Temco VF36RN, VF36RNH, VF36RP Homeowner's Installation And Operating Instructions Manual

PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING HEATERS

IMPORTANT: Read all instruc-

tions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty.

Vent-Free Gas Fireplaces

WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

— Do not store or use gasoline or

other flammable vapors and liquids in the vicinity of this or any other appliance.

— What to Do If You Smell Gas

• Do not try to light any appli-

ance.

• Do not touch any electrical

switch; do not use any phone in your building.

• Immediately call your gas

supplier from a neighbor's phone. Follow the gas supplier's instructions.

• If you cannot reach your gas

supplier, call the fire department.

Models: VF36RN, VF36RNH, VF36RP

Homeowner’s Installation and

— Installation and service must be

performed by a qualified installer, service agency or the gas supplier.

This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions for adequate combustion and ventilation air must be provided. Refer to Page 4.

Models with “N” after the model number use natural gas; models with “P” after the model number use Propane (LP) gas.

INSTALLER: DO NOT DISCARD THIS MANUAL - Leave in fireplace for homeowner.

Operating Instructions

Gas Fired Unvented Room Heaters

5L24

This appliance is UL Certified under ANSI Standard

Z21.11.2-2000 as an unvented room heater

Temco Fireplace Products

410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777

78586 11/03 Rev. 8

Temco VF36RN/RNH/RP

Table of Contents

This book contains your operating and installation instructions and should be kept in a safe place. For you to realize all the advantages and use of the reliable service that has been engineered into your TEMCO fireplace, you must carefully follow all of the instructions contained in this book regarding installation and operation of the fireplace. These instructions should be read carefully in their entirety before beginning installation of the fireplace. It is suggested that you wear work gloves and safety glasses to protect your hands and eyes when installing your fireplace.

NOTE: Authorities having jurisdiction (i.e. building inspectors, fire marshals, etc.) should be consulted before installation to determine the need to obtain a permit.

FAILURE TO FOLLOW THESE INSTRUCTIONS WILL VOID YOUR WARRANTY AND MAY PRESENT A FIRE HAZARD.

Important Information...................................................................................................................3

Provision for Adequate Combustion and Ventilation Air ..................................................................4

Fireplace Dimensions......................................................................................................................6

Installation & Operating Instructions

Locating the Fireplace........................................................................................................7

Gas Line.............................................................................................................................7

Drafts..................................................................................................................................7

Fan Kit................................................................................................................................7

Electrical Services..............................................................................................................7

Framing Clearances...........................................................................................................7

Clearances .........................................................................................................................8

Installation ..........................................................................................................................9

Gas Connection ...............................................................................................................10

High Altitude Installation ...................................................................................................10

Gas Pressure Check ........................................................................................................ 11

Gas Pipe Sizing Chart......................................................................................................11

Log Installation .................................................................................................................12

Log Assembly...................................................................................................................12

Lighting Instructions .........................................................................................................13

Match Lighting..................................................................................................................13

Flame Check ....................................................................................................................14

Finishing the Fireplace .....................................................................................................14

Managing Heat Output .....................................................................................................15

Maintenance

Cleaning ...........................................................................................................................15

Troubleshooting..........................................................................................................................16

Servicing ..........................................................................................................................16

Repair Parts .................................................................................................................................17

Warranty Information..................................................................................................................18

Installation And Startup Checklist.............................................................................................19

Warranty Registration.................................................................................................................21

78586

Important Information

INSTALLER: Please leave these instructions with the

owner. OWNER: Please retain these instructions for future reference.

IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE OPERATING.

WARNING: Any change to this heater or its controls can be dangerous.

This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with other gases.

This heater shall not be installed in a confined space or unusually tight construction unless provisions are provided for adequate combustion and ventilation air.

NOTES

• Due to high temperatures, the appliance should be

located out of traffic and away from furniture and draperies.

• Installation and repair must be done by a qualified service

person or gas appliance installer.

• A fireplace screen must be in place when the appliance is

operating. On models with movable screens, the screens must be closed when the fireplace is operating.

• The appliance must be inspected before use and at least

annually by a professional service person. More frequent cleaning may be required due to excessive lint from carpeting, bedding material, dust and pet hair, etc. It is important that the control compartment, burners and circulating air passageways of the appliance be kept clean.

• DO NOT place clothing or other flammable material on or

near the appliance.

• This appliance must only be used with pressures at the inlet

as shown in Table 1, Page 11 in installation instructions.

• The installation must conform with local codes or, in the

absence of local codes, with the NATIONAL FUEL GAS CODE, ANSI Z223, latest edition.

• Any safety screen or guard removed for servicing an appli-

ance must be replaced prior to operating the heater.

• The appliance and its appliance main gas shut-off valve must

be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psig (3.5 kpa).

• The appliance must be isolated from the gas supply piping

system by closing its equipment shut-off valve during any testing of the gas supply piping system at test pressures equal to or less than 1/2 psig (3.5 kpa).

• DO NOT use this heater in recreational vehicles, bedrooms or

bathrooms.

• If this is the ONLY gas appliance, we recommend a

minimum 200 pound cylinder with a fill gauge. Use of a 100 pound cylinder is not recommended. Other household gas appliances may require the tank size to be larger. Do not operate the vent-free heater if the fuel level in the propane tank is below 1/4 full.

Temco VF36RN/RNH/RP

• Use only with two-stage regulator.

• DO NOT use this heater if any part of it has been under

water. Immediately call a qualified technician to inspect the appliance and replace any part of the control system and any gas control which has been under water.

• This appliance may be installed in an after-market* manufac-

tured "mobile" home where not prohibited by state or local codes.

*After-market: Completion of sale, not for purpose of re-sale from the manufacturer.

• Children and adults should be alerted to the hazard of high

surface temperature and should stay away to avoid burns or clothing ignition.

• Although your gas logs are very realistic in appearance,

it is not a real wood-burning fireplace and must not be used for burning solid fuel.

• To avoid irreparable damage to the appliance or personal

injury; matches, paper, garbage or any other material must not be placed or thrown on top of the logs or into the flames.

• To avoid personal injury, do not touch hot surfaces when

the appliance is operating.

• Close supervision is necessary when the appliance is

being operated near children.

• Do not use to cook food.

• This appliance is intended to be used only for supplemental

heat. Do not use it routinely as a primary heat source. Continuous operation could produce excessive humidity depending on construction characteristics and outdoor temperatures (below 20°F). Over time, this could cause condensation to form and damage wall structures and exterior paint.

• An unvented room heater having an input rating of more than

10,000 btu per hour shall not be installed in a bedroom or bathroom.

This appliance may be installed in an aftermarket, permanently located, manufactured (mobile) home, where not prohibited by local codes.

WARNING: If the area in which the heater may be operated is smaller than that defined as an unconfined space or if the building is of unusually tight construction, provide adequate combustion and ventilation air by one of the methods described in the National Fuel Gas code, ANSI Z223.1, section 5.3 or applicable local codes.

WARNING: Do not use a blower insert, heat exchanger insert or other accessory not approved for use with this heater.

WARNING: During manufacturing, fabricating and shipping, various components of this appliance are treated with certain oils, films or bonding agents. These chemicals are not harmful but may produce annoying smoke and smells as they are burned off during the initial operation of the appliance, possibly causing headaches and eye/lung irritation. This is a normal and temporary occurrence.

78586

Temco VF36RN/RNH/RP

WARNING: Do not allow fans to blow directly into the fireplace. Avoid any drafts that alter burner flame pattern.

WARNING: Any glass doors on an unvented room heater shall be opened when the appliance is in operation.

Provisions for Adequate

Combustion and Ventilation Air

Today's homes are built more energy efficient than ever. New materials, increased insulation and new construction methods help reduce heat loss in homes. Home owners weather strip and caulk around windows and doors to keep the cold air out and the warm air in. During heating months, home owners want their homes as air tight as possible.

While it is good to make your home energy efficient, you need fresh air. All fuel-burning appliances need fresh air for proper combustion.

Supplying Adequate Ventilation

This appliance must be installed in an unconfined space. The National Fuel Gas Code's definitions for confined and unconfined spaces are as shown below.

The National Fuel Gas Code, ANSI Z223.1 defines a confined space as a space whose volume is less than 50 cubic feet per 1,000 Btu per hour (4.8 m3 per kw) of the aggregate input rating of all appliances installed in that space and an unconfined space as a space whose volume is not less than 50 cubic feet per 1,000 Btu per hour (4.8 m per kw) of the aggregate input rating of all appliances installed in that space. Rooms communicating directly with the space in which the appliances are installed, through openings not furnished with doors, are considered a part of the unconfined space.

Determining if You Have a

Confined or Unconfined Space

If additional ventilation from adjoining room(s) is supplied with grilles or doorless openings, add the volume of these rooms to compute the total volume of the applicable space.

2. Divide the space volume by 50 cubic feet to determine the maximum BTU/Hr the space can support. ________(volume of space) ÷ 50 cu. ft. = (Maximum BTU/Hr the space can support.

Example:

= 100 or 100,000 (maximum BTU/Hr the space can support)

3. Add the BTU/Hr of all gas burning appliances in the space.

Example:

*Do not include direct-vent gas appliances. Direct-vent draws combustion air from the outdoors and vents to the outdoors.

4. Compare the maximum BTU/Hr the space can support with the actual amount of BTU/Hr used. _______ BTU/Hr (maximum the space can support) _______ BTU/Hr (actual amount of BTU/Hr used)

Example:

support) 89,000 BTU/Hr (actual amount of BTU/Hr used)

The space in the above example is an unconfined space because the actual BTU/Hr used is less than the maximum BTU/Hr the space can support. If the space had been confined, your options would be as follows:

A. Rework worksheet, adding the space of an adjoining

room. If the extra space provides an unconfined space, remove door to adjoining room or add ventilation grills between rooms. See Ventilation Air From Inside Building.

B. Install a lower BTU/Hr heater, if lower BTU/Hr size

makes room unconfined.

5,000 cu. ft. (volume of space) ÷ 50 cu. ft.

Gas range ________________ BTU/Hr Vented gas heater __________ BTU/Hr Gas fireplace logs __________ BTU/Hr Other gas appliances* + _____ BTU/Hr Total = _____ BTU/Hr

Gas range 60,000 BTU/Hr

Vent-free logs + 29,000 BTU/Hr

Total = 89,000 BTU/Hr

100,000 BTU/Hr (maximum the space can

Use this worksheet to determine if you have a confined or unconfined space.

Space: Includes the room in which you will install heater plus any adjoining rooms with doorless passageways or ventilation grills between the rooms.

1. Determine the volume of the space (length x width x height). Length x Width x Height = _____cu. ft. (volume of space) Example: Space size 25’ (length) x 25’ (width) x 8’ (ceiling height) = 5,000 cu. ft. (volume of space)

Converting Confined Space

to Unconfined Space

Additional volume to convert a confined to an unconfined space could come from an adjoining space. When using an adjoining space, you can provide two permanent openings: one within 12" of the ceiling and one within 12" of the floor on the wall connecting the two spaces (see options 1 and 3, Figure 1), or remove the door into the adjoining room.

78586

Temco VF36RN/RNH/RP

Ventilation air from outdoors for unusually tight construction. WARNING: If the area in which the heater may be operated is smaller than that defined as an unconfined space or if the building is of unusually tight construction, provide adequate combustion and ventilation air by one of the methods described in the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Section 5.3 or applicable local codes.

Unusually tight construction is defined as construc-

tion where: a. walls and ceilings exposed to the outside atmo-

sphere have a continuous water vapor retarder with a rating of one perm (6x10.

-11

kg per pa-sec-m2) or

less with openings gasketed or sealed and

b. weather stripping has been added on openable

windows and doors.

c. caulking or sealants are applied to areas such as

joints around window and door frames, between sole plates and floors, between wall-ceiling joints, between wall panels, at penetrations for plumbing, electrical and gas lines and at other openings.

If your home meets all of the three criteria above, you must provide additional fresh air.

You may provide two permanent openings: one within 12" of the ceiling and one within 12" of the floor. Connect these items directly to the outdoors or spaces

open to the outdoors. These spaces include attics and crawl spaces. Follow the National Fuel Gas Code NFPA 54/ANSI Z223.1, Section 5.3, Air for Combustion and Ventilation for required size of ventilation grills or ducts.

IMPORTANT: Do not provide openings for inlet or outlet air into attic if attic has a thermostat-controlled power vent. Heated air entering the attic will activate the power vent.

You may provide two permanent openings: one within 12" of the ceiling and one within 12" of the floor. Connect these items directly to the outdoors or spaces open to the outdoors. These spaces include attics and crawl spaces. Follow the National Fuel Gas Code NFPA 54/ANSI Z223.1, Section 5.3, Air for Combustion and Ventilation for required size of ventilation grills or ducts.

WARNING: The BL-3 blower kit is equipped with a three prong (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three prong receptacle.

WARNING: Air openings that provide fresh air from an adjoining unconfined space shall not be blocked or obstructed in any way. Installation of unit should allow a minimum of 2” clearance from any part of the heater to any of the ventilation openings.

OPTION 1 Vents to Adjoining Room

Fig. 1 Ventilation options for confined spaces.

78586

OPTION 3 Vents to Adjoining Room

OPTION 2 Remove Door to Adjoining Room

12”

VO370-2

Temco VF36RN/RNH/RP

35³⁄₈"

Fireplace Dimensions

Rough Opening Depth

14¹⁄₂"

Rough Opening Width 36"

21¹⁄₈"

1/2"

35³⁄₈"

50"

1/2" Gas Connection

Left Side Only

Fig. 2 VF36 specifications and framing.

3⁷⁄₈"

6⁷⁄₈"

14¹⁄₂"

1/2” Clearance to Combustibles not Required at This Point

Rough Opening Height

32¹⁄₈"

33¹⁄₂"

36"

17"

1¹⁄₂"

31¹⁄₈"

78603

78586

Temco VF36RN/RNH/RP

Installation & Operating Instructions

Locating the Fireplace

Figure 3 shows some of the many ways your fireplace may be installed. Consider the traffic pattern in your room and the location of doors and windows. Moving air from ceiling fans, open doors and hot air grilles may cause the flames to soot. If a disturbance is found that affects the flames, it must be eliminated by turning off the ceiling fan, closing the door or closing/moving the hot air register. A corner location may be best where space is limited.

Your fireplace weighs no more than some of your fine furniture. If the fireplace is located near a load bearing wall, additional supports to the foundation will not be necessary.

NOTE: Heavy facings such as brick, stone, etc., may require additional foundation support.

NOTE: Although this unit may be installed on combustible surfaces, it must not be installed on carpet or vinyl.

The clearances to sidewalls and ceiling that are shown in Figures 5, 6a, 6b and 7 must be considered when choosing the location for the fireplace.

Fan Kit - Optional

(Part #BL-3) For installation of the optional fan, please refer to the

instructions included in the fan kit.

Electrical Services

All optional fan kits are equipped with a 120V, 60Hz blower, less than 12 amps.

A standard 120V outlet is needed near the fireplace in order to plug in the optional blower accessory. The blower is equipped with a standard 3-prong electrical plug.

Installation Tip: The blower will be easier to install if done at time of appliance installation.

Partial Room

Corner

Full Room Projection

Fig. 3 Locating the fireplace.

Projection

Flush

Room Divider

LU584-1

Gas Line

The gas line must be installed by a licensed gas line installer before framing in the fireplace.

Drafts

Do not locate the fireplace in high traffic areas or areas exposed to high drafts and winds. Locate the fireplace away from furniture and draperies.

Blower

Fig. 4 BL-3 blower installation

Speed Control

T142

Framing Clearances

The fireplace may be placed directly on a combustible floor, against a combustible wall at marked clearances or on a raised wooden platform.

If the fireplace is to be installed on a raised wooden platform, the platform must be a continuous level surface.

The fireplace must be secured in place so it cannot shift positions. The nailing flanges on the sides of the firebox make securing it to the framing easy. They were designed to allow the installation of 1/2" wallboard or plywood flush with the face of the fireplace.

Only the header (Fig. 5) may rest on the standoffs on top of the firebox. Framing must rest on top of standoffs.

78586

Temco VF36RN/RNH/RP

10"

12"

13"

17¹⁄₄"

21¹⁄₂"

26"

Min. 36"

From Top

of Unit to

Ceiling

When the fireplace is installed over carpeting, vinyl tile or any combustible material other than wood flooring, it must be installed on a metal or wood panel extending its full width and depth. Alternatively - the carpeting, vinyl tile, etc., may be removed from beneath the fireplace before installing.

Combustible materials must not be installed over or touch the black front surface of the fireplace.

21¹⁄₈"

14¹⁄₂"

36"

2” Min. Clearance to Mantel Leg

1/2"

1/2” Clearance not Required at This Point

14¹⁄₂" Min.

of 20¹⁄₄” above the fireplace opening. Required clearance varies with the amount of projection. (Fig. 6a) The mantel profile must fall within the crosssection shown in Figure 6a (with standard canopy) or Figure 6b (if a UC-2 Universal Canopy is used).

b. With UC-2 Universal Canopy: The minimum

distance above the fireplace opening to combustible material projecting 1” (tile moldings, breast boards, etc.) is 9”. Combustible material projecting 6” (a mantel shelf, for example) requires a minimum clearance of 12” above the fireplace opening. Required clearance varies with the amount of projection. (Fig. 6b)

c. Heat resistant material: Any heat resistant

material suitable for a continuos operating temperature of 120°C (248°F) must cover the wall surface directly above the fireplace opening and extend the full width of the fireplace opening for a distance of 9” above the opening of the fireplace. (Figs. 6a and 6b)

d. Refer to Figure 7 for mantel leg clearances.

36"

32¹⁄₈"

36¹⁄₈"

T143

Fig. 5 VF36 framing dimensions.

Clearances

To ensure a safe installation, the following instructions must be carefully observed.

1. Sidewall Clearances: Clearances from the side of the fireplace opening to any combustible wall should not be less than 2”.

2. Ceiling Clearances: The ceiling height should not be less than 36” from the top of the fireplace (See Figure 6a).

Mantel Clearances:

a. Mantel profile: The minimum distance above the

fireplace opening to combustible material projecting 1” (tile moldings, breast boards, etc.) is 13”. Combustible material projecting 6” (a mantel shelf, for example) requires a minimum clearance

NOTE: Due to the continuous heat output of a Vent Free Fireplace, occasional discoloration or peeling of paint and varnish materials may be noticed directly above the fireplace opening.

Ceiling Combustibles Allowed in Shaded Area

Combustible Header

Standoff Spacer

Fireplace Top Face

Fig. 6a Minimum mantel clearance with standard canopy.

Combustible Facewall

Noncombustible to Top of Standoff

Canopy

Top of Screen Frame

Top of Fireplace Opening

T144

78586

10"

Heat Resistant Material

Universal Canopy

Fig. 6b Minimum clearances with universal canopy.

Combustible Mantel

Noncombustible

Facing

Fireplace

Mantel Leg

T108

Fig. 7 Side clearance and projection.

Opening

2” Min. Clearance

22"

12"

Min.

Mantel Leg

Max. Projection 7”

Min.

18"

Min.

T107

This list of specific instructions will help you make certain that every installation operation is done correctly. Complete the installation steps in the sequence shown.

LOCAL BUILDING CODES SHOULD BE CONSULTED IN ALL CASES AS TO THE PARTICULAR REQUIREMENTS CONCERNING THE INSTALLATION OF FACTORY BUILT VENT FREE FIREPLACES.

Select the location for the fireplace by taking into consideration the factors previously outlined in the Planning Ahead section of this manual.

Step 1: Framing the Firebox

The entire fireplace can be elevated above the floor to achieve a raised hearth effect. This can be done by adding a small platform to achieve the desired height.

STOP! INSTALL CANOPY AT THIS TIME BY LOOSENING THE SCREWS LOCATED AT THE TOP FRONT OF THE FIREPLACE. NEXT, SLIDE THE SLOTTED FLANGE OF THE CANOPY UNDER THE LOOSENED SCREWS, THEN RETIGHTEN THE SCREWS TO SECURE THE CANOPY.

Temco VF36RN/RNH/RP

Step 2: Install the Firebox

Install the firebox into the framed opening by setting it directly in front of the opening and sliding it into the proper position.

Step 3: Level the Firebox

Check the level of the firebox on the top edge of the fireplace face. Shim if necessary.

Step 4: Secure the Firebox

Secure the fireplace to the framing. The nailing flanges on the firebox will make securing the firebox to the frame quick and easy. Use appropriate size nails or screws to secure the firebox.

Step 5: Removing the Front Screen Panel

To remove the screen panel, first open the control panel door. Using a 1/4" nut driver, remove the two screws that secure the screen panel to the front of the fireplace, (Refer to Figure 8 for the location). Carefully pull the bottom of the screen panel out toward you, then pull the panel down until the two pins at the top of the screen panel clears the holes in the top of the fireplace.

Reverse the above operation to reinstall the screen panel.

WARNING: The front screen on the fixed screen models must be installed before the fireplace is put into operation.

Pins Securing Top of Screen Panel

Screws Securing Bottom of

T145

Fig. 8 To remove screen panel, remove two screws securing screen, then pull panel down until top pins clear holes in top of fireplace.

Screen Panel (Control Panel Door is Open)

78586

Temco VF36RN/RNH/RP

Gas Connection

Gas Specifications

BTU/Hr

Model Fuel Hi Low

VF36RN Natural 29,000 18,000 VF36RP LP/Propane 29,000 23,000

VF36RNH Natural 29,000 18,000

Check Gas Type. Use only the gas type indicated on the heater's rating plate. If the gas type indicated on the plate is not your type of gas supply, DO NOT INSTALL. Contact your dealer for proper model.

Gas Piping. The gas supply line must be of an adequate size to handle the BTU/HR requirements and length of the run for the unit being installed.

Determine the minimum pipe size from the piping size chart on Page 10. The normal gas connection is 1/2" NPT made at the center of the unit.

WARNING

DANGER OF PROPERTY DAMAGE,

BODILY INJURY OR DEATH.

Make sure the heater is equipped to operate on the type of gas available. Models designated as natural gas are to be used with natural gas only. Heaters designated for use with liquified petroleum (l.p.) gas have orifices sized for commercially pure propane gas. They cannot be used with butane or a mixture of butane and propane.

Always use an external regulator for all LP appliances to reduce the supply tank pressure to a maximum of 13" w.c. This is in addition to the regulator fitted to the heater.

WARNING: Connecting directly to an unregulated LP tank can cause an explosion.

All piping must comply with local codes and ordinances or with the National Fuel Gas Code (ANSI Z223.1), whichever applies. Installation of a sediment trap is a requirement of this code.

Gas Connection. If installation is for L.P. gas, have L.P. installer use two-stage regulation and make all connections from the storage tank to the heater. Refer to the National Fuel Gas Code for the proper supply tank size with the Btu's/Hr requirements. If this is the ONLY gas appliance, we recommend a minimum 200 pound cylinder with a fill gauge. Use of a 100 pound cylinder is not recommended. Other household gas appliances may require the tank size to be larger. Do not operate the vent free fireplace if the fuel level in the propane tank is below 1/4 full.

Use pipe wrenches when making the connection to the valve to prevent turning or damage to gas valve.

WARNING

DANGER OF PROPERTY DAMAGE,

BODILY INJURY OR DEATH. Never use a match or open flame to test for leaks. Never exceed specified pressures for testing. High pressures may damage the appliance regulator which would require replacement. Liquified petroleum (LP) is heavier than air and it will settle in any low area, including open depressions and it will remain there unless area is ventilatedNever attempt start-up of unit before thoroughly ventilating area.

Connection between the manual shut-off valve and the gas valve can be made with a CSA design certified flexible connector if allowed by local codes. A drip leg is still required. Tighten all joints securely.

NOTE: If the manual gas shut-off valve is located in the control compartment, the two screws that hold the control cover in place during shipping must be left out so the control cover is removable by hand.

Testing the Gas Piping. Test all piping for leaks. When checking gas piping to the heater with gas pressure less than 1/2 psi, shut off manual gas valve for the heater.

If gas piping is to be checked with the pressure at or above 1/2 psi, the heater and manual shut off valve must be disconnected during testing to prevent damage to the regulator on the unit, (see WARNING).

To ensure that the gas lines and connections do not have any leaks, a pressure test should be performed.

Only a qualified installer should perform the pressure test to ensure that the unit is not damaged by high pressures!

gent) to each joint. Bubbles forming indicate a leak. Correct even the slightest leak at once.

If you connect natural gas to an LP gas unit, you may be unable to ignite the pilot. If the pilot does ignite, the front burner flame on the low setting will be bright blue but only 1/4" to 1/2" long and most likely lifting off the burner ports. If this is the case, turn the unit off immediately.

If you connect LP gas to a natural gas unit, the front burner flame on the low setting will be about 6" - 8" long. On the medium and high setting, the front burner flames will be bright yellow and about 10" in length. Turn the unit off immediately! If the unit is allowed to run in this condition, substantial amounts of soot will be generated and emitted into the house.

Apply soapsuds (or a liquid deter-

High Altitude Installation

CSA listed vent free gas fireplaces are tested and approved for elevations from 0 to 2,000 feet (0-610m) with no change to the rated input.

78586

Temco VF36RN/RNH/RP

When installing this fireplace at an elevation above 2,000 feet, it may be necessary to decrease the input rating by changing the existing burner orifice to a smaller size. Input should be reduced four percent (4%) for each 1,000 feet above sea level, unless the heating value of the gas has been reduced, in which case this general rule will not apply. To identify the proper orifice size, check with the local gas utility.

Consult your local gas utility for assistance in determining the proper orifice for your location.

Gas Pressure Check

The gas inlet pressure specified in Table 1 is the pressure where the field-installed gas line connects to the gas control. This is measured at the inlet test port on the gas valve in the appliance. Ensure that pressure is as shown in Table 1.

The manifold pressure is controlled by a regulator built into the gas control and should be checked at the pressure test points located between the flame adjustment knob and the control knob at the front of the

valve. The pressure connections accept 1/4” I.D. hose or tubing.

The pressure should be checked with the appliance burning on high (highest setting) and all other gas appliances turned on. One must then read the manometer and if pressures are not as specified in Table 1, then the inlet pressure must be adjusted.

After measuring the pressure, tighten the screw in the pressure test port and check for leaks. Replace the

control box cover and the two screws.

Table 1

Gas Inlet Pressure Natural Propane

Max. 14.0” w.c. 14.0” w.c.

Normal 7.0” w.c. 11.0” w.c.

Min.* 4.5” w.c. 11.0” w.c.

Regulator Pressure 3.5” w.c. 10.0” w.c.

*Minimum inlet supply pressure for the purpose of input adjustment.

CAUTION: If the appliance’s operating pressures are not checked and adjusted, improper combustion may result in soot being produced.

Gas Line Pipe Sizing

NOTE: To determine the size of the branch gas line from the main gas line to the fireplace, enter the tables below (for iron pipe or copper tubing) using the distance from the gas meter or second stage regulator to the furthest appliance on the gas system. Select a pipe or tube diameter which has enough capacity to meet the maximum input requirement of the fireplace. Regardless, do not use less than 1/2" diameter for the branch line. For any distances required longer than shown in these tables, refer to the National Fuel Gas Code.

NOTE: There may be a local gas utility requirement specifying a minimum diameter for gas piping. All units require a 1/2 inch pipe connection at the gas valve.

Cubic Feet per Hour based on 0.3" w.c. Pressure Drop

Specific Gravity for Natural Gas - 0.6 (1000 BTU/Cubic Foot)

Specific Gravity for Propane Gas - 1.6 (2550 BTU/Cubic Foot)

Length Nominal Inches for Iron Pipe Sizes (1,000s BTU/hr)

of 1/2” D 3/4” D 1” D 1¹⁄₄” D 1¹⁄₂” D

Pipe Natural Propane Natural Propane Natural Propane Natural Propane Natural Propane

20’ 92 143 190 296 350 546 730 1135 1100 1711 30’ 73 115 152 237 285 444 590 918 890 1385 40’ 63 97 130 202 245 380 500 778 760 1183 50’ 56 87 115 179 215 334 440 683 670 1043 60’ 50 79 105 163 196 304 400 622 610 949 70’ 46 71 96 151 180 280 370 576 560 872 90’ 40 61 84 130 160 250 320 497 490 763

100’ 38 59 79 122 150 235 305 474 460 717

CAPACITY OF PIPING

Outside Diameter Copper Tubing, Type L (1,000s BTU/hr)

Tubing Length 1/2” 5/8” 3/4” 7/8”

Feet 0.43 0.545 0.666 0.785

10 110 206 348 536 20 76 141 239 368 30 61 114 192 296 40 52 97 164 256 50 46 86 146 224 60 42 78 132 203 80 36 67 113 174

100 32 59 100 154

WARNING: Use only internally tinned copper tubing. If correct copper tubing is not used, tubing can deteriorate and develop gas leaks.

78586

Temco VF36RN/RNH/RP

Log Installation

With gloves, remove each of the logs by gripping at either end while avoiding any undue pressure. The logs are made from light-weight ceramic fiber and may break if undue force is applied.

The carton contains the following items: front log and rear log, 2 top twigs, a bag of volcanic ash and a bag embers.

Log Assembly

(Refer to Figures 9, 10 and 11)

1. Rear log should be installed onto rear log supports. Match slots on rear of log with the vertical log bracket tabs. (Fig. 9)

2. Place the bottom edge of the large front log between the two tabs located in the log support channel which centers the log left to right. (Fig. 9)

3. The two top twigs can then be placed in their designated positions located with pins on back logs and grooves on the front log.

4. Lava rock from the bag provided should be placed on the hearth pan area to suit individual appearance preferences. DO NOT place volcanic ash on burner, pilot or logs.

5. Platinum embers are to be placed only on top of the front burner port area. Equally space embers one layer thick. Do not pile ember material over one

layer thick as this does not enhance the “ember” appearance or improve the log set performance.

(Fig. 11)

6. Flames must not impinge (touch) on logs.

WARNING: Do not use more embers than those supplied with your unit. Do not use embers other than genuine “Platinum Embers” supplied by Temco Fireplace Products, Part No. 78037.

When you have completed these steps, compare log positions with Figure 10. The logs must be positioned as illustrated.

CAUTION: Proper location is critical. When positioning the log set, make sure the logs do not interfere with the sides of the fireplace before securing the chassis.

Front Log Locator Tabs (Left to Right)

T131

Fig. 9 Match slots on rear of log with vertical log bracket tabs.

Rear Log

Left Twig

Fig. 10 Correct log placement.

Rear Log Supports

Right Twig

Front Log

TL106

Platinum Embers

Fig. 11 Platinum ember placement.

WARNING: Failure to position the parts in accordance with this diagram or failure to use only parts specifically approved with this heater may result in property damage or personal injury.

TL107

78586

Temco VF36RN/RNH/RP

Installation of Optional Wireless Remote

Two remote control kits are offered. The standard ON/ OFF model is a WRD-1 and the thermostatic model is a WRST-K.

The remote receiver should be placed in the lower compartment of the fireplace behind the control cover panel.

There will be a battery terminal and two wire leads. The remote receiver does not need to be secured to the fireplace but can be placed on the floor under hearth pan assembly.

The enclosed jumper wires can be attached to the receiver wires by joining the female connectors from the receiver.

All connections should be made as shown in the remote kit instructions. The jumper wire should be routed behind the cover plate to the valve. The wires from your receiver can be connected to the two outer terminals on the valve, making sure it is the two outer terminals and not the center one. (Figs. 12 and 13) You may now refer to the lighting instructions for use. The log set should not be modified to accept any other type of remote control as no guarantee may be made regarding proper function. Refer to manufacturer’s instructions for battery replacement.

Installation of Millivolt Wall Switch

To install your millivolt wall switch, an approved wall box should be installed in a location suitable to you. The thermostat wire should be routed from the wall box to the log set and should be routed underneath the log set and pulled up to the valve’s wiring terminal as shown in Figure 15.

The two wires, letter “A”, should not be removed or changed. Remove switch wires, Letter B. The two female ends of your wire can be connected to the two outer connections just below the screw terminals as shown in Figures 12 and 15.

Now the wall switch can be wired as shown in Figure

14. The wires can be connected to either poles as they carry only millivolt current. No ground is used at the wall switch. See the lighting instructions on Page 14. Wall switch must be for millivolt operation.

Do not connect 120 Volts to wall switch.

Recommended Maximum Lead Length (Double

Wire) When Using Wall Switch or Thermostat

Wire Size Maximum Length

14 ga. 50’ 16 ga. 32’ 18 ga. 20’ 20 ga. 15’ 22 ga. 10’

NOTE: Must be stranded wire.

Fig. 12 Connect wires from receiver to terminals on valve.

A. Existing valve wiring (Do not tamper with) B. Remote receiver wires (red or white on either side)

Fig. 13 Attach receiver wires to outer two terminals on valve.

78586

T147

T149

Fig. 14 Optional wiring to wall switch.

A Thermopile (Do not remove) B Switch (OFF/ON) C Wires from receiver (red &

white) or wires from millivolt

wall

Fig. 15 Control valve terminal block.

T114

Temco VF36RN/RNH/RP

Optional Gas Shutoff Valve

Valve Control ON/OFF/PILOT

NOTE: Optional Remote Control Receiver May be Placed on Floor Behind Cover Panel

HI/LO Flame Adjustment

ON/OFF Switch

Piezo

Blower Speed Control (Optional)

Fig. 16 Fireplace control panel.

For Your Safety, Read Before Lighting

WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.

A. This appliance has a pilot which must be lighted by hand.

When lighting the pilot, follow these instructions exactly.

B. BEFORE OPERATION smell all around the appliance area

for gas. Be sure to smell next to the floor because some gas is heavier than air and will settle on the floor.

WHAT TO DO IF YOU SMELL GAS:

• Do not try to light any appliance.

• Do not touch any electrical switch; do not use any tele-

phone in your building.

• Immediately call your gas supplier from a neighbor's

telephone.

• Follow the gas supplier's instructions.

• If you cannot reach your gas supplier, call the fire depart-

ment.

C. Use only your hand to push in or turn the gas control knob.

Never use tools. If the knob will not push in or turn by hand, don't try to repair it. Call a qualified service technician. Force or attempted repair may cause a fire or an explosion.

D. Do not use this appliance if any part of it has been under

water. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system or gas control which has been under water.

E. Be sure both the receiver and the remote have had a 9 volt

battery installed in each.

T150

Lighting Instructions

1. STOP! Read the safety information above before proceed- ing.

2. Refer to Figure 17. To turn off the gas supply, depress the knob slightly and turn clockwise to the OFF position.

3. Wait five (5) minutes to clear out

Fig. 17 Fig. 19 Fig. 21

PILOT

OFF

any gas. Then smell for gas, including near the floor. If you smell gas, STOP! Follow “B” in the safety information above. If you don’t smell gas, go to the

Fig. 18

next step.

4. Refer to Figure 18. Locate the pilot. It is at the right side of the burner.

5. Refer to Figure 19. Push in the control knob and turn counterclockwise

to the PILOT position. Hold the control

knob in for a few seconds.

6. While still holding in the control knob, press the ignitor pushbutton several times. This will cause a spark at the pilot which will ignite the pilot gas. (Fig. 20)

To Turn OFF Gas to Appliance

7. Hold the control knob for 60 seconds to prevent the flame failure detector from shutting off the gas while its probe is warming up.

8. Release the control knob.

• If the knob does not pop up when

released, stop and immediately call

PILOT

your service technician.

• If the pilot will not stay lit after

PILOT

OFF

several tries, turn the gas control knob to OFF and call your service

technician or gas supplier.

9. Refer to Figure 21. When the

pilot remains lit, turn the control knob counterclockwise

Fig. 20

the ON position.

10.Lighting Instructions for Millivolt

Wall Switch. After the pilot is lit and the control knob is released,

Piezo

the wall switch can be switched to turn the unit “ON” or switched to turn it “OFF”. Refer to Page 13 for wiring.

Depress the control knob slightly and turn it clockwise to the OFF position. Refer to Figure 17.

78586

Match Lighting

If the pilot cannot be ignited with the piezo, it can be manually lit with the use of a match and lighter rod.

1. Place the match in the holder and light. With the right hand, depress and turn the control knob counterclockwise

to the PILOT position. Hold in for 20 seconds.

2. Take the lighter rod and lighted match and ignite the pilot.

3. Continue to hold the control knob for an additional 20 seconds to ensure pilot is maintained.

4. Proceed with Step 8 in the Lighting Instructions on Page

14.

Fig. 24 Air shutter settings.

Temco VF36RN/RNH/RP

Air Shutter Settings

Model A

VF36MN Closed

T134

VF36MP 0.375”

Flame Check

A periodic visual check of the flames should be made. The pilot flame should always be present when the appliance is in operation. (Fig. 22)

In normal operation (at full rate for approximately 15 minutes) the following flame appearance should be observed:

The flame should burn blue with some yellow flames visible. Height of the blue flame should be approximately 1” on high. The yellow flames should extend 6 to 8 inches above the large front log.

Typical flame shape seen in Figure 23. NOTE: For your safety, the appliance is equipped with

an oxygen depletion system. The system senses the oxygen in the atmosphere and switches off the gas supply in case the level of oxygen falls below a safe level. It must not be altered in any way.

Natural Gas

1¹⁄₂"

Fig. 22 Pilot flame position and location.

1¹⁄₂"

Propane

T140

Finishing the Fireplace

There are a wide variety of finishing materials available for your fireplace, from formal wall treatments with marble and mantels to rustic wood paneling, stone or brick.

It is important that the black face of the fireplace not be covered with any type of combustible material.

Noncombustible facing materials such as marble, brick or ceramic tile may overlap the black face of the fireplace up to the opening on either side of the fireplace. Seal all joints between the black fireplace face and the wall covering with a heat resistant material such as rock wool insulation or mortar. Be sure to use high temperature adhesive or mortar when anchoring brick, stone or tile to the face of the fireplace. Check to see whether man-made brick and stone are made of noncombustible materials before using them on the face of the fireplace. Some of these products contain combustible materials. Combustible wall coverings such a paneling or wallboard may not overlap the black face of the fireplace. The space between the wall covering and the fireplace should be sealed with a heat resistant material such as rock wool insulation or mortar.

NOTE: An “L” shaped steel lintel must be installed across the top of the firebox opening where facing materials such as brick or stone are used on the face of the firebox. It acts as a support/firestop. It should be attached to the face of the fireplace with screws and sealed to the fireplace with a heat resistant sealer. Refer to Figure 25 for finishing options.

Fig. 23 Correct burner flame appearance.

78586

WARNING: These vent free fireplaces are not to be used with glass doors.

TL108

Temco VF36RN/RNH/RP

Wallboard with Marble, Slate or Tile Facing

Finished Wall

Noncombustible Decorative Covering

Wallboard with Facing and Mantel

Fig. 25 Finishing options.

Stud Header

Must be enclosed with noncombustible material

Noncombustible Decorative Covering

Finished Wall Brick or

Stone Facing

Finished Wall

Brick or Stone Facing

Stud

Header

Steel Lintel

Stud

Header

Must be enclosed with noncombustible material

T146

Managing Heat Output

The heat output from the appliance can be controlled by the position of the flue damper on vented fireplaces. The damper setting should be fully closed for maximum heat output, partially closed for less heat output and fully open for minimum heat output.

The appliance may be used in a working solid fuel burning fireplace with the fuel damper closed only if unvented appliances are permitted by local state and city codes. It may also be operated as a decorative appliance whose prime function lies in the aesthetic effect of the flames when installed in a solid fuel burning fireplace with the flue damper open. If unvented heaters are not permitted, the fireplace vent damper must be locked at a minimum free (vent) area of 15 sq. ins.

Whenever the appliance is operated with the fireplace's flue damper closed, glass doors - if present - must be open and the outside air damper and the ash dump (if the fireplace is equipped with either one) must be closed.

The heat output from the appliance when operated as a vent-free heater may be controlled by adjusting the main gas valve. Reference lighting instructions on Page 14 and chart on Page 10 which shows inputs at all settings.

The main gas valve may be adjusted anywhere between high and low to give the desired combination of flame aesthetics and heat output.

78586

Maintenance

Temco VF36RN/RNH/RP

Cleaning

CAUTION: Before cleaning or moving logs or other

parts of the unit, be sure to read the section on important safeguards.

Cleaning should be done before the logs are used each year and after long periods of non-use. Professional servicing is recommended.

All cleaning should be carried out when the appliance is cold.

Only limited cleaning will be required under normal use. Dusting the front grate or the control knob panel may be required occasionally. Do not use any cleaning fluids to clean the logs or any other part of the appliance.

If the flames show any unusual shapes or behavior, or if the burner(s) fail to ignite properly, then the burner holes may require cleaning. If this occurs contact your nearest dealer to get the appliance serviced.

Alternatively, the appliance can be cleaned by removing the logs. Handle the logs gently so as not to damage them. Always lift each log by holding it carefully at each end.

After the logs are removed allowing access to the burner area, use the brush attachment from your vacuum cleaner to carefully remove dust and loose particles from the base, logs and from around the burner. Gloves are recommended when handling the logs. Use extreme caution when cleaning around the pilot (ODS). The pilot should not be moved or altered from the original factory setting (Pilot to burner preset location). To clean the pilot, take an Air Duster can (computer cleaner compressed air) and insert the nozzle into the primary air inlet. Shoot a short blast of air into the inlet to clear dust. (Fig. 26) The burner should not be removed or taken out of it’s locked and secure position (proper location of burners are critical).

Logs must be carefully replaced in their orignial, preset positions (Fig. 27), to prevent the rear flames from touching any log. No other arrangement is permitted. Incorrect placement can diminish combustion efficiency and cause sooting.

A qualified gas professional should periodically check and clean the orifices and burners per National Fuel Gas Code, Appendix B.

Lack of proper maintenance may void warranty.

Gas Outlet

Fig. 26 Use a short burst of air into the primary air inlet to clean pilot.

Rear Log

Left Twig

Fig. 27 Correct log placement.

Right Twig

Front Log

Primary Air Inlet

T141

TL106

78586

Temco VF36RN/RNH/RP

Troubleshooting

With proper installation and maintenance, your new gas fireplace should provide years of trouble-free service. If you do experience a problem, refer to the trouble shooting guide below. This guide will assist you or a qualified service person

in the diagnosis of problems and the corrective action to be taken. Any safety screen or guard removed for servicing an appliance must be replaced prior to operating the appliance. Use only a qualified service person when making repairs.

Symptom Possible Cause Corrective Action

1. Pilot will not light Air in gas line Purge gas lines and repeat ignition operation Low gas pressure Check gas pressure Gas supply turned off Turn on gas supply Blockage in gas line Check gas passage way ODS pilot orifice is clogged Call a qualified service person Control knob not in pilot position Turn control knob to pilot position Control knob not pressed in while Press in control knob while in pilot position

in pilot position

Ignitor did not spark Ignitor electrode positioned wrong Correct electrode position

Ignitor electrode broken Replace assembly Ignitor cable pinched or broken Free ignitor cable, if damaged replace it Ignitor cable not connected to ignitor Connect cable to ignitor

2. Pilot will not stay lit Partially clogged ODS pilot orifice Contact qualified service person or your gas company Corrosion of thermocouple contact Clean thermocouple contact Bad gas valve Replace gas valve Control knob not pressed in long After pilot lights, keep control knob pressed in for

enough 60 seconds Thermocouple connection loose at Tighten connection finger tight + 1/4 turn or replace

gas control or damaged thermocouple or replace ODS pilot assembly Pilot flame not touching thermocouple Contact a qualified service person

3. Main burner will not light Low gas supply pressure Contact your gas supplier Burner orifice clogged Clean burner orifice Control knob not in ON position Turn control knob to ON position

4. Heater shuts off on ODS Not enough fresh air is available Open window Low gas pressure Contact your gas supplier ODS pilot partially lit Contact a qualified service person

5. Sooting Low gas pressure Contact your gas company Clogged air intake/orifice Contact service agent for cleaning Flame impingement Insure no air currents are around appliance Logs misplaced Refer to installation instructions for proper log

placement

Repair and replacement work should only be done by a qualified service technician.

Servicing

Always shut off the gas supply and make sure the appliance is cool before beginning any service operation.

Always check for gas leaks after servicing.

78586

Repair Parts

Temco VF36RN/RNH/RP

Always include the correct name, part number, model number, control type and serial number of the appliance when ordering service parts. Refer to the parts list below.

Use manufacturer's authorized parts only. If you desire to communicate with the factory, write to Customer Service at:

Description VF36RN VF36RP VF36RNH

Grate Assembly 78442 78442 78445 Side Deflector 78443 78443 78443 Support Channel 78439 78439 78439 Air Scoop 78445 78445 78445 Valve - Natural 78126 - 78126 Valve - LP/Propane - 78127 Burner - Natural 78474 - 78474 Burner - LP/Propane - 78473 Pilot - Natural (OP) 78167 - Pilot - LP/Propane (OP) - 78169 Pilot - Natural - High Altitude - - 78216 Manifold Tube Split Nut 78449 78449 78449 Orifice #38 - Natural 78450 - 78450 Orifice #52 - LP/Propane - 78625 Tube, Flexible Gas Inlet 71598 71598 71598 Tube, Pilot 3/16” 71221 71221 71221 Ignitor, w/Nut (Piezo) 65180 65180 65180 Wire Assembly Rocker Switch 78596 78596 78596 Mini Rocker Switch PCOA049 PCOA049 PCOA049 Knob Extension On/Off (3”) 77958 77958 77958 Knob Extension Hi/Lo (3”) 77959 77959 77959 Embers, Platinum (Bag) 78037 78037 78037 Lava Gravel Assy 68688 68688 68688 Front Log 76895 76895 76895 Back Log 75317 75317 75317 Log, Right Twig 75318 75318 75318 Log, Left Twig 75319 75319 75319 Screen Panel Assy 78924 78924 78924

Temco Fireplace Products 410 Admiral Blvd. Mississauga, Ontario Canada L5T 2N6

78586

Temco VF36RN/RNH/RP

Limited Warranty

TEMCO Fireplace Products Vent-Free Gas Fireplaces

This warranty is limited to TEMCO Fireplace Products Vent-Free Gas Logs & Fireplaces (henceforth, Product) manufactured by TEMCO Fireplace Products (henceforth, TEMCO).

ONE YEAR WARRANTY

TEMCO warrants all components of the Product to be

free of defects in materials and workmanship for a period of one year from the date of installation, with the exception of the warranty on logs and ember base. If, by the sole determination of TEMCO, any component covered under this warranty is found to be defective, TEMCO will, at its option, repair or replace the defective component at no charge and will pay labor cost incurred as specified in the current TEMCO Labor Allowance Schedule, 71313. If TEMCO determines replacement or repair is not economically practical, TEMCO will, at its option, refund the purchase price of the Product. Date of installation and purchase price must be verified by acceptable proof of purchase prior to warranty action.

This warranty covers only parts and labor as provided above. In no case shall TEMCO be responsible for materials, components or construction which are not manufactured or supplied by TEMCO, or the labor necessary to install, repair or remove such materials, components or construction.

FIVE YEAR WARRANTY

TEMCO warrants the ceramic fiber and refractory compo-

nents and burners originally packed with the product to be free of defects in material and workmanship for a period of five (5) years from the date of installation, with the exception of breakage. If any ceramic components or refractory components are broken, such breakage must be reported as a Warranty Claim at the time of installation. Breakage claims arising after the initial installation will not be covered under any part of this warranty. Periodic maintenance must have been performed.

QUALIFICATIONS

For the above warranties to apply: The Product must be installed by a qualified installer;

strictly in accordance with TEMCO installation instructions, and in compliance with local codes and ordinances. The logs must be placed strictly in accor-

dance with the arrangement described in the installation instructions.

The Product must be operated and maintained according to the instructions furnished. Alteration of the Product

in any way is prohibited and voids any and all warranties. Removal of the data plate alters the Products and voids the warranty.

The installer must have completed the installation and Startup Checklist, a copy of which must be submitted along with proof of purchase, to obtain prior approval for warranty repair or replacement and to affect a warranty claim. The Checklist is found on Pages 20 and 21 of this manual.

The limited warranty applies only to the original owner of the Product or the original owner of the dwelling in which the Product was installed. Use of any parts other than genuine factory provided replacement parts shall void this warranty.

Limitations

TEMCO is not responsible for any incidental or conse-

quential damages caused by possible defects in the Product. The duration of any implied warranty with respect to the Product is limited to the duration of the foregoing warranties.

Some states and provinces do not allow exclusion of incidental or consequential damages or limits on the duration of implied warranties, so these limitations may not apply to you.

Warranty Fulfillment

Claims require specific agreement and consent from TEMCO Technical Services prior to performing any warranty repair or replacement. TEMCO reserves the right to investigate any and all warranty claims. The

appliance must not be removed prior to such investigation other than on direction from TEMCO.

Please provide the following information when communicating with TEMCO Technical Services, its Dealers or Distributors regarding service under this warranty.

Model Number: ____________________ Serial Number: _____________________ Date of Installation: ____/____/____ Purchased From: ___________________

TEMCO reserves the right to decide on the method of settlement (if any). This limited warranty is given in lieu of any other expressed or implied warranty, and supersedes all other TEMCO Product warranties.

78586

Temco VF36RN/RNH/RP

TEMCO FIREPLACE PRODUCTS GAS LOGS & FIREPLACES

INSTALLATION AND STARTUP CHECKLIST

Customer Copy

NOTE: TEMCO Fireplace Products gas logs and fireplaces require installation by a qualified gas appliance installer.

A copy of this checklist must be submitted, along with proof of purchase, when applying to Technical Services for prior written approval of warranty repair or replacement.

All Vent-Free Gas Fireplaces and Logs

Read and understand installation instructions before attempting installation. Assure that the model to be installed is of the CORRECT FUEL TYPE. Check markings on the shipping container (Model #’s

ending in “N” are natural gas products; models #’s ending in “P” are LP gas products.), tags on the burner assembly.

NOTES: REGULATORS ARE NOT FIELD-ADJUSTABLE. ANY ATTEMPT TO ADJUST VOIDS THIS WARRANTY. In order to ensure adequate combustion air, make sure that the model being installed has the appropriate heating

capacity for the unconfined space available. Allow a minimum of 50 cubic feet of unconfined space per 1000 BTU’s for all

gas appliances. Assure that gas line size is adequate for the model’s input rating (BTU’s per hour), the length of run from the meter or

second stage regulator to the farthest gas appliance, and other gas appliances on the system. A drip leg or sediment trap is required. LP models require a minimum tank size of 120 gallons water capacity and two stage regulation.

Assure that installation meets local codes and ordinances. Assure that there are no fans or blowers in the fireplace area. Check for leaks before lighting.

Using a manometer, verify proper gas pressure at the manifold with unit at maximum setting and other appliances operating.

inlet pressure: _______ (ins. wc) manifold pressure: ________ (ins. wc) Verify proper ignition of ODS and front and rear burners, as well as proper appearance of flames.

Verify that ceramic fiber and refractory components are properly positioned and secure. (Rear burner must not contact logs.)

Verify adequate clearance to mantels and other combustibles. Demonstrate correct operation of the product to the consumer. NOTE: LP models must not be operated if fuel tank is less

than 1/4 full. Observe the consumer operating the product properly. Explain and demonstrate proper periodic maintenance. Explain that operation with logs positioned other than as described in the manual voids the warranty and will cause poor

combustion and sooting. Verify the consumer’s understanding that warranty service work that is not pre-approved by the manufacturer’s Technical

Service Department (other than routine maintenance) may not qualify for reimbursement. Answer any questions the consumer may have about TEMCO Fireplace Products vent-free products.

Vent-Free Gas Logs Only

Verify that the fireplace in which the logs are to be installed is either a solid-fuel burning fireplace (either factory-built or masonry) with a working flue system connected to it or an approved vent-free firebox.

Verify that the fireplace has been thoroughly cleaned by a professional chimney sweep. If solvents have been used to clean the hearth, they must be allowed to evaporate before proceeding with installation.

Check firebox dimensions for adequate height, width, and depth. Verify that the grate assembly is attached to the firebox floor. Verify that any ash dump or outside air inlets are permanently sealed to avoid drafts within the firebox. Verify that no additional logs, ornaments or non-approved blower devices have been added. Repair any broken or damaged logs prior to operation. Check mantel clearances and verify installation of canopy if necessary. Glass doors must be removed or opened completely during operation of logs.

Please sign below that checklist has been completed and understood. DATE INSTALLED ____/____/____

Installer Phone Consumer Phone

78586

TEMCO FIREPLACE PRODUCTS GAS LOGS & FIREPLACES

INSTALLATION AND STARTUP CHECKLIST

Installer’s Copy
