Tempure Scientific UCR-5.2-G-TP User Manual

Features:

UCR-5.2-G-TP

Premier Undercounter Refrigerator (Free Standing)

Specifications:

Capacity 5.2 cubic ft
Temperature Range 0°C to 10°C Preset 4°C
Exterior (w x d x h) 23¾” x 24” x 32⅛”
Interior (w x d x h) 20¼” x 16½” x 26¾”

Specifications subject to change without notice

Temperature
Control

Microprocessor Temperature Controller

Digital Temperature Display
Exterior Finish Powder Coat Exterior
Legs Leveling
Door One Glass Swing Door, Magnetic

Gasket, Keyed Lock
Shelves Three Adjustable (Two Full, One Half)
Insulation High density urethane foam cabinet.
Refrigerant R134a
Compressor 1/5 hp
Defrost Cycle
Probe Access Port 3/8"
BTU's 310/hr
Voltage: Domestic 115
Amps 2
Shipping Weight 133 lbs.
Warranty

(Domestic)

Two (2) year parts and labor warranty
Five (5) year compressor warranty

Interior Light (Please note; Exterior Dimensions do not include
3" clearance required for installation)

ADA Compliant

Optimal Operating Conditions

Optimal operation of this unit requires it to be located in a climate controlled facility that maintains temperatures at or below 75°F with 55% relative humidity

1-866-923-PURE • Fax [phone] • Contact: sales@tempurescientic.com • Website: www.tempurescientic.com

Exterior

45½”

22”

23¾”

115VAC/60Hz/1PH

NEMA-5-15R

Unit Weight

Premier Undercounter Refrigerator

UCR-5.2-G-TP

1/8 2 93 lbs.1/5

24”

3Adj

1/8”

32

SET

23¾”

Front View Side View Top View

5.2 Cycle

1 Glass 0 23¾ 24 32

CUTSHEET

Model Defrost Door Int Door Shelves W” D” H” H.P. AmpsCu. Ft

UCR-5.2-G-TP
