TE-3X48RGBW PARLED AQUA
PARLED
TE-3X48RGBW
USER MANUAL
a qua
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
TE-3X48RGBW PARLED AQUA
S
TABLE OF CONTENT
PART 1 PRODUCT (GENERAL).................... ................... .............1.
1.1--P RODUCT INTROD UCTION ..................... ......... ...........................1 .
1. 2 PRODUCT FEATURE S-- .................................................................1.
1.3 TECH NICAL SPEC I F I CATIO NS-- ............................. ........................2.
1. 4 PHOTOMETRIC DATA-- ..................... ... ................... ...................... .2.
1. 5 SAFETY W ARN I NG-- ......................................................................3.
PART 2 INSTALLATION...............................................................4.
2.1--MOUN TING............... ....................... .............................................4.
2.2--POWE R CONNECTIO N....................................................... ........... 4.
2.3--SE TTIN G UP WITH A DM X512 CONTRO LLER............. ....................5.
2.3-1 - - D MX5 12 ADDRESSIN G W ITH OUT ID A DD RESS ING ... .. .. .... . ..... ..... ... ..... .. ..... .5.
2.3-2--DMX 5 1 2 ADDRESSING WITH ID ADDRE SS.......... ....... .................................5.
PART 3 DISPLAY PANEL OPERATION.........................................6.
3.1--BA SIC..........................................................................................6.
3.2--MENU.......................................................................... ................7.
3.3-- EDIT STATIC COLOU R. .................. .................................. ............8 .
3.4-- ACTIVATIN G AUTO PROGRAMS...................................... .............8.
3.5--RUN MODE......................................... ....................................... 8..
3.6 -- DMX5 1 2 SE TTING S.......................................... .. ........................9 .
3.7 --PERSONALITY.. ............................ ........................ ....... ..............9.
3.8 -- ID A DDRES S................................. ............. .......................... ......9.
3.9--EDITIN G CUSTOM PROGR AM S ............................................... . 10.
3.10--SPE CIAL SETTINGS..................................................... ............10.
3.11-- ................................................ ....................11WHITES SETTING
3.12-- ............................................... ................... 11WHITES BALANCE
3.13--A CTIVATE THE PA SSWORD ................................................ .... 1 1.
P A RT 4 USING A DMX 51 2 CONTROL L ER.. ....... .. ....... ... .. ....... ..... .1 2.
4.1--BASI C ADDR ES SING........................................................ .........12
4.2 --CHANNEL ASSIGNMENT...................................................... ......12.
4.3 --BAS IC INSTRUCT IONS FOR D MX 512 OPERA TION ... ............... ....17.
PART 5 APPENDIX.................................................. ....................18.
5.1- -TROUBLE SHOOTING ......... ............................ .................... ......18.
5.2 --M AINTENANCE ................ .................................................. ....... 19.
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
1
PRODUCT (GENERAL)
1.1 PRODUCT INTRODU CTION
This product is designed for indoor or outdoo r use. Suitable applications include wash or
e ff e ct lig h ti n g f o r a r chi t e c tu ra l, s ta g e, t he a t r e o r r oad s ho w ap p l i cati o n s . D i re c t i np u t of
DM X51 2 signal allows the units to be controlled from any DMX51 2 controller. This product
can be operated as a single unit or in multiple units for large applica tions.
1.2 PRODUCT FEATURES
LED FIXTURE
* IP67 protection rating
* RGBW Dimmer 0-100%
* Strobe
* Built-in automatic programs
* Upload custom parameters to slave fixtures
* LED display
* Display control 'lock-out'
* Direct DMX512 input
* Independent ID address
* Different white colors setting
* 'Over-heat' protection
TE-3X48RGBW PARLED AQUA
1
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
TE-3X48RGBW PARLED AQUA
1.3 TECHNICAL SPECIFICATIONS
LED MODULE
LED M ODUL E:
Voltage
Rate d Power
LED/U n it
Output/LE D
E n vi r o n m en t Te mp e r at u re
Coolin g
Dimensions
We ight
300mm
100~ 250V...50/60Hz
180W
IP67 protection rating
IP
48pcs (12 x RED / 1 2 x GREEN / 12 x BLUE/ 12 x W HITE)
3W
-20 ~ 40℃℃
Direc t air co nvection
335 x 30 0 x 235mm
9Kg
335mm
235mm
210mm
1.4 PHOTOMET RIC DATA
PHOTOMETRIC DATA
RED
3
2
1
0
1
2
3
GREEN
3
2
1
0
1
2
3
BLUE
3
2
1
0
1
2
3
403 1
2
673 0
2468
1410
2468
1080 512 294 195 LUX
4
1780 816 470 314 LUX
286 134 75 49 LUX
68
10Distanc e(m)
10Distanc e(m)
10Distanc e(m)
WHITE
15°
RGB
15°
RGB+WHITE
15°
3
2
1
0
1
2
3
3
2
1
0
1
2
3
3
2
1
0
1
2
3
4613
2 4 6 8 10D istance( m)
119 40
2468
175 00
2468
1 244 572 366 240 LUX
2 935 1315 795 548 LUX
10Distance(m)
4 300 2040 1182 792 LUX
10Distance(m)
15°
15°
15°
2
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
1.5 SAFET Y WARNING
IMPORTANT
【】
A LWAYS READ THE USER MANUAL BEF ORE O P ERATION.
【
PL EA SE CONFIRM THAT TH E POWER SUPP LY STATE D ON THE
PRODUCT IS THE SAME AS T HE MAINS POW ER SUPPLY IN YOU R
AREA.
T his product mu st be installed by a qualified professional.
●
Always operate the eq u ip m ent as descr ibed in the user manual.
●
●
A minimum distance of 0.5m must be maintained between the equipment and
combustible surface.
T he product mu st always be placed in a well ventilated area.
●
Always make sure that the equipment is installed securely.
●
●
D O NO T stan d c lose t o th e e qui pm ent a nd sta re di rectly i nt o t he LED lig ht
source.
Always disconnect the power supply before attempting and maintenance.
●
●
Alwa ys make s ure that t he supporting struc ture is solid an d can support the
combined weight of the products.
T he earth wire must always be connected to the ground.
●
Do not touch the power cables if your hands are wet.
●
】
TE-3X48RGBW PARLED AQUA
ATTE N TI ON
T his product left the place of manufacture in perfect condition. In order to
●
maintain this condition and for safe operation, the user must always follow the
instructions and safety w arnings described in this user manual.
Avoid shaking or strong impact s to any part of the equipment.
●
●
Make sure that all parts of the e quipment are kept clean and free of dust.
Always make sure that the power connecti ons are connected correct and
●
secure.
If there is any malfunction of the equipment, contact your dis tributor
●
immediately.
●
When transferring the product, it is advisable to use the original packaging i n
which the produ ct left the factory.
Shields, lenses or ultraviolet screens shall be changed if they have become
●
damaged to such an extent that their effecti veness is impaired.
The lamp (LED) shall be changed if it has become damaged or thermally
●
deformed.
3
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
2
IN STA LLAT ION
2.1 MOUNTING
HANGING
The fixture can be mounted in a hanging position
using the supporti ng bracket. The bracket
should be secured to the mounting truss or
structure using a standard mounting clamp .
Please note that when hanging the unit a safet y
cable should also be used.
UPRIGHT
TE-3X48RGBW PARLED AQUA
The fixture can be mounted in an upright or
sitting position using the supporting brackets.
The LED MODUL E can be mounted at any angle and in any
posi tion. It is poss ib le to furt her adjust the angle of the LED
MODULE using the tw o adjustm ent knobs located on the side of
the fixture.
2.2 POWER CONNECTIONS
@ 22 0V: 15 units may be connected in series
@120V: 7 units may be connected in series
Note:
1 . A s t h i s fixtu r e ' s DMX s ig na l cabl e c o n n ec t ion i s P a ra l l e l co nn e c t ion , s o if over 3 2 un i t s to b e
connected, then a DMX signal a mplifier is needed.
2. If the signal cable is over 60m between the DMX512 controller and fixt ure or beween two
fixtures, then a DMX signal amplifier is needed as well.
4
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
TE-3X48RGBW PARLED AQUA
2.3 SETTING UP WIT H A DMX512
CONTROLLER
2.3-1 DMX512 AD DRESSING WI THOUT ID ADDRESSING
STAG MODE)(
●
Conne ct the DMX512 controller to the units in series.
Each unit has 11 DMX channels so the DMX Addresses should increase by increments of
●
11 (e.g. 1,12,23,34...)
●
The ID address has not been set so therefore when using the controller CH11 must
be inactive ( CH11=0 ).
It is also possible to deactivate ID address selecting from the menu.
●
on the fixture
●
Each DMX Address may be used as many times as required.
●
Any DMX address in the range fro m 001 to 512 may be used.
Example:
DM X Add r.1 DM X Add r.12 DMX Add r.2 3
【】 【 】ID OFF Settings
.... ........
DM X512
CON TROLLER
The figure abov e shows a simple DMX512
layou t with the starting address of the first
unit set at 1, with th e second set at 12 and
so o n... (Note that when used in this way,
the CH11 ID functio n must be inactive (CH11=0))
2.3-2 DMX512 AD DRESSING WI TH ID ADDRESS STAG MODE)(
Conne ct the DMX512 controller to the units in series
●
Each unit has 11 DMX channels so the DMX Addresses should increase by increments of
●
11 (e.g. 1,12,23,34.. .)
●
Each DMX Address may be used as many times as requ ired.
Any DMX addr ess in the range from 001 to 512 may be used.
●
Each DMX address may carry up to 66 separate ID addresses.
●
●
should be set in the menu on each unit in ascending values
【】
ID
(i.e. 1,2,3...)
【】 【 】
ID On Settings
●
●
ID addresses are accessible from Ch9 on the DMX512 controller.
should be set in the menu on each unit.
5
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
Example:
DM X Addr.1
ID Add r.1
DM X Add r.1
ID Addr.2
DMX Add r .1
ID Add r.3
DMX Addr.1 2
ID A dd r. 1
TE-3X48RGBW PARLED AQUA
DM X Ad d r . 1 2
ID Ad dr.2
DM X Addr.12
ID Add r.3
............
3
DISPLAY PANEL OPERATION
3.1 BASIC
The LE D fixture is mounted with a LCD display and 4 control buttons.
DM X512
CONTROLLE R
The figure above shows a sim ple DMX layout
which ha s used three units at each DMX address.
The three units have different ID addresses which
allows the user to c ollectively control the whole
group of units at that DMX addre ss by set ti ng
CH11 to 0 , or to control each unit independently by
first selecting the DMX address and then by using
CH11 to locate the target ID address.
DOWN
MENU
ENTER
ENTER UP
MENU
scroll through the main menu or return to the main menu
enter the currently s elected menu or confirm the current function value
scroll 'UP' through the menu list or increase the value of the current function
scroll 'DO WN' through the menu list or dec r ease the value of the cur rent functi on
6
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
3.2 MENU
TE-3X48RGBW PARLED AQUA
MENU
STAT
AUTO
RUN DMX
DMX
PE RS
ID
EDIT
SET
CAL1
CAL2
Red
Gre en
Blue
White
St rob
AT.01
AT.02
AT.10
PR.01
PR .02
PR .10
SLAV
D(001~512)
STAG
Arc.1
Ar1.d
Arc.2
Ar2.d
Ar2.s
HSV
ID(01~66)
PR.01
PR .02
PR .10
UPL D
REST
ID
RGBW
POW
Dim
WT01
WT02
WT11
RGBW
(0~ 255)
(0~ 255)
(0~ 255)
(0~ 255)
(0~ 20)
SC.01
SC.02
SC.30
ON
OFF
ON
OFF
HIGH
NORM
Off
Dim1
Dim2
Dim3
Dim4
Red
Green
Blue
Whit e
Red
Green
Blue
Red
Gre en
Blue
White
Strobe
Time
Fade
(0~255)
(0~255)
(0~255)
(0~255)
(0~255)
(0~255)
(0~255)
(0~255)
(0~255)
(0~255)
(0~255)
(0~20)
(0~255)
(0~255)
KEY O N
OFF
7
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
3.3 EDIT STATIC COLOU
R
TE-3X48RGBW PARLED AQUA
MENU
STAT
Red
Gre en
Blue
White
St rob
(0~ 255)
(0~ 255)
(0~ 255)
(0~ 255)
(0~ 20)
STATIC COLOU R【】
Combine , , and to cr eate an infinite range
●
【】【 】【】【 】
Red Green Blue White
of colors (0-255)
Set the value of the (0-20Hz)
●
【】
Strobe
3.4 ACT IVATING AU TO PROGRAMS
MENU
AUTO
AT.01
AT.02
AT.10
PR.01
PR .02
PR .10
AUTO【】
Select the target program and press .
●
Programs to are fully pre-programmed and will not b e altered
●
【】【】
by chang es in m ode.
●
Programs to are fully pre-programmed and can be edited in
mode.
【】
EDIT
【】【】
3.5 RUN MODE
MENU
RUN DMX
RUN【】
RU N
Enter the mode to set working mode.
●
●
【】
mode is for using the DMX512 controller to control the fixtures.
【】
mode is for Master -- Sl ave operation.
●
【】
DMX
SLAV
【】 【 】
AUTO ENTER
AT. 01 AT.10
【】
EDIT
PR .01 PR.10
SLAV
8
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
3.6 DMX512 SETTING
S
TE-3X48RGBW PARLED AQUA
MENU
DMX
DMX【】
Enter the mode to set the DMX ADDRESS.
●
【】DMX
D(001~512)
3.7 PERSONALITY
MENU
PE RS
PERSONALITY【】
●
Enter the mode to select DMX mode:
Ar1.d , Arc.2 , Ar2.d , Ar2.s HSV
【】【】【】【】【】
【】 【】【】
STAG
Arc.1
Ar1.d
Arc.2
Ar2.d
Ar2.s
HSV
PERSONALITY STAG , Arc.1 ,
or .
3.8 ID ADDRESS
MENU
ID
ID【】
● Enter the mode to set the ID ADDRESS.
【】ID
ID(01~66)
9
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
TE-3X48RGBW PARLED AQUA
3.9 EDITING CUSTOM PROGRAMS
MENU
EDIT
PR.01
PR.02
PR.10
SC.01
SC.02
SC.30
EDIT CUSTOM【】
●
Enter the mode to edit the cus tom programs to
.
【】
PR.10
Each custom program has 30 steps that can be edited.
●
●
Each step a llows the creation of a scene using RED , GREEN ,
BLUE , WHITE STR OBE , TIME & FADE
.
【】
Fade
【】 【 】
EDIT PR.01
【】 【 】 【 】 【 】
Blue White , Strobe Time
3.10 SPECIAL SETTINGS
MENU
SET
UPLD
REST
ID
RGBW
POW
Dim
ON
OFF
ON
OFF
HIGH
NORM
Off
Dim1
Dim2
Dim3
Dim4
Red
Gr een
Blue
White
Strobe
Time
Fade
【】 【 】
(0~255)
(0~255)
(0~255)
(0~255)
(0~20)
(0~255)
(0~255)
Red Green
【】
SETTING
【】
Select to upload the custom p rograms from the current MASTER unit to
●
UPLD
the SLAVE units.
In order to activate the upload function the password must be entered.
●
Password is the same as the main access password.
●
When uploading the MASTER and SLAVE units will display YELLOW.
●
If an error occurs when up loading the MASTER and/or SLAVE units will display R ED.
●
On successful uploading of the custom programs the MASTER and SLAVE units
●
will display GREEN.
【】
In order to r eset custom modes to default values select .
●
【】
Enter in order to allow/disallow ID address functi on from the DMX512
●
ID
REST
controller.
When -- RGB TO WHITE is set to , on RGB = 25 5,255,255, th e
【】 【】
●
RGBW YES
color is perfect white as the actual RGB values are adjusted to mak e white. When it
is set to ,on RGB = 255,255,255 , the RGB values are not a djusted and the
output is most powerful. The s paramete r can be adjus ted in .
Enter to choose the operation power mode or ,
POW NORM HIGH
●
【】
NO
【】’
RGB W CAL 2
【】
【】 【 】【 】
when it is normal mode, the power cons umption is about 90W, while under high
mode, it is about 150W.
Enter to select d immer mode and dimmer speed. When DIMMER is set to
【】
●
, then RGBW and MASTER DIMMER are linear. The Dim 1/2 /3/4 are spee d
【】
modes of the non linear di mmer , is the faster, while is the slowest.
The setting here does not reac t on the the mode.
●
Dim
Off
【】 【 】
【】 【 】
Dim STAG
10
Dim 1 Dim4
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
3.11 WHITES SETTING
TE-3X48RGBW PARLED AQUA
MENU
CAL1
WT01
WT02
WT11
CAL1【】
Enter the to select white color of different color temperature.
●
T here are 11 pre-programmed White col ors can be edited by using ,
●
【】【】【】
, & .
Green Bl ue White
【】
CA L1
3.12 WHITE BALANCE
MENU
CAL2
CAL2【】
Enter the to adjust th e RGB parameter to make different whites.
●
When the new setting is activated, the DMX controller choos e RGB = 255,255,255,
●
【】
the white color will be made by the actual RGB values on the .
RGBW
CA L2
Red
Green
Blue
Whit e
Red
Green
Blue
(0~255)
(0~255)
(0~255)
(0~255)
(0~255)
(0~255)
(0~255)
【】
Red
CAL2
【】
3.13 A C TIVATE THE PASSWORD
MENU
KEY O N
OFF
KEYLOCK【】
【】
Enter the mode to select whether the access password is on or off.
●
●
In order to enter access pa ssword it is necessary to first press .
Access password is + + + .
●
KEY
【】【 】【 】【 】
UP DOWN UP DOWN
11
【】
ENTER
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
4
USING A DMX512 CONTROLLER
4.1 BASIC ADDRESSING
Connect all of the units in series us ing standard DMX512 signal cable or the IP65 rated cable
●
provided.
●
Set the DMX512 address in the menu.
It is possible to have the same DMX addre ss or inde pendent addres ses for each fixture.
●
【】DMX
4.2 CHANNEL ASSIGNMENT
●
Note: This product have three DMX512 channel configuration:
【】【 】【 】【】【】
Ar1.d , A rc.2 , Ar2.d , Ar2.s HSV
STAG
CHANNEL FUNC TIONVALUE
1
2
3
4
5
6
0 255
0 255
0 255
0 255
0 255
0 5
6
20
21
30
31
50
51
70
71
90
91
11 0
111
130
131 150
151 170
171 190
191 200
201 205
206 210
211 215
216 220
221 225
226 230
an d
MASTER DIMMER
RED
(or STEP TIME whe n C US.0 1-CUS. 10 in CH 8 is activated)
GREEN
(or FADE TIME when CUS. 01-CUS .10 in C H8 is ac tivated)
BLUE
WHITE
COLOR MACRO
NO FUNCTION
HIGH POWER(only when in NOR MAL POWER mode)
NO FUNCTION
R ED 100%/GREEN UP/B LUE 0%
RED DOW N/ GREEN 100%/BLUE 0 %
RED 0%/GR EEN1 0 0 %/BLU E UP
RED 0%/GREENDOWN/BLUE 100%
RED UP/GREEN 0%/BLUE 100%
RED 100% / GREEN 0%/BLUE DOWN
RED 100%/GREEN UP/BLUE U P
RED DOWN/GREEN DOWN/BLUE 100%
RED 100%/GREEN 100%/BLUE 100% /W H ITE 1 00%
WHITE 1: 3200K
WHITE 2: 3400K
WHITE 3: 4200K
WHITE 4: 4900K
WHITE 5: 5600K
WHITE 6: 5900K
TE-3X48RGBW PARLED AQUA
【】【】
STAG , Arc.1 ,
12
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
CHANNEL FUNC TIONVALUE
231 235
236 240
241 245
6
246 250
251 255
7
8
9
10
11
0 10
255
11
0 20
21 30
31 40
41 50
51
60
61 70
71 80
81 90
91 100
101 110
111 1 20
121 130
131 140
141 150
151
160
161 170
180
171
181 190
191
200
201 210
211 220
221 255
0 255
0 9
10 6 9
70 1 29
130 189
190 255
0 9
10 19
20 29
30 39
40 49
50 59
TE-3X48RGBW PARLED AQUA
WH IT E 7: 6500K
WH IT E 8: 7200K
WHITE 9: 8000K
WHIT E 10 : 8500K
WHITE 11: 10000K
STROBE
NO FUNCTION
1~20Hz
AUTO
NO FUNCTION
AUT O 1
AUT O 2
AUTO
3
AUTO
4
AUTO
5
AUTO
6
7
AUTO
AUTO
8
AUTO
9
AUTO
10
CUSTOM 1
CUSTOM 2
CUSTOM 3
CUSTOM 4
CUSTOM 5
CUSTOM 6
CUSTOM 7
CUSTOM 8
CUSTOM 9
CUSTOM 10
NO FUNCTION
AUTO SPEED ADJUS TME N T
Wh en usi ng CH8,AUTO01-AUTO10, this function activated
DIMMER SPEED
LINE AR DIM MER
NON LINE AR DIMMER 1 fastest（）
NON LINE AR DIMMER 2
NON LINE AR DIMMER 3
NON LIN EA R DI M M ER 4 s lowest（）
ID A DDRES S
ID1~ID66
ID1
ID2
ID3
ID4
ID5
13
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
CHANNEL FUNC TIONVALUE
60 69
70 79
80 89
90 99
100 109
110 119
120 129
130 139
140 149
150 159
11
160 169
170 179
180 189
190 199
200 209
210
211
TE-3X48RGBW PARLED AQUA
ID6
ID7
ID8
ID9
ID10
ID11
ID12
ID13
ID14
ID15
ID16
ID17
ID18
ID19
ID20
ID21
ID22
Arc.1
254
255
CHANNEL FUNC TIONVALUE
1
2
3
0 255
0 255
0 255
ID65
ID66
RED
GREEN
BLUE
14
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
Ar1.d
TE-3X48RGBW PARLED AQUA
CHANNEL FUNC TIONVALUE
Arc.2
1
2
3
4
0 255
0 255
0 255
0 255
CHANNEL FUNC TIONVALUE
1
2
3
4
0 255
0 255
0 255
0 255
MASTER DIMMER
RED
GREEN
BLUE
RED
GREEN
BLUE
WHITE
Ar2.d
CHANNEL FUNC TIONVALUE
1
2
3
4
5
0 255
0 255
0 255
0 255
0 255
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
MASTER DIMMER
RED
GREEN
BLUE
WHITE
15
Phonel : (1) 207-712-3004 http://www.te-lighting.com
Ar2.s
TE-3X48RGBW PARLED AQUA
CHANNEL FUNC TIONVALUE
HSV
1
2
3
4
5
6
0 255
0 255
0 255
0
255
0
255
0
255
CHANNEL FUNC TIONVALUE
MASTER DIMMER
RED
GREEN
BLUE
WHITE
STROBE
1
2
3
0 255
0 255
0 255
HUE(0~100% )
SATURATION(0~100%)
VAL U E(0~10 0%)
16
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
TE-3X48RGBW PARLED AQUA
4.3
MASTER DIMMER
CH1 controls the intensity of the currently projected color
●
●
When the slider is at the highest position (255) the intensit y of the outpu t is the maximum
R ED, G REEN & BLUE & WHITE COLO R SE LE CTION
CH2, CH3 & CH4 & CH5 control the intensity ratio of each of the RED, GREEN, BLUE &
●
WHITE LEDs.
When the slider is at the highest position (255) the intensit y of the color is the maximum.
●
●
CH2, CH3, CH4 & CH5 can be combined together to create over 16 million colors.
COLOR MACROS
●
CH6 selects the requ ired COLOR MACRO
●
CH6 has priority over CH2, CH3, CH4 & CH5
●
CH1 is used to control the intensity of the COLOR MACRO
STROBE
●
CH 7 controls the strobe of CH1 to CH6
●
Strobe 1 is with RGB in-step
●
Strobe 2 is with RGB out-step
Strobe 3 is a pulse strobe(fast on/slow off)
●
Strobe 4 is a pulse strobe (slow on/fast off)
●
●
CH7 has priority over CH2, C H3, CH4 &CH5.
BASIC INSTRUCTIONS FOR DMX512
OPERATION (STAGE1)
ID AD DRESS SELECTIO N
●
CH9 is used to select the target ID address .
●
Each indepe ndent DMX add ress may have upto 66 independent ID addresses.
An ID address of 0 will activate all ID address loca tions.
●
AUTO
●
CH8 selects the preset AUTO pro grams AT.01-AT.10 or the custom AUTO programs CUS.01-
CUS.1 0
●
When activ a ting the custom AUTO programs CUS.01 to CUS.10 then it is possible to control
the STEP TIME and FADE TIME using CH2 and CH3 respectively.
CH8 has priority over CH2, C H3, CH4, CH5, CH6 & CH7.
●
DIMMER SPEED
CH10 is for selecting the dimmer mode and dimmer speed. When DIMMER is set to ,
●
then RGBW and MASTER DIMMER are linear. The Dim 1/2/3/4 are differe nt speed of the non
linear dimmer .
【】Off
17
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
5
APPENDIX
5.1 TROUBLE SHOOTING
SITUATION CAUSE ACTION
1) No power input
2) Power connection e r r or
No d isplay
LED MODULE
on , bu t no con tro l
fr om d isplay
Displ ay normal,
bu t no resp onse
from buttons
No DMX signal
W h en the surf a ce
te mpe ratu re o f the
unit exceed 75 , the
te mpe ratu re p rote ction
no w ork .
Color mix in g
unev en,wit h splash
Pa rtial color
pa rt ial re d,part ial
green, part ial blue
or part ial white（）
LEDs of the same
colo r are not lit
Manual and program
can not save
℃
3) Displ ay damaged
4) D i splay board IC error or power input
connection er ror or two bo ard connect ion
error
5) Contrast de cay
1) Dis play IC reverse i nstall
2) Displ ay IC damaged
1 ) Button s dama ged
2) Display IC damaged
1) Signal C able erro r
2) Signal connc etion err or
3) The DMX signal rec ei ve IC damaged
4) DMX addr ess err or
1) The heat sensor r esistance of LED board
error
2) The temper atur e protection cir cuit on the
display error.
1) LE D not joining well
2) Lens not installing w ell
1) The current of one of the color gr oup LED s
is too strong or too weak.
2) LED brigh tness not enough
1) LE D damaged
2) LED damaged or Ma in PCB
，
，
TE-3X48RGBW PARLED AQUA
1) Check power sup ply
2) Check power con ne ctio n
3) Replace displ ay
4) Check the IC and all th e connections
5) A dj ust the LCD contrast
1) Check D isplay IC installation an d qu ality
1)Rep lace buttons
2) Replace Di splay IC
1) Che ck all sig nal Cables
2) Che ck all sig nal conncetions
3) Check the DMX s i gnal receive IC
4) Check DMX addres s
1) Replace the heat sensor resistance.
2) Ch e ck the tempera ture pro t ect ion ci rcui t.
1) Check LE Ds join ing
2) Check lens installing
1 ) Check dri ver current o f the pa rtial col or
LEDs on the Driver PCB
2) Chec k LED quality
3) Res e t t o fa ctory de fault setting.
1) Replace LED s
2) Replace damaged LED or Main PCB
1) Replace saving IC1) Saving IC damaged
18
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
5.2 MAINTENANCE
2
1
3
4
5
TE-3X48RGBW PARLED AQUA
14
13
6
12
11
8
7
No
Fron t cover
1
2
Rubber seal
3
Clear glass
4
Lens completed set
5
LED PC B
6
Heat sink
7
Brac ket
8
Power conn ection board
9
Display PCB
10
Display protecti on me tal plate
11
Safety chain board
Driver PC B
12
POW ER PCB (5V)
13
Power supp ly (24V)l
14
9
ITEM
10
19
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
TE-3X48RGBW PARLED AQUA
Connection Drawing
J1
十
J2
24 V
J3
0V
J3
DMXOUT
J1
J2J2J2
一
J2
DMXIN
0V
S
5V0 V
-B
-B
24V
屏蔽线
0V
5V
HXPEE
HX PEE
T P2- 09505
TP2- 09 505
J4
0V
POWER
LED
J3
J2
N
J1
L
POW ER
PO W ER O UT
AC 10 0V ~2 50 V
POWERIN
ADD : 19 Lacist St. Wesbrark, Maine, U.S.A. (04092) sales@te-lighting.com
Phonel : (1) 207-712-3004 http://www.te-lighting.com
Loading...
