Introduction

1 Introduction

1.1 Disclaimer

It is the user's responsibility to use this product prudently. This product is intended to be used only as a travel aid and must not be used for any purpose requiring precise measurement of direction, distance, or location.

For use in vehicles, it is the sole responsibility of the owner/operator of the TeleType GPS WorldNav 3000 XL to place and secure the GPS unit so that it will not interfere with the vehicle operating controls and safety devices, obstruct the driver's view of driving conditions, or cause damage or personal injury in the event of an accident. Do not mount the TeleType GPS WorldNav 3000 XL in a place where the driver or passengers are likely to impact it in an accident or collision. The mounting hardware supplied by TeleType Co. is not warranted against collision damage or the consequences thereof.

When used in vehicles, it is the sole responsibility of the driver of the vehicle to operate the vehicle in a safe manner, to maintain full surveillance of all driving conditions at all times, and not become distracted by the GPS system to the exclusion of safe driving practices. It is unsafe to operate the controls of the GPS system while you are driving. Failure by the driver of a vehicle equipped with a TeleType GPS system to pay full attention to operation of the vehicle and road conditions while the vehicle is in motion

Page 8

WorldNav 3000 XL

could result in an accident or collision with property damage and personal injury.

IN NO EVENT SHALL TELETYPE CO BE LIABLE FOR ANY INCIDENTAL, SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES, WHETHER RESULTING FROM THE USE, MISUSE, OR INABILITY TO USE THIS PRODUCT OR FROM DEFECTS IN THE PRODUCT. SOME STATES DO NOT ALLOW THE EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS MAY NOT APPLY TO YOU.

1.2 Welcome

Congratulations on purchasing the TeleType WorldNav 3000 XL! This document will provide you with information on how to use the GPS.

1.3 In the Box

Upon receiving your WorldNav 3000 XL, open the box to find the following items:

WorldNav 3000 XL Touch Screen GPS

Power cord for in-car use of WorldNav 3000 XL GPS

USB Sync cable for computer connectivity cord (and secondary power source indoors)

Plastic straps for stabilization

Black automobile mounting arm

Page 9

Introduction

Replacement fuse

Quick Start Guide

DVD containing PC Sync Software User' Guide and Tools

1.4 Your WorldNav 3000 XL GPS System

Front and Back of your WorldNav 3000 XL

Clockwise from Lower Left

Front of GPS Back of GPS A. Mark Waypoint Button H. Stylus insert B. Power Button I. Adapter hole C, D. Zoom In and Zoom Out Buttons J. Speaker hole E. Cursor Toggle Button K. SD Card Insert F. Save Button L. Antenna Flip Up G. Main Menu Button M. USB Connector site

Page 10

WorldNav 3000 XL

1.5 Quick Start Method

1. Plug in the WorldNav 3000 XL to the 12v cigarette lighter in your vehicle. Plug the power cord into the lower of the two holes on the right side of the GPS. The GPS will power on when you turn your car on.

2. If you purchased your WorldNav 3000 XL directly from TeleType Co., it has been prepared for use in your home state. You may choose to use a Secure Digital Card in the future, however it is not required for immediate operation of the GPS. If you purchased the Deluxe or Premium WorldNav version, it includes a Secure Digital Card which has already been inserted into the GPS (you can see it at the top of the GPS). The Deluxe version (1 gigabyte card) has been prepared with the entire United States and 3 million points of interest. If you purchased the Premium version, it has a 2-gigabyte Secure Digital Card inserted into your GPS. The 2 GB card has been prepared with the entire United States and 12 million points of interest. To insert your Secure Digital Card in the top of the GPS, make sure the metal connection points on the card match with those visible inside the device. To remove the card press down on the card, it will pop up and you can then remove the card from the slot.

Page 11

Introduction

Secure Digital Card

3. Attach your GPS system to the windshield by putting the suction cup on the window (moisten cup if necessary) and then by using the flip button next to the suction cup to achieve suction. Rest the GPS on the dash to help stabilize it against vibration.

4. Flip the built-in receiver up and pointed towards your windshield. The WorldNav 3000 XL will automatically lock into your GPS position; there is no configuration required. The GPS will know your direction of travel only once you begin to move.

GPS Mounted in Vehicle

5. Press the <I Agree> button with your finger or use the grey stylus found in the back of the GPS system.

Page 12

WorldNav 3000 XL

Disclaimer Screen

6. If the GPS has not yet locked into position, you will see <Where To> and <Menu> at the top of the map screen. The map will display your last position centered in the "target" [ ] area. Press < Where To> on the screen to get to the navigation screen.

Main Mapping Screen

Page 13

Introduction

7. Put in your destination by Address, Intersection or POI (point of interest).

8. The map route from your current location to the selected location should be displayed.

Routing from your last known position

9. If the GPS is locked into position you will hear "GPS position fixed, ready to navigate." The <Where To> and <Menu> buttons will disappear.

Page 14

WorldNav 3000 XL

Sample Routing Screen with Navigation Panel

Page 15

Part

Page 16

WorldNav 3000 XL

2 Getting started with your 3000XL

2.1 Review the main menu

Review the main menu. The main menu is accessed anytime you press the <Menu> space on the touch screen. There are fifteen entries on the main menu which is spread out over 5 screens. They are in alphabetical order:

2D/3D—to change between two and three dimensional views. NOTE: You will not see the names of most roadways on the 3D view but the map will look more realistic.

Brightness—to change the brightness of the touch screen.

Calibration—allows for the calibration of the screen using the stylus and a calibration crosshair on the screen. It is self explanatory and requires your stylus and a few minutes of time. It keeps your screen accurate.

Exit—to exit the menu and the map and enter the Opening Screen.

Find—to open the Find Wizard that helps you locate an address, a Point of Interest (POI), Intersection or listed Waypoint.

GPS—to list GPS information such as latitude,

Page 17

Getting started with your 3000XL

longitude, elevation, speed, heading and strength of signal.

Information—provides information on your current location.

My Points—lets you into the "My Points" menu so you can mark or manage your waypoints or set your home and office address.

Navigation Panel—lets you into a panel where you can set two identifying panels on your trip including, timer, distance to go, odometer, heading, satellite info and time.

Night—switches from a night screen to a day screen and vice versa.

POI Show—puts you into a POI Display screen to show a restaurant display, automotive display or other POI display.

Route—lets you into the route menu, situated on two separate screens, in which you can set a new route, view your route and indicate if you want the quickest or shortest route or avoid the main highways, reroute or clear your route, or start a simulation route.

System of units—switch between English and

Metric units

Page 18

WorldNav 3000 XL

Trip—shows you trip statistics such as total time and distance traveled

Volume—allows user to have the volume change with speed

2.2 Set a route from home

Your home address has been preset into the GPS but can be changed in the "My Points" Submenu by pressing <Set Home/ Office>. Follow these directions.

Main Mapping Screen

1. Press <Route> in the main menu and then press <New Route> in the Route submenu.

Page 19

Getting started with your 3000XL

Route Menu

2. You are sent to the Find Wizard and prompted to press one of the following: Address, POI, Intersection, My Points, History or Home. Select <Address>. Note: You can also get to the Find Wizard Menu when you press <Find> in the main menu.

Find Wizard Menu

Page 20

WorldNav 3000 XL

3. Put in the address, starting with the state, then the city, the street name and the street number.

Entering State

Entering City

Page 21

Getting started with your 3000XL

Entering Street Name

Entering Street Number

4. WorldNav 3000 XL will search for possible

choices. Select one.

Page 22

WorldNav 3000 XL

Finding a Street Address

5. Press <Route To>. The map with your route shown in blue is displayed. You can use the + or

- buttons on the GPS to zoom in or out on your route.

Your route displayed in blue

6. Drive. The GPS will prompt you at turns and you can follow the distance remaining or whatever

Page 23

Getting started with your 3000XL

other parameters you chose in the Navigation Panel. You can also see the written route by pressing <Route> and then <View Route>.

View Route Results

2.3 Routing to an intersection

This allows you to create a route to any intersection if you don't know the exact address of where you are going.

1. Press the <Menu> button and then scroll over to the <Find> button. Press <Find>.

Page 24

WorldNav 3000 XL

Main Menu and Find

2. This will put you into the Find Wizard where you can press the area labeled <Intersection>.

Find Wizard Menu

Page 25

Getting started with your 3000XL

Entering First Intersection Street

3. You will be prompted to enter the first street

beginning with the state, the city and finally the street name. Press <Next> between adding the various components of the address until you get to street name. Press <next> to input the second street in the intersection.

4. You must enter the second street and then press

<Find>. Note that it is not always necessary to put in "Street" or "Avenue" as you will have a pull down list of possible choices with or without putting in the words "Street" or "Avenue".

Page 26

WorldNav 3000 XL

Entering Second Intersection Street

5. Look at the list of possible selections. Pick one and select <Show> to see the intersection on a map.

Select Correct Intersection

6. You can choose the <Route to> space once you have selected the intersection that matches your choice. A map of the route will be displayed.

Page 27

Getting started with your 3000XL

Map of Route Shown in Blue

2.4 Routing using POIs

A POI is a point of interest such as a restaurant or gas station.

1. Select <Menu> and then <Find>.

Find Wizard

Page 28

WorldNav 3000 XL

2. In the Find Wizard, select <POI> or point of interest.

3. You will be prompted to select <By Nearest> or

<By Address>. Select one.

POI Search Options

4. Select <By nearest> for the purposes of this tutorial. Use this when you don't know the address or need to find something close by.

Page 29

Getting started with your 3000XL

Choosing Distance around Center of View

5. Select a range of 5 or 20 mile radius.

6. Select a category such as automotive, food and drink, business, education, etc.

Select POI Category

7. Select <Food & Drink> for the purposes of this tutorial.

Page 30

WorldNav 3000 XL

8. Enter the type of food and drink that you are interested in or select <All> for all types.

Select POI from choices

9. Enter the name of the place or select the place from a list of possible choices. Press <Route to> or <Show> to show a map of the route to the place you have selected. If you need to see the route, press <Route to>.

2.5 Finding or routing to a city

You can find a map of another city in your State and even route to that city.

1. Press <Menu> and then <Find> and finally

<Address>.

2. The WorldNav 3000 XL will prompt you for the

state and the city. Just press <Next> on the

Page 31

Getting started with your 3000XL

prompts for street name and number, leaving those spaces blank.

3. A list of choices will pop up. Select one and press

<show>.

Select a City

4. A map of the city you selected is available for you to search and explore, using the zoom button and the arrow keys to navigate inside the city.

Page 32

WorldNav 3000 XL

Map of Selected City

5. Press <Show> for a map of the city or <Route To> and you will get a route from your last known position to the selected city.

2.6 Finding a waypoint

If you have created a waypoint (to be explained later), you can find it in the Find Wizard Menu.

1. Press <Menu>, then <Find>.

Page 33

Getting started with your 3000XL

Find Wizard Menu

2. Select the <My Points> space.

3. Select <Find> to view the list of all waypoints.

Finding a Waypoint

4. Select the one you want and press <Show>. You will see the selected point centered on a map on the screen. If you want to <Route To>, press that

Page 34

WorldNav 3000 XL

button to create a route to your waypoint.

5. You can also find a waypoint through the <My Points> space on the Main Menu which will pull out the My Points Menu. There you can press <Manage> and get a list of your Waypoints. There you can <Edit> the waypoint, press <Go To> to see it on a map or <Delete> a selected waypoint.

My Points Menu

2.7 Finding or routing to an address

Press <Menu>, then <Find> to get to the Find Wizard Menu.

Page 35

Getting started with your 3000XL

Find Wizard Menu

1. Press the <Address> button. You will be

prompted to enter an address in the usual fashion beginning with the State.

2. Select the address from a list that fits with the

one you want. Press <Route to> or <Show> depending on whether or not you want the route displayed on the map.

Page 36

WorldNav 3000 XL

Selecting from a Choice of Addresses

2.8 History

This is on the Find Wizard Menu and provides a history of your recent addresses used in routing routes so that they can be repeated. Just select one of the items from the list that you want displayed. This is a good way to recreate a route you have looked up in your home while hooked up to the PC rather than figuring out your route in the car.

Page 37

Getting started with your 3000XL

History of Previous Routes

2.9 Reroute and Clear Route

If you are on a route and have strayed from it, press <Menu>, then <Route> and finally scroll to the

second

screen and press <Reroute>. Your position must be locked/ motionless when you activate this function. It will create a new route based on your current position. If you want to

clear the route

you have created, press <Clear Route>. Note that the GPS will automatically determine a new route for you to follow if you stray from the original path. The <Reroute> function is intended for manual use in case you prefer to create a new route without waiting for the GPS to reroute you to a new path.

Page 38

WorldNav 3000 XL

Reroute and Clear Route Choices

2.10 Your GPS Settings

GPS Information.

Press <Menu> to get to the main menu and then press <GPS>. This gives you the GPS information screen showing your latitude, longitude, elevation, speed, heading (direction of travel), and the total number and strength of satellite signals.

GPS Information Screen

Page 39

Part

III

Page 40

WorldNav 3000 XL

3 MP3 Player

3.1 Installing music

1. You can install MP3s on your WorldNav 3000 XL using the USB cable provided. You must first connect your device to the computer. The device will automatically turn on. You must always press <I Agree> to the disclaimer upon starting the WorldNav 3000 XL.

2. Insert the provided DVD into your PC or laptop computer. The "Maps, Music and More" screen will show up on your PC when the DVD loads.

WorldNav Installer - Maps, Music and More...

Page 41

MP3 Player

3. If your WorldNav 3000 XL is not firmly attached to the computer, you will see the following screen. Recheck your connections and press Retry.

WorldNav Installer - Not Connected

Page 42

WorldNav 3000 XL

WorldNav Installer - Connected

4. Press the <Music> icon found at the bottom of the installer screen. The music transfer screen will open.

Page 43

MP3 Player

WorldNav Music Transfer Screen

5. Press "Add music."

6. Select the MP3(s) you would like to install and press "Open".

7. The selected MP3s have now been installed into your WorldNav 3000 XL. They will appear on the list under "Music Already on Device."

3.2 Play your MP3s

You can play your MP3s

only

in your car as there is not enough power in the USB connection in your computer to play music.

1. To get to the MP3 player button, press

Page 44

WorldNav 3000 XL

<Menu>, then <Exit> to return to the main menu.

2. Press the Music Icon in the middle left corner of the main screen.

MP3 Player Button

3. Your MP3s will now be visible in a list on the MP3 player screen.

Page 45

MP3 Player

MP3s loaded onto MP3 Player

MP3 Player Buttons:

A. Stop E. Browse MP3's B. Play/Pause F. Close MP3 Player C. Back G. Cycle/Repeat D. Next H. Volume Button

4. Select the song you wish to play and press the play button.

5. To play the next song in the list, press the "Next" icon.

6. To play the previous song in the list, press the "Back" icon.

7. To stop playing a song, press the square

Page 46

WorldNav 3000 XL

"Stop" icon.

8. To browse your list, scroll the list up or down and select the song you wish to play.

9. To repeat your entire list, press the "Cycle" Icon at the top of the screen. To play through the list only once, press the "Repeat" Icon.

3.3 Uninstall MP3s

1. To uninstall MP3s, you first need to connect your WorldNav 3000 XL to your computer with the USB cable provided.

2. Insert the WorldNav Installer DVD into your computer.

Page 47

MP3 Player

WorldNav Installer - Maps, Music, and More...

3. Press "Music, Maps and More…".

4. Press the "Music" Icon in the Installer screen.

Page 48

WorldNav 3000 XL

WorldNav Music Transfer Screen

5. The Music Transfer Screen will be opened. Select the music you want removed.

6. To uninstall the MP3s from your device, click on the "Remove Music" button.

7. The selected MP3s have now been removed and will not be visible on the "Music Already on Device" list.

Page 49

Part

Page 50

WorldNav 3000 XL

4 Working with Waypoints

4.1 Create a Waypoint

A waypoint is a position marker that can be used to help create a route or mark a position for future reference. You can create waypoints regardless of whether the GPS device is active or inactive. If you are centered on a position that you would like to create a waypoint for, press the waypoint button (off the screen on the lower left of the device - flag symbol). The position will now be saved as a waypoint.

4.2 Mark waypoint at current position

Press <Menu> and then <My points>.

My Points Menu

1. Press <Mark> to mark your current position.

2. Enter the name for your current position and

Page 51

Working with Waypoints

select an icon to represent the position.

Naming a Waypoint

3. Your current position will now be recorded as a waypoint and will appear on the screen as the icon you selected.

4.3 Editing Waypoints

To edit your waypoints, press <Menu> and then <My points>. This will take you to the My Points menu.

1. Select Manage. This will take you to a screen entitled "Manage My Points". Select the waypoint you wish to edit and press <Edit>.

Page 52

WorldNav 3000 XL

Editing your Waypoints

2. Change the name of the waypoint by pressing the <Name> field and entering a new name.

Changing Name of Waypoint

3. When you are finished with any edits to that particular waypoint, press <OK>.

Page 53

Working with Waypoints

4. Once your edits have been saved, you can center the waypoint on the screen by pressing <Go To>.

4.4 Deleting a Waypoint

1. Press <Menu> and then <My Points>.

Manage My Points Menu

2. In the My Points Menu, press <Manage>. This will show you a list of your designated way points. Select one and press <Delete>. The way point will be removed from the list.

Page 54

Part

Page 55

Preferences

5 Preferences

5.1 Selecting a brightness level

Main Menu - Brightness

1. Press <Menu> and then <Brightness>.

2. Adjust the slider to increase or decrease the brightness of the screen.

Page 56

WorldNav 3000 XL

Brightness Screen

5.2 Choosing a system of units

Specify whether the WorldNav should display measurements in Metric or English units.

Main Menu - System of Units

1. First press <Menu> and then select <System of Units>.

Page 57

Preferences

2. You can toggle between Metric and English. Select one and then press <OK>.

System of Units Preferences

5.3 Selecting route preferences

This allows you to have your routes selected as the quickest path, the shortest path or a route that avoids major highways.

1. Press <Menu>, then <Route> and then <Route Setting>.

Page 58

WorldNav 3000 XL

Route Menu

2. Select the routing mode you prefer. If your state has a ferry system, you can select whether or not you want to make use of the ferry system.

Route Settings

Page 59

Preferences

5.4 Selecting navigation panel preferences

Press <Menu> and then <Navigation Panel>.

Navigation Panel Preferences

Navigation Panel While Driving

1. The navigation panel is located in the right lower corner of your route. It shows information related to your route. You can choose two values to display in the

Page 60

WorldNav 3000 XL

Navigation panel to be in either the Upper or the Lower Panel.

Navigation Panel Choices

2. In the Navigation Panel Menu, you can scroll the Upper and the Lower panel to select one of the following trip information items:

Arrival time:

Estimated time of

arrival.

DIST to go:

Distance to go.

Heading - Degree:

Directional

heading focused on degrees.

Heading - Text:

Directional

heading focused on text.

Odometer:

Odometer.

Satellite Info:

GPS signal

strength.

Speed:

Ground speed.

Page 61

Preferences

Time:

GPS (UTC) time.

Timer:

Trip timer.

5.5 Setting the POI preferences

This allows you to choose the types of POIs (for example, the restaurant types) you would like shown on the screen. For the purposes of this tutorial, let's decide the restaurant types you like.

1. Press <Menu> and then <POI Display>.

Main Menu - POI Show

2. This will take you to the POI Display Menu. Select <Restaurant Display>.

Page 62

WorldNav 3000 XL

POI Display Menu

3. This will take you to a scroll menu where you can select the types of restaurants you want displayed as a POI on the map. Select as many as you like and then press <OK>.

Restaurant POI Display Preferences

4. You can do the same for automotive displays and miscellaneous displays. Only those

Page 63

Preferences

areas you select will be revealed on the map. For example, if you deselect all boxes except for the restaurant category, only your selected restaurant styles will be displayed on the map.

5.6 Setting volume preferences

Press <Menu> and then <Volume>. This takes you to the volume screen where you select whether or not the volume changes with speed and at what speed the volume increases. Make your selection and press <OK>.

Volume Settings Screen

5.7 Auto Zoom

Auto-Zoom will automatically change your map zoom level depending on your speed. It will zoom in when you slow down and zoom out when you speed up.

Page 64

WorldNav 3000 XL

1. Press <Menu>, then <Route> and then <Route Setting>.

Route Menu

2. Check the <Enable Auto-Zoom> box to turn on the Auto Zoom feature. Uncheck the box to turn it off.

Auto Zoom

Page 65

Preferences

5.8 Changing the Time

This allows you to change the time by hours. Your position must be locked in.

1. This <Menu>, then <GPS>

Main Menu -GPS

2. This will bring you to the GPS Information screen. Click on the center button where the text ‘Change’ is displayed.

Page 66

WorldNav 3000 XL

GPS Status Screen

3. Click on the + and – buttons to change the hour accordingly.

Adjust Hours Screen

Page 67

Part

Page 68

WorldNav 3000 XL

6 Special Features

6.1 2D/3D Views

Your map can be shown in two dimensions where the streets are clearly marked. This looks like a regular map. For 3D mode, only the main streets are labeled but the map more clearly displays what your route looks while driving.

Routing in 3D Mode

Press <Menu> and either the <2D View> or <3D View> space in the main menu. The menu will automatically close and you can see the resulting view depending on your choice.

Page 69

Special Features

Routing in 2D Mode

Your next turn is shown on the upper section of the screen. Turn direction and distance remaining until the turn is displayed in the upper right hand corner of the screen. A checkered flag will appear in the same section when you reach your destination. The bottom two panels can be customized to display desired information (see section 5.1 - Selecting navigation panel preferences).

6.2 Day/Night Mode

Your map has the ability to have a black background and blue streets for night vision and a white background with gray streets for day vision.

Select <Menu> and then <Night Mode> or <Day Mode> in the main menu to choose between the two screen appearances.

Page 70

WorldNav 3000 XL

Night Vision Screen

6.3 Trip Information

Review trip statistics such as speed, distance to go, estimated time of arrival, time, odometer and timer simultaneously.

Press <Menu> and then <Trip> to see the trip statistics screen.

Page 71

Special Features

Trip Statistics Screen

6.4 Calibration

Use your stylus to press a series of cross-hatches that will appear on your screen to calibrate your screen display. You can repeat the process periodically to optimize your screen accuracy.

Main Menu - Calibration

Page 72

WorldNav 3000 XL

Calibration Screen

6.5 Map Information

If you press <Menu> and then <Info> the GPS will display the best estimate of your current location.

Map Information Screen

Page 73

Special Features

6.6 Simulating a Route

You can simulate a previously created route to preview what it will look like while you are driving.

1. Press <Menu>, then <Route>.

Route Menu

2. Navigate to the second screen and press the <Start Simulation> button. The simulation will automatically begin.

Page 74

WorldNav 3000 XL

Start Simulation Button

3. To end the simulation, press <Menu>, then <Route>, navigate to the second screen and press the <End Simulation> button.

6.7 Exit

Pressing the <Exit> button allows you to exit the navigation program but does not shut off the GPS altogether. You may want to use this function to allow access to the MP3 player or feature demo.

Page 75

Special Features

Menu - Exit

After exiting Main Menu

6.8 Installing and uninstalling maps

The WorldNav 3000 XL can be used throughout the United States. TeleType Co. also offers an enhanced points of interest database containing over 12 million businesses as well as hotels, restaurants, gas stations and more.

Page 76

WorldNav 3000 XL

1. To install extra maps that were not pre-installed (such as your home state), you need a Secure Device card such as those found in digital cameras that can be inserted into the top of the device.

2. Using the provided USB cable and the installed Secure Device card, connect your WorldNav 3000XL to your PC or laptop computer.

3. Insert the provided WorldNav Installation DVD into your computer.

WorldNav Installer - Maps, Music, and More...

4. Press "Music, Maps and More…". Select the state you wish to install. Select the desired

Page 77

Special Features

state(s), and press "Send". The state(s) you selected will now be installed on your GPS.

Installing maps to your WorldNav

5. Uninstalling Maps. On the GPS device, you must first press <Menu> and then <Exit> to exit out of the navigation program.

6. Insert your Secure Digital card into the device and connect the device to your PC. Put in the provided DVD.

7. Press "Music, Maps, and More…" to access the "Map" Icon.

8. Select the state(s) you wish to remove and

press "Remove". The state(s) you selected will now be removed.

Page 78

WorldNav 3000 XL

6.9 Changing adapter fuse

In the event that the power cable fails to power the GPS you can replace the fuse. The end of the cigarette lighter adapter unscrews, revealing a fuse just inside the cover. Replace the fuse with a functioning fuse ( an extra fuse is provided with your WorldNav product). Replacement fuses (2 Amps) are readily available from electronics stores.

Replacing the adapter fuse

Page 79

Part

VII

Page 80

WorldNav 3000 XL

7 Warnings and Cautions

Caution:

Use the WorldNav 3000 XL at your own risk. To reduce the risk of unsafe operation, please carefully review and understand this user manual.

Caution:

It is the user's responsibility to use this product prudently. This product is intended to be used only as a navigational aid and must not be used for any purpose requiring precise measurement of direction, distance, location, or topography. Statistics provided such as trip time are best estimates and may not accurately reflect true conditions.

Warning:

The Global Positioning System (GPS) is operated by the United States Government, which is solely responsible for its accuracy and maintenance. The system is subject to changes which could affect the accuracy and performance of all GPS equipment.

Warning:

For use in vehicles, it is the sole

responsibility of the owner/operator of the TeleType GPS WorldNav 3000 XL to place and secure the GPS unit so that it will not interfere with the vehicle operating controls and safety devices, obstruct the driver's view of driving conditions, or cause damage or personal injury in the event of an accident. Do not mount the TeleType GPS WorldNav 3000 XL in a place where the driver or passengers are likely to impact it in an accident or collision. The mounting

Page 81

Warnings and Cautions

hardware supplied by TeleType Co. is not warranted against collision damage or the consequences thereof.

Warning:

Page 82

Part

VIII

Page 83

Device Specifications

8 Device Specifications

Physical Specifications:

Storage: Recommended 1 or 2 GB SD storage

card.

Processor: Intel XScale Operating System:

Microsoft® Windows CE.NET 4.2 Core version

Display Screen:

3.5" TFT True Color LCD 320x240 Pixels

Memory: 64MB SDRAM

512MB Built-In Storage

Expansion Slot:

SD/MMC Slot for map and music storage

Audio: Built-in Speaker (0.5w)

3.5mm Stereo Headphone Jack

Input Method: Stylus Pen, Touch Screen, Key Button External Ports:

Mini USB (ver 1.1) connector

Power Supply:

12~24V / 2A

Dimension (H x W x D):

2.95 x 5.51 x 1.14 inches / 75 x 140 x 29 mm

Weight: 8 ounces / 226 grams Operating Temperatures :

Optimal: -4 F to 158 F (-20 C to 70 C) Maximum: 176 F (80 C)

Page 84

Part

Page 85

Troubleshooting Questions

9 Troubleshooting Questions

How do I power up my device?

There are two ways to power the device. The automobile cigarette lighter provides full power while limited power is given to the device through the USB cable connected to your Windows XP computer.

I can't get my device attached to the windshield.

Place the suction cup firmly on the window and flip the black switch which draws suction from the cup to attach the device. In cooler or drier conditions, you may need to warm the windshield or moisten the suction cup for maximum seal.

Why can't I get power via the USB cable?

This must be a tight connection so if it isn't working properly, check the connections. When using the MP3 player, it is recommended to store music on a Secure Digital Card.

Why aren't the streets labeled?

In 3D mode, only major thoroughfares are shown. Change to 2D mode to get more labeled streets.

What do I do if I change my destination during a route?

This requires a <clear route> maneuver done by pressing <Menu>, then <Route> and on the second screen, press <Reroute>. Alternatively, use the <New Route> feature to create a new route; the old route will be cleared

Page 86

WorldNav 3000 XL

from the display automatically.

What if the GPS can't locate my destination address?

Some addresses may not be listed. Change the route to locate the nearest intersection, or nearest town instead.

What if it seems the device is not showing my true location?

Sometimes, the device takes a few minutes to lock in on the satellite signal, after which your true location will be shown.

I can't get power on my car adapter.

If you can get power on the USB cable but not in your car, it is likely that the fuse inside the adapter is blown. Twist to unscrew the cover (the part that sticks into the lighter) and replace the fuse with a fresh one. A spare fuse has been included for your convenience. Also, make sure that the power adapter cord is attached to the bottom of the two holes on the right-hand side of the GPS. The top hole is for attaching the GPS to the speakers in your car (see section 6.8-Changing adapter fuse).

Page 87

Index

- 2 -

2D View 66

- 3 -

3D View 66

- A -

Add music 38 Arrival time 57 AutoZoom 61

- B -

Bird's eye view 66 Brightness level 53

- C -

Calibration 69 Car adapter 83 Cautions 78 Change destination 83 Clear route 35 Create a route from home 16 Create a waypoint 48

- D -

Day Mode 67 Delete a waypoint 51 Device specifications 81 Disclaimer 5 Distance to go 57, 68 Driving preferences 57 DTG 68 DVD 6, 38

- E -

Edit a waypoint 49 Elevation 36 English 54 Estimated time of arrival 68 ETA 68 Exit 72

- F -

Find a city 28 Find a POI 25 Find a street address 32 Find a waypoint 30

Page 88

WorldNav 3000 XL

- G -

Getting started 8 GPS information 36 GPS position 36 GPS satellites 36 GPS settings 36 GPS status 36

- H -

Hardware buttons 7 Hardware specifications 81 Heading 36, 57 History 34 Hours 63

- I -

Info 70 Information 70 Install maps 73 Install music 38 Installer 38 Intersection 21

- L -

Latitude 36

Longitude 36

- M -

Main menu 7, 14 Main menu buttons 14 Map Information 70 Map screen 7 Map transfer 73 Mark my current position 48 Mark waypoint 48 Metric 54 MP3s 38

- N -

Navigation panel 57 Navigation panel preferences 57 Night Mode 67 No power 83

- O -

Odometer 57, 68

- P -

Pan 7 Play MP3s 41 Play music 41

Page 89

Index

POI 25 POI display 59 POI routing 25 Position is off 83 Power up device 83

- Q -

Quick start method 8 Quickest route 55

- R -

Remove MP3s 44 Remove music 44 Repeat a route 34 Replace adapter fuse 76 Replacement fuse 6, 83 Reroute 35 Route 16 Route preferences 55 Route to 16 Route to a city 28 Route to a POI 25 Route to a street address 32 Route to a waypoint 30 Route to an intersection 21 Route via ferry 55

- S -

Satellite info 57 Secure Digital Card 8 Selecting brightness level 53 Set home address 16 Set office address 16 Set volume 61 Setting POI preferences 59 Shortest route 55 Show true location 83 Simulating a Route 71 Simulation 71 Simulator 71 Specifications 81 Speed 36, 57, 68 Streets aren't labelled 83 System of units 54

- T -

Time 57, 63, 68 Time Zone 63 Timer 36, 57, 68 Touch screen 6 Transfer MP3s 38 Trip information 68

Page 90

WorldNav 3000 XL

Troubleshoot 83

- U -

Uninstall maps 73 Uninstall MP3s 44 Uninstall music 44 USB cable 6

- V -

Volume preferences 61

- W -

Warnings 78 Waypoint 30, 48 Waypoint routing 30 Waypoints 7 Welcome 6 Windshield mount 6, 83

- Z -

Zoom 7, 61

Page 91

Notes:

Page 92

Notes:
