Telestream Wirecast Gear User guide

User Guide

Wirecast Gear User Guide | 272965

July 2019

User Guide

The latest version of the Wirecast Gear User Guide is available at:

http://www.telestream.net/pdfs/user-guides/Wirecast-Gear-2-User-Guide.pdf

2.0

Preface 5

Introduction to
Wirecast Gear

3

Contents

9

Introduction 9
Overview 9

Wirecast Gear Models 9

Features 10
Unpacking Wirecast Gear 10
Registering Wirecast Gear 11
Specifications 11

Operating System Specifications 11

Software Specifications 11

Hardware Specifications 12

Wirecast Gear
Panels

Introduction 13
Front Panel 14
Rear Panel 15
Rear Panel Differences 16

13

Installation of
Wirecast Gear

19

Introduction 19
Physical Mounting 19
Connections 19

4

Conte nts

Using
Wirecast Gear

Introduction 23
Getting Started 23
First Time Boot 23

23

Troubleshooting
and Updating Wirecast Gear

Introduction 27
General 27
Drive Initialization 28
Windows Update Issues 29

Support for
Wirecast Gear

31

27

Introduction 31
Obtaining Support | Information | Assistance 31
Return Merchandise Authorization (RMA) Procedure 33

Support and RMA Process 33

Regulatory Compliance Statements 35

Introduction 35

Copyrights and Trademark Notices

Copyright 2019 Telestream, LLC. All rights reserved. No part of this publication may be
reproduced, transmitted, transcribed, altered, or translated into any languages without
written permission of Telestream, LLC. Information and specifications in this document
are subject to change without notice and do not represent a commitment on the part
of Telestream.

5

Preface

Telestream, CaptionMaker, Episode, Flip4Mac, FlipFactory, Flip Player, Gameshow,
GraphicsFactory, Lightspeed, MetaFlip, Post Producer, ScreenFlow, Split-and-Stitch,
Switch, Tempo, TrafficManager, Vantage, VOD Producer and Wirecast, are registered
trademarks and Cricket, e-Captioning, iQ, iVMS, iVMS ASM, Inspector, MacCaption,
Pipeline, Vidchecker, and Surveyor are trademarks of Telestream, LLC. All other
trademarks are the property of their respective owners.

Limited Warranty and Disclaimers

Telestream, LLC (the Company) warrants to the original registered end user that the
product will perform as stated below for a period of one (1) year from the date of
shipment from factory, unless the customer has purchased additional warranty periods.

The Product hardware components, including equipment supplied but not
manufactured by the Company but NOT including any third party equipment that has
been substituted by the Distributor for such equipment (the "Hardware"), will be free
from defects in materials and workmanship under normal operating conditions and
use.

Warranty Remedies

Your sole remedies under this limited warranty are as follows:

The Company will either repair or replace (at its option) any defective Hardware
component or part with new or fully functioning hardware components.

6

Preface

Components may not be necessarily the same, but will be of equivalent operation and
quality.

Software Updates

Except as may be provided in a separate agreement between Telestream and You, if
any, Telestream is under no obligation to maintain or support the Software and
Telestream has no obligation to furnish you with any further assistance, technical
support, documentation, software, update, upgrades, or information of any nature or
kind.

Note: Wirecast Gear includes 90 days of complimentary support on both hardware
and software.

Restrictions and Conditions of Limited Warranty

This Limited Warranty will be void and of no force and effect if (i) Product Hardware or
Software Media, or any part thereof, is damaged due to abuse, misuse, alteration,
neglect, or shipping, or as a result of service or modification by a party other than the
Company, or (ii) Software is modified without the written consent of the Company.

Limitations of Warranties

THE EXPRESS WARRANTIES SET FORTH IN THIS AGREEMENT ARE IN LIEU OF ALL OTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, WITHOUT LIMITATION, ANY
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. No oral
or written information or advice given by the Company, its distributors, dealers or
agents, shall increase the scope of this Limited Warranty or create any new warranties.

Geographical Limitation of Warranty—This limited warranty is valid only within the
country in which the Product is purchased/licensed.

Limitations on Remedies—YOUR EXCLUSIVE REMEDIES, AND THE ENTIRE LIABILITY OF
TELESTREAM, LLC WITH RESPECT TO THE PRODUCT, SHALL BE AS STATED IN THIS
LIMITED WARRANTY. Your sole and exclusive remedy for any and all breaches of any
Limited Warranty by the Company shall be the recovery of reasonable damages which,
in the aggregate, shall not exceed the total amount of the combined license fee and
purchase price paid by you for the Product.

Damages

TELESTREAM, LLC SHALL NOT BE LIABLE TO YOU FOR ANY DAMAGES, INCLUDING ANY
LOST PROFITS, LOST SAVINGS, OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES
ARISING OUT OF YOUR USE OR INABILITY TO USE THE PRODUCT, OR THE BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY, EVEN IF THE COMPANY HAS BEEN ADVISED OF

THE POSSIBILITY OF THOSE DAMAGES, OR ANY REMEDY PROVIDED FAILS OF ITS
ESSENTIAL PURPOSE.

Further information regarding this limited warranty may be obtained by writing:
Telestream, LLC
848 Gold Flat Road
Nevada City, CA 95959 USA

You can call Telestream, LLC via telephone at [phone].

Preface

7

8

Preface

Introduction

This section presents an overview of Wirecast Gear models, features, etc., and how to
unpack, setup, and register it. Specifications are also provided.

9

Introduction to

Wirecast Gear

Topics

 Overview
 Unpacking Wirecast Gear
 Registering Wirecast Gear
 Specifications

Overview

Wirecast Gear is an integrated solution for live production, streaming, video ingest and
more. It is designed to provide an easy to operate experience and is based on a
standard Windows personal computer.

Note: Consult the Wirecast User Guide included with Wirecast Gear. You can download
this user guide from the Telestream web site at:

http://www.telestream.net/telestream-support/wire-cast/help.htm

Wirecast Gear Models

Wirecast Gear is available in these models:

• 310 – 4x HDMI Capture: 1x QuickSync x264 Encode + Many MOV Encodes

• 320 – 4x SDI Capture: 1x QuickSync x264 Encode + Many MOV Encodes

• 420 – 5x SDI Capture + 1x SDI Output: 4x NVENC x264 Encodes + Many MOV

Encodes

10

Introduction to Wirecast Gear

Unpacking Wirecast Gear

Features

Note: Additional encodes possible but may require reduced workflow.

• Windows 10 Pro 64-bit OS

• 4 Port (SDI or HDMI) high quality video ingest

• Wirecast Pro

• Convertible mini case with rubber feet for table-top use and included rackmount

brackets for installing in approved flight/transport cases or in-place rack configura-

tions. Unit has no platter-based hard drives, making it ideal for transport

• Extensive source inputs including professional video connectors

• Multiple LAN ports, USB 3.1 (including Type C) and more

• USB 3.1 (including Type C) and more

• ISO recording with full Instant Replay capability

• Three (model 310/320) or four (model 420) digital video output ports for multiple

display configuration and on-site large format display outputs (IMAG) with lowest

latency including support for up to UHD/4K resolutions

• Live source processing including scaling, rotation, color correction and keying.

• Compatible with industry standard applications such as Adobe CC, Microsoft Office

and most standard Windows 10 compatible applications/utilities

• System Refresh allows quick recovery to factory settings in case of system corrup-

tion or failure. All Telestream loaded applications will be recovered (user applica-

tions must be reinstalled)

Unpacking Wirecast Gear

Unpack the contents of the shipping container; identify each component and
determine that it has arrived in satisfactory condition.

If there is shipping damage to the box, note it on your shipping documents and contact
the carrier immediately. If the computer or box contents are damaged in any way, you
should file a claim with the carrier and notify Telestream immediately.

Note: Save the shipping container and packaging materials and store them in a safe
place. If you require service—or move your Wirecast Gear — the packaging materials
should be used for safe shipment.

Shipping Container Contents

Each Wirecast Gear box contains the following:

• Wirecast Gear computer

• Wireless Keyboard/Mouse combo

• Power cord

• Plastic bag

Registering Wirecast Gear

Registering your Wirecast Gear system is a requirement to gain access to your licensed
copies of Telestream-bundled software. It also ensures the following:

Safety—so you'll be kept informed of product feature updates and improvements

Service—to receive the excellent Telestream warranty service and technical support

Security—in the event of loss, theft or catastrophic events, your registration may serve

as proof of purchase for your insurance carrier

Registration is quick, easy, and important—follow these steps:

1. Go to the Wirecast Gear registration web page: http://www.telestream.net/

telestream-support/Wirecast-Gear/register.htm

2. Complete the Wirecast Gear registration.

3. Click Submit to complete registration.

Introduction to Wirecast Gear

Registering Wirecast Gear

11

Specifications

The following topics summarize Wirecast Gear specifications.

CAUTION: Wirecast Gear is a sealed device, with no user-serviceable parts or user­accessible expansion slots. You should never open or attempt to upgrade or alter the
computer. Doing so exposes you to electrical hazard, may damage the unit, and may
invalidate your warranty. If you have hardware or software problems with your
Wirecast Gear, follow the steps in the Return Merchandise Authorization (RMA)

Procedure later in this guide to obtain service.

Operating System Specifications

Wirecast Gear is pre-installed with Windows 10 OS. Please see the Microsoft web site for
specifications.

Software Specifications

• Telestream Wirecast Pro application software

• Telestream Switch application software

• NewBlueFX Titler Live

12

Introduction to Wirecast Gear

Specifications

Hardware Specifications

• Intel Core XEON E-2176G 12M Six Core 3.7GHz/4.7GHz Turbo

• Intel UHD Graphics 630 (model 310/320)

• NVIDIA QUADRO (model 420)

• Memory - 16GB DDR4 Dual Channel Memory

• System Drive - M.2 NVMe System Drive

• Storage Drive(s) - High speed SATA 6Gb/s SSD

• Video Ingest - Four (model 310/320) or five (model 420) channel professional cam-

era inputs with HDMI or SDI

• Motherboard features
– Intel® USB 3.1 with USB Type-C™
– 115dB SNR HD Audio with Built-in Rear Audio Amplifier
– Dual Intel® GbE LAN RJ45
– PS/2 Keyboard/Mouse Port
– USB 3.0 Ports - 4 rear/2 front
– Display outputs - DVI-D, dual HDMI, dual DP (310/320), quad DP (model 420)

• Wireless Keyboard and Mouse combo

• Power Supply: AC input, auto-sensing, suitable for most countries worldwide
– Input Range: 90 ~ 264Vac (RMS), Full Range Input
– Frequency: 47 ~ 63Hz
– Input Current: Max 6A (RMS) @ 115Vac, 3A (RMS) @ 230Va

• Dimensions: 16.55 x 9.85 x 2.25 inches, 2.0 U rackmount height

Note: Wirecast Gear has no user-serviceable parts. Any repair or additional PCI card

installation must be performed by Telestream or an authorized Telestream service
technician.

Introduction

The following topics describe the Wirecast Gear front and rear panels.

13

Wirecast Gear

Panels

Topics

Note: Please do not make any connections just yet. First, read the panel and connector

descriptions and then proceed to the Installation of Wirecast Gear topic for steps to
install and connect to the unit.

Wirecast Gear is available in HDMI and SDI configurations. Both configurations share
the same front panel features, but each configuration has a unique rear panel. Wirecast
Gear 300 series models include 4-channel HDMI (310) or SDI (320) professional inputs.
Wirecast Gear 420 include five SDI capture inputs and one SDI output.

 Front Panel
 Rear Panel
 Rear Panel Differences

14

Wirec ast Gear Panels

Front Panel

Front Panel

Wirecast Gear has the following connectors on the front panel.

USB

Line Out

Mic In

Power Switch

USB 3.0 Ports The USB 3.0 port supports the USB 3.0 specification and is compatible to
the USB 2.0/1.1 specification. Use this port for USB devices.

Line Out) Use this output for headphones or a speaker system.

Mic In Use this input for Microphones. Many live producers choose to use a USB-based

external audio configuration with either a simple A/D device with professional
connectors or a full audio mixer panel for tactile control of audio levels. Contact the
reseller who sold you your Wirecast Gear unit for specific brand and model information.

Power Switch This button turns the power on and off. When on, a blue light is
displayed.

Rear Panel

The Rear Panel connectors have the following functionality.

Wirecast Gear Panels

Rear Panel

15

Audio Inputs

DVI-D Port

RJ-45 LAN Ports

USB Type-C™ Port

USB 3.0/2.0 Ports

Aux SDI In/Out ports
(Model 420 only)

Admin. Monitor

Line Out

Mic In

Audio Inputs Combination mic (XLR) and line (Quarter Inch Jack) audio inputs.

Aux SDI Input and Output Ports (Model 420 only) The SDI IN is the fifth input and

the SDI OUT is the single output.

USB 3.0/2.0 Port The USB port supports the USB 3.1 specification and is compatible to
the USB 3.0/2.0/1.1 specification. Use this port for USB devices.

USB Type-C™ Port The USB Type-C port supports the USB 3.1 specification and is
compatible to the USB 3.0/2.0/1.1 specification. Use this port for USB devices.

RJ45 LAN Ports The Gigabit Ethernet LAN port provides Internet connection at up to 1
Gbps data rate. The following describes the states of the LAN port LEDs.

DVI-D Port The DVI-D port conforms to the DVI-D specification and supports a
maximum resolution of 1920x1200@60 Hz (the actual resolutions supported depend
on the monitor being used). Connect a monitor that supports DVI-D connection to this
port.

16

Wirec ast Gear Panels

Rear Panel Differences

Note: The DVI-D port does not support D-Sub connection by adapter.

Admin. Monitor Computer monitor port for Administrator use only.

Line Out (Green) Line out jack. This jack supports audio amplifying function. For better

sound quality, it is recommended that you connect your headphone/speaker to this
jack (actual effects may vary by the device being used). Use this audio jack for a
headphone or 2-channel speaker. This jack can be used to connect front speakers in a
4/5.1/7.1-channel audio configuration.

Mic In (Pink) The Mic in jack. Microphones must be connected to this jack.

WARNING: When removing any mic cable, pull it straight out from the connector to
prevent causing a short inside the cable connector.

Rear Panel Differences

Depending on the Wirecast Gear model, four HDMI inputs (model 310), four SDI inputs
(models 320), or four SDI inputs and 4 Display Ports (model 420) are provided on the
right side of the rear panel. The location and numbering of inputs are shown below.

• Model 310 rear panel with HDMI Only

HDMI 1 HDMI 2 HDMI 3 HDMI 4

Model 320 rear panel with SDI only

SDI 1 SDI 2 SDI 3 SDI 4

Wirecast Gear Panels

Rear Panel Differences

17

Model 420 rear panel with DP and SDI

DP 1 DP 2 DP 3 DP 4

SDI 1 SDI 2 SDI 3 SDI 4

Connect the inputs to your video sources, such as cameras, DVD players, computers,
editors, graphics cards, and other devices that produce a video output that you want to
use as an input for live production.

18

Wirec ast Gear Panels

Rear Panel Differences

Introduction

This section shows you how to install Wirecast Gear. This includes physical mounting
and wireless connections.

19

Installation of

Wirecast Gear

Note: Before installing Wirecast Gear, read through the section on Wirecast Gear

Panels.

Topics

 Physical Mounting
 Connections

Physical Mounting

Wirecast Gear comes configured for table-top use with the included feet pre-attached.
The unique size and shape of Wirecast Gear is designed to occupy a minimum of space
while making connectors and cables easily accessible.

Also included with all Gear systems are two rack-mount "ears" and screws that allow the
system to fit into a standard 19-inch rack and take up 2 RU (Rack Units). This
configuration is useful for in-place racks and mobile flypacks where convenient and
safe transport of your live production system is required.

Note: The rack-mount configuration will require removal of rubber feet remove the
vent warning label on top of the unit, if desired. It is there to remind you to never block
the top of chassis air vents.

Connections

To make connections to your Wirecast Gear system, refer to Wirecast Gear Panels for
connector functions and locations, and then follow these steps.

20

Installation of Wirecast Gear

Connectio ns

Note: The Wirecast Gear system is configured to work with up to three displays.

1. If available, plug a network cable into one of the available RJ45 Ethernet jacks.

Note: After it is powered on, Wirecast Gear will attempt to automatically connect to

your installed network configuration (via LAN). If your network requires authentication
or specific configuration, please check with your network administrator to determine
computer and network setting requirements.

2. Plug HDMI or SDI cables into the video input connectors on the right rear panel.

3. Plug a standard computer monitor into either the DP (model 310/320) or DVI

(model 420) monitor output ports on the back of the unit.

Note: Every Wirecast Gear unit has two (model 310/320) or four (model 420) display
outputs and one DVI-D output. These are standard display outputs that are used for
connecting computer monitors. If you have more than one monitor installed, Wirecast
will allow you to send a full screen output of your program to the second display as a
program monitor. These are also the ports to be used for in-venue, presentation
displays (also known as IMAG) as they provide for the lowest latency output.

4. Make audio input and output connections to Line In, Mic In, Speaker Out.

5. Locate the USB dongles shipped with WC Gear 2.

Note: The mouse dongle communicates to both the mouse and the keyboard.

Installation of Wirecast Gear

Connections

6. Insert the USB dongle into a USB port on the front or back of the Wirecast Gear box.

Front USB ports

21

Rear USB ports

7. Turn the keyboard and mouse on, using the power switch on each.

8. After all connections have been made, plug in the attached power cord to provide

power to the unit. For input power requirements, see Specifications.

9. Turn on Wirecast Gear unit by pushing the power button on the front. The button
will light, and the unit will begin to boot up.

22

Installation of Wirecast Gear

Connectio ns

Introduction

This section shows you how to get started using Wirecast Gear and what to do when
you boot up for the first time.

23

Using

Wirecast Gear

Topics

 Getting Started
 First Time Boot

Getting Started

To get started using Wirecast Gear, follow these steps:

1. If you aren’t familiar with Wirecast, read the Wirecast User Guide. You can download
it from the Telestream web site at:

http://www.telestream.net/telestream-support/wire-cast/help.htm

2. Personalize Windows as explained in the First Time Boot topic below.

3. Create individual Windows user accounts on the Wirecast Gear machine, if desired.

You are now ready to start using Wirecast to stream your live presentations.

First Time Boot

Every Wirecast Gear unit includes a pre-activated copy of Windows 10 Pro 64-bit. There
is no need to enter a serial number or product key.

When you first power up Wirecast Gear, you are prompted to configure Windows for
your locale and personal preferences. The following screen shots explain this process:

24

Using Wirecas t Gear

First Time Boot

1. Select Location, Language and Time.

2. When the Microsoft License Acceptance displays, read and click Accept.

3. Unless you have a specific requirement, click Use Express settings.

Using Wirec ast Gear

First Time Boot

25

4. When the Create Account window displays, enter your user name and password

and click Next.

Note: If you do not have an account and do not want to create one, click Use Domain
then click Skip.

After a brief period of configuration, your Wirecast Gear will boot for the first time into
Windows 10.

26

Using Wirecas t Gear

First Time Boot

Introduction

This section shows you how to troubleshoot Wirecast Gear and how to get updates

27

Troubleshooting

and Updating

Wirecast Gear

Topics

General

 General
 Drive Initialization
 Windows Update Issues

If your Wirecast Gear computer does not operate as expected, the following tips may
provide assistance.

CAUTION: Wirecast Gear is a sealed device, with no serviceable parts and no internal
peripheral bays. Please do not open the chassis to try to diagnose the hardware failure
yourself, unless permitted to do so. This will void your warranty with Telestream and
our manufacturer.

• Close any programs (except Wirecast) that you are not using because other pro-

grams can take up too much memory.

• Save any work in progress, then close and reopen Wirecast.

• Restart the computer. Random problems can sometimes be resolved by a restart.

Be sure to save your work before you shut the computer down.

If you cannot resolve an issue yourself, see Obtaining Support | Information | Assistance.

28

Troubleshooting and Updating Wirec ast Gear

Drive Initialization

Drive Initialization

If you have received a Wirecast Gear unit and it is missing the secondary hard drive in
Windows, but you can see it in Disk Management (right click on the start button,
choose disk management), the drive is just in need of initialization.

To do this, follow these steps:

1. Open Disk Management, right click the partition you need to format (partition D),
then select Format.

2. In the pop-up window, set file system and cluster size, then click OK.

Your drive is now accessible in Wirecast and Windows.

Windows Update Issues

If you receive an question mark (?) with a yellow exclamation mark next to the capture
devices, you may be experiencing a Microsoft Windows update issue.

Microsoft issued a statement updates will cause Windows computers (including
Wirecast Gear) to lose their drivers to capture devices.Below is a link to an article that
further explains the Microsoft Windows update issue:

http://www.howtogeek.com/243581/windows-10-may-delete-your-programs­without-asking/.

Troubleshooting and Updating Wirecast Gear

Question Mark

29

Windows Update Issues

30

Troubleshooting and Updating Wirec ast Gear

Windows Update Issues

Introduction

This section shows you how to obtain customer support for Wirecast Gear and how to
make returns.

31

Support for

Wirecast Gear

Topics

 Obtaining Support | Information | Assistance
 Return Merchandise Authorization (RMA) Procedure

Obtaining Support | Information | Assistance

Support options for your Wirecast Gear are listed and briefly described below. Provide
your organization name, and contact information, and the serial number of the affected
unit. If the problem cannot be resolved remotely, request an RMA (Return Material
Authorization).

32

Support for Wirecast Gear

Obtaining Suppo rt | Information | Assistance

Support Resources Details and Contact Information

Reseller Support If you purchased your Wirecast Gear from a reseller and

did not also purchase GearCare Premium Support, please
contact your reseller for product support.

Telestream Wirecast
Gear Support

GearCare Premium
Support

Wirecast Information,
Assistance, FAQs,
Forums, & Upgrades

Telestream, LLC General
Information

Customers who bought Wirecast Gear directly from
Telestream may request support as outlined below.

• Support Web Site: http://www.telestream.net/

telestream-support/Wirecast-Gear/support.htm

• Support Email: [e-mail]

Terms and times of support services vary, per the terms of
your current service contract with Telestream.

Customers who bought GearCare Premium Support may
request support as outlined below. Includes a 3-year
extended warranty and overnight replacement.

• US Support Phone: [phone]

• International Support Phone: [phone]

• Support Email: [e-mail]

See also the web sites above and below.

• Wirecast Web Site: http://www.telestream.net/

telestream-support/wire-cast/support.htm

• Web Site: www.telestream.net

• Sales and Marketing Email: [e-mail]

Telestream Technical
Writers

Physical location and mailing address:

Telestream, LLC
848 Gold Flat Road
Nevada City, CA USA 95959

• Email: [e-mail]

Comments, corrections, or suggestions about this guide
and other Telestream guides are encouraged.

Support for Wirec ast Gear

Return Merchandise Authorization (RMA) Procedure

Return Merchandise Authorization (RMA)
Procedure

If your Wirecast Gear needs service of any kind, see Obtaining Support | Information |

Assistance on the previous page for contact information.

If you are instructed by Telestream Support to return your Wirecast Gear, follow the
procedure below. Please do not return a Wirecast Gear unit unless you receive an RMA
number from Telestream first.

Before returning your Wirecast Gear, Telestream recommends that you back up the
entire contents of all computer drives.

Support and RMA Process

1. Contact the reseller where your hardware was purchased for service. If you

purchased directly from Telestream or your unit is covered by Premium Support,
contact Telestream.

2. Telestream Support opens a support case for you.

3. Telestream Support follows an established drill-down to categorize the problem,

and determine a resolution path.

4. If the problem is beyond our initial level of Support, our representatives will access
and diagnose your device remotely. You will need to grant us Internet access to
your device.

5. Upon a failed hardware diagnosis, our representative escalates the case to an RMA
and gives you instructions for shipping the unit to our manufacturing partner for
repair.

6. The RMA process triggers a case with our manufacturing partner.

a. If you have Premium Support, the manufacturing partner gathers your shipping

and contact information and sends you an overnight replacement. The
manufacturer will also give you instructions and an RMA for returning the failed
unit.

b.If you do not have Premium Support, the manufacturing partner gives you

instructions and an RMA for returning the failed unit and gathers your return
shipping information. You are requested to ship the unit to our manufacturing
partner for repair and return to you.

7. Upon case resolution, Telestream Support reviews and closes the case and sends
you a satisfaction questionnaire.

8. We appreciate your business and ask you to return the questionnaire promptly so
that we can continue to improve the quality of our product support to you and our
other customers.

33

34

Support for Wirecast Gear

Return Merchandise Authorization (RMA) Procedure

Introduction

This section presents the Regulatory Compliance Statements for the Wirecast Gear
models 310, 320 and 420. It also includes European Union and European Fair Trade
Association Regulatory Compliance, along with Warning and Caution Messages

35

Regulatory

Compliance

Statements

Note: This section will be added after the compliance process has been completed.

36

Regulator y Compliance Statements

Introduction
