Telit GE864 and GC864

Product Description

elliitt

4--

Y,,

D,,

80273ST10008A Rev. 3 - 10/02/06

4--

ctt

Telit Communications S.p.a. 2006

D,,

crrii

pttii

Telit GE864 and GC864

Product Description

This document is relating to the following products:

Model P/N

GE864-QUAD 3990250651 GE864-PY 3990250650 GC864-QUAD 3990250675 GC864-PY 3990250676 GE864-PY Interface 3990250672

80273ST10008A Rev. 3 - 10/02/06

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

Contents

1 OVERVIEW ..................................................................................................................7

2 GENERAL PRODUCT DESCRIPTION........................................................................9

2.1 Size.......................................................................................................................9

2.1.1 GE864 .............................................................................................................................. 9

2.1.2 GC864 ............................................................................................................................ 10

2.2 Weight ................................................................................................................11

2.3 Environmental requirements............................................................................11

2.3.1 Temperature range......................................................................................................... 11

2.3.2 Vibration Test (non functional)........................................................................................ 11

2.3.3 RoHS compliance........................................................................................................... 11

2.4 Operating Frequency ........................................................................................11

2.5 Transmitter output power.................................................................................12

2.6 Reference sensitivity.........................................................................................12

2.7 Antenna..............................................................................................................12

2.7.1 GC864 Antenna connector ............................................................................................. 13

2.8 SIM card holder support (GC864 only)............................................................13

2.9 Supply voltage...................................................................................................13

2.10 Power consumption..........................................................................................13

2.11 Embodied Battery charger................................................................................13

2.12 User Interface.....................................................................................................14

2.12.1 Speech Coding............................................................................................................ 14

2.12.2 SIM Reader ................................................................................................................. 14

2.12.3 SMS............................................................................................................................. 14

2.12.4 Real Time Clock and Alarm......................................................................................... 15

2.12.5 Data/fax transmission.................................................................................................. 15

2.12.6 Local security management ........................................................................................ 15

2.12.7 Call control .................................................................................................................. 15

2.12.8 Phonebook .................................................................................................................. 15

2.12.9 Characters management............................................................................................. 15

2.12.10 SIM related functions ............................................................................................... 15

Telit GE864 and GC864

Product Description

2.12.11 Call status indication ................................................................................................ 15

2.12.12 Indication of network service availability .................................................................. 16

2.12.13 Automatic answer (Voice, Data or FAX) .................................................................. 16

2.12.14 Supplementary services (SS)................................................................................... 16

2.12.15 Acoustic signaling .................................................................................................... 16

2.12.16 DTMF tones ............................................................................................................. 17

2.12.17 Buzzer output........................................................................................................... 17

2.12.18 RF Transmission Monitor ......................................................................................... 17

80273ST10008A Rev. 3 - 10/02/06

2.13 Logic level specifications.................................................................................17

2.13.1 Reset signal................................................................................................................. 18

2.14 RTC Bypass out.................................................................................................19

2.15 VAUX power output...........................................................................................19

2.16 Audio levels specifications...............................................................................20

2.17 Camera compatibility (EASY CAMERA) ..........................................................21

2.18 Converters .........................................................................................................21

2.18.1 ADC Converter ............................................................................................................ 21

2.18.2 DAC Converter ............................................................................................................ 21

2.19 Board to Board interface ..................................................................................23

2.19.1 GE864 balls allocation................................................................................................. 23

2.19.2 GE864 BGA balls layout.............................................................................................. 27

2.19.3 GC864 pins allocation ................................................................................................. 28

NOTE: RESERVED pins must not be connected ..........................................................30

2.20 Mounting the GE864 on your Board ................................................................31

2.20.1 General........................................................................................................................ 31

2.20.2 Module finishing & dimensions.................................................................................... 31

2.20.3 Stencil.......................................................................................................................... 31

2.20.4 PCB pad design .......................................................................................................... 31

2.20.5 Solder paste ................................................................................................................ 33

2.20.6 GE864 Solder reflow ................................................................................................... 33

2.21 Mounting the GC864 on your board................................................................. 35

2.22 Packing system .................................................................................................36

2.22.1 GE864 orientation on the tray ..................................................................................... 37

2.22.2 GC864 orientation on the tray ..................................................................................... 38

2.22.3 Moisture sensibility ...................................................................................................... 38

3 EVALUATION KIT......................................................................................................39

3.1 Evaluation Kit description ................................................................................40

3.1.1 Power Supply ................................................................................................................. 40

Telit GE864 and GC864

Product Description

3.1.2 Serial interface................................................................................................................ 40

3.1.3 Audio .............................................................................................................................. 40

3.1.4 GPIO and Leds............................................................................................................... 40

80273ST10008A Rev. 3 - 10/02/06

4 SERVICE AND FIRMWARE UPDATE.......................................................................41

4.1 Step-by-Step upgrade procedure.....................................................................41

4.2 Update the GE864 firmware on your interface board.....................................43

5 SOFTWARE FEATURES...........................................................................................45

5.1 Enhanced Easy GPRS Extension.....................................................................45

5.1.1 Overview......................................................................................................................... 45

5.1.2 Easy GPRS definition ..................................................................................................... 46

5.1.2.1 Configuring the GPRS access ................................................................................. 46

5.1.2.2 Configuring the embedded TCP/IP stack................................................................. 46

5.1.2.3 Defining the Internet peer to be contacted ............................................................... 46

5.1.2.4 Open the connection with the internet host.............................................................. 47

5.1.2.5 Close the Socket and deactivate the context ........................................................... 47

5.1.3 Enhanced Easy GPRS Outgoing connection ................................................................. 47

5.1.3.1 Configuring the GPRS access ................................................................................. 48

5.1.3.2 Configuring the embedded TCP/IP stack................................................................. 48

5.1.3.3 Defining the Internet peer to be contacted ............................................................... 48

5.1.3.4 Request the GPRS context to be activated.............................................................. 48

5.1.3.5 Open the connection with the internet host.............................................................. 49

5.1.3.6 Close the Socket without deactivating the context................................................... 49

5.1.4 Enhanced Easy GPRS Incoming Connection................................................................. 49

5.1.4.1 Defining the Internet Peer that can contact this device (firewall settings)................ 50

5.1.4.2 Request the socket connection to be opened in listen............................................. 51

5.1.4.3 Receiving connection requests ................................................................................ 51

5.1.4.4 Known limitations ..................................................................................................... 51

5.2 Jammed Detect & Report Extension................................................................52

5.2.1 Overview......................................................................................................................... 52

5.3 Easy Script Extension - Python interpreter.....................................................53

5.3.1 Overview......................................................................................................................... 53

5.3.2 Python 1.5.2+ Copyright Notice...................................................................................... 54

5.3.3 Python implementation description................................................................................. 55

5.3.4 Python core supported features...................................................................................... 56

5.3.5 Python Build-in Custom Modules.................................................................................... 56

5.4 AT Commands...................................................................................................57

6 CONFORMITY ASSESSMENT ISSUES....................................................................63

6.1 GE864-QUAD Conformity Assessment ...........................................................64

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

7 SAFETY RECOMMENDATIONS...............................................................................68

8 GE864 AND GC864 TECHNICAL SUPPORT ...........................................................69

9 LIST OF ACRONYMS................................................................................................70

10 DOCUMENT CHANGE LOG......................................................................................72

DISCLAIMER

The information contained in this document is proprietary information of Telit Communications S.p.A.

Telit Communications S.p.A. makes every effort to ensure the quality of the information it makes available. Notwithstanding the foregoing, Telit Communications S.p.A. does not make any warranty as to the information contained herein, and does not accept any liability for any injury, loss or damage of any kind incurred by use of or reliance upon the information.

Telit Communications S.p.A. disclaims any and all responsibility for the application of the devices characterized in this document, and notes that the application of the device must comply with the safety standards of the applicable country, and where applicable, with the relevant wiring rules.

Telit Communications S.p.A. reserves the right to make modifications, additions and deletions to this document at any time and without notice.

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

1 Overview

The Telit GE864 and GC864 modules are small, lightweight, low power consumption and RoHS

compliant devices that allow digital communication services wherever a GSM 850, 900, DCS 1800 or PCS 1900 network is present.

The GE864 is a low cost connector-less best solution for medium to high quantity projects. The GC864 is provided with a 80 pin Molex board to board connector and a 50 Ohm Murata RF

connector.

The GE864-PY and GC864-PY models integrate the “EASY SCRIPT” on top of all other features of the GE864-QUAD and GC864-QUAD. The PYTHON, is an engine script interpreter, allowing self controlled operations. With the EASY SCRIPT feature the GE864-PY and GC864-PY become a finite

product, they just needs your script to be run.

All GE864 and GC864 models includes all state-of-the-art features like GPRS Class 10, Voice, Circuit

Switched Data transfer, Fax, Phonebook and SMS support, ‘EASY GPRS’ embedded TCP/IP stack and ‘EASY CAMERA’ external camera support and battery charging capabilities.

The GE864 and GC864 are specifically designed and developed by Telit for OEM usage and

dedicated to portable data, voice and telematics applications such as:

• Telemetry and Telecontrol (SCADA applications)

• Security systems

• Automated Meter Reading (AMR)

• Vending machines

• POS terminals

• PDAs and Mobile Computing

• Phones and Payphones

• Automotive and Fleet Management applications

• Battery powered applications needing a battery charger

• Return channel for digital broadcasting

• Applications, where the external application processor can be replaced by the

PYTHON engine provided by the GE864-PY or GC864-PY

All four models support the following functionalities

9 EASY GPRS (AT driven embedded TCP/IP protocol stack) 9 EASY CAMERA (AT driven direct connection CAMERA function) 9 EASY SCAN (full GSM frequency scanning) 9 JAMMING DETECT & REPORT (detect the presence of disturbing devices)

From the interface point of view, the GE864 and GC864 provides the following:

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

9 Full RS232 UART, CMOS level (ASC0) interface for AT commands:

- Autobauding from 2.4 up to 57.6 Kbps

- Fixed baud rate up to 115.2 Kbps

9 Two wires RS232, CMOS level (ASC1) for PYTHON debug: 9 SIM card interface, 1.8 / 3 volts with auto-detection, hot insertion 9 21 x GPIO ports (max) 9 3 x A/D converters 9 1 x D/A converter 9 1 x buzzer output 9 1 x vibrator motor driver output 9 1 x single led supply output

In order to meet the competitive OEM and vertical market stringent requirements, Telit supports its customers with a dedicated

 Telit Evaluation Kit EVK2 to help you develop you application;

 A Website with all updated information available;  an high level specialist technical support to assist you in your development;

For more updated information concerning product Roadmap and availability, technical characteristics, commercial and other issues, please check on the Telit website Products > Modules.

NOTE module itself.

The Telit modules SW group is continuously working in order to add new features and improve the

overall performances.

The Telit modules are easily upgradeable by the developer using the Telit Flash Programmer. Furthermore, all the Telit modules have the conformity assessment against R&TTE.

: Some of the performances of the Telit modules depend on SW version installed on the

Support Policy with:

www.telit.com >

Telit GE864 and GC864

Product Description

2 General Product Description

2.1 Size

2.1.1 GE864

The Telit GE864 module overall dimension are:

• Length: 30 mm

• Width: 30 mm

• Thickness: 2.8 mm

80273ST10008A Rev. 3 - 10/02/06

Telit GE864 and GC864

Product Description

2.1.2 GC864

The Telit GC864 module overall dimensions are:

• Length: 36.2 mm

• Width: 30 mm

• Thickness: 3.2 mm

80273ST10008A Rev. 3 - 10/02/06

PRELIMINARY

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

2.2 Weight

GE864: 6 gr GC864: 8 gr. (preliminary)

2.3 Environmental requirements

The Telit GE864 and GC864 modules are compliant with the applicable ETSI reference

documentation GSM 05.05 Release1998.

2.3.1 Temperature range

GE864-QUAD /

GE864-PY

Temperature in normal operating conditions Temperature in extreme operating conditions*

Temperature in storage conditions * Temperature exceeding the range of normal operating conditions can affect the sensitivity, the performance and

the MTBF of the module.

–10°C ÷ +55°C –30°C ÷ +80°C

(preliminary)

–30°C ÷ +85°C

–10°C ÷ +55°C

–30°C ÷ +85°C

GC864-QUAD /

GC864-PY

–30°C ÷ +80°C

(preliminary)

2.3.2 Vibration Test (non functional)

• 10 ÷12Hz ASD = 1.92m 2 /s 3

• 12 ÷ 150Hz –3dB/oct

2.3.3 RoHS compliance

As a part of Telit corporate policy regarding environmental protection, the GE864 and GC864 comply

with the RoHS (Restriction of Hazardous Substances) directive of the European Union.(EU Directive 2002/95/EG).

2.4 Operating Frequency

The operating frequencies in GSM, DCS, PCS modes are conform to the GSM specifications.

Mode Freq. TX (MHz) Freq. RX (MHz) Channels (ARFC) TX - RX offset

850

E-GSM-900

DCS-1800 1710.2 - 1784.8 1805.2 - 1879.8 512 – 885 95 MHz

PCS-1900 1850.2 - 1909.8 1930.2 - 1989.8 512 - 810 80 MHz

824.2÷848.8 869.2÷893.8 0 ÷ 124 45 MHz

890.0 - 914.8 935.0 - 959.8 0 – 124 45 MHz

880.2 - 889.8 925.2 - 934.8 975 - 1023 45 MHz

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

2.5 Transmitter output power

GSM–850/900

The Telit GE864 and GC864 transceiver modules in GSM–850/900 operating mode are class 4 in

accordance with the specifications which determine the nominal 2W peak RF power (+33dBm) on 50 Ohm.

DCS–1800/PCS–1900 The Telit GE864 and GC864 transceiver modules in DCS–1800/PCS–1900 operating mode are class 1 in accordance with the specifications which determine the nominal 1W peak RF power (+30dBm)

on 50 Ohm.

2.6 Reference sensitivity

GSM–850/900

The sensitivity of the Telit GE864 and GC864 modules according to the specifications for the class 4 GSM 850/900 portable terminals are –107 dBm typical in normal operating conditions.

DCS–1800/PCS–1900

The sensitivity of the Telit GE864 and GC864 module according to the specifications for the class 1 portable terminals DCS-1800/PCS 1900 are –106 dBm typical in normal operating conditions.

2.7 Antenna

The antenna that the customer chooses to use should fulfill the following requirements:

Frequency range

Bandwidth

Gain Impedance Input power VSWR absolute max VSWR recommended

Depending by frequency band(s) provided by the network operator, the customer shall use the most suitable antenna for that/those band(s) 136 MHz in GSM 850/900, 170 MHz in DCS, 140 MHz PCS > 1.5 dBi 50 ohm > 2 W peak power 10:1

<= 2:1

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

2.7.1 GC864 Antenna connector

The GC864 module is equipped with a 50 Ohm RF connector from Murata, GSC type P/N MM93292700B.

The counterpart suitable is Murata MXTK92 Type or MXTK88 Type. Moreover, the GC864 has the antenna pads on the back side of the PCB. This allows the manual

soldering of the coaxial cable directly on the back side of the PCB. However, the soldering is not an advisable solution for a reliable connection of the antenna.

2.8 SIM card holder support (GC864 only)

The GC864 will have on the back side of the PCB, the necessary pads to manually solder a SIM

card holder. The type of the SIM card holder and its final position is being defined and will be known soon.

2.9 Supply voltage

The external power supply must be connected to VBATT signal and must fulfill the following requirements:

• Nominal operating voltage 3.8 V

• Operating voltage range 3.4 V - 4.2 V

Note

: Operating voltage range must never be exceeded; care must be taken in order to fulfill

min/max voltage requirements.

2.10 Power consumption

The typical current consumption of the Telit GE864 and GC864 are:

Power off current (typical)

Stand–by current (GSM Idle) < 4 mA

Operating current in voice ch. 170 mA

Operating current in voice ch. < 270 mA

Operating current in GPRS class 10 < 500 mA

< 26 μA;

rms

±20% @ typical network conditions

1.9 A

rms

@ typical network conditions

rms

@ worst network conditions

peak

2.11 Embodied Battery charger

The battery charger is suited for 3.7V Li-Ion rechargeable battery (suggested capacity 5001000mAH). The Charger needs only a CURRENT LIMITED power source input and charges the battery directly through VBATT connector pins.

Battery charger input pin CHARGE

Telit GE864 and GC864

Product Description

Battery pins VBATT, GND

Battery charger input voltage min 5.0 V

Battery charger input voltage typ 5.5 V

Battery charger input voltage max 7.0 V

Battery charger input current max 400mA

Battery type Li-Ion rechargeable

NOTE: If embodied battery charger is used, then a LOW ESR capacitor of at least 100μF must be

mounted in parallel to VBATT pin.

NOTE: when power is supplied to the CHARGE pin, a battery must always be connected to the

VBATT pin of the GE864 / GC864.

80273ST10008A Rev. 3 - 10/02/06

2.12 User Interface

The user interface is managed by AT commands specified on the ITU-T V.250, GSM 07.07 and

07.05 specifications.

2.12.1 Speech Coding

The GE864 and GC864 vocoders support the following rates:

 Half Rate  Full rate  Enhanced Full Rate  Adaptive Multi Rate

2.12.2 SIM Reader

The GE864 and GC864 support phase 2 GSM11.14 - SIM 3V volts ONLY with an external SIM

connector. For 5V SIM operation an external level translator can be added.

2.12.3 SMS

The GE864 and GC864 support the following SMS types:

 Mobile Terminated (MT) class 0 – 3 with signaling of new incoming SMS, SIM full, SMS

read

 Mobile Originated class 0 – 3 with writing, memorize in SIM and sending  Cell Broadcast compatible with CB DRX with signaling of new incoming SMS.

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

2.12.4 Real Time Clock and Alarm

The Telit GE864 and GC864 support the Real Time Clock and Alarm functions through AT

commands, furthermore an alarm output pin (GPIO6) can be configured to indicate the alarm with a hardware line output. Furthermore the Voltage Output of the RTC power supply is provided so that a backup capacitor can be added to increase the RTC autonomy.

2.12.5 Data/fax transmission

The Telit GE864 and GC864 support:

 GPRS Class 10, MS Class B  CSD up to 14.4 Kbps

 Fax service, Class 1 Group 3

2.12.6 Local security management

With lock of Subscriber Identity module (SIM), and security code request at power–up.

2.12.7 Call control

Call cost control function.

2.12.8 Phonebook

This function allows the storing of the telephone numbers in SIM memory. The capability depends on SIM version/memory.

2.12.9 Characters management

The Telit GE864 and GC864 supports the IRA characters set (International Reference Alphabet), in

TEXT and PDU mode.

2.12.10 SIM related functions

Activation/deactivation of the numbers stored in phone book FDN, ADN and PINs. Extension at the PIN2 for the PUK2 insertion capability for lock condition.

2.12.11 Call status indication

The call status indication by AT commands is supported.

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

2.12.12 Indication of network service availability

The STAT_LED pin status shows information on the network service availability and Call status. The pin is an Open Collector output where it is possible to directly connect a LED to show information on the network service availability and Call status. Therefore, the status indicated in the following table is reversed with respect to the pin status.

STAT_LED indications

LED status Device Status

permanently off device off

fast blinking (period 1s, Ton 0,5s)

slow blinking (period 3s, Ton 0,3s) Permanently on a call is active

Net search / Not registered / turning off Registered full service

2.12.13 Automatic answer (Voice, Data or FAX)

After a specified number of rings, the module will automatically answer with a beep. The user can set the number of rings by means of the command ATS0=<n>.

2.12.14 Supplementary services (SS)

 Call Barring,  Call Forwarding,  Calling Line Identification Presentation (CLIP),  Calling Line Identification Restriction (CLIR),  Call Waiting, other party call Waiting Indication,  Call Hold, other party Hold / Retrieved Indication,  Closed User Group supplementary service (CUG),  Advice of Charge,  Unstructured SS Mobile Originated (MO)

2.12.15 Acoustic signaling

The acoustic signaling of the GE864 and GC864 on the selected acoustic device are the following:

 Call waiting;  Ringing tone;  SMS received tone;  Busy tone;  Power on/off tone;  Off Hook dial tone;  Congestion tone;  Connected tone;  Call dropped;

Telit GE864 and GC864

Product Description

 No service tone;  Alarm tone.

80273ST10008A Rev. 3 - 10/02/06

2.12.16 DTMF tones

The DTMF tones are managed by specific AT commands. These tones are generated with AT commands only during voice calls. The minimum duration of a DTMF tone is 100 ms.

Group high

Group low

697 Hz 1 2 3

770 Hz 4 5 6 852 Hz 7 8 9

941 Hz * 0 #

NOTE by the network switches on commands sent by the Mobile Station (MS). Thus, the default duration parameters may vary from network to network. In case that the devices to be controlled by DTMF are sensitive related to the duration of the tones and timing of the sequences, dedicated investigations on the parameter settings have to be made.

: The GSM system architecture defines that the audio signal of the DTMF tones is inserted

1209 Hz 1336 Hz 1477 Hz

2.12.17 Buzzer output

The General Purpose I/O pin GPIO7 can be configured to output the BUZZER output signal, with only an external Mosfet/transistor and a diode a Buzzer can be directly driven. The ringing tone and the other signaling tones can be redirected to this Buzzer output with a specific AT command.

2.12.18 RF Transmission Monitor

As alternate function of the GPIO5, the GE864 and GC864 provide the RF transmission monitor.

When the alternate function is activated, the pin of GPIO5 changes to HIGH every time the module transmits an RF signal and remains HIGH for the duration of the transmission sequence, i.e. it does not change with every GSM signal burst.

2.13 Logic level specifications

Where not specifically stated, all the interface circuits work at 2.8V CMOS logic levels.

The following table shows the logic level specifications used in the GE864 and GC864 interface

circuits:

Absolute Maximum Ratings -Not Functional

Parameter Min Max

Input level on any -0.3V +3.75V

Telit GE864 and GC864

Product Description

digital pin when on

Input voltage on analog pins when on

-0.3V +3.0 V

80273ST10008A Rev. 3 - 10/02/06

Operating Range - Interface levels (2.8V CMOS)

Level Min Max

Input high level 2.1V 3.3V

Input low level 0V 0.5V

Output high level 2.2V 3.0V

Output low level 0V 0.35V

For 2,0V signals:

Operating Range - Interface levels (2.0V CMOS)

Level Min Max

Input high level 1.6V 3.3V

Input low level 0V 0.4V

Output high level 1,65V 2.2V Output low level 0V 0.35V

2.13.1 Reset signal

Signal Function I/O GE864 ball GC864 pin

RESET Phone reset I/O A2 54

RESET is used to reset the GE864 and GC864. Whenever this signal is pulled low, the GE864 / GC864

is reset. When the device is reset it stops any operation and after the release of the reset it shuts down, without doing any detach operation from the network where it is registered to. This behavior is not a proper shut down because any GSM device is requested to issue a detach request on turn off. For this reason the Reset signal must not be used to normally shutting down the device, but only as an emergency exit in the rare case the device remains stuck waiting for some network response.

The RESET is internally controlled on start-up to achieve always a proper power-on reset sequence, so there's no need to control this pin on start-up. It may only be used to reset a device

already on that is not responding to any command.

NOTE: do not use this signal to power off the Telit GE864 / GC864 module. Use the ON_OFF* signal to perform this function or the AT#SHDN command.

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

Reset Signal Operating levels:

Signal Min Max

RESET Input high 2.2V* 3.3V

RESET Input low 0V 0.2V

* this signal is internally pulled up so the pin can be left floating if not used.

If unused, this signal may be left unconnected. If used, then it must always be connected with an open collector transistor, to allow to the internal circuitry the power on reset and under voltage

lockout functions.

2.14 RTC Bypass out

The VRTC signal brings out the Real Time Clock supply which is separate from the rest of the digital part, allowing having only RTC going on when all the other parts of the device are off. To this power output a backup capacitor can be added in order to increase the RTC autonomy during power off of the battery. NO Devices must be powered from this pin.

2.15 VAUX power output

A regulated power supply output is provided in order to supply small devices from module. This output is active when the module is ON and goes off when module is shut down. The operating range characteristics of the supply are:

Operating Range - Vout power supply

Min Typ Max

Output voltage 2.75V 2.85V 2.95V

Output current 100mA

Output bypass capacitor 2.2μF

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

2.16 Audio levels specifications

The audio of the GE864 / GC864 is organized into two main paths:

- internal path (called also MT)

- external path (called also HF)

These two paths are meant respectively for handset and headset/hands-free use. The GE864 /

GC864 has a built in echo canceller and a noise suppressor, tuned separately for the two audio

paths; for the internal path the echo canceller parameters are suited to cancel the echo generated by a handset, while for the external audio path they are suited for a hands-free use. For more information on the audio refer to the Hardware User Guide. The following table reports all the audio level specifications.

Microphone characteristics Internal audio mic. input External audio mic. input

Line coupling

AC (100nF cond.) AC (100nF cond.)

Line type

Differential input resistance

Line nominal sensitivity 50mV

Max input voltage 360mV

Microphone nominal sensitivity

-45dB

Balanced Balanced

50kΩ 50kΩ

±2dB 3mV

rms

22mV

rms

±2dB / +24dB -45dB

Vrms/Pa

±2dB

rms

±2dB / +10dB

– Analog Gain suggested

Echo canceller type handset Car kit hands free

Speaker characteristics Internal audio ear. output External audio ear. output

Line coupling DC DC

Line type

Speaker impedance

Minimum load impedance

≥ 16Ω ± 5% @ 1kHz ≥ 16Ω ± 5% @ 1kHz

Bridged Bridged

15Ω 15Ω

Signal bandwidth 150-8000 Hz @ -3dB 150-8000 Hz @ -3dB

Maximum output 1,3 V

1,3 V

rms

Maximum power output

80mW/16Ω 80mW/16Ω

Volume level steps (SW) -2dB -2dB

Number of volume steps (SW) 14 14

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

2.17 Camera compatibility (EASY CAMERA)

The GE864 / GC864 provides a direct support for the camera whose characteristics are the following:

Model: TRANSCHIP TC5747 Technology: CMOS COLOR camera Max picture size: VGA 640x480 pixels Output format: JPEG Sensitivity: 4V/lux-sec (including gain)

The camera will be directly managed by the hardware/software with some interface circuitry, providing a custom AT command interface to operate with it.

The camera interface requires the pins and GPIOs:

Signal GE864 ball GC864 pin

CAM_SDA D7 36 CAM_SCL C6 35 CAM_CLK F8 44 CAM_ON K11 67 CAM_RST C9 76

When the camera is activated, then these pins are not accessible as GPIO. The AT commands of the module allows to take a snapshot and successively download it through the serial line in various formats.

2.18 Converters

2.18.1 ADC Converter

The on board A/D are 11-bit converter. They are able to read a voltage level in the range of 0÷2 volts applied on the ADC pin input, store and convert it into 11 bit word.

Input Voltage range 0 2 Volt AD conversion - 11 bits Resolution - < 1 mV Sampling rate 1 (idle) 60 (on traffic) secs

2.18.2 DAC Converter

The on board DAC is a 10 bit converter, able to generate a analogue value based a specific input in the range from 0 up to 1023. However, an external low-pass filter is necessary. See the HW User Guide for the details.

Min Max Units

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

Voltage range (filtered) 0 2 Volt Range 0 1023 Steps

Min Max Units

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

2.19 Board to Board interface

2.19.1 GE864 balls allocation

Ball Signal I/O Function Internal PULL UP Type

Audio

H9 EAR_MT- AO Handset earphone signal output, phase - Audio G10 EAR_MT+ AO Handset earphone signal output, phase + Audio H10 EAR_HF+ AO Handsfree ear output, phase + Audio J10 EAR_HF- AO Handsfree ear output, phase - Audio

J8 MIC_MT+ AI

G9 MIC_MT- AI

G8 MIC_HF+ AI

J9 MIC_HF- AI

F9 AXE I Handsfree switching 100K CMOS 2.8V

G5 VMICP O Microphone supply (*)

G3 VMICN O Microphone supply (*)

SIM card interface

C10 SIMCLK O External SIM signal – Clock 1,8 / 3V

E9 SIMRST O External SIM signal – Reset 1,8 / 3V D10 SIMIO I/O External SIM signal - Data I/O 1,8 / 3V C11 SIMIN I External SIM signal - Presence (active low) 47K 1,8 / 3V

D4 SIMVCC - External SIM signal – Power supply for the SIM 1,8 / 3V

Trace

D11 TX_TRACE O TX Data for debug monitor CMOS 2.8V F10 RX_TRACE I RX Data for debug monitor CMOS 2.8V

Prog. / Data + HW Flow Control

E7 C103/TXD I Serial data input (TXD) from DTE CMOS 2.8V

H8 C104/RXD O Serial data output to DTE CMOS 2.8V

B7 C108/DTR I

F7 C105/RTS I

F6 C106/CTS O Output for Clear to send signal (CTS) to DTE CMOS 2.8V

D9 C109/DCD O E11 C107/DSR O Output for Data set ready signal (DSR) to DTE CMOS 2.8V

B6 C125/RING O Output for Ring indicator signal (RI) to DTE CMOS 2.8V

IIC bus

D7 CAM_SDA / IIC_SDA I/O Camera IIC interface / Configurable GPIO CMOS 2.8V

C6 CAM_SCL / IIC_SCL I/O Camera IIC interface / Configurable GPIO CMOS 2.8V

DAC and ADC

Handset mic.signal input; phase+, nom. level 50mVrms Handset mic.signal input; phase-, nom. level 50mVrms Handsfree mic. input; phase +, nom. level 3mVrms Handsfree mic.input; phase -, nom. level 3mVrms

Input for Data terminal ready signal (DTR) from DTE Input for Request to send signal (RTS) from DTE

Output for Data carrier detect signal (DCD) to DTE

Audio

CMOS 2.8V

Telit GE864 and GC864

Product Description

Ball Signal I/O Function Internal PULL UP Type

C7 DAC_OUT AO Digital/Analog converter output D/A J11 ADC_IN1 AI Analog/Digital converter input A/D H11 ADC_IN2 AI Analog/Digital converter input A/D G11 ADC_IN3 AI Analog/Digital converter input A/D

Miscellaneous Functions

A2 RESET* I Reset input

E2 VRTC AO VRTC Backup capacitor Power

D8 STAT_LED O Status indicator led CMOS 1.8V

G1 CHARGE AI Charger input (*) Power

G2 CHARGE AI Charger input (*) Power

F8 MON1 / CAM_CLK I/O MON1 / Camera interface CMOS 2.8V

Input command for switching power ON or OFF

J5 ON_OFF* I

D5 VAUX1 - Power output for external accessories -

C5 VIBRO_EP O Vibrator motor driver output (*)

L8 PWRMON O Power ON Monitor CMOS 2.8V

L4 Antenna O Antenna output - 50 ohm RF

GPIO

G4 TGPIO_12 I/O Telit GPIO12 Configurable GPIO CMOS 2.8V

E5 TGPIO_23 I/O

C2 TGPIO_03 I/O Telit GPIO03 Configurable GPIO CMOS 2.8V

B3 TGPIO_04 I/O Telit GPIO04 Configurable GPIO CMOS 2.8V

C3 TGPIO_20 I/O Telit GPIO20 Configurable GPIO CMOS 2.8V

B4 TGPIO_14 I/O Telit GPIO14 Configurable GPIO CMOS 2.8V

D1 TGPIO_11 I/O Telit GPIO11 Configurable GPIO CMOS 2.8V

B1 TGPIO_19 I/O Telit GPIO19 Configurable GPIO CMOS 2.8V

C1 TGPIO_01 I/O Telit GPIO01 Configurable GPIO CMOS 2.8V

K7 TGPIO_18 I/O Telit GPIO18 I/O pin CMOS 2.8V

H5 TGPIO_17 I/O Telit GPIO17 GPIO pin CMOS 2.8V

F5 TGPIO_15 I/O Telit GPIO15 GPIO pin CMOS 2.8V K11 TGPIO_08 / CAM_ON I/O

B5 TGPIO_06 / ALARM I/O Telit GPIO06 Configurable GPIO / ALARM CMOS 2.8V

C9 TGPIO_09 / CAM_RST I/O Telit GPIO09 GPIO I/O pin / Camera Interface CMOS 2.8V

E6 TGPIO_02 / JDR I/O Telit GPIO02 I/O pin / Jammer detect report CMOS 2.8V

L9 TGPIO_07 / BUZZER I/O Telit GPIO07 Configurable GPIO / Buzzer CMOS 2.8V

H6 TGPIO_16 I/O Telit GPIO16 Configurable GPIO CMOS 2.8V K10 TGPIO_13 I/O Telit GPIO13 Configurable GPIO CMOS 2.8V

K8 TGPIO_05 / RFTXMON I/O L10 TGPIO_21 I/O Telit GPIO21 Configurable GPIO CMOS 2.8V

E8 TGPIO_22 I/O Telit GPIO22 Configurable GPIO

H3 TGPIO_10 I/O Telit GPIO10 I/O pin CMOS 2.8V

Power Supply

J1 VBATT - Main power supply Power

(toggle command). The pulse to be sent to the GE864 must be equal or greater than 1 second.

Reserved to detect ON/OFF. It is physically connected to L8 (PWRMON)

Telit GPIO08 Configurable GPIO / Camera Interface

Telit GPIO05 Configurable GPIO / Transmitter ON monitor

80273ST10008A Rev. 3 - 10/02/06

47K Pull up to VBATT

CMOS 2.8V

CMOS 1.8V

(not 2.8V !!)

Telit GE864 and GC864

Product Description

Ball Signal I/O Function Internal PULL UP Type

K1 VBATT - Main power supply Power

J2 VBATT - Main power supply Power

K2 VBATT - Main power supply Power

A1 GND - Ground Power

F1 GND - Ground Power

H1 GND - Ground Power

L1 GND - Ground Power

H2 GND - Ground Power

L2 GND - Ground Power

J3 GND - Ground Power

K3 GND - Ground Power

L3 GND - Ground Power

K4 GND - Ground Power

K5 GND - Ground Power

D6 GND - Ground Power

K6 GND - Ground Power

L6 GND - Ground Power A11 GND - Ground Power F11 GND - Ground Power L11 GND - Ground Power

RESERVED

A3 -

F3 -

J4 -

J6 -

J7 -

L7 -

F4 -

F2 -

E3 -

E4 -

D2 -

E1 -

G7 -

H7 -

G6 -

A9 -

B9 -

A8 - A10 -

C8 -

80273ST10008A Rev. 3 - 10/02/06

Telit GE864 and GC864

Product Description

Ball Signal I/O Function Internal PULL UP Type

B10 - B11 -

B8 -

A7 -

A6 -

A5 -

A4 -

B2 -

H4 -

C4 -

D3 -

K9 -

L5 - E10 -

80273ST10008A Rev. 3 - 10/02/06

NOTE: RESERVED pins must not be connected

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

2.19.2 GE864 BGA balls layout

A B C D E F G H J K L

GND TGPIO_19 TGPIO_01 TGPIO_11

RESET* - TGPIO_03 - VRTC - CHARGE GND VBATT VBATT GND

- TGPIO_04 TGPIO_20

- - VMICN TGPIO_10 GND GND GND

TOP

VIEW

GND CHARGE GND VBATT VBATT GND

- TGPIO_14 - SIMVCC - - TGPIO_12 - - GND Antenna

TGPIO_06

- - -

- -

- - SIMCLK SIMIO

/ ALARM

C125/RING

C108 /

DTR

VIBRO_EP VAUX1 TGPIO_23 TGPIO_15 VMICP TGPIO_17 ON_OFF* GND -

CAM_SCL

/ IIC_SCL

DAC_OUT

TGPIO_09

CAM_RST

GND

CAM_SDA

/ IIC_SDA

STAD_

LED

C109 /

DCD

TGPIO_02

/ JDR

C103 /

TXD

TGPIO_22

SIMRST AXE MIC_MT- EAR_MT- MIC_HF-

- RX_TRACE

C106 /

CTS

C105 /

RTS

MON1 /

CAM_CLK

TGPIO_16 - GND GND

MIC_HF+

EAR_MT+ EAR_HF+ EAR_HF- TGPIO_13 TGPIO_21

- - TGPIO_18 -

C104 /

RXD

MIC_MT+

TGPIO_05

RFTXMON

PWRMON

TESTMOD

TGPIO_07

/ BUZZER

GND - SIMIN

TX_TRACE

C107 /

DSR

GND ADC_IN3 ADC_IN2 ADC_IN1

TGPIO_08 / CAM_ON

GND

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

AUDIO Signals balls

SIM CARD interface balls

TRACE Signals balls

Prog. / data + Hw Flow Control signals balls

IIC signals balls

DAC and ADC signals balls

MISCELLANEOUS functions signals balls

TELIT GPIO balls

POWER SUPPLY VBATT balls

POWER SUPPLY GND balls

RESERVED

2.19.3 GC864 pins allocation

The GC864 uses an 80 pin Molex p.n. 53949-0878 male connector for the connections with the

external applications. This connector matches the 54150-0808 model

Pin Signal I/O Function Internal

Power Supply

1 VBATT - Main power supply Power

2 VBATT - Main power supply Power

3 VBATT - Main power supply Power

4 VBATT - Main power supply Power

5 GND - Ground Power

6 GND - Ground Power

7 GND - Ground Power

Audio

8 AXE I Handsfree switching

9 EAR_HF+ AO Handsfree ear output, phase + Audio

10 EAR_HF- AO Handsfree ear output, phase - Audio

11 EAR_MT+ AO Handset earphone signal output, phase + Audio

12 EAR_MT- AO Handset earphone signal output, phase - Audio

13 MIC_HF+ AI Handsfree microphone input; phase +, nominal level 3mVrms Audio

14 MIC_HF- AI Handsfree microphone input; phase -, nominal level 3mVrms Audio

15 MIC_MT+ AI Handset microphone signal input; phase+, nominal level 50mVrms Audio

16 MIC_MT- AI Handset microphone signal input; phase-, nominal level 50mVrms Audio

SIM Card Interface

18 SIMVCC - External SIM signal – Power supply for the SIM 1.8/3V

19 SIMRST O External SIM signal – Reset 1.8/3V

Pull up

100K

CMOS 2.8V

Type

Telit GE864 and GC864

Product Description

Pin Signal I/O Function Internal

20 SIMIO I/O External SIM signal - Data I/O 1.8/3V

21 SIMIN I External SIM signal - Presence (active low)

22 SIMCLK O External SIM signal – Clock 1.8/3V

Trace

23 RX_TRACE I RX Data for debug monitor CMOS 2.8V

24 TX_TRACE O TX Data for debug monitor CMOS 2.8V

Prog. / Data + Hw Flow Control

25 C103/TXD I Serial data input (TXD) from DTE CMOS 2.8V

26 C104/RXD O Serial data output to DTE CMOS 2.8V

27 C107/DSR O Output for Data set ready signal (DSR) to DTE CMOS 2.8V

28 C106/CTS O Output for Clear to send signal (CTS) to DTE CMOS 2.8V

29 C108/DTR I Input for Data terminal ready signal (DTR) from DTE CMOS 2.8V

30 C125/RING O Output for Ring indicator signal (RI) to DTE CMOS 2.8V

31 C105/RTS I Input for Request to send signal (RTS) from DTE CMOS 2.8V

32 C109/DCD O Output for Data carrier detect signal (DCD) to DTE CMOS 2.8V

IIC

35 CAM_SCL /

IIC_SCL

36 CAM_SDA /

IIC_SDA

37 ADC_IN1 AI Analog/Digital converter input A/D

38 ADC_IN2 AI Analog/Digital converter input A/D

39 ADC_IN3 AI Analog/Digital converter input A/D

40 DAC_OUT AO Digital/Analog converter output D/A

44 MON1_CAM I/O MON1 / Camera interface CMOS 2.8V

45 STAT_LED O Status indicator led CMOS 1.8V

46 GND - Ground Ground

49 PWRMON I Power ON Monitor CMOS 2.8V

50 VAUX1 - Power output for external accessories -

51 CHARGE AI Charger input (*) Power

52 CHARGE AI Charger input (*) Power

53 ON/OFF* I Input command for switching power ON or OFF (toggle command).

54 RESET* I Reset input

55 VRTC AO VRTC Backup capacitor Power

56 TGPIO_19 I/O Telit GPIO19 Configurable GPIO CMOS 2.8V

57 TGPIO_11 I/O Telit GPIO11 Configurable GPIO CMOS 2.8V

58 TGPIO_20 I/O Telit GPIO20 Configurable GPIO CMOS 2.8V

59 TGPIO_04 I/O Telit GPIO4 Configurable GPIO CMOS 2.8V

60 TGPIO_14 I/O Telit GPIO14 Configurable GPIO CMOS 2.8V

I/O Camera IIC interface / Configurable GPIO CMOS 2.8V

DAC and ADC

Miscellaneous Functions

The pulse to be sent to the GC864 must be equal or greater than 1 second.

Telit GPIO

80273ST10008A Rev. 3 - 10/02/06

Pull up

47K

1.8/3V

Pull up to VBATT

Type

Telit GE864 and GC864

Product Description

Pin Signal I/O Function Internal

61 TGPIO_15 I/O Telit GPIO15 GPIO pin CMOS 2.8V

62 TGPIO_12 I/O Telit GPIO12 Configurable GPIO CMOS 2.8V

63 TGPIO_10 I/O Telit GPIO10 I/O pin CMOS 2.8V

64 TGPIO_22 I/O Telit GPIO22 Configurable GPIO CMOS 1.8V

65 TGPIO_18 I/O Telit GPIO18 I/O pin CMOS 2.8V

66 TGPIO_03 I/O Telit GPIO3 Configurable GPIO CMOS 2.8V

67 TGPIO_08 / CAM_ON I/O Telit GPIO8 Configurable GPIO / Camera Interface CMOS 2.8V

68 TGPIO_06 / ALARM I/O Telit GPIO6 Configurable GPIO / ALARM CMOS 2.8V

69 TGPIO_23 I/O Reserved to detect ON/OFF. It is physically connected to pin 49

70 TGPIO_01 I/O Telit GPIO1 Configurable GPIO CMOS 2.8V

71 TGPIO_17 I/O Telit GPIO17 GPIO pin CMOS 2.8V

72 TGPIO_21 I/O Telit GPIO21 Configurable GPIO CMOS 2.8V

73 TGPIO_07 / BUZZER I/O Telit GPIO7 Configurable GPIO / Buzzer CMOS 2.8V

74 TGPIO_02 / JDR I/O Telit GPIO02 I/O pin / Jammer detect report CMOS 2.8V

75 TGPIO_16 I/O Telit GPIO16 Configurable GPIO CMOS 2.8V

76 TGPIO_09 /

CAM_RST

77 TGPIO_13 I/O Telit GPIO13 Configurable GPIO CMOS 2.8V

78 TGPIO_05 /

RFTXMON

17 -

33 -

34 -

41 -

42 -

43 -

47 -

48 -

79 -

80 -

(PWRMON)

I/O Telit GPIO9 GPIO I/O pin 7 Camera Interface CMOS 2.8V

I/O Telit GPIO05 Configurable GPIO / Transmitter ON monitor CMOS 2.8V

RESERVED

80273ST10008A Rev. 3 - 10/02/06

Type

Pull up

CMOS 2.8V

NOTE: RESERVED pins must not be connected

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

2.20 Mounting the GE864 on your Board

2.20.1 General

The Telit GE864 modules has been designed in order to be compliant with a standard lead-free SMT

process.

2.20.2 Module finishing & dimensions

Pin A1

Lead-free Alloy Surface finishing Sn/Ag/Cu for all solder pads

2.20.3 Stencil

Stencil’s apertures layout can be the same of the recommended footprint (1:1), we suggest a thickness of stencil foil ≥ 120µm.

2.20.4 PCB pad design

Non solder mask defined” (NSMD) type is recommended for the solder pads on the PCB.

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

Recommendations for PCB pad dimensions

Ball pitch [mm] 2,5 Solder resist opening diameter A [mm] 1,150 Metal pad diameter B [mm] 1 ± 0.05

Placement of microvias not covered by solder resist is not recommended inside the “Solder resist opening”, unless the microvia carry the same signal of the pad itself.

Holes in pad are allowed only for blind holes and not for through holes.

Telit GE864 and GC864

Product Description

Recommendations for PCB pad surfaces:

Finish Layer thickness [µm] Properties Electro-less Ni / Immersion Au

The PCB must be able to resist the higher temperatures which are occurring at the lead-free process. This issue should be discussed with the PCB-supplier. Generally, the wet-ability of tinlead solder paste on the described surface plating is better compared to lead-free solder paste.

3 –7 /

0.05 – 0.15

good solder ability protection, high shear force values

80273ST10008A Rev. 3 - 10/02/06

2.20.5 Solder paste

Solder paste

Lead free

Sn/Ag/Cu

2.20.6 GE864 Solder reflow

The following is the recommended solder reflow profile

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

Profile Feature Pb-Free Assembly

Average ramp-up rate (TL to TP) 3°C/second max Preheat – Temperature Min (Tsmin) – Temperature Max (Tsmax) – Time (min to max) (ts) Tsmax to TL – Ramp-up Rate Time maintained above: – Temperature (TL) – Time (tL) Peak Temperature (Tp) 245 +0/-5°C Time within 5°C of actual Peak Temperature (tp) Ramp-down Rate 6°C/second max. Time 25°C to Peak Temperature 8 minutes max.

150°C 200°C 60-180 seconds

3°C/second max

217°C 60-150 seconds

10-30 seconds

Note: All temperatures refer to topside of the package, measured on the package body surface.

Note: GE864 module can accept only one reflow process

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

2.21 Mounting the GC864 on your board

The position of the Molex board to board connector and the pin 1 are shown in the following picture.

Pin 1

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

2.22 Packing system

The Telit GE864 and GC864 are packaged on trays of 20 pieces each. This is especially suitable

for the GE864 according to SMT processes for pick & place movement requirements.

Section A-A

The size of the tray is: 329 x 176mm

Note that trays can withstand at the maximum temperature of 65° C.

Telit GE864 and GC864

Product Description

2.22.1 GE864 orientation on the tray

80273ST10008A Rev. 3 - 10/02/06

The modules on the tray are oriented as shown in A and the tray is oriented toward left as shown in B.

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

2.22.2 GC864 orientation on the tray

The GC864 will use the same tray of the GE864, and will be placed with the board to board connector

and the shield facing upper. The label including the IMEI number will be placed on the shield.

2.22.3 Moisture sensibility

The level of moisture sensibility of GE864 module is “3”, in according with standard IPC/JEDEC

J-STD-020, take care all the relatives requirements for using this kind of components.

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

3 Evaluation Kit

In order to assist you in the development of your Telit GE864 / GC864 module based application, Telit can supply the EVK2 Evaluation Kit with appropriate power supply, SIM card housing, RS 232 serial

port level translator, direct UART connection, Handset, Headset and Hands-free (car kit) audio, antenna.

The EVK2 provides a fully functional solution for a complete data/phone application. The standard serial RS232 9 pin connector placed on the Evaluation Kit allows the connection of the

EVK2 system with a PC or other DTE.

The development of the applications utilizing the Telit GE864 / GC864 module must present a proper

design of all the interfaces towards and from the module (e.g. power supply, audio paths, level translators), otherwise a decrease in the performances will be introduced or, in the worst case, a wrong design can even lead to an operating failure of the module.

In order to assist the hardware designer in his project phase, the EVK2 board presents a series of

different solutions, which will cover the most common design requirements on the market, and which can be easily integrated in the OEM design as building blocks or can be taken as starting points to develop a specific one.

GE864 / GC864 Evaluation Kit

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

3.1 Evaluation Kit description

For a detailed description of the Telit Evaluation Kit refer to the documentation provided with the Telit

GE864 / GC864 Hardware User Guide.

3.1.1 Power Supply

In the Board there are three different power sources, that embrace a wide range of applications, from the automotive +12V input to the stand alone battery powered device. The power sources nominal input voltages are:

• +12V input (typically automotive)

• +5V input (typically embedded systems)

• +3.8V input (Li-Ion Battery)

Each one of these power sources can supply the Telit GE864 / GC864 module and the whole circuitry embodied in the Evaluation Kit.

Only one of these power sources can be used at a time and it is selectable with two jumpers. For the battery power supply a Li-Ion battery charger circuit is provided.

3.1.2 Serial interface

The communications between your application and the Telit GE864 / GC864 module must be done

through a serial interface which can be a standard CMOS UART or a RS232 port. All levels of the RS232 port are conforming to RS232 and V.24 standard and a PC serial port can be directly connected to this connector. Both these interfaces are supported.

3.1.3 Audio

The Evaluation Kit board provides two software/hardware selectable audio paths, the internal and the

external one. All the handset, headset and hands free-car kit functions are supported. Furthermore for each audio path two solutions are presented: single ended and balanced

3.1.4 GPIO and Leds

All the General Purpose Input Output ports of the Telit GE864 / GC864 module are supported in a

dedicated connector and several leds are added as a debug aid.

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

4 Service and firmware update

The serial cable used for the communication with a PC can be also used to update the Telit GE864 /

GC864 module firmware. The RS232 connector DB type 9 pin 90° is used to connect the Telit Evaluation Kit. to any DTE .

All levels are conformed to RS232 and V.24 standard and a PC serial port can be directly connected to this connector. The firmware update can be done with a specific software tool provided by Telit that runs on windows based PCs.

4.1 Step-by-Step upgrade procedure

The firmware update can be done with a specific software tool provided by Telit that runs on Windows based PCs.

First the program will erase the content of flash memory, then the program will write on the flash memory. To update the firmware of the module, we suggest the following procedure:

I. Collect information about the Hardware and implemented version of Software by the

command

- AT+CGMR<enter>, which returns the Software version information;

- AT+CGMM<enter>, which returns the Model Identification.

II. Request the specific software for upgrading to Telit Technical Support

III. Switch off the module

IV. Mount the Telit GE864 / GC864 module in the Evaluation Kit (using the dedicated adaptor) and

supply power

V. Run the file application you received from the Technical Support (e.g. TFI_GE864.exe).

The following window will be displayed, Select the language preferred by pressing the correspondent button.

VI. The End User License Agreement will appear. Please, read it and accept the terms if you

are going to proceed.

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

VII. Press OK to the initial message.

NOTE: the power supply must not be disconnected during the firmware update.

VIII. Select the right COM port and speed. Note that to go faster than 115200 you need a

special hardware on the PC. Then Press the Download button and within 5 seconds poweron the GE864 / GC864.

Telit GE864 and GC864

Product Description

IX. Wait for the end of programming green message OK

80273ST10008A Rev. 3 - 10/02/06

The Telit GE864 / GC864 module is now programmed with the new firmware.

NOTE: the above pictures show how the application dialogs appear for the GM862 product. The GE864 / GC864 TFI application will look similar.

4.2 Update the GE864 firmware on your interface board

In order to allow you to update the GE864 firmware on a module already mounted on the interface board, is mandatory to foresee on the interface board the presence of the following line (Test Point or connector):

• C103/TXD Pin 37

• C104/RXD Pin 38

• ON_OFF Pin 4

• GND line (Pin 28 or 8 or 17 or 36 )

Is also recommended to foresee the presence on the interface board of the following line (Test Point or connector):

Telit GE864 and GC864

Product Description

• TX_TRACE Pin 25

• RX_TRACE Pin 26

• GND line (Pin 28 or 8 or 17 or 36 )

80273ST10008A Rev. 3 - 10/02/06

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

5 Software Features

5.1 Enhanced Easy GPRS Extension

5.1.1 Overview

The Easy GPRS feature allows the Telit GE864 / GC864 user to contact a device in internet and

establish with it a raw data flow over the GPRS and Internet networks. This feature can be seen as a way to obtain a "virtual" serial connection between the Application

Software on the Internet machine involved and the controller of the Telit GE864 / GC864 module,

regardless of all the software stacks underlying. An example of the protocol stack involved in the devices is reported:

Controller Device

Device ( Internet)

Local Remote

Application Application

EASY EASY TCP/UDP

GPRS GPRS

Serial Data

Line on

Driver Board

V.24 V.24

Telit

GE864 / GC864 networks

<<<---------------------------------- Virtual Serial link ---------------------------------->>>

Firewall

IP IP IP IP

network interworking

L2 L2

L1 L1

Remote

TCP/UDP

This particular implementation allows to the devices interfacing to the Telit GE864 / GC864 module the

use of the GPRS and Internet packet service without the need to have an internal TCP/IP stack

since this function is embedded inside the module. The new Enhanced version of the Easy GPRS

overcomes some of the known limitations of the previous implementation and implements some new features such as:

- Keep the GPRS context active even after the closing of a socket, allowing the application to keep the same IP address;

- Also Mobile terminated (incoming) connections can be made, now it is possible to receive incoming TCP connection requests;

- A new internal firewall has been implemented in order to guarantee a certain level of security on internet applications.

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

5.1.2 Easy GPRS definition

The Easy GPRS feature provides a way to replace the need of an Internet TCP/IP stack at the terminal equipment side. The steps that will be required to obtain a virtual serial connection (that is actually a socket) to the Internet peer are:

a) configuring the GPRS Access b) configuring the embedded TCP/IP stack behavior c) defining the Internet Peer to be contacted d) request the GPRS and socket connections to be opened (host is connected) e) exchange raw data f) close the socket and GPRS context

All these steps are achieved through AT commands. As for common modem interface, two logical status are involved: command mode and data traffic mode.

- In Command Mode (CM), some AT commands are provided to configure the Data Module Internet stack and to start up the data traffic.

- In data traffic mode (Socket Mode, SKTM), the client can send/receive a raw data stream which will be encapsulated in the previously configured TCP / IP packets which will be sent to the other side of the network and vice versa. Control plane of ongoing socket connection is deployed internally to the module.

5.1.2.1 Configuring the GPRS access

The GPRS access configuration is done by setting:

- the GPRS context number 1 parameters (see +CGDCONT command)

- the Authentication parameters: User Name and Password (see commands #USERID, #PASSW)

5.1.2.2 Configuring the embedded TCP/IP stack

The TCP/IP stack behavior must be configured by setting:

- the packet default size (see command #PKTSZ)

- the data sending timeout (see command #DSTO)

- the socket inactivity timeout (see command #SKTTO)

5.1.2.3 Defining the Internet peer to be contacted

As last setting definition, the host to be contacted and on which port/protocol must be set:

- the socket definition (see command #SKTSET)

Telit GE864 and GC864

Product Description

DNS to obtain the IP address relative to the host nick name provided. This process of context activation and DNS query may require a bit more time and requires that the GPRS network coverage is good enough to permit data transfers.

80273ST10008A Rev. 3 - 10/02/06

5.1.2.4 Open the connection with the internet host

With the AT#SKTOP all the process required to connect with the internet host starts:

- GE864 / GC864 activates the first context

- GE864 / GC864 proceeds to the authentication with the parameters specified

- Eventually does the DNS query to resolve the IP address of the host name internet peer

- GE864 / GC864 establishes a TCP/UDP (depending on the parameter request) connection with the given internet host

- Once the connection is up the module reports the code: CONNECT

From this moment the data incoming in the serial port is packet and sent to the Internet host, while the data received from the host is buffered and flushed to the Terminal Equipment.

5.1.2.5 Close the Socket and deactivate the context

The connection can be closed because of:

- remote host TCP connection close

- socket inactivity timeout

- Terminal Equipment by issuing the escape sequence "+++"

- Network deactivation

: if in the raw data to be sent there's an escape sequence, then the TE must work it out and

Note sent it in a different fashion to guarantee that the connection is not closed. The pause time is defined in the parameter S12. On the reception of an escape sequence the GE864 / GC864 closes the connection, deactivates the GPRS context returning to command mode and issuing the NO CARRIER code.

5.1.3 Enhanced Easy GPRS Outgoing connection

The New Enhanced Easy GPRS feature provides a way to place outgoing TCP/UDP connections and keep the same IP address after a connection, leaving the GPRS context active. The steps that will be required open a socket and close it without closing the GRPS context are:

g) configuring the GPRS Access h) configuring the embedded TCP/IP stack behavior i) defining the Internet Peer to be contacted j) request the GPRS context to be activated k) request the socket connection to be opened l) exchange data m) close the TCP connection while keeping the GPRS active

All these steps are achieved through AT commands. As for common modem interface, two logical statuses are involved: command mode and data traffic mode.

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

- In Command Mode (CM), some AT commands are provided to configure the Data Module Internet stack and to start up the data traffic.

5.1.3.1 Configuring the GPRS access

The GPRS access configuration is done by setting:

- the GPRS context number 1 parameters (see +CGDCONT command)

- the Authentication parameters: User Name and Password (see commands #USERID, #PASSW)

5.1.3.2 Configuring the embedded TCP/IP stack

The TCP/IP stack behavior must be configured by setting:

- the packet default size (see command #PKTSZ)

- the data sending timeout (see command #DSTO)

- the socket inactivity timeout (see command #SKTTO)

5.1.3.3 Defining the Internet peer to be contacted

As last setting definition, the host to be contacted and on which port/protocol must be set:

- the socket definition (see command #SKTSET)

This command permits also to specify the host name instead of its IP address, if a host name is given to the set command, then the module stores it as a host nick name. It is care of the module user to guarantee that the host nick name provided corresponds to an existing internet peer. If an host nick name has been given then, while opening the connection in response to the AT#SKTOP command, the module will autonomously activate a GPRS connection and query its DNS to obtain the IP address relative to the host nick name provided. This process of context activation and DNS query may require a bit more time and requires that the GPRS network coverage is good enough to permit data transfers. Note that this setting command is not needed if the new #SKTD command is used.

5.1.3.4 Request the GPRS context to be activated

With the new command #GPRS you can activate or deactivate a GPRS context INDEPENDENTLY from the TCP socket opening:

AT#GPRS=1 activates the context, AT#GPRS=0 deactivates the context

Therefore with the AT#GPRS=1 command the module

- GE864 / GC864 activates the context previously defined with AT+CGDCONT

- GE864 / GC864 proceeds to the authentication with the parameters specified

Telit GE864 and GC864

Product Description

Note that activating a context implies getting an IP address from the network and this will be maintained throughout the session. The response code to the AT#GPRS=1 command reports the IP address obtained from the network, allowing the user to report it to his server or application. Deactivating the context implies freeing the network resources previously allocated to the device.

80273ST10008A Rev. 3 - 10/02/06

5.1.3.5 Open the connection with the internet host

With the new command #SKTD (socket Dial) the TCP/UDP request to connect with the internet host starts:

- Eventually does the DNS query to resolve the IP address of the host name internet peer

- GE864 / GC864 establishes a TCP/UDP (depending on the parameter request) connection with the given internet host

- Once the connection is up the module reports the code: CONNECT

Note that the peer specifications of this socket Dial are within the command and not the one stored with #SKTSET command. From this moment the data incoming in the serial port is packet and sent to the Internet host, while the data received from the host is serialised and flushed to the Terminal Equipment.

NOTE: this command differently from the AT#SKTOP DOES NOT automate all the process of activating the GPRS, if no GPRS is active the command reports ERROR; therefore before issuing this command the GPRS shall be activated with AT#GPRS=1 command. In the same manner, when disconnecting the #SKTD command does not close the GPRS context, leaving it active for next connections until an AT#GPRS=0 command is issued or the network requests a context closing.

5.1.3.6 Close the Socket without deactivating the context

The connection can be closed because of:

- remote host TCP connection close

- socket inactivity timeout

- Terminal Equipment by issuing the escape sequence "+++"

- Network deactivation

Note: if in the raw data to be sent there's an escape sequence, then the TE must work it out and sent it in a different fashion to guarantee that the connection is not closed. The pause time is defined in the parameter S12. On the reception of an escape sequence if the socket was opened with the AT#SKTD command, the GE864 / GC864 closes the connection, does not deactivate the GPRS context and returns to command mode issuing the NO CARRIER code.

5.1.4 Enhanced Easy GPRS Incoming Connection

The New Enhanced Easy GPRS feature provides a way to accept incoming TCP/UDP connections and keep the same IP address after a connection, leaving the GPRS context active.

Telit GE864 and GC864

Product Description

The steps that will be required to open a socket in listen, waiting for connection requests from remote hosts and accept these request connections only from a selected set of hosts, then close it without closing the GRPS context are:

a) Configuring the GPRS Access b) Configuring the embedded TCP/IP stack behavior (see par. c) Defining the Internet Peer that can contact this device (firewall settings) (see par. d) Requesting the GPRS context to be activated (see par. e) Request the socket connection to be opened in listen (see par. f) Receive connection requests (see par. g) exchange data h) Close the TCP connection while keeping the GPRS active (see par.

All these steps are achieved through AT commands. As for common modem interface, two logical statuses are involved: command mode and data traffic mode.

- In Command Mode (CM), some AT commands are provided to configure the Data Module Internet stack and to start up the data traffic.

5.1.4.3)

80273ST10008A Rev. 3 - 10/02/06

5.1.3.2)

5.1.4.1)

5.1.3.4)

5.1.4.2)

5.1.3.6)

5.1.4.1 Defining the Internet Peer that can contact this device (firewall settings)

The GE864 / GC864 have an internal Firewall that controls the behavior of the incoming connections to the module. The firewall applies for INCOMING (listening) connections; OUTGOING connections will be always done regardless of the firewall settings. Firewall General policy is DROP, therefore all packets that are not included into an ACCEPT chain rule will be silently discarded.

When a packet incomes from the IP address <incoming IP>, the firewall chain rules will be scanned for matching with the following criteria:

<incoming IP> & <net mask> = <ip_address> ?

if the result is yes, then the packet is accepted and the rule scan is finished, otherwise the next chain is taken into account until the end of the rules when the packet is silently dropped if no matching was found.

For example, let assume we want to accept connections only from our devices which are on the IP addresses ranging from:

197.158.1.1 to 197.158.255.255

We need to add the following chain to the firewall:

Telit GE864 and GC864

Product Description

AT#FRWL=1,"197.158.1.1","255.255.0.0"

80273ST10008A Rev. 3 - 10/02/06

5.1.4.2 Request the socket connection to be opened in listen

With the new command #SKTL (socket Listen) the TCP request to start listening for connection requests is executed:

- GE864 / GC864 opens a listening socket on the port specified, waiting for incoming TCP

connections (depending on the parameter request) with the internet hosts

The parameters that shall be specified are the local port where packets shall be received, the type of socket and the closing behavior.

5.1.4.3 Receiving connection requests

Once the connection request is received, the module reports an indication of connection with an unsolicited code +CONN FROM: <remote address>

- then connection is accepted and once it is up the module reports the code:

CONNECT

From this moment the data incoming in the serial port is packet and sent to the Internet host, while the data received from the host is serialised and flushed to the Terminal Equipment. Note that the connections request are FIRST screened in the firewall, then if they are accepted they pass to the listening socket; therefore only hosts that are in the ACCEPT chain rules of the firewall can induce a connection request, the other host requests will be silently discarded without any indication to the remote host (for security reasons). Once the connection is received and closed, the socket is not anymore in listen. If the application needs again to be in listen, then it shall send again the socket listen #SKTL command.

NOTE: this command differently from the AT#SKTOP DOES NOT automate all the process of activating the GPRS, if no GPRS is active the command reports ERROR; therefore before issuing this command the GPRS shall be activated with AT#GPRS=1 command. In the same manner, when disconnecting the #SKTL command does not close the GPRS context, leaving it active for next connections until an AT#GPRS=0 command is issued or the network requests a context closing.

5.1.4.4 Known limitations

The implementation of the EASY GPRS feature has the following known limitations:

- Only one socket can be opened at a time, no multiple socket connections can be made;

- Only one connection request can be accepted at a time, subsequent requests will be silently

discarded.

- Only the first GPRS context is associated with this feature;

- It is taken for granted that external processor will be able to handle at least a limited v.24

implementation: RTS, CTS and, highly recommended, DCD lines; this because software flow control is not applicable to the feature;

- Due to the particularity of this feature, the flow control of both the directions uplink and

downlink is interlocked

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

5.2 Jammed Detect & Report Extension

5.2.1 Overview

The Jammed Detect & Report feature allows a Telit GE864 / GC864 to detect the presence of a

disturbing device such as a Communication Jammer and give indication to the user and/or send a report of that to the network. This feature can be very important in alarm, security and safety applications that rely on the module for the communications. In these applications, the presence of a Jammer device can compromise the whole system reliability and functionality and therefore shall be recognized and reported either to the local system for countermeasure actions or to the network providing remote actions. An example scenario could be an intrusion detection system that uses the module for sending the alarm indication for example with an SMS to the system owner, and a thief income using a Jammer to prevent any communication between the GSM module and the network. In such a case, the module detects the Jammer presence even before the break in and can trigger an alarm siren, other communication devices (PSTN modem) or directly report this condition to the network that can provide further security services for example sending SMS to the owner or police. Obviously this last service depends also from network infrastructure support and it may not be supported by some networks.

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

5.3 Easy Script Extension - Python interpreter

5.3.1 Overview

This feature is available only on the Telit GE864-PY and GC864-PY.

The Easy Script Extension is a feature that allows driving the modem "internally" writing the controlling application directly in a nice high level language: Python. The Easy Script Extension is aimed at low complexity applications where the application was usually done by a small microcontroller that managed some I/O pins and the GE864-PY and GC864-PY through the AT command interface. A schematic of such a configuration can be:

In order to eliminate this external controller, and further simplify the programming of the sequence

FLASH ROM

GSM-GPRS

Protocol Stack

FLASH ROM

memory

EXTERNAL

CONTROLLER

GE864 / GC864

RAM

PHYSICAL

AT SERIAL PORT

T COMMANDS

GPRS MODEM

ENGINE

HARDWARE RESOURCES

RAM

for

GSM-GPRS

modem

Protocol Stack

of operations, inside the GE864 / GC864-PY it is included:

- Python script interpreter engine v. 1.5.2+

- around 3MB of Non Volatile Memory room for the user scripts and data

Telit GE864 and GC864

Product Description

- 1.5 MB RAM reserved for Python engine usage

A schematic of this approach is:

GE864-PY / GC864-PY

FLASH ROM

PYTHON 1.5.2+

Available

User NVM

INTERPRETER

ENGINE

FLASH

Memory

(3Mbyte)

GSM-GPRS

Protocol

Stack

FLASH ROM

memory

VIRTUAL INTERNAL

AT SERIAL PORT

GPRS MODEM

ENGINE

80273ST10008A Rev. 3 - 10/02/06

MDM module

T COMMANDS

RAM

Available

RAM for

Python

Interpreter

(1.5 Mbyte)

RAM

for

GSM-GPRS

modem

Protocol

Stack

HARDWARE RESOURCES

5.3.2 Python 1.5.2+ Copyright Notice

The Python code implemented into the GE864-PY is copyrighted by Stichting Mathematisch Centrum, this is the license: Copyright © 1991-1995 by Stichting Mathematisch Centrum, Amsterdam, The Netherlands. All Rights Reserved Copyright (c) 1995-2001 Corporation for National Research Initiatives; All Rights Reserved. Copyright (c) 2001, 2002, 2003, 2004 Python Software Foundation; All Rights Reserved. All Rights Reserved are retained in Python. Permission to use, copy, modify, and distribute this software and its documentation for any purpose and without fee is hereby granted, provided that the above copyright notice appear in all copies and that both that copyright notice and this permission notice appear in supporting documentation, and that the names of Stichting Mathematisch Centrum or CWI or Corporation for

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

National Research Initiatives or CNRI not be used in advertising or publicity pertaining to distribution of the software without specific, written prior permission. While CWI is the initial source for this software, a modified version is made available by the Corporation for National Research Initiatives (CNRI) at the Internet address

ftp://ftp.python.org.

STICHTING MATHEMATISCH CENTRUM AND CNRI DISCLAIM ALL WARRANTIES WITH REGARD TO THIS SOFTWARE, INCLUDING ALL IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS, IN NO EVENT SHALL STICHTING MATHEMATISCH CENTRUM OR CNRI BE LIABLE FOR ANY SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES OR ANY DAMAGES WHATSOEVER RESULTING FROM LOSS OF USE, DATA OR PROFITS, WHETHER IN AN ACTION OF CONTRACT, NEGLIGENCE OR OTHER TORTIOUS ACTION, ARISING OUT OF OR IN CONNECTION WITH THE USE OR PERFORMANCE OF THIS SOFTWARE.

5.3.3 Python implementation description

Python scripts are text files; it is possible to run one Python script in the Telit GE864-PY / GC864PY.

The Python script is stored in NVM memory inside the module. Moreover, there is a file system inside the module that allows to write and read files with different names on one single level (no subdirectories are supported). The Python script is executed in a task inside the Telit GE864 / GC864 at the lowest priority, making sure this does not interfere with GPRS/GSM normal operations. This allows serial ports, protocol stack etc. to run independently from the Python script. The Python script interacts with the Telit GE864 / GC864 functionality through four build-in interfaces.

MDM

SPI

MOD

Print command

Serial port 1

Python engine

SER

Serial port 0

IIC

GPIO

Telit GE864 and GC864

Product Description

The MDM interface is the most important one. It allows Python script to send AT commands, receive responses and unsolicited indications, send data to the network and receive data from the network during connections. It is quite the same as the usual serial port interface in the Telit GE864 / GC864. The difference is that this interface is not a real serial port but just an internal software bridge between Python and mobile internal AT command handling engine. All AT commands working in the Telit GE864 / GC864 are working in this software interface as well. Some of them have no meaning on this interface, such as those regarding serial port settings. The usual concept of flow control keeps its meaning over this interface, but it's managed internally. The SER interface allows Python script to read from and write to the REAL, physical serial port where usually the AT command interface resides, for example to read NMEA information from a GPS device. When Python is running this serial port is free to be used by Python script because it is not used as AT command interface since the AT parser is mapped into the internal virtual serial port. No flow control is available from Python on this port. The GPIO interface allows Python script to handle general purpose input output faster than through AT commands, skipping the command parser and going directly to control the pins. The MOD interface is a collection of useful functions. For the debug, the print command is directly forwarded on the EMMI TX pin (second serial port) at 9600 baud 8N1.

80273ST10008A Rev. 3 - 10/02/06

5.3.4 Python core supported features

The Python core version is 1.5.2+ (string methods added to 1.5.2). You can use all Python statements and almost all Python built-in types and functions. The following are not supported:

complex; float; long; docstring.

Available modules are

marshal, imp, __main__, __builtin__, sys md5

All the others are not supported.

5.3.5 Python Build-in Custom Modules

Several build in custom modules have been included in the python core, specifically aimed at the hardware environment of the module. The build in modules included are:

MDM: interface between Python and mobile internal AT command handling; SER: interface between Python and mobile internal serial port ASC0 direct handling; GPIO: interface between Python and mobile internal general purpose input output direct handling; MOD: interface between Python and mobile miscellaneous functions. IIC: custom software Inter IC bus that can be mapped on creation over almost any GPIO pin

available.

SPI: custom software Serial Protocol Interface bus that can be mapped on creation over almost

any GPIO pin available.

More details about the Python modules are available in the reference guide.

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

5.4 AT Commands

The Telit GE864 / GC864 module can be driven via the serial interface using the standard AT

commands

The Telit GE864 / GC864 module is compliant with:

1. Hayes standard AT command set, in order to maintain the compatibility with existing SW

2. ETSI GSM 07.07 specific AT command and GPRS specific commands.

3. ETSI GSM 07.05 specific AT commands for SMS (Short Message Service) and CBS (Cell

4. FAX Class 1 compatible commands

Moreover the Telit GE864 / GC864 module supports also Telit proprietary AT commands for special

purposes.

The following table lists all supported AT commands and related brief description.

Hayes Compliant AT Commands

Generic Modem Control QUAD PY

&F Reset base section factory profile configuration &F1 Reset full factory profile configuration Z Soft reset +FCLASS Select active service class &Y Designate a default reset basic profile &P Designate a default reset full profile &W Store current configuration &Z Store telephone number in the internal phonebook &N Display internal phonebook stored numbers +GMI Request manufacturer identification +GMM Request model identification +GMR Request revision identification +GCAP Request capabilities list +GSN Request serial number &V Display current configuration & profile &V0 Display current configuration & profile &V1 Display S registers values &V2 Display last connection statistics &V3 Display S registers values \V Single line connect message %L Report line signal level %Q Report line quality +GCI Select the country of installation L Monitor speaker loudness M Monitor speaker mode

programs.

Broadcast Service)

At Commands availability for

GE864, GC864 models:

• •

The AT is an ATTENTION command and is used as a prefix to other parameters in a string. The AT command combined with other parameters can be set up in the communications package or typed in manually as a command line instruction.

Telit GE864 and GC864

Product Description

DTE - modem interface control QUAD PY

E Command echo Q Quiet result codes V Result code form X Extended result codes I Request identifier and software checksum &C Data carrier detect (DCD) control &D Data terminal ready (DTR) control &K Flow control &Q Sync/async mode &S Data set ready (DSR) control \R Ring (RI) control +IPR Fixed DTE interface rate +IFC DTE - DTA flow control +ILRR DTE - modem rate reporting +ICF DTE - modem character format

Call Control QUAD PY

D Dial T Set tone dial P Set pulse dial A Answer A/ Last command automatic repetition H Disconnect O Return to On Line Mode &G Guard tone

Modulation control QUAD PY

+MS Modulation control

\N Operating mode

Compression control QUAD PY

+DS Set data compression +DR Data compression reporting

Break control QUAD PY

\B Transmit break to remote \K Break handling

S parameters QUAD PY

S0 Number of rings to auto answer S1 Ring counter S2 Escape character S3 Carriage return character S4 Line feed character S5 Backspace character S7 Wait time for carrier, silence or dial tone S12 Escape prompt delay S25 Delay to DTR off S30 Disconnect inactivity timer S38 Delay before forced hang up

ETSI GSM 07.07 AT Commands QUAD PY

+CGMI Request manufacturer identification +CGMM Request model identification +CGMR Request revision identification +CGSN Request product serial number identification +CSCS Select TE character set +CIMI Request international mobile subscriber identity (IMSI)

Enable/disable line quality monitor and auto retrain or fallback / fallforward

80273ST10008A Rev. 3 - 10/02/06

• •

Telit GE864 and GC864

Product Description

Call control QUAD PY

+CBST Select bearer service type +CRLP Radio link protocol +CR Service reporting control +CEER Extended error report +CRC Cellular result codes +CSNS Single numbering scheme

Network service handling QUAD PY

+CNUM Subscriber number +COPN Read operator names +CREG Network registration report +COPS Operator selection +CLCK Facility lock/ unlock +CPWD Change facility password +CLIP Calling line identification presentation +CLIR Calling line identification restriction +CCFC Call forwarding number and conditions +CCWA Call waiting +CHLD Call holding services +CUSD Unstructured supplementary service data +CAOC Advice of charge +CLCC List current calls +CSSN SS Notification +CCUG Closed User Group supplementary service control

Mobile Equipment control QUAD PY

+CPAS Phone activity status +CFUN Set phone functionality (Power Saving Management) +CPIN Enter PIN +CSQ Signal quality +CPBS Select phonebook memory storage +CPBR Read phonebook entries +CPBF Find phonebook entries +CPBW Write phonebook entry +CCLK Clock Management +CALA Alarm Management +CALM Alert sound mode +CRSL Ringer sound level +CLVL Loudspeaker volume level +CMUT Microphone mute control +CACM Accumulated call meter +CAMM Accumulated call meter maximum +CPUC Price per unit and currency table +CCID Read ICCID (Integrated Circuit Card Identification)

Mobile equipment errors QUAD PY

+CMEE Report mobile equipment error

Voice Control (TIA IS-101) QUAD PY

+VTS: DTMF tones transmission

Commands For GPRS QUAD PY

+CGACT PDP context activate or deactivate +CGATT GPRS attach or detach +CGDATA Enter data state +CGDCONT Define PDP context +CGPADDR Show PDP address +CGREG GPRS network registration status +CGQMIN Quality of service profile (minimum acceptable)

80273ST10008A Rev. 3 - 10/02/06

• •

Telit GE864 and GC864

Product Description

+CGQREQ Quality of service profile (requested)

Commands For Battery Charger QUAD PY

+CBC Battery Charge

ETSI GSM 07.05 AT Commands for SMS and CB services QUAD PY

+CSMS Select message service +CPMS Preferred message storage +CMGF Message format +CSMP Set parameters in text mode +CSDH Show parameters in text mode +CSAS Save setting text mode +CRES Restore text mode settings +CSCB Select Cell Broadcast Message types

Message configuration QUAD PY

+CSCA Service center address

Message receiving and reading QUAD PY

+CNMI New message indications to Terminal Equipment +CMGL List messages +CMGR Read message

Message sending and writing QUAD PY

+CMGS Send message +CMSS Send message from storage +CMGW Write message to memory +CMGD Delete message

Custom AT Commands QUAD PY

#CGMI Request manufacturer identification #CGMM Request model identification #CGMR Request revision identification #CGSN Request product serial number identification #CIMI Request international mobile subscriber identity (IMSI) #CAP Change Audio Path #SRS Select ringer sound #SRP Select Ringer Path #STM Signalling Tones Mode #PCT Display PIN Counter #SHDN Software Shut Down #WAKE Wake from Alarm mode #QTEMP Query Temperature overflow #SGPO Set General Purpose Output #GGPI Read General Purpose Input #GPIO General Purpose Input/Output pin control #ADC Read Analog/Digital Converter Input #VAUX Auxiliary Voltage Output Control #MONI Monitor Cells #QSS Query SIM Status #ACAL Set Automatic Call #SMOV SMS Overflow #SHFEC Set Handsfree echo canceller #HFMICG Handsfree Microphone Gain #HSMICG Handset Microphone Gain #SHFSD Set Handsfree side tone #/ Repeat last command #NITZ Network Timezone #BND Select Band

FTP CLIENT AT Commands QUAD PY

#FTPOPEN FTP Open command

80273ST10008A Rev. 3 - 10/02/06

• •

Telit GE864 and GC864

Product Description

#FTPCLOSE FTP Close command #FTPPUT FTP Put command #FTPGET FTP Get command #FTPTYPE FTP Type command #FTPMSG FTP read message command #FTPDELE FTP Delete command #FTPPWD FTP print working directory command #FTPCWD FTP change working directory command #FTPLIST FTP List command

FAX Class 1 Commands QUAD PY

+FCLASS Select active service class +FMI Report manufacturer ID +FMM? Report model ID +FMR Report revision ID

Transmission/Reception control QUAD PY

+FTS Stop Transmission and pause +FRS Wait for receive silence +FTM Transmit data modulation +FRM Receive data modulation +FTH Transmit data with HDLC framing +FRH Receive data with HDLC framing

Serial port control QUAD PY

+FLO Select flow control specified by type +FPR Select serial port rate +FDD Double escape character replacement control

Enhanced Easy GPRS custom AT command Definition QUAD PY

#USERID Authentication User ID control #PASSW Authentication Password control #PKTSZ Packet Size control #DSTO Data Sending TimeOut control #SKTTO Socket inactivity timeout control #SKTSET Socket definition control #SKTOP Socket Open command #QDNS Query DNS #SKTCT Socket TCP Connection Timeout #SKTSAV Socket Parameters Save Command #SKTRST Socket Parameters Reset Command #GPRS GPRS context activation control #SKTD Socket Dial #SKTL Socket Listen #FRWL Firewall setup

Easy Camera Extension - Camera Management QUAD PY

#CAMON Camera ON #CAMOFF Camera OFF #TPHOTO Camera Take Photo #RPHOTO Camera Read Photo #OBJL Object List #OBJR Object Read #CAMQUA Camera Select Quality of Photo #CMODE Camera Select Operating MODE

Email management QUAD PY

#ESMTP Email SMTP server #EADDR Email sender address #EUSER Email authentication USER NAME #EPASSW Email authentication PASSWORD

80273ST10008A Rev. 3 - 10/02/06

• •

Telit GE864 and GC864

Product Description

#SEMAIL Send Email #EMAILACT E-mail context activation control #EMAILD E-mail socket dial #ESAV Email Parameters Save Command #ERST Email Parameters Reset Command

Easy Scan Extension QUAD PY

#CSURV

#CSURVC Network Survey in computer friendly format #CSURVU Network Survey of user defined 900/1800/1900 chan. #CSURVUC Network Survey in computer friendly format #CSURVF Network Survey Format

Jammed Detect & Report custom AT command QUAD PY

#JDR Jammed Detect & Report

PYTHON Script Management commands QUAD PY

#WSCRIPT Write script command #ESCRIPT Select Active script command #RSCRIPT Read script command #LSCRIPT List script names command #DSCRIPT Delete script command #REBOOT Reboot command

Network Survey of the complete 900/1800/1900 Network

80273ST10008A Rev. 3 - 10/02/06

• •

•

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

6 Conformity Assessment Issues

The Telit GE864 and GC864 are assessed to be conform to the R&TTE Directive.

If the antenna connected to the module is conforming to the requirements specified under this

document, it requires no further evaluation under Article 3.2 of the R&TTE Directive and do not

require further involvement of a R&TTE Directive Notified Body for the final product. In all other cases, or if the manufacturer of the final product is in doubt then the equipment

integrating the radio module must be assessed against Article 3.2 of the R&TTE Directive.

In all cases assessment of the final product must be made against the Essential requirements of

the R&TTE Directive Articles 3.1(a) and (b), safety and EMC respectively, and any relevant Article 3.3 requirements.

The Telit GE864 and GC864 are conform with the following European Union Directives:

 R&TTE Directive 1999/5/EC (Radio Equipment & Telecommunications Terminal

Equipments)

 Low Voltage Directive 73/23/EEC and product safety  Directive 89/336/EEC for conformity for EMC

In order to satisfy the essential requisite of the R&TTE 99/5/EC directive, the GE864 module is compliant with the following standards:

 GSM (Radio Spectrum). Standard: EN 301 511 and 3GPP 51.010-1  EMC (Electromagnetic Compatibility). Standards: EN 301 489-1 and EN 301 489-7  LVD (Low Voltage Directive) Standards: EN 60 950

In this document and the Hardware User Guide, Software User Guide all the information you may need for developing a product meeting the R&TTE Directive is included.

Furthermore the Telit GE864 / GC864 module is FCC Approved as module to be installed in other

devices. This device is to be used only for fixed and mobile applications. If the final product after integration is intended for portable use, a new application and FCC is required.

The Telit GE864 / GC864 is conforming with the following US Directives:

− Use of RF Spectrum. Standards: FCC 47 Part 24 (GSM 1900)

− EMC (Electromagnetic Compatibility). Standards: FCC47 Part 15

To meet the FCC's RF exposure rules and regulations:

- The system antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all the persons and must not be co-located or operating in conjunction with any other antenna or transmitter.

- The system antenna(s) used for this module must not exceed 3 dBi for mobile and fixed or mobile operating configurations.

- Users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance.

Manufacturers of mobile, fixed or portable devices incorporating this module are advised to clarify any regulatory questions and to have their complete product tested and approved for FCC compliance.

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

6.1 GE864-QUAD Conformity Assessment

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

7 SAFETY RECOMMENDATIONS

READ CAREFULLY

Be sure the use of this product is allowed in the country and in the environment required. The use of this product may be dangerous and has to be avoided in the following areas:

 Where it can interfere with other electronic devices in environments such as hospitals,

airports, aircrafts, etc

 Where there is risk of explosion such as gasoline stations, oil refineries, etc

It is responsibility of the user to enforce the country regulation and the specific environment regulation.

Do not disassemble the product; any mark of tampering will compromise the warranty validity.

We recommend following the instructions of the hardware user guides for a correct wiring of the product. The product has to be supplied with a stabilized voltage source and the wiring has to be conforming to the security and fire prevention regulations.

The product has to be handled with care, avoiding any contact with the pins because electrostatic discharges may damage the product itself. Same cautions have to be taken for the SIM, checking carefully the instruction for its use. Do not insert or remove the SIM when the product is in power saving mode.

The system integrator is responsible of the functioning of the final product; therefore, care has to be taken to the external components of the module, as well as of any project or installation issue, because the risk of disturbing the GSM network or external devices or having impact on the security. Should there be any doubt, please refer to the technical documentation and the regulations in force.

Every module has to be equipped with a proper antenna with specific characteristics. The antenna has to be installed with care in order to avoid any interference with other electronic devices and has to guarantee a minimum distance from the body (20 cm). In case of this requirement cannot be satisfied, the system integrator has to assess the final product against the SAR regulation.

The European Community provides some Directives for the electronic equipments introduced on the market. All the relevant information’s are available on the European Community website:

http://europa.eu.int/comm/enterprise/rtte/dir99-5.htm

The text of the Directive 99/05 regarding telecommunication equipments is available, while the applicable Directives (Low Voltage and EMC) are available at:

http://europa.eu.int/comm/enterprise/electr_equipment/index_en.htm

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

8 GE864 and GC864 Technical Support

Telit’s technical support to GE864 and GC864 wireless modems customers consists in:

• Technical documentation

>Modules > selected model.

• Engineering support

conditions.

: available for download into the Website www.telit.com >Products

: accessible via E-Mail service with 48 hr replies assured under normal

Telit GE864 and GC864

Product Description

9 List of acronyms

ACM ASCII AT CB CBS CCM CLIP CLIR CMOS CR CSD CTS DAI DCD DCE DRX DSR DTA DTE DTMF DTR EMC ETSI FTA GPRS GSM HF IMEI IMSI IRA ITU IWF LCD LED LF ME MMI MO MS MT OEM PB PDU PH PIN PLMN

Accumulated Call Meter American Standard Code for Information Interchange Attention commands Cell Broadcast Cell Broadcasting Service Call Control Meter Calling Line Identification Presentation Calling Line Identification Restriction Complementary Metal-Oxide Semiconductor Carriage Return Circuit Switched Data Clear To Send Digital Audio Interface Data Carrier Detected Data Communications Equipment Data Receive Data Set Ready Data Terminal Adaptor Data Terminal Equipment Dual Tone Multi Frequency Data Terminal Ready Electromagnetic Compatibility European Telecommunications Equipment Institute Full Type Approval (ETSI) General Radio Packet Service Global System for Mobile communication Hands Free International Mobile Equipment Identity International Mobile Subscriber Identity Internationale Reference Alphabet International Telecommunications Union Inter-Working Function Liquid Crystal Display Light Emitting Diode Linefeed Mobile Equipment Man Machine Interface Mobile Originated Mobile Station Mobile Terminated Other Equipment Manufacturer Phone Book Protocol Data Unit Packet Handler Personal Identity Number Public Land Mobile Network

80273ST10008A Rev. 3 - 10/02/06

Telit GE864 and GC864

Product Description

PUCT PUK RACH RLP RMS RTS RI SCA SIM SMD SMS SMSC SS TIA UDUB USSD

Price per Unit Currency Table PIN Unblocking Code Random Access Channel Radio Link Protocol Root Mean Square Ready To Send Ring Indicator Service Center Address Subscriber Identity Module Surface Mounted Device Short Message Service Short Message Service Center Supplementary Service Telecommunications Industry Association User Determined User Busy Unstructured Supplementary Service Data

80273ST10008A Rev. 3 - 10/02/06

Telit GE864 and GC864

Product Description

80273ST10008A Rev. 3 - 10/02/06

10 Document Change Log

Revision Date Changes

DRAFT #0 Draft for comments DRAFT #1 23/06/2005 Updated Para 2.16 Interfaces on GE864 and Pins allocation

Added BGA Balls layout Updated Para 2.17 Updated Para 2.18 Updated Para 3

DRAFT #2 04/08/2005 1 Overview: updated

2.3 Environmental requirements: changed

2.6 reference sensitivity: updated

2.16: Interfaces on GE864 and Pins allocation: changed

2.17 with all info regarding the soldering process: changed Disclaimer: added Safety Recommendation: added AT commands Availability table: added

ISSUE #3 25/01/2006 GC864 drawings and size: added

GC864 Antenna connector: added RF Transmission Monitor: added DAC Converter: changed GE864 balls allocation: E10 ball now reserved GC864 pins allocation: added Mounting the GC864 on your board: added Conformity assessment Issues: changed GE864-QUAD Conformity assessment: added Safety Recommendations: changed GE864 and GC864 Technical Support: changed

Telit Wireless Solutions GE864 Series, GE864-QUAD, GC864 Series, GC864-PY, GC864-QUAD Product Description

Specifications and Main Features

Frequently Asked Questions

User Manual

1 Overview

2 General Product Description

2.1 Size

2.1.1 GE864

2.1.2 GC864

2.2 Weight

2.3 Environmental requirements

2.3.1 Temperature range

2.3.2 Vibration Test (non functional)

2.3.3 RoHS compliance

2.4 Operating Frequency

2.5 Transmitter output power

2.6 Reference sensitivity

2.7 Antenna

2.7.1 GC864 Antenna connector

2.8 SIM card holder support (GC864 only)

2.9 Supply voltage

2.10 Power consumption

2.11 Embodied Battery charger

2.12 User Interface

2.12.1 Speech Coding

2.12.2 SIM Reader

2.12.3 SMS

2.12.4 Real Time Clock and Alarm

2.12.5 Data/fax transmission

2.12.6 Local security management

2.12.7 Call control

2.12.8 Phonebook

2.12.9 Characters management

2.12.10 SIM related functions

2.12.11 Call status indication

2.12.12 Indication of network service availability

2.12.13 Automatic answer (Voice, Data or FAX)

2.12.14 Supplementary services (SS)

2.12.15 Acoustic signaling

2.12.16 DTMF tones

2.12.17 Buzzer output

2.12.18 RF Transmission Monitor

2.13 Logic level specifications

2.13.1 Reset signal

2.14 RTC Bypass out

2.15 VAUX power output

2.16 Audio levels specifications

2.17 Camera compatibility (EASY CAMERA)

2.18 Converters

2.18.1 ADC Converter

2.18.2 DAC Converter

2.19 Board to Board interface

2.19.1 GE864 balls allocation

2.19.2 GE864 BGA balls layout

2.19.3 GC864 pins allocation

NOTE: RESERVED pins must not be connected

2.20 Mounting the GE864 on your Board

2.20.1 General

2.20.2 Module finishing & dimensions

2.20.3 Stencil

2.20.4 PCB pad design

2.20.5 Solder paste

2.20.6 GE864 Solder reflow

2.21 Mounting the GC864 on your board

2.22 Packing system

2.22.1 GE864 orientation on the tray

2.22.2 GC864 orientation on the tray

2.22.3 Moisture sensibility

3 Evaluation Kit

3.1 Evaluation Kit description

3.1.1 Power Supply

3.1.2 Serial interface

3.1.3 Audio

3.1.4 GPIO and Leds

4 Service and firmware update

4.1 Step-by-Step upgrade procedure

4.2 Update the GE864 firmware on your interface board

5 Software Features

5.1 Enhanced Easy GPRS Extension

5.1.1 Overview
