MW12
AC2100 Tri-band Whole Home Mesh WiFi System
www.tendacn.com
MW12
AC2100 Whole Home Mesh WiFi System
Product Description
The MW12 is a whole home Mesh WiFi system designed for medium to large households with a high speed
broadband service. Powered by Tenda Mesh technology, it creates a distributed network with several nodes
throughout your home. A 3-pack of MW12 is able to cover up to 500 m2 / 6000 sq.ft. AC2100 tri-band design
and full gigabit ports support and give full play to your high speed broadband service. It carries a 900 MHz
strong CPU and 256 MB large memory, and is able to handle more devices on your network. All terminals
can enjoy high-speed tri-band WiFi at the same time, indicating low latency for internet games, smooth
streaming of 4K videos and VR HD applications. It features easy and wire-free installation and allows both
auto-networking and manual addition. With seamless roaming around the house, the MW12 creates a
high-speed and intelligent Mesh WiFi system throughout your home.
01
MW12/AC2100 Tri-band Whole Home Mesh WiFi System
Selling Points
Tri-band AC2100 Mesh For Best
Internet Experience
Tri-band AC2100 Mesh solution exploits the full potential of
your Fiber access. Three bands(2.4GHz, 5GHz-1, 5GHz-2)
are used as backhaul to eliminate the lag while multiple devices
streaming at the same time.
Built-in Signal Enhancement Module
It adopts 5GHz dedicated powerful WLAN full-featured front
-end module, equipped with integrated signal amplifier. The
concentrated signal makes sure stronger and more stable Multi
-story home WiFi coverage. You can enjoy best signal in any
conner.
Whole Home Seamless Roaming
MW12 units work together under one unified network supported
by 802.11k/v/r protocal,always connect your devices with the
best performance node while the devices freely moving around
in your house.
Compatible with All Nova-series
Any Nova-series product (MW3, MW5, MW5S, MW5G, MW6,
MW12) can be used as an extra unit in existing Nova network
easily to meet varies house type requirement.
Connection for over 100 Devices
02
Equipped with dual-core 900MHz CPU, 256M DDR3 memory
supporting MU-MIMO technology to bring lag-free experience
for over 100 devices.
MW12/AC2100 Tri-band Whole Home Mesh WiFi System
Selling Points
Featuring QoS Technology
Quality of Service (QoS) optimizes traffic so that stream with
higher priority can pass first, which brings better performance
for 4K video,HD-VR Game and etc.
Remote Control with APP
All Nova units are delivered pre-paired right out of the box,
and a new node can be added to original Nova network with
3 simple steps.
Easily manage your Nova units with Tenda WiFi APP. The real
-time progress of online devices is all in your hands.
Purchase Guide
Feature
Mode
Compatible
Broadband
Max. Mesh nodes
supported (Qty./Size)
MW3 (3-pack) MW5 (3-pack) MW6 (3-pack) MW12 (3-pack)MW5G (3-pack)
AC1200WiFi Speed AC1200 AC1200 AC2100AC1200
100 Mbps
up to 3500 sq.ftCoverage Area* up to 3500 sq.ft up to 6000 sq.ft up to 6000 sq.ftup to 3500 sq.ft
5 (5000 sq.ft)
Style with Minimalist and Fashionable
With its stylish design, you can display Nova like a piece of
workart in your entertainment center.
>100 Mbps ≥200 Mbps ≥500 Mbps
6 (6000 sq.ft) 9 (12000 sq.ft) 12 (15000 sq.ft)6 (6000 sq.ft)
＞100 Mbps
Max. No. of
Connected Devices
03
40 devices
60 devices 90 devices 120 devices80 devices
MW12/AC2100 Tri-band Whole Home Mesh WiFi System
Processor Dual core 900MHz CPU
RAM 256MB DDR3
RF
Standard&Protocol
Ethernet Interface
Antennas
Button 1 x Reset Button
LED Indicator
Power
Dimensions
2.4G: 18.5±1dBm@MCS7 VHT40
5.1G: 18.5±1dBm@MCS9 VHT80
5.4G-5.8G: 21±1dBm@MCS9 VHT80(dedicated backhaul)
IEEE802.11a/b/g/n/ac
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
3 x 10/100/1000Mbps RJ45 ports per node
4 x Internal antenna
1 x Tri-color LED Indicator(Green,Yellow,Red)
Input: 100-240V—50/60Hz, 0.6A ; Output: 12V1.5A
100 x 100 x 100mm (3.9 x 3.9 x 3.9in)
Wireless Features
Wireless Standards IEEE802.11a/b/g/n/ac (WiFi 5 wave 2)
Wireless roaming
Comply with IEEE802.11k/v/r
Mesh network Standard IEEE802.11s
Rate
Frequency
Basic Features
Wireless Security WPA-PSK/WPA2-PSK(default)
2.4GHz: 300Mbps
5GHz-1: 867Mbps
5GHz-2: 867Mbps
2.4~2.4835GHz
5.15~5.25GHz
5.47~5.725GHz (for EU countries)
5.725~5.85GHz
SSID Broadcast
Beam Forming
MU-MIMO
AP Steering
Band Steering
04
W12/AC2100 Tri-band Whole Home Mesh WiFi System
Software Features
Operating Mode Router Mode,Bridge Mode
Internet Connection Type
DHCP Server DHCP Server, DHCP Client List
Virtual Server Port Forwarding, DMZ Host, UPnP
Parental Control
Firewall
Special Features
Others
PPPoE, Dynamic IP, Static IP, PPPoE(Russia), PPTP(Russia), L2TP(Russia)
Client Filter
Manually setting up DNS server
Forbid TCP/UDP flood attack
VPN(PPTP/L2TP/IPsec )pass through
Dedicated Backhaul
Turbo Backhaul Mode
Fast Roaming
Smart QoS (Gaming, Video & Audio, Download)
Auto-sensing internet connection
Support App management and Remote management
Guest Network
Firmware upgrade online
Others
Operating Temperature Storage Temperature: -40 °C - 70 °C
Storage Temperature -40 ~ 70
Operating Humidity
Storage Humidity
APP installation
Certification CE, FCC, RoHS
Tenda Technology Bldg.Intʼ l E-City,
#1001 Zhong Shan Yuan Rd.,Nanshan District,Shenzhen China.
E-mail:support@tenda.com.cn
Tel:+86-755-2765 7098
Fax:+86-755-2765 7178
10%~90% RH non-condensing
5%~90% RH non-condensing
Available in iOS 8.0 or later, Android 4.0 or later
05
Specifications are subject to change without notice.Copyright ©2019 SHENZHEN TENDA TECHNOLOGY CO
TENDA TECHNOLOGY CO.,LTD. All other brand names mentioned herein are the trademark or registered trademar
