TerraTec MIDI HUBBLE User Manual
TERRATEC PRODUCER MIDI HUBBLE
English Manual
Version 1.0, from: August 2004
CE Declaration
We:
TerraTec Electronic GmbH, Herrenpfad 38, D-41334 Nettetal, Germany
hereby declare that the product:
TerraTec Producer MIDI HUBBLE,
to which this declaration refers is in compliance with the following standards or standard-
izing documents:
1. EN 55013
2. EN 55020
The following are the stipulated operating and environmental conditions for said compli-
ance:
residential, business and commercial environments and small-company environments.
This declaration is based on:
Test report(s) of the EMC testing laboratory
The information in this document is subject to change without notice and shall not be deemed as a
warranty by the seller. No warranties, express or implied, are made with regard to the quality,
suitability or accuracy of this document. The manufacturer reserves the right to change the contents
of this document and/or the associated products at any time without the provision of prior notice to
specific persons or organizations. The manufacturer shall not be held liable for damages of any
kind arising from the use, or the inability to use this product or its documentation, even if the
possibility of such damage is known. The information in this document is subject to copyright. All
rights are reserved. No part of this manual may be reproduced or transmitted in any form or for any
purpose without the express written permission of the copyright holders. Product and brand names
contained in this document are used for identification purposes only. All registered trademarks,
product designations or brand names used in this document are the registered property of their
respective owners.
®
©TerraTec
Electronic GmbH, 1994 - 2004. All rights reserved (08/17/04).
2 MIDI Hubble (English)
Contents
Welcome! ....................................................................................................................... 4
Scope of delivery. ........................................................................................................4
Notes on USB interface, hub and power supply........................................................... 5
Bus-powered operation without separate AC adapter.................................................. 5
Self-powered operation with separate AC adapter....................................................... 6
Installing the drivers under Windows 2000 and XP. ...................................................6
Installing the Control Panel in MAC OS X (OS 10.3.3 or higher)................................ 6
Notes for Windows users............................................................................................. 7
Notes for Macintosh users. .......................................................................................... 7
The ports of the MIDI HUBBLE module ....................................................................... 7
The front panel ............................................................................................................ 7
The rear panel ............................................................................................................. 8
The control panel. .........................................................................................................8
LED Filter................................................................................................................. 9
Firmware (update).................................................................................................... 9
MIDI Thru............................................................................................................... 10
Appendix A—Technical Data...................................................................................... 11
MIDI HUBBLE (English) 3
Welcome!
We're pleased that you've chosen a product from the TerraTec Producer line for your
musical endeavors and would like to congratulate you on your decision. With the MIDI
HUBBLE System, you've purchased a sophisticated piece of state-of-the-art studio
equipment. Thanks to its wealth of options and proven technology, it will serve you well—
both in demanding studio environments and day-to-day home recording for years to
come.
Enjoy your MIDI HUBBLE.
Sincerely,
Your TerraTec Producer Team
Scope of delivery.
Start by making sure that nothing is missing.
The MIDI HUBBLE System package should contain the following items:
n
MIDI HUBBLE module
n
1.8 m USB connecting cable (plug type A to B)
n
Product CD-ROM (driver and software)
n
This manual
n
Service request form
n
Registration documents
n
BeSonic Premium Account
Please return the enclosed registration card to us at the earliest possible opportunity, or
register online at:
http://www.terratec.net/register.htm
.
4 MIDI Hubble (English)
