Tenda AC21 User Manual

What it does
01
AC21/AC2100 Dual Band Gigabit WiFi Router
AC21
AC2100 Dual Band Gigabit Wireless Router
802.11ac wave2 techonology and provides WiFi speed up to 2033Mbps (2.4 GHz: 300Mbps, 5GHz: 1733Mbps) to achieve the
best performance for your fiber internet connection. Powered by 4X4 MU-MIMO technology of 5GHz band, it provides wider WiFi
coverage and faster WiFi speed than regular routers with 3X3 MU-MIMO technology. Equipped with full gigabit ports, it supports
up to 1000Mbps bandwith access. The 28nm 1GHz CPU equipped with 500MHz co-processor, dual-core design brings a faster
processing speed and provides optimized operation. Featured with 6*6dBi external antennas , AC21 outshines in performance
and wall penetration capacity.
AC2100 Dual-Band Gigabit Wireless Router
AC21
www.tendacn.com
02
AC21/AC2100 Dual Band Gigabit WiFi Router
Main Features
AC2100 for Advanced WiFi Speed
AC21 is a dual-band gigabit wireless router, adopted with 802.11 ac wave2 techonology and provides speed up to 2033 Mbps to get the most out of your gigabit fiber internet.
4x4 MU-MIMO for 5GHz Band
Powered by 4X4 MU-MIMO techonology of 5GHz band, it provides wider WiFi coverage and faster WiFi speed than regular routers with 3X3 MU-MIMO techo- nology.
Built-in Signal Amplifier for Main Chip
Built-in signal amplifier used both on 2.4GHz and 5GHz bands of AC21 to enhance the penetration capability and expand the WiFi coverage.
6*6dBi External Antennas for Better WiFi Signal
With 6*6 dBi external antennas and four data streams of 5Ghz band, the AC21 can provide optimized WiFi coverage and better 5GHz WiFi signal.
Support Fiber Internet Up to 1000Mbps
Equipped with full gigabit ports, it supports up to 1000Mbps bandwith access.
Dual-core Design Bring a More Stable Operation
The 28nm 1GHz CPU equipped with 500MHz co-processor, dual-core design brings a faster processing speed and provides optimized operation.
Support IPv6 Protocol
AC21 supports IPv6, it can reduce the data transmission time and minimize the lag, provide a better gaming experience.
AC21
AC2100 Dual Band Gigabit Wireless Router
What it does
802.11ac wave2 techonology and provides WiFi speed up to 2033Mbps (2.4 GHz: 300Mbps, 5GHz: 1733Mbps) to achieve the
best performance for your fiber internet connection. Powered by 4X4 MU-MIMO technology of 5GHz band, it provides wider WiFi
coverage and faster WiFi speed than regular routers with 3X3 MU-MIMO technology. Equipped with full gigabit ports, it supports
up to 1000Mbps bandwith access. The 28nm 1GHz CPU equipped with 500MHz co-processor, dual-core design brings a faster
processing speed and provides optimized operation. Featured with 6*6dBi external antennas , AC21 outshines in performance
and wall penetration capacity.
01
AC21/AC2100 Dual Band Gigabit WiFi Router
Main Features
AC21/AC2100 Dual Band Gigabit WiFi Router
03
Specification
Hardware Specification
Wireless Features
Software Features
IEEE802.3, IEEE802.3u,IEEE802.3ab
1*10/100/1000Mbps WAN port;
3*10/100/1000Mbps LAN ports;"
6*6dBi external antennas
1* WPS/Reset button,
Input 󰵼AC 100-240V~50/60Hz 0.6A
Output󰵼DC 12V1.5A"
231.3*150.6*39.6mm
Sys*1,WAN*1, LAN*1,WiFi/WPS*1
Standards
Antenna
Button
Dimensions
LED Indicator
IEEE 802.11ac wave2/a/n 5GHz
IEEE 802.11b/g/n 2.4GHz
5GHz: Up to 1733Mbps
2.4GHz: Up to 300Mbps
Simultaneous dual band 2.4 & 5GHz
CE: <20dBm(2.4G) <23dBm(5G)
FCC: <30dBm
SSID Broadcast: Enable/Disable;
Transmission Power: high, medium, low
Beamforming
MU-MIMO
WPA-PSK/WPA2-PSK, WPA/WPA2;
Wireless Security: Enable/Disable;
WPS(WiFi Protected Set-up) fast encryption"
Internet Connection Type
Operating Mode
PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)
Wireless Router Mode
Universal Repeater Mode
WISP Mode
DHCP Server DHCP Client List DHCP Reservation
Port Forwarding DMZ Host UPnP
Environment
Frequency
Transmit Power
Basic Features
wireless Security
Wireless Standards
DHCP Server
Virtual Server
Interface
Power
AC2100 for Advanced WiFi Speed
AC21 is a dual-band gigabit wireless router, adopted with 802.11 ac wave2 techonology and provides speed up to 2033 Mbps to get the most out of your gigabit fiber internet.
4x4 MU-MIMO for 5GHz Band
Powered by 4X4 MU-MIMO techonology of 5GHz band, it provides wider WiFi coverage and faster WiFi speed than regular routers with 3X3 MU-MIMO techo­nology.
Built-in Signal Amplifier for Main Chip
Built-in signal amplifier used both on 2.4GHz and 5GHz bands of AC21 to enhance the penetration capability and expand the WiFi coverage.
6*6dBi External Antennas for Better WiFi Signal
With 6*6 dBi external antennas and four data streams of 5Ghz band, the AC21 can provide optimized WiFi coverage and better 5GHz WiFi signal.
Support Fiber Internet Up to 1000Mbps
Equipped with full gigabit ports, it supports up to 1000Mbps bandwith access.
Dual-core Design Bring a More Stable Operation
The 28nm 1GHz CPU equipped with 500MHz co-processor, dual-core design brings a faster processing speed and provides optimized operation.
02
Support IPv6 Protocol
AC21 supports IPv6, it can reduce the data transmission time and minimize the lag, provide a better gaming experience.
AC21/AC2100 Dual Band Gigabit WiFi Router
Specification
Hardware Specification
Standards
Interface
Antenna
Button
Power
Dimensions
LED Indicator
Wireless Features
Wireless Standards
Environment
Frequency
IEEE802.3, IEEE802.3u,IEEE802.3ab
1*10/100/1000Mbps WAN port;
3*10/100/1000Mbps LAN ports;
6*6dBi external antennas
1* WPS/Reset button,
AC 100-240V~50/60Hz 0.6A
Input
Output
231.3*150.6*39.6mm
Sys*1,WAN*1, LAN*1,WiFi/WPS*1
IEEE 802.11ac wave2/a/n 5GHz
IEEE 802.11b/g/n 2.4GHz
5GHz: Up to 1733Mbps
2.4GHz: Up to 300Mbps
2.400-2.4835GHz5.150-5.250GHz
DC 12V1.5A
Transmit Power
Basic Features
wireless Security
Software Features
Internet Connection Type
Operating Mode
DHCP Server
CE: <20dBm(2.4G) <23dBm(5G)
SSID Broadcast: Enable/Disable;
Transmission Power: high, medium, low
Beamforming
MU-MIMO
WPA-PSK/WPA2-PSK, WPA/WPA2;
Wireless Security: Enable/Disable;
WPS(WiFi Protected Set-up) fast encryption"
PPPoE, Dynamic IP, Static IP
PPPoE(Russia), PPTP(Russia), L2TP(Russia)
Wireless Router Mode
Universal Repeater Mode
WISP Mode
DHCP Server DHCP Client List DHCP Reservation
03
Virtual Server
Port Forwarding DMZ Host UPnP
AC21/AC2100 Dual Band Gigabit WiFi Router
Specification
Software Features
Client Filter
Security
Firewall
DDNS
VPN
Special Features
Special Features
Parental Control(support black list and white list)
Remote Web Management
Forbid UDP flood attack Forbid TCP flood attack
Forbid flood attack Forbid WAN PING from internet
Support DynDNS, Oray.com, 88ip
IPsec pass through PPTP pass through
L2TP pass through PPTP server
PPTP client L2TP client
Smart Traffic Prioritisation PPPoE Username/password Clone
Smart WiFi Schedule Smart Power Saving
Smart LED on/off Tenda Cloud
Tenda App
Bandwidth Control Guest Network
IPTV MAC Clone
Static Routing System Log
Software Features
Temperature
Humidity
Factory Defaul Settings
Certificates
EIRP Power (Max)
Package Contents
Backup & Restore configurations Firmware upgrade online
Firmware upgradeable via browser Supports IPv6
Operating Temperature: 0 ~ 40 ;
Storage Temperature: -40
Operating Humidity:10% ~ 90% RH non-condensing;
Storage Humidity: 5% ~ 90%RH non-condensing."
Default Access: tendawifi.com
CE/FCC/RoHS
2.400-2.4835GHz:19.86dBm (EIRP); 5.150-5.250GHz:22.96dBm (EIRP)
Wireles Router*1
Power Adapter *1
Install Guide*1
Ethernet Cable*1"
~ 70 ."
E-mail:support@tenda.com.cn
Tenda Technology Bldg.Int’ l E-City, #1001 Zhong Shan Yuan Rd.,Nanshan District,Shenzhen China.
Specifications are subject to change without notice.Copyright ©2019 SHENZHEN TENDA TECHNOLOGY CO.,LTD. All rights reserved. Tenda is the trademark of SHENZHEN TENDA TECHNOLOGY CO.,LTD.
All other brand names mentioned herein are the trademark or registered trademarks of their respective holders.
Tel:+86-755-2765 7098 Fax:+86-755-2765 7178
