FOR MODEL :
EVOLVE
TREADMILL USER’S GUIDE
I N T R O D U C T I O N
CONGRATULATIONS on choosing your treadmill! You’ve taken an important step in developing and sustaining an exercise program! Your treadmill is a tremendously effective tool for achieving your personal fitness goals. Regular use of your treadmill can improve the quality of your life in so many ways.
Whether your goal is to win races or simply enjoy a fuller, healthier lifestyle, a Tempo Fitness treadmill can help you attain it – adding quality performance to your at-home workouts, with the ergonomics and innovative features you need to get stronger and healthier, faster. Because we're committed to designing fitness equipment from the inside out, we use only quality components.
You want exercise equipment that offers the most comfort, the best reliability and quality in its class.
Tempo Fitness delivers.
TABLE OF CONTENTS
Important Precautions |
4 |
|
|
About Your Treadmill |
6 |
|
|
Before You Begin |
10 |
|
|
Treadmill Operation |
13 |
|
|
Conditioning Guidelines |
16 |
|
|
Troubleshooting & Maintenance |
20 |
|
|
Limited Warranty |
23 |
CONTACT INFORMATION |
Back Panel |
IMPORTANT PRECAUTIONS INTRODUCTION
ABOUT YOUR TREADMILL
BEFORE YOU BEGIN
TREADMILL OPERATION
TROUBLESHOOTING CONDITIONING & MAINTENANCE GUIDELINES
LIMITED WARRANTY
IMPORTANT INTRODUCTION PRECAUTIONS
YOUR ABOUT TREADMILL
BEFORE BEGIN YOU
TREADMILL OPERATION
LIMITED TROUBLESHOOTING CONDITIONING WARRANTY MAINTENANCE & GUIDELINES
IMPORTANT PRECAUTIONS
SAVE THESE INSTRUCTIONS
Read all instructions before using this treadmill. When using an electrical product, basic precautions should always be followed, including the following: Read all instructions before using this treadmill. It is the responsibility of the owner to ensure that all users of this treadmill are adequately informed of all warnings and precautions. If you have any questions after reading this manual, contact Customer Tech Support at the number listed on the back panel of this manual.
WARNING |
Connect this exercise product to a properly grounded outlet only. See grounding |
instructions. |
GROUNDING INSTRUCTIONS
This product must be grounded. If a treadmill should malfunction or breakdown, grounding provides a path of least resistance for electrical current to reduce the risk of electrical shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with local codes and ordinances.
Improper connection of the equipment-grounding conductor can result in a risk of
WARNING electric shock. Check with a qualified electrician or serviceman if you are in doubt as to whether the product is properly grounded. Do not modify the plug provided
with the product. If it will not fit the outlet, have a proper outlet installed by a qualified electrician.
This product is for use on a nominal 110-volt circuit and has a grounding plug that looks like the illustration. This product must be used on a dedicated circuit. To determine if you are on a dedicated circuit, shut off the power to that circuit and observe if any other devices lose power. If so, move devices to a different circuit. Note: There are usually multiple outlets on one circuit. It is recommended that the treadmill be used with a 15 amp circuit for optimal performance.
3-Pole Grounded Outlet
GROUNDED
TREADMILL
POWER CORD
At NO time should pets or children under the age of 12 be closer to the treadmill than 10 feet. At NO time should children under the age of 12 use the treadmill.
Children over the age of 12 should not use the treadmill without adult supervision.
WARNING To reduce the risk of burns, fire, electrical shock or injury to persons:
•Never use the treadmill before securing the safety tether clip to your clothing.
•If you experience any kind of pain, including but not limited to chest pains, nausea, dizziness, or shortness of breath, stop exercising immediately and consult your physician before continuing.
•Do not wear clothes that might catch on any part of the treadmill.
•Always wear athletic shoes while using this equipment.
•Do not jump on the treadmill.
•Keep power cord away from heated surfaces.
•Do not insert or drop any object into any opening.
•Unplug treadmill before moving or cleaning it. To clean, wipe surfaces down with soap and slightly damp cloth only; never use solvents. (See MAINTENANCE)
•At no time should more than one person be on treadmill while in operation.
•The treadmill should not be used by persons weighing more than 114 kg (250 lbs). Failure to comply will void the warranty.
•The treadmill is intended for in-home use only. Do not use this treadmill in any commercial, rental, school or institutional setting. Failure to comply will void the warranty.
•Do not use treadmill in any location that is not temperature controlled such as but not limited to garages, porches, pool rooms, bathrooms, car ports or outdoors. Failure to comply may void the warranty.
•Use the treadmill only as described in this manual.
Do not use ANY lubricant |
CAUTION
Do not apply ANY lubricant to the folding mechanism.
This could damage it. Failure to comply may void the warranty.
Other safety tips for your treadmill
OPERATION
WARNING To reduce the risk of damaging important components on your treadmill, it is strongly
recommended that your treadmill is plugged into a dedicated 15 amp circuit, without the use of an additional extension cord and/or power strip. Failure to comply may void the warranty.
IMPORTANT: The treadmill is not compatible with GFCI-equipped outlets.
It is essential that your treadmill is used only indoors, in a climate-controlled room. If your treadmill has been exposed to colder temperatures or high moisture climates, it is strongly recommended that the treadmill is warmed up to room temperature before first time use. Failure to do so may cause premature electronic failure.
IMPORTANT PRECAUTIONS INTRODUCTION
ABOUT YOUR TREADMILL
BEFORE YOU BEGIN
TREADMILL OPERATION
LIMITED TROUBLESHOOTING CONDITIONING WARRANTY & MAINTENANCE GUIDELINES
IMPORTANT INTRODUCTION PRECAUTIONS
YOUR ABOUT TREADMILL
BEFORE BEGIN YOU
TREADMILL OPERATION
TROUBLESHOOTING CONDITIONING MAINTENANCE & GUIDELINES
ABOUT YOUR TREADMILL
THERE IS NO ASSEMBLY REQUIRED FOR THIS TREADMILL!
UNPACKING
Place the treadmill carton on a level flat surface. It is recommended that you place a protective covering on your floor. Take CAUTION when handling and transporting this unit. Never open box when it is on its side. Unpack the unit where it will be used. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN INJURY!
Before proceeding, find your treadmill’s serial number and model name located on the stabilizer leg and enter it in the space provided below.
Enter your serial number and model name in the boxes below:
SERIAL NUMBER:
MODEL NAME:
*Refer to the serial number and model name when calling for service.
*Also enter this serial number on your Warranty Card.
LIMITED WARRANTY
READING RACK |
CONSOLE |
|
SAFETY KEY PLACEMENT |
STORAGE POCKET |
|
|
TOUCH PAD PANEL WITH LCD DISPLAY |
|
FRONT HANDLEBAR |
|
CONSOLE MAST |
LOCKING HANDLEBAR |
|
|
LOCKING LATCH |
MOTOR COVER |
|
|
RUNNING BELT / RUNNING DECK |
SIDE RAIL |
|
ROLLER END CAP |
REAR ROLLER |
|
ADJUSTMENT BOLTS |
TRANSPORT HANDLE |
|
FOLDING HANDLEBAR |
|
LOCK BUTTONS |
STABILIZER BRACKET |
|
(LOCATED ON UNDERSIDE OF TREADMILL) |
CIRCUIT BREAKER
POWER CORD
ON/OFF SWITCH
STABILIZER LEGS
TRANSPORT WHEEL
IMPORTANT PRECAUTIONS INTRODUCTION
ABOUT YOUR TREADMILL
BEFORE YOU BEGIN
TREADMILL OPERATION
TROUBLESHOOTING CONDITIONING & MAINTENANCE GUIDELINES
LIMITED WARRANTY
IMPORTANT INTRODUCTION PRECAUTIONS
YOUR ABOUT TREADMILL
BEFORE BEGIN YOU
TREADMILL OPERATION
LIMITED TROUBLESHOOTING CONDITIONING WARRANTY MAINTENANCE & GUIDELINES
U N F O L D I N G
The treadmill was folded in the carton when purchased. Follow these steps to unfold the treadmill.
1. |
Press and hold both lock buttons |
|
|
with your thumbs. |
4 |
|
|
|
2. |
Carefully lift the console module |
2 |
|
||
|
upward until it is in the upright |
|
|
position. The locking latch will |
|
|
automatically engage. |
|
3. |
Pull the LOCKING BAR upward until |
1 |
|
it is tight. |
|
|
|
|
4. |
Gently pull the front handlebar |
3 |
|
downward. |
CAUTION:
Do not use the treadmill if the
LOCKING BAR is not tight.
F O L D I N G
Follow these steps to fold the treadmill.
1.Gently pull the front handlebar upward.
2.Pull the LOCKING bar downward to release the lock.
3.Pull locking latch upward.
4.Carefully pull the console module downward until it rests flat on the treadmill deck.
5.Press down on the console module until both locks engage.
LOCKING LATCH
3
5 |
2 |
