Teltonika RUT950 User Manual

Download

USER MANUAL

RUT950 LTE Router

Before using the device we strongly recommend reading this user manual first.

Do not rip open the device. Do not touch the device if the device block is broken.

All wireless devices for data transferring may be susceptible to interference, which could

affect performance.

The device is not water-resistant. Keep it dry. Device is powered by low voltage +9V DC power adaptor.

Legal notice

Copyright © 2015 TELTONIKA Ltd. All rights reserved. Reproduction, transfer, distribution or storage of part or all of the contents in this document in any form without the prior written permission of TELTONIKA Ltd is prohibited. The manufacturer reserves the right to modify the product and manual for the purpose of technical improvement without prior notice.

Other product and company names mentioned herein may be trademarks or trade names of their respective owners.

Attention

Table of Contents

Legal notice .............................................................................................................................................................. 2

Attention.................................................................................................................................................................. 2

SAFETY INFORMATION ............................................................................................................................................ 8

Device connection ............................................................................................................................................... 9

1 Introduction ................................................................................................................................................. 10

2 Specifications ............................................................................................................................................... 10

2.1 Ethernet ................................................................................................................................................... 10

2.2 Wi-Fi ......................................................................................................................................................... 10

2.3 Hardware ................................................................................................................................................. 10

2.4 Electrical, Mechanical & Environmental .................................................................................................. 10

2.5 Applications ............................................................................................................................................. 11

3 Setting up your router ................................................................................................................................. 12

3.1 Installation ............................................................................................................................................... 12

3.1.1 Front Panel and Back Panel ............................................................................................................. 12

3.1.2 Connection status LED indication .................................................................................................... 12

3.1.3 Hardware installation ...................................................................................................................... 13

3.2 Logging in ................................................................................................................................................. 13

4 Operation Modes ......................................................................................................................................... 16

5 Powering Options ........................................................................................................................................ 16

5.1 Powering the device from higher voltage................................................................................................ 17

6 Status ........................................................................................................................................................... 18

6.1 Overview .................................................................................................................................................. 18

6.2 System Information ................................................................................................................................. 19

6.3 Network Information ............................................................................................................................... 20

6.4 Device information .................................................................................................................................. 29

6.5 Services .................................................................................................................................................... 30

6.6 Routes ...................................................................................................................................................... 30

6.6.1 ARP ................................................................................................................................................... 30

6.6.2 Active IP-Routes ............................................................................................................................... 31

6.6.3 Active IPv6-Routes ........................................................................................................................... 31

6.7 Graphs ...................................................................................................................................................... 31

6.7.1 Mobile Signal Strength ..................................................................................................................... 31

6.7.2 Realtime Load .................................................................................................................................. 32

6.7.3 Realtime Traffic ................................................................................................................................ 33

6.7.4 Realtime Wireless ............................................................................................................................ 35

6.7.5 Realtime Connections ...................................................................................................................... 36

6.8 Mobile Traffic ........................................................................................................................................... 37

6.9 Speed Test ................................................................................................................................................ 38

6.10 Events Log ............................................................................................................................................ 38

6.10.1 All Events ......................................................................................................................................... 38

6.10.2 System Events .................................................................................................................................. 39

6.10.3 Network Events ............................................................................................................................... 40

6.10.4 Events Reporting ............................................................................................................................. 41

6.10.5 Reporting Configuration .................................................................................................................. 42

7 Network ....................................................................................................................................................... 45

7.1 Mobile ...................................................................................................................................................... 45

7.1.1 General ............................................................................................................................................. 45

7.1.2 SIM Management ............................................................................................................................ 48

7.1.3 Network Operators .......................................................................................................................... 49

7.1.4 Mobile Data Limit............................................................................................................................. 50

7.1.5 SIM Idle protection .......................................................................................................................... 51

7.2 WAN ......................................................................................................................................................... 52

7.2.1 Operation Mode .............................................................................................................................. 52

7.2.2 Common configuration .................................................................................................................... 53

7.3 LAN ........................................................................................................................................................... 59

7.3.1 Configuration ................................................................................................................................... 59

7.3.2 DHCP Server ..................................................................................................................................... 60

7.4 Wireless ................................................................................................................................................... 63

7.5 VLAN......................................................................................................................................................... 66

7.5.1 VLAN Networks ................................................................................................................................ 66

7.5.2 LAN Networks .................................................................................................................................. 67

7.6 Firewall ..................................................................................................................................................... 67

7.6.1 General Settings ............................................................................................................................... 67

7.6.2 DMZ .................................................................................................................................................. 68

7.6.3 Port Forwarding ............................................................................................................................... 69

7.6.4 Traffic Rules...................................................................................................................................... 71

7.6.5 Custom Rules ................................................................................................................................... 75

7.6.6 DDOS Prevention ............................................................................................................................. 75

7.6.7 Port Scan Prevention ....................................................................................................................... 78

7.7 Routing ..................................................................................................................................................... 79

7.7.1 Static Routes .................................................................................................................................... 79

7.7.2 Dynamic Routes ............................................................................................................................... 80

7.8 Load Balancing ......................................................................................................................................... 83

8 Services ........................................................................................................................................................ 84

8.1 VRRP ......................................................................................................................................................... 84

8.1.1 VRRP LAN Configuration Settings .................................................................................................... 84

8.1.2 Check Internet connection ............................................................................................................... 84

8.2 TR-069 ...................................................................................................................................................... 85

8.2.1 TR-069 Parameters Configuration ................................................................................................... 85

8.3 Web filter ................................................................................................................................................. 85

8.3.1 Site blocking ..................................................................................................................................... 85

8.3.2 Proxy Based Content Blocker ........................................................................................................... 86

8.4 NTP ........................................................................................................................................................... 87

8.5 VPN .......................................................................................................................................................... 88

8.5.1 OpenVPN .......................................................................................................................................... 88

8.5.2 IPSec ................................................................................................................................................. 90

8.5.3 GRE Tunnel ....................................................................................................................................... 93

8.5.4 PPTP ................................................................................................................................................. 95

8.5.5 L2TP .................................................................................................................................................. 96

8.6 Dynamic DNS ............................................................................................................................................ 97

8.7 SMS Utilities ............................................................................................................................................. 98

8.7.1 SMS Utilities ..................................................................................................................................... 98

8.7.2 Call Utilities .................................................................................................................................... 104

8.7.3 User Groups ................................................................................................................................... 105

8.7.4 SMS Management .......................................................................................................................... 106

8.7.5 Remote Configuration .................................................................................................................... 107

8.7.6 Statistics ......................................................................................................................................... 110

8.8 SNMP ..................................................................................................................................................... 110

8.8.1 SNMP Settings ................................................................................................................................ 111

8.8.2 TRAP Settings ................................................................................................................................. 112

8.9 SMS Gateway ......................................................................................................................................... 112

8.9.1 Post/Get Configuration .................................................................................................................. 112

8.9.2 Email to SMS .................................................................................................................................. 115

8.9.3 Scheduled Messages ...................................................................................................................... 115

8.9.4 Auto Reply Configuration ............................................................................................................... 116

8.9.5 SMS Forwarding ............................................................................................................................. 117

8.9.6 SMPP .............................................................................................................................................. 119

8.10 Hotspot .............................................................................................................................................. 119

8.10.1 General settings ............................................................................................................................. 120

8.10.2 Internet Access Restriction Settings .............................................................................................. 122

8.10.3 Logging........................................................................................................................................... 122

8.10.4 Landing Page .................................................................................................................................. 124

8.10.5 Radius server configuration ........................................................................................................... 125

8.10.6 Statistics ......................................................................................................................................... 126

8.11 CLI....................................................................................................................................................... 126

8.12 Auto Reboot ....................................................................................................................................... 127

8.12.1 Ping Reboot ................................................................................................................................... 127

8.12.2 Periodic Reboot ............................................................................................................................. 128

8.13 UPNP .................................................................................................................................................. 128

8.13.1 General Settings ............................................................................................................................ 128

8.13.2 Advanced Settings ......................................................................................................................... 129

8.13.3 UPnP ACLs ...................................................................................................................................... 129

8.13.4 Active UPnP Redirects ................................................................................................................... 129

8.14 QoS ..................................................................................................................................................... 130

9 System ........................................................................................................................................................ 131

9.1 Setup Wizard .......................................................................................................................................... 131

9.2 Profiles ................................................................................................................................................... 133

9.3 Administration ....................................................................................................................................... 133

9.3.1 General ........................................................................................................................................... 133

9.3.2 Troubleshoot .................................................................................................................................. 134

9.3.3 Backup ............................................................................................................................................ 135

9.3.4 Diagnostics ..................................................................................................................................... 137

9.3.5 MAC Clone ..................................................................................................................................... 138

9.3.6 Overview ........................................................................................................................................ 138

9.3.7 Monitoring ..................................................................................................................................... 139

9.4 User scripts ............................................................................................................................................ 140

9.5 Restore point ......................................................................................................................................... 140

9.5.1 Restore point create ...................................................................................................................... 140

9.5.2 Restore point load.......................................................................................................................... 141

9.6 Firmware ................................................................................................................................................ 141

9.6.1 Firmware ........................................................................................................................................ 141

9.6.2 FOTA ............................................................................................................................................... 142

9.7 Reboot .................................................................................................................................................... 142

10 Device Recovery ......................................................................................................................................... 143

10.1 Reset button ...................................................................................................................................... 143

10.2 Bootloader’s WebUI ........................................................................................................................... 143

11 Glossary ...................................................................................................................................................... 144

The device is intended for supply from a Limited Power Source (LPS) that power consumption

should not exceed 15VA and current rating of over current protective device should not exceed 2A.

The highest transient over voltage in the output (secondary circuit) of used PSU shall not

exceed 36V peak.

The device can be used with the Personal Computer (first safety class) or Notebook (second safety class). Associated equipment: PSU (power supply unit) (LPS) and personal computer (PC) shall comply with the requirements of standard EN 60950-1.

Do not mount or service the device during a thunderstorm.

To avoid mechanical damages to the device it is recommended to transport it packed in a damage-proof pack.

Protection in primary circuits of associated PC and PSU (LPS) against short circuits and earth faults of associated PC shall be provided as part of the building installation.

SAFETY INFORMATION

In this document you will be introduced on how to use a RUT950 router safely. We suggest you to adhere to the

following recommendations in order to avoid personal injuries and or property damage.

You have to be familiar with the safety requirements before using the device!

To avoid burning and voltage caused traumas, of the personnel working with the device, please follow these

safety requirements.

To avoid mechanical damages to the device it is recommended to transport it packed in a damage-proof pack. While using the device, it should be placed so, that its indicating LEDs would be visible as they inform in which working mode the device is and if it has any working problems.

Protection against over current, short circuiting and earth faults should be provided as a part of the building installation.

Signal level of the device depends on the environment in which it is working. In case the device starts working insufficiently, please refer to qualified personnel in order to repair this product. We recommend forwarding it to a repair center or the manufacturer. There are no exchangeable parts inside the device.

Device connection

1 Introduction

Thank you for purchasing a RUT950 LTE router! RUT950 is part of the RUT9xx series of compact mobile routers with high speed wireless and Ethernet

connections.

This router is ideal for people who‘d like to share their internet on the go, as it is not restricted by a cumbersome

cable connection. Unrestricted, but not forgotten: the router still supports internet distribution via a broadband cable, simply plug it in to the wan port, set the router to a correct mode and you are ready to browse.

2 Specifications

2.1 Ethernet

 IEEE 802.3, IEEE 802.3u standards  3 x LAN 10/100Mbps Ethernet ports  1 x WAN 10/100Mbps Ethernet port  Supports Auto MDI/MDIX

2.2 Wi-Fi

 IEEE 802.11b/g/n WiFi standards  2x2 MIMO  AP and STA modes  64/128-bit WEP, WPA, WPA2, WPA&WPA2 encryption methods  2.401 – 2.495GHz Wi-Fi frequency range  20dBm max WiFi TX power  SSID stealth mode and access control based on MAC address

2.3 Hardware

 High performance 560 MHz CPU with 128 Mbytes of DDR2 memory  5.5/2.5mm DC power socket  Reset/restore to default button  2 x SMA for LTE , 2 x RP-SMA for WiFi antenna connectors  4 x Ethernet LEDs, 1 x Power LED  1 x bi-color connection status LED, 5 x connection strength LEDs

2.4 Electrical, Mechanical & Environmental

 Dimensions (H x W x D) 80mm x 106mm x 46mm  Weight 250g  Power supply 100 – 240 VAC -> 9 VDC wall adapter  Input voltage range 9 – 30VDC  Power consumption < 7W  Operating temperature -40° to 75° C  Storage temperature -45° to 80° C  Operating humidity 10% to 90% Non-condensing  Storage humidity 5% to 95% Non-condensing

2.5 Applications

1,2,3

LAN Ethernet ports

1 LTE auxiliary antenna connector

WAN Ethernet port

2 LTE main antenna connector

5,6,7

LAN LEDs

3,5

Wi-Fi antenna connectors

WAN LED

4 Reset button

Power socket

Power LED

Connection status LED

Signal strength indication LEDs

3 Setting up your router

3.1 Installation

After you unpack the box, follow the steps, documented below, in order to properly connect the device. For

better Wi-Fi performance, put the device in clearly visible spot, as obstacles such as walls and door hinder the signal.

1. First assemble your router by attaching the necessary antennas and inserting the SIM card.

2. To power up your router, please use the power adapter included in the box. (IMPORTANT: Using a different

power adapter can damage and void the warranty for this product.).

3. If you have a wired broadband connection you will also have to connect it to the WAN port of the router.

3.1.1 Front Panel and Back Panel

3.1.2 Connection status LED indication

Constant blinking (~ 2Hz) – router is turning on. LED turned off – it has no 4G data connection LED turned on – it has 4G data connection.

Explanation of connection status LED indication:

1. Green and red blinking alternatively ever 500 ms: no SIM or bad PIN;

2. Green, red and yellow blinking alternatively every 500 ms: connecting to GSM;

3. Red blinking every 1 sec: connected 2G, but no data session established;

4. Yellow blinking every 1 sec: connected 3G, no data session established;

5. Green blinking every 1 sec: connected 4G, no data session established;

Red lit and blinking rapidly while data is being transferred: connected 2G with data session; Yellow lit and blinking rapidly while data is being transferred: connected 3G with data session; Green lit and blinking rapidly while data is being transferred: connected 4G with data session;

1. Press the start button

2. Type in “network connections”, wait for the results to pop

up.

SIM 1 (primary)

SIM 2 (secondary)

3.1.3 Hardware installation

1. Remove back panel and insert SIM card which was given by your ISP (Internet Service Provider). Correct SIM card

orientation is shown in the picture.

2. Attach LTE main and Wi-Fi antennas.

3. Connect the power adapter to the socket on the front panel of the device. Then plug the other end of the power

adapter into a wall outlet or power strip.

4. Connect to the device wirelessly (SSID: Teltonika_Router) or use Ethernet cable and plug it into any LAN

Ethernet port.

3.2 Logging in

After you’re complete with the setting up as described in the section above, you are ready to start logging into your router and start configuring it. This example shows how to connect on Windows 7. On windows Vista: click Start -> Control Panel -> Network and Sharing Centre -> Manage network Connections -> (Go to step 4). On Windows XP: Click Start -> Settings -> Network Connections -> (see step 4). You won’t see “Internet protocol version 4(TCP/IPv4)”, instead you’ll have to select “TCP/IP Settings” and click options -> (Go to step 6)

We first must set up our network card so that it could properly communicate with the router.

3. Click “View network connections”

4. Then right click on your wireless device that you use to connect to other access points (It is the one with the name

“Wireless Network Connection” and has signal bars on its

icon).

5. Select Internet Protocol Version 4 (TCP/IPv4) and then click Properties

6. By default the router is going to have DHCP enabled, which

means that if you select “Obtain an IP address automatically” and “Obtain DNS server address automatically”, the router

should lease you an IP and you should be ready to login.

7. If you choose to configure manually here’s what you have to do:

First select an IP address. Due to the stock settings that your router has arrived in you can only enter an IP in the

form of 192.168.1.XXX , where XXX is a number in the range of 2-254 (192.168.1.2 , 192.168.1.254 , 192.168.1.155 and

so on… are valid; 192.168.1.0 , 192.168.1.1 , 192.168.1.255 , 192.168.1.699 and so on… are not). Next we enter the subnet mask: this has to be “255.255.255.0”. Then we enter the default gateway: this has to be “192.168.1.1”. Finally

we enter primary and secondary DNS server IP’s. One will suffice, though it is good to have a secondary one as well as it

will act as a backup if the first should fail. The DNS can be your routers IP (192.168.1.1), but it can also be some external DNS server (like the one Google provides: 8.8.8.8).

Right click on the Wireless network icon and select Connect / Disconnect. A list should pop up with all available wireless networks. Select “Teltonika” and click connect. Then we launch our favorite browser and enter the routers IP into the address field:

Press enter. If there are no problems you should be greeted with a login screen such as this:

Enter the default password, which is “admin01” into the “Password” field and then either click Login with your

mouse or press the Enter key. You have now successfully logged into the RUT950!

From here on out you can configure almost any aspect of your router.

WAN

Main WAN

Backup WAN

LAN

Mobile

√

Ethernet

√

√ √ Wi-Fi

√

4 Operation Modes

The RUT9xx series router supports various operation modes. It can be connected to the internet (WAN) via mobile, standard Ethernet cable or via a wireless network. When connecting to the internet, you may also backup your main WAN connection with one or two backup connections. Any interface can act like backup if configured so. At first router uses its main WAN connection, if it is lost then router tries to connect via backup with higher priority and if that fails too, router tries the second backup option.

In later sections it will be explained, in detail, how to configure your router to work in a desired mode.

5 Powering Options

The RUT9xx router can be powered from power socket or over Ethernet port. Depending on your network architecture you can use LAN 1 port to power the device.

RUT9xx can be powered from power socket and over Ethernet simultaneously. Power socket has higher priority meaning that the device will draw power from power socket as long as it is available.

When RUT9xx is switching from one power source to the other it loses power for a fraction of the second and may reboot. The device will function correctly after the reboot.

Though the device can be powered over Ethernet port it is not compliant with IEEE 802.3af-2003 standard. Powering RUT9xx from IEEE 802.3af-2003 power supply will damage the device as it is not rated for input voltages of PoE standard.

5.1 Powering the device from higher voltage

If you decide not to use our standard 9 VDC wall adapters and want to power the device from higher voltage (15 – 30 VDC) please make sure that you choose power supply of high quality. Some power supplies can produce voltage peaks significantly higher than the declared output voltage, especially during connecting and disconnecting them.

While the device is designed to accept input voltage of up to 30 VDC peaks from high voltage power supplies can harm the device. If you want to use high voltage power supplies it is recommended to also use additional safety equipment to suppress voltage peaks from power supply.

6 Status

The status section contains various information, like current IP addresses of various network interfaces; the state of the routers memory; firmware version; DHCP leases; associated wireless stations; graphs indicating load, traffic, etc.; and much more.

6.1 Overview

Overview section contains various information summaries.

Field Name

Sample value

Explanation

Router Name

RUT950

Name of the router (hostname of the routers system). Can be changed in System -> Administration.

Host name

Teltonika-RUT950.com

Indicates how router will be seen by other devices on the network. Can be changed in System -> Administration.

Router Model

Teltonika RUT950 LTE

Routers model.

Firmware Version

RUT9XX_R_00.02.345

Shows the version of the firmware that is currently loaded in the router. Newer versions might become available as new features are added. Use this field to decide whether you need a firmware upgrade or not.

Kernel Version

3.10.36

The version of the Linux kernel that is currently running on the router.

Local Time

2016-05-06, 05:54:10

Shows the current system time. Might differ from your computer, because the router synchronizes it's time with an NTP server. Format [year-month-day, hours: minutes: seconds].

Uptime

0d 0h 47m 35s (since 2016-05-06, 05:06:35)

Indicates how long it has been since the router booted up. Reboots will reset this timer to 0. Format [day’s hours minutes seconds (since yearmonth-day, hours: minutes: seconds)].

Load Average

1 min: 100%; 5 mins: 87%; 15 mins: 52%

Indicates how busy the router is. Let's examine some sample output: "1 min: 22%, 5 mins: 13%, 15 mins: 20%". The first number mean past minute and second number 22% means that in the past minute there have been, on average, 22% processes running or waiting for a resource.

Temperature

34° C

Device’s temperature

6.2 System Information

The System Information tab contains data that pertains to the routers operating system.

System explanation:

Field Name

Sample Value

Explanation

Free

79972 kB / 126556 kB (63%)

The amount of memory that is completely free. Should this rapidly decrease or get close to 0, it would indicate that the router is running out of memory, which could cause crashes and unexpected reboots.

Cached

15848 kB / 126556 kB (12%)

The size of the area of memory that is dedicated to storing frequently accessed data.

Buffered

5920 kB / 126556 kB (4%)

The size of the area in which data is temporarily stored before moving it to another location.

Field Name

Sample Value

Explanation

Data connection state

Connected

Mobile data connection status

IMEI

860461024350889

Modem's IMEI (International Mobile Equipment Identity) number

IMSI

246012101426458

IMSI (International Mobile Subscriber Identity) is used to identify the user in a cellular network

Memory explanation:

6.3 Network Information

6.3.1.1 Mobile

Display information about mobile modem connections.

Mobile information:

SIM card state

Ready

Indicates the SIM card's state, e.g. PIN required, Not inserted, etc.

Signal strength

-88 dBm

Received Signal Strength Indicator (RSSI). Signal's strength measured in dBm

Cell ID

2C86315

ID of operator cell that device is currently connected to

RSRP

-119 dBm

Indicates the Reference Signal Received Power

RSRQ

-11 dBm

Indicates the Reference Signal Received Quality

SINR

-1.2 dBm

Indicates the Signal to Interference plus Noise Ratio

10.

Operator

OMNITEL LT

Operator's name of the connected GSM network

11.

Operator state

Registered (home)

GSM network's status

12.

Connection type

4G (LTE)

Indicates the GSM network's access technology

13.

Bytes received

39.9 KB (40832 bytes)

How many bytes were received via mobile data connection

14.

Bytes sent

27.0 KB (27674 bytes)

How many bytes were sent via mobile data connection

6.3.1.2 WAN

Display information about WAN connection.

Field Name

Sample Value

Explanation

Interface

Wired

Specifies through what medium the router is connecting to the internet. This can either be Wired, Mobile or Wi-Fi.

Type

Static

Specifies the type of connection. This can either be static or DHCP.

IP address

192.168.99.69

The IP address that the routers uses to connect the internet.

WAN MAC

00:1E:42:00:00:01

MAC (Media Access Control) address used for communication in a Ethernet WAN (Wide Area Network)

Netmask*

255.255.255.0

Specifies a mask used to define how large the WAN network is

Gateway*

192.168.99.254

Indicates the default gateway, an address where traffic destined for the internet is routed to.

DNS*

8.8.8.8

Domain name server(s).

Connected*

1h 45m 27s

How long the connection has been successfully maintained.

Field Name

Sample Value

Explanation

Name

Lan

LAN instance name

IP address

192.168.99.218

Address that the router uses on the LAN network.

Netmask

255.255.255.0

A mask used to define how large the LAN network is

Ethernet MAC address

00:1E:42:00:00:00

MAC (Media Access Control) address used for communication in a Ethernet LAN (Local Area Network)

Connected for

1h 53m 56s

How long LAN has been successfully maintained.

WAN information:

*-These fields show up on other connection modes.

** - Exclusively to other Modes with DHCP.

6.3.1.3 LAN

Display information about LAN connections.

LAN information:

Field Name

Sample Value

Explanation

Hostname

DHCP client's hostname

IP address

192.168.99.120

Each lease declaration includes a single IP address that has been leased to the client

LAN name

Lan

LAN instance name

MAC address

D4:85:64:65:2B:D4

The MAC (Media Access Control) address of the network interface on which the lease will be used. MAC is specified as a series of hexadecimal octets separated by colons

Lease time remaining

10h 11m 13s

Remaining lease time for addresses handed out to clients

DHCP Leases

If you have enabled a DHCP server this field will show how many devices have received an IP address and what those IP addresses are.

6.3.1.4 Wireless

Wireless can work in two modes, Access Point (AP) or Station (STA). AP is when the wireless radio is used to create an Access Point that other devices can connect to. STA is when the radio is used to connect to an Access Point via WAN.

6.3.1.4.1 Station

Display information about wireless connection (Station mode).

Field Name

Sample Value

Explanation

Channel

1 (2.41 GHz)

The channel that the AP, to which the router is connected to, uses. Your wireless radio is forced to work in this channel in order to maintain the connection.

Country code

00 (World)

Country code.

SSID

Teltonika_Router

The SSID that the AP, to which the routers is connected to, uses.

Mode

Station (STA)

Connection mode – Client indicates that the router is a client to some local AP.

Encryption

no encryption

The AP, to which the router is connected to, dictates the type of encryption.

Wireless MAC

00:1E:42:10:80:22

The MAC address of the access points radio.

Signal Quality

61%

The quality between routers radio and some other device that is connecting to the router. Will show 0% if no devices are trying to connect or are currently maintaining a connection.

Bit rate

43.3 MBit/s

The physical maximum possible throughput that the routers radio can handle. Keep in mind that this value is cumulative - The bit rate will be shared between the router and other possible devices that connect to the local AP.

Client mode information

6.3.1.4.2 Access Point

Display information about wireless connection (Access Point mode).

Field Name

Sample Value

Explanation

Channel

11 (2.46 GHz)

The channel which is used to broadcast the SSID and to establish new connections to devices.

Country code

00(World)

Country code.

SSID

Teltonika_Router_Test

The SSID that is being broadcast. Other devices will see this and will be able to use to connect to your wireless network.

Mode

Access Point (AP)

Connection mode – Master indicates that you router is an access point.

Encryption

No Encryption

The type of encryption that the router will use to authenticate, establish and maintain a connection.

Wireless MAC

00:1E:42:00:00:03

MAC address of your wireless radio.

Signal Quality

80%

The quality between routers radio and some other device that is connecting to the router. Will show 0% if no devices are trying to connect or are currently maintaining a connection.

Bit rate

54.0 MBit/s

The bit rate will be shared between all devices that connect to the routers wireless network.

Field Name

Sample Value

Explanation

MAC Address

FC:C2:DE:91:36:A6

Associated station's MAC (Media Access Control) address

Device Name

Android-9aed2b2077a54c74

DHCP client's hostname

Signal

-54dBm

Received Signal Strength Indicator (RSSI). Signal's strength measured in dBm

RX Rate

24.0Mbit/s, MCS 0, 20MHz

The rate at which packets are received from associated station

TX Rate

54.0Mbit/s, MCS 0, 20MHz

The rate at which packets are sent to associated station

Wireless AP information

Additional note: MBit/s indicates the bits not bytes. To get the throughput in bytes divide the bit value by 8, for e.g. 54MBits/s would be 6.75MB/s (Mega Bytes per second).

6.3.1.5 Associated Stations

Outputs a list of all devices and their MAC addresses that are maintain a connection with your router right now.

This can either be the information of the Access Point that the router is connecting to in STA mode or a list of all devices that are connecting to the router in AP mode:

6.3.1.6 OpenVPN Client

Display OpenVPN connection information on client side.

Field Name

Sample Value

Explanation

Enabled

Yes/No

OpenVPN status

Status

Connected

Connection status

Type

Client

A type of OpenVPN instance that has been created

10.0.0.2

Remote virtual network's IP address

Mask

255.255.255.255

Remote virtual network's subnet mask

Time

0h 0m 13s

For how long the connection has been established

Field Name

Sample Value

Explanation

Enabled

Yes/No

OpenVPN status

Status

Connected

Connection status

Type

Server

A type of OpenVPN instance that has been created

10.0.0.1

Remote virtual network's IP address

Mask

255.255.255.255

Remote virtual network's subnet mask

Time

0h 3m 24s

For how long the connection has been established

Field Name

Sample Value

Explanation

Common Name

Test001

Client connection

Real Address

212.59.13.225:52638

Client’s IP address and port number

Virtual Address

10.0.0.6

Virtual address which has been given to a client

Connection Since

Thu May 05 2016 07:46:29 GMT + 0300 (FLE Standard Time)

Since when connection has been established

6.3.1.7 OpenVPN Server

Display OpenVPN connection information on server side.

6.3.1.8 Clients information

It will show information, when router is configured as OpenVPN TLS server.

Field Name

Sample Value

Explanation

Status

Enabled

VRRP status

Virtual IP

192.168.1.253

Virtual IP address(- es) for LAN’s VRRP (Virtual Router Redundancy Protocol ) cluster

Priority

100

Router with highest priority value on the same VRRP (Virtual Router Redundancy Protocol) cluster will act as a master, range [1 - 255]

Router**

Master

Connection mode – Master

6.3.1.9 VRRP

VRRP (Virtual Router Redundancy Protocol) for LAN

**-Exclusive to other Modes with Slave.

6.3.1.10 Topology

Network scanner allows you to quickly retrieve information about network devices. When router is configured to use Mobile as WAN and Connection type is selected „PPP“, then possible to scan only the LAN side.

Field Name

Sample Value

Explanation

Type

SSH; HTTP; HTTPS

Type of connection protocol

Status

Disabled/Enabled

Connection status

Port

22; 80; 443

Connection port used

Active Connections

0(0.00B);1(9.26 KB); 6(558.12 KB)

Count of active connections and amount of data transmitted in KB

6.3.1.11 Access

Display information about local and remote active connections status.

**-Exclusive to other Modes with Slave.

6.3.1.11.1 Last Connections

Displays information about local and remote last 3 connections status

Field Name

Sample Value

Explanation

Type

SSH; HTTP; HTTPS

Type of connection protocol

Date

2016-03-03, 13:40:59

Date and time of connection

192.168.2.10

IP address from which the connection was made

Authentications Status

Failed; Succeed

Status of authentication attempt

Field Name

Sample Value

Explanation

Serial number

02345678

Serial number of the device

Product code

RUT950101010

Product code of the device

Batch number

0222

Batch number used during device’s manufacturing process

Hardware revision

0321

Hardware revision of the device

IMEI

860461024164561

Identification number of the internal modem

IMSI

246020100070220

Subscriber identification number of the internal modem

Ethernet LAN MAC

3E:83:6F:84:E1:A4

MAC address of the Ethernet LAN ports

Ethernet WAN MAC

AE:F4:F3:5B:9D:CC

MAC address of the Ethernet WAN port

Wireless MAC

N/A

MAC address of the Wi-Fi interface

Model

ME909-521

Router’s modem model

10.

FW version

11.235.07.00.00

Router’s modem firmware version

6.4 Device information

The page displays factory information that was written into the device during manufacturing process.

Field Name

Sample Value

Explanation

IP Address

192.168.99.17

Recently cashed IP addresses of every immediate device that was communicating with the router

MAC Address

00:25:22:D7:CA:A7

Recently cached MAC addresses of every immediate device that was communicating with the router

Interface

br-lan

Interface used for connection

6.5 Services

The page displays usage of the available services.

6.6 Routes

The page displays ARP table and active IP routes of the device.

6.6.1 ARP

Show the routers active ARP table. An ARP table contains recently cached MAC addresses of every immediate device that was communicating with the router.

Field Name

Sample Value

Explanation

Network

ppp

Interface to be used to transmit TCP/IP packets through

Target

192.168.99.0/24

Indicates where a TCP/IP packet, with a specific IP address, should be directed

IP Gateway

0.0.0.0

Indicates through which gateway a TCP/IP packet should be directed

Metric

Metric number indicating interface priority of usage

Field Name

Sample Value

Explanation

Network

loopback

Network interface used

Target

0:0:0:0:0:0:0:0/0

Indicates where a TCP/IP packet, with a specific IP address, should be directed

IPv6-Gateway

0:0:0:0:0:0:0:0/0

Indicates through which gateway a TCP/IP packet should be directed

Metric

FFFFFFFF

Metric number indicating interface priority of usage

6.6.2 Active IP-Routes

Show the routers routing table. The routing table indicates where a TCP/IP packet, with a specific IP address, should be directed to.

6.6.3 Active IPv6-Routes

Display active IPv6 routes for data packet transition.

6.7 Graphs

Real-time graphs show how various statistical data changes over time.

6.7.1 Mobile Signal Strength

Displays mobile signal strength variation in time (measured in dBm)

Field Name

Sample Value

Explanation

Connection type

3G (WCDMA)

Type of mobile connection used

Signal

-72 dBm

Current signal strength value

Average

-72.0 dBm

Average signal strength value

Peak

-72 dBm

Peak signal strength value

6.7.2 Realtime Load

This tri-graph illustrates average CPU load values in real time. The graph consists out of three color coded graphs, each one corresponding to the average CPU load over 1 (red), 5 (orange) and 15 (yellow) most recent minutes.

Field Name

Sample Value

Explanation

1/5/15 Minutes Load

0.83

Time interval for load averaging, colour of the diagram

Average

0.86

Average CPU load value over time interval (1/5/15 Minute)

Peak

1.50

Peak CPU load value of the time interval

6.7.3 Realtime Traffic

This graph illustrates average system inbound and outbound traffic over the course of ~3 minutes; each new measurement is taken every 3 seconds. The graph consists out of two colors coded graphs (green graph shows the outbound traffic, blue graph shows inbound traffic). Although not graphed, the page also displays peak loads and average of inbound and outbound traffic.

Field Name

Explanation

Bridge

Cumulative graph, which encompasses wired Ethernet LAN and the wireless network.

LAN

Graphs the total traffic that passes through both LAN network interfaces.

WAN (Wired)

Graphs the amount of traffic which passed through the current active WAN connection.

Mobile

Graphs the amount of traffic which passed through the mobile network connection.

Wi-Fi

Shows the amount of traffic that has been sent and received through the wireless radio.

6.7.4 Realtime Wireless

Display the wireless radio signal, signal noise and theoretical maximum channel permeability. Average and peak signal levels are displayed.

6.7.5 Realtime Connections

Displays currently active network connections with the information about network, protocol, source and destination addresses, transfer speed.

Field Name

Sample Value

Explanation

Enable

Enable/Disable

Make a functionality active/inactive

Interval between records (sec)

The interval between logging records (minimum 60 sec)

6.8 Mobile Traffic

Displays mobile connection data sent and received in KB of this day, week, Month.

By default mobile traffic usage logging is disabled. To use this functionality is needed to enable it.

6.9 Speed Test

Speed test is a tool for measuring your internet connection upload and download speeds. You can select servers for manual testing, or use auto test.

6.10 Events Log

Event log displays such actions as: login, reboot, firmware flashing and reset.

6.10.1 All Events

Display all router events, their types and time of occurrence.

6.10.2 System Events

Display all system events, their type and time of occurrence. Events include authentication or reboot requests, incoming and outgoing SMS and calls, Mails, Configuration changes, DHCP events.

6.10.3 Network Events

Display information about recent network events like connection status change, lease status change, network type or operator change.

6.10.4 Events Reporting

Allow to view, enable/disable or modify created rules for events reporting.

6.10.4.1 Events Reporting Configuration

Allow to review created rules details and modify them, so after event occurrence, messages or emails are sent to specified address or phone numbers with information about the event.

Field Name

Sample Value

Explanation

Enable

Enable/Disable

Make a rule active/inactive

Event type

Reboot

Select event type about which occurrence information will be sent

Event subtype

After unexpected shut down

Specify event subtype to activate the rule

Event subtype

All/Loaded

Event subtype for which the rule is applied

Action

Send SMS

Action to perform when an event occurs

Enable delivery retry

Enable/Disable

Enables to send SMS again if first try to send SMS was unsuccessful.

Message text on Event

Router name - %rn; Event type - %et; Event text - %ex; Time stamp

- %ts;

Message text on specific event

Get status after reboot

Enable/Disable

Receive router status information after reboot

Recipient‘s

phone number

+123456789

For whom you want to send a SMS

6.10.5 Reporting Configuration

Displays configured services for event reporting, allows enabling, disabling, viewing and modifying parameters.

Field Name

Sample Value

Explanation

Enable

Enable/Disable

Make a rule active/inactive

Events log

System

Events log for which the rule is applied

Transfer type

FTP

Events log file transfer type: Email/FTP

Compress file

Enable

Enable/disable compress events log file using gzip

Host

192.168.123.12 3

FTP (File Transfer Protocol) host name, e.g. ftp.exemple.com,

192.168.123.123. Allowed characters (a-z-A-Z0-9!@#$%^&*+-/=?_`{|}~. )

User name

Username

User name for authentication on SMTP (Simple Mail Transfer Protocol) or FTP (File Transfer Protocol) server. Allowed characters (a-z-A-Z0-9!@#$%^&*+/=?_`{|}~. )

Password

password

Password for authentication on SMTP (Simple Mail Transfer Protocol) or FTP (File Transfer Protocol) server. Allowed characters (a-z-A-Z0-9!@#$%^&*+/=?_`{|}~. )

Interval between reports

Week

Send report every selected time interval

Weekday

Monday

Day of the week to get events log report

10.

Hour

Hour of the day to get events log report

6.10.5.1 Events Log Report Configuration

Allow to change the configuration of periodic events reporting to email or FTP.

FTP:

Field Name

Sample Value

Explanation

Enable

Enable/Disable

Make a rule active/inactive

Events log

System

Event log for which the rule is applied

Transfer type

Events log file transfer type: Email/FTP

Compress file

Enable

Enable/disable compress events log file using gzip

Subject

Subject of an email

Message

YourMessage

Message to send in email

SMTP server

smtp.gmail.com

SMTP (Simple Mail Transfer Protocol) server address

SMTP server port

SMTP (Simple Mail Transfer Protocol) server port

Secure connection

Enable/Disable

Enables/disables secure connection. Use only if server supports SSL or TLS

10.

User name

User

User name for authentication on SMTP (Simple Mail Transfer Protocol)

11.

Password

●●●●●●●

User password for authentication on SMTP (Simple Mail Transfer Protocol)

12.

Sender‘s email

address

sendersemail@ example.com

An address that will be used to send your email from. Allowed characters (a-zA-Z0-9._%+-)

13.

Recipient‘s

email address

recipientemail@ example.com

For whom you want to send an email to. Allowed characters (a-zA-Z0-

9._%+-)

14.

Interval between reboots

Week

Send report every select time interval

15.

Weekday

Sunday

Day of the week to get events log report

16.

Hour

Hour of the day to get events log report

Email:

Field Name

Sample value

Explanation

Connection type

PPP / NDIS

PPP mode uses dialling number to establish data connection. NDIS mode (default) does not use dialling and PPP protocol to establish data connection it is usually faster than PPP mode.

Mode

NAT / Passthrough / Use bridge

NAT mode enables network address translation on router. Bridge mode bridges LTE data connection with LAN. In this mode the router does not have internet connection as ISP provides IP directly to end device (PC, tablet or smart phone).Using Bridge mode will disable most of the router capabilities and you can access your router's settings only by using static IP address on your end device. Passthrough mode is similar with bridge mode except that in passthrough mode router does have internet connection.

APN

“APN”

Access Point Name (APN) is a configurable network identifier used by a mobile device when connecting to a GSM carrier.

PIN number

“1234” or any number

that falls between 0000 and 9999

A personal identification number is a secret numeric password shared between a user and a system that can be used to authenticate the user to the system.

Dialing number

*99***1#

Dialling number is used to establish a mobile PPP (Point-to-PointProtocol) connection.

Authentication method

CHAP, PAP or none

Authentication method, which your carrier uses to authenticate new connections. (This selection is unavailable on the alternate model)

Username

“username”

Your username that you would use to connect to your carriers network. This field becomes available when you select an authentication method (i.e. authentication method is not “none”). These fields are always enabled on the alternate model.

Password

“password”

Your password that you would use to connect to your carriers network. This field becomes available when you select an authentication method (i.e. authentication method is not “none”).

7 Network

7.1 Mobile

7.1.1 General

7.1.1.1 Mobile configuration

Here you can configure mobile settings which are used when connecting to your local 3G/LTE network.

These fields are always enabled on the alternate model.

Service mode

2G only, 2G preferred, 3G only, 3G preferred, 4G (LTE) only, 4G (LTE) preferred or automatic.

Your network preference. If your local mobile network supports 2G, 3G and 4G (LTE) you can specify to which network you wish to connect. E.g.: if you choose 2G, the router will connect to a 2G network, so long as it is available, otherwise it will connect to a network that provides better connectivity. If you select auto, then the router will connect to the network that provides better connectivity.

10.

Deny data roaming

Enable/Disable

If enabled this function prevents the device from establishing mobile data connection while not in home network.

11.

Use IPv4 only

Enable / Disable

If enabled this function makes the device to use only IPv4 settings when connecting to operator.

Warning: If an invalid PIN number was entered (i.e. the entered PIN does not match the one that was used to protect the SIM card), your SIM card will get blocked. To avoid such mishaps it is highly advised to use an unprotected SIM. If you happen to insert a protected SIM and the PIN number is incorrect, your card won’t get blocked immediately, although after a couple of reboots OR configuration saves it will.

7.1.1.1.1 Passthrough mode

Using Passthrough Mode will disable most of the router capabilities!

DHCP mode: Static

Enter your computer MAC address (xx:xx:xx:xx:xx:xx) to MAC Address field and select Lease time (expire time for lease addresses). Device, which MAC address will be entered, will get IP from GSM operator. Other connected devices to the router LAN will get IP from router DHCP server, but these devices will not have internet access.

DHCP mode: Dynamic

Using Dynamic mode, device will get IP from GSM operator , which connect to the router firstly. Using Passthrough in dynamic mode, the DHCP in LAN will be disabled.

DHCP mode: No DHCP

Using no DHCP mode, IP (also subnet, gateway and DNS) from GSM operator should be entered in device, which is connected to the router LAN, manually. Using Passthrough in no DHCP mode, the DHCP in LAN will be disabled.

Field name

Possible values

Explanation

Enable

Enable/Disable

Mobile Data On Demand function enables you to keep mobile data connection on only when it's in use

No data timeout(sec)

1-99999999

A mobile data connection will be terminated if no data is transferred during the timeout period

Field name

Possible values

Explanation

Enable

Enable/Disable

Enable/disable try to connect to LTE network every x seconds (used only if service mode is set to 4G (LTE) preferred)

Reregister

Enable/Disable

If this enabled, modem will be reregister before try to connect to LTE network

Interval (sec)

180 - 3600

Time in seconds between tries to connect to LTE network. Range [180-3600]

7.1.1.2 Mobile Data On Demand

7.1.1.3 Force LTE network

Field name

Possible values

Explanation

Primary SIM card

SIM 1 / SIM 2

SIM card that will be used in the system as a primary SIM card

Enable automatic switching

Enable/Disable

Automatically switch between primary and secondary SIM cards based on the various rules and criterions defined below

Check interval

1-3600

Check interval in seconds

On weak signal

Enable/Disable

Perform a SIM card switch when a signal's strength drops below a certain threshold

On data limit*

Enable/Disable

Perform a SIM card switch when mobile data limit for your current SIM card is exceeded

On SMS limit*

Enable/Disable

Perform a SIM card switch when SMS limit for your current SIM card is exceeded

On roaming

Enable/Disable

Perform a SIM card switch when roaming is detected

No network

Enable/Disable

Perform a SIM card switch when no operator is detected

On network denied

Enable/Disable

Perform a SIM card switch when network is denied

10.

On data connection fail

Enable/Disable

Perform a SIM card switch when data connection fails

7.1.2 SIM Management

* Your carrier's data usage accounting may differ. Teltonika is not liable should any accounting discrepancies occur.

Field Name

Sample Value

Explanation

SIM card in use

SIM 1 / SIM 2

Shows current SIM card’s in use

Current operator

OMNITEL LT

Operator's name of the connected GSM network

7.1.3 Network Operators

7.1.3.1 Network Operators

This function lets you Scan, Select and enter manual Network Operator to which router should connect. Function will provide great utility when router is in Roaming conditions. Operator is selected only for the active SIM card. In order to specify operator for the other SIM card it must first be selected as primary SIM in “SIM Management”.

Note: after clicking Scan for operators’ button- You will lose current mobile connection! For changing network operator

status have to be available. There is manual connection to network operator, you have to fill numeric name, and it’s

have to be available.

Field name

Possible values

Explanation

Enable

Enable/Disable

Enable/disable operators blocking

Mode

White list/Black list

White list - allows every operator on the list and blocks everything else. Black list – block every operator on the list and allow everything else

Name

Tele2 LT

Operator’s name

Operator code

24603

Operator’s code

Field Name

Sample value

Explanation

Enable data connection limit

Enable/Disable

Disables mobile data when a limit for current period is reached

Data limit* (MB)

200

Disable mobile data after limit value in MB is reached

Period

Month/Week/Day

Period for which mobile data limiting should apply

Start day/ Start hour

A starting time for mobile data limiting period

7.1.3.2 Operator List

This function lets to create white list/black list based on operator’s code.

7.1.4 Mobile Data Limit

This function lets you limit maximum amount of data transferred on WAN interface in order to minimize unwanted traffic costs.

7.1.4.1 Data Connection Limit Configuration

* Your carrier's data usage accounting may differ. Teltonika is not liable should any accounting discrepancies occur.

Field Name

Sample value

Explanation

Enable

Enable/Disable

Enables SIM idle protection

Period

Month / Week

Switches between monthly and weekly SIM activation periods

Day

1-31 / Monday Sunday

Specifies the day for SIM idle protection activation, 1-31 if Period is Month, and Monday – Sunday if period is week.

Hour

1-24

Specifies the hour for SIM idle protection activation

Minute

1-60

Specifies the minute for SIM idle protection activation

Host to ping

8.8.8.8

Specifies IP address or domain name to send data packages to

Ping package size

Specifies ping Package size in bytes

Ping requests

Specifies requests to be sent

Field Name

Sample value

Explanation

Enable SMS warning

Enable/Disable

Enables sending of warning SMS message when mobile data limit for current period is reached

Data limit* (MB)

300

Send warning SMS message after limit value in MB is reached

Period

Month/Week/Day

Period for which mobile data limiting should apply

Start day/ Start hour

A starting time for mobile data limiting period

Phone number

+37012345678

A phone number to send warning SMS message to, e.g. +37012345678

7.1.4.2 SMS Warning Configuration

* Your carrier's data usage accounting may differ. Teltonika is not liable should any accounting discrepancies occur.

7.1.5 SIM Idle protection

Some operators block user SIM cards after period of inactivity. This function enables router to periodically switch to secondary SIM card and establish data connection with mobile network in order to prevent SIM card blocking.

7.1.5.1 Settings

Field Name

Sample value

Explanation

SIM

SIM1 / SIM2

Displays SIM number

SIM state

OK (inserted)

Displays status of the SIM card

Host IP

8.8.8.8

Displays the IP of the Host

Ping

Success

Displays status of ping attempt

Type

Explanation

Main WAN

Switches between Mobile, Wired and Wi-Fi interface for main WAN

Backup WAN/Load balancing

Let’s user to select one or two interfaces for WAN backup

Interface Name

Displays WAN interface name, and changes interface priority, the interface at the table top has the highest priority

Protocol

Displays protocol used by WAN interface

IP Address

Displays IP address acquired by specific interface

Sort

Sorts table rows and changes interface priority, the highest interface has highest priority

7.1.5.2 Test

Tests the functioning of idle protection with your parameters entered at settings tab.

7.2 WAN

7.2.1 Operation Mode

Your WAN configuration determines how the router will be connecting to the internet.

Filed name

Sample

Explanation

IPv4 address

192.168.99.162

Your routers address on the WAN network

IPv4 netmask

255.255.255.0

A mask used to define how “large” the WAN network is

IPv4 gateway

192.168.99.254

Address where the router will send all the outgoing traffic

IPv4 broadcast

192.168.99.255

Broadcast address (auto generated if not set). It is best to leave this blank unless you know what you are doing.

Use custom DNS servers

8.8.8.8

8.8.6.6

Usually the gateway has some predefined DNS servers. As such the

router, when it needs to resolve a hostname (“www.google.com”, “www.cnn.com”, etc…) to an IP address, it will forward all the DNS

requests to the gateway. By entering custom DNS servers the router will take care of host name resolution. You can enter multiple DNS servers to provide redundancy in case the one of the server fails.

7.2.2 Common configuration

Common configuration allows you to configure your TCP/IP settings for the wan network.

You can switch between the Static, DHCP or PPPoE protocol by selecting the protocol that you want to use and then pressing Switch Protocol.

7.2.2.1 General Setup

7.2.2.1.1 Static:

This is the configuration setup for when you select the static protocol.

Filed name

Sample

Explanation

PAP/CHAP username

test

Your username and password that you would use to connect to your carriers network.

PAP/CHAP password

your_password

A mask used to define how “large” the WAN network is

Access Concentrator

auto

Specifies the name of access concentrator. Leave empty to auto detect.

Service Name

auto

Specifies the name of the service. Leave empty to auto detect.

7.2.2.1.2 DHCP:

When you select the DHCP protocol you can use it as is, because most networks will not require any additional advanced configuration.

7.2.2.1.3 PPPoE

This protocol is mainly used by DSL providers:

This is the configuration setup for when you select PPPoE protocol.

7.2.2.2 Advanced

These are the advanced settings for each of the protocols, if you are unsure of how to alter these attributes it is highly recommended to leave them to a trained professional:

Field name

Sample value

Explanation

Disable NAT

On/Off

Toggle NAT on and off.

Override MAC address

86:48:71:B7:E9:E4

Override MAC address of the WAN interface. If your ISP gives you a static IP address it might also bind it to your computers MAC address (i.e. that IP will only work with your computer). In this field you can enter your computers MAC address and fool the gateway in thinking that it is communicating with your computer.

Override MTU

1500

Maximum Transmission Unit – specifies the largest possible size of a data packet.

Use gateway metric

The WAN configuration by default generates a routing table entry. With this field you can alter the metric of that entry.

Field name

Sample value

Explanation

Disable NAT

Enable/Disable

If checked, router will not perform NAT (masquerade) on this interface

Use broadcast flag

Enable/Disable

Required for certain ISPs, e.g. Charter with DOCSIS 3

Use default gateway

Enable/Disable

If unchecked, no default route is configured

Use DNS server advertised by peer

Enable/Disable

If unchecked, the advertised DNS server addresses are ignored

User gateway metric

The WAN configuration by default generates a routing table entry

7.2.2.2.1 Static

7.2.2.2.2 DHCP

With this field you can alter the metric of that entry

Client ID to send when requesting DHCP

Specify client ID which will be sent when requesting DHCP (Dynamic Host Configuration Protocol)

Vendor Class to send when requesting DHCP

Specify vendor class which be sent when requesting DHCP (Dynamic Host Configuration Protocol)

Override MAC address

86:48:71:B7:E9:E4

Override MTU

1500

Maximum transmission unit – specifies the largest possible size of a data packet.

Field name

Sample value

Explanation

Disable NAT

Enable/Disable

If checked, router will not perform NAT (masquerade) on this interface

Use default gateway

Enable/Disable

If unchecked, no default route is configured

Use gateway metric

Use DNS servers advertised by peer

Enable/Disable

If unchecked, the advertised DNS server addresses are ignored

LCP echo failure threshold

Presume peer to be dead after given amount of LCP echo failures, use 0 to ignore failures

LCP echo interval

Send LCP echo requests at the given interval in seconds, only effective in conjunction with failure threshold

Inactivity timeout

Close inactive connection after the given amount of seconds, use 0 to persist connection

7.2.2.2.3 PPPoE

7.2.2.2.4 IP Aliases

IP aliases are a way of defining or reaching a subnet that works in the same space as the regular network.

As you can see, the configuration is very similar to the static protocol; only in the example a 99th subnet is defined. Now if some device has an IP in the 99 subnet (192.168.99.xxx) and the subnets gateway metric is “higher” and

the device is trying to reach the internet it will reroute it’s traffic not to the gateway that is defined in common

configurations but through the one that is specified in IP aliases.

You may also optionally define a broadcast address and a custom DNS server.

7.2.2.2.5 Backup WAN configuration

Backup WAN is function that allows you to back up your primary connection in case it goes down. There can be two backup connections selected at the same time, in that case, when primary connection fails, router tries to use backup with higher priority and if that is unavailable or fails too, then router tries the backup with lower priority.

The majority of the options consist of timing and other important parameters that help determine the health of your primary connection. Regular health checks are constantly performed in the form of ICMP packets (Pings) on your primary connection. When the connections state starts to change (READY->NOT READY and vice versa) a necessary amount of failed or passed health checks has to be reached before the state changes completely. This delay is instituted

so as to mitigate “spikes” in connection availability, but it also extends the time before the backup link can be brought

up or down.

Field Name

Sample value

Explanation

Health monitor Interval

Disable/5/10/20/30/60/120 Seconds

The interval at which health checks are performed

Health monitor ICMP host(s)

Disable/DNS Server(s) /WAN GW/Custom

Where to Ping for a health check. As there is no definitive way to determine when the connection

to internet is down for good, you’ll have to define

a host whose availability that of the internet as a whole.

Health monitor ICMP timeout

1/3/4/5/10 Seconds

How long to wait for an ICMP request to come back. Set a higher value if your connection has high latency or high jitter (latency spikes).

Attempts before failover

1/3/5/10/15/20

How many checks should fail for your WAN connection to be declared DOWN for good.

Attempts before recovery

1/3/5/10/15/20

How many checks should pass for your WAN connection to be declared UP.

7.2.2.3 How do I set up a backup link?

First we must select a main link and choose one or two backup links in WAN section. Then push the “Edit” button

and configure your WAN and Backup Wan settings to your liking. Click Save and wait until the settings are applied. Now in the Status -> Network Information -> WAN page there should be a status indication for the backup WAN. If everything is working correctly you should see something like this:

The above picture shows the status for Backup WAN configured on a wired main link. You can now simulate a downed link by simply unplugging your Ethernet WAN cable. When you’ve done so you should see this:

And, if you plug the cable back in you should, again, see this:

Field name

Sample value

Explanation

IP address

192.168.1.1

Address that the router uses on the LAN network

IP netmask

255.255.255.0

A mask used to define how large the LAN network is

IP broadcast

IP broadcasts are used by BOOTP and DHCP clients to find and send requests to their respective servers

Field name

Sample value

Explanation

Accept router advertisements

Enable/Disable

If enabled allows accepting router advertisements (Disabled by default)

Override MTU

1500

MTU (Maximum Transmission Unit) specifies the largest possible size of a data packet

Use gateway metric

With this field you can alter the metric of that entry

Use WAN port as LAN

Enable/Disable

Enable/disable WAN port using as LAN port

7.3 LAN

This page is used to configure the LAN network, where all your devices and computers that you connect to the router will reside.

7.3.1 Configuration

7.3.1.1 General Setup

7.3.1.2 Advanced settings

Field Name

Sample value

Explanation

DHCP

Enable / Disable/ DHCP Relay

Manage DHCP server

Start

100

The starting address of the range that the DHCP server can use to give out to devices. E.g.: if your LAN IP is 192.168.2.1 and your subnet mask is 255.255.255.0 that means that in your network a valid IP address has to be in the range of [192.168.2.1 – 192.168.2.254](192.168.2.0 and 192.168.2.255 are special unavailable addresses). If the Start value is set to 100 then the DHCP server will only be able to lease out addresses starting from 192.168.2.100

Limit

150

How many addresses the DHCP server gets to lease out. Continuing on the above example: if the start address is 192.168.2.100 then the end address will be

192.168.2.254 (100 + 150 – 1 = 254).

Lease time

How long can a leased IP be considered valid. An IP address after the specified amount of time will expire and the device that leased it out will have to request for a new one. Select Hour or Minute (minimum 2min).

7.3.2 DHCP Server

The DHCP server is the router side service that can automatically configure the TCP/IP settings of any device that requests such a service. If you connect a device that has been configured to obtain IP address automatically the DHCP server will lease an IP address and the device will be able to fully communicate with the router.

7.3.2.1 General Setup

Field Name

Sample Value

Explanation

Dynamic DHCP

Checked/Unchecked

Dynamically allocate client addresses, if set to 0 only clients present in the ethers files are served

Force

Checked/Unchecked

Forces DHCP serving even if another DHCP server is detected on the same network segment.

IP netmask

You can override your LAN netmask here to make the DHCP server think it’s serving a larger or a smaller network than it actually is.

DHCP Options

Additional options to be added for this DHCP server. For example with '26,1470' or 'option:mtu, 1470' you can assign an MTU per DHCP. Your client must accept MTU by DHCP for this to work.

Field Name

Sample Value

Explanation

Hostname

Printer

Name which will be linked with IP address.

MAC address

10:a5:d0:70:9c:72 (192.168.1.104)

Device MAC address

IP address

192.168.1.104

Device IP address

7.3.2.2 Advanced settings

You can also define some advanced options that specify how the DHCP server will operate on your LAN network.

7.3.2.3 Static Leases

This page is used to configure static IP leases.

7.3.2.4 IP Aliases

7.3.2.4.1 General Setup

IP aliases are the way of defining or reaching a subnet that works in the same space as the regular network.

7.3.2.4.2 Advanced Settings

You may also optionally define a broadcast address and a custom DNS server.

7.4 Wireless

On this page you can configure your wireless settings. Depending on whether your WAN mode is set to Wi-Fi or not, the page will display either the options for configuring an Access Point or options for configuring a connection to some local access point.

Access Point:

Here you can see the Overview of the wireless configuration. It is divided into two main sections – device and interface. One is dedicated to configuring hardware parameters other – software.

Here you can toggle the availability of the wireless radio and the physical channel frequency.

Important note: As seen in the picture you should always Save before toggling the radio on and off.

SSID – Your wireless networks identification string. This is the name of your Wi-Fi network. When other Wi-Fi capable computers or devices scan the area for Wi-Fi networks they will see your network with this name.

Hide SSID – Will render your SSID hidden from other devices that try to scan the area.

Connect to WRP100 automatically – let Teltonika WRP100 wireless repeater connect to this router automatically.

Field name

Sample value

Explanation

Mode

Auto, b, g, g+n

Different modes provide different throughput and security options.

Country Code

Any ISO/IEC 3166 alpha2 country code

Selecting this will help the wireless radio configure its internal parameters to meet your countries wireless regulations.

Transmit power

20%/40%/60%/80%/100%

Select Wi-Fi signal power

Fragmentation threshold

2346

The smallest packet size that can be fragmented and transmitted by multiple frames. In areas were interference is a problem, setting a lower fragment threshold might help reduce the probability of unsuccessful packet transfers, thus increasing speed.

RTS/CTS Threshold

2346

Request to send threshold. It can help resolve problems arising when several access points are in the same area, contending.

7.4.1.1 Device

7.4.1.1.1 Advanced Settings

Here you can configure more advanced parameters:

7.4.1.2 Interface

7.4.1.2.1 Security

Encryption – there are many modes of encryption, a distinctive classis pointed out below.

First select an encryption method: TKIP, CCMP, TKIP&CCMP and auto. Note: Some authentication methods won’t support TKIP (and TKIP&CCMP) encryption. After you’ve selected your encryption method, you should enter your pass

phrase, which must be at least 8 characters long.

7.4.1.2.2 MAC-Filter

Filter – you can define a rule for what to do with the MAC list you’ve defined. You can either allow only the listed MACs or allow ALL, but forbid only the listed ones.

7.4.1.2.3 Advanced settings

Separate clients – prevents Wi-Fi clients from communicating with each other on the same subnet.

Increase TTL packet size – increase TTL packet size for incoming packets.

7.4.1.3 Client

RUT9xx can work as a Wi-Fi client. Client mode is nearly identical to AP, except for the fact that most for the options are dictated by the wireless access point that the router is connecting to. Changing them can result in an interrupted connection to an AP.

In addition to standard options you can also click the Scan button to rescan the surrounding area and attempt to connect to a new wireless access point.

Field Name

Sample Value

Explanation

VLAN mode

Disabled / Port based / Tag based

Lets user to choose the VLAN mode or disable VLAN functionality.

Field Name

Sample Value

Explanation

VLAN ID

VLAN Identification number, allowed in range (1-4094)

LAN ports 1 / 2 / 3

Switches each LAN port between ON, OFF or tagged state.

Wireless access points

Enabled / Disabled

Assign selected access point(s) to selected LAN.

LAN

None

Select to which LAN to assign selected LAN ports and wireless access points.

7.5 VLAN

On this page you can configure your Virtual LAN settings, either Port based or Tag based.

7.5.1 VLAN Networks

7.5.1.1 VLAN Functionality

7.5.1.2 VLAN Network List

If VLAN mode – Port based:

Field Name

Sample Value

Explanation

VLAN ID

VLAN Identification number, allowed in range (1-4094)

Wireless access points

Enabled / Disabled

Assign selected access point(s) to selected LAN.

LAN

None

Select to which LAN to wireless access point(s).

Field Name

Sample Value

Explanation

LAN name

Lan

Specifies new LAN name

Interface name

eth0 tap0

Specifies LAN interface name

If VLAN mode – Tag based:

7.5.2 LAN Networks

In this page you can create extra LAN networks, and assign them with LAN Ports and wireless access points. You can get extra information on how to configure any of your LAN’s settings in section – 7.3 LAN

7.6 Firewall

In this section we will look over the various firewall features that come with RUT9.

7.6.1 General Settings

The routers firewall is a standard Linux iptables package, which uses routing chains and policies to facilitate control over inbound and outbound traffic.

Field Name

Sample value

Explanation

Drop Invalid packets

Checked/Unchecked

A “Drop” action is performed on a packet that is determined to be invalid

Input

Reject/Drop/Accept

DEFAULT* action that is to be performed for packets that pass through the Input chain.

Output

Reject/Drop/Accept

DEFAULT* action that is to be performed for packets that pass through the Output chain.

Forward

Reject/Drop/Accept

DEFAULT* action that is to be performed for packets that pass through the Forward chain.

*DEFAULT: When a packet goes through a firewall chain it is matched against all the rules for that specific chain. If no rule matches said packet, an according Action (either Drop or Reject or Accept) is performed.

Accept – Packet gets to continue down the next chain.

Drop – Packet is stopped and deleted.

Reject – Packet is stopped, deleted and, differently from Drop, an ICMP packet containing a message of rejection is sent to the source of the dropped packet.

7.6.2 DMZ

By enabling DMZ for a specific internal host (for e.g.: your computer), you will expose that host and its services to the routers WAN network (i.e. - internet).

Field Name

Sample value

Explanation

Name

Enable_SSH_WAN_PASSTHROUGH

Name of the rule. Used purely to make it easier to manage rules.

Protocol

TCP/UDP/TCP+UDP/Other

Type of protocol of incoming packet.

External Port

1-65535

From this port on the WAN network the traffic will be forwarded.

Internal IP address

IP address of some computer on your LAN

The IP address of the internal machine that hosts some service that we want to access from the outside.

Internal port

1-65535

To that port on the internal machine the rule will redirect the traffic.

7.6.3 Port Forwarding

Here you can define your own port forwarding rules.

You can use port forwarding to set up servers and services on local LAN machines. The above picture shows how you can set up a rule that would allow a website that is being hosted on 192.168.1.109, to be reached from the outside by entering http://routersExternalIp:12345/.

When you click edit you can fine tune a rule to near perfection, if you should desire that.

Field Name

Sample value

Explanation

Name

ENABLE_SSH_WAN_PASSTHROUGH

Name of the rule. Used purely to make it easier to manage rules.

Protocol

TCP/UDP/TCP+ UDP/ICMP/Custom

You may specify multiple by selecting (custom) and then entering protocols separated by space

Source zone

LAN/VPN/WAN

Match incoming traffic from this zone only

Source MAC address

any

Match incoming traffic from these MACs only

Source IP address

any

Match incoming traffic from this IP or range only

Source port

any

Match incoming traffic originating from the given source port or port range on the client host only

External IP address

any

Match incoming traffic directed at the given IP address only

External port

Match incoming traffic directed at the given destination port or port range on this host only

10.

Internal zone

LAN/VPN/WAN

Redirect matched incoming traffic to the specified internal zone

11.

Internal IP address

127.0.0.1

Redirect matched incoming traffic to the specified internal host

12.

Internal port

any

Redirect matched incoming traffic to the given port on the internal host

13.

Enable NAT loopback

Enable/Disable

NAT loopback enables your local network (i.e. behind your router/modem) to connect to a forward-facing IP address (such as 208.112.93.73) of a machine that it also on your local network

14.

Extra arguments

Passes additional arguments to iptables. Use with care!

Field Name

Explanation

Name

Name of the rule. Used for easier rules management purpose only

Protocol

Protocol type of incoming or outgoing packet

Source

Match incoming traffic from this IP or range only

Destination

Redirect matched traffic to the given IP address and destination port

Action

Action to be taken for the packet if it matches the rule

Enable

Self-explanatory. Uncheck to make the rule inactive. The rule will not be deleted, but it also will not be loaded into the firewall.

Sort

When a packet arrives, it gets checked for a matching rule. If there are several rules that match the rule, the first one is applied i.e. the order of the rule list impacts how your firewall operates, therefore you are given the ability to sort your list as you wish.

7.6.4 Traffic Rules

The traffic rule page contains a more generalized rule definition. With it you can block or open ports, alter how traffic is forwarded between LAN and WAN and many more things.

You can configure firewall rule by clicking edit button.

Field Name

Sample value

Explanation

Name

“Allow-DHCP-Relay”

Used to make rule management easier

Restrict to address family

IPv4 and IPV6

Match traffic from selected address family only

Protocol

TCP/UDP/Any/ICMP/Custom

Protocol of the packet that is being matched against traffic rules.

Match ICMP type

any

Match traffic with selected ICMP type only

Source zone

any zone/LAN/VPN/WAN

Match incoming traffic from this zone only

Source MAC address

any

Match incoming traffic from these MACs only

Source address

any

Match incoming traffic from this IP or range only

Source port

any

Match incoming traffic originating from the given source port or port range on the client host only

Destination zone

Device/Any zone/LAN/VPN/WAN

Match forwarded traffic to the given destination zone only

10.

Destination address

any

Match forwarded traffic to the given destination IP address or IP range only

11.

Destination port

Match forwarded traffic to the given destination port or port range only

12.

Action

Drop/Accept/Reject + chain + additional rules

Action to be taken on the packet if it matches the rule. You can also define additional options like limiting packet volume, and defining to which chain the rule belongs

Field Name

Sample value

Explanation

Name

Open_Port_rule

Used to make rule management easier

Protocol

TCP/UDP/Any/ICMP/Custom

Protocol of the packet that is being matched against traffic rules.

External port

1-65535

Match incoming traffic directed at the given destination port or port range on this host.

Field Name

Sample value

Explanation

Name

Forward rule new

Used to make rule management easier

Source

LAN/VPN/WAN

Match incoming traffic from selected address family only

Protocol

TCP/UDP/Any/ICMP/Custom

Protocol of the packet that is being matched against traffic rules.

7.6.4.1 Open Ports On the Router

7.6.4.2 New Forward Rule

7.6.4.3 Source NAT

Source NAT is a specific form of masquerading which allows fine grained control over the source IP used for outgoing traffic, for example to map multiple WAN addresses to internal subnets.

Field Name

Sample value

Explanation

Name

SNAT

Used to make rule management easier

Protocol

TCP/UDP/Any/ICMP/Custom

Protocol of the packet that is being matched against traffic rules.

Source

LAN/VPN/WAN

Match incoming traffic from selected address family only

Destination

LAN/VPN/WAN

Forward incoming traffic to selected address family only

SNAT

Rewrite to source IP 10.101.1.10

SNAT (Source Network Address Translation) rewrite packet\'s source IP address and port

Enable

Enable/Disable

Make a rule active/inactive

Field Name

Sample value

Explanation

Name

SNAT

Used to make rule management easier

Protocol

TCP/UDP/Any/ICMP/Custom

Protocol of the packet that is being matched against traffic rules.

Source zone

LAN/VPN/WAN

Match incoming traffic from this zone only

Source MAC address

any

Match incoming traffic from these MACs only

Source address

any

Match incoming traffic from this IP or range only

Source port

any

Match incoming traffic originating from the given source port or port range on the client host only

Destination zone

LAN/VPN/WAN

Match forwarded traffic to the given destination zone only

Destination IP address

Select from the list

Match forwarded traffic to the given destination IP

You can configure firewall source NAT rule, by clicking edit button.

address or IP range only

Destination port

any

Match forwarded traffic to the given destination port or port range only

10.

SNAT IP address

“10.101.1.10”

Rewrite matched traffic to the given IP address

11.

SNAT port

“22”

Rewrite matched traffic to the given source port. May be left empty to only rewrite the IP address'

12.

Extra arguments

Passes additional arguments to iptables. Use with care!

7.6.5 Custom Rules

Here you have the ultimate freedom in defining your rules – you can enter them straight into the iptables program. Just type them out into the text field ant it will get executed as a Linux shell script. If you are unsure of how to use iptables, check out the internet for manuals, examples and explanations.

7.6.6 DDOS Prevention

7.6.6.1 SYN Flood Protection

SYN Flood Protection allows you to protect from attack that exploits part of the normal TCP three-way handshake to consume resources on the targeted server and render it unresponsive. Essentially, with SYN flood DDoS, the offender sends TCP connection requests faster than the targeted machine can process them, causing network saturation.

Field Name

Sample value

Explanation

Enable SYN flood protection

Enable/Disable

Makes router more resistant to SYN flood attacks.

SYN flood rate

“25”

Set rate limit (packets/second) for SYN packets above which the traffic is considered a flood.

SYN flood burst

“50”

Set burst limit for SYN packets above which the traffic is considered a flood if it exceeds the allowed rate.

TCP SYN cookies

Enable/Disable

Enable the use of SYN cookies (particular choices of initial TCP sequence numbers by TCP servers).

Field Name

Sample value

Explanation

Enable ICMP requests

Enable/Disable

Blocks remote ICMP echo-request type

Enable ICMP limit

Enable/Disable

Enable ICMP echo-request limit in selected period

Limit period

Second/Minute/Hour/Day

Select in what period limit ICMP echo-request

Limit

“10”

Maximum ICMP echo-request during the period

Limit burst

“5”

Indicating the maximum burst before the above limit kicks in.

7.6.6.2 Remote ICMP requests

Attackers are using ICMP echo request packets directed to IP broadcast addresses from remote locations to generate denial-of-service attacks.

Field Name

Sample value

Explanation

Enable SSH limit

Enable/Disable

Enable SSH connections limit in selected period

Limit period

Second/Minute/Hour/Day

Select in what period limit SSH connections

Limit

“10”

Maximum SSH connections during the period

Limit burst

“5”

Indicating the maximum burst before the above limit kicks in.

Field Name

Sample value

Explanation

Enable HTTP limit

Enable/Disable

Limits HTTP connections per period

Limit period

Second/Minute/Hour/Day

Select in what period limit HTTP connections

Limit

“10”

Maximum HTTP connections during the period

Limit burst

“10”

Indicating the maximum burst before the above limit kicks in.

7.6.6.3 SSH Attack Prevention

Prevent SSH (Allows a user to run commands on a machine's command prompt without them being physically present near the machine.) attacks by limiting connections in defined period.

7.6.6.4 HTTP Attack Prevention

HTTP attack sends a complete, legitimate HTTP header, which includes a 'Content-Length' field to specify the size of the message body to follow. However, the attacker then proceeds to send the actual message body at an extremely slow rate (e.g. 1 byte/110 seconds). Due to the entire message being correct and complete, the target server will attempt to obey the 'Content-Length' field in the header, and wait for the entire body of the message to be transmitted, hence slowing it down.

Field Name

Sample value

Explanation

Enable HTTPS limit

Enable/Disable

Limits HTTPS connections per period

Limit period

Second/Minute/Hour/Day

Select in what period limit HTTPS connections

Limit

“10”

Maximum HTTPS connections during the period

Limit burst

“10”

Indicating the maximum burst

Field Name

Sample value

Explanation

Enable

Enable/Disable

Enable port scan prevention

Interval

Time interval in seconds counting how much port scan (10 – 60 sec.)

Scan count

How much port scan before blocked

7.6.6.5 HTTPS Attack Prevention

7.6.7 Port Scan Prevention

7.6.7.1 Port Scan

Field Name

Explanation

SYN-FIN attack

Protect from SYN-FIN attack

SYN-RST attack

Protect from SYN-RST attack

X-Mas attack

Protect from X-Mas attack

FIN scan

Protect from FIN scan

NULLflags attack

Protect from NULLflags attack

7.6.7.2 Defending type

7.7 Routing

7.7.1 Static Routes

Static routes specify over which interface and gateway a certain host or network can be reached.

Field name

Value

Explanation

Routing table

MAIN/WAN/WAN2/WAN3

Defines the table to use for the route

Interface

MAIN/WAN/WAN2/WAN3

The zone where the target network resides

Destination address

IP address

The address of the destination network

Netmask

IP mask

Mask that is applied to the Target to determine to what actual IP addresses the routing rule applies

Gateway

IP address

To where the router should send all the traffic that applies to the rule

Metric

integer

Used as a sorting measure. If a packet about to be routed fits two rules, the one with the higher metric is applied.

192.168.55.161

255.255.255.255

Only applies to 192.168.55.161

192.168.55.0

255.255.255.0

Applies to IPs in range 192.168.55.0-192.168.55.255

192.168.55.240

255.255.255.240

Applies 192.168.55.240 - 192.168.55.255

192.168.55.161

255.255.255.0

192.168.55.0 - 192.168.55.255

192.168.0.0

255.255.0.0

192.168.0.0 - 192.168.255.255

Field name

Value

Explanation

Enable

Enable/Disable

Enable dynamic routes

Router ID

192.168.1.1

Router’s ID

Additional note on Target & Netmask: You can define a rule that applies to a single IP like this: Target - some IP; Netmask - 255.255.255.255. Furthermore you can define a rule that applies to a segment of IPs like this: Target – some IP that STARTS the segment; Netmask – Netmask that defines how large the segment is. E.g.:

7.7.2 Dynamic Routes

7.7.2.1 General

Dynamic routes provide dynamic routing which enables router to select paths according to real-time logical network layout changes.

Field name

Value

Explanation

Enable

Enable/Disable

Enables OSPF protocol

Stub

Enable/Disable

Enable/Disable stub

RFC1583 compatibility

Enable/Disable

Enables OSPF compatibility with RFC1583 specification

Import

All/None/custom

Set if the protocol must import routes

Export

All/None/custom

Set if the protocol must export routes

Field name

Value

Explanation

Area name

OSPF_area

OSPF area’s name

Enable

Yes/No

Enable/disable OSPF area

7.7.2.2 OSPF Protocol

7.7.2.2.1 OSPF General Instance

7.7.2.2.2 OSPF Area

The OSPF network can be divided into sub-domains called areas.

To see at specific configuration settings press “edit” button located in newly created OSPF area. A new page with detailed configuration appears, as shown in the picture below.

Field name

Value

Explanation

Enabled

Enable/Disable

Enable specific OSPF area

Stub

Enable/Disable

Enable/disable stub

Interface

br-lan

A interface that new instance will have

New IP

Name of the new OSPF network configuration. Used for easer configurations management purpose only

7.7.2.3 General Protocol

Field name

Value

Explanation

Enable

Enable/Disable

Enable/Disable settings

Learn

Enable/Disable

Enables routes learning

Persist

Enable/Disable

If checked it allows to store routes. After a restart, routes will be still configured

Scan time

Time between scans

Import

All

Set if the protocol must import routes

Export

All

Set if the protocol must export routes

Enable

Enable/Disable

If checked the protocol will not be configured

Scan time

Time between scans

Field name

Explanation

Prefix

Protocol prefix of incoming or outgoing packet

Type

Protocol type of incoming or outgoing packet

7.7.2.3.1 Static Routes

7.8 Load Balancing

Load balancing lets users divide traffic between different interfaces.

Field name

Sample

Explanation

Enable

Enable/Disable

Enable VRRP (Virtual Router Redundancy Protocol) for LAN

IP address

192.168.1.253

Virtual IP address for LAN's VRRP (Virtual Router Redundancy Protocol) cluster

Virtual ID

Routers with same IDs will be grouped in the same VRRP (Virtual Router Redundancy Protocol) cluster, range [1-255]

Priority

100

Router with highest priority value on the same VRRP (Virtual Router Redundancy Protocol) cluster will act as a master, range [1-255]

Field name

Sample

Explanation

Enable

Enable/Disable

Enable WAN's connection monitoring

Ping IP address

8.8.4.4

A host to send ICMP (Internet Control Message Protocol) packets to

Ping interval

Time interval in seconds between two Pings

Ping timeout (sec)

Response timeout value, interval [1 - 9999]

Ping packet size

ICMP (Internet Control Message Protocol) packet's size, interval [0 1000]

Ping retry count

100

Failed Ping attempt’s count before determining that connection is lost, interval [1 – 9999]

8 Services

8.1 VRRP

8.1.1 VRRP LAN Configuration Settings

8.1.2 Check Internet connection

Field name

Sample

Explanation

Enable

Enable/Disable

Enable TR-069 client

Enable Periodic Transmission

Enable / Disable

Enable periodic transmissions of data to server

User name

admin

User name for authentication on TR-069 server

Password

*******

Password for authentication on TR-069 server

URL

http://192.168.1.110:8080

TR-069 server URL address

8.2 TR-069

TR-069 is a standard developed for automatic configuration and management of remote devices by Auto Configuration Servers (ACS).

8.2.1 TR-069 Parameters Configuration

8.3 Web filter

8.3.1 Site blocking

Field name

Sample

Explanation

Enable

Enable/Disable

Enable host name based websites blocking

Mode

Whitelist/Blacklist

Whitelist - allow every site on the list and block everything else. Blacklist block every site on the list and allow everything else.

Enable

Enable/Disable

Check to enable site blocking

Host name

www.yahoo.com

Block/allow site with this hostname

Field name

Sample

Explanation

Enable

Enable/Disable

Enable proxy server based URL content blocking. Works with HTTP protocol only

Mode

Whitelist/Blacklist

Whitelist - allow every part of URL on the list and block everything else. Blacklist - block every part of URL on the list and allow everything else

URL content

example.com

Block/allow any URL containing this string. Example.com, example.*, *.example.com

8.3.2 Proxy Based Content Blocker

Field name

Description

Current System time

Local time of router.

Time zone

Time zone of your country.

Enable NTP

Enable system’s time synchronization with time server using NTP (Network Time

Protocol)

Update interval

How often router updates systems time

Save time to flash

Save last synchronized time to flash memory

Count of time synchronizations

Total amount of times that router will do the synchronization. Note: If left blank - the count will be infinite

Offset frequency

Adjust the minor drift of the clock so that it will be more accurate

8.4 NTP

NTP configuration lets you setup and synchronize routers time.

Note, that under Time Servers at least one server has to be present, otherwise NTP will not serve its purposes.

8.5 VPN

8.5.1 OpenVPN

VPN (Virtual Private Network) is a method for secure data transfer through unsafe public network. This section explains how to configure OpenVPN, which is implementation of VPN supported by the RUT9 router.

A picture below demonstrates default OpenVPN configurations list, which is empty, so you have to define a new configuration to establish any sort of OpenVPN connection. To create it, enter desired configuration name in “New configuration name” field, select device role from “Role” drop down list. For example, to create an OpenVPN client with configuration name demo, select client role, name it “demo” and press “Add New” button as shown in the following picture.

To see at specific configuration settings press “edit” button located in newly created configuration entry. A new page with detailed configuration appears, as shown in the picture below (TLS client example).

Field name

Explanation

Enabled

Switches configuration on and off. This must be selected to make configuration active.

TUN/TAP

Selects virtual VPN interface type. TUN is most often used in typical IP-level VPN connections, however, TAP is required to some Ethernet bridging configurations.

Protocol

Defines a transport protocol used by connection. You can choose here between TCP and UDP.

Port

Defines TCP or UDP port number (make sure, that this port allowed by firewall).

LZO

This setting enables LZO compression. With LZO compression, your VPN connection will

There can be multiple server/client instances.

You can set custom settings here according to your VPN needs. Below is summary of parameters available to set:

generate less network traffic; however, this means higher router CPU loads. Use it carefully with high rate traffic or low CPU resources.

Encryption

Selects Packet encryption algorithm.

Authentication

Sets authentication mode, used to secure data sessions. Two possibilities you have here:

“Static key” means, that OpenVPN client and server will use the same secret key, which must be uploaded to the router using “Static pre-shared key” option. “TLS” authentication mode

uses X.509 type certificates. Depending on your selected OpenVPN mode (client or server) you have to upload these certificates to the router: For client: Certificate Authority (CA), Client certificate, Client key. For server: Certificate Authority (CA), Server certificate, Server key and Diffie-Hellman (DH) certificate used to key exchange through unsafe data networks. All mention certificates can be generated using OpenVPN or Open SSL utilities on any type host machine. Certificate generation and theory is out of scope of this user manual.

TLS cipher

Packet encryption algorithm (cipher)

Remote host/IP address

IP address of OpenVPN server (applicable only for client configuration).

10.

Resolve Retry

Sets time in seconds to try resolving server hostname periodically in case of first resolve failure before generating service exception.

11.

Keep alive

Defines two time intervals: one is used to periodically send ICMP request to OpenVPN server, and another one defines a time window, which is used to restart OpenVPN service, if no ICPM request is received during the window time slice. Example Keep Alive “10 60”

12.

Remote network IP address

IP address of remote network, an actual LAN network behind another VPN endpoint.

13.

Remote network IP netmask

Subnet mask of remote network, an actual LAN network behind another VPN endpoint.

14.

Max routes

Allow a maximum number of routes to be pulled from an OpenVPN server

15.

HMAC authentication algorithm

Sets HMAC authentication algorithm

16.

Additional HMAC authentication

Add an additional layer of HMAC authentication on top of the TLS control channel to protect against DoS attacks

17.

Certificate authority

Certificate authority is an entity that issues digital certificates. A digital certificate certifies the ownership of a public key by the named subject of the certificate.

18.

Client certificate

Client certificate is a type of digital certificate that is used by client systems to make authenticated requests to a remote server. Client certificates play a key role in many mutual authentication designs, providing strong assurances of a requester's identity.

19.

Client key

Authenticating the client to the server and establishing precisely who they are

After setting any of these parameters press “Save” button. Some of selected parameters will be shown in the configuration list table. You should also be aware of the fact that router will launch separate OpenVPN service for every configuration entry (if it is defined as active, of course) so the router has ability to act as server and client at the same time.

8.5.2 IPSec

The IPsec protocol client enables the router to establish a secure connection to an IPsec peer via the Internet. IPsec is supported in two modes - transport and tunnel. Transport mode creates secure point to point channel between two hosts. Tunnel mode can be used to build a secure connection between two remote LANs serving as a VPN solution.

Field name

Value

Explanation

Enable

Enabled/Disabled

Check box to enable IPSec.

IKE version

IKEv1 or IKEv2

Method of key exchange

Mode

“Main” or “Aggressive”

ISAKMP (Internet Security Association and Key Management Protocol) phase 1 exchange mode

My identifier type

Address, FQDN, User FQDN

Choose one accordingly to your IPSec configuration

My identifier

Set the device identifier for IPSec tunnel. In case RUT has Private IP, its identifier should be its own LAN network address. In this way, the Road Warrior approach is possible.

Dead Peer

Enabled/Disabled

The values clear, hold and restart all active DPD

IPsec system maintains two databases: Security Policy Database (SPD) which defines whether to apply IPsec to a packet or not and specify which/how IPsec-SA is applied and Security Association Database (SAD), which contain Key of each IPsec-SA.

The establishment of the Security Association (IPsec-SA) between two peers is needed for IPsec communication. It can be done by using manual or automated configuration.

Note: router starts establishing tunnel when data from router to remote site over tunnel is sent. For automatic tunnel establishment used tunnel Keep Alive feature.

Detection

Pre shared key

A shared password to authenticate between the peer

Remote VPN endpoint

Domain name or IP address. Leave empty or any

IP address/Subnet mask

Remote network secure group IP address and mask used to determine to what subnet an IP address belongs to. Range [0-32]. IP should differ from device LAN IP

10.

Enable keep alive

Enabled/Disabled

Enable tunnel keep alive function

11.

Host

A host address to which ICMP (Internet Control Message Protocol) echo requests will be send

12.

Ping period (sec)

Send ICMP echo request every x seconds. Range [0-999999]

Field name

Value

Explanation

Encryption algorithm

DES, 3DES, AES 128, AES 192, AES256

The encryption algorithm must match with another incoming connection to establish IPSec

Authentication

MD5, SHA1, SHA256, SHA384, SHA512

The authentication algorithm must match with another incoming connection to establish IPSec

Hash algorthm

MD5, SHA1, SHA256, SHA384, SHA512

The hash algorithm must match with another incoming connection to establish IPSec

DH group

MODP768, MODP1024, MODP1536, MODP2048, MODP3072, MODP4096

The DH (Diffie-Helman) group must with another incoming connection to establish IPSec

PFS group

MODP768, MODP1024, MODP1536, MODP2048, MODP3072, MODP4096, No PFS

The PFS (Perfect Forward Secrecy) group must match with another incoming connection to establish IPSec

Lifetime

Hours, Minutes, Seconds

The time duration for phase

Phase 1 and Phase 2 must be configured accordingly to the IPSec server configuration, thus algorithms, authentication and lifetimes of each phase must be identical.

8.5.3 GRE Tunnel

GRE (Generic Routing Encapsulation RFC2784) is a solution for tunneling RFC1812 private address-space traffic over an intermediate TCP/IP network such as the Internet. GRE tunneling does not use encryption it simply encapsulates data and sends it over the WAN.

In the example network diagram two distant networks LAN1 and LAN2 are connected.

To create GRE tunnel the user must know the following parameters:

1. Source and destination IP addresses.

2. Tunnel local IP address

3. Distant network IP address and Subnet mask.

Field name

Explanation

Enabled

Check the box to enable the GRE Tunnel function.

Remote endpoint IP address

Specify remote WAN IP address.

Remote network

IP address of LAN network on the remote device.

Remote network netmask

Network of LAN network on the remote device. Range [0-32].

Local tunnel IP

Local virtual IP address. Cannot be in the same subnet as LAN network.

Local tunnel netmask

Network of local virtual IP address. Range [0-32]

MTU

Specify the maximum transmission unit (MTU) of a communications protocol of a layer in bytes.

TTL

Specify the fixed time-to-live (TTL) value on tunneled packets [0-255]. The 0 is a special value meaning that packets inherit the TTL value.

PMTUD

Check the box to enable the Path Maximum Transmission Unit Discovery (PMTUD) status on this tunnel.

10.

Enable Keep alive

It gives the ability for one side to originate and receive keep alive packets to and from a remote router even if the remote router does not support GRE keep alive.

11.

Keep Alive host

Keep Alive host IP address. Preferably IP address which belongs to the LAN network on the remote device.

12.

Keep Alive interval

Time interval for Keep Alive. Range [0 - 255].

Field name

Explanation

Enable

Check the box to enable the PPTP function.

Local IP

IP Address of this device (RUT)

Remote IP range begin

IP address leases beginning

Remote IP range end

IP address leases end

Username

Username to connect to PPTP (this) server

Password

Password to connect to PPTP server

User IP

Users IP address

8.5.4 PPTP

Point-to-Point Tunneling Protocol (PPTP) is a protocol (set of communication rules) that allows corporations to extend their own corporate network through private "tunnels" over the public Internet. Effectively, a corporation uses a wide-area network as a single large local area network. A company no longer needs to lease its own lines for wide-area communication but can securely use the public networks. This kind of interconnection is known as a virtual private network (VPN).

Field name

Explanation

Enable

Enable current configuration

Use as default gateway

Use this PPTP instance as default gateway

Server

The server IP address or hostname

Username

The user name for authorization with the server

Password

The password for authorization with the server

Field name

Explanation

Enable

Check the box to enable the L2TP Tunnel function.

Local IP

IP Address of this device (RUT)

Remote IP range begin

IP address leases beginning

Remote IP range end

IP address leases end

Username

Username to connect to L2TP (this) server

Password

Password to connect to L2TP server

8.5.5 L2TP

Allows setting up a L2TP server or client. Below is L2TP server configuration example.

Client configuration is even simpler, which requires only Servers IP, Username and Password.

Field name

Value

Explanation

Enable

Enable/Disable

Enables current DDNS configuration.

Status

Timestamp of the last IP check or update.

Service

1. dydns.org

2. 3322.org

3. no-ip.com

4. easydns.com

5. zoneedit.com

Your dynamic DNS service provider selected from the list. In case your DDNS provider is not present from the ones provided, please feel free to use "custom" and add hostname of the update URL.

Hostname

yourhost.example.org

Domain name which will be linked with dynamic IP address.

Username

your_username

Name of the user account.

Password

your_password

Password of the user account.

IP Source

Public

This option allows you to select specific RUT interface, and then send

8.6 Dynamic DNS

Dynamic DNS (DDNS) is a domain name service allowing to link dynamic IP addresses to static hostname.

To start using this feature firstly you should register to DDNS service provider (example list is given in description).

You are provided with add/delete buttons to manage and use different DDNS configurations at the same time!

You can configure many different DDNS Hostnames in the main DDNS Configuration section.

To edit your selected configuration, hit Edit.

Private Custom

the IP address of that interface to DDNS server. So if, for example, your RUT has Private IP (i.e. 10.140.56.57) on its WAN (3G interface), then you can send this exact IP to DDNS server by selecting "Private", or by selecting "Custom" and "WAN" interface. The DDNS server will then resolve hostname queries to this specific IP.

Network

WAN

Source network

IP renew interval (min)

10 (minutes)

Time interval (in minutes) to check if the IP address of the device have changed.

10.

Force IP renew

472 (minutes)

Time interval (in minutes) to force IP address renew.

8.7 SMS Utilities

RUT950 has extensive amount of various SMS Utilities. These are subdivided into 6 sections: SMS Utilities, Call Utilities, User Groups, SMS Management, Remote Configuration and Statistics.

8.7.1 SMS Utilities

All configuration options are listed below:

- Reboot

- Get status

- Get OpenVPN status

- Switch WiFi on/off

- Switch mobile data on/off

- Change mobile data settings

- Get list of profiles

- Change profile

- Manage OpenVPN

- SSh access control

- Web access control

- Restore to default

- Force SIM switch

- FW upgrade from server

- Config update from server

- Switch monitoring on/off

Field name

Explanation

Notes

Reboot

Enable

This check box will enable and disable SMS reboot function.

Allows router restart via SMS.

Action

The action to be performed when this rule is met.

SMS text

SMS text which will reboot router.

SMS text can contain letters, numbers, spaces and special symbols. Capital letters also matters.

Authorization method

What kind of authorization to use for SIM management.

No authorization, by serial or by router admin password.

Allowed users

Whitelist of allow users

From all numbers, from group or from single number.

Get status via SMS after reboot

Check this to recieve connection status via SMS after a reboot.

If you select this box, router will send status once it has rebooted and is operational again. This is both separate SMS Rule and an option under SMS Reboot rule.

Message text

Which status information should be included in SMS: Data state, Operator, Connection type, Signal Strength, Connection State, IP

You can select which status elements to display.

Get status

You can choose your SMS Keyword (text to be sent) and authorized phone number in the main menu. You can edit each created rule by hitting Edit button.

Enable

Check this to receive connection status via SMS.

Allows to get router‘s status via SMS. This is both

separate SMS Rule and an option under SMS Reboot rule.

Action

The action to be performed when this rule is met.

Enable SMS Status

This check box will enable and disable SMS status function.

SMS status is disabled by default.

SMS text

SMS text which will send routers status.

SMS text can contain letters, numbers, spaces and special symbols. Capital letters also matters.

Authorization method

What kind of authorization to use for SIM management.

No authorization, by serial or by router admin password.

Allowed users

Whitelist of allow users

From all numbers, from group or from single number.

Message text

Which status information should be included in SMS: Data state, Operator, Connection type, Signal Strength, Connection State, IP

You can select which status elements to display.

Get OpenVPN status

Enable

This check box will enable and disable this function.

Allows to get OpenVPN‘s status via SMS.

Action

The action to be performed when this rule is met.

SMS text

SMS text which will send OpenVPN status.

SMS text can contain letters, numbers, spaces and special symbols. Capital letters also matters.

Authorization method

What kind of authorization to use for SIM management.

No authorization, by serial or by router admin password.

Allowed users

Whitelist of allow users

From all numbers, from group or from single number.

Switch WiFi On/Off

Enable

This check box will enable and disable this function.

Allows Wi-Fi control via SMS.

Action

The action to be performed when this rule is met.

Turn WiFi ON or OFF.

SMS text

SMS text which will turn Wi-Fi ON/OFF.

SMS text can contain letters, numbers, spaces and special symbols. Capital letters also matters.

Authorization method

What kind of authorization to use for SIM management.

No authorization, by serial or by router admin password.

Allowed users

Whitelist of allow users

From all numbers, from group or from single number.

Write to config

Permanently saves Wi-Fi state.

With this setting enabled, router will keep Wi-Fi state even after reboot. If it is not selected, router will revert Wi-Fi state after reboot.

Switch mobile data on/off

Enable

This check box will enable and disable this function.

Allows mobile control via SMS.

Action

The action to be performed when this rule is met.

Turn mobile ON or OFF.

SMS text

SMS text which will turn mobile data ON/OFF.

SMS text can contain letters, numbers, spaces and special symbols. Capital letters also matters.

Authorization method

What kind of authorization to

No authorization, by serial or by router admin

100
