Terasic DE0-CV User Manual
DE0-CV User Manual
1
www.terasic.com
May 4, 2015
DE0-CV User Manual
1
www.terasic.com
May 4, 2015
CONTENTS
Chapter 1 Introduction ..................................................................................................... 3
1. 1 Package Contents ............................................................................................................................ 3
1. 2 DE0-CV System CD ....................................................................................................................... 4
1. 3 Layout and Components ................................................................................................................. 4
1. 4 Block Diagram of the Cyclone V Starter Board .............................................................................. 6
1. 5 Getting Help .................................................................................................................................... 7
Chapter 2 Control Panel ................................................................................................... 8
2. 1 Control Panel Setup......................................................................................................................... 8
2. 2 Controlling the LEDs, 7-segment Displays................................................................................... 10
2. 3 Switches and Push-buttons ............................................................................................................ 12
2. 4 SDRAM Controller and Programmer ........................................................................................... 12
2. 5 SD Card ......................................................................................................................................... 14
2. 6 VGA .............................................................................................................................................. 15
2. 7 Overall Structure of the DE0-CV Control Panel ........................................................................... 16
Chapter 3 Using the Starter Kit ..................................................................................... 18
3. 1 Configuration of Cyclone V FPGA on DE0-CV ........................................................................... 18
3. 2 Using the LEDs and Switches ....................................................................................................... 21
3. 3 Using the 7-segment Displays ....................................................................................................... 25
3. 4 Clock Circuitry .............................................................................................................................. 27
3. 5 Using 2x20 GPIO Expansion Headers .......................................................................................... 27
3. 6 Using VGA.................................................................................................................................... 30
3. 7 PS/2 Serial Port ............................................................................................................................. 32
3. 8 Micro SD-Card Socket .................................................................................................................. 33
3. 9 Using SDRAM .............................................................................................................................. 34
Chapter 4 DE0-CV System Builder ............................................................................... 37
4. 1 Introduction ................................................................................................................................... 37
4. 2 General Design Flow..................................................................................................................... 37
4. 3 Using DE0-CV System Builder .................................................................................................... 38
DE0-CV User Manual
2
www.terasic.com
May 4, 2015
Chapter 5 Examples of Advanced Demonstrations ................................................... 43
5. 1 DE0-CV Factory Configuration .................................................................................................... 43
5. 2 SDRAM Test in Nios II ................................................................................................................. 45
5. 3 SDRAM Test in Verilog ................................................................................................................ 48
5. 4 PS/2 Mouse Demonstration........................................................................................................... 49
5. 5 Micro SD Card file system read .................................................................................................... 53
5. 6 VGA Pattern .................................................................................................................................. 57
DE0-CV User Manual
3
www.terasic.com
May 4, 2015
Chapter 1
Introduction
The DE0-CV presents a robust hardware design platform built around the Altera Cyclone V FPGA,
which is optimized for the lowest cost and power requirement for transceiver applications with
industry-leading programmable logic for ultimate design flexibility. With Cyclone V FPGAs, you
can get the power, cost, and performance levels you need for high-volume applications including
protocol bridging, motor control drives and capture cards, and handheld devices. The DE0-CV
development board includes hardware such as on-board USB Blaster, video capabilities and much
more. By leveraging all of these capabilities, the DE0-CV is the perfect solution for showcasing,
evaluating, and prototyping the true potential of the Altera Cyclone V FPGA.
The DE0-CV contains all components needed to use the board in conjunction with a computer that
runs the Microsoft Windows XP or later.
11.. 1
1
PPaacckkaaggee CCoonntteennttss
Figure 1-1 shows a photograph of the DE0-CV package.
Figure 1-1 The DE0-CV package contents
The DE0-CV package includes:
The DE0-CV board
5V DC Power Supply
Type A Male to Type B Male USB Cable
DE0-CV User Manual
4
www.terasic.com
May 4, 2015
11.. 2
2
DDEE00--CCVV SSyysstteemm CCDD
The DE0-CV System CD contains the documentation and supporting materials, including the User
Manual, Control Panel, System Builder, reference designs and device datasheets. User can
download this System CD from the web (http://cd-de0-cv.terasic.com).
11.. 3
3
LLaayyoouutt aanndd CCoommppoonneennttss
This section presents the features and design characteristics of the board.
A photograph of the board is shown in Figure 1-2 and Figure 1-3. It depicts the layout of the board
and indicates the location of the connectors and key components.
Figure 1-2 Development Board (top view)
DE0-CV User Manual
5
www.terasic.com
May 4, 2015
Figure 1-3 Development Board (bottom view)
This board has many features that allow users to implement a wide range of designed circuits, from
simple circuits to various multimedia projects.
The following hardware is provided on the board:
FFPPGGAA DDeevviiccee
Cyclone V 5CEBA4F23C7N Device
49K Programmable Logic Elements
3080 Kbits embedded memory
4 Fractional PLLs
CCoonnffiigguurraattiioonn aanndd DDeebbuug
g
Serial Configuration device – EPCS64 on FPGA
On-Board USB Blaster (Normal type B USB connector)
JTAG and AS mode configuration supported
MMeemmoorryy DDeevviiccee
DE0-CV User Manual
6
www.terasic.com
May 4, 2015
64MB SDRAM, x16 bits data bus
CCoommmmuunniiccaattiioonn
PS/2 mouse/keyboard
CCoonnnneeccttoorrss
2x20 GPIO Header
DDiissppllaayy
Uses a 4-bit resistor-network DAC
With 15-pin high-density D-sub connector
MMiiccrroo SSDD CCaarrdd SSoocckkeett
Provides SPI and 4-bit SD mode for Micro SD Card access
SSwwiittcchheess,, BBuuttttoonnss aanndd LLEEDDss
10 LEDs
10 Slide Switches
4 Debounced Push Buttons
1 CPU reset Push Buttons
Six 7-Segments
PPoowweerr
5V DC input
11.. 4
4
BBlloocckk DDiiaaggrraamm ooff tthhee CCyycclloonnee VV SSttaarrtteerr BBooaarrdd
Figure 1-4 gives the block diagram of the board. To provide maximum flexibility for the user, all
connections are made through the Cyclone V FPGA device. Thus, the user can configure the FPGA
to implement any system design.
DE0-CV User Manual
7
www.terasic.com
May 4, 2015
Figure 1-4 Board Block Diagram
11.. 5
5
GGeettttiinngg HHeellpp
Here are the addresses where you can get help if you encounter any problem:
Terasic Inc.
9F., No.176, Sec.2, Gongdao 5th Rd, East Dist, Hsinchu City, 30070. Taiwan
Email: support@terasic.com
Tel.: +886-3-5750-880
Web: http://www.DE0-CV.terasic.com
DE0-CV User Manual
8
www.terasic.com
May 4, 2015
Chapter 2
Control Panel
The DE0-CV board comes with a Control Panel program that allows users to access various
components on the board from a host computer. The host computer communicates with the board
through a USB connection. The program can be used to verify the functionality of components on
the board or be used as a debug tool while developing any RTL code.
This chapter first presents some basic functions of the Control Panel, then describes its structure in
the block diagram form, and finally describes its capabilities.
22.. 1
1
CCoonnttrrooll PPaanneell SSeettuupp
The Control Panel Software Utility is located in the directory “Tools/ControlPanel” in the DE0-CV
System CD. It's free of installation, just copy the whole folder to your host computer and launch the
control panel by executing the “DE0CV_ControlPanel.exe”.
Specific control circuits should be downloaded to your FPGA board before the control panel can
request it to perform required tasks. The program will call Quartus II tools to download the control
circuit to the FPGA board through the USB-Blaster[USB-0] connection.
To activate the Control Panel, perform the following steps:
1. Make sure Quartus II 14.0 or a later version is installed successfully on your PC.
2. Set the RUN/PROG switch to the RUN position.
3. Connect the USB cable provided to the USB Blaster port, connect the 5V power supply, and
turn the power switch ON.
4. Start the executable DE0CV_ControlPanel.exe on the host computer. The Control Panel user
interface shown in Figure 2-1 will appear.
5. The DE0CV_ControlPanel.sof bit stream is loaded automatically as soon as the
DE0CV_ControlPanel.exe is launched.
6. In case of a disconnect, click on CONNECT where the .sof will be re-loaded onto the board.
DE0-CV User Manual
9
www.terasic.com
May 4, 2015
Please note that the Control Panel will occupy the USB port until you close that port; you cannot use Quartus II
to download a configuration file into the FPGA until the USB port is closed.
7. The Control Panel is now ready to use; experience it by setting the ON/OFF status for some
LEDs and observing the result on the DE0-CV board.
Figure 2-1 The DE0-CV Control Panel
The concept of the DE0-CV Control Panel is illustrated in Figure 2-2. The “Control Circuit” that
performs the control functions is implemented in the FPGA board. It communicates with the
Control Panel window, which is active on the host computer, via the USB Blaster link. The
graphical interface is used to send commands to the control circuit. It handles all the requests and
performs data transfers between the computer and the DE0-CV board.
DE0-CV User Manual
10
www.terasic.com
May 4, 2015
Figure 2-2 The DE0-CV Control Panel concept
The DE0-CV Control Panel can be used to light up LEDs, change the values displayed on the
7-segment, monitor buttons/switches status, read/write the SDRAM Memory, output VGA color
pattern to VGA monitor, read SD Card specification information. The feature of reading/writing a
word or an entire file from/to the Memory allows the user to develop multimedia applications
without worrying about how to build a Memory Programmer.
22.. 2
2
CCoonnttrroolllliinngg tthhee LLEEDDss,, 77--sseeggmmeenntt DDiissppllaayyss
A simple function of the Control Panel is to allow setting the values displayed on LEDs, 7-segment
displays.
Choosing the LED tab leads to the window in Figure 2-3. Here, you can directly turn the LEDs on
or off individually or by clicking “Light All” or “Unlight All”.
DE0-CV User Manual
11
www.terasic.com
May 4, 2015
Figure 2-3 Controlling LEDs
Choosing the 7-SEG tab leads to the window shown in Figure 2-4. From the window, directly use
the left-right arrows to control the 7-SEG patterns on the DE0-CV board which are updated
immediately. Note that the dots of the 7-SEGs are not enabled on the DE0-CV board.
Figure 2-4 Controlling 7-SEG display
DE0-CV User Manual
12
www.terasic.com
May 4, 2015
The ability to set arbitrary values into simple display devices is not needed in typical design
activities. However, it gives users a simple mechanism for verifying that these devices are
functioning correctly in case a malfunction is suspected. Thus, it can be used for troubleshooting
purposes.
22.. 3
3
SSwwiittcchheess aanndd PPuusshh--bbuuttttoonnss
Choosing the Switches tab leads to the window in Figure 2-5. The function is designed to monitor
the status of slide switches and push buttons in real time and show the status in a graphical user
interface. It can be used to verify the functionality of the slide switches and push-buttons.
Figure 2-5 Monitoring switches and buttons
The ability to check the status of push-button and slide switch is not needed in typical design
activities. However, it provides users a simple mechanism to verify if the buttons and switches are
functioning correctly. Thus, it can be used for troubleshooting purposes.
22.. 4
4
SSDDRRAAMM CCoonnttrroolllleerr aanndd PPrrooggrraammmmeerr
The Control Panel can be used to write/read data to/from the SDRAM chips on the DE0-CV board.
As shown below, we will describe how the SDRAM may be accessed; Click on the Memory tab and
select “SDRAM” to reach the window in Figure 2-6.
DE0-CV User Manual
13
www.terasic.com
May 4, 2015
Figure 2-6 Accessing the SDRAM
A 16-bit word can be written into the SDRAM by entering the address of the desired location,
specifying the data to be written, and pressing the Write button. Contents of the location can be read
by pressing the Read button. Figure 2-6 depicts the result of writing the hexadecimal value 06CA
into offset address 200, followed by reading the same location.
The Sequential Write function of the Control Panel is used to write the contents of a file into the
SDRAM as follows:
1. Specify the starting address in the Address box.
2. Specify the number of bytes to be written in the Length box. If the entire file is to be loaded,
then a checkmark may be placed in the File Length box instead of giving the number of bytes.
3. To initiate the writing process, click on the Write a File to Memory button.
4. When the Control Panel responds with the standard Windows dialog box asking for the
source file, specify the desired file location in the usual manner.
The Control Panel also supports loading files with a .hex extension. Files with a .hex extension are
ASCII text files that specify memory values using ASCII characters to represent hexadecimal
values. For example, a file containing the line
0123456789ABCDEF
DE0-CV User Manual
14
www.terasic.com
May 4, 2015
defines eight 8-bit values: 01, 23, 45, 67, 89, AB, CD, EF. These values will be loaded
consecutively into the memory.
The Sequential Read function is used to read the contents of the SDRAM and fill them into a file as
follows:
1. Specify the starting address in the Address box.
2. Specify the number of bytes to be copied into the file in the Length box. If the entire
contents of the SDRAM are to be copied (which involves all 64 Mbytes), then place a checkmark
in the Entire Memory box.
3. Press Load Memory Content to a File button.
4. When the Control Panel responds with the standard Windows dialog box asking for the
destination file, specify the desired file in the usual manner.
22.. 5
5
SSDD CCaarrdd
The function is designed to read the identification and specification information of the SD Card.
The 4-bit SD MODE is used to access the SD Card. This function can be used to verify the
functionality of the SD Card Interface. Follow the steps below to perform the SD Card exercise:
1. Choosing the SD Card tab leads to the window in Figure 2-7.
2. Insert an SD Card to the DE0-CV board, and then press the Read button to read the SD Card. The
SD Card‟s identification, specification, and file format information will be displayed in the control
window.
DE0-CV User Manual
15
www.terasic.com
May 4, 2015
Figure 2-7 Reading the SD Card Identification and Specification
22.. 6
6
VVGGAA
DE0-CV Control Panel provides VGA pattern function that allows users to output color pattern to
LCD/CRT monitor using the DE0-CV board. Follow the steps below to generate the VGA pattern
function:
Choosing the VGA tab leads to the window in Figure 2-8.
Plug a D-sub cable to the VGA connector of the DE0-CV board and LCD /CRT monitor.
The LCD/CRT monitor will display the same color pattern on the control panel window.
Click the drop down menu shown in Figure 2-8 where you can output the selected pattern
individually.
DE0-CV User Manual
16
www.terasic.com
May 4, 2015
Figure 2-8 Controlling VGA display under Control Panel
22.. 7
7
OOvveerraallll SSttrruuccttuurree ooff tthhee DDEE00--CCVV CCoonnttrrooll PPaanneell
The DE0-CV Control Panel is based on a Nios II Qsys system instantiated in the Cyclone V FPGA
with software running on the on-chip memory. The software part is implemented in C code; the
hardware part is implemented in Verilog HDL code with Qsys builder. The source code is not
available on the DE0-CV System CD.
To run the Control Panel, users should follow the configuration setting according to Section 3.1.
Figure 2-9 depicts the structure of the Control Panel. Each input/output device is controlled by the
Nios II Processor instantiated in the FPGA chip. The communication with the PC is done via the
USB Blaster link. The Nios II interprets the commands sent from the PC and performs the
corresponding actions.
DE0-CV User Manual
17
www.terasic.com
May 4, 2015
Figure 2-9 The block diagram of the DE0-CV control panel
DE0-CV User Manual
18
www.terasic.com
May 4, 2015
Chapter 3
Using the Starter Kit
This chapter provides an instruction to use the board and describes the peripherals.
33.. 1
1
CCoonnffiigguurraattiioonn ooff CCyycclloonnee VV FFPPGGAA oonn DDEE00--CCVV
The DE0-CV board contains a serial configuration device that stores configuration data for the
Cyclone V FPGA. This configuration data is automatically loaded from the configuration device
into the FPGA when powered on. Using the Quartus II software, it is possible to reconfigure the
FPGA at any time, and it is also possible to change the non-volatile data that is stored in the serial
configuration device. Both types of programming methods are described below.
1. JTAG programming: In this method of programming, named after the IEEE standards Joint Test
Action Group, the configuration bit stream is downloaded directly into the Cyclone V FPGA. The
FPGA will retain this configuration as long as power is applied to the board; the configuration
information will be lost when the power is turned off.
2. AS programming: In this method, called Active Serial programming, the configuration bit
stream is downloaded into the Altera EPCS64 serial configuration device. It provides non-volatile
storage of the bit stream, so that the information is retained even when the power supply to the
DE0-CV board is turned off. When the board‟s power is turned on, the configuration data in the
EPCS64 device is automatically loaded into the Cyclone V FPGA.
The sections below describe the steps to perform both JTAG and AS programming. For both
methods the DE0-CV board is connected to a host computer via a USB cable. Using this connection,
the board will be identified by the host computer as an Altera USB Blaster device.
Loading...
