
Pulling out the head with wet hands or with the head faced toward
your face may result in injury due to the spatula tip.
●
When removing the head, do not hold the spatula.
Failure to follow these instructions may result in failure of the the
appliance.
3
Remove the water tank cover from the back and take out the water tank.
Install Remove
Water tank cover
Water tank
How to Use
Skin care with this appliance should be undertaken for no more than once a day, and the time of use should
be within 10 min for one session. The number of times of use should be once or twice a week.
When 10 min have passed after pressing the Power switch, the power is turned off automatically.
Do not use this appliance for care around the eyes or ears.
(Failure to follow these instructions may result in accident or adverse
effects.)
If your skin has an injury or wound, the appliance should not be used
under any circumstances.
(Failure to follow these instructions may result in skin problems or injury.)
WARNING
HI/LOW
ON/OFF
FAC E
BODY
HI/LOW
ON/OFF
FAC E
BODY
②
①
4
Remove the water tank cap. Then, fill the tank with purified or tap water up to
the upper limit of the water level. Tighten the water tank cap firmly. Then, wipe
droplets off the tank before loading it into the body.
●
If your skin is wet or you do not use the mist function, you can use the appliance without putting water into the
water tank.
Note that without water in the tank, pressing the Mist button during peeling does not enable misting.
●
No water other than purified or tap water must be used.
Turn the water
tank cap
counterclockwise
to remove it.
Put water into the
water tank.
Turn the water
tank cap
clockwise to
reinstall it.
Load the water tank into
the body in the order of
① and then ②.
Reinstall the water
tank cap on the
body.
Up to here
With the marks aligned,
insert the water tank
cap into the water tank.
Press this down
5
Press and hold down the Power switch to turn on
the power.
●
The appliance emits a short beep [pit] and recognizes the installed
head, causing the head indicator lamp to light up.
●
The power is turned off automatically about 10 min after pressing
the Power switch.
●
If you have installed the head on the body with the head inserting
block filled with water, pressing and holding down the Power switch
may be unable to turn on the power owing to action of the safety
device.
6
Select the peeling strength by pressing the
Changeover switch.
The HI/LOW mode is toggled each time the switch
is pressed.
Preset to "LOW" as the mode that immediately
follows the startup.
HI: Blue LOW: Green
●
At the beginning of use, "LOW" should be set to use the appliance
for a short time.
●
Stop using the appliance if you experience any discomfort.
Slide
Press the
Power switch.
Press the
Changeover
switch.
How to Use
7
●
This appliance should be used on bare skin without makeup.
●
If you experience any disorder in the portion of care during or after using the appliance (e.g. rubification, rash,
itch), stop use immediately and consult with a medical specialist.
●
Do not use the appliance many times on the same region.
●
Be sure to moisten your skin before peeling.
●
When using the appliance, do not press the spatula against your skin using excessive force.
●
Whenever you find dirt or grime on the metallic section of the spatula, wipe it off using a towel or tissue.
●
If the water tank contains no water, no mist will be sprayed.
●
If large droplets are placed on the spatula tip, those attached to the skin will hardly be shed while being
transformed into mist. In this case, wipe away the droplets once before use.
●
While holding down the Mist button, the spatula vibration stops. This does not indicate a failure.
●
As a guide for sliding, move the spatula at about a speed of 10 cm for 3 sec without stopping it in the same
position.
8
After use, turn off the Power switch. Discard the tank water, and clean the head
and body.
After the inside of the water tank has dried fully, reinstall the body cap and
subcap and store the appliance in a low-humidity location.
Direction of movement
Press the Mist
button.
Release the Mist
button.
Mist
Spray mist onto the skin to moisten it. Place the spatula on the wet skin and move it around.
7
Spray mist onto the desired portion of peeling to moisten the skin. Then, gently
place the spatula on the skin and slide it around slowly.
Adjust the tilt of the spatula so that mist on the skin can be shed.
How to Use
[Using the FACE Head]
①
Install the FACE head on the body. Make sure that when you turn on the Power switch, the head
indicator lamp FACE is on.
②
By pressing the Mist button, spray mist will moisten your
skin.
●
Take care to prevent the spatula tip from touching the skin.
③
With the spatula gently placed on the skin, slowly slide it
from bottom to top.
●
While using the appliance, you will hear a continuous metallic sound
[keeeeen]; this does not indicate a failure.
● Face lines
● Cheeks
●
Jaw and around mouth
● Around nostril
④
After use, resume your regular daily skin care regime.
●
Condition your skin with beauty lotion, and supplement oil with emulsion or equivalent.
⑤
After use, wipe dirt and grime off the head using a soft cloth or tissue, for example.
How to Use
9
● Decollete
●
Use the FACE head.
①
By pressing the Mist button, spray mist will moisten
your skin.
●
Take care to prevent the spatula tip from touching the skin.
Advanced Use
②
With the spatula gently placed on the skin, slowly slide it upward.
③
After use, supplement oil with cream or other material for moisture retention.
[Using the BODY Head]
①
Install the BODY head on the body.
When you turn on the Power switch, make sure that the head indicator lamp BODY is on.
②
By pressing the Mist button, spray mist will moisten your skin.
●
Take care to prevent the spatula tip from touching the skin.
③
With the spatula gently placed on the skin, slowly slide it outward.
●
While using the appliance, you will hear a continuous metallic sound [keeeeen]; this is not a failure.
④
After use, supplement oil with cream or other material for moisture retention.
● Knees ● Heels ● Elbows
⑤
After use, wipe dirt and grime off the head using a soft cloth or tissue, for example.
How to Use
[Timing of charge]
●
The low battery status is indicated by the battery lamp that flashes (when the power is on) while
consecutive short beeps [pit pit pit …] are generated for 10 sec, and the power is turned off
automatically.
-> Immediately charge the battery.
●
This product can be used with AC 100 to 240V power supply.
[Safety device]
●
If water enters the head inserting block, the power can no longer be turned on or off owing to
action of the safety device.
-> To take action for this case, with the head removed from the body, drain off the water from the
head and head inserting block, clean them, reinstall the head in the initial position, and press
the Power switch to restore to normal operation.
[Cleaning]
●
Make sure that the power is off and the power adapter has been removed. Then start the cleaning.
●
Body, head, and spatula block
Wipe away dirt and grime using a soft dry cloth.
●
If it is difficult to remove dirt or grime from the body, soak a soft cloth in a soap-and-water
solution or a water-diluted neutral detergent, and wring well. Then, use this cloth to wipe dirt and
grime off the body.
● Body
● Spatula block
● Head
To wipe the head
inserting block, use a
soft dry cloth.
* A wet cloth must
not be used to wipe
the inserting block.
Water tank and water tank cap
Discard the tank water. Then, after drying naturally, reinstall the tank on the body.
How to Use
Loading...
