Tensmate TENS+EMS User Manual
User manual
EN
Contents
- 1 -
2 Foreword
3 General information
4 Overview
5 You might also like...
6 Charging the TENSMATE battery
7 Features and mode description
8 Directions for use
9 Electrode guidelines
10 Electrode recommendations
10 Maintenance and care
11 Storage conditions
11 Technical specications
12 Indications of use
13 Unique benets
14 Regular application principles
15 Regular application methods
15 Pain in the trunk
16 Pain in the joints and limbs
17 Electrode placement variations
18 Troubleshooting
20 Contraindications
21 Warnings and precautions
23 Adverse reactions
24 Warranty information
- 3 -- 2 -
Foreword
Before operation, please read carefully this user’s manual and be clear about the instructions.
Do you suer from PAIN, MUSCLE TENSION or STRESS?
The
TENSMATE can quickly relax tense muscles and relieve pain. It is modern day home therapy device using the
latest bio-electrical technology.
The
TENSMATE is designed to provide endless amount of relaxing, deep, soothing sensations in the areas you
need relief. Relax, feel good and rejuvenate your body and soul. Don’t live with unhealthy physical and mental
tension anymore.
Enjoy the
TENSMATE and live life at fullest, whether you’re at home, at work or on vacation. You’ ll love how
good it feels!
Please read the instructions carefully before usig this instrument.
The
TENSMATE is a double-channel battery operated muscle stimulation system that helps to relieve minor
muscular aches and pains. It comprises of two main components: an electronic stimulatory module which
generates the required stimulation signals and 2 sets of pro-neo neonatal ECG electrode pads with lead wires.
To be used for temporary pain relief associated with sore and aching muscles in the lower back, upper extremities
(arms), lower extremities (legs) and joints due to strain from exercise or normal household work activities.
It is intended to be used to stimulate healthy muscles in order to improve and facilitate muscle performance.
Included in this package:
TENSMATE unit
1 set of LARGE single sided adhesive electrode pads
(2 ½ inches - hand shape)
1 set of SMALL single sided adhesive electrode
pads (1 ¾ inch - small oval shape)
2 Electrode Wires
USB Cable
AC Adapter
User Manual
Pad Holder
Structure:
1. Control unit 6. Pad Holder
2. USB cable 7. LCD screen
3. AC adapter 8. Power switch
4. Electrode wires 9. Outputs
5. Electrode pads 10. USB port
General information
2
3
5
4
6
TENS
mate
TENS
1
10
8
9
7
TENS
mate
TENS
- 5 -- 4 -
USB cable:
use to charge
the Acu XPO battery
AC adapter: use with USB
cable to charge battery
Electrodes:
use to attach to
your bare skin to perform
stimulation
Electrode wires:
use to make
the connection between the
device and the electrodes
Pad holder:
use to store
electrode pads and wires
after use
Overview: control unit and accessories
Battery
icon
Port 2
Pause
Port 1
Intensity
indicator
USB port
Timer
T
On/O switch
Decrease
intensity
M
Mode
selector
Increase
intensity
Mode
indicator
Timer
indicator
You might also like...
Snap-on stimulation sandals: use to ease foot and
ankle pain. It will make your feet feel rejuvenated and
pain-free.
* The items above are not included in the package. They are available at your local distributor .
Silver thread conductive gloves: use to ease hand and wrist pain.
They provide drug-free relief from acute hand and wrist ailments
via a larger conductivity area for even more ecient results.
Silver thread conductive socks: use for
entire foot, ankle and lower leg stimulation.
They provide drug-free relief from acute foot
and ankle ailments via a larger conductivity
area for even more ecient results.
Use at home or during travel.
Wide & rectangular conductive belt:
use for any form of knee, shoulder, elbow,
hip & back ailments.They can help reduce
pain, improve & facilitate muscle performance.
- 7 -- 6 -
3
* Via a standard wall outlet
* Via a computer USB port
1
2
The unit is nished charging when the battery
icon on LCD indicating fully.
The unit is nished charging when the battery icon on
LCD indicating fully.
Charging the TENSMATE battery:
1
2
Connect the AC adapter to any
standard wall outlet.
(A red light will appear to show
that power is owing from the
outlet to the adapter)
Connect the small end of the
USB cable to the unit and the
bigger end to the AC adapter.
Connect the small end of the USB cable to the unit
and bigger end to the USB port on a computer
(computer must be turned on).
* Notes:
1. The lithium battery can be recharged through both AC adapter and USB cable.
2. While charging, the screen in ON position indicates the charge, while in OFF position the screen is blank.
However the battery will charge in either one of the power positions (ON or OFF).
3. The battery should be charged for 8-10 hours before rst use.
Features:
FDA approved Class II Medical Device Adjustable timer
A large, easy to read LCD display Dual outputs (2 ports)
Backlight for increased readability Rechargeable internal lithium battery
20 intensity level settings Stainless steel backing
11 modes +TENS 2 year warranty
Mode description:
We suggest that you initially experiment using each of the modes. The mode or combination of modes that gives you
the most desirable sensations and comfort is the most appropriate one to use for your current condition.
Intensity should be set at a level where you will experience some muscular vibration and involuntary muscle
movements. It should be set to give a “comfortable” intensity and should not be painful.
Timing of application should be at least 10 to 20 minutes.
Frequency of application should be at one to three times per day.
TENS
mate
TENS
TENS
mate
TENS
