W18E
AC1200 Gigabit Wireless Hotspot Router
www.tendacn.com
W18E
AC1200 Gigabit Wireless Hotspot
What it does
W18E is designed to provide wireless network for small
oce, internet café, large house etc premise. It is
compliant with 802.11a/n/ac standard and delivers
wireless rate up to 1200Mbps. Features with external
power amplier and 4 high gain antenna, it provide
superior wireless coverage and high quanlity wi
connection expirence for mobile user. Adopt of 11ac
dual band,airtime fairness,5G bandsteering etc wireless
optimization technology to improve wireless user
capacity and ensure high qualied Wi-Fi connection.
Router
Main Features
2.4GHz 11n 300Mbps
5GHz 11ac 867Mbps
Multi WAN Load Balance
Gigabit Port
Captive Portal
Smart bandwidth control
PPTP/L2TP/IPSec Server
01
W15E / AC1200 Wireless Hotspot Router
High Density User Access
Adopt of 11ac dual band 1167Mbps rate,airtime fairness,5G
bandsteering etc wireless optimization technology to
improve wireless user capacity and ensure high qualified Wi-Fi
connection.
Smart Bandwidth Control
W18E features with smart bandwidth management. It will
adjust each user's download and upload bandwidth automatically according to all users bandwidth usage to avoid bandwidth insufficient.
Full Gigabit Ethernet ports
W18E with 4 Gigabit ports have 10 times wired speed than fast
ethernet ports. It is a better choice to promote the expriences for
accessing Internet.
Multi WAN Load Balance
W18E supports 3 WAN ports. It can realize bandwidth averaging between two WAN ports base IP Group. Also it reserve the
possibility of bandwidth expansion in the future.
Captive Portal
W18E integrates with captive protal service. A landing page
will pop-up when mobile device connect to wifi network.
Once username and password is provided, the user will be
able to access Internet.
PPTP/L2TP/IPSec Server
W18E supports multiple VPN protocols including IPsec, PPTP
and L2TP in Client/Server mode. It is easily to setup a secure
data link between branch and headquater through
LAN-to-LAN/Client-to-LAN mode.
02
W15E / AC1200 Wireless Hotspot Router
Specications
Hardware Specications
Dimension
Frequency
Wireless Speed
RAM
FLASH
Max Power Consumption
Interfaces
Power
Software Specifications
Max user capacity
Max Wifi user capacity
Internet Connection Type
Authrization Service
Captive Portal
Bandwidth Control
Internet Access Control
VPN Protocal
220*135*30(mm)(LxWxH)
2.4GHz\5GHz
300+867Mbps
128MB
8MB
12W
4*GE(1~3 WAN/ 1~3 LAN)
12V 1A
80
50
PPPoE/DHCP/Static IP/Russian L2TP/India
Captive Portal
300 Portal Accounts
Customize E-bulletin
Smart Bandwith Control
Manual Definition
IP/mac/URL Filter
PPTP、L2TP、IPSEC
Port Forwarding
Security Setting
DDNS
UPNP
Firmware Upgrade
System Tool
Network Status View
Port Forwarding
DMZ
DDoS Protection
ARP Attack Protection
Support
Support
Local
online Upgrade
Schedule Reboot
Restore or Backup Configuration
Network structure topology
Traffic Statistics
03
W15E / AC1200 Wireless Hotspot Router
www.tendacn.com
Tenda Technology Bldg.Int ’ IE-City,
#1001 Zhong Shan Yuan Rd.,Nanshan District,Shenzhen China.
E-mail: support@tenda.cn
Tel: 0755-2765 7098
Fax: 0755-2765 7178
PC: 518055
