Teletek electronics MAG2, MAG4 User Manual

English

MAG2 MAG4

FIRE CONTROL PANEL

User Manual

/metal and plastic box/

2 Fire Control Panel MAG2/4 - User Manual

CONTENTS

Guarantee ...................................................................................................................3

1. Using the MAG2/4 controls ...................................................................................4

1.1 Operation modes ...........................................................................................5

1.2 LED indication for zones status ...................................................................5

1.3 LED indication for the technical troubles ....................................................5

1.4 LED indication for the system status ..........................................................6

1.5 Buttons for programming and operation ....................................................6

1.6 Switch for changing over between Access Levels 1 and 3 .......................6

1.7 Sound signalization .......................................................................................7

2. Installing the MAG2/4 re panels .........................................................................7

3. Testing the MAG2/4 re panels ............................................................................8

4. Connecting the zone circuits ...............................................................................8

5. Connecting the sounders circuits .......................................................................9

6. Connecting the FAULT and FIRE relays ..............................................................9

7. Class Change Function .........................................................................................9

8. Operation instructions ........................................................................................10

8.1 Zone Enabling/ Disabling ...........................................................................10

8.2 Sounders Enabling/ Disabling ....................................................................10

8.3 “One man” zone testing .............................................................................. 11

9. Technical specications .....................................................................................12

10. Connection diagrams ........................................................................................13

11. Fire alarm record ...............................................................................................14

12. Service record....................................................................................................14

13. Fire alarm event LOG ........................................................................................15

14. Spare parts kits..................................................................................................15

1293

DoP No: 075

1293 - CPR - 0510

Teletek Electronics JSC, 14 Srebarna Str., 1407 Soa, Bulgaria

EN 54-2:1997/A1:2006/AC:1999; EN 54-4:1997/A2:2006/AC:1999

MAG2/4

Intended for use in re detection and re alarm systems in and around buildings.

Essential Characteristics Performance

Performance under re conditions Pass

Response delay (response time to re) Pass

Operational reliability Pass

Durability of operational reliability and response delay: temperature resistance Pass

Durability of operational reliability: humidity resistance Pass

Durability of operational reliability: vibration resistance Pass

Durability of operational reliability: electrical resistance Pass

Fire Control Panel MAG2/4 - User Manual 3

GUARANTEE

The guarantee terms are determined by the serial number (barcode) of the electronic device!

During the guarantee period the manufacturer shall, at its sole discretion, replace or repair any defective product when it is returned to the factory. All parts replaced and/or repaired shall be covered for the remainder of the original guarantee, or 6 months, whichever period is longer. The original purchaser shall immediately send manufacturer a written notice of the defective parts or workmanship.

International Guarantee

Foreign customers shall possess the same guarantee rights as those any customer in Bulgaria, except that manufacturer shall not be liable for any related customs duties, taxes or VAT, which may be payable.

Guarantee Procedure

The guarantee will be granted when the appliance in question is returned. The guarantee period and the period for repair are determined in advance. The manufacturer shall not accept any product, of which no prior notice has been received via the RAN form at:

http://www.teletek-electronics.com/en/support/Service

The setup and programming included in the technical documentation shall not be regarded as defects. Teletek Electronics bears no responsibility for the loss of programming information in the device being serviced.

Conditions for waiving the guarantee

This guarantee shall apply to defects in products resulting only from improper materials or workmanship, related to its normal use. It shall not cover:

• Devices with destroyed serial number (barcode);

• Damages resulting from improper transportation and handling;

• Damages caused by natural calamities, such as re, oods, storms, earthquakes or lightning;

• Damages caused by incorrect voltage, accidental breakage or water; beyond the control of the manufacturer;

• Damages caused by unauthorized system incorporation, changes, modications or surrounding objects:

• Damages caused by peripheral appliances (unless such peripheral appliances have been supplied by the manufacturer:

• Defects caused by inappropriate surrounding of installed products;

• Damages caused by failure to use the product for its normal purpose; Damages caused by improper maintenance;

• Damages resulting from any other cause, bad maintenance or product misuse. In the case of a reasonable number of unsuccessful attempts to repair the product, covered by this guarantee, the manufacturer’s liability shall be limited to the replacement of the product as sole compensation for breach of the guarantee. Under no circumstances shall the manufacturer be liable for any special, accidental or consequential damages, on the grounds of breach of guarantee, breach

of agreement, negligence, or any other legal notion.

Waiver

This Guarantee shall contain the entire guarantee and shall be prevailing over any and all other guarantees, explicit or implicit (including any implicit guarantees on behalf of the dealer, or adaptability to specic purposes), and over any other responsibilities or liabilities on behalf of the manufacturer. The manufacturer does neither agree, nor empower, any person, acting on his own behalf, to

modify, service or alter this Guarantee, nor to replace it with another guarantee, or another liability with regard to this product.

Unwarranted Services

The manufacturer shall repair or replace unwarranted products, which have been returned to its factory, at its sole discretion under the conditions below. The manufacturer shall accept no products for which no prior notice has been received via the RAN form at:

http://www.teletek-electronics.com/en/support/Service

The products, which the manufacturer deems repairable, will be repaired and returned. The manufacturer has prepared a price list and those products, which can be repaired, shall be paid for by the Customer. The devices with unwarranted services carry 6 month guarantee for the replaced parts. The closest equivalent product, available at the time, shall replace the products, the manufacturer deems un-repairable. The cur-

rent market price shall be charged for every replaced product.

This manual contains information on limitations regarding product use and function and information on the limitations as to liability of the manufacturer.

The entire manual should be carefully read!

WARNING

The system is to be installed by a qualied person to the latest Fire Alarm and Installation Regulations which are mandatory in the applicable country of installation. Before commencing the installation of this Fire Alarm Panel, ensure it is sited in a position, which is visible to the Fire Brigade when entering the premises, and where ease of access is provided for users and service engineers. Space must be available to easily open external and internal doors. The Electrical Supply to the panel must be isolated and must not be capable of being accidentally switched off. A ‘Lockable Switch fuse Unit’ positioned within 2 meters of the panel should be clearly labelled FIRE

ALARM - DO NOT SWITCH OFF. EN 54-2 compatible panels.

All specications are subject to change without notice.

Technical Support help:

+359 (2) 9694 800

4 Fire Control Panel MAG2/4 - User Manual

1. Using the MAG2/4 control

Description of the front panels elements:



LED indication for the zones status: MAG2 - 2 zones MAG4 - 4 zones



Buttons for programming and operation, see item 1.5.



LED indication for the system status, see item 1.4.



LED indication for the technical troubles - see item 1.3.

Note: This indication is not visible for the user. To examine the technical troubles in the system, the engineer has to remove the front cover of the box.



Switch for changing over between Access Levels 1 and 2 - see item 1.6.

Front view MAG2 Front view MAG4

 

 

 

 

 

Fire Control Panel MAG2/4 - User Manual 5

1.1 Operation modes:

MODE Indication

Normal • The green LED next to the ‘power Supply 230V AC’ will be illuminated.

Fire

• The integrated red status FIRE LED and a zone identication LED will ash together on receipt of a FIRE condition and become steady after the

SILENCE ALARM button is pressed.

• An internal buzzer will operate until silenced with SILENCE BUZZER

button.

• The external sounders will operate.

• The FIRE relay on the main board will energize.

Fault

• The yellow GENERAL FAULT LED will always illuminate together with an external or internal identication LED.

• An internal buzzer will sound.

• The FAULT relay on the main will de-energize.

1.2 LED indication for the zones status:

ZONE LED Indication

Red • Fire alarm in the zone.

Yellow

• Zone fault - open or short circuit. Detector head removed.

• Zone test - the LED is blinking during the test procedure.

1.3 LED indication for the technical faults:

FAULT Fault description

○ µP Processor break down.

○ Sounder 1

Sounder Circuit One fault - open or short circuit, reverse

connected sounder, or bad sounder parameters.

○ Sounder 2

Sounder Circuit Two fault - open or short circuit, reverse

connected sounder, or bad sounder parameters.

○ +24V DC Overload Overload of “+24” VDC power supply.

○ +24V DC Failed Absence of “+24” VDC power supply.

○ Battery Low Low battery condition.

○ Battery Lost Battery loss.

○ AC Mains Supply loss.

○ Charger Battery charger fault.

○ AUX Auxiliary supply fault.

○ Earth Short circuit to earth.

Battery Low, Battery Lost and Charger LEDs are lighting up together in case of

overload of the battery charger output.
