TerraMaster F2-421 operation manual
Data Storage Master
TerraMaster NAS
Model: F2-421
Fundamentals and Preliminaries
Copyright © 2019 TerraMaster All Rights Reserved.
Contents
1. Overview
2. Hardware Installation
3. Software Installation
4. Initialisation
5. Getting Started
2
2
5
7
11
Model:F2-421
1
1. Overview
A TNAS product includes hardware, operating systems (OS), and other auxiliary applications. Therefore, you
should carefully read the instructions prior to operation. For any questions, please visit the “Help”
section at TerraMaster's official website, or contact our technical support team at sales@terra-master.com.
Once you receive your new TerraMaster TNAS product, please install and set up your TNAS according to the
“Quick Installation Guide”.
Please note that given our commitment to the continuous improvement of our products, their
appearances, designs, and specifications may be subject to change without prior notification.
Finally, the images and illustrations in this instruction manual may be slightly different from the actual
product, and so please always refer to the actual product.
2. Hardware Installation
2.1 Package List
Once you receive your new TNAS, please check to ensure that the package includes the items detailed
below. If any items are missing, please contact the reseller immediately.
TNAS unit X 1 Power core X 1 Power adaptor X 1 Several screws
Installation guide X 1 Network core X 1
Product brochure
(optional)
Model:F2-421
2
2.2 Appearance
Panel Illustration: Rear Cover Illustration:
⑧
②
③
④
SN
①
②
③
①
Item
Hard drive tray
Hard drive indicator
Network indicator
⑦
⑥
⑤
SN
⑤
⑥
⑦
USB 3.0 host interface (×2)
Item
Power interface
Network interface
④
SN
⑤
⑥
⑦
⑧
Power switch/Power indicator
Item
Power interface
Network interface
USB 3.0 host (×2)
HDMI interface
DC 12V power input
NOTE: Do not use a third-party power adaptor.
1000M/100M bps network interface
Use to connect USB storage device or USB wireless adaptor
For displaying the software codes or commands,
not for video playing.
⑧
Description
HDMI interface
Model:F2-421
3
