Quick Manual
v1.6
Easy OBDII tracker
FMB002
2
FMB002 | Wiki
Table of Contents
Know your device .......................................................................... 3
Pinout ................................................................................................. 4
Set up your device ......................................................................... 5
How to insert Micro-SIM card and connect the battery ................ 5
PC Connection (Windows) ................................................................ 6
How to install USB drivers (Windows) ............................................. 6
Configuration (Windows) ................................................................. 6
Quick SMS configuration .................................................................. 8
Mounting recommendations ....................................................... 9
LED indications ............................................................................ 10
Basic characteristics ................................................................... 10
Safety information ...................................................................... 13
Certification and Approvals ....................................................... 14
Warranty ...................................................................................... 15
Warranty Disclaimer ....................................................................... 15
3
FMB002 | Wiki
Know your device
Figure 1 FMB002 device view
4
FMB002 | Wiki
Pinout
Table 1 OBDII pinout
PIN NUMBER
PIN NAME
DESCRIPTION
2
PWM_BUS+/VPW
4
GND (-)
Ground
5
GND (-)
Ground
6
CAN_H
CAN high
7
K-Line
10
PWM_BUS-
14
CAN_L
CAN low
15
L-Line
16
VCC (10 - 30) V DC (+)
Power supply (+10-30 V DC)
Figure 2 FMB002 OBDII socket pinout
5
FMB002 | Wiki
Set up your device
How to insert Micro-SIM card and
connect the battery
1. Open the top cover of the device. Cover is opened by unclipping
it at the recessed corner.
2. Insert Nano-SIM card as shown with PIN request disabled or
read our Wiki how to enter it later in Teltonika Configurator.
Make sure that Nano-SIM card is fitted properly into the holder.
3. Connect the battery as shown to device.
4. After configuration, see “PC Connection (Windows)”, attach
device cover back.
Device is ready to be mounted.
Figure 4 Device case removal
Figure 3 Nano-SIM card insert
Figure 6 Battery connection
Figure 5 Attach device cover back
