LX210 Push Button Dialer Users Manual
1
Programming The LX210 Push Button Dialer
Default Program Password
#0* (This can be changed via register 70)
Programming Prompts
(beeps)
1 beep = register
valid continue
entry.
2 beeps = dialer
accepted program
entry.
4 beeps = error
in
programming.
Note
The dialer must finish dialing before entering programming mode.
If there is no dial string set, wait until “busy tone”, then enter #0*.
Programming:
To program the LX210 connect a telephone with a keypad to the same line as the dialer.
Pick up the telephone then push the button and wait for the short busy tone and enter
program password #0* using the telephone keypad and wait for the beep. You are now
in program mode and may program any of the below registers.
Example: Dialer will dial 5551212 when button is pushed.
1. Lift telephone handset and push button.
2. Wait for short busy tone.
3. Dial #0* to enter program mode
4. Dial 01 and wait for beep (Register 01 DIAL OUT STRING 1)
5. Dial 5551212 ## and wait for beep
6. Dial 20 and wait for beep (Register 20 DIAL INSTRUCTIONS)
7. Dial 62 (makes dialer pause for 2 seconds)
8. Dial 1 (makes dialer dial out contents of register 1) in this case 5551212
9. Dial 60 (makes dialer pause 10 seconds then hangs up)
10. Dial ## and wait for beep.
11. Dial ** (exits programming)
12. Done
Copyright Telongo LLC.2009 | www.telongo.com
www.telongo.com
LX210 Push Button Dialer Users Manual
2
REGISTER 70
PROGRAM ACCESS CODE
Default = #0*
1 = 1
5 = 5
9 = 9
#2 = A
Max Entry = 16
2 = 2
6 = 6
0 = 0
#3 = B
3 = 3
7 = 7
* = *
#4 = C
4 = 4
8 = 8
#1 = #
#5 = D
**Important Note** This program register must be sealed with a ##
Example
00 123 ## This sets the program access code to 123
Description
This allows the user to change the default program access code
User Notes
REGISTER 01
DIAL OUT STRING 1
Default =
Empty
1 = 1
5 = 5
9 = 9
#2 = A
Max Entry = 16
2 = 2
6 = 6
0 = 0
#3 = B
3 = 3
7 = 7
* = *
#4 = C
4 = 4
8 = 8
#1 = #
#5 = D
**Important Note** This program register must be sealed with a ##
Example
01 12086391595 ## This sets dial string 1 to 12086391595
Description
Must be indicated to dial in Register 20.
User Notes
Copyright Telongo LLC.2009 | www.telongo.com
www.telongo.com
LX210 Push Button Dialer Users Manual
3
REGISTER 02
DIAL OUT STRING 2
Default =
Empty
1 = 1
5 = 5
9 = 9
#2 = A
Max Entry = 16
2 = 2
6 = 6
0 = 0
#3 = B
3 = 3
7 = 7
* = *
#4 = C
4 = 4
8 = 8
#1 = #
#5 = D
**Important Note** This program register must be sealed with a ##
Example
02 12086391595 ## This sets dial string 2 to 12086391595.
Description
Must be indicated to dial in Register 20.
REGISTER 03
DIAL OUT STRING 3
Default =
Empty
1 = 1
5 = 5
9 = 9
#2 = A
Max Entry = 16
2 = 2
6 = 6
0 = 0
#3 = B
3 = 3
7 = 7
* = *
#4 = C
4 = 4
8 = 8
#1 = #
#5 = D
**Important Note** This program register must be sealed with a ##
Example
03 12086391595 ## This sets dial string 3 to 12086391595.
Description
Must be indicated to dial in Register 20.
User Notes
Copyright Telongo LLC.2009 | www.telongo.com
www.telongo.com
LX210 Push Button Dialer Users Manual
4
REGISTER 04
DIAL OUT STRING 4
Default =
Empty
1 = 1
5 = 5
9 = 9
#2 = A
Max Entry = 16
2 = 2
6 = 6
0 = 0
#3 = B
3 = 3
7 = 7
* = *
#4 = C
4 = 4
8 = 8
#1 = #
#5 = D
**Important Note** This program register must be sealed with a ##
Example
04 12086391595 ## This sets dial string 4 to 12086391595
Description
Must be indicated to dial in Register 20.
User Notes
REGISTER 10
DTMF INTERVAL
Default = 3
1 = 50ms
5 = 90ms
9 = 130ms
#2= 170ms
2 = 60ms
6 = 100ms
0 = 140ms
#3 = 180ms
3 = 70ms
7 = 110ms
* = 150ms
#4 = 190ms
4 = 80ms
8 = 120ms
# 1= 160ms
#5 = 200ms
Example
10 4 This sets the dtmf dial interval to 80ms.
Description
Dtmf interval is the rate the dialer out pulses dtmf tones to the local
office exchange or other chosen network or carrier.
User Notes
Copyright Telongo LLC.2009 | www.telongo.com
www.telongo.com
LX210 Push Button Dialer Users Manual
5
REGISTER 20
DIAL INSTRUCTIONS
Default =
Empty
* Max digit entry for this register is 16
* This Register must be sealed with a ##
Command
Description
1
Dial String 1
2
Dial String 2
3
Dial String 3
4
Dial String 4
7
Dial Serial Number
5x
Dials DTMF Digit (x) See table below for (x) definition
<Example>
19 = Dial Dtmf
9
1 = DTMF 1
5 = DTMF 5
9 = DTMF 9
#2 = DTMF A
2 = DTMF 2
6 = DTMF 6
0 = DTMF 0
#3 = DTMF B
3 = DTMF 3
7 = DTMF 7
* = DTMF *
#4 = DTMF C
4 = DTMF 4
8 = DTMF 8
#1 = DTMF #
#5 = DTMF D
6x
Pause for (x) Seconds See table below for (x) definition
1 = 1 second
6 = 6 seconds
* = 11 seconds
2 = 2 seconds
7 = 7 seconds
#1 = 12 seconds
3 = 3 seconds
8 = 8 seconds
4 = 4 seconds
9 = 9 seconds
5 = 5 seconds
0 = 10 seconds
Example
20 61 1 61 5#1 5#1 ##
Description
Dialer will go off hook, pause 1 second, dial string 1 (Register 1), pause
1 second, dial a DTMF ##, hang up.
User Notes
Copyright Telongo LLC.2009 | www.telongo.com
www.telongo.com
LX210 Push Button Dialer Users Manual
6
REGISTER 99
SET TO FACTORY DEFAULTS
Example
99 1 Defaults dialer database
Description
This defaults the dialer back to factory settings.
User Notes
REGISTER **
EXIT PROGRAM MODE
**
** Exits programming mode and hangs up the dialer.
Example
** Exits program mode.
Description
This exits program mode
User Notes
