Terasic CY8CKIT-035 User Manual

CONTENTS
CHAPTER 1
INTRODUCTION TO THE PME EBK
...........................................................................3
CHAPTER 2
PME EBK ARCHITECTURE
............................................................................................7
CHAPTER 3
PME EBK HARDWARE OVERVIEW
.............................................................................10
CHAPTER 4
EXAMPLE PROJECTS FOR THE PME
.........................................................................13
CHAPTER 5
SCHEMATICS
........................................................................................................37
1
2
CHAPTER 6
APPENDIX
.....................................................................................................................48
Chapter 1
Introduction to the PME EBK
In general terms, power management or power supervision is a combination of sequencing, monitoring and control of multiple regulators and/or point-of-load DC power converters in a system. Typical solutions for power management include multiple devices such as CPLDs, mixed-signal ASICs and/or limited-functionality and inflexible discrete devices. Power management solutions require: (1) rapid fault detection capabilities for high-availability systems of the power converters in the system; (2) accurate and reliable power rail sequencing of the power converters during power-on and power-off events; (3) voltage and current measurement of the power converters to optimize power consumption and/or for data logging; and, (4) closed-loop control of the power converters through trimming and, for development and manufacturing test purposes, margining of voltage rails in the system.
The PSoC Power Management Expansion Board Kit (PME EBK) is part of the PSoC development kit ecosystem and is designed to work with the CY8CKIT-001 PSoC Development Kit (DVK) and the CY8CKIT-030 PSoC 3 Development Kit (DVK). It enables you to evaluate the system power management functions and capabilities of PSoC 3 devices. You can evaluate the example projects described in this guide or design and customize your own system power management solution using components in Cypress's PSoC CreatorTM software (included in this kit) or by altering example projects provided with this kit.
The PSoC Power Management Expansion Board Kit (PME EBK) is used with the PSoC family of devices and is specifically designed and packaged for use with the PSoC 3 device family. PSoC 3 is a programmable system-on-chip platform that combines precision analog and digital logic with a high performance, single-cycle, 67MHz 8051 processor. With the flexibility of the PSoC architecture, you can easily create your own custom power management solution on chip with the exact functionality you need, in the way you want it—no more, no less.
1.1 Features
The PSoC Power Management Expansion Board Kit (PME EBK) is intended to provide a demonstration and development platform for Cypress and customers in developing power management/supervisor solutions including:
• Power Supply Sequencing
• Power Supply Voltage and Current Measurement
• Power Supply Voltage Trimming and Margining
• Power Supply Over-Voltage and Under-Voltage Fault Detection
• EEPROM Data Recording
• I2C/SMBus/PMBus Host Communications Interface
3
Figure 1-1 shows a simplified block diagram of the most fundamental components on the PME
EBK and how they interact to aid in understanding of the hardware. Not all hardware components are shown.
Figure 1-1 PME EBK Block Diagram
1.2 About the KIT
The PSoC Power Management Expansion board kit (PME) consists of:
• Cypress PME EBK
• Quick Start Guide
• Power DC Adaptor 12V/2A
• System CD containing:
○ User’s Guide (this document) ○ PSoC Creator and pre-requisite software ○ PSoC Programmer and pre-requisite software ○ PME Example Firmware for the CY8CKIT-001 PSoC Development Kit
Advanced Sequencer Power Supervisor
4
○ PME Example Firmware for the CY8CKIT-030 PSoC 3 Development Kit
Advanced Sequencer Power Supervisor
○ Application Note (AN62496) “Voltage Sequencing with PSoC ® 3 and PSoC ® 5” ○ Application Note (AN60220) “Multiplexed Comparator using PSoC ® 3” ○ Datasheets for key PME EBK components
Figure 1-2 shows a photograph of the PME EBK contents.
Figure 1-2 PME EBK Package Contents
5
6
1.3 PSoC Creator
Cypress's PSoC Creator software is a state-of-the-art, easy-to-use integrated development environment (IDE) that introduces a game changing, hardware and software design environment based on classic schematic entry and revolutionary embedded design methodology.
With PSoC Creator, you can:
• Draw a schematic of the hardware circuit you would like to build inside PSoC and the tool will
automatically place and route the components for you
• Eliminate external CPLDs or standard logic ICs by integrating state machines and simple glue
logic in your design Trade-off architecture decisions between hardware and software, allowing you to focus on what matters and getting you to market faster
PSoC Creator also enables you to tap into an entire tools ecosystem with integrated compiler tool chains, RTOS solutions, and production programmers to support PSoC 3.
1.4 Getting Help
Certified as a Cypress Authorized Design Partner, Terasic offers design expertise in rapidly developing PSoC Solutions to get your products into production quickly and reducing your development and BOM costs. Terasic provides customized board designs for academia and industry.
For additional information visit:
www.cypress.com/go/CY8CKIT-035
or
http://pme.terasic.com
For support please contact:
Online: www.cypress.com/go/support Telephone (24x7): +1-800-541-4736 ext. 8 (USA) +1-408-943-2600 ext. 8 (International)
Chapter 2
PME EBK Architecture
This chapter provides information about the architecture and block diagram of the PME EBK.
2.1 Layout and Components
Photos of the PME EBK are shown in Figure 2-1 and Figure 2-2. They depict the layout of the
board and indicate the locations of the connectors and key components.
Figure 2-1 PME PCB (Top)
7
Figure 2-2 PME PCB (Bottom)
2.2 PSoC 4+1 Power Supervisor Solution on the PME
The PSoC Power Management EBK contains 4 DC voltage regulator circuits. They all have enable inputs to allow PSoC to control the power up and power down sequencing of the regulators as well as the necessary passive components to enable PSoC to measure their output voltage and load currents using its built-in ADC converter. The regulators chosen support having their output voltage trimmed (or margined) by PSoC and the necessary passive components to enable PSoC to detect under and over voltage fault conditions using its internal window comparator hardware. PME EBK also provides an I2C/SMBus/PMBus compatible header to support systems that have a requirement for communication with a host controller. All of this functionality is implemented on a single PSoC
3. The PME routes all the input/output signals for power management/supervision to a PSoC 3 mounted on a development kit platform such as the CY8CKIT-001 PSoC Development Kit or CY8CKIT-030 PSoC 3 Development Kit. PSoC 3 is not mounted on the PME EBK itself.
Figure 2-3 shows a high-level overview of the 4+1 Power Management solution that can be
implemented using the PME. Up to 4 secondary regulators can be sequenced through the logic-level enable outputs (labeled as EN[4]). The 4 secondary voltage rails along with one primary input power rail (labeled as V[4+1]) can be multiplexed into a 12 bit, differential Delta Sigma ADC configured for a single-ended input range of 0-4096 mV at 27 ksps with a 0.1% accurate internal reference. For load current measurements across a series shunt resistor (labeled as I[4+1]), the ADC configuration is dynamically changed to a differential input range of ±256mV at 22.9 ksps. A firmware interrupt service routine (ISR) running on PSoC is responsible for taking the raw ADC readings and converting them to actual voltages (in mV) and currents (in μA), performing simple IIR filtering and using this information to increase or decrease the duty cycles of the
8
pulse-width-modulated (PWM) outputs for regulator trimming and margining. The trim/margin PWM outputs from PSoC (labeled as TR[4]) are filtered with a single RC filter stage on PME EBK and fed into the voltage feedback input of the regulators. A single time-multiplexed window comparator is implemented in PSoC using 2 voltage DAC’s (to set the under and over voltage limits for each rail), 2 comparators and a programmable glitch filter. This window comparator loops through each channel at 2μs per channel that it monitors (labeled as C[4+1]). Note that all 5 monitored supply rail voltages are connected to both the V[4+1] and C[4+1] input pins. Each voltage is connected to 2 pins to enable the hardware window comparator and the ADC with input multiplexer to run asynchronously to each other at different speeds in order to give the fastest possible fault detection time.
Figure 2-3 4+1 PSoC Power Management Functional Diagram
Note that PME EBK hardware limits support to a maximum of 4 secondary regulator circuits. The PSoC 3 Power Supervisor solution can be easily extended to support up to 12 secondary regulator circuits. Contact Cypress for further information on the full 12+1 PSoC Power Supervisor solution.
9
Chapter 3
PME EBK Hardware Overview
Figure 3-1 PME Hardware Components
The Power Management EBK Board consists of a 12V primary input power source and 4 secondary voltage rails: V1=5V, V2=3.3V, V3=2.5V and V4=1.8V. Voltage rail V1 feeds power to the other three rails V2, V3 and V4. Therefore, disabling V1 will disable V2-V4 as a result. Each secondary rail consists of a regulator with enable input, circuitry that enables PSoC to apply a DC control voltage to the regulator feedback or adjust pin, as well as fixed and adjustable (potentiometer) load elements. Two jumpers are provided for each rail to (1) disconnect all loads or (2) disconnect only the adjustable load.
PME EBK provides an I2C/SMBus/PMBus connector. A 40-pin (2×20) header J1 is provided to interface this board with the host PSoC on a development kit platform such as the CY8CKIT-001
10
11
PSoC Development Kit or CY8CKIT-030 PSoC 3 Development Kit. The header carries voltage enables, regulator voltage, regulator load currents and trim/margin control signals for each regulator on PME EBK. The I2C physical layer signals (SDA/SCL) from PSoC are also routed across this header to enable connection to an external host or management processor that supports standard I2C, SMBus or PMBus protocol interfaces.
3.1 2x20 pin Interface Header
The following table outlines the definition of the 40-pin J1 header interface.
Table 3-1 2x20 Header (J1) Pin Definition
Description Signal Pin Pin Signal Description
Voltage Regulator 4, Enable V4EN 1 2 V3EN Voltage Regulator 3, Enable Voltage Regulator 2, Enable V2EN 3 4 V1EN Voltage Regulator 1, Enable
- NC 5 6 NC ­Power Rail Current (measured as single ended voltage)
IIN 7 8 VIN Power Rail Sensing Voltage
Analog Ground AGND 9 10 NC ­Voltage Regulator 4, Fault Sensing Voltage
C4 11 12 C3 Voltage Regulator 3, Fault
Sensing Voltage Voltage Regulator 2, Fault Sensing Voltage
C2 13 14 C1 Voltage Regulator 1, Fault
Sensing Voltage Voltage Regulator 4, Trim TR4 15 16 TR3 Voltage Regulator 3, Trim Voltage Regulator 2, Trim TR2 17 18 TR1 Voltage Regulator 1, Trim Analog Ground AGND 19 20 NC ­Voltage Regulator 4, Current (Measured as differential voltage)
I4 21 22 V4 Voltage Regulator 4
Voltage Regulator 3, Current (Measured as differential voltage)
I3 23 24 V3 Voltage Regulator 3
Voltage Regulator 2, Current (Measured as differential voltage)
I2 25 26 V2 Voltage Regulator 2
Voltage Regulator 1 Current (Measured as single ended voltage)
I1 27 28 V1 Voltage Regulator 1
Analog Ground AGND 29 30 NC -
- NC 31 32 /ALERT Alert Signal (I2C/SMBus/PMBus) Serial Data (I2C/SMBus/PMBus) SDAT 33 34 SCL Serial Clock (I2C/SMBus/PMBus)
unused D3V3 35 36 VADJ unused Digital Ground DGND 37 38 D5V unused
Optional 12V Power from DVK DVIN 39 40 DGND Digital Ground
12
3.2 PME EBK Headers and Jumpers
A number of headers and jumpers are provided on the PME EBK. The following table outlines the function of each item and the default configuration.
Table 3-2 PME Jumper Settings
PCB Designator
Description Factory Default
Configuration
J1 2×20 pin header for connecting to PSoC DVK ­J2 5-pin header for connecting an external host or management
processor via I2C/SMBus/PMBus
-
J3 Power Jack ­J4 2×20 pin header that replicates signals on J1 for easy connection to a
logic analyzer or oscilloscope
-
J5 3-pin header for primary input power source selection. Place jumper in
1-2 position to source power from the DC power jack J3. Place in 2-3 position to source power from the PSoC platform DVK
2-3 position
J6 2-pin header for connecting all loads on V1=5V rail (this includes the
fixed and adjustable loads on V1 as well as the load presented by the V2, V3 and V4 rails)
Installed
J7 2-pin header for connecting the potentiometer load on V1=5V rail Installed J8 2-pin header for connecting both loads on V2=3.3V rail (fixed and
adjustable)
Installed
J9 2-pin header for connecting potentiometer load on V2=3.3V rail Installed
J10 2-pin header for connecting ALL loads on V3=2.5V rail (fixed and
adjustable)
Installed
J11 2-pin header for connecting variable potentiometer on V3=2.5V rail Installed J12 2-pin header for connecting ALL loads on V4=1.8V rail (fixed and
adjustable)
Installed
J13 2-pin header for connecting variable potentiometer on V4=1.8V rail Installed
3.3 Development Kit (DVK) Compatibility
This kit contains an expansion board only and requires a Cypress development kit platform in order to use it. This kit is compatible with both the CY8CKIT-001 PSoC DVK and the CY8CKIT-030 PSoC 3 DVK.
NOTE: Early revisions of the CY8CKIT-001 PSoC Development Kit contained an early engineering sample release (ES2) of the PSoC 3 CY8C38xxx Device Family Processor Module which is not compatible with the example projects that accompany this kit. If you have an early revision of the kit you can upgrade free of charge at www.cypress.com/go/psoc3kitupgrade.
Chapter 4
Example Projects for the PME
4.1 Introduction
This section provides details on how to operate the hardware and run the example projects provided.
4.2 Software Installation
Perform the following steps to install the PSoC PME EBK software: Insert the kit CD into the CD drive of your PC. The CD is designed to auto-run and the kit menu
should appear. (See Figure 4-1)
Figure 4-1 CD Autorun Kit Menu
NOTE: If auto-run does not execute, double-click AutoRun on the root directory of the CD. After the installation is complete, the kit contents are available at the following location: C:\Program Files\Terasic\PSoC Power Management EBK\1.0
13
When installing the PSoC Power Management EBK software, the installer checks if your system has the required software. This includes PSoC Creator, PSoC Programmer, Windows Installer, .NET framework, Adobe Acrobat Reader, and KEIL Compiler. If these applications are not installed, then the installer prompts you to install all pre-requisite software, which is also available on the kit CD. The software can be uninstalled using one of the following methods:
z Go to Start > Control Panel > Add or Remove Programs; select appropriate software
package; select the Remove button.
z Go to Start > All Programs > Cypress > Cypress Update Manager > Cypress Update
Manager; select the Uninstall button for the appropriate software package.
z Insert the kit CD and click Install the kit contents fr om CD button. In the CyInstaller for
PSoC Power Management EBK 1.0 window, select Remove from the Installation Type
drop-down menu. Follow the instructions to uninstall. (NOTE: this method will only un install the kit software and not all the other material/software that may have been installed along with the kit software)
4.3 Hardware Setup
The kit includes example projects for both the CY8CKIT-001 PSoC DVK and the CY8CKIT-030 PSoC 3 DVK hardware platforms. The main difference between the projects for the two hardware platforms is the PSoC pin mapping. Other differences will be highlighted in the sections that describe details of the example projects. The following sections describe how to set up the hardware to run the example projects. For a given DVK base platform, the same hardware configuration applies to both example projects.
CY8CKIT-001 PSoC DVK
1. Using the pin header/breadboard area of the PSoC DVK base board, use jumper wires to make
the following connections:
z “SW1” to P1_4 z “SW2” to P1_5
Figure 4-2 CY8CKIT-001 PSoC DVK Breadboard
14
