If you have purchased your Tv405 with factory fitted
leg option, carefully turn the amplifier upside down and
screw in the supplied 4 legs hand tight only,
As you return the unit to the upright position be very
careful not to let the legs touch the ground until the
unit is fully upright [this will avoid unnecessary strain on
the fixing brackets and leg posts].
Once the legs are fitted the amplifier should not be moved
Please be aware that leads could pull the unit over, do not
apply force to the lead and always steady the amplifier
when inserting or removing leads.
WARNING
Under no circumstances retro fit legs to this unit
Your guarantee will be void and the unit may become
very dangerous, For many reasons the legs supplied
have been tested to meet special standards and are not
interchangeable or retro-fittable.
Fuse T1A
IEC Mains INLET
Use only supplied lead. Always unplug
the mains supply before changing the fuse
T
405
T
T
ELLY
ONE
T
T
ELLY
ONE
R
The popular musician’s choice
Thank you for purchasing the TV405, we are very
grateful that you have allowed us to do the
things we love, and that’s making unique fun
British hand built amplifiers, with this in mind
we honour a full one year warranty, and so
want you to enjoy your product to the full
Please don't go inside the ‘405
as it will invalidate any guarantee and
is very dangerous as there are very
high hazardous voltages present .
Our circuitry goes right back to
the 1950's in design (with a
few unique tweeks of our own)
Enough said an immense big
Thank You for purchasing
our designs incorporated
in the TellyTone TV405
from each and every
member of team
TellyTone !
Page 3
SAFETY INSTRUCTIONS IMPORTANT !
Read and keep these instructions. Do not use this apparatus near water. Heed all warnings.
Follow all instructions carefully. Mains powered apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus
Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat Do not defeat the safety purpose of the grounding type
plug has two blades and a third grounding prong. The wide blade or the third prong is provided
for your safety. If the provided plug does not fit into your outlet, consult a qualified electrician
for replacement of the obsolete outlet Always. protect the power cord from being walked on
or pinched particularly at plugs, convenience receptacles, and the point where they exit from the
apparatus. Only use attachments/accessories specified by the manufacturer.
WARNING
This apparatus shall be connected to a mains socket outlet with a protective earthing connection.
Unplug this apparatus during lightning storms or when unused for long periods of time. Turning off
the power switch does not completely isolate this product from the power line so remove the plug
from the socket if not using it for extended periods of time. Keeping the product well ventilated
install this product near the wall socket and keep the power plug easily accessible
Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power cord or plug is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped
Never install this equipment on the far position from wall outlet receptacle. Do not install this
equipment in a confined space such as a box for the conveyance or similar unit. Excessive sound
pressure from the speaker can cause hearing loss. Use only with the stand specified by the
manufacturer sold with the apparatus. Be careful not to pull cables input leads etc to avoid
injury or fire from tip-over. Clean only with a dry cloth
The lightning flash with arrowhead symbol within an
equilateral triangle, is intended to alert the user to
the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the product.
Location of the controls
Input for guitar
(auto impedance)
Treble control
Rotate clockwise
for max treble
Bass control
Rotate clockwise for
max Bass
Pregain distortion control
Master volume control
Low frequency cut off filter
Red least cut off
White most cut off
Mains On Off switch
Depress for On (illuminates)
For sound settings visit www.tellytone.com
Page 4
T
405
T
T
ELLY
ONE
T
T
ELLY
ONE
R
The popular musician’s choice
Please remember the TV405
must never be covered
THIS IS A HIGH VOLTAGE DEVICE
COMPLETELY READ AND UNDERSTAND
THIS MANUAL CAREFULLY BEFORE OPERATING
Specifications..................
Output power 28 watts RMS
Supply
Options 405 leg pack
This Class 1 device
must be earthed
at all times.
Specification
E and O E.
Speaker 1x Celestion 12" 50 watt 8 ohm
Dimensions (WxDxH) 60x28x40 cm
(with fitted legs) 60x28x69 cm
Input Standard 6.3mm jack input
230v AC mains only
Weight 19.6 kg 43.22lbs
