Page 1

TELUS

i365 Mike Phone

Getting Started Guide

Page 2

DECLARATION OF CONFORMITY

Per FCC CFR 47 Part 2 Section 2.1077(a)

Responsible Party Name: Motorola, Inc. Address: 8000 West Sunrise Boulevard Plantation, FL 33322 USA Phone Number: 1 (800) 453-0920 Hereby declares that the product: Product Name: i365 (i365IS) Model Number: H01XAN6JR5AN (i365)

H01XAN6JR6AN (i365IS) Conforms to the following regulations: FCC Part 15, subpart B, section 15.107(a),

15.107(d) and section 15.109(a) Class B Digital Device As a personal computer peripheral, this device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause

harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note:

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Page 3

Page 4

HELLOMOTO

PTT Button

Audio Jack

Volume Keys

Left Soft Key

Perform function

in lower left

display.

Talk Key

Make &

answer calls.

Menu Key

From home screen,

open main menu.

4-Way

Navigation Key

Right Soft Key

Perform function in lower right display.

Home/End Key

End calls, exit menu system.

Power Key

OK Key

In menus & lists, press to select

Status Indicator

Microphone

Speaker

Speaker On/Off

Key

Smart Key

Earpiece

Introducing your new Mike i365 wireless phone. Here’s a quick anatomy lesson.

Page 5

check it out

Home Screen

Main Menu

Exit

Main Menu

g l

Press the O key to open the

Call Alert Queue

screen

Press and hold the

Power Key

for a

few seconds, or until the screen lights up, to turn on your phone.

up, down, left or right ( )

Press the Navigation key

to highlight a menu feature.

Press the O key

to select.

Page 6

Motorola, Inc. Consumer Advocacy Office 1307 East Algonquin Road Schaumburg, IL 60196

www.hellomoto.com Note:

Do not ship your phone to the above address. If you need to return your phone for repairs, replacement, or warranty service, please contact the Motorola Customer Support Center at:

1-800-453-0920 (United States) 1-877-483-2840 (TTY/TDD United States for hearing impaired)

Certain mobile phone features are dependent on the capabilities and settings of TELUS’s network. Additionally, certain features may not be activated by TELUS, and/or TELUS's network settings may limit the feature’s functionality. Always contact TELUS Client Care about feature availability and functionality. All features, functionality, and other product specifications, as well as the information contained in this user's guide are based upon the latest available information and are believed to be accurate at the time of printing. Motorola reserves the right to change or modify any information or specifications without notice or obligation.

MOTOROLA and the Stylized M Logo are registered in the US Patent & Trademark Office. All other product or service names are the property of their respective owners. Java and all other Javabased marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the U.S. and other countries.

Page 7

Page 8

contents

check it out . . . . . . . . . . . 2

menu map. . . . . . . . . . . . 7

Use and Care . . . . . . . . . 9

essentials . . . . . . . . . . . 10

about this guide . . . . . 10

SIM card . . . . . . . . . . . . 11

battery . . . . . . . . . . . . . 11

turn it on & off . . . . . . 15

make a phone call. . . . 15

answer a phone call . . 16 make a private call . . . 16 answer a private call. . 17 store a phone number

or private ID . . . . . . . . 18

call a stored phone number or private ID . 19 your phone number

and Private ID . . . . . . . 19

text messages . . . . . . 20

manage memory . . . . 23

using your handset

as a modem . . . . . . . . 24

accessories. . . . . . . . . 24

for more information. . 25

Safety and General

Information . . . . . . . . . . 28

Service & Repairs. . . . . 34

Specific Absorption

Rate Data. . . . . . . . . . . . 35

Motorola Limited Warranty for the United

States and Canada . . . . 37

Information From the World Health

Organization . . . . . . . . . 42

Patent and Trademark

Information . . . . . . . . . . 44

Privacy a

Security . . . . . . . . . . . . . 45

Smart Practices

While Driving . . . . . . . . 46

index . . . . . . . . . . . . . . . 48

nd Data

contents

Page 9

contents

Page 10

main menu

Browser

Java Apps

• Java System

Shop

Settings

• (see next page)

VoiceRecord

• [New VoiceRec]

Contacts

• [New Contact]

Messages

• [Create Message]

•Voice Mail

• Text Inbox

•Drafts

• Text Outbox

• Fax Mail

• Net Alert

Call Forward

Datebook

Memo

menu map

Call Timers

• Last Call

• Phone Reset

• Phone Lifetime

•Prvt/Grp Reset

• Prvt/Grp Life

• Circuit Reset

• Circuit Lifetime

• Kbytes Reset

Recent Calls

Shortcuts

•[New Entry]

• 1)Shortcuts

• 2)Cntcs[New Contact]

• 3)Recent Calls

• 4)Contacts

• 5)Datebook

• 6)Messages

• 7)VoiceRecord

•8)Browser

• 9)Call Forward

My Info

•My Name

• Line 1

• Line 2

• Private ID

• Group ID

• Carrier IP

• IP1 Address

• IP2 Address

• Circuit Data

Profiles

Call Alert

GPS

• Position

•Privacy

• Interface

Ring Ton es

• Vibrate All

• Ringer

• Vibrate

• Silent

My Pictures

PT Manager

• Send Event

• Send My Info

• Send Contact

• Configure

Talk Around

Bluetooth

• Hands Free

• Link to Devices

• Device History

•Setup

•Find Me

This is the standard Main Menu layout. Your phone’s menu may be a little different.

menu map

Page 11

settings menu

Display/Info

• Wallpaper

•Text Size

• Theme

• Home Icons

• Backlight

•Clock

• Menu View

• Large Dialing

• Status Light

• Language

Phone Calls

• Set Line

•Any Key Ans

• Auto Redial

• Call Waiting

• Auto Ans

• Minute Beep

• Call Duration

• TTY

• Notifications

• DTMF Dialing

• Prepend

menu map

2-Way Radio

• Tkgrp Silent

•Tkgrp Area

• One Touch PTT

• Alert Type

•On/Off PTT

• Store Rcvd Info

Pers onalize

• Menu Options

•Up Key

•Down Key

•Left Key

• Right Key

• Center Key

• Left Sftkey

• Right Sftkey

•Power Up

Vol u me

• Line 1

• Line 2

• Messages

• Earpiece

• Speaker

•Keypad

• Java Earpie ce

• Java Spkr

•Data

Security

• Phone Lock

• Keypad Lock

• SIM PIN

• GPS PIN

• Change Passwds

Advanced

• Alert Timeout

• Headset/Spkr

• Connectivity

• Reset Defaults

• Return to Home

•Transmitters

• Phone Only

• Baud Rate

Page 12

Use and Care

To care for your Mike phone, please keep it away from:

extreme heat or cold cleaning solutions

Avoid temperatures below

-10°C/14°F or above 45°C/113°F.

microwaves the ground

Don’t try to dry your phone in a microwave oven.

To clean your phone, use only a dry soft cloth. Don’t use alcohol or other cleaning solutions.

Don’t drop your phone.

Use and Care

Page 13

essentials

Caution:

time, read the Important Safety and Legal information included in the gray-edged pages at the back of this guide.

Before using the phone for the first

about this guide

This guide shows how to locate a menu feature as follows:

Find it: M > u >

This means that, from the home screen:

Press the menu key M to open the

Settings

menu.

essentials

Phone Calls

Press the navigation key to scroll to

Phone Calls

select it.

symbols

, and press the center key r to

This means a feature is network or subscription dependent and may not be available in all areas. Contact TELUS for more information.

This means a feature requires an optional accessory.

Page 14

SIM card

insert the SIM card

Turn off your phone and remove your battery before you install or remove a SIM card.

Carefully slide the SIM card into your phone, until it lies flat in the SIM card holder.

Warning:

remove your SIM card from your phone unless absolutely necessary.

To avoid loss or damage, do not

battery

Battery Use & Battery Safety

• Motorola recommends you always use Motorola-branded batteries and chargers.

damage caused by non-Motorola batteries and/or chargers.

Caution:

or charger may present a risk of fire, explosion, leakage, or other hazard. Improper battery use, or use of a damaged battery, may result in a fire, explosion, or other hazard.

•

Battery usage by children should be supervised.

The warranty does not cover

Use of an unqualified battery

essentials

Page 15

•Important

: Motorola mobile devices are designed to work best with qualified batteries. If you see a message on your display such as

Battery

Unable to Charge

, take the

following steps:

•

Remove the battery and inspect it to confirm that it bears a Motorola “Original Equipment” hologram;

•

If there is no hologram, the battery is not a qualified battery;

•

If there is a hologram, replace the battery and retry charging it;

•

If the message remains, contact a Motorola Authorized Service Center.

•

New batteries or batteries stored for a long time may take more time to charge.

•Charging precautions:

your battery, keep it near room

essentials

Invalid

When charging

temperature. Never expose batteries to temperatures below 0°C (32°F) or above 45°C (113°F) when charging. Always take your mobile device with you when you leave your vehicle.

•

When storing your battery, keep it in a cool, dry place.

•

It is normal over time for battery life to decrease, and for the battery to exhibit shorter runtime between charges or require more frequent or longer charging times.

•Avoid damage to battery and mobile device.

Do not disassemble, open, crush, bend, deform, puncture, shred, or submerge the battery or mobile device. Avoid dropping the battery or mobile device, especially on a hard surface. If your battery or mobile device has been subjected to such damage, take it to a Motorola

Page 16

Authorized Service Center before using.

Do not

attempt to dry it with an appliance or heat source, such as a hair dryer or microwave oven.

•Use care when handling a charged battery:

inside a pocket, purse, or other container with metal objects. Contact with metal objects (e.g., jewelry, keys, beaded chains) could complete an electrical circuit (short circuit), causing the battery to become very hot, which could cause damage or injury.

Promptly dispose of used batteries in accordance with local regulations. Contact your local recycling center for proper battery disposal.

Warning:

because they may explode.

Particularly when placing it

Never dispose of batteries in a fire

battery installation

Rotate the release lock counterclockwise until it releases the battery door.

Remove the battery door.

essentials

Page 17

Push the battery down until it snaps in place.

Replace the battery door and press it gently until you hear a click.

essentials

battery charging

New batteries are not fully charged.

charge using the charger

Pull out the connector cover, and insert the charger into the accessory connector on your phone as shown.

Plug the other end of the charger into the appropriate electrical outlet.

When you charge the battery, the battery level indicator at the upper right of the screen shows charging progress. At least one segment of the indicator must be visible to ensure full phone functionality while charging.

Page 18

Tip:

Motorola batteries have circuitry that protects the battery from damage from overcharging.

Note:

This handset complies with environmental energy consumption requirements by notifying the user to unplug the charger from the power outlet when the charger is disconnected from phone/power outlet. This notice can be dismissed permanently by pressing

under No.

turn it on & off

To turn on your phone, press and hold

for a few seconds or until the display turns on. If prompted, enter your four-digit unlock code.

To turn off your phone, press and hold two seconds.

Note:

If you press the W for more than four

seconds, the handset will power “On” in

Transmitters Off

phone with transmitters off, ensure the power key is not held at about 4 seconds after power-up is initiated. To power up the phone normally from charging mode, wait until the

Charger Attached

press the power key.

mode. To avoid turning on the

screen is displayed, and then

for

make a phone call

Enter a phone number and press O to make a call or use a voice command.

Tip:

For best performance avoid touching the

antenna with your fingers during the call.

To hang up press

essentials

Page 19

answer a phone call

When your phone rings and/or vibrates, you have the following options:

If you want to answer the call on speaker phone, press the speaker key up press the smart key

If you want to answer the call using the handset, press

If you are using a Bluetooth headset, you can press the answer key on your Bluetooth headset. To hang up press the same key on your Bluetooth.

. To hang up press o.

(

)

. To hang

make a private call

With Mike’s Direct Connect service, you use your phone as a long-range, digital 2-way radio using one-to-one Private calls or one-to-many group calls.

essentials

Your Private ID is the number at which you receive one-to-one Private calls.

Talkgroup numbers are numbers through which you receive one-to-many group calls.

Your Mike sales representative creates Talkgroups for you and assigns each Talkgroup to a Talkgroup number. You can choose a name for each of your Talkgroups when you create entries for them in Contacts.

to make a Private call

Enter the Private ID you want to call.

Press and hold the PTT button. Begin talking after your phone emits a chirping sound.

Release the PTT button to listen.

To end the call press

Note:

A Private call ends automatically if there

is no activity on the call for a few seconds.

Page 20

send call alerts

Sending a call alert discretely lets the recipient know that you want to talk to him or her on a Private call.

When you send a call alert, the recipient’s handset displays your name and emits a series of beeps or vibrations.

The recipient has the following options:

Option

Answer

: Begin a Private call with the sender.

Queue

: Store the call alert to the call alert

queue.

Clear

: Dismiss and delete the call alert.

When the message the display, press the PTT button until the message

Alert Successful

Ready To Alert

appears.

appears on

answer a private call

When your phone emits a chirping sound or vibrates to indicate you are receiving a Private call, wait for the caller to finish speaking.

Press and hold the PTT button and begin talking after your phone emits a chirping sound.

Release the PTT button to listen.

To end the call press

to send a call alert

Enter the Private ID you want to call as you would when making a Private call.

Press - under

Alert

answer a call alert

When you receive a call alert, you must answer, queue, or clear it. You cannot receive phone calls or Private calls until you do.

essentials

Page 21

to answer a call alert

Press the PTT button to start a Private call with the sender.

Queue the call allert by pressing - under

Queue

Clear the call alert by pressing - under

Clear

store a phone number or private ID

You can store a phone number or private ID in

Contacts

Find it: M > L >

Enter a name for the new entry. Each entry’s name can contain 20 characters.

essentials

[New Contact]

Select a specific

Select a type for the entry (

Work1, Work2, Home, Email, Fax, Pager, Talkgroup, IP

Other

)

. To store a private ID choose

Private

Enter the number for the entry and press

under

Tip:

Before saving the entry, you can save more information. You can store an Email address, IP addresses, and more. You can choose a special ringer, create Contact entries that are groups of Private IDs called Group IDs.

After you have saved the number, the new Contacts entry is displayed.

Done

Ringer

Mobile, Private

Page 22

call a stored phone number or private ID

Shortcut:

under

Find it: M > L.

From the home screen press -

Contcs

Scroll to the

Tip:

By pressing the first letter of the name of the taken to all the contact names starting with the letter you pressed.

If the Contacts entry contains more than one number, scroll left or right until the type of the number you want to call is displayed ( etc.).

If you chose a phone number, press O to call the entry.

Contacts

entry.

Contacts

you want, you will be

Mobile, Private, Work1, Work2, Home

If you chose a Private ID, or Talkgroup ID, press and hold the PTT button to call the number.

Tip:

If the Contacts entry you scrolled to contains a Private ID, you can make an instant Private call to that Private ID by pressing and holding the PTT button, even if the Private ID is not the type of number displayed.

your phone number and Private ID

Find it: M > J.

Tip:

Want to see your phone number or Private ID while you’re on a call? Press

My Info

essentials

Page 23

text messages

Text messaging allows you to send and receive short text messages to and from other Mike handsets. Messages you receive appear on your handset’s display and in the text message inbox.

set it up

Before you begin using text messaging, you may need to set up your signature, service center number, and expiration information.

Shortcut:

under

Find it: M > E > M >

From the home screen press -

Mesg

> M >

essentials

Text Msg Setup

The following options become available:

option

Signature

: Enter your signature (up to 11

characters long).

Delivery Rpt

report once the message has been delivered.

Srvc Cntr No

service center. If you do not know this number, contact your service provider.

Expire After

messages you send are saved at the service center if they cannot be delivered. After this period, they are discarded.

Cleanup

phone to delete sent messages.

If you select the number of days after which sent messages are deleted or the number of messages to be kept.

: Set it to

: Enter the phone number of your

: This is the amount of time

: Set this option to On if you want your

Cleanup

if you wish to receive a

, select

Clean Up After

to set

Page 24

Press - under you entered.

Done

to save the information

receive a text message

To view the message press - under

To dismiss the message notification press

under

Back

Note:

If your phone is powered off when you receive a text message, your phone notifies you the next time you power it on. If you are out of your coverage area, your phone alerts you when you return to your coverage area.

Tip:

While reading a text and numeric message that contains a phone number, you can press

to call that number.

Read

read from the Message center

From the home screen press - under

Mesg

Text Inbox

Select the message you want to read or press the number of the message you want to read. If the message fills more than one screen, scroll to read it.

Tip:

Scrolling through one message lets

you view the next message.

To reply to the message, press - under

or to see all other choices, including forwarding and deleting the message, calling the sender, or storing the sender’s number in

Contacts

, press M.

create and send text messages

From the home screen press - under

Mesg

[Create Message]

You can also create a text message from the

Text Inbox, Text Outbox

To address the message use the keypad to enter the phone number of the person

, or

essentials

Drafts

Page 25

you want to send the message to and press

From the

Contcs

number you want.

Select message or to use a quick note press under you want.

Press M >

Fax, x400, Paging, Email, ERMES

If you want to send the message, press

without sending it, press

Note:

of delivery press

Send To

screen press - under

, or press M >

Msg

and enter the text of the

Browse

and scroll to the quick note

Set Send Method

under

Send

If you want to request confirmation

essentials

Recent Calls

or to delete the message

. Select the

and select

, or

Voice

under

Delivery Report

Cancel

> On.

Text

use drafts

When you save a message as a draft, it is saved in the drafts folder.

Shortcut:

under

From the home screen press -

Mesg

Drafts

Select the draft you want to edit. You also have the choice to create new text messages from this menu.

To edit the fields you want to change, follow step 2 through step 5 in “create and send text messages” above.

resend text messages

Shortcut:

under

From the home screen press -

Mesg

Text Outbox

Scroll to the message you want to resend or press the number of the message you want to resend.

Press M >

Re-send

Page 26

delete sent text messages

Shortcut:

under

delete all unlocked sent messages

Shortcut:

under

From the home screen press -

Mesg

Text Outbox

Scroll to the message you want to delete.

Press - under

From the home screen press -

Mesg

Text Outbox

Press M >

Press - under

Delete

Yes

to confirm.

Delete All.

Yes to confirm.

manage memory

Your text inbox, outbox, and drafts folder have a set amount of memory available for storing messages.

The text inbox holds 20 messages. If the text inbox is full, you cannot receive messages until you delete some.

The outbox and drafts folder hold 30 messages each. If the outbox and drafts folder memory is full, you cannot send messages or save drafts until you delete some.

To view the amount of memory available in your text inbox:

Shortcut:

under

To view the amount of memory available in your outbox and drafts folder:

Shortcut:

under

From the home screen press -

Mesg

> M >

From the home screen press -

Mesg

> M >

Text Msg Setup > Mem Mtr-Inbox

Text Msg Setup > Mem Mtr-Other

essentials

Page 27

using your handset as a modem

You can use your handset as a modem (Packet Data only) with a laptop, handheld device, or desktop computer. Circuit Data is not supported. In order to use your handset as a modem, you must create either a wired or wireless connection between your handset and the other device.

To connect your handset wirelessly, you must have a Bluetooth adapter for the other device.

connect via Bluetooth

Use your handset as a modem via Bluetooth. The laptop, handheld device, or desktop computer you want to connect to must have a Bluetooth adapter installed.

Check that the adapter is properly installed, and then follow the specific instructions

essentials

outlined in the device’s user guide to connect the device to your handset.

When used as a modem, your handset is enabled for used for small file transfers such as email.

Note:

the iDEN Wireless Data Services software (available separately). For more information on setting up your computer and your handset for Packet Data calls, contact TELUS Client Care

Data Modem

To use these services, you must install

transfer mode, which is

accessories

Your handset comes with a battery, and a charger.

To order additional accessories, log on to our Web site www.telusmobility.com or contact your Mike Dealer.

Page 28

for more information

If you have questions about your handset, contact your Mike Dealer or TELUS Client Care.

essentials

Page 29

essentials

Page 30

Important Safety and

Legal Information

Page 31

Safety and General Information

Safety Information

This section contains important information on the safe and efficient operation of your phone. Read this information before using your integrated multi-service portable radio.*

Exposure to Radio Frequency (RF) Energy

Your phone contains a transmitter and receiver. When it is ON, it receives and transmits RF energy. When you communicate with your phone, the system handling your call controls the power level at which your phone transmits.

Your Motorola phone is designed to comply with local regulatory requirements in your country concerning exposure of human beings to RF energy.

Portable Radio Product Operation and EME Exposure

Your Motorola radio product is designed to comply with the following national and international standards and guidelines regarding exposure of human beings to radio frequency electromagnetic energy (EME):

Safety Information

* The information provided in this document supersedes

•

United States Federal Communications Commission, Code of Federal Regulations; 47 CFR part 2 sub-part J.

•

American National Standards Institute (ANSI) / Institute of Electrical and Electronics Engineers (IEEE). C95. 1-1992.

•

Institute of Electrical and Electronics Engineers (IEEE). C95. 1-2005 Edition.*

•

International Commission on Non-Ionizing Radiation Protection (ICNIRP) 1998.

•

Ministry of Health (Canada). Safety Code 6. Limits of Human Exposure to Radio frequency Electromagnetic Fields in the Frequency Range from 3 kHz to 300 GHz,

1999.

•

Australian Communications Authority Radio communications (Electromagnetic Radiation - Human Exposure) Standard 2003.

•

ANATEL, Brazil Regulatory Authority, Resolution 303 (July 2, 2002) "Regulation of the limitation of exposure to

the general safety information in user’s guides published prior to May 1, 2006

Page 32

electrical, magnetic, and electromagnetic fields in the radio frequency range between 9 kHz and 300 GHz." "Attachment to Resolution 303 from July 2, 2002."

Operational Precautions

To assure optimal radio product performance and to be sure that human exposure to RF does not exceed the guidelines set forth in the relevant standards, always follow these instructions and precautions:

Phone Operation

When placing or receiving a phone call, hold your radio product as you would a wireline telephone.

microphone

Two-way radio operation

Your radio product has been designed and tested to comply with national and international standards and guidelines regarding human exposure to RF electromagnetic energy, when operated in the two-way mode (at the face, or at the abdomen when using an audio accessory) at usage factors of up to 50% talk/50% listen.

Transmit no more than the rated duty factor of 50% of the time. To transmit (talk), push the PTT button. To receive calls, release the PTT button. Transmitting 50% of the time or less, is important because this radio generates measurable RF energy only when transmitting (in terms of measuring for standards compliance).

Speak directly into the

When using your radio product as a traditional two-way radio,

vertical position with the microphone one to two inches (2.5 to 5 cm) away from the lips

If you wear a radio product on your body when transmitting, always place the radio product in a Motorola approved clip, holder, holster, case or body harness. If you do not use a body-worn accessory supplied or approved by Motorola and are not using the radio product in the intended use positions along side the head in the phone mode or in front of the face in the two-way radio mode, or if you hang your device from a lanyard around your neck, keep the device at least 2.5 centimeters (1 inch) from your body when transmitting.

hold the radio product in a

Approved Accessories

For a list of approved Motorola accessories call 1-800-453-0920, or visit our website at www.hellomoto.com

RF Energy Interference/Compatibility

Nearly every electronic device is subject to RF energy interference from external sources if inadequately shielded, designed or otherwise configured for RF energy compatibility. In some circumstances your handset may cause interference with other devices.

Safety Information

Page 33

Follow Instructions to Avoid Interference Problems

Turn OFF your radio product where posted notices instruct you to do so.

In an aircraft, turn off your radio product whenever instructed to do so by airline staff. If your radio product offers an airplane mode or similar feature, consult airline staff about using it in flight.

Implantable Medical Devices

If you have an implantable medical devices, such as a pacemaker or defibrillator, consult your physician before using this radio product.

Persons with implantable medical devices should observe the following precautions:

•

ALWAYS keep the phone more than 20 centimeters (8 inches) from the implantable medical device when the phone is turned ON.

•

DO NOT carry the phone in a breast pocket;

•

Use the ear opposite the implantable medical device to minimize the potential for interference.

•

Turn OFF the phone immediately if you have any reason to suspect that the interference is taking place.

Read and follow the directions from the manufacturer of your implantable medical device. If you have any questions about using

Safety Information

your wireless phone with your implantable medical device, consult your health care provider.

Hearing Aids

Some phones may interfere with some hearing aids. In the event of such interference, you may want to consult your hearing aid manufacturer or physician to discuss alternatives.

Other Medical Devices and Health Care Facilities

If you use any other personal medical devices, consult your physician or the manufacturer or your device to determine if it is adequately shielded from RF energy. Turn off your radio product when instructed to do so in hospitals or health care facilities that may be using equipment that is sensitive to external RF energy.

Bluetooth

This device supports Bluetooth 2.0 including EDR and A2DP Stereo profiles. In order for Bluetooth devices to communicate with one another, they must utilize the same Bluetooth profile. To determine the profiles supported by other Motorola devices, visit www.hellomoto.com/bluetooth. For other devices, contact their respective manufacturer.

Certain Bluetooth features including those listed may not be supported by all compatible Bluetooth-enabled devices, and/or the functionality of such features may be limited in certain devices, or by certain wireless carriers. Contact your wireless carrier about feature availability and functionality.

Page 34

Driving Precautions

032374o

032376o

Check the laws and regulations on the use of radio products in the area where you drive. Always obey them.

When using your radio product while driving, please:

•

Give full attention to driving and to the road. Using a phone may be distracting. Discontinue a call if you can’t concentrate on driving.

•

Use hands free operation, if available.

•

Pull off the road and park before making or answering a call if driving conditions so require.

•

Do not place a handset in the airbag deployment area.

Responsible driving practices can be found in the “Smart Practices While Driving” section at the end of this guide and/or at the Motorola Web site: www.motorola.com/callsmart

Note:

The use of wireless phones while driving may cause distraction. Discontinue a call if you can’t concentrate on driving. Additionally, the use of wireless devices and their accessories may be prohibited or restricted in certain areas. Always obey the laws and regulations on the use of these products.

Operational Warnings

Obey all posted signs when using phones in public areas.

Potentially Explosive Atmospheres

Areas with potentially explosive atmospheres are often but not always posted, and can include fueling areas such as below decks on boats, fuel or chemical transfer or storage facilities, or areas where the air contains chemicals or particles, such as grain, dust or metal powders.

When you are in such area, turn off your handset, and do not remove, install, or charge batteries unless it is a radio product type especially qualified for use in such areas as “Intrinsically Safe” (for example, Factory Mutual, CSA, or UL approved). In such areas, sparks can occur and cause an explosion or fire.

Batteries and Chargers

Caution: Improper treatment or use of batteries may present a danger of fire, explosion, leakage, or other hazard. For more information, see the “Battery Use and Battery Safety” section in this user’s guide.

Your battery, charger, or portable radio may contain symbols, defined as follows:

Symbol Definition

Important safety information follows.

Do not dispose of your battery or phone in a fire.

Safety Information

Page 35

Symbol Definition

032375o

032378o

Li Ion BATT

Your battery or phone may require recycling in accordance with local laws. Contact your local regulatory authorities for more information.

Do not throw your battery or phone in the trash.

Your phone contains an internal lithium ion battery.

Do not let your battery, charger, or phone get wet.

Listening at full volume to music or voice through a headset may damage your hearing.

Choking Hazards

Your portable radio or its accessories may include detachable parts, which may present a choking hazard to small children. Keep your device and its accessories away from small children.

Safety Information

Glass Parts

Some parts of your phone may be made of glass. This glass could break if the product is dropped on a hard surface or receives a substantial impact. If glass breaks, do not touch or attempt to remove. Stop using your phone until the glass is replaced by a qualified service center.

Seizures/Blackouts

Some people may be susceptible to epileptic seizures or blackouts when exposed to flashing lights, such as when playing video games. These may occur even if a person has never had a previous seizure or blackout.

If you have experienced seizures or blackouts, or if you have a family history of such occurrences, please consult with your physician before playing video games or enabling a flashing-lights feature (if available) on your phone.

Discontinue use and consult a physician if any of the following symptoms occur: convulsion, eye or muscle twitching, loss of awareness, involuntary movements, or disorientation. It is always a good idea to hold the screen away from your eyes, leave the lights on in the room, take a 15-minute break every hour, and stop use if you are very tired.

Caution About High Volume Usage

Listening at full volume to music or voice through a headset may damage your hearing.

Page 36

Repetitive Motion

When you repetitively perform actions such as pressing keys or entering finger-written characters, you may experience occasional discomfort in your hands, arms, shoulders, neck, or other parts of your body. If you continue to have discomfort during or after such use, stop use and see a physician.

Open Source Software Information

You may choose to obtain a copy of any source code being made publicly available by Motorola directly from the Motorola website opensource.motorola.com.

Additionally, for instructions on how to obtain a copy of any source code being made publicly available by Motorola related to software used in this Motorola mobile device, please send your request in writing to:

MOTOROLA, Inc. OSS Management 600 North US Hwy 45 Libertyville, IL 60048 USA.

Motorola has created the www.opensource.motorola.com to serve as a portal for interaction with the software community-at-large.

Safety Information

Page 37

Service & Repairs

If you have questions or need assistance, we’re here to help. Go to www.motorola.com/support

number of customer care options. You can also contact the

, where you can select from a

Export Law Assurances

Service & Repairs

This product is controlled under the export regulations of the United States of America and Canada. The Governments of the United States of America and Canada may restrict the exportation or re-exportation of this product to certain destinations. For further information contact the U.S. Department of Commerce or the Canadian Department of Foreign Affairs and International Trade.

Service & Repairs

Motorola Customer Support Center at 1 (800) 453-0920 (United States), 1 (877) 483-2840 (TTY, TDD United States for hearing impaired).

Page 38

Specific Absorption Rate Data

SAR Data

ALL MODELS WITH FCC ID IHDP56HJ1 MEET THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVE S.

Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radio frequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.

The exposure standard for wireless mobile phones employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. conducted using standard operating positions reviewed by the FCC with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In

Tests for SAR are

general, the closer you are to a wireless base station antenna, the lower the power output.

Before a phone model is available for sale to the public, it must be tested and certified to the FCC that is does not exceed the limit established by the requirement adopted by the government for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for the model i365 (i365IS) phone when tested for use at the ear is 1.09 W/kg and when tested on the body, as described in this user guide, is 1.28 W/kg during packet data transmission. (Measurements for phones worn on the body differ among models, depending upon available accessories and FCC requirements.)

While there may be differences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure. Please note that improvements to this product model could cause differences in the SAR value for later products; in all cases, products are designed to be within the guidelines.

Additional information on Specific Absorption Rates (SAR) can be found on the Cellular Telecommunications Industry Association (CTIA) web-site at http://www.ctia.org Telecommunications Association (CWTA) Web site: http://www.cwta.ca

or the Canadian Wireless

SAR Data

Page 39

1. In the United States and Canada, the SAR limit for mobile phones used by the public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.

2. The SAR information includes the Motorola testing protocol, assessment procedure, and measurement uncertainty range for this product.

SAR Data

Page 40

Motorola Limited Warranty for the United States and Canada

Warran ty

What Does this Warranty Cover?

Note: FOR IDEN SUBSCRIBER PRODUCTS, ACCESSORIES AND SOFTWARE PURCHASED IN THE UNITED STATES OR CANADA

What Does this Warranty Cover?

Subject to the exclusions contained below, Motorola, Inc. warrants its Motorola iDEN Digital Mobile and Portable Handsets ("Products"), Motorola-branded or certified accessories sold for use with these Products ("Accessories") and Motorola software contained on CD-Roms or other tangible media and sold for use with these Products ("Software") to be free from defects in materials and workmanship under normal consumer usage for the period(s) outlined below.

consumer's exclusive remedy, and applies as follows to new Products, Accessories and Software purchased by

This limited warranty is a

consumers in the United States or Canada, which are accompanied by this written warranty:

Products Covered Length of Coverage

Products as defined above.

Accessories as defined above.

Products or Accessories that are Repaired or Replaced.

One (1) year

purchase by the first consumer purchaser of the product.

One (1) year

purchase by the first consumer purchaser of the product.

The balance of the original warranty or for ninety (90) days

from the date returned to the consumer, whichever is longer.

from the date of

Warranty

Page 41

Products Covered Length of Coverage

Software

as defined above. Applies only to physical defects in the media that embodies the copy of the software (e.g. CD-ROM, or floppy disk).

What is not covered? (Exclusions)

Normal Wear and Tear

replacement of parts due to normal wear and tear are excluded from coverage.

Ornamental Decorations

emblems, graphics, rhinestones, jewels, gemstones and their settings, and other decorative elements, are excluded from coverage.

Batteries

. Only batteries whose fully charged capacity falls below 80% of their rated capacity and batteries that leak are covered by this limited warranty.

Abuse & Misuse

improper operation, storage, misuse or abuse, accident or neglect, such as physical damage (cracks, scratches, etc.) to the surface of the product resulting from misuse; (b) contact with liquid, water, rain, extreme humidity or heavy perspiration, sand, dirt or the like, extreme heat, or food; (c) use of the Products or Accessories for

Warranty

Ninety (90) days from the date of purchase.

. Periodic maintenance, repair and

. Ornamental decorations such as

. Defects or damage that result from: (a)

commercial purposes or subjecting the Product or Accessory to abnormal usage or conditions; or (d) other acts which are not the fault of Motorola, are excluded from coverage.

Use of Non-Motorola Products and Accessories

damage that result from the use of Non-Motorola branded or certified Products, Accessories, Software or other peripheral equipment are excluded from coverage.

Unauthorized Service or Modification

resulting from service, testing, adjustment, installation, maintenance, alteration, including without limitation, software changes, or modification in any way by someone other than Motorola, or its authorized service centers, are excluded from coverage.

Altered Products

numbers or date tags that have been removed, altered or obliterated; (b) broken seals or that show evidence of tampering; (c) mismatched board serial numbers; or (d) nonconforming or non-Motorola housings, antennas, or parts, are excluded from coverage.

Communication Services

Products, Accessories or Software due to any communication service or signal you may subscribe to or use with the Products, Accessories or Software is excluded from coverage.

Software Embodied in Physical Media.

that the software will meet your requirements or will work in combination with any hardware or software applications provided by third parties, that the operation of the software products will be

. Products or Accessories with (a) serial

. Defects, damages, or the failure of

. Defects or

. Defects or damages

No warranty is made

Page 42

uninterrupted or error free, or that all defects in the software products will be corrected.

Software NOT Embodied in Physical Media

not embodied in physical media (e.g. software that is downloaded from the internet), is provided "as is" and without warranty.

Who is covered?

consumer purchaser, and is not transferable.

What will Motorola Do?

charge repair, replace or refund the purchase price of any Products, Accessories or Software that does not conform to this warranty. We may use functionally equivalent reconditioned/refurbished/pre-owned or new Products, Accessories or parts. No data, software or applications added to your Product, Accessory or Software, including but not limited to personal contacts, games and ringer tones, will be reinstalled. To avoid losing such data, software and applications please create a back up prior to requesting service.

How to Obtain Warranty Service or Other Information?

obtain service or information, please call: Motorola iDEN Customer Services 1-800-453-0920 or

954-723-4910 TTY-877-483-2840 Or visit us online at http://www.motorola.com/iden You will receive instructions on how to ship the Products,

Accessories or Software, at your expense, to a Motorola Authorized Repair Center. To obtain service, you must include: (a) a

This warranty extends only to the first

Motorola, at its option, will at no

. Software that is

copy of your receipt, bill of sale or other comparable proof of purchase; (b) a written description of the problem; (c) the name of your service provider, if applicable; (d) the name and location of the installation facility (if applicable) and, most importantly; (e) your address and telephone number.

What Other Limitations Are There?

WARRANTIES, INCLUDING WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS LIMITED WARRANTY, OTHERWISE THE REPAIR, REPLACEMENT, OR REFUND AS PROVIDED UNDER THIS EXPRESS LIMITED WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER, AND IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OF IMPLIED. IN NO EVENT SHALL MOTOROLA BE LIABLE, WHETHER IN CONTRACT OR TORT (INCLUDING NEGLIGENCE) FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT, ACCESSORY OR SOFTWARE, OR FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES OF ANY KIND, OR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA, SOFTWARE OR APPLICATIONS OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE ABILITY OR INABILITY TO USE THE PRODUCTS, ACCESSORIES OR SOFTWARE TO THE FULL EXTENT THESE DAMAGES MAY BE DISCLAIMED BY LAW.

Some states and jurisdictions do not allow the limitation or exclusion of incidental or consequential damages, or limitation on the length of an implied warranty, so the above limitations or

ANY IMPLIED

Warranty

Page 43

exclusions may not apply to you. This warranty gives you specific legal rights, and you may also have other rights that vary from state to state or from one jurisdiction to another.

Laws in the United States and other countries preserve for Motorola certain exclusive rights for copyrighted Motorola software such as the exclusive rights to reproduce and distribute copies of the Motorola software. Motorola software may only be copied into, used in, and redistributed with, the Products associated with such Motorola software. No other use, including without limitation disassembly of such Motorola software or exercise of the exclusive rights reserved for Motorola, is permitted.

Patent and Software Provisions

MOTOROLA will defend, at its own expense, any suit brought against the end user purchaser to the extent that it is based on a claim that the Product or parts infringe a United States patent, and Motorola will pay those costs and damages finally awarded against the end user purchaser in any such suit which are attributable to any such claim, but such defense and payments are conditioned on the following:

a.That MOTOROLA will be notified promptly in writing by such purchaser of any notice of such claim;

b.That MOTOROLA will have sole control of the defense of such suit and all negotiations for its settlement or compromise; and

Warranty

c.Should the Product or parts become, or in MOTOROLA'S opinion be likely to become, the subject of a claim of infringement of a United States patent, that such purchaser will permit MOTOROLA, at its option and expense, either to procure for such purchaser the right to continue using the Product or parts or to replace or modify the same so that it becomes non-infringing or to grant such purchaser a credit for the Product or parts as depreciated and accept its return. The depreciation will be an equal amount per year over the lifetime of the Product or parts as established by MOTOROLA.

MOTOROLA will have no liability with respect to any claim of patent infringement which is based upon the combination of the Product or parts furnished hereunder with software, apparatus or devices not furnished by MOTOROLA, nor will MOTOROLA have any liability for the use of ancillary equipment or software not furnished by MOTOROLA which is attached to or used in connection with the Product or any parts thereof.

Laws in the United States and other countries preserve for MOTOROLA certain exclusive rights for copyrighted MOTOROLA software, such as the exclusive rights to reproduce in copies and distribute copies of such MOTOROLA software. MOTOROLA software may be used in only the Product in which the software was originally embodied and such software in such Product may not be replaced, copied, distributed, modified in any way, or used to produce any derivative thereof. No other use including, without limitation, alteration, modification, reproduction, distribution, or reverse engineering of such MOTOROLA software or exercise or rights in such MOTOROLA software is permitted. No license is

Page 44

granted by implication, estoppel or otherwise under MOTOROLA patent rights or copyrights.

Warranty

Page 45

Information From the World Health Organization

WHO Information

Present scientific information does not indicate the need for any special precautions for the use of mobile phones. If you are concerned, you may want to limit your own or your children’s RF

exposure by limiting the length of calls or by using hands-free devices to keep mobile phones away from your head and body.

Source: WHO Fact Sheet 193 Further information: http://www.who.int./peh-emf

Product Registration

Registration

Online Product Registration: http://direct.motorola.com/hellomoto/

Motosupport/source/registration.asp Product registration is an important step toward enjoying your new

Motorola product. Registration permits us to contact you for product or software updates and allows you to subscribe to updates on new products or special promotions. Registration is for U.S. residents only and is not required for warranty coverage. The website link above will not register this product for warranty service.

Please retain your original dated sales receipt for your records. For warranty service of your Motorola Personal Communications

WHO Information

Product you will need to provide a copy of your dated sales receipt to confirm warranty status.

Thank you for choosing a Motorola product.

Page 46

Wireless: The New Recyclable

Recycling

Your wireless phone can be recycled. Recycling your phone reduces the amount of waste disposed in landfills and allows recycled materials to be incorporated into new products.

The Cellular Telecommunications Industry Association (CTIA) and its members encourage consumers to recycle their phones and have taken steps to promote the collection and environmentally sound recycling of end-of-life devices.

California Perchlorate Label

Perchlorate Label

Some mobile phones use an internal, permanent backup battery on the printed circuit board that may contain very small amounts of perchlorate. In such cases, California law requires the following label:

“Perchlorate Material - special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate.

There is no special handling required by consumer.

”

As a phone user, you have an important role in ensuring that this device is recycled properly. When it comes time to give this phone up or trade it in for a new one, please remember that the phone, the charger, and many of its accessories can be recycled. It's easy. To learn more about CTIA's Recycling Program for Used Wireless Devices, please visit us at: http://recycling.motorola.young-america.com/ index.html

Recycling

Page 47

Patent and Trademark Information

Patent and Trademark

Microsoft and Microsoft Internet Explorer are registered trademarks of Microsoft Corporation.

T9 is a trademark owned by Tegic Communications.

Text Input Patent and Trademark Information.

T9 This product is covered by U.S. Pat. 5,818,437, U.S. Pat. 5,953,541,

U.S. Pat. 6,011,554 and other patents pending. Java and all other Java-based marks are trademarks or registered

trademarks of Sun Microsystems, Inc. in the U.S. and other countries.

All other product names or services mentioned in this manual are the property of their respective trademark owners.

Patent and Trademark

Software Copyright Notice

The Motorola products described in this manual may include copyrighted Motorola and third party software stored in semiconductor memories or other media. Laws in the United States and other countries preserve for Motorola and third party software providers certain exclusive rights for copyrighted software, such as the exclusive rights to distribute or reproduce the copyrighted software. Accordingly, any copyrighted software contained in the Motorola products may not be modified, reverse-engineered, distributed, or reproduced in any manner to the extent allowed by law. Furthermore, the purchase of the Motorola products shall not be deemed to grant either directly or by implication, estoppel, or otherwise, any license under the copyrights, patents, or patent applications of Motorola or any third party software provider, except for the normal, non-exclusive, royalty-free license to use that arises by operation of law in the sale of a product.

Page 48

Privacy and Data Security

Motorola understands that privacy and data security are important to everyone. Because some features of your phone may affect your privacy or data security, please follow these recommendations to enhance protection of your information:

• Monitor access:

leave it where others may have unmonitored access. Lock your device’s keypad where this feature is available.

• Keep software up to date:

software/application vendor releases a patch or software fix for your phone which updates the device’s security, install it as soon as possible.

• Erase before recycling:

data from your phone prior to disposing of it or turning it in for recycling. For step-by-step instructions on how to delete all personal information from your device, please contact your local service provider.

Keep your phone with you and do not

If Motorola or a

Delete personal information or

• Understanding AGPS:

emergency caller location requirements of the FCC, certain Motorola phones incorporate Assisted Global Positioning System (AGPS) technology. AGPS technology also can be used in non-emergency applications to track and monitor a user’s location, for example, to provide driving directions. Users who prefer not to permit such tracking and monitoring should avoid using such applications.

If you have further questions regarding how use of your phone may impact your privacy or data security, please contact Motorola at privacy@motorola.com, or contact your TELUS Client Care.

In order to comply with

Privacy and Data Security

Page 49

Smart Practices While Driving

Driving Safety

Check the laws and regulations on the use of phones and their accessories in the areas where you drive. Always obey them. The use of these devices may be prohibited or restricted in certain areas. Go to for more information.

Your phone lets you communicate by voice and data, almost anywhere, anytime, wherever wireless service is available and safe conditions allow. When driving a car, driving is your first responsibility. If you choose to use your phone while driving, remember the following tips:

• Get to know your Motorola phone and its features

• When available, use a hands-free

• Position your phone within easy reach.

Drive Safe, Call Smart

such as speed dial and redial.

features help you to place your call without taking your attention off the road.

If possible, add an additional

device.

layer of convenience to your phone with one of the many Motorola Original hands-free accessories available today.

access your phone without removing your eyes from the

Driving Safety

www.motorola.com/callsmart

If available, these

Be able to

road. If you receive an incoming call at an inconvenient time, if possible, let your voice mail answer it for you.

• Let the person you are speaking with know you are driving; if necessary, suspend the call in heavy traffic or hazardous weather conditions.

snow, ice, and even heavy traffic can be hazardous.

• Do not take notes or look up phone numbers while

• Dial sensibly and assess the traffic; if possible,

• Do not engage in stressful or emotional

• Use your phone to call for help.

Jotting down a “to do” list or going through your

driving.

address book takes attention away from your primary responsibility, driving safely.

place calls when your car is not moving or before pulling into traffic.

moving, dial only a few numbers, check the road and your mirrors, then continue.

conversations that may be distracting.

you are talking with aware you are driving and suspend conversations that can divert your attention away from the road.

emergency number in the case of fire, traffic accident, or medical emergencies.**

If you must make a call while

Rain, sleet,

Make people

Dial 911 or other local

Page 50

• Use your phone to help others in emergencies.

see an auto accident, crime in progress, or other serious emergency where lives are in danger, call 911 or other local emergency number, as you would want others to do for you.**

• Call roadside assistance or a special non-emergency wireless assistance number when necessary.

serious hazard, a broken traffic signal, a minor traffic accident where no one appears injured, or a vehicle you know to be stolen, call roadside assistance or other special non-emergency wireless number.*

* Wherever wireless phone service is available.

If you see a broken-down vehicle posing no

If you

Driving Safety

Page 51

index

accessories 10 answer a call 16

battery charging 14 battery installation 13

call

answer 16 end 15 make 15

center select key 10

dial a phone number 15

index

Drafts 22
