Tenada TED8620B User Manual

1．Brief Introduction of TED8620B ADSL Modem

1.1 Product Features

Welcome to use Tenda ADSL Modem TED8620B

1.1.1 Features

 Pure bridge mode，support 64 groups of VPI/VCI setting
 Max Downstream/Upstream: 8Mbps/1Mbps
 Max Transmission Distance: 5.4 Kms
 Excellent and Friendly User Configuration Interface, compliant with the currently popular

Server/Browser mode

1.1.1 Protocol
Support Full-Wire ADSL standard

 ANSI T1. 413 Issue 2
 ITU-T G. 992. 1 (G. dmt)
 ITU-T G. 992. 2 (G. Lite)
 Multi-Mode

1.1.2 Data Packing
 Support RFC 1483 Bridge

1.2 Unpacking
Please unpack and you would find the following items inside:

 One unit of TED8620B ADSL Modem
 One English User’s Manual
 One ADSL Splitter
 One RJ45 Cable
 2 RJ11 Cable
 One piece of product warranty card

If you found any of the above items missing, please contact your local distributor or
contact us with the warranty card.

1.3 Physical Environment Required
In order to reach maximum performance, we recommend using the following computer
configuration:

 Pentium 233MHz of above
 64MB Memory of above
 10M Base T Ethernet NIC or above
 WIN9X WIN2000 WINXP WINME WINNT

1.4 Introduction of External Components

1.4.1 LED Indicators

Figure 1.1 TED8620B Front Panel
There are 5 LED indicators on front panel of TED8620R, you can know the working status
of the modem through the LED, they indicate as follows:
