Outdoor CPE8000
Installation and Configuration Guide V1.0
Page 1
Table of contents
1. OVERVIEW ................................................................................................................................................ 4
1.1. USER INTERFACE SPECIFICATION ......................................................................................................... 4
1.2. LTE INTERFACE SPECIFICATION ........................................................................................................... 4
2. GETTINGSTARTED ................................................................................................................................. 4
2.1. PACKING LIST AND CPE UNIT ............................................................................................................... 4
2.2. INSTALLING THE EQUIPMENT ................................................................................................................. 5
Device logic connection
Installing Outdoor Unit (ODU)
LED Display
3. MANAGING CPE DEVICE ...................................................................................................................... 8
3.1. WEB LOGIN--192.168.0.1 ................................................................................................................... 8
3.2. LTE STATUS DISPLAY-OVERVIEW ........................................................................................................ 8
3.3. LTE CONFIGURATION .......................................................................................................................... 10
......................................................................................................................................... 7
Radio Settings-ND&S Configure
APN Setting-Bearer configure
3.4. ENODEB SELECTION ........................................................................................................................... 12
PLMN Selection
eNodeB Setting
3.5. NETWORK CONFIGURATION ................................................................................................................ 14
................................................................................................................................. 12
................................................................................................................................. 13
Modify MTU Size
Change model from Router to Bridge
3.6. SERVICE CONFIGURATION-DMZ SETTING .......................................................................................... 16
3.7. SYSTEM MAINTENANCE ....................................................................................................................... 16
...................................................................................................................... 5
........................................................................................................... 6
..................................................................................................... 10
......................................................................................................... 10
............................................................................................................................... 14
............................................................................................ 15
Telnet Enable
TR069 Configuration
Firmware Upgrade over HTTP
Change Password
Load Factory Default
4. FAQ AND TROUBLESHOOTING......................................................................................................... 20
..................................................................................................................................... 16
......................................................................................................................... 17
........................................................................................................ 18
............................................................................................................................. 19
........................................................................................................................ 19
Page 2
PLEASE READ THESE SAFETY PRECAUTIONS!
RF Energy Health Hazard
The radio equipment described in this guide uses radio frequency transmitters. Although the
power level is low, the concentrated energy from a directional antenna may pose a health
hazard.
Do not allow people to come in close proximity to the front of the antenna while the transmitter is
operating.
Protection from Lightning
Before connecting this instrument to the power line, make sure that the voltage of the power
source matches the requirements of the instrument. The unit must be standards.
Disposal and Recycling Information
Pursuant to the WEEE EU Directive electronic and electrical waste must not be disposed of
with unsorted waste.Please contact your local recycling authority for disposal of this product.
Reduction of Hazardous Substances
This CPE is compliant with the EU Registration, Evaluation, Authorisation and Restriction
ofChemicals (REACH) Regulation (Regulation No 1907/2006/EC of the European Parliament
and of the Council) and the EU Restriction of Hazardous Substances (RoHS)
Directive(Directive 2002/95/EC of the European Parliament and of the Council).
FCC Notice, USA
The CPE8000 units comply with Part 25 of the FCC rules. Operation is subject to the following two
conditions:
• This device may not cause harmful interference.
• This device must accept any interference received including interference that may cause undesired
operation.
This device is specifically designed to be used under Part 15, Subpart E of the FCC Rules and
Regulations. Any unauthorized modification or changes to this device may void the user’s authority to
operate this device.
Furthermore, this device is intended to be used only when installed in accordance with the instructions
outlined in this manual. Failure to comply with these instructions may also void the user’s authority to
operate this device and/or the manufacturer’s warranty.
The grantee is not responsible for any changes or modifications not expressly approved by the party
responsible for compliance. Such modifications could void the user’s authority to operate the equipment.
Page 3
Model
Description & User Interface
ODU
1. Overview
The ODU is a high performance 4G LTE outdoor CPE product designed
to enable quick LTE fixed data service deployment to the remote
customers. It provides high data throughput and networking features to
end users who need both bandwidth and quality service in the remote
area.
1.1. User Interface Specification
- Panel antenna:
B3_7 14dBi, B20 7dBi, B38_40_41 13dBi, B42_43 15dBi
- 1 RJ45 10/100M LAN Port
- PWR, RUN, LAN, SIM, LTE(1-5) LEDs
- 48 VDC PoE supply, ODU Power <10 Watts
- Dimensions: 203 mm (L) × 203 mm (W) × 76.5 mm (D)
- Weight: < 2 Kg
1.2. LTE Interface Specification
Frequency Bands Band 3_7 / 20 / 38_40_41 / 42_43
Radio Access 3GPP LTE Release9
Operation Mode TDD, 2RX, 1TXD, DLMIMO
Output Power Up to 23 dBm at antenna port
Throughput Category 4
SIM Support SIM card slot
2. GettingStarted
2.1. Packing list and CPE Unit
Page 4
Upon receiving the product, please unpack the product package carefully. Each product is shipped with
Outdoor CPE Products
Quantity
the following items:
Table 2-1 Packing List
ODU unit 1
Power adapter 1
Power Line 1
Mounting brackets 1
PC Ethernet Cable 1
If you find any of the items is missing, please contact our local distributor immediately.
CPE Unit：
Unpacking the Equipment Table 2-1 lists all the standard parts that are supplied in your LTE CPE
Unit Installation Package. Please take the time to unpack the package and check its contents
against this list.
2.2. Installing the Equipment
Device logic connection
For outdoor CPE product, it is suggested that the CPE device be installed in a shaded area to
avoid direct sun light exposure which may cause over heat in certain extreme weather condition.
The CPE should be properly grounded for proper protection against lighting or power surge.
To power on the device, the outdoor CPE must uses a 48V PoE integrated DC power supply
adapter. The power adapters can operate in 90-250V AC range and therefore can be used in
different country. Once the device is powered up, the user should wait for about 2 minutes before
Page 5
the device becomes operational. For CPE with the RUN LED indicator, a slowly flashing light
indicates the system has completed the startup procedure.
To connect PC, LAN switch or other type of IP device to the CPE product, the user should use
standard CAT5 Ethernet cable and connect to the appropriate LAN port. Once connect the CPE
LAN LED indicator should come on.
Installing Outdoor Unit (ODU)
Mounting Bracket::
Header Connection:
Page 6
